AGM GLT-14 User manual

14" LED Selfie
Ring Light
User Manual
Model: GLT-14

Thank you for purchasing this product. In order to get the best performance experience, please read
this manual carefully before use so that you can use it correctly.
Product overview: The ring light comes with a tripod and a mobile phone holder, which can help
when extra lighting is needed for makeup, taking pictures, recording videos, reading books and live
broadcasts.
Product structure: (as shown in the picture)

Package List：
①Inverted Folding Tripod:
④Adapter:
③Installation buckle:
②Ring light:

⑤Phone Holder with Pivot Mount:
⑥Remote Shutter:
⑦Remote control to adjust brightness:
Remote Shutter Instructions
Button B
Button A
LED
ON/OFF
Front Back
Battery Back
CT-
Auxiliary
Section
ON OFF
CT+
<
<
<
<

Product Features:
• The dimmable LED ring light has 3 lighting modes: white, warm yellow and warm white, which can
maintain long-lasting brightness. Each lighting mode has 10 adjustable brightness.
• Compatible with most smartphones, the width of the phone should be between 2.3 to 3.6 inches,
and it can be compatible with most smartphones with or without phone cases.
• The USB port can be used to connect USB chargers, power bank supplies, computer hosts and
laptops and other devices.
• The included wireless Bluetooth remote shutter can be connected to a mobile phone, allowing you
to control the device wirelessly and freely.
Function Features:
• The feet of the top tripod should be opened and extended to provide complete support on a flat
surface. When extending the height of the tripod, make sure the legs are fixed.
• The adjustable tripod pan/tilt allows you to find the best angle to illuminate the object, take photos or
broadcast live easily.
• Very suitable for creating real-time videos using smartphones, very suitable for blogs, real-time
video chat, social media, real-time streaming and beauty videos, etc.
Steps for usage:
1. Unfold the Inverted Tripod ①.
2. Install the Mounting Buckle ③on the tripod ①, and then tighten it.
3. Install the Ring Light ②fixed on the mounting buckle ③
4. Install the Phone Holder with Pivot Mount ⑤on the Ring Light ②
5. Fix the smartphone in the holder by opening the spring-adjusted flip cover. Do not use excessive
force.
6. Align the adapter to the power hole behind the ring light and use the plug to connect to the mains.
7. Turn on the power button of Remote Shutter (located on the side of the Remote Shutter ⑥), and
then turn on the smartphone' s bluetooth and search for "AB Shutter3" device (the indicator LED of
Remote Shutter flashes, and enter into"AB Shutter3".), the list and pairing will be completed
automatically within 1 second.
8. Turn on the power button of the Remote Control ⑦and select the lighting mode.
Product specification:
Outer diameter: 390mm
Magnetic bead type: 2835 0.5W
Number of lamp beads: 224pcs
Color temperature: 3000K~6500K
Brightness: 6000lm (lumens)
Color rendering index: 85Ra
Power supply: 30W
Package Size: 46.5 * 10 * 52cm
Power supply: DC 12V (2-3A)
Power cord length: 9.5 ft
Precautions:
● Keep this manual for future reference and maintenance only.
● Make sure not to replace the bulb when it is plugged into a socket or other power source.
● Do not open or change the internal wiring under any circumstances.
● Keep this product away from children.
● Clean the product with a soft dry cloth.
● This product can only be used under rated voltage and frequency.
● Do not try to change the power supply or adjust the voltage.

● Avoid pulling the power cord to unplug the power plug, and do not touch the power cord with wet
hands.
● Never try to insert any metal objects into the cooling holes of the illuminator.
● If the equipment is damaged, especially the power cord, please stop using the product.
● Do not use it in the rain, bath or near water sources.
● Please note that improper use or improper maintenance can cause fire or electric shock. For indoor
use only.
● All photos and illustrations are for reference only.
Technical Support
If possible, please review the troubleshooting steps provided in the manual first or visit our website as
normally they have a lot of information to solve the problem you might have. If all else fails and you
believe the product is defective, please contact us for details. For technical questions, product
information and to order spare parts, our service team is available to you as follows:
Service time: Monday to Friday from 9 a.m. to 6 p.m.
E-Mail: [email protected]
URL: http://www.agmlight.com
Please make sure that you have the following information on
hand.
· Operation manual
· Model number (this can be found on the cover of this manual)
· Description of the accessories
· Accessory number
· Proof of purchase with date of purchase
· Order number
IMPORTANT NOTE:
Please do not send your product to our address without unauthorization from our service team. The
costs and the risk of loss for unthorized return products, we reserve the right to refuse signing it.
