Agria Cyclone 5900 Quick guide

Translation of the original Operating In-
structions
Hydrostatic Implement Carrier
agria 5900 Cyclone
5900 331; -351
Before commissioning please read the operating in-
structions and note the safety and warning information!
Operating Instructions No. 998 432GB-C 07.18

2
agria 5900 Cyclone
Nameplate
Please enter here:
Machine art. no.: .............................................................
ID/machine no.: ..............................................................
Engine type: ...................................................................
Engine no.: .....................................................................
Date of purchase: ...........................................................
For nameplate see page 4, Fig. A/4
Petrol engine: For engine no. see page 87, fig. C/4
Please provide this information for each spare parts order,
to prevent errors in delivery.
Only use genuine Agria spare parts!
The technical data, illustrations and dimensions provided in
these operating instructions are non-binding. No claims may
be derived from them. We reserve the right to make im-
provements without amending this manual.
Scope of delivery
(please check):
Equipment carrier
Tool kit
Original Operating Instructions
Original engine operating instructions
Machine identity card
(in envelope on outside of box)
Please complete the machine identity card and re-
turn it to Agria-Werke.

Hydrostatic Implement Carrier agria 5900 Cyclone
3
Symbols
Warning symbol, refer-
ence to danger point
Important information
Fuel
Choke
Spark plug connector on
Engine start
Engine stop
Engine speed
Engine oil level
Air filter
Battery
Clutch
Wheel drive
Fast
Transmission oil level
Hydraulic steering
Manual steering
PTO shaft
Brake
Parking brake
Closed (locked)
Open (unlocked)
Turn anti-clockwise
Turn clockwise
Visual inspection
Attachment point for re-
covery, lashing, towing
Wear protective gloves
Fan cooling
Grease lubrication point
Maintenance interval
Before each start-up
After each cleaning (in
particularly with a high-
pressure cleaner)
Annually
See separate engine op-
erating instructions
- agria-Service - = contact your agria
service centre

4
agria 5900 Cyclone
Designation of parts
Fig. A
Fig. B

Hydrostatic Implement Carrier agria 5900 Cyclone
5
Fig. A
1
Gearbox/hydraulic oil filling
3
Idling loop (bypass)
4
Nameplate (ID/machine no.)
5
Fuse for control module
6
Gearbox vent plug
7
Strap
8
Bar rollers
9
Steering bar centre screw
11
Handlebars
21
Eye bolt with cap nut, top
22
PTO shaft
23
Eye bolt with cap nut, bottom
24
Transmission oil drain plug
25
Brake drum
26
Wheel hub
27
Oil filter cartridge
28
Engine
29
Supporting foot
Fig. B
1
T-handle for handlebar side-
ways movement
2
Cam lever for brake
4
Safety lever
5
Manual clutch lever
6
Ratchet for manual clutch lever
7
Shifting rod for PTO
8
Shift cable for steering bar
9
Speed control lever
11
Operating hours counter
12
Ignition lock/ignition key
13
Socket outlet
14
Turning assistant momentary switch
15
Rocker switch driving
16
Momentary switch neutral
17
Illuminated fault indicator
18
Mode momentary switch

6
Hydrostatic Implement Carrier agria 5900 Cyclone

Hydrostatic Implement Carrier agria 5900 Cyclone
7
Contents
Nameplate....................................................................................................2
Scope of delivery..........................................................................................2
Symbols...............................................................................................3
Designation of parts...........................................................................4
Fig. A............................................................................................................4
Fig. B............................................................................................................4
1Safety Instructions ......................................................................10
Intended use...............................................................................................10
2Technical Data .............................................................................17
Machine......................................................................................................17
Wheel combinations, track dimensions ......................................................20
Petrol engine 13 hp ....................................................................................21
Petrol engine 22 hp ....................................................................................22
Noise and vibrational acceleration values ..................................................23
3Devices and Operating Elements...............................................24
Engine........................................................................................................24
Speed regulating lever................................................................................25
Safety circuit............................................................................................... 25
Ignition lock ................................................................................................26
Warning signal............................................................................................26
Clutch.........................................................................................................27
PTO shaft shifting.......................................................................................27
Gearbox...................................................................................................... 28
easy-control drive control ...........................................................................28
Pushing operation ......................................................................................29
Hydraulic steering.......................................................................................29
Service and parking brake..........................................................................30
Steering bar................................................................................................30
Loading strap..............................................................................................31
Attachment points.......................................................................................32
Supporting foot...........................................................................................32
Driving wheels............................................................................................32
Hood...........................................................................................................34
Gantry axle adjustment............................................................................... 34
Installing and removing implements ...........................................................36

8
Hydrostatic Implement Carrier agria 5900 Cyclone
LED lamps..................................................................................................37
Battery........................................................................................................37
Fuses..........................................................................................................37
4Commissioning and Operation ..................................................38
Commissioning...........................................................................................38
Danger zone...............................................................................................40
Before starting the engine ..........................................................................41
Starting the petrol engine ...........................................................................42
Stopping the petrol engine..........................................................................43
Working......................................................................................................44
Working on slopes......................................................................................46
Safety instructions for handling ..................................................................48
5Maintenance and Repair .............................................................49
Petrol engine 13 hp ....................................................................................50
Petrol engine 22 hp ....................................................................................53
Battery........................................................................................................58
Machine......................................................................................................59
Safety circuit............................................................................................... 63
Engine stop circuit......................................................................................64
Clutch play..................................................................................................65
Labels.........................................................................................................66
General....................................................................................................... 67
Cleaning.....................................................................................................67
Storage.......................................................................................................68
6Troubleshooting and Remedies.................................................70
Petrol engine..............................................................................................70
Electric start equipment..............................................................................73
Machine......................................................................................................74
7Decommissioning / Disposal......................................................75
Paints, Wear parts.............................................................................76
Inspection and Maintenance Overview...........................................77
Electric diagram of petrol engine....................................................80
Lubrication plan................................................................................82
Hydraulic diagram.............................................................................83
Hydraulic hoses ................................................................................84

Hydrostatic Implement Carrier agria 5900 Cyclone
9
Declaration of Conformity................................................................85
Designation of parts Fig. C, Petrol engine....................................86

1 Safety Instructions
10
Hydrostatic Implement Carrier agria 5900 Cyclone
1 Safety Instructions
Before commissioning, please read the
operating instructions and note:
Warning
symbol
This symbol has been used throughout
these operating instructions to highlight
all sections relevant to your safety. Also
pass on all safety instructions to other
users.
Intended use
The machine meets the current state of
the art and complies with the applicable
safety regulations at the time of market-
ing within the context of the approved
use. In terms of design it was not possi-
ble to eliminate either the foreseeable
misuse or the remaining risk without
limiting the functionality in accordance
with the regulations.
The agria 5900 Cyclone equipment
carrier is a manually guided, self-
propelled, single-axle machine which
powers add-on devices approved in the
Agria sales list (based on intended use).
Any other use is considered to be con-
trary to the intended purpose. The man-
ufacturer is not liable for any damages
resulting from such use and the risk is
entirely the user's own.
Intended use also includes observance
of the operating, servicing and mainte-
nance conditions stipulated by the man-
ufacturer.
Unauthorized changes to the machine,
especially to the safety equipment, may
lead to increased levels of danger, which
would rule out any manufacturer liability
for resulting damage.
When using the machine on public roads
–and when being transported –the
national road traffic regulations of the
relevant country must be complied with
(marking, lighting, etc.).
The machine must be operated as di-
rected in the operating instructions.
Other operators must given instruction if
required.
Any improper use or execution of activi-
ties at the machine not described in
these instructions constitutes unauthor-
ized misuse and is not within the statuto-
ry limits for liability of the manufacturer.
Improper use of the machine can en-
danger people and may result in dam-
age to the machine or other property of
the operator. It can also impair the func-
tionality of the machine.
Reasonable foreseeable misuse
Foreseeable misuse and improper han-
dling include inter alia:
Removal or manipulation of protec-
tive and safety devices
Use of non-approved add-on devic-
es
Failure to observe maintenance
intervals
Omitting measurements and tests
for the early detection of damage
Failure to replace wearing parts
Incorrectly executed maintenance or
repair work
Improper use.
Working with defective electrical or
mechanical devices
Transport and manoeuvring move-
ments with add-on devices switched
on
General safety and accident
prevention regulations
Basic rule:
Please observe the relevant accident
prevention regulations as well as the
generally recognized rules pertaining to

1 Safety Instructions
Hydrostatic Implement Carrier agria 5900 Cyclone
11
safety, occupational health and traffic
laws.
The use of public transportation routes is
subject to the Road Traffic Act in its
latest version.
Please check the traffic and operating
safety of the machine before each com-
missioning!
The machine may only be used, ser-
viced and repaired by persons who are
familiar with it and have been instructed
in the hazards involved.
Persons under the age of 16 must not
operate the machine!
Only work with good visibility and in
good lighting conditions.
Operator clothing must fit tightly. Wear
sturdy footwear.
The affixed warning and information
signs provide important information for
safe operation; please observe them for
your own safety!
The engine must be switched off for
transport on motor vehicles or trailers
outside the working area.
Be careful with rotating tools - keep a
safe distance!
Be careful with coasting tools. Before
you start working on them, wait until they
have come to a complete stop!
There is a risk of crushing and shearing
on power-operated parts!
Riding on the implement during opera-
tion is not permitted.
Driving behaviour, steering –and possi-
bly –braking capability and tipping be-
haviour are influenced by attached or
suspended devices and loads. Therefore
ensure adequate steering and braking
capability.
Match the operating speed to the condi-
tions.
Do not adjust the setting of the engine
speed governor. A high speed increases
the risk of accidents.
Working area and danger zone
The working area is the entire area to be
worked on. The user is responsible for
third parties in the working area.
Staying in the danger zone of the ma-
chine is not permitted (see page 40).
Check the work area before starting and
moving. Pay special attention to children
and animals.
Foreign objects are to be removed from
the area to be worked on prior to starting
work. Look out for additional foreign
objects while working and remove these
promptly.
For operation in enclosed areas, ensure
that a safety distance is kept from edges
to prevent damage to tools.
Operation and protective de-
vices
Before you start work
Familiarize yourself with the equipment
and operating elements and their func-
tions. Above all, learn how to turn the
engine off quickly and safely in an
emergency!
Ensure that all protective devices are
mounted and properly adjusted!
If no add-on device is attached, the PTO
shaft must be switched off and covered
with the protective cap.
Suitable shoes must be worn depending
on the type of ground surface (vegeta-
tion, humidity ...), so that the operator
does not slip or fall.
Startup
Do not start the engine in closed rooms,
the exhaust fumes contain carbon mon-
oxide, which is very toxic if inhaled!
Before starting the engine, set all operat-
ing elements to neutral or idle position.
Do not step in front of the machine or
the add-on device to start the engine.

1 Safety Instructions
12
Hydrostatic Implement Carrier agria 5900 Cyclone
Do not use assist-starting liquids when
using electrical assist-starting devices
(jumper cable). Danger of explosion!
Operation
Never leave the operator's position at
the steering bar while working.
Never adjust operator bars while work is
in progress –risk of accident!
For all work with the device, especially
when turning, the machine operator
must maintain the distance from the
device shown by the bars.
Riding on the implement during opera-
tion or in transport is not permitted.
In the event of any clogging to the work
equipment or add-on device, the engine
must be stopped and the work equip-
ment or add-on device must be cleaned
with appropriate tools. There may be
tension in the drive train as a result of
the blockage, which is why you should
resolve the blockage carefully.
In the event of any damage to the ma-
chine or the add-on device, shut down
the engine immediately and have the
damage repaired.
In the event of any malfunctions to the
steering, stop and park the machine
immediately. Have the fault resolved
without delay.
If there is a risk of skidding down on
sloping terrain, then the machine must
be held by an attendant using a bar or a
rope. The attendant must be located
above the machine at a safe distance
from the work equipment.
Work across the slope along contour
lines if possible. If possible, turn the
machine in uphill direction.
Finishing work
Never leave the machine unsupervised
while the engine is running.
Switch the engine off before leaving the
machine. Then close the fuel tap(s) (if
present).
Protect the machine against unauthor-
ized use. In ignition key models, remove
the ignition key; otherwise, remove the
spark plug connector.
Implements
Attach an implement only when engine
and implement drive are switched off.
Prior to attaching and starting the im-
plement, read and observe the operating
instructions of the implement.
Use adequate tools and wear gloves to
replace implements and parts thereof.
Put the supporting equipment to the
proper position and ensure stability
when you attach or remove an imple-
ment.
Secure machine and implements against
rolling away (parking brake - if installed,
wheel chocks).
There is a risk of injuries when you at-
tach an implement. Take special care.
Attach an implement in accordance with
the regulations and only at the specified
fixtures.
Always switch off the working tools dur-
ing a transport ride or when you drive to
adjacent working areas.
Secure machine and implement against
unauthorized use and rolling away when
you leave it. If necessary, install
transport or safety equipment, and put it
in protective position.
Mowing equipment
When handled improperly, the sharp
edges of the mower knives can cause
significant injuries. Always wear protec-
tive gloves when you work on the
knives.
Ensure that the screwing movements
are away from the cutting edges when
you replace a knife and loosen or secure
the knife driver.
Wear protective goggles and protective
gloves when you grind the knives.

1 Safety Instructions
Hydrostatic Implement Carrier agria 5900 Cyclone
13
Ballast
Always attach ballast properly at the
attachment points provided.
Maintenance and cleaning
Only trained specialist personnel, who
can carry out professional maintenance
and repair, may carry out this work.
Do not carry out maintenance and clean-
ing with the engine running.
When working on the engine always
remove the ignition key (if present) and
also the spark plug connector in the
case of petrol engines.
Protective devices and tools that are
subject to wear and tear must be regu-
larly inspected and replaced if neces-
sary!
Damaged cutting tools must be re-
placed!
When replacing cutting tools use suita-
ble tools and protective gloves.
Do not carry out repair work such as
welding, grinding, drilling, etc. on struc-
tural, safety-relevant parts (such as
steering bar, tractor hitches, etc.)!
Disconnect the battery before commenc-
ing welding work.
During welding work, make sure that the
electrical and electronic components of
the machines are not influenced.
Keep the machine and attachments
clean, to avoid the risk of fire.
Regularly check nuts and bolts for tight-
ness and retighten if necessary.
After maintenance and cleaning, ensure
that the protective devices are re-
installed and properly adjusted!
Only use genuine Agria spare parts.
Carry out a functional and safety test
after completing the work.
Storage
Never store the machine in rooms with
open heating.
Do not park the machine in closed
rooms with fuel left in the tank. Fuel
vapours are hazardous.
Engine, fuel and oil
Do not run the engine in a closed room.
There is a high risk of poisoning! There-
fore always replace damaged exhaust
parts.
Handle hot engine components with
caution!
The silencer and other engine parts get
very hot when the engine is running and
are still hot directly after the engine is
switched off. Keep a sufficient distance
from hot surfaces and keep children
away from the running engine.
Caution is needed when handling fuel.
These is an increased risk of fire. Never
handle fuel near open flames, ignitable
sparks or hot engine parts.
Do not refuel in closed rooms. No smok-
ing when refuelling!
Refuel only with the engine switched off
and cooled down.
Do not spill fuel. Use a suitable filling
device.
If you spilled fuel, push the machine
away from the spilled liquid before you
start the engine.
Make sure fuel is of the specified quality.
Store fuel in approved containers only.
Drain fuel only outdoors and into suita-
ble containers.
In the interests of safety, replace the fuel
tank cap and other tank caps if dam-
aged.
Store anti-corrosion agents and stabi-
lizer fluids out of the reach of children. If
sickness and vomiting occur, consult a
doctor immediately. In the event of con-

1 Safety Instructions
14
Hydrostatic Implement Carrier agria 5900 Cyclone
tact with the eyes rinse immediately with
plenty of water. Avoid inhaling vapours.
Read and observe enclosed instructions!
Before disposing of opened and seem-
ingly empty pressurized tins make sure
they are completely empty. Empty them
in a well-ventilated area safe from
sparks and flames. Dispose of tins as
hazardous waste if necessary.
When working with oil, fuel and grease
wear suitable protective gloves and use
skin protection agents if necessary.
Be careful when draining hot oil, danger
of burns.
Make sure the oil used is of the specified
quality. Store in approved containers
only.
Dispose of oil, fuel, grease and filters
separately and properly.
Hydraulic system
The hydraulic system is at high pres-
sure.
Ensure that the hydraulic hoses are
connected correctly when you connect
hydraulic components.
High-pressurized hydraulic oil can
penetrate your skin and cause severe
injuries. Danger to life!
See a doctor immediately when you are
hurt. Risk of infection!
Prior to working on the hydraulic system
depressurize it and switch off the engine
(specialized workshop).
To avoid injuries, use suitable devices
when you try to locate leaks (specialized
workshop).
Check hydraulic hose lines at regular
intervals for leaks and ageing. Replace
them as necessary. Always replace
them after the specified intervals at the
latest.
Only use genuine Agria hydraulic hoses.
Tyres and tyre pressure
When you work on the wheels ensure
that the machine is parked securely and
is secured against rolling away.
Only skilled specialists are allowed to
repair tyres, using suitable installation
tools.
Check the tyre pressure at regular inter-
vals. There is a risk of explosion from
excessive tyre pressure.
Observe the required tyre pressure
when you use ballast.
During each service work, tighten the
drive wheel bolts and nuts and check the
tightening torque.
Electrical system and battery
Persons with cardiac pacemakers are
not allowed to touch the energized parts
of the ignition system as long as the
engine is running.
When working on the electrical system
always disconnect the battery (negative
terminal).
Ensure that the battery is connected
correctly - first the positive terminal and
then the negative terminal! Reverse the
sequence when disconnecting!
Be careful with battery gases - risk of
explosion!
Avoid sparks and naked flames in the
vicinity of batteries.
Remove the plastic cover (if installed)
before you recharge a battery. This
avoids the accumulation of highly explo-
sive gases!
Caution when handling battery acid -
caustic!
Only use specified fuses. If the rating of
the fuses used is too high, the electrical
system may be irreparably damaged -
danger of fire!
Always cover the positive terminal with
the specified cover or terminal cap.

1 Safety Instructions
Hydrostatic Implement Carrier agria 5900 Cyclone
15
Description of the warning, prohibition and mandatory signs
Prior to starting up the machine, read and observe the operat-
ing instructions and safety instructions.
Prior to starting cleaning, maintenance or repair work, switch
off the engine and pull the sparking-plug connector. Remove
the ignition key if there is one.
Caution - risk of fire
- Refuel only with the engine switched off and cooled down.
- No naked flame.
The engine exhausts contain poisonous gas
- Keep your distance.
Never run the engine in a closed room.
Handle hot engine components with caution!
Keep sufficient distance to hot surfaces.
Keep a safe distance to the mower knives when the engine is
running!
When working with the machine wear individual hearing pro-
tection.
Wear sturdy footwear.
Check the engine oil level at least every 8 operating hours.

1 Safety Instructions
16
Hydrostatic Implement Carrier agria 5900 Cyclone

2 Technical Data
Hydrostatic Implement Carrier agria 5900 Cyclone
17
2 Technical Data
Machine
Machine dimensions: a1; e1= wheel axle offset to the front
(mm)
a
a1
b
c
e
e1
h
l
5.00-10 AS
600
713
760
270
270
167
approximately
990
1350
20x8.00-10
21x11.00-8
5.00-12 AS
290
approximately
1010
23x8.50-12
23x10.50-12

2 Technical Data
18
Hydrostatic Implement Carrier agria 5900 Cyclone
Clutch: ..................................................................................... Dry single-disc clutch
Gearbox:.....................................................................................................Hydrostat
Travel speeds:.............................................................................Forward 0 - 7 km/h
Reverse 0 –3.6 km/h
PTO shaft:.....................................................................................................805 rpm
independent of gear at an engine speed of 3600 rpm
Sense of rotation: Clockwise, looking on the PTO shaft. The same for forward and
reverse drive.
Steering:......................................................................... Fully hydraulic bar steering
Steering bar lockable with shutdown of the hydraulic system for hand bar steering
Steering bar:................................................................................. Height adjustment
Side adjustment without tools
Oil for gearbox and hydrostat: ............................................................... Optionally:
Multigrade oil: .....................................................SAE 10W-40 API-SE/SF (or higher)
Bio-grade hydraulic oil: .................................................. Synthetic Ester Base: HEES
Viscosity to ISO: VG 46
Cleanliness class min. 16/13 –ISO 4406, e.g.
ARAL: ..................................................................................................Vitam EHF 46
BP:........................................................................................................ Biohyd SE 46
ESSO: ..............................................................................................................HE 46
FUCHS: ..............................................................................................Plantohyd S 46
PANOLIN: .................................................................. HLP Synth 46 + 2 ‰ Antifoam
Filling volume at first filling:.......................................................... approximately 7.0 l
Oil change:....................................................................................approximately 5.0 l
Oil filter:...............................................................................Screwed cartridge AW 14
Drive control: ...................................................................... easy-control control unit
Lighting: ....................................................................................... 2x LED, 3 W each

2 Technical Data
Hydrostatic Implement Carrier agria 5900 Cyclone
19
Weights:
Empty weight (with full fuel tank, without portal axle):
without driving wheels
with 23x8.50-12
13 hp
180.0 kg
207.0 kg
22 hp
201.0 kg
228.0 kg
Empty weight (with full fuel tank, with portal axle 5939 011):
without driving wheels
with 23x8.50-12
13 hp
201.0kg
228.0 kg
22 hp
222.0 kg
249.0 kg
Possible tyres:
5990 611...........................................................................23x8.50-12 field wide tyres
0190 112.......................................................................................5.00-10 field profile
3490 411.......................................................................................5.00-12 field profile
3490 511............................................................................... 20x 8.00-10 lawn profile
3490 611..................................................................................21x11.00-8 Terra-Grip
Terra-Grip tyres require wheel track enlargement:
5519 031........................................................................................................2 x 9 cm
5990 711.........................................................................23x10.50-12 field wide tyres
Tyre pressure at:
5.00-10 .......................................................................................................... 1.5 bars
5.00-12...........................................................................................................1.5 bars
21x11.00-8..................................................................................................... 0.8 bars
20x8.00-10.....................................................................................................0.8 bars
23x8.50-12 .................................................................................................... 1.3 bars
23x10.50-12...................................................................................................1.3 bars
5917 011.................................................................. grab wheels 10 in fir 5.00-10 AS
5917 021.............................grab wheels 12 in for 5.00-12; 23x8.50-12; 23x10.50-12
5913 011....................................................................................sprocket drums 12 in
Driving wheel attachment and utilization see page 32

2 Technical Data
20
Hydrostatic Implement Carrier agria 5900 Cyclone
Wheel combinations, track dimensions
