Agilent Technologies Medalist i3070 Series User guide

©Agilent Technologies 2010 Medalist i3070 System Installation 1-1
System Installation
■Tools Required, 1-2
■Getting Started, 1-3
■Setting Up the Support Arm with Monitor, Keyboard,
and Mouse, 1-4
■Setting Up the Strip Printer, 1-15
■Preparing the Testhead, 1-16
■Powering the PDU and Controller, 1-19
■Installing a Support Bay and Instrument Rack, 1-21
■Enabling the Testhead, 1-25
■Verifying the Vacuum Subsystem, 1-28
■Verifying the Testhead, 1-32
■Completing the Installation, 1-33
■In Case of Difficulty, 1-34
CAUTION
;The Medalist In-circuit Test System should only
be installed by an Agilent-Authorized Service
Representative.
Testhead boot conflicts may occur if this system is
on a network with Medalist 3070 UNIX
controllers with IP addresses other than in the
10.3.112.XX series.
CAUTION
;The Medalist test development software requires
that decimals in the board file use a period (.) and
not any other character such as a comma. Make
use that Windows is set to use a period for
decimals. (Select Control Panel > Regional and
Language Options > Regional Options tab. Click
Customize; in the Numbers tab ensure that the
selected Decimal symbol is a period.)

©Agilent Technologies 2010 Medalist i3070 System Installation 1-2
Tools Required
Tools Required These tools are needed in addition to the tools supplied
with the system shipment:
■BNC-to-dual banana coaxial cable for Diagnostics
■BNC(F)-to-BNC(F) (barrel) connector for
Diagnostics
■Pin Verification Fixture (PVF) for Diagnostics
■T10 & T20 Torx drivers
■#2 Phillips or Posi screwdriver
■1/4-inch flat blade screwdriver
■5- and 10-mm hex key wrenches
■Diagonal-cutters to cut straps
■Utility knife to open boxes
■7/16-inch and 9/16-inch, 3/8-inch square-drive
sockets
■6-inch-long, 3/8-inch square-drive extension
■3/8-inch square-drive ratchet
■Cordless drill – 14.4 Volt, 3/8-inch drill / driver kit

©Agilent Technologies 2010 Medalist i3070 System Installation 1-3
Getting Started
Getting Started 1 Verify that site preparation is complete.
a View the customer’s completed Site Preparation
checklist.
b Obtain a copy of the system plan drawing.
2 Check for shipping damage.
If shipping damage is found, contact your local
Agilent representative.
3 Uncrate the system.
4 Check the system and the contents of all crates
and boxes against the order.
Check that:
■A support bay is included with four-module
systems to hold DUT power supplies.
■The strip printer and licenses are included.
■The bag on the testhead contains:
• a pod key,
• a probe cradle,
• a certificates of calibration,
• a certificate of hardware address for the System
Card, and
• configuration printouts.
■The bag on the testhead cradle contains:
• a female quick-disconnect compressed air
fitting, and
• an Installation Kit (it contains various tools and
parts).

©Agilent Technologies 2010 Medalist i3070 System Installation 1-4
Setting Up the Support Arm with Monitor, Keyboard, and Mouse
Setting Up the
Support Arm with
Monitor, Keyboard,
and Mouse
The default location for the controller’s monitor,
keyboard and mouse support arm is on the right side of
the testhead, when facing the testhead from the front.
If the preferred location of the support arm is on the left
side, the pod cover(s) must be removed, then the
monitor, keyboard and mouse wiring must be re-routed.
■Install the Support Arm, Monitor, Keyboard, and
Mouse, 1-5
■Adjust the Support Arm, 1-14
Safety Precautions
Pinch hazard locations when performing the following
procedures include the following.
Figure 1-1 Pinch hazard locations
This label on the machine indicates the location
of a pinch hazard that may cause minor or
moderate injury if the warning is ignored.
Do not place your fingers between
the collar and support arm when
adjusting the height of the arm.
Do not place your fingers between
the monitor support and the support
arm when rotating the support arm.
Do not place your fingers near the
hinges when moving the keyboard
tray up or down.

©Agilent Technologies 2010 Medalist i3070 System Installation 1-5
Setting Up the Support Arm with Monitor, Keyboard, and Mouse
Install the Support Arm, Monitor, Keyboard, and
Mouse
Follow the instructions in Table 1-1.
Table 1-1 Install the support arm, monitor, keyboard, mouse
Task
1 Remove the two shipping bolts.
Do this so that the testhead can be rotated. Figure 1-3 on page 1-13 shows the location of the shipping bolts.
CAUTION
;Remove the shipping bolts before attempting to rotate the testhead. Otherwise, damage can result.
Shipping bolts can be stored for later use in the holes used by the testhead pallet shipping brackets.
2 If the support arm will be installed on the left (non-default) side, follow the steps for this task. Otherwise, continue with
task 3.
CAUTION
;Before rotating the testhead, remove all objects from the rotational path of the testhead. Damage could
result if the testhead hits anything while being rotated.
Remove the pod cover:
a If testhead connectors (BNC) are visible over the pod cover, rotate the testhead about 10 degrees to allow the pod cover
to be removed.
Apply PDU power to activate the testhead rotation switch. See Powering the PDU and Controller on page 1-19.
b Use a T20 Torx driver to remove the pod cover screws and then remove the pod cover.
c Remove power to the PDU if connected.

©Agilent Technologies 2010 Medalist i3070 System Installation 1-6
Setting Up the Support Arm with Monitor, Keyboard, and Mouse
3 Install the pole mount assembly.
a Pry the plastic square plug (if present) from the column of the testhead cradle where the pole mount assembly will be
installed.
b Install the pole mount assembly in the column.
c Open the pod door (if installing on the right).
Secure the pole mount assembly to the cradle with the
screws and washers provided.
Table 1-1 Install the support arm, monitor, keyboard, mouse (continued)
Task

©Agilent Technologies 2010 Medalist i3070 System Installation 1-7
Setting Up the Support Arm with Monitor, Keyboard, and Mouse
4 Install support arm assembly.
a Position the safety collar on the pole mount assembly
and tighten the screw using the Allen key.
b Hold the support arm with both hands while moving it
down onto the collar on the pole mount assembly.
Tighten with the hand lever.
Table 1-1 Install the support arm, monitor, keyboard, mouse (continued)
Task
safety collar
hand lever

©Agilent Technologies 2010 Medalist i3070 System Installation 1-8
Setting Up the Support Arm with Monitor, Keyboard, and Mouse
5 Install the keyboard tray.
a Secure the keyboard tray to the support arm using the
four nuts and bolts provided.
Alternatively, you can attach the keyboard tray to the
support arm first.
Then flip the keyboard tray up before installing the
support arm on the pole mount assembly.
Table 1-1 Install the support arm, monitor, keyboard, mouse (continued)
Task
keyboard
tray
fasten with
nuts & bolts

©Agilent Technologies 2010 Medalist i3070 System Installation 1-9
Setting Up the Support Arm with Monitor, Keyboard, and Mouse
6 Install the monitor.
a Remove the four screws on the monitor stand and
remove the monitor stand.
b Secure the monitor onto the monitor support with the
screws provided. Tighten the screws by hand.
c To adjust the height of the monitor, loosen the screw on
the monitor support using an Allen key.
7 Install keyboard and mouse.
To position the mouse on the right, route the mouse and keyboard cables through the hole on the right side of the
keyboard tray. (Do the opposite to position the mouse on the left.)
Table 1-1 Install the support arm, monitor, keyboard, mouse (continued)
Task
monitor stand
loosen screw for
height adjustment
tighten screws to secure monitor (4 screws)

©Agilent Technologies 2010 Medalist i3070 System Installation 1-10
Setting Up the Support Arm with Monitor, Keyboard, and Mouse
8 Route the monitor, keyboard and mouse cables:
CAUTION
;If the cables are not routed with enough slack (between 130 - 150 cm), they can be damaged when the
support arm is moved.
NOTE
The keyboard and mouse have cables which are long enough to allow installation on the left side.
For two- and four-module systems, a second video monitor cable is pre-installed to accommodate support
arm installation on the left side. For one-module systems, the existing video monitor cable is long enough
to reach to the left side. Re-route it through the testhead cable troughs.
It may be necessary to obtain a 8120-1763 power cord extension cable to connect power from the PDU to
the video monitor. Route the power cable through the testhead cable trough.
Table 1-1 Install the support arm, monitor, keyboard, mouse (continued)
Task

©Agilent Technologies 2010 Medalist i3070 System Installation 1-11
Setting Up the Support Arm with Monitor, Keyboard, and Mouse
a Connect the cables to the monitor.
b Tuck the monitor, keyboard and mouse cables into the support arm. Use the cable ties and spiral wrap to secure the
cables as needed.
c Route the cables down the pole mount and through the cable trunking, then snap the cover onto the cable trunking.
d Connect the cables to the controller.
e Bundle the cables neatly behind the testhead and secure with cable ties.
9 Install the barcode scanner (if applicable).
Connect the barcode scanner cables as shown in Figure 1-2 and route the cable to the controller.
Table 1-1 Install the support arm, monitor, keyboard, mouse (continued)
Task
tuck and secure cables underneath the support arm
cable trunking cable trunking cover

©Agilent Technologies 2010 Medalist i3070 System Installation 1-12
Setting Up the Support Arm with Monitor, Keyboard, and Mouse
Figure 1-2 Connect barcode scanner cables
10 Tidy and secure all cables, using cable ties where necessary.
11 Replace pod cover and door (if applicable).
Close the pod door. Replace the pod cover and use a T20 Torx driver to tighten the pod cover screws.
Table 1-1 Install the support arm, monitor, keyboard, mouse (continued)
Task
connect to keyboard
keyboard extension
cable
connect to
controller

©Agilent Technologies 2010 Medalist i3070 System Installation 1-13
Setting Up the Support Arm with Monitor, Keyboard, and Mouse
Figure 1-3 Rear of testhead
cable trough
Shipping bolt and bracket at one of these
locations (on each side of testhead)

©Agilent Technologies 2010 Medalist i3070 System Installation 1-14
Setting Up the Support Arm with Monitor, Keyboard, and Mouse
Adjust the Support Arm
You can adjust the height of the support arm and also
rotate it. Always adjust the height before rotating it.
To raise the support arm
1 Loosen the hand lever on the support arm and raise
the arm to the desired height. Tighten the hand lever.
NOTE
Use both hands when moving the support arm:
one hand to hold the arm and the other to push the
monitor support backwards (Figure 1-4).
2 Use an Allen key to loosen the screw on the safety
collar and raise it until it touches the bottom of the
arm. Tighten the screw on the collar to support the
arm.
To lower the support arm
1 Use an Allen key to loosen the screw on the safety
collar and lower the collar out of the way.
2 Loosen the hand lever on the arm and lower the arm
to the desired height. Tighten the hand lever.
NOTE
Use both hands when moving the support arm:
one hand to hold the arm and the other to push the
monitor support backwards (Figure 1-4).
3 Raise the collar until it touches the bottom of the arm
and tighten the screw on the collar to support the
arm.
To rotate the support arm
Make sure that the hand lever on the arm and the safety
collar are firmly secured before rotation.
Figure 1-4 Use both hands for support
hand lever
safety collar

©Agilent Technologies 2010 Medalist i3070 System Installation 1-15
Setting Up the Strip Printer
Setting Up the Strip
Printer
Install the Strip Printer Tray
Unpack the strip printer tray and install it in the testhead
column opposite the monitor and keyboard.
A plastic cover may need to be pried out of the top of
the column first.
Install the Strip Printer
1 Unpack the strip printer and place it on the strip
printer tray.
2 Connect the pre-routed power and data cables.
NOTE
To install the strip printer on the left side, re-route
the power and data cables through the testhead
cable trough.

©Agilent Technologies 2010 Medalist i3070 System Installation 1-16
Preparing the Testhead
Preparing the
Testhead
This section contains:
■Install the Footswitch, 1-16
■Install the Probe and Probe Cradle, 1-17
■Install the Fixture Pull-Down Label - Non-English
Only, 1-17
■Attach the Site LAN Cable, 1-18
Install the Footswitch
NOTE
The footswitch must be connected to the system.
The footswitch must be pressed to lock fixtures on
the testhead.
1 Locate the footswitch and cable that are coiled on the
front of the testhead cradle (Figure 1-5).
2 Unpack the footswitch and place it on the floor in
front of the testhead.
Figure 1-5 Location of the footswitch
footswitch cable under
front of testhead cradle

©Agilent Technologies 2010 Medalist i3070 System Installation 1-17
Preparing the Testhead
Install the Probe and Probe Cradle
The probe cradle (Figure 1-6) is located on the pod
cover of the testhead as shipped from the factory. If the
customer wants the probe in a different location, an
extra strip of sticky-backed hook-and-loop fastener is
provided with the system so you can re-locate the probe
cradle.
WARNING
;Do not place the probe cradle where it could
interfere with an overhanging test fixture, thereby
presenting a pinch hazard between the fixture and
the probe cradle.
Do not place the probe cradle where it could
interfere with testhead rotation.
1 Peel the backing paper off the hook-and-loop
fastener and affix the fastener where the customer
wants the probe cradle to be (note the Warning
above).
2 Remove the probe cradle from its current location
and press it firmly onto the hook-and-loop fastener
you just installed.
3 Unpack the probe and insert it in the probe cradle.
Figure 1-6 Probe cradle
Install the Fixture Pull-Down Label - Non-English
Only
If installing the system in an English-speaking country,
skip this step.
1 Locate the Fixture Pull-down Air Labels.
2 Choose the label that is of the correct language for
the location and apply it over the English text that is
silk-screened on the rear of the testhead near the
compressed air connectors.

©Agilent Technologies 2010 Medalist i3070 System Installation 1-18
Preparing the Testhead
Attach the Site LAN Cable
If the system will be connected to a network, connect
the LAN cable from the RJ45 coupler at the rear of the
pod to the site network.
Figure 1-7 LAN cable and coupler
NOTE
The RJ45 coupler should be visible from the rear
of the controller’s pod. It should not be necessary
to remove the pod cover to attach the site LAN
cable.
RJ45 LAN cable
Coupler

©Agilent Technologies 2010 Medalist i3070 System Installation 1-19
Powering the PDU and Controller
Powering the PDU
and Controller
Supply Power to the PDU
CAUTION
;Disconnect testhead power before connecting or
disconnected testhead cables. Otherwise, damage
can result.
1 Connect the PDU power cable to the power source:
Instructions for connecting power are given in the
Site Preparation manual.
WARNING
;High Leakage Current — The safety ground in
most installation is included in the AC cord. The
system has a high leakage current therefore a
safety ground must be connected to the same
panel or location where the AC voltage is
connected. The safety ground in most installation
is included in the AC cord. A shock hazard can
arise if the AC input and the safety ground are not
grounded to the same point.
NOTE
The PDU is not serviceable; if it is defective, it
must be replaced.
WARNING
;DO NOT open the PDU for any reason.
Voltages capable of causing injury or death are
present inside the PDU, even with the switches
off.
2 Switch on the Mains Disconnect Switch:
The PDU has two switches, both of which are
accessible from the rear of the pod:
■One is the green Switched Circuits Enabled rocker
switch that enables power to the testhead – DO
NOT switch this one on yet.
■The other is the large, red rotary Mains Disconnect
Switch that enables power to the PDU outlets,
video monitor, and system controller – switch
only this one on now.

©Agilent Technologies 2010 Medalist i3070 System Installation 1-20
Powering the PDU and Controller
Switch on the Controller
1 Switch on the monitor.
2 Open the pod door and switch on the controller.
NOTE
A line of random characters may be printed on the
strip printer. This is normal and should be ignored.
NOTE
If the Windows registration key is needed, it can
be found on the testhead controller after removing
the pod cover.
Network Configuration
If the system will be connected to a network, configure
the network now or close the configuration window(s)
and set it up later.
Instructions for network configuration can be found in
System Administration in the on-line help.
Log on to Complete the Installation
Log on as calibrate, which allows system configuration
and testing. The default password is Agilent1.
