Agri-Fab 45-01011 User manual

Model No.'s
45-01011
45-01713
190-653A
190-368B
PRINTED IN USA
UTILITY CARTS
(SEE SPECIFICATIONS ON PAGE 7)
OWNERS
MANUAL
Assembly
Operation
Maintenance
Repair Parts
CAUTION:
Read Rules or
Sa e Operation
and Instructions
Care ully
FORM NO. 48459 (REV. 7/03)
the fastest way to purchase parts
www.speedepart.com
Agri-Fab¨

2
SAFETY RULES
Remember, any power equipment can cause injury i operated improperly or i the user does not understand how
to operate the equipment. Exercise caution at all times when using power equipment.
CARTON CONTENTS
LOOK FOR THIS SYMBOL TO POINT OUT
IMPORTANT SAFETY PRECAUTIONS. IT
MEANS -- ATTENTION! BECOME ALERT!
YOUR SAFETY IS INVOLVED.
5. Latch Stand Bracket
6. Tailgate Rein orcement Bracket
7. Tailgate
8. Front Panel
9. Wheel Support
10. Axle
11. Draw Bar Tongue
12. Cart Body (2)
13. Wheels (2)
1. Tailgate Guides (2)
2. Corner Caps (2)
3. Latch Lock Lever
4. Hitch Bracket
CARTON CONTENTS (Loose Parts)
CAUTION: VEHICLE BRAKING AND
STABILITY MAY BE AFFECTED WITH
THE ADDITION OF AN ACCESSORY
OR AN ATTACHMENT. BE AWARE OF
CHANGING CONDITIONS ON SLOPES.
Exercise caution at all times when using power equipment.
Read this owners manual be ore attempting to assemble or operate the cart.
Read the vehicle owners manual and know how to operate your tractor, be ore using the cart attachment.
Do not at any time carry passengers in this cart. It has not been designed to carry passengers.
Never allow children to operate the tractor or the cart attachment.
Do not allow adults to operate the tractor or cart attachment without proper instructions.
Always begin with the transmission in irst (low) and gradually increase speed as conditions permit.
Tow the cart at reduced speed over rough terrain and hillsides or near creeks and ditches to prevent tipping
over and loss o control. Do not drive too close to a creek or ditch.
Vehicle braking and stability may be a ected with the attachment o this cart. Do not ill cart to maximum weight
capacity without checking the capability o the towing vehicle to sa ely pull and stop with the cart attached.
Be ore operating vehicle on any grade (hill) re er to the sa ety rules in the vehicle owner's manual concerning
sa e operation on slopes. Re er also to the slope guide on page 11 o this manual. Stay off steep slopes!
Do not tow this cart on highways or on public thorough ares.
Maximum towing speed is 10 m.p.h.
Follow maintenance and lubrication instructions as outlined in this manual.
135
4
2
10
13
12
9
11
8
7
6

3
FIGURE 1 - HARDWARE PACK
A B C
D
EG
H
IJ
K
L
O
Not Shown Full Size
HARDWARE SHOWN FULL SIZE
PQ
(45-01713 &
190-368B Only)
N
M
R
S
F
45-01011 45-01713
Ref. Description 190-653A 190-368B
A Hex Bolt, 1/4" x 1/2" 21 21
B Hex Bolt, 3/8" x 1" 1 1
C Truss Hd. Bolt, 5/16" x 3/4" Lg. 12 12
D Hex Nut, 1/4" 21 21
E Hex Nut, 5/16" 14 14
F Hex Lock Nut, 5/16" 1 1
G Hex Nut, 3/8" 1 1
H Lock Washer, 3/8" 1 1
I Flat Washer, 1" 0 4
J Flat Washer, 3/4" 4 0
K Cotter Pin, 1/8" x 1" Lg. 2 0
L Cotter Pin, 1/8" x 1-1/2" Lg. 0 2
M Spring 1 1
N Hex Bolt 5/16-18 x 3-3/4" 1 1
O Hub Cap 2 2
P Spacer Tube, 2" Lg. 0 2
Q Hair Cotter Pin 1/8" 1 1
R Spring Puller Tool 1 1
S Hitch Pin 1 1

4
ASSEMBLY INSTRUCTIONS
FIGURE 2
5. Position the tailgate rein orcement bracket on
outside o cart as shown in igure 3. Assemble to
the bottom o the cart body using our 5/16" x 3/4"
truss head bolts and 5/16" hex nuts. Do not
tighten. See igure 3.
6. Position the tailgate guides on the inside o the
cart bodies with guide channels to the ront as
shown in igure 3. Assemble using our 1/4" x 1/2"
hex bolts and 1/4" hex nuts. Do not tighten.
FIGURE 4
TOOLS REQUIRED FOR ASSEMBLY
(1) Screwdriver
(1) Pliers
(2) 7/16" Wrenches
(2) 1/2" Wrench
(2) 9/16" Wrenches
1. Remove the hardware pack and all loose parts
rom the carton. Be sure the carton is empty
be ore discarding.
2. Lay out all parts as shown in the carton contents.
FIGURE 3
3. Position cart body halves upright on a smooth
level sur ace such as a garage loor or a paved
driveway. See igure 2.
4. Assemble halves together using three 1/4" x 1/2"
hex bolts and 1/4" hex nuts as shown in igure 2.
Do not tighten.
DO NOT LEAVE THE CART UNATTENDED IN
UPRIGHT POSITION DURING ASSEMBLY. A
FALLINGCARTCAN CAUSEPERSONALINJURY!
PAY CLOSE ATTENTION TO THE STABILITY OF
THE CART WHILE IT REMAINS IN AN UPRIGHT
POSITION. FOR BEST STABILITY, ASSEMBLE
ON A SMOOTH, LEVEL SURFACE.
CAUTION
7. At this time, with the cart body halves pulled
together, tighten the our truss head bolts as-
sembled in step 5 and then tighten the our hex
bolts assembled in step 6. Do not tighten the
three hex bolts that were assembled in step 4.
8. Care ully reverse the position o the cart so that it
rests on the tailgate rein orcement bracket, as shown
in igure 4.
1/4" x 1/2" HEX BOLT
1/4" HEX NUT
1/4" x 1/2"
HEX BOLT
5/16" x 3/4"
TRUSS HEAD BOLT
5/16" HEX NUT
1/4" HEX NUT
TAILGATE
REINFORCEMENT
BRACKET
TAILGATE GUIDE

5
FIGURE 6
11. Turn the latch stand bracket so that the aligning tab
is at the rear (bottom) o the bracket. Assemble the
latch stand bracket to the cart using our 1/4" x 1/2"
hex bolts and 1/4" hex nuts. TIGHTEN. See igure 7.
FIGURE 7
FIGURE 5
9. Assemble the ront panel over the end o the cart
using our 1/4" x 1/2" hex bolts and 1/4" hex nuts
as shown in igure 5. Leave two holes shown in
igure 5 empty in the bottom o the panel. Pull the
cart body halves together and tighten the two
bolts in the bottom o the ront panel, then tighten
the bolt in each side.
At this time tighten the three bolts in the bottom o
the cart which were assembled in step 4.
FIGURE 8
10. Assemble the wheel support to the cart using eight
5/16" x 3/4" truss head bolts and 5/16" hex nuts as
shown in igure 6. Heads o bolts go to the inside
o cart bed. Tighten.
12. Assemble the two corner caps to the ront corners o
the cart using our 1/4" x 1/2" hex bolts and 1/4" hex
nuts. Also assemble two 1/4" x 1/2" hex bolts and
1/4" hex nuts to the two rear corners o the cart.
TIGHTEN. See igure 8.
1/4" x 1/2"
HEX BOLTS
1/4" HEX NUT
1/4" HEX NUT
LEAVE HOLES OPEN FOR
LATCH STAND BRACKET
5/16" HEX
NUT
WHEEL
SUPPORT
5/16" x 3/4"
TRUSS HEAD BOLT
1/4" x 1/2"
HEX BOLT
LATCH STAND BRACKET
1/4" HEX NUT
ALIGNING TAB
AT BOTTOM
CORNER CAP
1/4" x 1/2"
HEX BOLT
1/4" HEX NUT
1/4" HEX
NUT

6
FIGURE 9
FIGURE 10
FIGURE 11
FIGURE 12
13. To prevent accidental tipping during the ollowing
assembly procedures, lower the cart to rest upside
down on its top langes, so that the wheel support is
acing up. See igure 9.
14. Lay the drawbar tongue (open side acing up) onto
the Wheel Support and the Latch Stand Bracket.
Assemble the axle through the wheel support and the
tongue. See igure 9.
IMPORTANT: Make sure drawbar tongue is securely
locked to the latch stand bracket by the latch lock
lever.
17. Place a spacer tube onto each end o the axle
(models 45-01713 & 190-368B only). See igure 12.
18. Assemble a lat washer, a wheel with the valve stem
acing out, and another lat washer onto the axle as
shown in igure 12. Secure the wheel on the axle with
a cotter pin, spreading the ends o the pin around the
axle. Press a hub cap onto the lat washer. Repeat on
other end o axle.
15. Place the latch lock lever through the slot in the draw
bar tongue as shown in igure 10. Assemble the 5/16"
x 3-3/4" hex bolt through the tongue, the lever and
two 5/16" hex nuts (one on each side o the lever).
Assemble the 5/16" hex lock nut onto the end o the
bolt and tighten so that the bolt can still rotate reely.
Tighten the two 5/16" hex nuts against the sides o
the latch lock lever so that the lever is centered in the
slot. See igure 10.
AXLE
DRAW BAR
TONGUE
LATCH STAND
BRACKET
5/16" HEX NUTS
5/16" HEX
LOCK NUT
LATCH
LOCK
LEVER
5/16" x 3-3/4"
HEX BOLT
COTTER PIN
WHEEL
HUB CAP
FLAT
WASHER
FLAT
WASHER
AXLE
SPACER TUBE
(45-01713 & 190-368B ONLY)
16. Hook the short end o the spring into the hole in the
latch lock lever. Use the spring puller tool to hook the
long end o the spring into the square hole in the
tongue. The spring puller tool can be stored when
inished. See igure 11.
LONG END
OF SPRING
LATCH LOCK LEVER
SPRING PULLER TOOL

7
MAINTENANCE
1. At the beginning o each season, lubricate, with a
light machine oil, the latch, the latch pivot bolt,
and the area o the axle where the draw bar tongue
pivots.
2. Grease or oil the wheel bearings periodically. Use
automotive wheel bearing type grease or 20 weight
oil.
3. Keep tires illed to the recommended tire pressure
o 12-14 Lbs.
MODELS 45-01011 & 190-653A 10 Cu. Ft. (Std.)
Tires: 16.00" x 4.0" Pneumatic
Axle: 3/4" Dia. Steel
Capacity: Up to 750 Lbs. Max.
Approx. Sh. Wt. 105 Lbs.
CART MODEL SPECIFICATIONS
MODEL 45-01713 & 190-368B 10 Cu. Ft. (H.D.)
Tires: 15.00" x 6.0" Pneumatic, Tur Tread
Axle: 1.0" Dia. Steel
Capacity: Up to 1000 Lbs. Max.
Approx. Sh. Wt. 127 Lbs.
OPERATION
1. Re er to the vehicle owners manual or instructions
about sa e operation on slopes.
2. Use the slope guide provided on page 11 o this
manual to determine i slope angle is too steep or
sa e operation.
3. For best handling and traction, distribute the weight
o the load evenly in the cart.
4. Always test to make sure your tractor has adequate
towing and braking capabilities whenever hauling a
substantial amount o weight in your cart. Use extra
caution when operating on slopes.
DO NOT EXCEED WEIGHT CAPACITY OF CART
One cubic foot of dirt weighs approximately 150 lbs.
5. To dump material rom the cart, remove the tailgate
by li ting it straight up and out rom between the
guides. Release the spring latch on the tongue by
pulling the latch lock lever orward, away rom the
cart. The cart bed will then tilt backwards to empty its
contents. A ter emptying, pull the ront o the bed
down toward the cart tongue until the latch snaps into
place. Replace the tailgate i desired.
6. The maximum towing speed or this cart is 10 m.p.h.
IMPORTANT!
CAUTION: TO AVOID POSSIBLE
INJURY, BEFORE RELEASING THE
LATCH BE SURE THAT NO ONE IS
NEAR THE CART.
CAUTION: VEHICLE BRAKING AND
STABILITY MAY BE AFFECTED WITH
THE ADDITION OF AN ACCESSORY
OR AN ATTACHMENT. BE AWARE OF
CHANGING CONDITIONS ON SLOPES.
19. Turn cart over so that it rests right side up on its
wheels.
20. Assemble the end o the hitch bracket (two holes)
down through the slot at the ront o the drawbar
tongue. Fasten it to the tongue using the 3/8" x 1"
hex bolt, 3/8" lock washer and 3/8" hex nut.
Tighten. See igure 13.
21. Assemble the hitch pin through the hitch bracket
and the tongue and secure with the 1/8" hair cotter
pin. See igure 13.
22. Place the tailgate down into the tailgate guides so
that the holes in the bottom lip o tailgate it over
the truss head bolts in the bottom o the cart. This
completes the assembly o your cart.
FIGURE 13
TONGUE
3/8" x 1"
HEX BOLT
3/8" LOCK
WASHER
3/8" HEX
NUT
HITCH
BRACKET
1/8" HAIR
COTTER
PIN
HITCH PIN

8
REPAIR PARTS FOR UTILITY CARTS
MODELS 45-01011, 190-653A, 45-01713 & 190-368B
11
15
13
15
14
2
18
18
20
A
19
12
18
19
9
5
26
12
6
11
10
A
18
19
7
8
24
23
1
3
19
4
19
20
21
18
1
21
22
29
30
B
B
25
27
16
28
21
21
17
31
31

9
REPAIR PARTS LIST FOR UTILITY CARTS
MODELS 45-01011, 190-653A, 45-01713 & 190-368B
* Purchase Common Hardware Locally
REF. PART 45-01011 45-01713
NO. NO. DESCRIPTION 190-653A 190-368B
1 23985 Cart Body 2 2
2 23502 Tailgate 1 1
3 62458 Tailgate Rein orcement Bracket 1 1
4 23548 Guide, Tailgate 2 2
5 23492 Front Panel 1 1
6 23506 Wheel Support 1 -----
23507 Wheel Support ----- 1
7 24497 Latch Stand Bracket 1 1
8 24498 Latch Lock Lever 1 1
9 23014 Hitch Bracket 1 1
10 24749 Draw Bar Tongue 1 -----
24750 Draw Bar Tongue ----- 1
11 24896 Axle, Wheel 3/4" Dia. 1 -----
24897 Axle, Wheel 1" Dia. ----- 1
12 23484 Cap, Front Corner 2 2
13 43008 Wheel, 16/4.00 x 8.00 2 -----
46272 Wheel, 15/6.00 x 8.00 ----- 2
14 43010 Cotter Pin, 1/8" Dia. x 1" * 2 -----
43093 Cotter Pin, 1/8" Dia. x 1-1/2" * ----- 2
15 43009 Washer, Flat 3/4" * 4 -----
43601 Washer, Flat 1" * ----- 4
16 44678 Spacer Tube, 1-1/4" O.D. x 2" Lg. ----- 2
17 43014 Hub Cap 2 2
18 43175 Hex Bolt, 1/4-20 x 1/2" * 21 21
19 46978 Hex Nut, 1/4-20 (SEMS) 21 21
20 43814 Truss Hd. Bolt, 5/16-18 x 3/4" Lg.* 12 12
21 46980 Hex Nut, 5/16-18 (SEMS) 14 14
22 43001 Hex Bolt, 3/8-16 x 1" Lg. * 1 1
23 43003 Lock Washer, 3/8" * 1 1
24 43015 Hex nut, 3/8-16 * 1 1
25 47408 Extension Spring 1 1
26 47622 Spring Puller Tool 1 1
27 47407 Hex Bolt, 5/16-18 x 3-3/4* 1 1
28 43064 Hex Lock Nut, 5/16-18* 1 1
29 23353 Hitch Pin 1 1
30 43343 Hair Cotter Pin, 1/8" (#4) * 1 1
31 44264 Wheel Bearing 4 ----
44488 Wheel Bearing ---- 4
48459 Owner's Manual 1 1
the fastest way to purchase parts
www.speedepart.com

10
NOTES

11
SLOPE GUIDE
(Keep this sheet in a safe place for future reference.)
Use this guide to determine if a slope is safe for the operation of your tractor and cart.
Refer also to the instructions in your vehicle owners manual.
CAUTION: DO NOT OPERATE YOUR TRACTOR AND CART ON
A SLOPE IN EXCESS OF 10 DEGREES. BE SURE OF YOUR
TRACTOR'S TOWING AND BRAKING CAPABILITIES BEFORE
OPERATING ON A SLOPE. AVOID ANY SUDDEN TURNS OR
MANEUVERS WHILE ON A SLOPE.

the fastest way to purchase parts
www.speedepart.com
REPAIR PARTS
Agri-Fab, Inc.
303 West Raymond
Sullivan, IL. 61951
217-728-8388
www.agri- ab.com
© 2001 Agri-Fab, Inc.
