AICARE A66 User manual
1)Non-contact and high-precision body temperature measurement;
2)It can select ℃ or ℉;
Setting method: press the " "key for 8 seconds to switch in the
startup state.
3)Alarm value can be set (the default value of this product is 38℃)
Setting method: the default is set;
4)Beep prompt function (it can set to turn on or turn off the buzzer)
Setting method: press the " "key once to turn on the buzzer in
the startup state;
5)The LCD display with backlight can be used by users in darkness.
Setting method: press the " "key once to turn on the backlight in
the startup state; press the " " key for 8 seconds to convert to
object test in the startup state;
6)Automatic range selection; resolution is 0.1℃ (0.1℉)
7)The latest 32 measured data can be memorized and stored (press
the up and down keys to check the latest 32 stored and measured
data)
8)Automatic data keeping and automatic shutdown
Product Specification
Model: A66
Jiangxi AICARE Medical Technology Co., Ltd.
Table of Contents
1. Description..............................................................................................
2. Safety Manual for Use........................................................................
3. Characteristics.......................................................................................
4. Other Instructions for Use................................................................
5. Notes before Use.................................................................................
6. Product Structure.................................................................................
7. Description of LCD Screen................................................................
8. Scope of Application and Contraindications of Products......
9. Technical Indicators.............................................................................
10. Operating Instructions for Use......................................................
11. Reference Value of Body Temperature.......................................
12. Advice.....................................................................................................
13. Care and Maintenance......................................................................
14. Instructions for Waste Disposal.....................................................
15. Symbol Description............................................................................
16. List of Product Accessories..............................................................
1
1
2
2
3
3
4
4
5
6
7
8
8
9
1 0
1 0
I. Description
II. Safety Manual for Use
Please read this manual carefully before using the infrared
thermometer.
The environment temperature when using this product is
16℃ ~ 35℃.
Please do not place this product in an environment higher than
50℃ or lower than 0℃.
Please do not place this product near charged objects to
avoid electric shock.
Please do not use this product in an environment with relative
humidity greater than 85%.
Please do not place this product too close to the electromagnetic
range. (such as radio, mobile phone, etc.).
Please do not expose this product to the sun, or place it close to
the stove, and not contact with water.
Please do not strike or drop this product, and do not use the
product if it is damaged.
Sweat on forehead, hair, hat or scarf will affect the measuring
accuracy.
Please confirm that the measuring distance is in the range
of 5-10cm.
When forehead sweat or other reasons cause forehead temperature
not to reflect the human temperature normally, please measure the
human temperature from posterior earlobe.
When cleaning is required, wipe the instrument surface gently
with alcohol.
If the product has any problem, please contact with the distributor
rather than repairing the product individually. It is forbidden to
measure the body temperature.
when the environment temperature changes greatly.
-1-
III. Characteristics
IV. Other Instructions for Use
-2-
V. Notes before Use
Power On Self-checking
VI. Product Structure
①．Infrared sensor
②．Liquid crystal display (LCD) screen
③．Backlight on/off key
④．Up button (view historical data)
⑤．Down button (view historical data)
⑥．Sound switch key
⑦．Measuring switch
⑧．Battery cover
⑨．Handle
-3-
Figure 1
①
②
③
④
⑤
⑥
⑦
⑧
⑨
VII. Description of LCD Screen
①．Body temperature mode (BODY)
②．Digital reading
③．Storage position
④．Temperature ℃/F
VIII. Scope of Application and
Contraindications of Products
-4-
Figure 2
①
②
③
④
IX. Technical Indicators
1. Basic parameters
Display the accurate digits
0.1℃（0.1℉）
Storage temperature
-20-55℃
Operating environment temperature
16℃～35℃
Relative humidity
≤85%
Power
DC 3V(2 AAA batteries)
Specification
160*100*40mm
Weight
100g
Production date
See the product certificate for details.
2. Measuring range
Model temperature measuring range in human body
32.0-42.9℃
Range of measuring distance
5-10cm
Automatic shutdown
About 20s
3. Measuring accuracy
32.0℃～34.9℃
±0.3℃
35.0℃～42.0℃
±0.2℃
42.1℃～42.9℃
±0.3℃
4. Service life
The service life of the product is 40,000 times, and the product is valid
for 5 years.
5. Software release version
V1.0
-5-
X. Operating Instructions for Use
-6-
This product is a non-contact infrared thermometer that
specializes in measuring the temperature of human forehead,
and the measured temperature will be different according to the
difference of human skin; different measured parts of human can
result in different temperatures as the exposed parts of the
human are greatly affected by the environment temperature.
Infrared thermometer is a thermometer specialized in measuring
the human forehead, it is widely used in families, and this product
cannot replace doctors' diagnosis.
Aim at the target to be tested, press the measuring switch, and LCD
will display all the numbers and characters of the self-checking and a
self-checking screen will appear, as shown in Figure 1 below. This
picture will be displayed for about 1 second.
After the self-checking is completed, a sound of “beep” will be
heard, indicating that the power-on self-checking has been
completed, and the temperature value of the tested target will be
displayed on the LCD.
The product is mainly composed of an infrared sensor, a LCD screen,
a button, a shell, a handle, a battery and a circuit board.
1. Scope of application of products
The body temperature of the tested object is displayed by measuring the
thermal radiation on the forehead.
2. Contraindications of products
1) Birth defects, congenital malformation, septic shock, circulatory failure and
other diseases that may affect forehead temperature measurement seriously.
2) Suffering from mental disorders.
3) Suffering from serious heart, liver and kidney diseases.
6. Working, storage and transportation environment requirements
1) Working environment:
Environment temperature: 16℃ ~ 35℃;
Relative humidity: ≦85%;
Atmospheric pressure: 70 kpa ~ 106 kpa
Power: DC 3V(2 AAA batteries)
2) Storage and transportation environment:
Environment temperature:-20℃ ~+55℃;
Relative humidity: 10% ~ 85%;
No corrosive gas, well ventilated room.
Transportation requirements must conform to regulations of the order
contract, but severe impact, vibration and rain and snow splash during
transportation must be prevented.
1.Battery instructions
An indicating arrow on the ellipse is arranged at the bottom of the
handle; please push the battery cover forwards lightly in the direction
of the arrow with your hand here, and install the battery, so that it can
be tested and used.
Notes of battery installation and replacement:
1) After the battery cover is opened, place the battery at the place
where the battery is installed according to the positive and negative
directions. Pay attention to the correct direction of the positive and
negative electrodes.
2) Wait for 10 minutes to warm up after first using or just placing the
new battery;
3) When the battery capacity is insufficient, the symbol will appear on
the display screen, prompting to replace the new battery. Open the
battery cover (see product structure ⑧) and pay attention to the
positive and negative polarity when replacing the new battery.
Incorrect placement may cause damage to the product.
4) Please take out the battery when the product is not used for a long
time to prolong its service life, and prevent the thermometer from
being damaged due to leakage of battery liquid.
2. Measuring steps of body temperature
1) Aim the thermometer at the middle of forehead (above the
eyebrows) and keep it vertical with a distance of about 5-10cm, and
press the measuring switch to display the temperature immediately.
1)Non-contact and high-precision body temperature measurement;
2)It can select ℃ or ℉;
Setting method: press the " "key for 8 seconds to switch in the
startup state.
3)Alarm value can be set (the default value of this product is 38℃)
Setting method: the default is set;
4)Beep prompt function (it can set to turn on or turn off the buzzer)
Setting method: press the " "key once to turn on the buzzer in
the startup state;
5)The LCD display with backlight can be used by users in darkness.
Setting method: press the " "key once to turn on the backlight in
the startup state; press the " " key for 8 seconds to convert to
object test in the startup state;
6)Automatic range selection; resolution is 0.1℃ (0.1℉)
7)The latest 32 measured data can be memorized and stored (press
the up and down keys to check the latest 32 stored and measured
data)
8)Automatic data keeping and automatic shutdown
Product Specification
Model: A66
Jiangxi AICARE Medical Technology Co., Ltd.
Table of Contents
1. Description..............................................................................................
2. Safety Manual for Use........................................................................
3. Characteristics.......................................................................................
4. Other Instructions for Use................................................................
5. Notes before Use.................................................................................
6. Product Structure.................................................................................
7. Description of LCD Screen................................................................
8. Scope of Application and Contraindications of Products......
9. Technical Indicators.............................................................................
10. Operating Instructions for Use......................................................
11. Reference Value of Body Temperature.......................................
12. Advice.....................................................................................................
13. Care and Maintenance......................................................................
14. Instructions for Waste Disposal.....................................................
15. Symbol Description............................................................................
16. List of Product Accessories..............................................................
1
1
2
2
3
3
4
4
5
6
7
8
8
9
1 0
1 0
I. Description
II. Safety Manual for Use
Please read this manual carefully before using the infrared
thermometer.
The environment temperature when using this product is
16℃ ~ 35℃.
Please do not place this product in an environment higher than
50℃ or lower than 0℃.
Please do not place this product near charged objects to
avoid electric shock.
Please do not use this product in an environment with relative
humidity greater than 85%.
Please do not place this product too close to the electromagnetic
range. (such as radio, mobile phone, etc.).
Please do not expose this product to the sun, or place it close to
the stove, and not contact with water.
Please do not strike or drop this product, and do not use the
product if it is damaged.
Sweat on forehead, hair, hat or scarf will affect the measuring
accuracy.
Please confirm that the measuring distance is in the range
of 5-10cm.
When forehead sweat or other reasons cause forehead temperature
not to reflect the human temperature normally, please measure the
human temperature from posterior earlobe.
When cleaning is required, wipe the instrument surface gently
with alcohol.
If the product has any problem, please contact with the distributor
rather than repairing the product individually. It is forbidden to
measure the body temperature.
when the environment temperature changes greatly.
-1-
III. Characteristics
IV. Other Instructions for Use
-2-
V. Notes before Use
Power On Self-checking
VI. Product Structure
①．Infrared sensor
②．Liquid crystal display (LCD) screen
③．Backlight on/off key
④．Up button (view historical data)
⑤．Down button (view historical data)
⑥．Sound switch key
⑦．Measuring switch
⑧．Battery cover
⑨．Handle
-3-
Figure 1
①
②
③
④
⑤
⑥
⑦
⑧
⑨
VII. Description of LCD Screen
①．Body temperature mode (BODY)
②．Digital reading
③．Storage position
④．Temperature ℃/F
VIII. Scope of Application and
Contraindications of Products
-4-
Figure 2
①
②
③
④
IX. Technical Indicators
1. Basic parameters
Display the accurate digits
0.1℃（0.1℉）
Storage temperature
-20-55℃
Operating environment temperature
16℃～35℃
Relative humidity
≤85%
Power
DC 3V(2 AAA batteries)
Specification
160*100*40mm
Weight
100g
Production date
See the product certificate for details.
2. Measuring range
Model temperature measuring range in human body
32.0-42.9℃
Range of measuring distance
5-10cm
Automatic shutdown
About 20s
3. Measuring accuracy
32.0℃～34.9℃
±0.3℃
35.0℃～42.0℃
±0.2℃
42.1℃～42.9℃
±0.3℃
4. Service life
The service life of the product is 40,000 times, and the product is valid
for 5 years.
5. Software release version
V1.0
-5-
X. Operating Instructions for Use
-6-
This product is a non-contact infrared thermometer that
specializes in measuring the temperature of human forehead,
and the measured temperature will be different according to the
difference of human skin; different measured parts of human can
result in different temperatures as the exposed parts of the
human are greatly affected by the environment temperature.
Infrared thermometer is a thermometer specialized in measuring
the human forehead, it is widely used in families, and this product
cannot replace doctors' diagnosis.
Aim at the target to be tested, press the measuring switch, and LCD
will display all the numbers and characters of the self-checking and a
self-checking screen will appear, as shown in Figure 1 below. This
picture will be displayed for about 1 second.
After the self-checking is completed, a sound of “beep” will be
heard, indicating that the power-on self-checking has been
completed, and the temperature value of the tested target will be
displayed on the LCD.
The product is mainly composed of an infrared sensor, a LCD screen,
a button, a shell, a handle, a battery and a circuit board.
1. Scope of application of products
The body temperature of the tested object is displayed by measuring the
thermal radiation on the forehead.
2. Contraindications of products
1) Birth defects, congenital malformation, septic shock, circulatory failure and
other diseases that may affect forehead temperature measurement seriously.
2) Suffering from mental disorders.
3) Suffering from serious heart, liver and kidney diseases.
6. Working, storage and transportation environment requirements
1) Working environment:
Environment temperature: 16℃ ~ 35℃;
Relative humidity: ≦85%;
Atmospheric pressure: 70 kpa ~ 106 kpa
Power: DC 3V(2 AAA batteries)
2) Storage and transportation environment:
Environment temperature:-20℃ ~+55℃;
Relative humidity: 10% ~ 85%;
No corrosive gas, well ventilated room.
Transportation requirements must conform to regulations of the order
contract, but severe impact, vibration and rain and snow splash during
transportation must be prevented.
1.Battery instructions
An indicating arrow on the ellipse is arranged at the bottom of the
handle; please push the battery cover forwards lightly in the direction
of the arrow with your hand here, and install the battery, so that it can
be tested and used.
Notes of battery installation and replacement:
1) After the battery cover is opened, place the battery at the place
where the battery is installed according to the positive and negative
directions. Pay attention to the correct direction of the positive and
negative electrodes.
2) Wait for 10 minutes to warm up after first using or just placing the
new battery;
3) When the battery capacity is insufficient, the symbol will appear on
the display screen, prompting to replace the new battery. Open the
battery cover (see product structure ⑧) and pay attention to the
positive and negative polarity when replacing the new battery.
Incorrect placement may cause damage to the product.
4) Please take out the battery when the product is not used for a long
time to prolong its service life, and prevent the thermometer from
being damaged due to leakage of battery liquid.
2. Measuring steps of body temperature
1) Aim the thermometer at the middle of forehead (above the
eyebrows) and keep it vertical with a distance of about 5-10cm, and
press the measuring switch to display the temperature immediately.
1)Non-contact and high-precision body temperature measurement;
2)It can select ℃ or ℉;
Setting method: press the " "key for 8 seconds to switch in the
startup state.
3)Alarm value can be set (the default value of this product is 38℃)
Setting method: the default is set;
4)Beep prompt function (it can set to turn on or turn off the buzzer)
Setting method: press the " "key once to turn on the buzzer in
the startup state;
5)The LCD display with backlight can be used by users in darkness.
Setting method: press the " "key once to turn on the backlight in
the startup state; press the " " key for 8 seconds to convert to
object test in the startup state;
6)Automatic range selection; resolution is 0.1℃ (0.1℉)
7)The latest 32 measured data can be memorized and stored (press
the up and down keys to check the latest 32 stored and measured
data)
8)Automatic data keeping and automatic shutdown
Product Specification
Model: A66
Jiangxi AICARE Medical Technology Co., Ltd.
Table of Contents
1. Description..............................................................................................
2. Safety Manual for Use........................................................................
3. Characteristics.......................................................................................
4. Other Instructions for Use................................................................
5. Notes before Use.................................................................................
6. Product Structure.................................................................................
7. Description of LCD Screen................................................................
8. Scope of Application and Contraindications of Products......
9. Technical Indicators.............................................................................
10. Operating Instructions for Use......................................................
11. Reference Value of Body Temperature.......................................
12. Advice.....................................................................................................
13. Care and Maintenance......................................................................
14. Instructions for Waste Disposal.....................................................
15. Symbol Description............................................................................
16. List of Product Accessories..............................................................
1
1
2
2
3
3
4
4
5
6
7
8
8
9
1 0
1 0
I. Description
II. Safety Manual for Use
Please read this manual carefully before using the infrared
thermometer.
The environment temperature when using this product is
16℃ ~ 35℃.
Please do not place this product in an environment higher than
50℃ or lower than 0℃.
Please do not place this product near charged objects to
avoid electric shock.
Please do not use this product in an environment with relative
humidity greater than 85%.
Please do not place this product too close to the electromagnetic
range. (such as radio, mobile phone, etc.).
Please do not expose this product to the sun, or place it close to
the stove, and not contact with water.
Please do not strike or drop this product, and do not use the
product if it is damaged.
Sweat on forehead, hair, hat or scarf will affect the measuring
accuracy.
Please confirm that the measuring distance is in the range
of 5-10cm.
When forehead sweat or other reasons cause forehead temperature
not to reflect the human temperature normally, please measure the
human temperature from posterior earlobe.
When cleaning is required, wipe the instrument surface gently
with alcohol.
If the product has any problem, please contact with the distributor
rather than repairing the product individually. It is forbidden to
measure the body temperature.
when the environment temperature changes greatly.
-1-
III. Characteristics
IV. Other Instructions for Use
-2-
V. Notes before Use
Power On Self-checking
VI. Product Structure
①．Infrared sensor
②．Liquid crystal display (LCD) screen
③．Backlight on/off key
④．Up button (view historical data)
⑤．Down button (view historical data)
⑥．Sound switch key
⑦．Measuring switch
⑧．Battery cover
⑨．Handle
-3-
Figure 1
①
②
③
④
⑤
⑥
⑦
⑧
⑨
VII. Description of LCD Screen
①．Body temperature mode (BODY)
②．Digital reading
③．Storage position
④．Temperature ℃/F
VIII. Scope of Application and
Contraindications of Products
-4-
Figure 2
①
②
③
④
IX. Technical Indicators
1. Basic parameters
Display the accurate digits
0.1℃（0.1℉）
Storage temperature
-20-55℃
Operating environment temperature
16℃～35℃
Relative humidity
≤85%
Power
DC 3V(2 AAA batteries)
Specification
160*100*40mm
Weight
100g
Production date
See the product certificate for details.
2. Measuring range
Model temperature measuring range in human body
32.0-42.9℃
Range of measuring distance
5-10cm
Automatic shutdown
About 20s
3. Measuring accuracy
32.0℃～34.9℃
±0.3℃
35.0℃～42.0℃
±0.2℃
42.1℃～42.9℃
±0.3℃
4. Service life
The service life of the product is 40,000 times, and the product is valid
for 5 years.
5. Software release version
V1.0
-5-
X. Operating Instructions for Use
-6-
This product is a non-contact infrared thermometer that
specializes in measuring the temperature of human forehead,
and the measured temperature will be different according to the
difference of human skin; different measured parts of human can
result in different temperatures as the exposed parts of the
human are greatly affected by the environment temperature.
Infrared thermometer is a thermometer specialized in measuring
the human forehead, it is widely used in families, and this product
cannot replace doctors' diagnosis.
Aim at the target to be tested, press the measuring switch, and LCD
will display all the numbers and characters of the self-checking and a
self-checking screen will appear, as shown in Figure 1 below. This
picture will be displayed for about 1 second.
After the self-checking is completed, a sound of “beep” will be
heard, indicating that the power-on self-checking has been
completed, and the temperature value of the tested target will be
displayed on the LCD.
The product is mainly composed of an infrared sensor, a LCD screen,
a button, a shell, a handle, a battery and a circuit board.
1. Scope of application of products
The body temperature of the tested object is displayed by measuring the
thermal radiation on the forehead.
2. Contraindications of products
1) Birth defects, congenital malformation, septic shock, circulatory failure and
other diseases that may affect forehead temperature measurement seriously.
2) Suffering from mental disorders.
3) Suffering from serious heart, liver and kidney diseases.
6. Working, storage and transportation environment requirements
1) Working environment:
Environment temperature: 16℃ ~ 35℃;
Relative humidity: ≦85%;
Atmospheric pressure: 70 kpa ~ 106 kpa
Power: DC 3V(2 AAA batteries)
2) Storage and transportation environment:
Environment temperature:-20℃ ~+55℃;
Relative humidity: 10% ~ 85%;
No corrosive gas, well ventilated room.
Transportation requirements must conform to regulations of the order
contract, but severe impact, vibration and rain and snow splash during
transportation must be prevented.
1.Battery instructions
An indicating arrow on the ellipse is arranged at the bottom of the
handle; please push the battery cover forwards lightly in the direction
of the arrow with your hand here, and install the battery, so that it can
be tested and used.
Notes of battery installation and replacement:
1) After the battery cover is opened, place the battery at the place
where the battery is installed according to the positive and negative
directions. Pay attention to the correct direction of the positive and
negative electrodes.
2) Wait for 10 minutes to warm up after first using or just placing the
new battery;
3) When the battery capacity is insufficient, the symbol will appear on
the display screen, prompting to replace the new battery. Open the
battery cover (see product structure ⑧) and pay attention to the
positive and negative polarity when replacing the new battery.
Incorrect placement may cause damage to the product.
4) Please take out the battery when the product is not used for a long
time to prolong its service life, and prevent the thermometer from
being damaged due to leakage of battery liquid.
2. Measuring steps of body temperature
1) Aim the thermometer at the middle of forehead (above the
eyebrows) and keep it vertical with a distance of about 5-10cm, and
press the measuring switch to display the temperature immediately.
1)Non-contact and high-precision body temperature measurement;
2)It can select ℃ or ℉;
Setting method: press the " "key for 8 seconds to switch in the
startup state.
3)Alarm value can be set (the default value of this product is 38℃)
Setting method: the default is set;
4)Beep prompt function (it can set to turn on or turn off the buzzer)
Setting method: press the " "key once to turn on the buzzer in
the startup state;
5)The LCD display with backlight can be used by users in darkness.
Setting method: press the " "key once to turn on the backlight in
the startup state; press the " " key for 8 seconds to convert to
object test in the startup state;
6)Automatic range selection; resolution is 0.1℃ (0.1℉)
7)The latest 32 measured data can be memorized and stored (press
the up and down keys to check the latest 32 stored and measured
data)
8)Automatic data keeping and automatic shutdown
Product Specification
Model: A66
Jiangxi AICARE Medical Technology Co., Ltd.
Table of Contents
1. Description..............................................................................................
2. Safety Manual for Use........................................................................
3. Characteristics.......................................................................................
4. Other Instructions for Use................................................................
5. Notes before Use.................................................................................
6. Product Structure.................................................................................
7. Description of LCD Screen................................................................
8. Scope of Application and Contraindications of Products......
9. Technical Indicators.............................................................................
10. Operating Instructions for Use......................................................
11. Reference Value of Body Temperature.......................................
12. Advice.....................................................................................................
13. Care and Maintenance......................................................................
14. Instructions for Waste Disposal.....................................................
15. Symbol Description............................................................................
16. List of Product Accessories..............................................................
1
1
2
2
3
3
4
4
5
6
7
8
8
9
1 0
1 0
I. Description
II. Safety Manual for Use
Please read this manual carefully before using the infrared
thermometer.
The environment temperature when using this product is
16℃ ~ 35℃.
Please do not place this product in an environment higher than
50℃ or lower than 0℃.
Please do not place this product near charged objects to
avoid electric shock.
Please do not use this product in an environment with relative
humidity greater than 85%.
Please do not place this product too close to the electromagnetic
range. (such as radio, mobile phone, etc.).
Please do not expose this product to the sun, or place it close to
the stove, and not contact with water.
Please do not strike or drop this product, and do not use the
product if it is damaged.
Sweat on forehead, hair, hat or scarf will affect the measuring
accuracy.
Please confirm that the measuring distance is in the range
of 5-10cm.
When forehead sweat or other reasons cause forehead temperature
not to reflect the human temperature normally, please measure the
human temperature from posterior earlobe.
When cleaning is required, wipe the instrument surface gently
with alcohol.
If the product has any problem, please contact with the distributor
rather than repairing the product individually. It is forbidden to
measure the body temperature.
when the environment temperature changes greatly.
-1-
III. Characteristics
IV. Other Instructions for Use
-2-
V. Notes before Use
Power On Self-checking
VI. Product Structure
①．Infrared sensor
②．Liquid crystal display (LCD) screen
③．Backlight on/off key
④．Up button (view historical data)
⑤．Down button (view historical data)
⑥．Sound switch key
⑦．Measuring switch
⑧．Battery cover
⑨．Handle
-3-
Figure 1
①
②
③
④
⑤
⑥
⑦
⑧
⑨
VII. Description of LCD Screen
①．Body temperature mode (BODY)
②．Digital reading
③．Storage position
④．Temperature ℃/F
VIII. Scope of Application and
Contraindications of Products
-4-
Figure 2
①
②
③
④
IX. Technical Indicators
1. Basic parameters
Display the accurate digits
0.1℃（0.1℉）
Storage temperature
-20-55℃
Operating environment temperature
16℃～35℃
Relative humidity
≤85%
Power
DC 3V(2 AAA batteries)
Specification
160*100*40mm
Weight
100g
Production date
See the product certificate for details.
2. Measuring range
Model temperature measuring range in human body
32.0-42.9℃
Range of measuring distance
5-10cm
Automatic shutdown
About 20s
3. Measuring accuracy
32.0℃～34.9℃
±0.3℃
35.0℃～42.0℃
±0.2℃
42.1℃～42.9℃
±0.3℃
4. Service life
The service life of the product is 40,000 times, and the product is valid
for 5 years.
5. Software release version
V1.0
-5-
X. Operating Instructions for Use
-6-
This product is a non-contact infrared thermometer that
specializes in measuring the temperature of human forehead,
and the measured temperature will be different according to the
difference of human skin; different measured parts of human can
result in different temperatures as the exposed parts of the
human are greatly affected by the environment temperature.
Infrared thermometer is a thermometer specialized in measuring
the human forehead, it is widely used in families, and this product
cannot replace doctors' diagnosis.
Aim at the target to be tested, press the measuring switch, and LCD
will display all the numbers and characters of the self-checking and a
self-checking screen will appear, as shown in Figure 1 below. This
picture will be displayed for about 1 second.
After the self-checking is completed, a sound of “beep” will be
heard, indicating that the power-on self-checking has been
completed, and the temperature value of the tested target will be
displayed on the LCD.
The product is mainly composed of an infrared sensor, a LCD screen,
a button, a shell, a handle, a battery and a circuit board.
1. Scope of application of products
The body temperature of the tested object is displayed by measuring the
thermal radiation on the forehead.
2. Contraindications of products
1) Birth defects, congenital malformation, septic shock, circulatory failure and
other diseases that may affect forehead temperature measurement seriously.
2) Suffering from mental disorders.
3) Suffering from serious heart, liver and kidney diseases.
6. Working, storage and transportation environment requirements
1) Working environment:
Environment temperature: 16℃ ~ 35℃;
Relative humidity: ≦85%;
Atmospheric pressure: 70 kpa ~ 106 kpa
Power: DC 3V(2 AAA batteries)
2) Storage and transportation environment:
Environment temperature:-20℃ ~+55℃;
Relative humidity: 10% ~ 85%;
No corrosive gas, well ventilated room.
Transportation requirements must conform to regulations of the order
contract, but severe impact, vibration and rain and snow splash during
transportation must be prevented.
1.Battery instructions
An indicating arrow on the ellipse is arranged at the bottom of the
handle; please push the battery cover forwards lightly in the direction
of the arrow with your hand here, and install the battery, so that it can
be tested and used.
Notes of battery installation and replacement:
1) After the battery cover is opened, place the battery at the place
where the battery is installed according to the positive and negative
directions. Pay attention to the correct direction of the positive and
negative electrodes.
2) Wait for 10 minutes to warm up after first using or just placing the
new battery;
3) When the battery capacity is insufficient, the symbol will appear on
the display screen, prompting to replace the new battery. Open the
battery cover (see product structure ⑧) and pay attention to the
positive and negative polarity when replacing the new battery.
Incorrect placement may cause damage to the product.
4) Please take out the battery when the product is not used for a long
time to prolong its service life, and prevent the thermometer from
being damaged due to leakage of battery liquid.
2. Measuring steps of body temperature
1) Aim the thermometer at the middle of forehead (above the
eyebrows) and keep it vertical with a distance of about 5-10cm, and
press the measuring switch to display the temperature immediately.
1)Non-contact and high-precision body temperature measurement;
2)It can select ℃ or ℉;
Setting method: press the " "key for 8 seconds to switch in the
startup state.
3)Alarm value can be set (the default value of this product is 38℃)
Setting method: the default is set;
4)Beep prompt function (it can set to turn on or turn off the buzzer)
Setting method: press the " "key once to turn on the buzzer in
the startup state;
5)The LCD display with backlight can be used by users in darkness.
Setting method: press the " "key once to turn on the backlight in
the startup state; press the " " key for 8 seconds to convert to
object test in the startup state;
6)Automatic range selection; resolution is 0.1℃ (0.1℉)
7)The latest 32 measured data can be memorized and stored (press
the up and down keys to check the latest 32 stored and measured
data)
8)Automatic data keeping and automatic shutdown
Product Specification
Model: A66
Jiangxi AICARE Medical Technology Co., Ltd.
Table of Contents
1. Description..............................................................................................
2. Safety Manual for Use........................................................................
3. Characteristics.......................................................................................
4. Other Instructions for Use................................................................
5. Notes before Use.................................................................................
6. Product Structure.................................................................................
7. Description of LCD Screen................................................................
8. Scope of Application and Contraindications of Products......
9. Technical Indicators.............................................................................
10. Operating Instructions for Use......................................................
11. Reference Value of Body Temperature.......................................
12. Advice.....................................................................................................
13. Care and Maintenance......................................................................
14. Instructions for Waste Disposal.....................................................
15. Symbol Description............................................................................
16. List of Product Accessories..............................................................
1
1
2
2
3
3
4
4
5
6
7
8
8
9
1 0
1 0
I. Description
II. Safety Manual for Use
Please read this manual carefully before using the infrared
thermometer.
The environment temperature when using this product is
16℃ ~ 35℃.
Please do not place this product in an environment higher than
50℃ or lower than 0℃.
Please do not place this product near charged objects to
avoid electric shock.
Please do not use this product in an environment with relative
humidity greater than 85%.
Please do not place this product too close to the electromagnetic
range. (such as radio, mobile phone, etc.).
Please do not expose this product to the sun, or place it close to
the stove, and not contact with water.
Please do not strike or drop this product, and do not use the
product if it is damaged.
Sweat on forehead, hair, hat or scarf will affect the measuring
accuracy.
Please confirm that the measuring distance is in the range
of 5-10cm.
When forehead sweat or other reasons cause forehead temperature
not to reflect the human temperature normally, please measure the
human temperature from posterior earlobe.
When cleaning is required, wipe the instrument surface gently
with alcohol.
If the product has any problem, please contact with the distributor
rather than repairing the product individually. It is forbidden to
measure the body temperature.
when the environment temperature changes greatly.
-1-
III. Characteristics
IV. Other Instructions for Use
-2-
V. Notes before Use
Power On Self-checking
VI. Product Structure
①．Infrared sensor
②．Liquid crystal display (LCD) screen
③．Backlight on/off key
④．Up button (view historical data)
⑤．Down button (view historical data)
⑥．Sound switch key
⑦．Measuring switch
⑧．Battery cover
⑨．Handle
-3-
Figure 1
①
②
③
④
⑤
⑥
⑦
⑧
⑨
VII. Description of LCD Screen
①．Body temperature mode (BODY)
②．Digital reading
③．Storage position
④．Temperature ℃/F
VIII. Scope of Application and
Contraindications of Products
-4-
Figure 2
①
②
③
④
IX. Technical Indicators
1. Basic parameters
Display the accurate digits
0.1℃（0.1℉）
Storage temperature
-20-55℃
Operating environment temperature
16℃～35℃
Relative humidity
≤85%
Power
DC 3V(2 AAA batteries)
Specification
160*100*40mm
Weight
100g
Production date
See the product certificate for details.
2. Measuring range
Model temperature measuring range in human body
32.0-42.9℃
Range of measuring distance
5-10cm
Automatic shutdown
About 20s
3. Measuring accuracy
32.0℃～34.9℃
±0.3℃
35.0℃～42.0℃
±0.2℃
42.1℃～42.9℃
±0.3℃
4. Service life
The service life of the product is 40,000 times, and the product is valid
for 5 years.
5. Software release version
V1.0
-5-
X. Operating Instructions for Use
-6-
This product is a non-contact infrared thermometer that
specializes in measuring the temperature of human forehead,
and the measured temperature will be different according to the
difference of human skin; different measured parts of human can
result in different temperatures as the exposed parts of the
human are greatly affected by the environment temperature.
Infrared thermometer is a thermometer specialized in measuring
the human forehead, it is widely used in families, and this product
cannot replace doctors' diagnosis.
Aim at the target to be tested, press the measuring switch, and LCD
will display all the numbers and characters of the self-checking and a
self-checking screen will appear, as shown in Figure 1 below. This
picture will be displayed for about 1 second.
After the self-checking is completed, a sound of “beep” will be
heard, indicating that the power-on self-checking has been
completed, and the temperature value of the tested target will be
displayed on the LCD.
The product is mainly composed of an infrared sensor, a LCD screen,
a button, a shell, a handle, a battery and a circuit board.
1. Scope of application of products
The body temperature of the tested object is displayed by measuring the
thermal radiation on the forehead.
2. Contraindications of products
1) Birth defects, congenital malformation, septic shock, circulatory failure and
other diseases that may affect forehead temperature measurement seriously.
2) Suffering from mental disorders.
3) Suffering from serious heart, liver and kidney diseases.
6. Working, storage and transportation environment requirements
1) Working environment:
Environment temperature: 16℃ ~ 35℃;
Relative humidity: ≦85%;
Atmospheric pressure: 70 kpa ~ 106 kpa
Power: DC 3V(2 AAA batteries)
2) Storage and transportation environment:
Environment temperature:-20℃ ~+55℃;
Relative humidity: 10% ~ 85%;
No corrosive gas, well ventilated room.
Transportation requirements must conform to regulations of the order
contract, but severe impact, vibration and rain and snow splash during
transportation must be prevented.
1.Battery instructions
An indicating arrow on the ellipse is arranged at the bottom of the
handle; please push the battery cover forwards lightly in the direction
of the arrow with your hand here, and install the battery, so that it can
be tested and used.
Notes of battery installation and replacement:
1) After the battery cover is opened, place the battery at the place
where the battery is installed according to the positive and negative
directions. Pay attention to the correct direction of the positive and
negative electrodes.
2) Wait for 10 minutes to warm up after first using or just placing the
new battery;
3) When the battery capacity is insufficient, the symbol will appear on
the display screen, prompting to replace the new battery. Open the
battery cover (see product structure ⑧) and pay attention to the
positive and negative polarity when replacing the new battery.
Incorrect placement may cause damage to the product.
4) Please take out the battery when the product is not used for a long
time to prolong its service life, and prevent the thermometer from
being damaged due to leakage of battery liquid.
2. Measuring steps of body temperature
1) Aim the thermometer at the middle of forehead (above the
eyebrows) and keep it vertical with a distance of about 5-10cm, and
press the measuring switch to display the temperature immediately.
1)Non-contact and high-precision body temperature measurement;
2)It can select ℃ or ℉;
Setting method: press the " "key for 8 seconds to switch in the
startup state.
3)Alarm value can be set (the default value of this product is 38℃)
Setting method: the default is set;
4)Beep prompt function (it can set to turn on or turn off the buzzer)
Setting method: press the " "key once to turn on the buzzer in
the startup state;
5)The LCD display with backlight can be used by users in darkness.
Setting method: press the " "key once to turn on the backlight in
the startup state; press the " " key for 8 seconds to convert to
object test in the startup state;
6)Automatic range selection; resolution is 0.1℃ (0.1℉)
7)The latest 32 measured data can be memorized and stored (press
the up and down keys to check the latest 32 stored and measured
data)
8)Automatic data keeping and automatic shutdown
Product Specification
Model: A66
Jiangxi AICARE Medical Technology Co., Ltd.
Table of Contents
1. Description..............................................................................................
2. Safety Manual for Use........................................................................
3. Characteristics.......................................................................................
4. Other Instructions for Use................................................................
5. Notes before Use.................................................................................
6. Product Structure.................................................................................
7. Description of LCD Screen................................................................
8. Scope of Application and Contraindications of Products......
9. Technical Indicators.............................................................................
10. Operating Instructions for Use......................................................
11. Reference Value of Body Temperature.......................................
12. Advice.....................................................................................................
13. Care and Maintenance......................................................................
14. Instructions for Waste Disposal.....................................................
15. Symbol Description............................................................................
16. List of Product Accessories..............................................................
1
1
2
2
3
3
4
4
5
6
7
8
8
9
1 0
1 0
I. Description
II. Safety Manual for Use
Please read this manual carefully before using the infrared
thermometer.
The environment temperature when using this product is
16℃ ~ 35℃.
Please do not place this product in an environment higher than
50℃ or lower than 0℃.
Please do not place this product near charged objects to
avoid electric shock.
Please do not use this product in an environment with relative
humidity greater than 85%.
Please do not place this product too close to the electromagnetic
range. (such as radio, mobile phone, etc.).
Please do not expose this product to the sun, or place it close to
the stove, and not contact with water.
Please do not strike or drop this product, and do not use the
product if it is damaged.
Sweat on forehead, hair, hat or scarf will affect the measuring
accuracy.
Please confirm that the measuring distance is in the range
of 5-10cm.
When forehead sweat or other reasons cause forehead temperature
not to reflect the human temperature normally, please measure the
human temperature from posterior earlobe.
When cleaning is required, wipe the instrument surface gently
with alcohol.
If the product has any problem, please contact with the distributor
rather than repairing the product individually. It is forbidden to
measure the body temperature.
when the environment temperature changes greatly.
-1-
III. Characteristics
IV. Other Instructions for Use
-2-
V. Notes before Use
Power On Self-checking
VI. Product Structure
①．Infrared sensor
②．Liquid crystal display (LCD) screen
③．Backlight on/off key
④．Up button (view historical data)
⑤．Down button (view historical data)
⑥．Sound switch key
⑦．Measuring switch
⑧．Battery cover
⑨．Handle
-3-
Figure 1
①
②
③
④
⑤
⑥
⑦
⑧
⑨
VII. Description of LCD Screen
①．Body temperature mode (BODY)
②．Digital reading
③．Storage position
④．Temperature ℃/F
VIII. Scope of Application and
Contraindications of Products
-4-
Figure 2
①
②
③
④
IX. Technical Indicators
1. Basic parameters
Display the accurate digits
0.1℃（0.1℉）
Storage temperature
-20-55℃
Operating environment temperature
16℃～35℃
Relative humidity
≤85%
Power
DC 3V(2 AAA batteries)
Specification
160*100*40mm
Weight
100g
Production date
See the product certificate for details.
2. Measuring range
Model temperature measuring range in human body
32.0-42.9℃
Range of measuring distance
5-10cm
Automatic shutdown
About 20s
3. Measuring accuracy
32.0℃～34.9℃
±0.3℃
35.0℃～42.0℃
±0.2℃
42.1℃～42.9℃
±0.3℃
4. Service life
The service life of the product is 40,000 times, and the product is valid
for 5 years.
5. Software release version
V1.0
-5-
X. Operating Instructions for Use
-6-
This product is a non-contact infrared thermometer that
specializes in measuring the temperature of human forehead,
and the measured temperature will be different according to the
difference of human skin; different measured parts of human can
result in different temperatures as the exposed parts of the
human are greatly affected by the environment temperature.
Infrared thermometer is a thermometer specialized in measuring
the human forehead, it is widely used in families, and this product
cannot replace doctors' diagnosis.
Aim at the target to be tested, press the measuring switch, and LCD
will display all the numbers and characters of the self-checking and a
self-checking screen will appear, as shown in Figure 1 below. This
picture will be displayed for about 1 second.
After the self-checking is completed, a sound of “beep” will be
heard, indicating that the power-on self-checking has been
completed, and the temperature value of the tested target will be
displayed on the LCD.
The product is mainly composed of an infrared sensor, a LCD screen,
a button, a shell, a handle, a battery and a circuit board.
1. Scope of application of products
The body temperature of the tested object is displayed by measuring the
thermal radiation on the forehead.
2. Contraindications of products
1) Birth defects, congenital malformation, septic shock, circulatory failure and
other diseases that may affect forehead temperature measurement seriously.
2) Suffering from mental disorders.
3) Suffering from serious heart, liver and kidney diseases.
6. Working, storage and transportation environment requirements
1) Working environment:
Environment temperature: 16℃ ~ 35℃;
Relative humidity: ≦85%;
Atmospheric pressure: 70 kpa ~ 106 kpa
Power: DC 3V(2 AAA batteries)
2) Storage and transportation environment:
Environment temperature:-20℃ ~+55℃;
Relative humidity: 10% ~ 85%;
No corrosive gas, well ventilated room.
Transportation requirements must conform to regulations of the order
contract, but severe impact, vibration and rain and snow splash during
transportation must be prevented.
1.Battery instructions
An indicating arrow on the ellipse is arranged at the bottom of the
handle; please push the battery cover forwards lightly in the direction
of the arrow with your hand here, and install the battery, so that it can
be tested and used.
Notes of battery installation and replacement:
1) After the battery cover is opened, place the battery at the place
where the battery is installed according to the positive and negative
directions. Pay attention to the correct direction of the positive and
negative electrodes.
2) Wait for 10 minutes to warm up after first using or just placing the
new battery;
3) When the battery capacity is insufficient, the symbol will appear on
the display screen, prompting to replace the new battery. Open the
battery cover (see product structure ⑧) and pay attention to the
positive and negative polarity when replacing the new battery.
Incorrect placement may cause damage to the product.
4) Please take out the battery when the product is not used for a long
time to prolong its service life, and prevent the thermometer from
being damaged due to leakage of battery liquid.
2. Measuring steps of body temperature
1) Aim the thermometer at the middle of forehead (above the
eyebrows) and keep it vertical with a distance of about 5-10cm, and
press the measuring switch to display the temperature immediately.
1)Non-contact and high-precision body temperature measurement;
2)It can select ℃ or ℉;
Setting method: press the " "key for 8 seconds to switch in the
startup state.
3)Alarm value can be set (the default value of this product is 38℃)
Setting method: the default is set;
4)Beep prompt function (it can set to turn on or turn off the buzzer)
Setting method: press the " "key once to turn on the buzzer in
the startup state;
5)The LCD display with backlight can be used by users in darkness.
Setting method: press the " "key once to turn on the backlight in
the startup state; press the " " key for 8 seconds to convert to
object test in the startup state;
6)Automatic range selection; resolution is 0.1℃ (0.1℉)
7)The latest 32 measured data can be memorized and stored (press
the up and down keys to check the latest 32 stored and measured
data)
8)Automatic data keeping and automatic shutdown
Product Specification
Model: A66
Jiangxi AICARE Medical Technology Co., Ltd.
Table of Contents
1. Description..............................................................................................
2. Safety Manual for Use........................................................................
3. Characteristics.......................................................................................
4. Other Instructions for Use................................................................
5. Notes before Use.................................................................................
6. Product Structure.................................................................................
7. Description of LCD Screen................................................................
8. Scope of Application and Contraindications of Products......
9. Technical Indicators.............................................................................
10. Operating Instructions for Use......................................................
11. Reference Value of Body Temperature.......................................
12. Advice.....................................................................................................
13. Care and Maintenance......................................................................
14. Instructions for Waste Disposal.....................................................
15. Symbol Description............................................................................
16. List of Product Accessories..............................................................
1
1
2
2
3
3
4
4
5
6
7
8
8
9
1 0
1 0
I. Description
II. Safety Manual for Use
Please read this manual carefully before using the infrared
thermometer.
The environment temperature when using this product is
16℃ ~ 35℃.
Please do not place this product in an environment higher than
50℃ or lower than 0℃.
Please do not place this product near charged objects to
avoid electric shock.
Please do not use this product in an environment with relative
humidity greater than 85%.
Please do not place this product too close to the electromagnetic
range. (such as radio, mobile phone, etc.).
Please do not expose this product to the sun, or place it close to
the stove, and not contact with water.
Please do not strike or drop this product, and do not use the
product if it is damaged.
Sweat on forehead, hair, hat or scarf will affect the measuring
accuracy.
Please confirm that the measuring distance is in the range
of 5-10cm.
When forehead sweat or other reasons cause forehead temperature
not to reflect the human temperature normally, please measure the
human temperature from posterior earlobe.
When cleaning is required, wipe the instrument surface gently
with alcohol.
If the product has any problem, please contact with the distributor
rather than repairing the product individually. It is forbidden to
measure the body temperature.
when the environment temperature changes greatly.
-1-
III. Characteristics
IV. Other Instructions for Use
-2-
V. Notes before Use
Power On Self-checking
VI. Product Structure
①．Infrared sensor
②．Liquid crystal display (LCD) screen
③．Backlight on/off key
④．Up button (view historical data)
⑤．Down button (view historical data)
⑥．Sound switch key
⑦．Measuring switch
⑧．Battery cover
⑨．Handle
-3-
Figure 1
①
②
③
④
⑤
⑥
⑦
⑧
⑨
VII. Description of LCD Screen
①．Body temperature mode (BODY)
②．Digital reading
③．Storage position
④．Temperature ℃/F
VIII. Scope of Application and
Contraindications of Products
-4-
Figure 2
①
②
③
④
IX. Technical Indicators
1. Basic parameters
Display the accurate digits
0.1℃（0.1℉）
Storage temperature
-20-55℃
Operating environment temperature
16℃～35℃
Relative humidity
≤85%
Power
DC 3V(2 AAA batteries)
Specification
160*100*40mm
Weight
100g
Production date
See the product certificate for details.
2. Measuring range
Model temperature measuring range in human body
32.0-42.9℃
Range of measuring distance
5-10cm
Automatic shutdown
About 20s
3. Measuring accuracy
32.0℃～34.9℃
±0.3℃
35.0℃～42.0℃
±0.2℃
42.1℃～42.9℃
±0.3℃
4. Service life
The service life of the product is 40,000 times, and the product is valid
for 5 years.
5. Software release version
V1.0
-5-
X. Operating Instructions for Use
-6-
This product is a non-contact infrared thermometer that
specializes in measuring the temperature of human forehead,
and the measured temperature will be different according to the
difference of human skin; different measured parts of human can
result in different temperatures as the exposed parts of the
human are greatly affected by the environment temperature.
Infrared thermometer is a thermometer specialized in measuring
the human forehead, it is widely used in families, and this product
cannot replace doctors' diagnosis.
Aim at the target to be tested, press the measuring switch, and LCD
will display all the numbers and characters of the self-checking and a
self-checking screen will appear, as shown in Figure 1 below. This
picture will be displayed for about 1 second.
After the self-checking is completed, a sound of “beep” will be
heard, indicating that the power-on self-checking has been
completed, and the temperature value of the tested target will be
displayed on the LCD.
The product is mainly composed of an infrared sensor, a LCD screen,
a button, a shell, a handle, a battery and a circuit board.
1. Scope of application of products
The body temperature of the tested object is displayed by measuring the
thermal radiation on the forehead.
2. Contraindications of products
1) Birth defects, congenital malformation, septic shock, circulatory failure and
other diseases that may affect forehead temperature measurement seriously.
2) Suffering from mental disorders.
3) Suffering from serious heart, liver and kidney diseases.
6. Working, storage and transportation environment requirements
1) Working environment:
Environment temperature: 16℃ ~ 35℃;
Relative humidity: ≦85%;
Atmospheric pressure: 70 kpa ~ 106 kpa
Power: DC 3V(2 AAA batteries)
2) Storage and transportation environment:
Environment temperature:-20℃ ~+55℃;
Relative humidity: 10% ~ 85%;
No corrosive gas, well ventilated room.
Transportation requirements must conform to regulations of the order
contract, but severe impact, vibration and rain and snow splash during
transportation must be prevented.
1.Battery instructions
An indicating arrow on the ellipse is arranged at the bottom of the
handle; please push the battery cover forwards lightly in the direction
of the arrow with your hand here, and install the battery, so that it can
be tested and used.
Notes of battery installation and replacement:
1) After the battery cover is opened, place the battery at the place
where the battery is installed according to the positive and negative
directions. Pay attention to the correct direction of the positive and
negative electrodes.
2) Wait for 10 minutes to warm up after first using or just placing the
new battery;
3) When the battery capacity is insufficient, the symbol will appear on
the display screen, prompting to replace the new battery. Open the
battery cover (see product structure ⑧) and pay attention to the
positive and negative polarity when replacing the new battery.
Incorrect placement may cause damage to the product.
4) Please take out the battery when the product is not used for a long
time to prolong its service life, and prevent the thermometer from
being damaged due to leakage of battery liquid.
2. Measuring steps of body temperature
1) Aim the thermometer at the middle of forehead (above the
eyebrows) and keep it vertical with a distance of about 5-10cm, and
press the measuring switch to display the temperature immediately.
1)Non-contact and high-precision body temperature measurement;
2)It can select ℃ or ℉;
Setting method: press the " "key for 8 seconds to switch in the
startup state.
3)Alarm value can be set (the default value of this product is 38℃)
Setting method: the default is set;
4)Beep prompt function (it can set to turn on or turn off the buzzer)
Setting method: press the " "key once to turn on the buzzer in
the startup state;
5)The LCD display with backlight can be used by users in darkness.
Setting method: press the " "key once to turn on the backlight in
the startup state; press the " " key for 8 seconds to convert to
object test in the startup state;
6)Automatic range selection; resolution is 0.1℃ (0.1℉)
7)The latest 32 measured data can be memorized and stored (press
the up and down keys to check the latest 32 stored and measured
data)
8)Automatic data keeping and automatic shutdown
Product Specification
Model: A66
Jiangxi AICARE Medical Technology Co., Ltd.
Table of Contents
1. Description..............................................................................................
2. Safety Manual for Use........................................................................
3. Characteristics.......................................................................................
4. Other Instructions for Use................................................................
5. Notes before Use.................................................................................
6. Product Structure.................................................................................
7. Description of LCD Screen................................................................
8. Scope of Application and Contraindications of Products......
9. Technical Indicators.............................................................................
10. Operating Instructions for Use......................................................
11. Reference Value of Body Temperature.......................................
12. Advice.....................................................................................................
13. Care and Maintenance......................................................................
14. Instructions for Waste Disposal.....................................................
15. Symbol Description............................................................................
16. List of Product Accessories..............................................................
1
1
2
2
3
3
4
4
5
6
7
8
8
9
1 0
1 0
I. Description
II. Safety Manual for Use
Please read this manual carefully before using the infrared
thermometer.
The environment temperature when using this product is
16℃ ~ 35℃.
Please do not place this product in an environment higher than
50℃ or lower than 0℃.
Please do not place this product near charged objects to
avoid electric shock.
Please do not use this product in an environment with relative
humidity greater than 85%.
Please do not place this product too close to the electromagnetic
range. (such as radio, mobile phone, etc.).
Please do not expose this product to the sun, or place it close to
the stove, and not contact with water.
Please do not strike or drop this product, and do not use the
product if it is damaged.
Sweat on forehead, hair, hat or scarf will affect the measuring
accuracy.
Please confirm that the measuring distance is in the range
of 5-10cm.
When forehead sweat or other reasons cause forehead temperature
not to reflect the human temperature normally, please measure the
human temperature from posterior earlobe.
When cleaning is required, wipe the instrument surface gently
with alcohol.
If the product has any problem, please contact with the distributor
rather than repairing the product individually. It is forbidden to
measure the body temperature.
when the environment temperature changes greatly.
-1-
III. Characteristics
IV. Other Instructions for Use
-2-
V. Notes before Use
Power On Self-checking
VI. Product Structure
①．Infrared sensor
②．Liquid crystal display (LCD) screen
③．Backlight on/off key
④．Up button (view historical data)
⑤．Down button (view historical data)
⑥．Sound switch key
⑦．Measuring switch
⑧．Battery cover
⑨．Handle
-3-
Figure 1
①
②
③
④
⑤
⑥
⑦
⑧
⑨
VII. Description of LCD Screen
①．Body temperature mode (BODY)
②．Digital reading
③．Storage position
④．Temperature ℃/F
VIII. Scope of Application and
Contraindications of Products
-4-
Figure 2
①
②
③
④
IX. Technical Indicators
1. Basic parameters
Display the accurate digits
0.1℃（0.1℉）
Storage temperature
-20-55℃
Operating environment temperature
16℃～35℃
Relative humidity
≤85%
Power
DC 3V(2 AAA batteries)
Specification
160*100*40mm
Weight
100g
Production date
See the product certificate for details.
2. Measuring range
Model temperature measuring range in human body
32.0-42.9℃
Range of measuring distance
5-10cm
Automatic shutdown
About 20s
3. Measuring accuracy
32.0℃～34.9℃
±0.3℃
35.0℃～42.0℃
±0.2℃
42.1℃～42.9℃
±0.3℃
4. Service life
The service life of the product is 40,000 times, and the product is valid
for 5 years.
5. Software release version
V1.0
-5-
X. Operating Instructions for Use
-6-
This product is a non-contact infrared thermometer that
specializes in measuring the temperature of human forehead,
and the measured temperature will be different according to the
difference of human skin; different measured parts of human can
result in different temperatures as the exposed parts of the
human are greatly affected by the environment temperature.
Infrared thermometer is a thermometer specialized in measuring
the human forehead, it is widely used in families, and this product
cannot replace doctors' diagnosis.
Aim at the target to be tested, press the measuring switch, and LCD
will display all the numbers and characters of the self-checking and a
self-checking screen will appear, as shown in Figure 1 below. This
picture will be displayed for about 1 second.
After the self-checking is completed, a sound of “beep” will be
heard, indicating that the power-on self-checking has been
completed, and the temperature value of the tested target will be
displayed on the LCD.
The product is mainly composed of an infrared sensor, a LCD screen,
a button, a shell, a handle, a battery and a circuit board.
1. Scope of application of products
The body temperature of the tested object is displayed by measuring the
thermal radiation on the forehead.
2. Contraindications of products
1) Birth defects, congenital malformation, septic shock, circulatory failure and
other diseases that may affect forehead temperature measurement seriously.
2) Suffering from mental disorders.
3) Suffering from serious heart, liver and kidney diseases.
6. Working, storage and transportation environment requirements
1) Working environment:
Environment temperature: 16℃ ~ 35℃;
Relative humidity: ≦85%;
Atmospheric pressure: 70 kpa ~ 106 kpa
Power: DC 3V(2 AAA batteries)
2) Storage and transportation environment:
Environment temperature:-20℃ ~+55℃;
Relative humidity: 10% ~ 85%;
No corrosive gas, well ventilated room.
Transportation requirements must conform to regulations of the order
contract, but severe impact, vibration and rain and snow splash during
transportation must be prevented.
1.Battery instructions
An indicating arrow on the ellipse is arranged at the bottom of the
handle; please push the battery cover forwards lightly in the direction
of the arrow with your hand here, and install the battery, so that it can
be tested and used.
Notes of battery installation and replacement:
1) After the battery cover is opened, place the battery at the place
where the battery is installed according to the positive and negative
directions. Pay attention to the correct direction of the positive and
negative electrodes.
2) Wait for 10 minutes to warm up after first using or just placing the
new battery;
3) When the battery capacity is insufficient, the symbol will appear on
the display screen, prompting to replace the new battery. Open the
battery cover (see product structure ⑧) and pay attention to the
positive and negative polarity when replacing the new battery.
Incorrect placement may cause damage to the product.
4) Please take out the battery when the product is not used for a long
time to prolong its service life, and prevent the thermometer from
being damaged due to leakage of battery liquid.
2. Measuring steps of body temperature
1) Aim the thermometer at the middle of forehead (above the
eyebrows) and keep it vertical with a distance of about 5-10cm, and
press the measuring switch to display the temperature immediately.
XI. Reference Value of Body Temperature
1. Normal body temperature range at different measuring positions
Measuring part
Normal temperature (℃) Normal Fahrenheit （℉）
Anus
Oral cavity
Armpit
Ear
Forehead
36.6~38
97.8~100.4
35.5~37.5
95.9~99.5
34.7~37.3
94.4~99.1
35.8~38
96.4~100.4
36~37.2
97.4~98.4
-7-
Age
Normal temperature (℃)
Normal Fahrenheit （℉）
0~2 years old
36.4~38.0
97.5~100.4
3~10 years old
36.1~37.8
97.0~100.0
11~65
years old
35.9~37.6
96.6~99.7
>65 years old
35.8~37.5
96.4~99.5
XII. Advice
XIII. Care and Maintenance
-8-
XIV. Instructions for Waste Disposal
-9-
XV. Symbol Description
Symbol figure
Symbol figure
i
XVI. List of Product Accessories
One infrared thermometer, one manual and one certificate;
Names and Contents of Harmful Substances in Products
-10-
Certificate
This product meets the technical
requirements after inspection and is qualified.
Medical Infrared Thermometer
2) When the measuring switch is pressed (see product structure
⑦), the current temperature value is displayed on the current
display screen, and the measured data can be automatically stored
(press the up and down keys to check the latest 32 stored
measured data)
Notes:
1) Before measurement, please make sure there is no hair, sweat,
cosmetics or hats covering, etc.
2) When the forehead sweat or other reasons cause the forehead
temperature not to reflect the human temperature normally,
please aim at the posterior earlobe to measure the body
temperature. At the same time, please ensure that there is no hair,
sweat, cosmetics or hat covering, etc.
3) If the thermometer has not been used for a long time, the
environment temperature will be detected when it is used again,
and the startup time will be extended by 1-2 seconds.
4) Human temperature varies with different times of the day and is
also affected by other external conditions, such as age, sex, skin
color, etc.
2. Normal body temperature range of different ages
Human temperature varies with different times of the day and is
also affected by other external conditions, such as age, sex, skin
color, thickness, etc. Please refer to the following table for the
normal temperature range of different ages:
2. Product maintenance
If you encounter the following problems during use, please follow
the instructions in the maintenance instructions to find a solution.
If the problem still exists, please contact with our customer service.
1)LCD cannot display numerical values.
If the temperature is lower than 32℃ or higher than 42.9℃ in the
human measuring state, the LCD will display "Lo" or "HI" rather
than data.
2)LCD displays information "HI"
When using a non-contact electronic thermometer, the LCD
displays the information “HI", and it analyzes and shows that it
exceeds the measuring range or the measured temperature is
higher than 42.9℃ in the human temperature measuring mode.
3)LCD displays information "Lo"
When using a non-contact electronic thermometer, the LCD
displays the information "Lo", and it analyzes and shows that it is
lower than the measuring range or the measured temperature is
lower than 32℃ in the human temperature measuring mode.
When the information "Lo" or "Hi" appears, the following
situations are for reference:
■Direct disposal of electronic products and batteries in garbage
cans will cause harm to the environment. Please dispose them
according to the local laws.
■Don't throw the infrared thermometer in the garbage can at the
end of use; please dispose it according to the local laws or contact
with the manufacturer for recycling.
Notes:
The body temperature of women is different from that of men.
Generally, it is 0.3℃ higher than that of men. During ovulation, the
body temperature will be 0.3℃- 0.5℃ higher than the usual
temperature.
The protective glass outside the LCD frame is very important and
also the fragile part of the instrument, so it must be used carefully.
Please do not charge the non-rechargeable battery and do not
throw the battery into the fire.
Please do not expose the product to the sun or touch water.
1, Product maintenance and cleaning
1)The probe part is the most precise part of the product and must
be carefully protected.
2)Do not clean the product by using corrosive detergent.
3)Do not immerse this product in water or other liquids.
4)Place the product in a dry place to avoid dust, pollution and
direct sunlight.
5)Please clean the infrared thermometer regularly, usually once a
month. If necessary, the infrared thermometer can be cleaned
properly according to the actual dirty condition. Please clean the
infrared thermometer by dry soft cloth. If the instrument is
especially dirty, the main body can be wiped with dried cloth
stained with water or neutral detergent, and then it is wiped with
dry cloth.
6)The product will be calibrated automatically without manual
calibration.
The human body is a very complex bio-integrated system, and the
body temperature is an important data for the normal life activities
of the human body; usually, we measure the temperature of
forehead, cochlea, anus, oral cavity and armpit to detect our health
status; the body temperature measured in different parts will be
different. Please refer to the following table for specific differences:
Reasons for displaying information "Lo" or "HI"
The temperature value is affected by hair and sweat
The temperature is affected by airflow change;
The measuring distance is too far
Walking indoors from outdoor with low temperature or high temperature;
Suggestions
Ensure there are no obstacles when
measuring the temperature
Ensure stable air during temperature
measurement
Please note that the measuring
distance is in the range of 5-10cm
Please wait for 20 minutes, and measure the body temperature
after the tested person adapts to the measuring environment.
Meaning
Note: refer to the
attached documents
Low voltage prompt
Do not discard it at
random.
Meaning
Refer to instructions
for use.
Type B application
part
Part name
PCB board (including LCD)
Battery
Shell
Packaging materials
Harmful substance
Lead
Mercury
Cadmium Hexavalent
chromium Polybrominated
biphenyl Polybrominated
diphenyl ether
This form is prepared according to SJ/T 11364-2014.
O: indicates that the content of the hazardous substance in all homogeneous
materials of the par is below the limit requirement specified in GB/T 26572.
X: indicates that the content of the harmful substance in at least one homogeneous
material of the part exceeds the limit requirement specified in GB/T 26572.
The "hazardous substances" shown in this form will not cause any harm to human and
the environment under normal use of the product.
The "hazardous substances" and their existing parts shown in this form provide
information on the existence of relevant substances to consumers and recycling
practitioners, which is helpful for proper disposal of products when they are discarded.
One-year Free Warranty Card
Purchasing place:
Product model:
Purchasing date:
Address:
Tel: Postcode:
Email:
Body number:
Mobile phone:
Customer name:
Product name: Medical Infrared Thermometer
Product model: A66
Manufacturer:
Jiangxi AICARE Medical Technology Co., Ltd.
Inspector:
Name of registrant /manufacturer:
Jiangxi AICARE Medical Technology Co., Ltd.
Domicile:
South Side of South Ring Road, Le'an County, Fuzhou City,
Jiangxi Province (No. 1 Building, New Era Home Group, Le' an
County)
Contact information: 0794-6577516
Name of after-sales service unit:
Jiangxi AICARE Medical Technology Co., Ltd.
Contact information: 0794-6577516
Address:
South Side of South Ring Road, Le'an County, Fuzhou City,
Jiangxi Province (No. 1 Building, New Era Home Group, Le' an
County)
[Date of Approval and Modification of Manual]: March 06, 2020
XI. Reference Value of Body Temperature
1. Normal body temperature range at different measuring positions
Measuring part
Normal temperature (℃) Normal Fahrenheit （℉）
Anus
Oral cavity
Armpit
Ear
Forehead
36.6~38
97.8~100.4
35.5~37.5
95.9~99.5
34.7~37.3
94.4~99.1
35.8~38
96.4~100.4
36~37.2
97.4~98.4
-7-
Age
Normal temperature (℃)
Normal Fahrenheit （℉）
0~2 years old
36.4~38.0
97.5~100.4
3~10 years old
36.1~37.8
97.0~100.0
11~65
years old
35.9~37.6
96.6~99.7
>65 years old
35.8~37.5
96.4~99.5
XII. Advice
XIII. Care and Maintenance
-8-
XIV. Instructions for Waste Disposal
-9-
XV. Symbol Description
Symbol figure
Symbol figure
i
XVI. List of Product Accessories
One infrared thermometer, one manual and one certificate;
Names and Contents of Harmful Substances in Products
-10-
Certificate
This product meets the technical
requirements after inspection and is qualified.
Medical Infrared Thermometer
2) When the measuring switch is pressed (see product structure
⑦), the current temperature value is displayed on the current
display screen, and the measured data can be automatically stored
(press the up and down keys to check the latest 32 stored
measured data)
Notes:
1) Before measurement, please make sure there is no hair, sweat,
cosmetics or hats covering, etc.
2) When the forehead sweat or other reasons cause the forehead
temperature not to reflect the human temperature normally,
please aim at the posterior earlobe to measure the body
temperature. At the same time, please ensure that there is no hair,
sweat, cosmetics or hat covering, etc.
3) If the thermometer has not been used for a long time, the
environment temperature will be detected when it is used again,
and the startup time will be extended by 1-2 seconds.
4) Human temperature varies with different times of the day and is
also affected by other external conditions, such as age, sex, skin
color, etc.
2. Normal body temperature range of different ages
Human temperature varies with different times of the day and is
also affected by other external conditions, such as age, sex, skin
color, thickness, etc. Please refer to the following table for the
normal temperature range of different ages:
2. Product maintenance
If you encounter the following problems during use, please follow
the instructions in the maintenance instructions to find a solution.
If the problem still exists, please contact with our customer service.
1)LCD cannot display numerical values.
If the temperature is lower than 32℃ or higher than 42.9℃ in the
human measuring state, the LCD will display "Lo" or "HI" rather
than data.
2)LCD displays information "HI"
When using a non-contact electronic thermometer, the LCD
displays the information “HI", and it analyzes and shows that it
exceeds the measuring range or the measured temperature is
higher than 42.9℃ in the human temperature measuring mode.
3)LCD displays information "Lo"
When using a non-contact electronic thermometer, the LCD
displays the information "Lo", and it analyzes and shows that it is
lower than the measuring range or the measured temperature is
lower than 32℃ in the human temperature measuring mode.
When the information "Lo" or "Hi" appears, the following
situations are for reference:
■Direct disposal of electronic products and batteries in garbage
cans will cause harm to the environment. Please dispose them
according to the local laws.
■Don't throw the infrared thermometer in the garbage can at the
end of use; please dispose it according to the local laws or contact
with the manufacturer for recycling.
Notes:
The body temperature of women is different from that of men.
Generally, it is 0.3℃ higher than that of men. During ovulation, the
body temperature will be 0.3℃- 0.5℃ higher than the usual
temperature.
The protective glass outside the LCD frame is very important and
also the fragile part of the instrument, so it must be used carefully.
Please do not charge the non-rechargeable battery and do not
throw the battery into the fire.
Please do not expose the product to the sun or touch water.
1, Product maintenance and cleaning
1)The probe part is the most precise part of the product and must
be carefully protected.
2)Do not clean the product by using corrosive detergent.
3)Do not immerse this product in water or other liquids.
4)Place the product in a dry place to avoid dust, pollution and
direct sunlight.
5)Please clean the infrared thermometer regularly, usually once a
month. If necessary, the infrared thermometer can be cleaned
properly according to the actual dirty condition. Please clean the
infrared thermometer by dry soft cloth. If the instrument is
especially dirty, the main body can be wiped with dried cloth
stained with water or neutral detergent, and then it is wiped with
dry cloth.
6)The product will be calibrated automatically without manual
calibration.
The human body is a very complex bio-integrated system, and the
body temperature is an important data for the normal life activities
of the human body; usually, we measure the temperature of
forehead, cochlea, anus, oral cavity and armpit to detect our health
status; the body temperature measured in different parts will be
different. Please refer to the following table for specific differences:
Reasons for displaying information "Lo" or "HI"
The temperature value is affected by hair and sweat
The temperature is affected by airflow change;
The measuring distance is too far
Walking indoors from outdoor with low temperature or high temperature;
Suggestions
Ensure there are no obstacles when
measuring the temperature
Ensure stable air during temperature
measurement
Please note that the measuring
distance is in the range of 5-10cm
Please wait for 20 minutes, and measure the body temperature
after the tested person adapts to the measuring environment.
Meaning
Note: refer to the
attached documents
Low voltage prompt
Do not discard it at
random.
Meaning
Refer to instructions
for use.
Type B application
part
Part name
PCB board (including LCD)
Battery
Shell
Packaging materials
Harmful substance
Lead
Mercury
Cadmium Hexavalent
chromium Polybrominated
biphenyl Polybrominated
diphenyl ether
This form is prepared according to SJ/T 11364-2014.
O: indicates that the content of the hazardous substance in all homogeneous
materials of the par is below the limit requirement specified in GB/T 26572.
X: indicates that the content of the harmful substance in at least one homogeneous
material of the part exceeds the limit requirement specified in GB/T 26572.
The "hazardous substances" shown in this form will not cause any harm to human and
the environment under normal use of the product.
The "hazardous substances" and their existing parts shown in this form provide
information on the existence of relevant substances to consumers and recycling
practitioners, which is helpful for proper disposal of products when they are discarded.
One-year Free Warranty Card
Purchasing place:
Product model:
Purchasing date:
Address:
Tel: Postcode:
Email:
Body number:
Mobile phone:
Customer name:
Product name: Medical Infrared Thermometer
Product model: A66
Manufacturer:
Jiangxi AICARE Medical Technology Co., Ltd.
Inspector:
Name of registrant /manufacturer:
Jiangxi AICARE Medical Technology Co., Ltd.
Domicile:
South Side of South Ring Road, Le'an County, Fuzhou City,
Jiangxi Province (No. 1 Building, New Era Home Group, Le' an
County)
Contact information: 0794-6577516
Name of after-sales service unit:
Jiangxi AICARE Medical Technology Co., Ltd.
Contact information: 0794-6577516
Address:
South Side of South Ring Road, Le'an County, Fuzhou City,
Jiangxi Province (No. 1 Building, New Era Home Group, Le' an
County)
[Date of Approval and Modification of Manual]: March 06, 2020
XI. Reference Value of Body Temperature
1. Normal body temperature range at different measuring positions
Measuring part
Normal temperature (℃) Normal Fahrenheit （℉）
Anus
Oral cavity
Armpit
Ear
Forehead
36.6~38
97.8~100.4
35.5~37.5
95.9~99.5
34.7~37.3
94.4~99.1
35.8~38
96.4~100.4
36~37.2
97.4~98.4
-7-
Age
Normal temperature (℃)
Normal Fahrenheit （℉）
0~2 years old
36.4~38.0
97.5~100.4
3~10 years old
36.1~37.8
97.0~100.0
11~65
years old
35.9~37.6
96.6~99.7
>65 years old
35.8~37.5
96.4~99.5
XII. Advice
XIII. Care and Maintenance
-8-
XIV. Instructions for Waste Disposal
-9-
XV. Symbol Description
Symbol figure
Symbol figure
i
XVI. List of Product Accessories
One infrared thermometer, one manual and one certificate;
Names and Contents of Harmful Substances in Products
-10-
Certificate
This product meets the technical
requirements after inspection and is qualified.
Medical Infrared Thermometer
2) When the measuring switch is pressed (see product structure
⑦), the current temperature value is displayed on the current
display screen, and the measured data can be automatically stored
(press the up and down keys to check the latest 32 stored
measured data)
Notes:
1) Before measurement, please make sure there is no hair, sweat,
cosmetics or hats covering, etc.
2) When the forehead sweat or other reasons cause the forehead
temperature not to reflect the human temperature normally,
please aim at the posterior earlobe to measure the body
temperature. At the same time, please ensure that there is no hair,
sweat, cosmetics or hat covering, etc.
3) If the thermometer has not been used for a long time, the
environment temperature will be detected when it is used again,
and the startup time will be extended by 1-2 seconds.
4) Human temperature varies with different times of the day and is
also affected by other external conditions, such as age, sex, skin
color, etc.
2. Normal body temperature range of different ages
Human temperature varies with different times of the day and is
also affected by other external conditions, such as age, sex, skin
color, thickness, etc. Please refer to the following table for the
normal temperature range of different ages:
2. Product maintenance
If you encounter the following problems during use, please follow
the instructions in the maintenance instructions to find a solution.
If the problem still exists, please contact with our customer service.
1)LCD cannot display numerical values.
If the temperature is lower than 32℃ or higher than 42.9℃ in the
human measuring state, the LCD will display "Lo" or "HI" rather
than data.
2)LCD displays information "HI"
When using a non-contact electronic thermometer, the LCD
displays the information “HI", and it analyzes and shows that it
exceeds the measuring range or the measured temperature is
higher than 42.9℃ in the human temperature measuring mode.
3)LCD displays information "Lo"
When using a non-contact electronic thermometer, the LCD
displays the information "Lo", and it analyzes and shows that it is
lower than the measuring range or the measured temperature is
lower than 32℃ in the human temperature measuring mode.
When the information "Lo" or "Hi" appears, the following
situations are for reference:
■Direct disposal of electronic products and batteries in garbage
cans will cause harm to the environment. Please dispose them
according to the local laws.
■Don't throw the infrared thermometer in the garbage can at the
end of use; please dispose it according to the local laws or contact
with the manufacturer for recycling.
Notes:
The body temperature of women is different from that of men.
Generally, it is 0.3℃ higher than that of men. During ovulation, the
body temperature will be 0.3℃- 0.5℃ higher than the usual
temperature.
The protective glass outside the LCD frame is very important and
also the fragile part of the instrument, so it must be used carefully.
Please do not charge the non-rechargeable battery and do not
throw the battery into the fire.
Please do not expose the product to the sun or touch water.
1, Product maintenance and cleaning
1)The probe part is the most precise part of the product and must
be carefully protected.
2)Do not clean the product by using corrosive detergent.
3)Do not immerse this product in water or other liquids.
4)Place the product in a dry place to avoid dust, pollution and
direct sunlight.
5)Please clean the infrared thermometer regularly, usually once a
month. If necessary, the infrared thermometer can be cleaned
properly according to the actual dirty condition. Please clean the
infrared thermometer by dry soft cloth. If the instrument is
especially dirty, the main body can be wiped with dried cloth
stained with water or neutral detergent, and then it is wiped with
dry cloth.
6)The product will be calibrated automatically without manual
calibration.
The human body is a very complex bio-integrated system, and the
body temperature is an important data for the normal life activities
of the human body; usually, we measure the temperature of
forehead, cochlea, anus, oral cavity and armpit to detect our health
status; the body temperature measured in different parts will be
different. Please refer to the following table for specific differences:
Reasons for displaying information "Lo" or "HI"
The temperature value is affected by hair and sweat
The temperature is affected by airflow change;
The measuring distance is too far
Walking indoors from outdoor with low temperature or high temperature;
Suggestions
Ensure there are no obstacles when
measuring the temperature
Ensure stable air during temperature
measurement
Please note that the measuring
distance is in the range of 5-10cm
Please wait for 20 minutes, and measure the body temperature
after the tested person adapts to the measuring environment.
Meaning
Note: refer to the
attached documents
Low voltage prompt
Do not discard it at
random.
Meaning
Refer to instructions
for use.
Type B application
part
Part name
PCB board (including LCD)
Battery
Shell
Packaging materials
Harmful substance
Lead
Mercury
Cadmium Hexavalent
chromium Polybrominated
biphenyl Polybrominated
diphenyl ether
This form is prepared according to SJ/T 11364-2014.
O: indicates that the content of the hazardous substance in all homogeneous
materials of the par is below the limit requirement specified in GB/T 26572.
X: indicates that the content of the harmful substance in at least one homogeneous
material of the part exceeds the limit requirement specified in GB/T 26572.
The "hazardous substances" shown in this form will not cause any harm to human and
the environment under normal use of the product.
The "hazardous substances" and their existing parts shown in this form provide
information on the existence of relevant substances to consumers and recycling
practitioners, which is helpful for proper disposal of products when they are discarded.
One-year Free Warranty Card
Purchasing place:
Product model:
Purchasing date:
Address:
Tel: Postcode:
Email:
Body number:
Mobile phone:
Customer name:
Product name: Medical Infrared Thermometer
Product model: A66
Manufacturer:
Jiangxi AICARE Medical Technology Co., Ltd.
Inspector:
Name of registrant /manufacturer:
Jiangxi AICARE Medical Technology Co., Ltd.
Domicile:
South Side of South Ring Road, Le'an County, Fuzhou City,
Jiangxi Province (No. 1 Building, New Era Home Group, Le' an
County)
Contact information: 0794-6577516
Name of after-sales service unit:
Jiangxi AICARE Medical Technology Co., Ltd.
Contact information: 0794-6577516
Address:
South Side of South Ring Road, Le'an County, Fuzhou City,
Jiangxi Province (No. 1 Building, New Era Home Group, Le' an
County)
[Date of Approval and Modification of Manual]: March 06, 2020
XI. Reference Value of Body Temperature
1. Normal body temperature range at different measuring positions
Measuring part
Normal temperature (℃) Normal Fahrenheit （℉）
Anus
Oral cavity
Armpit
Ear
Forehead
36.6~38
97.8~100.4
35.5~37.5
95.9~99.5
34.7~37.3
94.4~99.1
35.8~38
96.4~100.4
36~37.2
97.4~98.4
-7-
Age
Normal temperature (℃)
Normal Fahrenheit （℉）
0~2 years old
36.4~38.0
97.5~100.4
3~10 years old
36.1~37.8
97.0~100.0
11~65
years old
35.9~37.6
96.6~99.7
>65 years old
35.8~37.5
96.4~99.5
XII. Advice
XIII. Care and Maintenance
-8-
XIV. Instructions for Waste Disposal
-9-
XV. Symbol Description
Symbol figure
Symbol figure
i
XVI. List of Product Accessories
One infrared thermometer, one manual and one certificate;
Names and Contents of Harmful Substances in Products
-10-
Certificate
This product meets the technical
requirements after inspection and is qualified.
Medical Infrared Thermometer
2) When the measuring switch is pressed (see product structure
⑦), the current temperature value is displayed on the current
display screen, and the measured data can be automatically stored
(press the up and down keys to check the latest 32 stored
measured data)
Notes:
1) Before measurement, please make sure there is no hair, sweat,
cosmetics or hats covering, etc.
2) When the forehead sweat or other reasons cause the forehead
temperature not to reflect the human temperature normally,
please aim at the posterior earlobe to measure the body
temperature. At the same time, please ensure that there is no hair,
sweat, cosmetics or hat covering, etc.
3) If the thermometer has not been used for a long time, the
environment temperature will be detected when it is used again,
and the startup time will be extended by 1-2 seconds.
4) Human temperature varies with different times of the day and is
also affected by other external conditions, such as age, sex, skin
color, etc.
2. Normal body temperature range of different ages
Human temperature varies with different times of the day and is
also affected by other external conditions, such as age, sex, skin
color, thickness, etc. Please refer to the following table for the
normal temperature range of different ages:
2. Product maintenance
If you encounter the following problems during use, please follow
the instructions in the maintenance instructions to find a solution.
If the problem still exists, please contact with our customer service.
1)LCD cannot display numerical values.
If the temperature is lower than 32℃ or higher than 42.9℃ in the
human measuring state, the LCD will display "Lo" or "HI" rather
than data.
2)LCD displays information "HI"
When using a non-contact electronic thermometer, the LCD
displays the information “HI", and it analyzes and shows that it
exceeds the measuring range or the measured temperature is
higher than 42.9℃ in the human temperature measuring mode.
3)LCD displays information "Lo"
When using a non-contact electronic thermometer, the LCD
displays the information "Lo", and it analyzes and shows that it is
lower than the measuring range or the measured temperature is
lower than 32℃ in the human temperature measuring mode.
When the information "Lo" or "Hi" appears, the following
situations are for reference:
■Direct disposal of electronic products and batteries in garbage
cans will cause harm to the environment. Please dispose them
according to the local laws.
■Don't throw the infrared thermometer in the garbage can at the
end of use; please dispose it according to the local laws or contact
with the manufacturer for recycling.
Notes:
The body temperature of women is different from that of men.
Generally, it is 0.3℃ higher than that of men. During ovulation, the
body temperature will be 0.3℃- 0.5℃ higher than the usual
temperature.
The protective glass outside the LCD frame is very important and
also the fragile part of the instrument, so it must be used carefully.
Please do not charge the non-rechargeable battery and do not
throw the battery into the fire.
Please do not expose the product to the sun or touch water.
1, Product maintenance and cleaning
1)The probe part is the most precise part of the product and must
be carefully protected.
2)Do not clean the product by using corrosive detergent.
3)Do not immerse this product in water or other liquids.
4)Place the product in a dry place to avoid dust, pollution and
direct sunlight.
5)Please clean the infrared thermometer regularly, usually once a
month. If necessary, the infrared thermometer can be cleaned
properly according to the actual dirty condition. Please clean the
infrared thermometer by dry soft cloth. If the instrument is
especially dirty, the main body can be wiped with dried cloth
stained with water or neutral detergent, and then it is wiped with
dry cloth.
6)The product will be calibrated automatically without manual
calibration.
The human body is a very complex bio-integrated system, and the
body temperature is an important data for the normal life activities
of the human body; usually, we measure the temperature of
forehead, cochlea, anus, oral cavity and armpit to detect our health
status; the body temperature measured in different parts will be
different. Please refer to the following table for specific differences:
Reasons for displaying information "Lo" or "HI"
The temperature value is affected by hair and sweat
The temperature is affected by airflow change;
The measuring distance is too far
Walking indoors from outdoor with low temperature or high temperature;
Suggestions
Ensure there are no obstacles when
measuring the temperature
Ensure stable air during temperature
measurement
Please note that the measuring
distance is in the range of 5-10cm
Please wait for 20 minutes, and measure the body temperature
after the tested person adapts to the measuring environment.
Meaning
Note: refer to the
attached documents
Low voltage prompt
Do not discard it at
random.
Meaning
Refer to instructions
for use.
Type B application
part
Part name
PCB board (including LCD)
Battery
Shell
Packaging materials
Harmful substance
Lead
Mercury
Cadmium Hexavalent
chromium Polybrominated
biphenyl Polybrominated
diphenyl ether
This form is prepared according to SJ/T 11364-2014.
O: indicates that the content of the hazardous substance in all homogeneous
materials of the par is below the limit requirement specified in GB/T 26572.
X: indicates that the content of the harmful substance in at least one homogeneous
material of the part exceeds the limit requirement specified in GB/T 26572.
The "hazardous substances" shown in this form will not cause any harm to human and
the environment under normal use of the product.
The "hazardous substances" and their existing parts shown in this form provide
information on the existence of relevant substances to consumers and recycling
practitioners, which is helpful for proper disposal of products when they are discarded.
One-year Free Warranty Card
Purchasing place:
Product model:
Purchasing date:
Address:
Tel: Postcode:
Email:
Body number:
Mobile phone:
Customer name:
Product name: Medical Infrared Thermometer
Product model: A66
Manufacturer:
Jiangxi AICARE Medical Technology Co., Ltd.
Inspector:
Name of registrant /manufacturer:
Jiangxi AICARE Medical Technology Co., Ltd.
Domicile:
South Side of South Ring Road, Le'an County, Fuzhou City,
Jiangxi Province (No. 1 Building, New Era Home Group, Le' an
County)
Contact information: 0794-6577516
Name of after-sales service unit:
Jiangxi AICARE Medical Technology Co., Ltd.
Contact information: 0794-6577516
Address:
South Side of South Ring Road, Le'an County, Fuzhou City,
Jiangxi Province (No. 1 Building, New Era Home Group, Le' an
County)
[Date of Approval and Modification of Manual]: March 06, 2020
XI. Reference Value of Body Temperature
1. Normal body temperature range at different measuring positions
Measuring part
Normal temperature (℃) Normal Fahrenheit （℉）
Anus
Oral cavity
Armpit
Ear
Forehead
36.6~38
97.8~100.4
35.5~37.5
95.9~99.5
34.7~37.3
94.4~99.1
35.8~38
96.4~100.4
36~37.2
97.4~98.4
-7-
Age
Normal temperature (℃)
Normal Fahrenheit （℉）
0~2 years old
36.4~38.0
97.5~100.4
3~10 years old
36.1~37.8
97.0~100.0
11~65
years old
35.9~37.6
96.6~99.7
>65 years old
35.8~37.5
96.4~99.5
XII. Advice
XIII. Care and Maintenance
-8-
XIV. Instructions for Waste Disposal
-9-
XV. Symbol Description
Symbol figure
Symbol figure
i
XVI. List of Product Accessories
One infrared thermometer, one manual and one certificate;
Names and Contents of Harmful Substances in Products
-10-
Certificate
This product meets the technical
requirements after inspection and is qualified.
Medical Infrared Thermometer
2) When the measuring switch is pressed (see product structure
⑦), the current temperature value is displayed on the current
display screen, and the measured data can be automatically stored
(press the up and down keys to check the latest 32 stored
measured data)
Notes:
1) Before measurement, please make sure there is no hair, sweat,
cosmetics or hats covering, etc.
2) When the forehead sweat or other reasons cause the forehead
temperature not to reflect the human temperature normally,
please aim at the posterior earlobe to measure the body
temperature. At the same time, please ensure that there is no hair,
sweat, cosmetics or hat covering, etc.
3) If the thermometer has not been used for a long time, the
environment temperature will be detected when it is used again,
and the startup time will be extended by 1-2 seconds.
4) Human temperature varies with different times of the day and is
also affected by other external conditions, such as age, sex, skin
color, etc.
2. Normal body temperature range of different ages
Human temperature varies with different times of the day and is
also affected by other external conditions, such as age, sex, skin
color, thickness, etc. Please refer to the following table for the
normal temperature range of different ages:
2. Product maintenance
If you encounter the following problems during use, please follow
the instructions in the maintenance instructions to find a solution.
If the problem still exists, please contact with our customer service.
1)LCD cannot display numerical values.
If the temperature is lower than 32℃ or higher than 42.9℃ in the
human measuring state, the LCD will display "Lo" or "HI" rather
than data.
2)LCD displays information "HI"
When using a non-contact electronic thermometer, the LCD
displays the information “HI", and it analyzes and shows that it
exceeds the measuring range or the measured temperature is
higher than 42.9℃ in the human temperature measuring mode.
3)LCD displays information "Lo"
When using a non-contact electronic thermometer, the LCD
displays the information "Lo", and it analyzes and shows that it is
lower than the measuring range or the measured temperature is
lower than 32℃ in the human temperature measuring mode.
When the information "Lo" or "Hi" appears, the following
situations are for reference:
■Direct disposal of electronic products and batteries in garbage
cans will cause harm to the environment. Please dispose them
according to the local laws.
■Don't throw the infrared thermometer in the garbage can at the
end of use; please dispose it according to the local laws or contact
with the manufacturer for recycling.
Notes:
The body temperature of women is different from that of men.
Generally, it is 0.3℃ higher than that of men. During ovulation, the
body temperature will be 0.3℃- 0.5℃ higher than the usual
temperature.
The protective glass outside the LCD frame is very important and
also the fragile part of the instrument, so it must be used carefully.
Please do not charge the non-rechargeable battery and do not
throw the battery into the fire.
Please do not expose the product to the sun or touch water.
1, Product maintenance and cleaning
1)The probe part is the most precise part of the product and must
be carefully protected.
2)Do not clean the product by using corrosive detergent.
3)Do not immerse this product in water or other liquids.
4)Place the product in a dry place to avoid dust, pollution and
direct sunlight.
5)Please clean the infrared thermometer regularly, usually once a
month. If necessary, the infrared thermometer can be cleaned
properly according to the actual dirty condition. Please clean the
infrared thermometer by dry soft cloth. If the instrument is
especially dirty, the main body can be wiped with dried cloth
stained with water or neutral detergent, and then it is wiped with
dry cloth.
6)The product will be calibrated automatically without manual
calibration.
The human body is a very complex bio-integrated system, and the
body temperature is an important data for the normal life activities
of the human body; usually, we measure the temperature of
forehead, cochlea, anus, oral cavity and armpit to detect our health
status; the body temperature measured in different parts will be
different. Please refer to the following table for specific differences:
Reasons for displaying information "Lo" or "HI"
The temperature value is affected by hair and sweat
The temperature is affected by airflow change;
The measuring distance is too far
Walking indoors from outdoor with low temperature or high temperature;
Suggestions
Ensure there are no obstacles when
measuring the temperature
Ensure stable air during temperature
measurement
Please note that the measuring
distance is in the range of 5-10cm
Please wait for 20 minutes, and measure the body temperature
after the tested person adapts to the measuring environment.
Meaning
Note: refer to the
attached documents
Low voltage prompt
Do not discard it at
random.
Meaning
Refer to instructions
for use.
Type B application
part
Part name
PCB board (including LCD)
Battery
Shell
Packaging materials
Harmful substance
Lead
Mercury
Cadmium Hexavalent
chromium Polybrominated
biphenyl Polybrominated
diphenyl ether
This form is prepared according to SJ/T 11364-2014.
O: indicates that the content of the hazardous substance in all homogeneous
materials of the par is below the limit requirement specified in GB/T 26572.
X: indicates that the content of the harmful substance in at least one homogeneous
material of the part exceeds the limit requirement specified in GB/T 26572.
The "hazardous substances" shown in this form will not cause any harm to human and
the environment under normal use of the product.
The "hazardous substances" and their existing parts shown in this form provide
information on the existence of relevant substances to consumers and recycling
practitioners, which is helpful for proper disposal of products when they are discarded.
One-year Free Warranty Card
Purchasing place:
Product model:
Purchasing date:
Address:
Tel: Postcode:
Email:
Body number:
Mobile phone:
Customer name:
Product name: Medical Infrared Thermometer
Product model: A66
Manufacturer:
Jiangxi AICARE Medical Technology Co., Ltd.
Inspector:
Name of registrant /manufacturer:
Jiangxi AICARE Medical Technology Co., Ltd.
Domicile:
South Side of South Ring Road, Le'an County, Fuzhou City,
Jiangxi Province (No. 1 Building, New Era Home Group, Le' an
County)
Contact information: 0794-6577516
Name of after-sales service unit:
Jiangxi AICARE Medical Technology Co., Ltd.
Contact information: 0794-6577516
Address:
South Side of South Ring Road, Le'an County, Fuzhou City,
Jiangxi Province (No. 1 Building, New Era Home Group, Le' an
County)
[Date of Approval and Modification of Manual]: March 06, 2020
XI. Reference Value of Body Temperature
1. Normal body temperature range at different measuring positions
Measuring part
Normal temperature (℃) Normal Fahrenheit （℉）
Anus
Oral cavity
Armpit
Ear
Forehead
36.6~38
97.8~100.4
35.5~37.5
95.9~99.5
34.7~37.3
94.4~99.1
35.8~38
96.4~100.4
36~37.2
97.4~98.4
-7-
Age
Normal temperature (℃)
Normal Fahrenheit （℉）
0~2 years old
36.4~38.0
97.5~100.4
3~10 years old
36.1~37.8
97.0~100.0
11~65
years old
35.9~37.6
96.6~99.7
>65 years old
35.8~37.5
96.4~99.5
XII. Advice
XIII. Care and Maintenance
-8-
XIV. Instructions for Waste Disposal
-9-
XV. Symbol Description
Symbol figure
Symbol figure
i
XVI. List of Product Accessories
One infrared thermometer, one manual and one certificate;
Names and Contents of Harmful Substances in Products
-10-
Certificate
This product meets the technical
requirements after inspection and is qualified.
Medical Infrared Thermometer
2) When the measuring switch is pressed (see product structure
⑦), the current temperature value is displayed on the current
display screen, and the measured data can be automatically stored
(press the up and down keys to check the latest 32 stored
measured data)
Notes:
1) Before measurement, please make sure there is no hair, sweat,
cosmetics or hats covering, etc.
2) When the forehead sweat or other reasons cause the forehead
temperature not to reflect the human temperature normally,
please aim at the posterior earlobe to measure the body
temperature. At the same time, please ensure that there is no hair,
sweat, cosmetics or hat covering, etc.
3) If the thermometer has not been used for a long time, the
environment temperature will be detected when it is used again,
and the startup time will be extended by 1-2 seconds.
4) Human temperature varies with different times of the day and is
also affected by other external conditions, such as age, sex, skin
color, etc.
2. Normal body temperature range of different ages
Human temperature varies with different times of the day and is
also affected by other external conditions, such as age, sex, skin
color, thickness, etc. Please refer to the following table for the
normal temperature range of different ages:
2. Product maintenance
If you encounter the following problems during use, please follow
the instructions in the maintenance instructions to find a solution.
If the problem still exists, please contact with our customer service.
1)LCD cannot display numerical values.
If the temperature is lower than 32℃ or higher than 42.9℃ in the
human measuring state, the LCD will display "Lo" or "HI" rather
than data.
2)LCD displays information "HI"
When using a non-contact electronic thermometer, the LCD
displays the information “HI", and it analyzes and shows that it
exceeds the measuring range or the measured temperature is
higher than 42.9℃ in the human temperature measuring mode.
3)LCD displays information "Lo"
When using a non-contact electronic thermometer, the LCD
displays the information "Lo", and it analyzes and shows that it is
lower than the measuring range or the measured temperature is
lower than 32℃ in the human temperature measuring mode.
When the information "Lo" or "Hi" appears, the following
situations are for reference:
■Direct disposal of electronic products and batteries in garbage
cans will cause harm to the environment. Please dispose them
according to the local laws.
■Don't throw the infrared thermometer in the garbage can at the
end of use; please dispose it according to the local laws or contact
with the manufacturer for recycling.
Notes:
The body temperature of women is different from that of men.
Generally, it is 0.3℃ higher than that of men. During ovulation, the
body temperature will be 0.3℃- 0.5℃ higher than the usual
temperature.
The protective glass outside the LCD frame is very important and
also the fragile part of the instrument, so it must be used carefully.
Please do not charge the non-rechargeable battery and do not
throw the battery into the fire.
Please do not expose the product to the sun or touch water.
1, Product maintenance and cleaning
1)The probe part is the most precise part of the product and must
be carefully protected.
2)Do not clean the product by using corrosive detergent.
3)Do not immerse this product in water or other liquids.
4)Place the product in a dry place to avoid dust, pollution and
direct sunlight.
5)Please clean the infrared thermometer regularly, usually once a
month. If necessary, the infrared thermometer can be cleaned
properly according to the actual dirty condition. Please clean the
infrared thermometer by dry soft cloth. If the instrument is
especially dirty, the main body can be wiped with dried cloth
stained with water or neutral detergent, and then it is wiped with
dry cloth.
6)The product will be calibrated automatically without manual
calibration.
The human body is a very complex bio-integrated system, and the
body temperature is an important data for the normal life activities
of the human body; usually, we measure the temperature of
forehead, cochlea, anus, oral cavity and armpit to detect our health
status; the body temperature measured in different parts will be
different. Please refer to the following table for specific differences:
Reasons for displaying information "Lo" or "HI"
The temperature value is affected by hair and sweat
The temperature is affected by airflow change;
The measuring distance is too far
Walking indoors from outdoor with low temperature or high temperature;
Suggestions
Ensure there are no obstacles when
measuring the temperature
Ensure stable air during temperature
measurement
Please note that the measuring
distance is in the range of 5-10cm
Please wait for 20 minutes, and measure the body temperature
after the tested person adapts to the measuring environment.
Meaning
Note: refer to the
attached documents
Low voltage prompt
Do not discard it at
random.
Meaning
Refer to instructions
for use.
Type B application
part
Part name
PCB board (including LCD)
Battery
Shell
Packaging materials
Harmful substance
Lead
Mercury
Cadmium Hexavalent
chromium Polybrominated
biphenyl Polybrominated
diphenyl ether
This form is prepared according to SJ/T 11364-2014.
O: indicates that the content of the hazardous substance in all homogeneous
materials of the par is below the limit requirement specified in GB/T 26572.
X: indicates that the content of the harmful substance in at least one homogeneous
material of the part exceeds the limit requirement specified in GB/T 26572.
The "hazardous substances" shown in this form will not cause any harm to human and
the environment under normal use of the product.
The "hazardous substances" and their existing parts shown in this form provide
information on the existence of relevant substances to consumers and recycling
practitioners, which is helpful for proper disposal of products when they are discarded.
One-year Free Warranty Card
Purchasing place:
Product model:
Purchasing date:
Address:
Tel: Postcode:
Email:
Body number:
Mobile phone:
Customer name:
Product name: Medical Infrared Thermometer
Product model: A66
Manufacturer:
Jiangxi AICARE Medical Technology Co., Ltd.
Inspector:
Name of registrant /manufacturer:
Jiangxi AICARE Medical Technology Co., Ltd.
Domicile:
South Side of South Ring Road, Le'an County, Fuzhou City,
Jiangxi Province (No. 1 Building, New Era Home Group, Le' an
County)
Contact information: 0794-6577516
Name of after-sales service unit:
Jiangxi AICARE Medical Technology Co., Ltd.
Contact information: 0794-6577516
Address:
South Side of South Ring Road, Le'an County, Fuzhou City,
Jiangxi Province (No. 1 Building, New Era Home Group, Le' an
County)
[Date of Approval and Modification of Manual]: March 06, 2020
Table of contents
Popular Thermometer manuals by other brands
ThermoWorks
ThermoWorks Thermapen Blue operating instructions
PCE Instruments
PCE Instruments PCE-IR-100 user manual
Livan
Livan BT0512-03 user manual
ECOWITT
ECOWITT WN34D instructions
VISIOMED
VISIOMED bewell connect MyThermo Pocket BW-MTX1 manual
Extech Instruments
Extech Instruments 407445 instruction manual
