Agilent Technologies 8960 Series 10 E5515A,B Wireless Communications Test Set
Agilent Technologies E1960A GSM Mobile Test Application
Programming Guide
Test Application Revision A.04
© Copyright Agilent Technologies 1998, 1999
Printed in U.S.A. March 2000
Agilent Part Number: E1960-90002
Revision G
http://www.agilent.com/find/8960support/

Notice
Information contained in this document is subject to change without notice.
All Rights Reserved. Reproduction, adaptation, or translation without prior written
permission is prohibited, except as allowed under the copyright laws.
This material may be reproduced by or for the U.S. Government pursuant to the Copyright
License under the clause at DFARS 52.227-7013 (APR 1988).
Agilent Technologies, Inc.
Learning Products Department
24001 E. Mission
Liberty Lake, WA 99019-9599
U.S.A.

3
S:\Hp8960\E1960A GSM Mobile Test Application\A.04 Release\Proguide\programming_guide_front.fm
Safety, Warranty, and Regional Sales and
Service Offices Information

4
S:\Hp8960\E1960A GSM Mobile Test Application\A.04 Release\Proguide\programming_guide_front.fm
Safety, Warranty, and Regional Sales and Service Offices Information
Manufacturer’s Declaration
This statement is provided to comply with the requirements of the German Sound Emission Directive,
from 18 January 1991.
This product has a sound pressure emission (at the operator position) < 70 dB(A).
• Sound Pressure Lp < 70 dB(A).
• At Operator Position.
• Normal Operation.
• According to ISO 7779:1988/EN 27779:1991 (Type Test).
Herstellerbescheinigung
• Schalldruckpegel Lp < 70 dB(A).
• Diese Information steht im Zusammenhang mit den Anforderungen der
Maschinenlärminformationsverordnung vom 18 Januar 1991.
• Am Arbeitsplatz.
• Normaler Betrieb.
• Nach ISO 7779:1988/EN 27779:1991 (Typprüfung).

5
S:\Hp8960\E1960A GSM Mobile Test Application\A.04 Release\Proguide\programming_guide_front.fm
Safety, Warranty, and Regional Sales and Service Offices Information
Safety Considerations
GENERAL
This product and related documentation must be reviewed for familiarization with safety markings and
instructions before operation.
This product has been designed and tested in accordance with IEC Publication 1010, "Safety
Requirements for Electronic Measuring Apparatus," and has been supplied in a safe condition. This
instruction documentation contains information and warnings which must be followed by the user to
ensure safe operation and to maintain the product in a safe condition.
SAFETY EARTH GROUND
A uninterruptible safety earth ground must be provided from the main power source to the product
input wiring terminals, power cord, or supplied power cord set.
SAFETY SYMBOLS
Indicates instrument damage can occur if indicated operating limits are exceeded.
Indicates hazardous voltages.
Indicates earth (ground) terminal
WARNING A WARNING note denotes a hazard. It calls attention to a procedure, practice, or
the like, which, if not correctly performed or adhered to, could result in
personal injury. Do not proceed beyond a WARNING sign until the indicated
conditions are fully understood and met.
CAUTION A CAUTION note denotes a hazard. It calls attention to an operation procedure, practice,
or the like, which, if not correctly performed or adhered to, could result in damage to or
destruction of part or all of the product. Do not proceed beyond an CAUTION note until
the indicated conditions are fully understood and met.
!

6
S:\Hp8960\E1960A GSM Mobile Test Application\A.04 Release\Proguide\programming_guide_front.fm
Safety, Warranty, and Regional Sales and Service Offices Information
WARNING This product is a Safety Class I instrument (provided with a protective earthing
ground incorporated in the power cord). The mains plug shall only be inserted
in a socket outlet provided with a protective earth contact. Any interruption of
the protective conductor inside or outside of the product is likely to make the
product dangerous. Intentional interruption is prohibited.
Whenever it is likely that the protection has been impaired, the instrument
must be made inoperative and be secured against any unintended operation.
If this instrument is to be energized via an autotransformer (for voltage
reduction), make sure the common terminal is connected to the earth terminal
of the power source.
If this product is not used as specified, the protection provided by the
equipment could be impaired. This product must be used in a normal condition
(in which all means for protection are intact) only.
No operator serviceable parts in this product. Refer servicing to qualified
personnel. To prevent electrical shock, do not remove covers.
Servicing instructions are for use by qualified personnel only. To avoid
electrical shock, do not perform any servicing unless you are qualified to do so.
The opening of covers or removal of parts is likely to expose dangerous
voltages. Disconnect the product from all voltage sources while it is being
opened.
The power cord is connected to internal capacitors that my remain live for
5 seconds after disconnecting the plug from its power supply.
For Continued protection against fire hazard, replace the line fuse(s) only with
250 V fuse(s) or the same current rating and type (for example, normal blow or
time delay). Do not use repaired fuses or short circuited fuseholders.
Always use the three-prong ac power cord supplied with this product. Failure to
ensure adequate earth grounding by not using this cord may cause product
damage.
This product is designed for use in Installation Category II and Pollution
Degree 2 per IEC 1010 and IEC 664 respectively. FOR INDOOR USE ONLY.
This product has autoranging line voltage input, be sure the supply voltage is
within the specified range.
To prevent electrical shock, disconnect instrument from mains (line) before
cleaning. Use a dry cloth or one slightly dampened with water to clean the
external case parts. Do not attempt to clean internally.
Ventilation Requirements: When installing the product in a cabinet, the
convection into and out of the product must not be restricted. The ambient
temperature (outside the cabinet) must be less than the maximum operating
temperature of the product by 4° C for every 100 watts dissipated in the cabinet.
If the total power dissipated in the cabinet is greater than 800 watts, then forced
convection must be used.

7
S:\Hp8960\E1960A GSM Mobile Test Application\A.04 Release\Proguide\programming_guide_front.fm
Safety, Warranty, and Regional Sales and Service Offices Information
Product Markings
CE - the CE mark is a registered trademark of the European Community. A CE mark accompanied by a
year indicated the year the design was proven.
CSA - the CSA mark is a registered trademark of the Canadian Standards Association.
CERTIFICATION
Agilent Technologies, Inc. certifies that this product met its published specifications at the time of
shipment from the factory. Agilent Technologies further certifies that its calibration measurements are
traceable to the United States National Institute of Standards and Technology, to the extent allowed by
the Institute’s calibration facility, and to the calibration facilities of other International Standards
Organization members
WARRANTY
This Agilent Technologies instrument product is warranted against defects in material and
workmanship for a period of one year from date of shipment. During the warranty period, Agilent
Technologies, Inc. will at its option, either repair or replace products which prove to be defective.
For warranty service or repair, this product must be returned to a service facility designated by Agilent.
Buyer shall prepay shipping charges to Agilent and Agilent shall pay shipping charges, duties, and
taxes for products returned to Agilent from another country.
Agilent warrants that its software and firmware designated by Agilent for use with an instrument will
execute its programming instructions when properly installed on that instrument. Agilent does not
warrant that the operation of the instrument, or software, or firmware will be uninterrupted or error
free.
LIMITATION OF WARRANTY
The foregoing warranty shall not apply to defects resulting from improper or inadequate maintenance
by Buyer, Buyer-supplied software or interfacing, unauthorized modification or misuse, operation
outside of the environmental specifications for the product, or improper site preparation or
maintenance.
NO OTHER WARRANTY IS EXPRESSED OR IMPLIED. AGILENT SPECIFICALLY DISCLAIMS
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE.
EXCLUSIVE REMEDIES
THE REMEDIES PROVIDED HEREIN ARE BUYER’S SOLE AND EXCLUSIVE REMEDIES.
AGILENT SHALL NOT BE LIABLE FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES, WHETHER BASE ON CONTRACT, TORT, OR ANY OTHER LEGAL
THEORY.
ASSISTANCE
Product maintenance agreements and other customer assistance agreements are available for Agilent
Technologies products. For any assistance, contact your nearest Agilent Technologies Sales and Service
Office.

8
S:\Hp8960\E1960A GSM Mobile Test Application\A.04 Release\Proguide\programming_guide_front.fm
Safety, Warranty, and Regional Sales and Service Offices Information
European Contact: Your local Agilent Technologies Sales and Service Office or Agilent Technologies GmbH
Department ZQ/Standards Europe, Herrenberger Strasse 130,D-71034 Böblinger, Germany (FAX[phone])
DECLARATION OF CONFORMITY
according to ISO/IEC Guide 22 and EN 45014
Manufacturer’s Name: Agilent Technologies Inc.
Manufacturer’s Address: 24001 E. Mission Avenue
Liberty Lake, Washington 99019-9599
USA
declares that the product
Product Name: Agilent Technologies 8960 Series 10
Wireless Communications Test Set
Model Number: Agilent Technologies E5515A,B
Product Options: This declaration covers all options of
the above product.
conforms to the following Product specifications:
Safety: IEC 1010-1:1990+A1+A2 / EN 61010-1:1993
EMC: CISPR 11:1990/EN 55011:1991- Group 1, Class A
EN50082-1:1992
IEC 801-2:1991 - 4kV CD,8kV AD
IEC 801-3:1984 3V/m
IEC 801-4:1988 0.5 kV Sig. Lines, 1 kV Power Lines
Supplementary Information:
This product herewith complies with the requirements of the Low Voltage Directive
73/23/EEC and the EMC Directive 89/336/EEC
and carries the CE-marking accordingly.
Spokane, Washington USA November 20,1998
Vince Roland
Reliability & Regulatory
Engineering Manager

9
S:\Hp8960\E1960A GSM Mobile Test Application\A.04 Release\Proguide\programming_guide_front.fm
Safety, Warranty, and Regional Sales and Service Offices Information
Table 1. Regional Sales and Service Offices
United States of America:
Agilent Technologies
Test and Measurement Call Center
P.O. Box 4026
Englewood, CO 80155-4026
(tel) 1 800 452 4844
Canada:
Agilent Technologies Canada Inc.
5159 Spectrum Way
Mississaua, Ontario
L4W 5G1
(tel) 1 877 894 4414
Europe:
Agilent Technologies
European Marketing
Organization
P.O. Box 999
1180 AZ Amstelveen
The Netherlands
(tel) (3120) 547 9999
Japan:
Agilent Technologies Japan Ltd.
Measurement Assistance Center
9-1 Takakura-Cho, Hachioji-Shi,
Tokyo 192-8510, Japan
(tel) (81) 456-56-7832
(fax) (81) 426-56-7840
Latin America:
Agilent Technologies
Latin America Region
Headquarters
5200 Blue Lagoon Drive,
Suite #950
Miami, Florida 33126
U.S. A.
(tel) [phone]
(fax) [phone]
Australia/New Zealand:
Agilent Technologies
Australia Pty Ltd
347 Burwood Highway
Forest Hill, Wictoria 3131
(tel) 1 800 629 485
(Austrailia)
(fax) (61 3) 9272 0749
(tel) 0 800 738 378
(New Zealand)
(fax) (64 4) 802 6881
Asia Pacific:
Agilent Technologies
19/F, Cityplaza One,
111 Kings Road,
Taikoo shing, Hong Kong, SAR
(tel) (852) 2599 7899
(fax) (852) 2506 9233

10
S:\Hp8960\E1960A GSM Mobile Test Application\A.04 Release\Proguide\programming_guide_front.fm
Safety, Warranty, and Regional Sales and Service Offices Information

Contents
11
Introduction
Conventions Used in This Programming Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Purpose of This Programming Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
How This Programming Guide Is Organized . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
How to Use This Programming Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
About the Programming Examples Presented in This Programming Guide . . . . . . . . .16
Step 1: Set the Test Set’s Operating Mode to Active Cell
Background . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Overview of Active Cell Operating Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Setting the Test Set’s Operating Mode to Active Cell . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Step 2: Configure the Base Station Emulator (BSE)
Background . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Configuring the Broadcast Channel Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Configuring the Traffic Channel Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Things That Can Go Wrong . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Step 3: Configure the Measurement Execution Parameters
Background . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Configuring Measurement Averaging Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Configuring Measurement Triggering Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Configuring the Burst Synchronization Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Configuring Measurement Timeout Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Configuring Measurement Specific Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Step 4: Establish an Active Link with Mobile Station
Background . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Process for Making a Base Station Originated Call . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Process for Making a Mobile Station Originated Call . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Step 5: Set the Mobile Station’s Operating Conditions
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Step 6: Make Measurements
Background . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Things That Can Go Wrong . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Step 6a: Start Set Of Concurrent Measurements
Starting Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

12
Contents
Step 6b: Determine if a Measurement Is Done
Background . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Step 6c: Obtain a Set of Measurement Results
Background . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Step 7: Perform an Intra-Cell Handover
Background . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Performing an Intra-Cell Handover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Performing a Dual-Band Handover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Step 8: Disconnect the Mobile Station from the BSE
Background . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Terminating an Active Call from the Base Station Emulator . . . . . . . . . . . . . . . . . . . . 58
Terminating an Active Call from the Mobile Station . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Comprehensive Program Example
Example Program With Comments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Example Program Without Comments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

13
S:\Hp8960\E1960A GSM Mobile Test Application\A.04 Release\Proguide\Chapters\prog_prog_guide_intro.fm
Programming the Agilent Technologies 8960 Series 10 for GSM Mobile Testing in Active Cell Operating Mode
Programming the Agilent Technologies 8960
Series 10 for GSM Mobile Testing in Active Cell
Operating Mode

14
S:\Hp8960\E1960A GSM Mobile Test Application\A.04 Release\Proguide\Chapters\prog_prog_guide_intro.fm
Programming the Agilent Technologies 8960 Series 10 for GSM Mobile Testing in Active Cell Operating Mode
Introduction
Introduction
Conventions Used in This Programming Guide
Throughout this Programming Guide the term “test set” refers to an Agilent Technologies 8960 Series 10
wireless communications test set with the E1960A GSM mobile test application installed.
Purpose of This Programming Guide
The test set represents state-of-the-art technology in one-box-testers and contains many powerful test
capabilities which are accessible through easy-to-use GPIB programming commands. The purpose of this
Programming Guide is to teach you how to write a basic control program, using the test set’s GPIB command
set. This program will perform fundamental manufacturing tests on a GSM mobile station with the test set
operating in active cell mode.
How This Programming Guide Is Organized
The Programming Guide is organized around a typical set of tasks a control program would normally perform
when testing a GSM mobile station in a manufacturing environment. The set of tasks is shown in “Figure 1.
Typical Flow of Tasks Performed by Control Program” on page 15.
Typically in a manufacturing environment, steps 1, 2, and 3 are done once each time a production run is
started, steps 4 and 8 are done once for each mobile station tested during the production run, and steps 5, 6,
and 7 are done iteratively for each mobile station tested during the production run. The number of iterations
for steps 5, 6, and 7 is dependent upon how many mobile station operating conditions are being tested (that is,
number of channels, number of power levels, and so fourth).

15
S:\Hp8960\E1960A GSM Mobile Test Application\A.04 Release\Proguide\Chapters\prog_prog_guide_intro.fm
Programming the Agilent Technologies 8960 Series 10 for GSM Mobile Testing in Active Cell Operating Mode
Introduction
Figure 1. Typical Flow of Tasks Performed by Control Program
Step 5:
Set mobile station
operating conditions.
Step 4:
Establish active link
with mobile station.
No
Stop
No
Step 1:
Set test set’s operating
mode to active cell.
Step 2:
Configure base station
emulator (BSE).
Start
Step 7:
Perform
intra-cell handover.
Step 8:
Disconnect mobile
station from BSE.
Step 6c:
Obtain set of
measurement results.
Step 6b:
Determine if a
measurement
is done.
Step 3:
Configure measurement
execution parameters.
Step 6: Make measurements.
Step 6a:
Start set of concurrent
measurements.
Assign
mobile station
to new TCH?
All measurements done.
Yes
Yes

16
S:\Hp8960\E1960A GSM Mobile Test Application\A.04 Release\Proguide\Chapters\prog_prog_guide_intro.fm
Programming the Agilent Technologies 8960 Series 10 for GSM Mobile Testing in Active Cell Operating Mode
Introduction
How to Use This Programming Guide
This Programming Guide is divided into 9 sections. Sections 1 through 8 (step 1 through 8) should be read in
sequence. Each section, in order, discusses one of the tasks to be performed by the control program, showing
how to accomplish that task using the test set’s GPIB command set. As you progress through each section your
understanding of how the test set’s GPIB interface operates will increase as you see the control program
evolve.
The last section of the Programming Guide presents a “Comprehensive Program Example” on page 63 which
uses all of the topics discussed in sections 1 through 8 together in one program to give the programmer a sense
of how to tie everything together.
About the Programming Examples Presented in This Programming Guide
Programming Language:
Programming examples presented in this Programming Guide are written in the Rocky Mountain BASIC
programming language, also known as RMB.
Syntax Used in Programming Examples:
1. Programming examples use the shortened form of the command syntax to minimize GPIB bus transactions.
The shortened form of a command is defined by use of capital letters in the command syntax.
Example 1. Command Syntax:
CALL:STATus:TCHannel:TSLot?
Example 2. Shortened Form:
CALL:STAT:TCH:TSL?
2. Programming examples do not include default nodes. Default nodes in the command syntax are defined by
enclosing the node inside the [ ] brackets.
Example 3. Command Syntax:
CALL[:CELL[1]]:ACTivated[:STATe]<ON|1|OFF|0>
Example 4. Command Syntax without Default Nodes:
CALL:ACT <ON|1|OFF|0>
3. Programming examples make extensive use of compound commands using the ; and the ;: separators. Refer
to the test set’s reference information for information on the definition and use of these command
separators.

17
S:\Hp8960\E1960A GSM Mobile Test Application\A.04 Release\Proguide\Chapters\prog_prog_guide_step1.fm
Step 1: Set the Test Set’s Operating Mode to Active Cell
Step 1: Set the Test Set’s Operating Mode to Active Cell
Background
The test set contains a GSM base station emulator (BSE). The BSE’s primary purpose is to provide the GSM
call processing necessary for parametric measurements on the RF and audio signals of a GSM mobile station
(MS).
An important characteristic of the test set’s BSE is its operating mode. The operating mode sets the way in
which the BSE interacts with the mobile station. The BSE has two operating modes; active cell mode and test
mode.
Active cell mode is used when emulating a normal GSM cell. Test mode is used when it is not possible, or not
desired, to communicate with the MS via over-the-air signaling, but downlink stimulus and uplink
measurements are still needed.
This Programming Guide focuses on programming the test set’s BSE in active cell operating mode.
Overview of Active Cell Operating Mode
Active cell is the default operating mode of the test set’s BSE and is used when emulating a normal GSM cell
(that is, active signaling between the MS and the BSE).
Active Cell Features
The basic features provided by the BSE when the operating mode is set to active cell are:
• Generation of a BCH (broadcast channel) without TCH (traffic channel).
• Support for location updating.
• Call setup, both MS and BSE originated.
• Changing TCH parameters during a call using over-the-air signaling.
• BSE initiated and MS initiated call disconnection.
• All measurements supported in the test application are available.
• The BSE automatically controls the test set’s demodulation receiver.

18
S:\Hp8960\E1960A GSM Mobile Test Application\A.04 Release\Proguide\Chapters\prog_prog_guide_step1.fm
Step 1: Set the Test Set’s Operating Mode to Active Cell
Setting the Test Set’s Operating Mode to Active Cell
The test set’s operating mode is set using the CALL:OPERating:MODE command.
Example 1. Command Syntax:
CALL:OPERating:MODE <CELL|TEST>
Example 2. Programming Example:
!**********************************************************************
! Step 1: Set Test Set Operating Mode To Active Cell
!**********************************************************************
!
OUTPUT Test_set;”CALL:OPER:MODE CELL

19
S:\Hp8960\E1960A GSM Mobile Test Application\A.04 Release\Proguide\Chapters\prog_prog_guide_step2.fm
Step 2: Configure the Base Station Emulator (BSE)
Step 2: Configure the Base Station Emulator (BSE)
Background
The test set contains a GSM base station emulator (BSE). In active cell operating mode the BSE, using the
test set’s GMSK modulated source, generates a downlink (BSE to MS direction) broadcast channel (BCH)
which represents a cell. The MS can camp to this signal, just as it would camp to a cell on a real network. The
BSE can then page the MS on the BCH and listen to the response of the MS on the uplink (MS to BSE
direction), using the test set’s demodulating receiver. Calls can then be set up with the establishment of a
traffic channel (TCH) in both the downlink and uplink directions. Measurements can be made, using the
BSE’s measuring receiver, under essentially identical conditions to that which the MS would experience on a
real network.
The BS Emulator can emulate a cell in any one of the following GSM frequency bands:
• PGSM - Primary (band) GSM, also known as GSM900
• EGSM - Extension (band) GSM (includes PGSM)
• DCS - Also known as DCS1800
• PCS - Also known as PCS1900
NOTE The term GSM is used to refer to any combination of, or all of, the supported bands. It is not used
as a shortened term for PGSM.
The task of configuring the BSE consists of configuring the BCH and the TCH. There are numerous
parameters that can be configured for both the BCH and the TCH. It may not be necessary to configure all the
parameters all the time. The test set’s default settings should allow a properly functioning MS to successfully
camp on the cell under most circumstances.
In a manufacturing environment it may be desirable to explicitly configure the BCH and TCH parameters to
ensure that the settings have not been corrupted by someone setting a parameter’s value through the test set’s
front panel.

20
S:\Hp8960\E1960A GSM Mobile Test Application\A.04 Release\Proguide\Chapters\prog_prog_guide_step2.fm
Step 2: Configure the Base Station Emulator (BSE)
Configuring the Broadcast Channel Parameters
The broadcast channel parameters are configured using the CALL processing subsystem commands shown in
the following table.
Table 1. Broadcast Channel Settable Parameters
Parameter Command Syntax Footnote
Broadcast Band CALL[:CELL[1]]:BAND <PGSM|EGSM|DCS|PCS> 1
Cell Power CALL[:CELL[1]]:POWer[:AMPlitude]<numeric value>[<suffix>]
Cell Power State CALL[:CELL[1]]:POWer:STATe <ON|1|OFF|0>
Cell Power and State CALL[:CELL[1]]:POWer[:SAMPlitude]<numeric value>[<suffix>] 2
Cell BCH Number CALL[:CELL[1]]:BCHannel[:ARFCn][:SELected]<numeric value>
OR
CALL[:CELL[1]]:BCHannel[:ARFCn]:<PGSM|EGSM|DCS|PCS>
<numeric value>
3
Mobile Country Code CALL[:CELL[1]]:MCCode <numeric value> 4
PCS Mobile Country Code CALL[:CELL[1]]:PMNCode:VALue <numeric value> 4
Use PCS MNC CALL[:CELL[1]]:PMNCode:STATe <ON|1|OFF|0> 4
PCS Mobile Country Code
and Use PCS NMC State CALL[:CELL[1]]:PMNCode[:SVALue] <numeric value> 4, 5
Mobile Network Code CALL[:CELL[1]]:MNCode <numeric value> 4
Location Area Code CALL[:CELL[1]]:LACode <numeric value> 4
Network Color Code CALL[:CELL[1]]:NCCode <numeric value> 4
Base Station Color Code CALL[:CELL[1]]:BCCode <numeric value> 4
Paging IMSI CALL:PAGing:IMSI <string>
Repeat Paging State CALL:PAGing:REPeat[:STATe] <ON|1|OFF|0>
Paging Mode CALL:PAGing:MODE <NORMal | REORg> 7
Paging Multiframes CALL:PAGing:MFRames <numeric value>
Auto IMEI Request CALL:IMEI:AUTO <ON|1|OFF|0>
BA Table Entries CALL[:CELL[1]]:BA:TABle[:SELected][<numeric value>{,<numeric
value>}]
OR
CALL[:CELL[1]]:BA:TABle:<PGSM|EGSM|DCS|PCS> [<numeric
value>{,<numeric value>}]
6
