Aim SoloDL Operation instructions

AIM Infotech
Ducati Hypermotard
Release 1.00

1
1
Bike years
This tutorialdescribes how to connect AIM SoloDL, EVO4 and ECU Bridge to Ducati Hypermotard from
2009 onward.
2
CAN bus connection
Ducati Hypermotard communicates through the CAN Busthat can be reached on an FCI connector
placed under thebike seat and shown herebelow.

2
3
Connection with AIM devices
Herefollow instructions on how to connect this Ducati biketo AIM SoloDL, EVO4 and ECU Bridge:
3.1
Connection with SoloDL
To connect SoloDL to this Ducati bike use the seven pins right Binder female connector placed under
the logger.This connection requires adedicated cable properly designed and developed by AIM
whose part number is V02569170.Through this cable you can also power yourSoloDL. Here below
SoloDL female Binder position with its pinout and the dedicated cable are shown.

3
3.2
Connection with EVO4
EVO4 has the CAN Bus on the ECU connector (highlighted inred here below). This connection requires
a dedicated cable properly designed and developed by AIM whose part numberisV02563150.
Please note:EVO4 needs externalpower. Refer to EVO4 user manual to know how to power the
logger.
Herebelow EVO4 RPM connector and the dedicated cableare shown.

4
3.3
Connection with ECU Bridge
ECU Bridge is available in different versions.The one that fits thisinstallation has partnumber
X90BGDDDA.Through the FCI connector you can also power yourECU Bridge.Here belowyou see
ECU Bridge with the FCIconnector.

5
4
AIM Loggerconfiguration
Once the ECU connected to the logger, thislastone is tobeconfigured as connected to thatECU.
Run Race Studio 2 softwareand follow this path:
•Device Configuration –> Select thedevice you are using;
•select theconfiguration or press “New” to create a newone;
•select ECUmanufacturer “Ducati” and ECUModel “Hypermotard”;
•transmit theconfiguration to the device pressing “Transmit”.
5
Available channels
Channels received by AIM devices connected to Ducati Hypermotard are:
ID CHANNEL NAME FUNCTION
ECU_1 HY_RPM RPM
ECU_2 HY_SPEED Vehicle speed
ECU_3 HY_THRT2 Throttleposition sensor 1
ECU_4 HY_THRT1 Throttleposition sensor 2
ECU_5 HY_ENGT Engine temperature
ECU_6 HY_IAT Intake airtemperature
ECU_7 HY_VBATT Battery supply
ECU_8 HY_GEAR Engaged gear
ECU_9 HY_OIL_LAMP Oil alarm
