Agilent E5022A/B and E5023A Hard Disk Read/Write Test System
Operation Manual
27th Edition
Software Revision
This manual applies directly to system which has
the software revision B.04.00.
Part No. E5023-90090
January 2004
Printed in Japan
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2
Notices
The information contained in this document is subject to change without notice.
This document contains proprietary information that is protected by copyright.All rights
are reserved. No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of the Agilent Technologies, Inc.
Agilent Technologies Japan, Ltd.
Component Test PGU Kobe
1-3-2, Murotani, Nishi-Ku, Kobe-shi, Hyogo, 651-2241 Japan
Microsoft is a registered trademark of Microsoft Corporation.
Windows 95/2000 and Visual Basic are registered trademarks of Microsoft Corporation.
Acrobat Reader is a registered trademark of Adobe Corporation.
AgilentTechnologies Japan, Ltd. 1998-2004
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

3
Manual Printing History
The manual’s printing date and part number indicate its current edition. The printing date
changes when a new edition is printed. (Minor corrections and updates that are
incorporated at reprint do not cause the date to change.) The manual part number changes
when extensive technical changes are incorporated.
November 1998 1st Edition
January 1999 2nd Edition
May 1999 3rd Edition
June 1999 4th Edition
August 1999 5th Edition
August 1999 6th Edition
November 1999 7th Edition
December 1999 8th Edition
February 2000 9th Edition
April 2000 10th Edition
June 2000 11th Edition
July 2000 12th Edition
July 2000 13th Edition
October 2000 14th Edition
November 2000 15th Edition
December 2000 16th Edition
March 2001 17th Edition
June 2001 18th Edition
August 2001 19th Edition
August 2001 20th Edition
October 2001 21st Edition
February 2002 22nd Edition (part number: E5023-90040)
July 2002 23rd Edition (part number: E5023-90050)
September 2002 24th Edition (part number: E5023-90060)
January 2003 25th Edition (part number: E5023-90070)
March 2003 26th Edition (part number: E5023-90080)
January 2004 27th Edition (part number: E5023-90090)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

5
Safety Summary
The following general safety precautions must be observed during all phases of operation,
service, and repair of this instrument. Failure to comply with these precautions or with
specific WARNINGS elsewhere in this manual may impair the protection provided by the
equipment. In addition it violates safety standards of design, manufacture, and intended use
of the instrument.
The Agilent Technologies, Inc. assumes no liability for the customer’s failure to comply
with these requirements.
• Ground The Instrument
To avoid electric shock hazard, the instrument chassis and cabinet must be connected to
a safety earth ground by the supplied power cable with earth blade.
• DO NOT Operate In An Explosive Atmosphere
Do not operate the instrument in the presence of flammable gasses or fumes. Operation
of any electrical instrument in such an environment constitutes a definite safety hazard.
• Keep Away From Live Circuits
Operating personnel must not remove instrument covers. Component replacement and
internal adjustments must be made by qualified maintenance personnel. Do not replace
components with the power cable connected. Under certain conditions, dangerous
voltages may exist even with the power cable removed. To avoid injuries, always
disconnect power and discharge circuits before touching them.
• DO NOT Service Or Adjust Alone
Do not attempt internal service or adjustment unless another person, capable of
rendering first aid and resuscitation, is present.
• DO NOT Substitute Parts Or Modify Instrument
Because of the danger of introducing additional hazards, do not install substitute parts
or perform unauthorized modifications to the instrument. Return the instrument to
Agilent Technologies Sales and Service Office for service and repair to ensure that
safety features are maintained.
• Dangerous Procedure Warnings
Warnings, such as the example below, precede potentially dangerous procedures
throughout this manual. Instructions contained in the warnings must be followed.
WARNING Dangerous voltages, capable of causing death, are present in this instrument. Use
extreme caution when handling, testing, and adjusting this instrument.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6
• When you notice any of the unusual conditions listed below, immediately
terminate operation and disconnect the power cable.
Contact your local Agilent Technologies sales representative or authorized service
company for repair of the instrument. If you continue to operate without
repairing the instrument, there is a potential fire or shock hazard for the operator.
— Instrument operates abnormally.
— Instrument emits abnormal noise, smell, smoke or sparklike light during
operation.
— Instrument generates high temperature or electrical shock during operation.
— Power cable, plug or receptacle on instrument is damaged.
—Foreign substance or liquid has fallen into the instrument.
Warning
• Do not stick your fingers near the HLM- Spindle stage while it is moving as it may
cause injury to the operating personnel.
• Do not stick your fingers in shroud while the spindle is running.
• The furnished shroud does not provide protection from glass shards which can cause
death or serious injury. To prevent injury to the operating personnel use a safety cover
when you use glass media. Contact Agilent Technologies when you design a safety
cover.
Caution
• Strong magnetic fields exist in the X-Y stage drive motors. Keep magnetic devices
away from the motor to avoid damaging it.
• When applications such as VEE and Visual Basic is aborted abnormally or when the
reset button on the spinstand turns to red, you should remove the cassette first before
restarting. The cassette and spindle could bump into the shroud as the head moves to
home position during restarting.
Safety Symbol
General definitions of safety symbols used on the instrument or in manuals are listed
below.
Instruction Manual symbol: the product is marked with this symbol when it is necessary for
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

7
the user to refer to the instrument manual.
Alternating current.
Direct current.
On (Supply).
Off (Supply).
In position of push-button switch.
Out position of push-button switch.
Frame (or chassis) terminal. A connection to the frame (chassis) of the equipment which
normally include all exposed metal structure.
Do not stick your fingers.
WARNING This warning sign denotes a hazard. It calls attention to a procedure, practice,
condition or the like, which, if not correctly performed or adhered to, could result in
injury or death to personnel.
CAUTION This Caution sign denotes a hazard. It calls attention to a procedure, practice, condition or
the like, which, if not correctly performed or adhered to, could result in damage to or
destruction of part or all of the product.
NOTE Note denotes important information. It calls attention to a procedure, practice, condition or
the like, which is essential to highlight.
Certification
Agilent Technologies, Inc. certifies that the module and the spectrum analyzer and the
oscilloscope met its published specifications at the time of shipment from the factory.
Agilent Technologies further certifies that their calibration measurements are traceable to
the United States National Institute of Standards and Technology, to the extent allowed by
the Institution’s calibration facility, or to the calibration facilities of other International
Standards Organization members.
Documentation Warranty
The material contained in this document is provided "as is," and is subject to being
changed, without notice, in future editions. Further, to the maximum extent permitted by
applicable law, Agilent disclaims all warranties, either express or implied with regard to
this manual and any information contained herein, including but not limited to the implied
warranties of merchantability and fitness for a particular purpose. Agilent shall not be
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

8
liable for errors or for incidental or consequential damages in connection with the
furnishing, use, or performance of this document or any information contained herein.
Should Agilent and the user have a separate written agreement with warranty terms
covering the material in this document that conflict with these terms, the warranty terms in
the separate agreement will control.
Exclusive Remedies
The remedies provided herein are buyer’s sole and exclusive remedies. Agilent
Technologies shall not be liable for any direct, indirect, special, incidental, or
consequential damages, whether based on contract, tort, or any other legal theory.
Assistance
Product maintenance agreements and other customer assistance agreements are available
for Agilent Technologies products.
For any assistance, contact your nearest Agilent Technologies Sales and Service Office.
Addresses are provided at the back of this manual.
Typeface Conventions
Bold Boldface type is used when a term is defined. For
example: icons are symbols.
Italic Italic type is used for emphasis and for titles of
manuals and other publications.
Sample Program
A sample program is installed in the PC. The sample program list is described in the
programming manual.
The customer shall have the personal, non-transferable rights to use, copy, or modify
SAMPLE PROGRAMS in this manual for the Customer’s internal operations. The
customer shall use the SAMPLE PROGRAMS solely and exclusively for their own
purpose and shall not license, lease, market, or distribute the SAMPLE PROGRAMS or
modification of any part thereof.
Agilent Technologies shall not be liable for the quality, performance, or behavior of the
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

9
SAMPLE PROGRAMS. Agilent Technologies especially disclaims that the operation of
the SAMPLE PROGRAMS shall be uninterrupted or error free. The SAMPLE
PROGRAMS are provided AS IS.
AGILENT TECHNOLOGIES DISCLAIMS THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Agilent Technologies shall not be liable for any infringement of any patent, trademark,
copyright, or other proprietary rights by the SAMPLE PROGRAMS or their use. Agilent
Technologies does not warrant that the SAMPLE PROGRAMS are free from
infringements of such rights of third parties. However, Agilent Technologies will not
knowingly infringe or deliver software that infringes the patent, trademark, copyright, or
other proprietary right of a third party.
