Agrisem DSF1600 User manual

USER MANUAL
Pneumatic seeders
DSF1600 | DSF2200
NOTT-GB-705-A 29/03/2018
EN - Original manual
AGRISEM INTERNATIONAL S.A
535 Rue Pierre Levasseur
CS 60263
44158 ANCENIS
FRANCE
Tel.: [phone]
Fax: [phone]

User manual - Pneumatic seeders - DSF1600 | DSF2200
3
NOTT-GB-705-A
29/03/2018
Contents
FOREWORD ....................................................................................................................5
1. Introduction ................................................................................................................6
1.1. Purpose of the user manual ................................................................................................................6
1.2. Using the manual ................................................................................................................................6
1.3. Ordering the manual............................................................................................................................7
1.4. Interpreting the version of the manual.................................................................................................7
1.5. Description of warning terms...............................................................................................................7
2. Presentation of the machine .....................................................................................9
2.1. Intended use of the equipment............................................................................................................9
2.2. General view of the machine.............................................................................................................10
3.Identication............................................................................................................. 11
3.1. Validity of the user manual ................................................................................................................ 11
3.2. Location and description of data plate............................................................................................... 11
3.3. Identicationofthemachine..............................................................................................................12
4. Warranty....................................................................................................................13
4.1. Warranty conditions...........................................................................................................................13
4.2. Exclusive liability clause....................................................................................................................16
5. Safety instructions...................................................................................................17
5.1. Safety instructions.............................................................................................................................17
5.2. Safety symbols on the machine ........................................................................................................30
6. Operation ..................................................................................................................34
6.1. Location and description of controls..................................................................................................34
6.2. Start-up..............................................................................................................................................38
6.3. Distribution head ...............................................................................................................................63
6.4. DSFowratetest..............................................................................................................................63
6.5. Tablesofdeliveryowrateaccordingtoworkingwidth.....................................................................65
6.6. Frontpacker ......................................................................................................................................70
6.7. A-Manager terminal...........................................................................................................................70
6.8. A-Touch terminal ...............................................................................................................................70
7. Terminal.....................................................................................................................71
7.1. Characteristics of the A-Manager terminal ........................................................................................71
7.2. Characteristics of the A-Touch terminal.............................................................................................72

User manual - Pneumatic seeders - DSF1600 | DSF2200
4
NOTT-GB-705-A
29/03/2018
7.3. Customerconguration .....................................................................................................................73
7.4. Product database ..............................................................................................................................77
7.5. 1 and 2 motor seed rate test .............................................................................................................84
7.6. Tramlining..........................................................................................................................................90
7.7. Manual adjustment of application rate...............................................................................................97
7.8. Sown area information ......................................................................................................................98
7.9. Boutmarker(solenoidvalveoption)................................................................................................100
7.10. Light (standard) ...............................................................................................................................102
7.11. Diagnostic mode..............................................................................................................................103
7.12. Installation mode - junction box table..............................................................................................109
7.13. Error messages............................................................................................................................... 116
8. Winter Storage - Handling - Transport ................................................................. 118
8.1. Storage............................................................................................................................................ 118
8.2. Handling .......................................................................................................................................... 119
8.3. Transport .........................................................................................................................................120
9. Servicing - Maintenance ........................................................................................121
9.1. Maintenance tips .............................................................................................................................121
9.2. Maintenance consumables..............................................................................................................125
9.3. Maintenance schedule ....................................................................................................................125
9.4. Maintenance operations..................................................................................................................126
10. Failures..................................................................................................................133
10.1. Causes and remedies .....................................................................................................................133
10.2. Fuses...............................................................................................................................................134
11. Characteristics......................................................................................................135
12. Technical terms and abbreviations.....................................................................136
13. Appendices ...........................................................................................................137

User manual - Pneumatic seeders - DSF1600 | DSF2200
5
NOTT-GB-705-A
29/03/2018
FOREWORD
We thank you for the condence you have shown in AGRISEM INTERNATIONAL by purchasing this item of
equipment.
This manual is provided with your machine to enable you to make optimum use of your equipment, in particular
under safe working conditions.
All owners are reminded that the manual is an essential accessory which must remain with the machine at all
times, and that in the event of resale, article 1615 of the Civil Code requires that as such it must be handed
over to the new owner.
You are also reminded that as the manual is essential to the machine, all owners must undertake to leave it
physically available with the machine for all users to consult.
This manual contains details of the characteristics of your new equipment. Please read it and ensure that all
users scrupulously follow the instructions contained. The following pages provide essential information on your
machine, read them carefully.
Your AGRISEM INTERNATIONAL dealer will provide high quality servicing, as well as any assistance you may
require. For servicing, remember that your dealer is the person who is most familiar with your machine and
wishes to give you complete satisfaction.
All information and characteristics given in this manual are current at the time of publication. However, the
policy of continuous improvement of our products requires us to reserve the right to make changes at any time
without prior notice.
This user manual is published for wide circulation and the availability of the equipment indicated, whether
on the basic machine or as accessories, may vary according to the region in which the machine is used. All
combinations available at the time of publishing the manual will be described therein.

User manual - Pneumatic seeders - DSF1600 | DSF2200
Introduction
6
NOTT-GB-705-A
29/03/2018
1. Introduction
1.1. Purpose of the user manual
You have just taken ownership of your AGRISEM INTERNATIONAL machine. It has been designed to give
complete satisfaction.
The equipment has been carefully designed using the latest technological solutions to reduce usage costs.
However, for the best and most cost-effective use of your AGRISEM INTERNATIONAL machine, please read
this manual carefully before starting it up and strictly follow the instructions. In particular, follow the instructions
for adjusting and servicing the machine, as well as the safety precautions, very carefully.
Please contact our distributor for any information or advice.
This user manual is an integral part of the machine and must always be kept with the machine, especially in
the event of resale.
AGRISEM INTERNATIONAL is constantly seeking to improve its products and reserves the right to modify or
improve its products with no obligation to apply these modications or improvements to products already on
the market.
The instructions in this manual are not exhaustive and cannot cover all eventualities. The user must comply with
the applicable legislation, in particular with regard to safety, ensure that the rules of safety and caution dictated
by the situation are applied, use common sense and adapt the use of the machine to the circumstances.
It is the Purchaser’s responsibility to check that the AGRISEM INTERNATIONAL machine complies with
the applicable legislation and regulations at the nal destination.
DANGER
The instructions in this user manual must be read, understood and applied by any persons
who will be carrying out work on or with the machine, in particular:
- use of the machine (including preparation, repairs required during work and maintenance),
- maintenance (servicing and inspection),
- transport.
AGRISEM INTERNATIONAL cannot be held liable for personal injury or damage to equipment and malfunctions
resulting from failure to comply with the instructions given by the manufacturer in this manual.
IMPORTANT
AGRISEM INTERNATIONAL information
Return the warranty certicate within 15 days together with a copy of the invoice (without these
documents the warranty procedure cannot be implemented).
1.2. Using the manual
1.2.1. Functional organisation
Wherever possible, the contents of the user manual are classed by function.
1.2.2. Search help
The table of contents helps you to nd information.

User manual - Pneumatic seeders - DSF1600 | DSF2200
Introduction
7
NOTT-GB-705-A
29/03/2018
1.3. Ordering the manual
You can order the user manual by sending a request to:
AGRISEM INTERNATIONAL S.A.
535 Rue Pierre Levasseur
CS 60263
44158 ANCENIS - France
Tel.: [phone] – Fax: [phone]
1.4. Interpreting the version of the manual
The version of the manual is indicated on the cover page and consists of the following.
Description of manual version
Example: NOTT-GB-705-A
Character Description
NOTT User manual
FR
GB
DE
PL
RU
English
French
German
Polish
Russian
705 Type of machine
A Version of the manual
1.5. Description of warning terms
DANGER
This pictogram indicates a hazardous situation for the user.
Consequences: death or serious injury are inevitable.
WARNING
This pictogram indicates a hazardous situation for the user.
Consequences: death or serious injury may occur.
CAUTION
This pictogram indicates a hazardous situation for the user and the equipment.
Consequences: the user may suffer minor injuries, the equipment may suffer minor damage.
IMPORTANT
This pictogram indicates required information.
Consequences: material damage, physical risks, nancial risks.

User manual - Pneumatic seeders - DSF1600 | DSF2200
Introduction
8
NOTT-GB-705-A
29/03/2018
NOTE
This pictogram provides advice.
Consequences: more efcient use.
BARRED BIN
Indicates that waste must not be disposed of in a conventional dustbin but collected through
special channels.
MOEBIUS LOOP
The universal recycling symbol. It indicates that the product or its packaging is technically
recyclable, not that it is or will be recycled.
The products will only be recycled under two conditions:
- the sorting and recycling channel exists in your region,
- the products have been correctly sorted.

User manual - Pneumatic seeders - DSF1600 | DSF2200
Presentation of the machine
9
NOTT-GB-705-A
29/03/2018
2. Presentation of the machine
2.1. Intended use of the equipment
The AGRISEM INTERNATIONAL DSF 1600 and DSF 2200 front-mounted hopper ranges are exclusively
designed for professional use in accordance with the recognised rules for the purposes of performing
agricultural work.
The DSF1600 and DSF 2200 front-mounted hoppers are designed and adapted for hitching onto the front link
arm of a tractor for the purpose of:
- storing seed and solid fertiliser products,
- metering seed and solid fertiliser products,
- distributing seed and solid fertiliser products, to the seeding units. The seeding units do not form part of
the machine.
The DSF1600 and DSF 2200 front-mounted hoppers must be operated, maintained and repaired only by
persons who are entirely familiar with the machine and who are aware of the possible risks.
Correct use implies strictly adhering to the instructions given in the user manual as well as the operating,
servicing and repair rules dened by the manufacturer.
The user and the owner are responsible for complying with the specic accident prevention instructions and
well as the general rules relating to safety, occupational medicine and highway legislation.
Any use other than that dened above will be deemed to be inconsistent with the intended use and will exempt
the manufacturer from all from any liability in the event of damage or injury. The risks of such use shall be borne
by the user alone.
Competencies and level of training
Activity Person
instructed
Person having
undergone
specialised
training
Person
specially
trained for this
activity
Shipment/transport - x x
Start-up x x -
Installation and set-up of equipment - x -
Operation x x -
Servicing x x -
Troubleshooting and resolution of faults and incidents x x -
Waste reprocessing/disposal - - x

User manual - Pneumatic seeders - DSF1600 | DSF2200
Presentation of the machine
10
NOTT-GB-705-A
29/03/2018
2.2. General view of the machine
NOTT-0001
1
2
3
4
5
6
7
8
Fig. 1
No. Description
1 Hopper
2 Hitching frame
3 Parking stand
4 Signal lights
5 Pipeline
6 Radar

User manual - Pneumatic seeders - DSF1600 | DSF2200
Identication
11
NOTT-GB-705-A
29/03/2018
3. Identication
3.1. Validity of the user manual
This user manual is valid for the following machines.
Machine Type Serial number
From To
Pneumatic seeders DSF1600 18S1600105
Pneumatic seeders DSF2200 18S2200101
IMPORTANT
This user manual is published for wide circulation and the availability of the equipment
indicated, whether on the basic machine or as accessories, may vary according to the region
in which the machine is used. All combinations available at the time of publishing the manual
will be described therein.
3.2. Location and description of data plate
The data plate is located on the lower hitching beam.
NOTT-0051
1
Fig. 2
The data plate includes the following information:
No. Description
1Model
2 Serial number
3Year of manufacture
4Empty weight of the equipment
NOTT-0052
1 2
3 4
Fig. 3

User manual - Pneumatic seeders - DSF1600 | DSF2200
Identication
12
NOTT-GB-705-A
29/03/2018
The serial number is made up as follows.
No. Description
1Year of manufacture
2 S = pneumatic seeder
3Hopper capacity in litres
4 Incremental number
NOTT-0053
17 S 1600 120
1 2 3 4
Fig. 4
3.3. Identication of the machine
On receipt of the machine, please enter the corresponding information below:
Information Fill-in the column with the requested information
Type of machine
................................................................................................
Serial number
................................................................................................
Year of manufacture
................................................................................................
Date of rst use
................................................................................................
Name of the dealer
................................................................................................
Dealer's address ................................................................................................
................................................................................................
................................................................................................
................................................................................................
Dealer's telephone number
................................................................................................
AGRISEM INTERNATIONAL S.A.
535 Rue Pierre Levasseur
CS 60263
44158 ANCENIS - France
Tel.: (33) +33 (0)2.51.14.14.40 – Fax: [phone]
E-mail: [email protected]
IMPORTANT
This document should be kept inside this user manual.

User manual - Pneumatic seeders - DSF1600 | DSF2200
Warranty
13
NOTT-GB-705-A
29/03/2018
4. Warranty
4.1. Warranty conditions
NOTE
Return the warranty certicate within 15 days together with a copy of the invoice (without these
documents the warranty procedure cannot be implemented).
The warranty conditions applicable to machines tted exclusively with original parts from
AGRISEM INTERNATIONAL are as follows:
By selling new products to its dealers, the manufacturer provides a guarantee according to which, subject
to certain conditions, the goods are free of material or workmanship defects. The purchasers of new
AGRISEM INTERNATIONAL equipment shall request all necessary information from the dealer having
supplied them the equipment.
As part of its policy of constant product improvement, the manufacturer reserves the right to change the
characteristics of its equipment without notice and accepts no liability in the event of possible differences
between the characteristics of its products and the description of said products in its publications.
4.1.1. Duration
If a defect is observed on a structural part within a period of 12 months as from the date of delivery of the
machine, and if this defect is due to faulty raw materials, or its manufacture at the factory. The parts alleged to
be faulty must be returned to the Company's address for expert inspection:
AGRISEM INTERNATIONAL S.A. – 535 Rue Pierre Levasseur – CS 60263 – 44158 ANCENIS - France
Tel.: [phone] – Fax: [phone]
The following shall be considered to constitute proof of the date of delivery of the equipment:
- the date of the delivery slip and the purchaser’s invoice.
- the return of the warranty certicate within 15 days (with the dealer's and purchaser’s stamp and signature)
following delivery of the equipment.
4.1.2. Machines and parts concerned
For the purposes of this warranty, the term “Machine” is exclusively used to designate machines and parts
manufactured by AGRISEM INTERNATIONAL. (It does not include external components, in particular tyres,
hydraulic hoses, etc. even though these parts are also supplied by the company)
NOTE
The warranty is void if any modications have been made to the machine without the formal
approval of AGRISEM INTERNATIONAL or if parts other than those manufactured by the
company have been tted (e.g. counterfeit wear parts).
4.1.3. Scope of the warranty
The warranty is limited to the reimbursement or repair of parts acknowledged to have material or machining
defects, in our factories and by our Technical Departments.
Any costs linked to the dismantling and replacement of the faulty part are not covered by the warranty. The cost
of transporting machines or machine parts to the place of repair and their return to their owner is not covered
either.
Wear parts are not covered by the warranty.

User manual - Pneumatic seeders - DSF1600 | DSF2200
Warranty
14
NOTT-GB-705-A
29/03/2018
4.1.4. Preconditions
The machine must be maintained and used in accordance with the instructions in this user manual.
All of the safety measures described in the user manual and in the manuals of any additional equipment must
be complied with.
All protection and safety components are to be inspected regularly and replaced if necessary, including
cylinders, hydraulic hoses, spring and turbo safety devices. refer to the chapters “Safety instructions”, page
17 and “Servicing - Maintenance”, page 121.
The warranty is only valid if the customer has met the contract's general obligations, in particular the payment
conditions.
4.1.5. Pre-delivery inspection
When supplying a machine, the dealer is required to perform a number of operations. These involve, rstly,
a complete inspection of the machine prior to delivery so that the machine is supplied ready for immediate
use. They also involve providing comprehensive training to the purchaser regarding the basic principles of
machine operation and servicing. This training covers the instruments and controls, routing servicing and
safety instructions. All those who will be involved in the use and the servicing of the machine are required to
attend this training.
4.1.6. Warranty exclusions
The warranty will not apply:
- If the faults are due to normal wear, incorrect use, lack of maintenance, inadequate monitoring or negligence.
- If the machine is damaged by an accident or develops a fault due to being used for purposes other than
those specied by AGRISEM INTERNATIONAL.
- In the event of improper use of the machine. Please refer to the chapter “Intended use of the equipment”,
page 9 regarding this point.
- If the manufacturer's instructions and requirements given in this manual are not complied with, particularly
those regarding safety, assembly, start-up, use, operation and servicing.
- In the event of improper handling on the part of the user.
- For causes due to the presence of foreign bodies.
- In the event of damage due to the machine being combined with other machines or instruments without
the prior written agreement of AGRISEM INTERNATIONAL, and/or without complying with the instructions
given by the manufacturers of the tractor and other instruments or machines.
- If the machine is used with protection and safety devices that are incorrectly tted or not working.
- If the machine has been modied without prior written permission from AGRISEM INTERNATIONAL, or if
spare parts, accessories or equipment have been tted to the machine which were not recommended by
AGRISEM INTERNATIONAL.
- In the event of non-compliant repair.
- In the event of damage during transport or handling by a carrier. It is the recipient’s responsibility to lodge
the necessary complaints with the carrier.
- The adverse consequences of the machine being immobilised due to a fault or incident on the machine
are not covered by the warranty.
- Personal injury to the owner or a third party and the indirect consequences resulting from this are not
covered by the warranty.
Moreover, AGRISEM INTERNATIONAL shall not be liable for the payment of compensation for any reason
whatsoever in the event of the loss of crops or any damage whatsoever due to a fault, hidden defect or
machine breakdown.

User manual - Pneumatic seeders - DSF1600 | DSF2200
Warranty
15
NOTT-GB-705-A
29/03/2018
The purchaser is always responsible for the choice of product and the suitability of the machine for the result that
he hopes to obtain. He is responsible for its correct use in line with professional practice and the regulations.
Under no circumstances will AGRISEM INTERNATIONAL have any obligation with regard to the nal result.
4.1.7. Limitations and liability
The warranty cannot be assigned or transferred to any other person without the prior written permission of
AGRISEM INTERNATIONAL.
Under no circumstances do those selling our machines have the right or power to make any decision
whatsoever, either express or tacit, in the company's name.
The technical assistance given by the company or its representatives with the repairing or operation of
equipment does not make it liable for any costs and in no way alters or leads to the waiving of the conditions
of this warranty.
4.1.8. Warranty enforcement procedure
TO BE STRICTLY ADHERED TO BY THE DISTRIBUTOR AND BY THE PURCHASER
The warranty's enforcement is subject to strict compliance by the dealer and the user with the following
requirements:
1 - Returning by the dealer of the warranty certicate duly completed and signed by the dealer and the
purchaser.
2 - Claims must be made without fail using an AGRISEM INTERNATIONAL "WARRANTY CLAIM FORM" (see
appendix) and sent by registered letter with acknowledgement of receipt by the dealer to the company’s
technical department within 10 days of the incident. This form must be completed legibly by the dealer and
must include the following information:
• Name and address of the dealer, code No.,
• Name and address of the purchaser,
• Type of machine,
• Working width,
• Machine serial number,
• Date of delivery to the purchaser,
• Date of breakdown,
• Precise references of the parts replaced, No. and date of invoice,
• Make and model of the tractor used,
• Detailed description and alleged cause of the incident.
• Surface worked with the Disc-O-Mulch,
• Utilised agricultural land belonging to the farm,
• Type of soil in terms of % clay,
• Proof of wear part invoice,
• Stones (yes/no),
• Parts replaced (yes/no) (send the photocopy of the invoice).
3 - Allegedly faulty parts are to be returned by the dealer to the company's address for an expert inspection,
together with the copy of the warranty claim form provided for this purpose. The dealer must order the
faulty part from the spare parts department. Any transport costs incurred by the returning of said parts are
payable by the sender.
4 - The nal decision regarding payment under the terms of the warranty shall be made by the company’s
technical or general management. Whatever the reason for the warranty claim, this decision is nal and
irrevocable and the purchaser undertakes to accept this decision both with regard to the fault and the
replacement of the part or parts.

User manual - Pneumatic seeders - DSF1600 | DSF2200
Warranty
16
NOTT-GB-705-A
29/03/2018
Under no circumstances are the company's salesmen authorised to make such a decision, which would
be void.
NOTE
In the event of refusal, the part remains at the customer’s disposal for eight days. After this
time it will be disposed of with no appeal possible.
Under no circumstances do those selling our machines have the right or power to make any decision
whatsoever, either express or tacit, in the Company's name.
4.1.9. Warranty extension
If the customer subscribes to the warranty extension, please see this agreement for the terms and conditions
of the enforcement of this warranty extension.
4.2. Exclusive liability clause
AGRISEM INTERNATIONAL accepts no liability for damages (and any related indirect consequences) resulting
from one or more of the following causes:
- Non-compliant use of the machine.
- Failure to follow the manufacturer's instructions given in this manual, particularly those regarding safety,
assembly, start-up, use, operation and servicing.
- Unsuitable assembly, start-up, use and maintenance of the machine.
- Use of the machine with faulty protection and safety devices or safety and protection devices that are
incorrectly installed or not working.
- Combination of the machine with other instruments or machines without the written agreement of
AGRISEM INTERNATIONAL and/or without complying with the instructions given by the manufacturers
of the tractor and the other instruments or machines.
- Modications made to the machine without the written permission of AGRISEM INTERNATIONAL.
- Fitting of spare parts, accessories or equipment on the machine which are not genuine or which have not
been recommended by AGRISEM INTERNATIONAL.
- Failure to monitor the wear parts on the machine.
- Use of the machine other than for the purposes specied by the manufacturer.
- Non-compliant repair and maintenance.
- Catastrophes resulting from the presence of foreign bodies, unforeseeable circumstances and cases of
force majeure.
Moreover, AGRISEM INTERNATIONAL cannot be held liable for injury to the owner or a third party or for the
indirect consequences of such an injury, whether or not it results from a fault. You are reminded that a safe
distance of 50 metres must be maintained around the machine.
Any claim for compensation for damage that did not occur directly on the machine is excluded.
AGRISEM INTERNATIONAL cannot be held liable for damage caused by driving or use errors.
AGRISEM INTERNATIONAL cannot be held liable for compensation for the consequences of the instrument's
immobilisation due to a fault or an incident on the machine.

User manual - Pneumatic seeders - DSF1600 | DSF2200
Safety instructions
17
NOTT-GB-705-A
29/03/2018
5. Safety instructions
5.1. Safety instructions
5.1.1. Introduction
The instructions in this user manual must be read and understood before the machine is used for the rst time.
This user manual is published for wide circulation and the availability of the equipment indicated, whether on
the basic machine or as accessories, may vary according to the region in which the machine is used.
Always consult the dealer/retailer if you do not understand any part of this manual. It is important that you
understand and observe these instructions.
The safety instructions given in this chapter are in addition to those given in other chapters of this manual.
The machine is used in conjunction with an agricultural tractor. Only careful reading of the user manuals of
both items of equipment (tractor + machine/tool) will ensure the complete safety of property and people when
working.
Most accidents which occur during work, maintenance or travel from one place to another are due to a failure
to observe the most basic safety rules. It is therefore essential for anyone likely to be working with this machine
to adhere to the basic rules listed below and to the safety instructions displayed on the stickers afxed to the
machine.
This machine has been designed for a specic task. It must always be in good working order and must only be
repaired using AGRISEM INTERNATIONAL OEM parts.
This machine must be used, maintained and repaired only by competent persons who are familiar with its
features and its operating procedures and who are aware of the safety rules for accident prevention and the
dangers to which they may be exposed.
This machine must only be used in accordance with its purpose and in a condition that does not present any
safety risks. Any malfunctions likely to be detrimental to safety must be corrected immediately.
The user is required to strictly adhere to the safety instructions in this manual and the stickers afxed to the
machine. The safety panels and guards have been omitted from some illustrations in this manual for the sake
of clarity. Never use the machine if these items are not installed. If any of these items have been removed to
carry out a repair, they must be reinstalled before operation.
The user is also required to strictly comply with the current legislation with regard to accident prevention, safety
at work (labour code), occupational medicine, highway legislation and waste treatment.
Before using the machine for the rst time, read all of the safety instructions in this user manual carefully and
familiarise yourself with the controls.
The machine must never be entrusted to a person who is not trained to use it.
Liability and warranty
In addition to the other cases mentioned in this manual, the manufacturer denies any liability for any injury or
damage to equipment resulting from one or more of the following causes:
- Failure to follow the manufacturer's instructions given in this manual, particularly those regarding safety,
assembly, start-up, use, operation and servicing.
- Non-compliant use of the machine.
- Unsuitable assembly, start-up, use and maintenance of the machine.
- Use of the machine with faulty protection and safety devices or safety and protection devices that are
incorrectly installed or not working.

User manual - Pneumatic seeders - DSF1600 | DSF2200
Safety instructions
18
NOTT-GB-705-A
29/03/2018
- Combining of the machine with other instruments or machines without the written agreement of
AGRISEM INTERNATIONAL and/or without complying with the instructions given by the manufacturers
of the tractor and the other instruments or machines.
List of compatible AGRISEM INTERNATIONAL machines
• Combiplow: Disc-O-Mulch / Maximulch / Actimulch
• DSF: Disc-O-Mulch / Maximulch / Actimulch
• DSA: Disc-O-Mulch / Maximulch / Actimulch
• DS500/200: Disc-O-Mulch / Maximulch / Actimulch
- Modications made to the machine without the written permission of AGRISEM INTERNATIONAL.
- Fitting of spare parts, accessories or equipment on the machine which are not genuine or which have not
been recommended by AGRISEM INTERNATIONAL. Spare parts are available via the online spare parts
catalogue (accessible via http://parts.agrisem.com/) or through your approved customer service network.
- Failure to monitor the wear parts on the machine.
- Use of the machine other than for the purposes specied by the manufacturer.
- Non-compliant repair and maintenance.
- Catastrophes resulting from the presence of foreign bodies, unforeseeable circumstances and cases of
force majeure.
Similarly, in addition to the other cases mentioned in this manual, any claim under the warranty linked to
damage resulting from one or more of the above-mentioned causes is excluded.
5.1.2. Instructions to be followed before using the machine
Wear close-tting clothes. Loose clothing may become caught in moving parts.
Wear the appropriate personal protective equipment (PPE) for the tasks to be performed (gloves, shoes,
goggles, helmet, ear protection, etc.).
Be aware that tillage equipment, even if not very wide, has very sharp parts (blades, shares, disks, etc.) which
can cause serious injury in the event of an accident.
Operate the controls with care.
Before each use, check the area around the machine, no-one must be within 50 metres of the machine. Check
that there is sufcient visibility to ensure this condition of use.
Before carrying out any work, ensure that weight distribution on the tractor ensures a stable assembly. The
tractor must be sufciently ballasted at the front to avoid any risk of the front lifting. If not, add weights to the
front of the tractor.
Check before each use that screws, nuts and bolts are correctly tightened in accordance with the maintenance
operation described in this manual Re-tighten if necessary.
No-one must be within 50 metres of the machine when it is being folded and unfolded.
Check that the machine is correctly hitched.
Always install the pins and locking systems.
Check that the machine meets personal safety requirements.
Whenever you use the machine, check that the safety and protection devices (safety devices, emergency stop,
wheel chock, extinguisher) are in place and working. Replace any worn or damaged protectors immediately.
Move any people or animals likely to be in the area where the machine is being manoeuvred or used. A
50-metre safety zone must be kept clear around the machine.
Go around the machine looking for any external damage and checking the condition of the protection devices.
The protection devices must be clean, legible and in good condition. If this is not the case, contact the
AGRISEM INTERNATIONAL customer service department in order to replace them.

User manual - Pneumatic seeders - DSF1600 | DSF2200
Safety instructions
19
NOTT-GB-705-A
29/03/2018
Only persons authorised by the owner of the machine and who have been trained and instructed are allowed
to work on and with this machine. The operator is responsible towards third parties when he is working on and
with the machine.
The owner of the machine must:
- Provide the operator with the user manual.
- Ensure that the operator has read it and understands it.
- Ensure that the operator knows the basic instructions regarding safety at work and accident prevention.
Immediately disinfect any cut or injury that comes into contact with the products contained in the machine.
5.1.3. Instructions to be followed for hitching and unhitching
Ensure good compatibility of the tractor-to-machine hitching device. Only combine equipment that is compatible
(machine and tractor). If in doubt, contact the AGRISEM INTERNATIONAL customer service network .
Check that the tractor has the characteristics necessary to hitch the machine (see “Characteristics”, page
135.
WARNING
Use of a tractor that is non-compliant with the machine to which it is attached will incur the
following risks:
- Coupling failure
- Instability under load
- Instability during manoeuvring
- Insufcient braking capacity
Check that the tractor meets the necessary requirements before installing or hitching the machine.
The machine must only be mounted on or hitched to a tractor if it meets the necessary requirements.
Perform a braking test to check that the tractor can provide the regulatory deceleration power even with the
machine mounted or hitched.
Refer principally to the tractor user manual, the reference below are for guidance only.

User manual - Pneumatic seeders - DSF1600 | DSF2200
Safety instructions
20
NOTT-GB-705-A
29/03/2018
Data needed for calculation
NOTT-0222
Fig. 5
No. Unit Description Comment
TL[kg] Empty weight of the tractor see the tractor's user manual or registration
papers
TV[kg] Front axle load on empty tractor
TH[kg] Rear axle load on empty tractor
GH[kg] Total weight of rear-mounted machine or
rear ballast
See technical characteristics of the
machine or the rear ballast
GV[kg] Total weight of front-mounted machine or
front weight
see technical characteristics of the
front-mounted machine or front ballast
a [m] Distance between the centre of gravity of
the front-mounted machine or front ballast
and the centre of the front axle (sum of
a1+ a2)
see technical characteristics of the tractor
and the front-mounted machine or front
ballast, or measurement
a1[m] Distance between the centre of the front
axle and the centre of the lower arms'
hitch point
see the tractor's user manual,
or measurement
a2[m] Distance between the centre of the lower
arms' hitch point and the centre of gravity
of the front-mounted machine or front
ballast (distance from the centre of gravity)
see technical characteristics of the
front-mounted machine or front ballast, or
measurement
b [m] Wheel base of the tractor see the tractor's user manual or registration
papers or measurement
