Agri-Fab 45-0260 User manual

• Safety
• Assembly
• Operation
• Maintenance
• Parts
42" Heavy Duty
LAWNSWEEPER
CAUTION:
Read Rules for
Safe Operation
and Instructions
Carefully
PRINTED IN U.S.A. FORM NO. 46814 (REV. 7/98)
OWNERS
MANUAL
Model No.
45-0260
190-163-100
190-163-190

2
6. Vehicle braking and stability may be affected with
the attachment of this sweeper. Do not fill sweeper to
maximum capacity without checking the capability of the
towing vehicle to safely pull and stop with the sweeper
attached. Stay off of steep slopes.
7. Stop and inspect vehicle and sweeper for damage after
striking an object.Repair any damage before continuing
operation.
8. Keep sweeper away from fire. Excessive heat can dam-
age the brushes and hopper bag and could cause the
bag and its contents to burn.
9. Before storing the sweeper, always empty the hopper
bag to avoid spontaneous combustion.
10. Follow maintenance and lubrication instructions as
outlined in the maintenance section of this manual.
1. Read the vehicle and sweeper owners manuals and
know how to operate your vehicle and sweeper before
using this sweeper attachment. Always instruct other
users before they operate the sweeper.
2. Do not permit children to operate sweeper.
3. Do not permit anyone to ride on sweeper.
4. Never attach the hopper rope to any part of your body
or clothing! Never hold onto the rope while towing the
sweeper! Attach the rope to the towing vehicle to keep
it away from wheels and rotating parts.
5. Operate the sweeper at reduced speed on rough ter-
rain, near ditches and on hillsides to prevent loss of
control.
Any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment.
Exercise caution at all times, when using power equipment.
MAINTENANCE..............................................................12
STORAGE.......................................................................12
SERVICE AND ADJUSTMENTS....................................13
TROUBLESHOOTING....................................................13
REPAIR PARTS EXPLOSION........................................14
REPAIR PARTS LIST.....................................................15
SAFETY RULES...............................................................2
FULL SIZE HARDWARE CHART.....................................3
CARTON CONTENTS......................................................4
SWEEPER ASSEMBLY INSTRUCTIONS........................5
HOPPER ASSEMBLY INSTRUCTIONS..........................7
KNOW YOUR SWEEPER...............................................11
HOW TO USE YOUR SWEEPER...................................11
Look for this symbol to point out important safety precautions. It means--Attention!!
Become alert!! Your safety is involved.
SAFETY
TABLE OF CONTENTS

3
REF. QTY. DESCRIPTION REF. QTY. DESCRIPTION
A B C D EF G HI
J
K
L
M
N
O
T
U
R
PQ
ZY AA BB CC
S
V
W X
SHOWN FULL SIZE
NOT SHOWN FULL SIZE
P 1 Flat Washer, 5/16" Std. Wrt.
Q 2 Flat Washer, 5/16" (Small)
R 6 Lock Washer, 5/16"
S 1 Lock Washer (Tooth), 5/16"
T 1 Hairpin Cotter, 1/8"
U 2 Hairpin Cotter, 3/32"
V 2 Clevis Pin, 1/4" x 1-1/2"
W 1 Spacer Bushing,
X 2 Hitch Spacer, 3/4"
Y 4 Hopper Mount Clamp
Z 2 Vinyl Cap
AA 1 Grip
BB 1 Knob, Plastic
CC 1 Hitch Pin
A 2 Hex Bolt, 5/16-18 x 3" Lg.
B 2 Hex Bolt, 5/16-18 x 2-1/4" Lg.
C 4 Hex Bolt, 5/16-18 x 1-3/4" Lg.
D 2 Hex Bolt, 1/4-20 x 1-1/4" Lg.
E 2 Hex Bolt, 3/8-16 x 3/4" Lg.
F 4 Hex Bolt, 5/16-18 x 3/4" Lg.
G 1 Carriage Bolt, 5/16-18 x 3/4" Lg.
H 6 Slotted Screw, #10-32 x 5/8" Lg.
I 2 Curved Head Bolt, 1/4-20 x 1" Lg.
J 2 Hex Lock Nut, 3/8"
K 8 Hex Lock Nut, 5/16"
L 4 Hex Nut (Plain), 5/16"
M 4 Hex Lock Nut, 1/4"
N 6 Hex Lock Nut, #10-32
O 2 Palnut, 3/8"
HARDWARE PACKAGE CONTENTS

4
CARTON CONTENTS (Loose Parts in Carton)
10. Hopper Bag
11. Windscreen
12. Upper Hopper Tube, R.H.
13. Upper Hopper Tube, L.H.
14. Lower Hopper Tube, R.H.
15. Lower Hopper Tube, L.H.
16. Hopper Bag Pivot Rod
17. Hopper Support Rod (2)
18. Bag Retaining Strap
19. Bag Frame Strap
1. Sweeper Housing Assembly
2. Bag Arm Tube (2)
3. Hitch Tube, L.H.
4. Hitch Bracket
5. Hitch Bracket (Straight)
6. Height Adjustment Strap
7. Height Adjustment Handle
8. Hitch Tube, R.H.
9. Rope
CARTON CONTENTS
REMOVAL OF PARTS FROM CARTON
Remove the sweeper, the loose parts and the hardware
package from the carton.Lay out the parts and hardware
as shown on pages 3 and 4.
1
2
3
4
5
6
7
8
2
9
10
11
12 13
14
15
16
17
18 19
ASSEMBLY

5
ASSEMBLY OF SWEEPER
TOOLS REQUIRED FOR ASSEMBLY
(1) Pliers
(1) Screwdriver
(1) Hammer
(1) Adjustable Wrench
(1) 9/16" Open End or Box End Wrench
(1) 7/16" Open End or Box End Wrench
(1) 1/2" Open End or Box End Wrench
(1) 3/8" Open End or Box End Wrench
Note: Right hand (R.H.) and left hand (L.H.) are determined
from the operators position while seated on the tractor.
1. Cut off the plastic tie holding the height adjustment tube
in place. See figure 1.
2. Assemble the R.H. and L.H. hitch tubes to the sweeper
housing using four 5/16" x 1-3/4" hex bolts, 5/16" lock
washers and 5/16" hex nuts. Do not tighten yet. See
figure 1.
FIGURE 1
5/16" LOCK
WASHER
5/16" x 1-3/4"
HEX BOLT
HITCH TUBE (L.H.)
PLASTIC TIE
5/16" HEX NUT
5/16" x 3"
HEX BOLT
5/16" LOCK
WASHER
5/16" HEX
LOCK NUT
SPACER
BUSHING
HEIGHT
ADJUSTMENT
STRAP
5/16" FLAT
WASHER
(SMALL)
FIGURE 2
If your tractor hitch has 10" to 13" ground clearance use
the instructions below to assemble the sweeper hitch
brackets. If your tractor hitch has less than 10" ground
clearance, go to page 6.
4. Assemble the bent hitch bracket on top and the straight
hitch bracket to the bottom of the hitch tubes.Fasten with
two 5/16" x 2-1/4" hex bolts and 5/16" hex lock nuts as
shown in figure 3. The bolts should straddle the front
hitch tube bolt. Do not tighten yet.
5. At this time tighten the four bolts fastening the hitch
tubes to the sweeper housing. Next, tighten the two
bolts fastening the hitch tubes together. Finally, tighten
the two bolts fastening the hitch brackets to the hitch
tubes.
6. Assemble the hitch pin, two 3/4" spacers and the 1/8"
hairpin cotter to the hitch brackets. See figure 3.
FIGURE 3
5/16" HEX LOCK NUT
HITCH BRACKET
(STRAIGHT)
HITCH
BRACKET
HITCH PIN
5/16" x 2-1/4"
HEX BOLT
3/4" SPACERS
1/8" HAIRPIN
COTTER
3. Place the spacer bushing into the hole in the height ad-
justment strap.Place the strap with the bushing between
the hitch tubes, aligned with the rear hole. Fasten the
hitch tubes together, with the strap and bushing between
them, using two 5/16" x 3" hex bolts, 5/16" flat washers
(smaller), 5/16" lock washers and 5/16" hex lock nuts.
Do not tighten yet. See figure 2.

6
FIGURE 6
5/16" x 1-5/8"
CURVED
HEAD BOLT
BOWED
WASHER
5/16" LOCK
WASHER
1/4" HEX NUT
5/16" HEX NUT
GRIP
HEIGHT
ADJUSTMENT
HANDLE
HEIGHT
ADJUSTMENT
TUBE
FIGURE 5
5/16" x 3/4"
CARRIAGE BOLT
5/16" TOOTH
LOCK WASHER
KNOB
5/16" FLAT
WASHER
(STD. WRT.)
HEIGHT
ADJUSTMENT
HANDLE
HEIGHT
ADJUSTMENT
STRAP
10. Assemble the height adjustment handle to the height
adjustment tube using the curved bolts, washers and
nuts which come pre-assembled to the tube.Tighten the
height adjustment handle so that the height adjustment
strap is aligned with the outside of the handle.See figure
5.
11. Assemble the grip onto the end of the height adjustment
handle as shown in figure 5.
If your tractor hitch has 8" to 10" ground clearance,
use the instructions below to assemble the sweeper
hitch brackets. If your tractor hitch has more than 10"
ground clearance, refer back to page 5.
7. Assemble the bent hitch bracket to the bottom and the
straight hitch bracket on top of the hitch tubes. Fasten
with two 5/16" x 2-1/4" hex bolts and two 5/16" hex lock
nuts as shown in figure 4.The bolts should straddle the
front hitch tube bolt. Do not tighten yet.
8. At this time tighten the four bolts fastening the hitch
tubes to the sweeper housing. Next, tighten the two
bolts fastening the hitch tubes together. Finally, tighten
the two bolts fastening the hitch brackets to the hitch
tubes.
9. Assemble the hitch pin, two 3/4" spacers and the
1/8" hairpin cotter to the hitch brackets. See figure 4.
12. Place the 5/16" tooth-lock washer between the height
adjustment handle and the height adjustment strap.
Insert the 5/16" x 3/4" carriage bolt through the handle,
the tooth-lock washer and the strap.Assemble the 5/16"
Std. Wrt. washer and the plastic knob onto the end of
the bolt and tighten. See figure 6.
FIGURE 4
5/16" HEX
LOCK NUT
HITCH PIN
HITCH
BRACKET
5/16" x 2-1/4"
HEX BOLT
HITCH
BRACKET
(STRAIGHT)
HAIRPIN COTTER
3/4" SPACERS

7
1/4" x 1"
CURVED HEAD BOLT
LOWER
HOPPER
TUBE
1/4 " HEX LOCK NUT
4. Assemble the two lower hopper tubes together using a
1/4" x 1" curved head bolt and a 1/4" hex lock nut. See
figure 10.
ASSEMBLY OF HOPPER BAG
1. Insert the left hand upper hopper tube through the
stitched flaps of the hopper bag, starting at the
center cut out in the top of the bag. See figures
7, 8 and 9. Repeat for the right hand upper hopper
tube.
5. Place the assembled lower hopper tubes into the bottom
of the hopper bag as shown in figure 11.
6. Assemble the ends of the upper and lower hopper tubes
together using two 3/8" x 3/4" hex bolts (on the inside)
and two 3/8" hex lock nuts (on the outside). Tighten to
allow bag to pivot freely. See figure 11.
FIGURE 9
1/4" HEX LOCK NUT
1/4" HEX LOCK NUT
1/4" x 1" CURVED HEAD BOLT
FIGURE 11
LOWER HOPPER TUBE
HOPPER BAG
BOTTOM
UPPER
HOPPER
TUBE
3/8 " HEX LOCK NUT
(OUTSIDE)
3/8" x 3/4" HEX BOLT
(INSIDE)
FIGURE 8
FIGURE 10
UPPER
HOPPER
TUBES
2. Slide the two upper hopper tubes together and line up
the center holes as shown in figure 8.
Right Left
BAG FLAP
UPPER HOPPER TUBE
(LEFT HAND SHOWN)
END HERE
CENTER CUT OUT
(START HERE)
FIGURE 7
3. Fasten the upper hopper tubes together using a 1/4" x
1" curved head bolt and a 1/4" hex lock nut. See figure
9.

8
FIGURE 14
IMPORTANT: Do not over bend the support rods during
the following step. Over bending will cause the spring steel
rods to loose supporting tension.
10. Assemble the two hopper support rods as shown in
figure 15. Place end of rod into hole in upper hopper
tube and bend rod just enough to fit bottom end of rod
into hole in bottom hopper tube.
8. Assemble the frame strap to the lower hopper tube us-
ing two 1/4" x 1-1/4" hex bolts and 1/4" hex lock nuts.
See figure 13.
7. Assemble the bag retainer and the bag frame strap to
the front edge of the bag bottom. Place the bag retainer
on top and the bag frame strap underneath the bag bot-
tom. Fasten retainer and strap together using six #10 x
5/8" slotted screws and #10-32 hex lock nuts.See figure
12.
FIGURE 17
#10-32 HEX
LOCK NUT
FRAME STRAP
FRONT EDGE OF BAG BOTTOM
#10-32 x 5/8" SCREW
BAG RETAINER
FIGURE 12
FIGURE 13
1/4" x 1-1/4" HEX BOLT
(OUTSIDE)
LOWER
HOPPER
TUBE
1/4" HEX
LOCK NUT
FRAME STRAP
9. Secure the bag corners over the lower hopper tube by
snapping the flap to the bag bottom on both sides. See
figure 14.
SNAP
FLAP
12. Assemble a vinyl cap onto each bag arm tube as shown
in figure 17.
FIGURE 16
FIGURE 15
SUPPORT RODS
11. Locate (by touch) the hole in each upper hopper tube.
Pierce holes through the stitched bag flaps, aligned with
the located holes in both hopper tubes. See figure 16.
UPPER HOPPER TUBE
VINYL CAP

9
FIGURE 19
13. Slide the hopper bag pivot rod through the side of an
upper hopper tube where the hole was pierced.
Assemble onto the rod a mounting clamp, two bag arm
tubes and another mounting clamp as shown in figure
18. Push the rod on through the upper hopper tube on
the opposite side of the bag.
16. Secure the rope to the top center of the hopper bag
frame as shown in figure 20.
FIGURE 18
5/16" x 3/4"
HEX BOLT
5/16" HEX
LOCK NUT
PALNUT
MOUNTING CLAMP
14. Assemble the two remaining hopper mount clamps onto
the pivot rod on the outside of the bag. Fasten them to
the inside clamps using four 5/16" x 3/4" hex bolts and
5/16" hex lock nuts. Tighten securely. See figure 19.
15. Assemble two palnuts by lightly tapping them onto the
ends of the pivot rod with a hammer. See figure 19.
HINT: To ease assembly of the palnuts, place the bag on
its side on a hard surface. With the bottom end of the
pivot rod against the surface, tap a palnut onto the top
end of the rod. Repeat for other end of rod.
1/4" x 1-1/2"
CLEVIS PIN
3/32" HAIRPIN
COTTER
HITCH TUBE
HITCH TUBE
BAG ARM TUBE
FIGURE 22
FIGURE 20
18. To assemble the hopper bag to the sweeper, slide the
ends of the bag arm tubes into the ends of the hitch
tubes and secure with two 1/4" x 1-1/2" clevis pins and
3/32" hairpin cotters. See figure 22.
17. Assemble the wind screen to the hopper bag frame by
snapping the screen's four corners loops around the
frame's upper hopper tubes. See figure 21.
UPPER
HOPPER
TUBE
WIND SCREEN
SNAP
LOOP
FIGURE 21
MOUNTING CLAMP
BAG ARM TUBE
PIVOT ROD

10
ATTACHING SWEEPER HITCH TO TRACTOR
1. Place the tractor and sweeper on a flat level surface.
2. Set the sweeper height adjustment handle to about the
middle of its adjustment range.
3. Attach the sweeper hitch to the tractor hitch, arranging
the 3/4" spacers into one of the six possible combinations
shown in GROUP A and GROUP B diagrams below.
IMPORTANT: To obtain the best performance from your
sweeper, arrange the spacers so that the sweeper bag is
approximately level with the ground and approximately 5"
to 7" off the ground as shown in figure 23.
GROUP "B" - For vehicles with hitch-
es having 10" to 13" ground clearance.
GROUP "A" - For vehicles with hitch-
es having 8" to 10" ground clearance.
BLACK LINE IS TRACTOR HITCH
HITCH BRACKET MOUNTED
BELOW HITCH TUBES
BLACK LINE IS TRACTOR HITCH
HITCH BRACKET MOUNTED
ABOVE HITCH TUBES
FIGURE 23
APPROXIMATELY LEVEL
(5" to 7" FROM SURFACE)
BRUSH HEIGHT ADJUSTED
APPROXIMATELY MID-WAY

11
KNOW YOUR SWEEPER
Hopper Bag Collects grass clippings, leaves and debris.
Hopper Rope Permits dumping of hopper bag from the drivers seat.
Windscreen Helps prevent collected material from being blown out of hopper bag.
Bag Arm Tubes Connects the hopper bag to the sweeper housing.
Pivot Rod Allows hopper bag to tilt forward to dump material.
Height Adjustment Handle Adjusts the operating height of the sweeper.
Height Adjustment Strap Holds the height adjustment handle in position when locked.
Knob Locks the height adjustment handle to the height adjustment strap.
Hitch Bracket Connects the sweeper to the towing vehicle. Adjusts for various height tractor hitches.
HOW TO USE YOUR SWEEPER
BRUSH HEIGHT ADJUSTMENT
To adjust your sweeper brushes to the best operating
height, loosen the adjustment knob and push down
on the height adjustment lever to raise the brush. See
figure 23. Best adjustment is when the brush setting is
1/2" down into the grass. Always mow the grass to an
even height before sweeping.
SWEEPING SPEED
Try a starting speed of approximately 3 m.p.h. (third
gear on most tractors). Depending on the conditions,
it may be necessary to adjust the sweeping speed in
order to achieve best results.
CAUTION: Keep sweeper away from fire. Exces-
sive heat can damage the brushes and hopper
bag and could cause the bag and its contents to
burn.
CAUTION: Never attach the hopper rope to any
part of your body or clothing! Never hold onto
the rope while towing the sweeper! Attach the
rope to the towing vehicle to keep it away from
wheels and rotating parts.
DUMPING OF SWEEPER
Your sweeper can be dumped easily without getting off of
the rider or tractor. Simply pull the rope forward to dump
the hopper. Always empty hopper after each use.
HOPPER BAG
WINDSCREEN
BAG ARM TUBE
PIVOT ROD HEIGHT
ADJUSTMENT
HANDLE
KNOB
HITCH
BRACKETS
HEIGHT
ADJUSTMENT
STRAP
HEIGHT
ADJUSTMENT
STRAP
HOPPER
ROPE
OPERATION

12
MAINTENANCE SCHEDULE
Fill in dates as you
complete regular service.
Check for loose fasteners X
Check for worn or damaged parts X X
Lubricate brush shaft bearings X
Lubricate wheel bearings X
Clean Sweeper X X
Clean/Lubricate gears X
Before each use
After each use
Twice a year
Every season
Before storage
Every two years
Service Dates
CUSTOMER RESPONSIBILITIES
Read and follow the maintenance schedule and the
procedures listed in the maintenance section.
SCHEDULED MAINTENANCE
1. Clean the sweeper after each use.
Inspect for worn or damaged parts, such as brushes
and wheels.
2. Lubricate the brush shaft bearing twice a year with a
few drops of light weight oil. See figure 24.
FIGURE 24
3. Every two years, remove the wheels and clean the
gears found inside the wheel housing. After cleaning,
lubricate with an even coat of light grease. To remove
the wheel, pop off the hub cap using a screwdriver and
remove the lock nut and flat washer. See figure 25.
CLEANING
1. Clean sweeper housing with a soft brush or cloth.
2. Clean debris from hopper bag with a brush or broom.
3. Remove any material which has wrapped around brushes
or ends of brush shaft.
FIGURE 25
HEX BOLT FLAT WASHER
FLAT WASHER
HEX LOCK NUT
HUB CAP
SPACER
HEIGHT ADJUSTMENT SLOT
HEX BOLT
OIL BEARINGS HERE
FLAT WASHER
1. Clean the sweeper and hopper bag thoroughly to help
prevent rust and mildew.
2. To collapse the hopper bag for storage, remove the two
hopper support rods from the rear of the hopper.
3. Store in a dry area.
CAUTION: Before storing the sweeper,
always empty the hopper bag to avoid
spontaneous combustion.
STORAGE
MAINTENANCE

13
WHEEL GEAR AND PAWL SERVICE
IMPORTANT: Do not remove both wheels at the same
time to avoid mixing of parts. (The R.H. and L.H. ratchet
gears are not interchangeable.) Make notes on the position
of washers and snap rings during disassembly.
1. Remove one wheel from the sweeper.
2. Remove the retaining rings and washers which hold the
ratchet gear onto the brush shaft.
3. Remove the gear by sliding it off the brush shaft. (Look
for the pawl, which may fall out of the brush shaft when
the ratchet gear is removed.) See figure 27.
4. To reassemble, insert the pawl through the rectangular
hole in the brush shaft. Make sure the pawl is turned so
that the flat side of the pawl will press against the flat
side of the internal teeth in the ratchet gear.
5. Lightly grease the shaft and fill the ratchet gear with
grease. Assemble the ratchet gear back onto the
shaft.
6. Lightly grease the axle and the wheel's gear teeth and
then reassemble the wheel. The brushes should rotate
only during forward rotation of the wheel. If the brushes
are driven (rotated) by both forward and reverse rotation
of the wheel, the pawl is assembled incorrectly and must
BRUSH REPLACEMENT
NOTE: Brush replacement should be done one brush at
a time.
1. Remove the hopper bag from the sweeper.
2. Loosen the hex bolts and lock nuts on two single brush
retainers which clamp one brush to the double brush
retainers. Do Not loosen or remove the bolts which
fasten the double brush retainers to the brush shaft.
See figure 26.
3. Slide the brush out of the retainers, noting on which
side of the brush the bristles overlap. See figure 26.
4. Install new brush, making sure the bristles overlap on
the same side of the brush as before. See figure 26.
BRUSH ROTATION
BRUSH ROTATION
OVERLAP
BRISTLES
OVERLAP
BRISTLES
SINGLE
BRUSH
RETAINERS
DOUBLE BRUSH RETAINER
BRUSH
SHAFT
1. Brushes set too low.
2. Brushes are jammed
3. Wheels are jammed.
Wheels skid when sweeping. 1. Adjust height till brushes are 1/2"
down into grass.
2. Stop sweeper. Remove obstruction.
3. Remove one wheel at a time to check
for obstruction or damage. Refer to
Service and Adjustments section.
FIGURE 26
FIGURE 27
RATCHET
GEAR
PAWL
SERVICE AND ADJUSTMENTS
TROUBLESHOOTING

14
REPAIR PARTS FOR MODEL 45-0260 - 42" LAWNSWEEPER
A
C
A
A
B
B
C
D
D
1
2
3
4
5
6
7
7
7
8
9
10
11
12
13
14
15
15
15
15
16
16
17
18 19
20
21
22
23
23
23
23
23
24
25
26
26
27
28
29
29
29
29
30 31
32
33
33
35
36 37
38
39 41
42
43
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
58
59
60
61
60
61
64
63
62
65
66 67
68
69
70
71
72
73
74
75
75
76
77
77
78
78
79
80
81
82
83
84
84
85
86
34 34
87

15
REF. PART QTY. DESCRIPTION
NO. NO.
1 46776 1 Hitch Tube, R.H.
2 46777 1 Hitch Tube, L.H.
3 24182 1 End Plate, R.H.
4 24183 1 End Plate, L.H.
5 24184 1 Wrapper
6 43175 2 Bolt, Hex 1/4-20 x 1/2" Lg.
7 C-9M5732 26 Rivet, Pop
8 24185 1 Brace, Rear Support
9 46778 1 Skirt, 42"
10 24186 1 Retainer, Skirt
11 23336 2 Washer, Special
12 63463 1 Height Adjustment Tube Ass'y.
13 44947 2 Bolt, Cvd. Hd. 5/16-18 x 1-5/8" Lg.
14 44695 2 Washer, Bowed 1" x .32" x .06"
15 43086 12 Lock Washer, 5/16"
16 43083 6 Nut, Hex 5/16-18 Thread
17 R19212113 2 Washer, 5/8" SAE
18 1629-56 2 Retainer, Dust Cover
19 44910 2 Bushing, Brush Shaft
20 24188 1 Brush Shaft
21 46780 4 Brush, 42"
22 43012 8 Bolt, Hex 1/4-20 x 3/4" Lg.
23 43013 18 Nut, Hex Lock 1/4-20 Thread
24 23580 4 Retainer, Brush (Double)
25 23581 8 Retainer, Brush (Single)
26 44008 2 Washer, Flat 1-1/8" x .78" x .025"
27 1671-1 2 Pawl
28 44692 4 Bolt, Hex 5/16-18 x 1/2" Lg.
29 43064 12 Nut, Hex Lock 5/16-18 Thread
30 44911 2 Spacer,.39 I.D". x 1-1/4" O.D. x .5"
31 44006 2 Washer, Flat .849" x .598" x .025"
32 46219 2 Spacer,.78 I.D". x 1-1/4" O.D. x .5"
33 1650-21 4 Ring, Retaining .594"
34 44007 6 Washer,Shim 1-1/8"x.594" x .025"
35 141 2 Washer, Flat 1-1/2"x .375" x .062"
36 1038 2 Nut, Hex Lock 3/8-24 Thread
37 2674-32 2 Hub Cap
38 44961 2 Bolt, Hex 3/8-24 x 3-1/4" Lg.
39 23400 2 Bushing, Spacer
40 2692-6 1 Gear, Pinion R.H. (not shown)
41 2692-7 1 Gear, Pinion L.H.
42 43661 4 Bolt, Hex 1/4-20 x 1" Lg.
43 63027 2 Ass'y, Dust Cover
44 46730 1 Tube, Upper Hopper Frame R.H.
REF. PART QTY. DESCRIPTION
NO. NO.
45 46731 1 Tube, Upper Hopper Frame L.H.
46 46732 1 Tube, Lower Hopper Frame R.H.
47 46733 1 Tube, Lower Hopper Frame L.H.
48 46736 1 Hopper Bag
49 46737 1 Wind Screen
50 24189 1 Strap, Bag Frame
51 43926 2 Rod, Hopper Support
52 43737 1 Hopper Rope
53 24190 1 Retainer, Bag
54 24191 1 Strap, Height Adjustment
55 23687 1 Bracket, Hitch
56 24192 1 Bracket, Hitch (Straight)
57 24193 1 Handle, Height Adjustment
58 46781 2 Tube, Bag Arm
59 46823 1 Rod, Hopper Bag Pivot
60 44985 2 Wheel & Tire Ass'y.(with bearings)
61 45088 4 Wheel Bearing
62 46782 2 Bolt, Hex 5/16-18 x 3" Lg.
63 43224 2 Bolt, Hex 5/16-18 x 2-1/4" Lg.
64 43084 4 Bolt, Hex 5/16-18 x 1-3/4" Lg.
65 46847 1 Bushing, Spacer
66 R19111116 2 Washer,Flat (5/16)11/32" x 11/16"
67 43720 1 Knob, Wing 5/16-18 Thread
68 43080 1 Bolt, Carriage 5/16-18 x 3/4" Lg.
69 43081 1 Washer, Flat 5/16" Std. Wrt.
70 43943 1 Grip, Height Adjust
71 44732 1 Washer, Tooth Lock 5/16"
72 23353 1 Pin, Hitch
73 23368 2 Tube, Hitch Spacer
74 43343 1 Hairpin Cotter, 1/8" #4
75 23331 4 Clamp, Hopper Mount
76 43182 4 Bolt, Hex 5/16-18 x 3/4" Lg.
77 44917 2 Palnut, 3/8"
78 43978 2 Bolt, Cvd. Hd. 1/4-20 x 1" Lg.
79 1509-90 2 Bolt, Hex 1/4-20 x 1-1/4" Lg.
80 43346 6 Bolt, Sl. Tr. Hd. #10-32 x 5/8" Lg.
81 43662 6 Nut, Hex Lock #10-32 SEMS
82 43407 2 Bolt, Hex 3/8-16 x 3/4" Lg.
83 43082 2 Nut, Hex Lock 3/8-16 Thread
84 44481 2 Cap, Vinyl
85 43055 2 Hairpin Cotter, 3/32" #3
86 46867 2 Pin, Clevis 1/4" x 1-1/2" Lg.
87 43070 2 Washer, 3/8" Std. Wrt.
46814 1 Owners Manual
REPAIR PARTS LIST FOR MODEL 45-0260 - 42" LAWNSWEEPER
PARTS

16
REPAIR PARTS
303 West Raymond
Sullivan, IL. 61951
217-728-8388
