Agria 5500 GRIZZLY compact User manual

Before commissioning the machine, read operating
instructions and observe warnings and safety instructions!
Operating Instructions No. 998 766-B 03.12
&
ToolCarrier
5500 Grizzly
- compact
- comfort
-premium
OperatingInstructions
Translation of the original operating instructions
4436,4672_1
compact:
- Differential
- Safety hillholder
- Petrol engine EH 25 D
comfort:
- Differential
- Safety hillholder
- Petrol engine EH 34 D
premium:
- Steering brake clutch
- Brake central
- Petrol engine EH 25 D
- Petrol engine EH 34 D

2agria Tool Carrier 5500 Grizzly
Symbols, Name Plate
Please complete:
Machine Type No.:.......................
Identification No.:
...................................................
EngineType:.................................
EngineNo.:...................................
Date of Purchase:.......................
For name plate, refer to p5/fig. A/17.
For Engine type and number, refer to
p40/fig. D/1.
Please state these data when order-
ing spare parts to avoid wrong deliv-
eries.
Only use original agria spare parts!
Specifications, figures and dimen-
sions stated in these instructions are
notbinding.Noclaims can be derived
from them. We reserve the right for
improvements without changing
these instructions.
This delivery comprises:
l Operating instructions
l Tool carrier
l Tool kit
Symbols
Warning – Danger
Important information
ChokeFuel
Oil Glue
Air filter Clutch
Forward Reverse
PTOBrake
Parking brake
Engine Start
Engine Stop
Engine oil level
Air cooling
Transmission oil level
Visual check
Mowing drive
Wheel drive
Fast
Slow
Differential lock
Tyre air pressure
Open (unlocked)
Closed (locked)
Clockwise
Anti clockwise

agria Tool Carrier 5500 Grizzly 3
Designation of Parts
Grizzly compact, comfort with Differential
Fig. A
Fig. B
Grizzly premium with Steering brake clutch
Fig. A
Fig. B

4agria Tool Carrier 5500 Grizzly
Designation of Parts
Figure A
1Eye bolt with cap nut, top
2Hood-receiving spherical button
3 Transmission oil filling opening and oil dip-stick
4Disc brake (safety hillholder)
5Hexagonal nut for steering handle central mounting
6Hooked yoke for retaining rope
7 Tool kit
8Steering handles
9PTO shifting mechanism
10 PTO
11 Eye bolt with cap nut, bottom
12 Wheel hub
16 Transmission drain screw
17 Name plate/Identification no.
18 Engine
Figure B
1Locking bolt for lateral steering adjustment
3Engine-off-switch
4Safety shifting lever
5Hand lever for steering brake clutch, left
6Hand lever for clutch and safety hillholder (Vers.compact, comfort)
6Hand lever for clutch (Vers.Premium)
7 Pawl for hand clutch lever
8PTO shifting mechanism
9Speed control lever
10 Gear shifting lever
11 Locking lever for R shifting (Vers.compact, comfort)
11 Gear shifting lever F-R (Vers.premium)
12 Pawl for F-R shifting
13 Lever for F-R shifting
14 Pawl for differential lock
15 Lever for differential lock
16 Hand lever for steering brake clutch, right
17 Pawl for parking brake
18 Lever for brake central

agria Tool Carrier 5500 Grizzly 5
Index
Scope of Supply ............................... 2
Designation of Parts .......... 5, 40
Recommendations
Lubricants ......................................... 6
Fuel ................................................... 6
Maintenance and Repair .................. 6
1. Safety Instructions..........7-12
Due Use............................................ 7
2. Specifications
Dimensions ..................................... 13
Machine .................................... 14, 16
Vibration Acceleration Value..... 14, 16
Track Width Plan....................... 15, 17
Petrol Engine EH 25D .................... 18
Petrol Engine EH 34D .................... 19
Noise Level ............................... 18, 19
Operation on Slopes................. 18, 19
3. Devices and
Operating Elements
Engine............................................. 20
Safety Circuit .................................. 21
Clutch/Safety Hillholder .................. 22
Gearbox.................................... 23, 24
Differential Gear.............................. 25
Single Wheel Steering Brake Clutch26
Central Brake (premium) ................ 26
Steering Handle .............................. 27
Loading Eye.................................... 27
Fixing Points ................................... 27
Drive-Wheels ........................... 28 - 30
Wheel Weight.................................. 31
Hood ............................................... 31
Coupling and Decoupling
Attachments.................................... 32
4. Commissioning and
Operation
Commissioning the Machine .......... 33
Starting the Petrol Engine .............. 34
Switching off the Petrol Engine ...... 35
Mowing............................................ 36
Danger Zone................................... 37
5. Maintenance
Petrol Engine ........................... 38 - 42
- Air Filter ........................................ 39
- Spark Plug .................................... 41
Machine .......................................... 43
Hand Lever Adjustment .................. 47
Safety Hillholder ............................. 48
General Maintenance, Cleaning..... 49
Storage ........................................... 50
Diagram: Electric Circuit ....... 51
6. Troubleshooting ..........52 - 53
Varnishes, Wear Parts............ 54
Lubrication Plan..................... 57
Inspection and
Maintenance Chart................. 58
Conformity Declaration ......... 61
Note fold-out pages!
Fig. A + B .................................. 3
Fig. C ....................................... 56
Fig. D ....................................... 60
