18V Cordless Precision Clutch
Shut-O󰀨 Angle Nutrunner
Models: SPC-A21025Q
SPC-A21025
SPC-A21038
SPC-A21625Q
SPC-A21625
SPC-A21638
SPC-A23038
SPC-A23538
SPC-A25038
SPC-A27038
SPC-A210050

2
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com
- 2 -
FUNCTION GUIDE: ANGLE NUTRUNNER 3/8” & 1/2” SQ. DR
(A) (B)
(C)
(D)
(G)
(E)
(H)
(I)
(F)
(J)
(A) The angled head is indexable for multiple head positions.
(B) User can distinguish wrench model with color ring.
(C) Covered Torque Adjustment.
(D) LED light for workpiece illumination.
(E) LED indicator provides simple process information to the operator.
The signal is visible from any angle.
(F) Easy Press button for simple Forward/Reverse selection.
(G) Tool Trigger with repeat protection feature to avoid double hits on already
seated fastener.
(H) Ergonomic handle design provides optimal balance.
( I ) Easy attached sliding battery system.
(J) Lightweight Li-Ion battery pack delivers long tool operating times.

3
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com - 3 -
(A) (C)
(D)
(E)
(H)
(F)
(I)
(J)
(G)
(K)
(B)
FUNCTION GUIDE: ANGLE NUTRUNNER 1/4” QUICK CHANGE
(A) The angled head is indexable for multiple head positions.
(B) 1/4” Hex with quick change chuck.
(C) User can distinguish wrench model with color ring.
(D) Covered Torque Adjustment.
(E) LED light for workpiece illumination.
(F) LED indicator provides simple process information to the operator.
The signal is visible from any angle.
(G) Easy Press button for simple Forward/Reverse selection.
(H) Tool Trigger with repeat protection feature to avoid double hits on already
seated fastener.
( I ) Ergonomic handle design provides optimal balance.
(J) Easy attached sliding battery system.
(K) Lightweight Li-Ion battery pack delivers long tool operating times.

4
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com
- 4 -
General Safety
Work Area Safety
• Keep your work area clean and
well lit. Cluttered benches and dark
areas invite accidents.
• Do not operate power tools in
explosive atmospheres, such as
in the presence of flammable
liquids, gases, or dust. Power
tools create sparks which may ignite
the dust or fumes.
• Keep bystanders, children, and
visitors away while operating a
power tool. Distractions can cause
you to lose control.
Personal Safety
• Stay alert, watch what you are
doing and use common sense
when operating a power tool.
Do not use tool while tired or
under the influence of drugs,
alcohol, or medication. A moment
of inattention while operating power
tools may result in serious personal
injury.
• Dress properly. Do not wear loose
clothing or jewelry. Contain long
hair. Keep your hair, clothing, and
gloves away from moving parts.
Loose clothes, jewelry, or long hair
can be caught in moving parts.
WARNING! READ ALL INSTRUCTIONS. Always observe the safety regulations
applicable in your country to reduce the risk of fire, electric shock, and personal
injury. Understand the following safety instructions before attempting to operate this
product. Always wear eye protection when working with power tools. Keep these
instructions in a safe place.
SAVE THESE INSTRUCTIONS
• Do not overreach. Keep proper
footing and balance at all times.
Proper footing and balance
enables better control on the tool in
unexpected situations.
• Use safety equipment. Always
wear eye protection. Dust mask,
non-skid safety shoes, hard hat, or
hearing protection must be used for
appropriate conditions.
Tool Use and Care
• Use clamps or other practical
ways to secure and support the
work piece to a stable platform.
Holding the work piece by hand or
against your body is unstable and
may lead to loss of control.
• Do not force tools. Use the
correct tool for your application.
The correct tool will do the job better
and safer at the rate for which it is
designed.
• Do not use tool if switch does
not turn it on or off. Any tool that
cannot be controlled with the switch
is dangerous and must be repaired.
• Store idle tools out of reach of
children and other untrained
persons. Tools are dangerous in the
hands of untrained users.

5
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com - 5 -
• Check for misalignment or
binding of moving parts, breakage
of parts, and any other condition
that may affect the tool operation.
If damaged, have the tool serviced
before using. Many accidents are
caused by poorly maintained tools.
• Use only Signature Series
recommended accessories for
your model tool. Accessories that
may be suitable for one tool, may
become hazardous when used on
another tool.
Service
• Tool service must be performed
only by qualified repair personnel.
Service or maintenance performed
by unqualified personnel could
result in a risk of injury.
• When servicing an AIMCO
Signature Series Precision Clutch
tool it is important to use AIMCO
Signature Series parts and all
work should be undertaken by a
qualified AIMCO Signature Series
Authorized Technician. Use of
unauthorized parts or work performed
by a non-authorized technician will
void warranty and may create a risk
of damage to the tool, risk of electric
shock, or injury to a user.
Additional Safety Rules
Battery Charger
Caution: To reduce risk of injury, charge
only the authorized batteries. Other
types of batteries may burst, causing
personal injury and damage.
• Before using battery charger, read
all instructions and cautionary
markings on batteries, chargers, and
products using batteries.
• Do not allow anything to cover or
clog the charger vents.
• Do not expose charger to rain, snow,
or wet conditions.
• To reduce the risk of damage to
electric plug and cord, pull by plug
rather than cord when disconnecting
charger.
• Use of an attachment not
recommended or sold by the
manufacturer may result in a risk
of fire, electric shock, or injury to
persons.
• Make sure cord for charger is located
so that it will not be stepped on,
tripped on, tripped over, or otherwise
subjected to damage or stress.
• Do not abuse the power cord. Never
use the cord to carry the charger.
Keep cord away from heat, oil,
water, sharp edges, or moving
parts. Replace damaged cords
immediately.
• Do not operate charger if it has
been damaged in any way. Take it to
a qualified service center for repair.
• To reduce risk of electric shock,
unplug charger from outlet before
attempting any maintenance or
cleaning. Turning off controls will not
reduce this risk.
• Do not disassemble charger or
battery cartridge. Take it to a qualified
service center when repair is required.
Incorrect reassembly may result in a
risk of electric shock or fire.

6
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com
- 6 -
Battery Pack
• Do not charge battery pack when
temperature is below 0°C (32°F) or
above 40°C (104°F).
• Do not attempt to use a step-down
transformer, an engine generator, or
DC power receptacle.
• Do not short the battery pack: Do
not touch the terminals with any
conductive material. Avoid storing
battery cartridge in a container with
other metal objects such as nails,
coins, paper clips, etc.
• Do not expose battery cartridge to
water or rain. A battery short can
cause large current flow, overheating,
possibly burns, and even a breakdown.
• Do not store the machine and
battery pack in locations where the
temperature may reach or exceed
50°C (122°F).
• Do not incinerate the battery pack
even if it is severely damaged or
completely worn out. The battery
pack can explode in a fire.
• Be careful not to drop, shake, or
strike the battery.
• Do not charge inside a box or
container of any kind. The battery
must be placed in a well-ventilated
area during charging.
• Do not dispose of battery packs
into household waste, fire or water.
Battery packs should be collected,
recycled or disposed of in an
environmentally-friendly manner. Call
authorized warranty centers for
locations to dispose of damaged or
inoperable batteries.
Functional Description
The Signature Series Precision Clutch
industrial shut off wrench is designed
for nut tightening/loosening and screw
driving/loosening. It is not appropriate to
use for wood/mild steel drilling. Please
refer to Figure 1 to familiarize yourself
with the major components of this tool
before use.
5
6
2
4
3
1
7
Figure 1
1. Power Switch
Depressing the power switch will
energize the LED light (2) in front
and the tool starts to rotate. When
released, power to the motor
ceases and the tool stops working
immediately. The LED light will
remain on for 5 seconds, then shut
off.
2. LED Light
3. Forward/Reverse Button
The tool is always in forward
operation unless the Forward/
Reverse button is pressed. When
the button is pressed, the blue LED
shows and the tool will be in reverse
operation. To switch tool back to
forward operation, simply press

7
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com - 7 -
the button again. The blue LED
disappears and the tool is back in
forward operation.
4. Anvil (Drive Shaft)
The anvil will accept any 1/4” hex
bit or 1/2” square drive hex socket
depending on specific model. Be
sure the bit/socket is fully engaged
before operating the tool. Otherwise,
the bit/socket may detach and
cause property damage or personal
injury. Use only impact-type sockets
or industrial grade bits.
5. Angle Head Orientation
Adjust the angle head kit to the
degree you wish. (in 45° increments
for a total of eight positions for head
orientation).
6. Torque Adjustment Cover
Open the torque adjustment cap. Use
the supplied torque adjustment tool
to either tighten or loosen the spring
until the desired torque is reached.
7. Li-Ion Battery
This battery provides electrical
power to the motor. Please charge
it according to the charging
instructions listed in this manual.
WARNING: Use the tool to either
tighten or loosen nuts and screws ONLY
in stipulated torque and voltage ranges.
Assembly
Check for damage to the tool, parts, or
accessories that may have occurred
during transport. Take the time to
thoroughly read and understand this
manual prior to operation.
This tool kit contains:
1 - 18V Signature Series Cordless
Precision Clutch Shut off Angle
Tool
1 - 18V Li-Ion Battery Pack
1 - Torque Adjustment Tool
1 - Angle Head Adjustment Tool
4 - Color Rings for tool Identification
1 - Instruction Manual
Attaching or Removing Battery Pack
1. To connect battery, line up the tracks
and attach the battery pack. Slide
toward the battery pack until it locks
into position with a click.
SLIDE

8
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com
- 8 -
2. To remove the battery pack, press the
red button on the top of the battery
pack and release the battery pack.
1. PRESS
2. RELEASE
This product has been carefully
inspected prior to leaving the factory.
It should provide you with years
of satisfying service under normal
operating conditions. Do not, however,
force the tool to perform outside its
design parameters. Such usage will void
the warranty.
WARNING! Read the instruction
manual before operating the tool.
Always wear safety glasses or
face shields when operating this
product. Failure to do so can result
in injury.
1. Slide battery into the bottom of the
housing handle until a click sound
occurs. Do not force battery: It
should slide easily into place with
nominal force. Any difficulty doing
so indicates incorrect alignment.
2. Tool speed is preset to the maximum
range of the tool. With an SPC-
2PGM External Programming
Module (optional accessory), tool
speeds may be reset to a lower
speed within the range of the tool.
3. Select a proper size socket/drive
bit and insert into the quick change
holder or install onto the square
drive of the tool.
4. Depress the trigger to engage the
LED light and start the tool.
5. When the pre-set torque is reached,
the tool’s precision clutch will shut
off the tool automatically.
6. Prior to using on an application, it is
advised to verify the output torque
of the tool as set. Check the torque
on an Auditor™ Digital Tester (or
comparable system).
7. Delivered torque to the application
may vary due to the type of joint
the tool is tightening. Good practice
is to perform periodic audits of
the application. Auditor™ Torque
Wrenches or Rotary Transducers are
ideally suited to make these checks.
Forward/Reverse Rotation Switch
Operation
To prevent damage, do not press
Forward/Reverse button until the tool
comes a complete stop.
Forward Rotation Operation
The tool is in forward operation if the
blue light is unlit.

9
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com - 9 -
Reverse Rotation Operation
By long pressing the F/R switch, users
are able to choose the mode of reverse
operation, either automatic or manual.
Mode 1: Automatic – Tool returns
to forward operation automatically
after reverse operation.
Mode 2: Manual – Tool needs to
be adjusted manually to return to
forward operation after reverse
operation.
Steps for Torque Adjustment
NOTE: Remove the battery pack before
adjusting the torque to avoid injury.
1. Open the cover and use an open end
wrench (or torque adjustment tool
on quick change models) to rotate
the square drive until the adjust hole
position appears below the cover.
Adjust Hole Cover
Square Hole
2. Turn the torque adjustment tool
clockwise to increase the torque
and counterclockwise to decrease
the torque.
Press
Increase
Decrease
Steps for Angle Head Position
Indexing
1 Use an open end wrench and the
supplied adjustment wrench to
loosen the nut by turning in the
opposite direction to remove the
angle head assembly.

10
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com
- 10 -
2. Adjust the angle head assembly to
the degree you wished then put it
back on the tool (in 45° increments
for a total of eight positions for head
orientation).
3. Use an open end wrench and
the supplied adjustment wrench
to tighten the nut by turning in
opposite direction to complete angle
adjustment.

11
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com - 11 -
TOOL LED INDICATIONS
Status of the LED indicator
and Beep Status of the Tool
Action to be
Taken
LED lights RED, YELLOW, and
GREEN together for one second.
A long beep for one second
The motor is switched
on None required
LED lights RED for one second.
A long beep for one second
The preset torque is
not reached (NOK)
The application
should be
reworked
LED lights RED for one second.
A long beep for one second
The screw has been
refastened after
already tight-Double
Hit (NOK)
The application
should be
reworked
LED lights GREEN.
The preset torque
is reached and the
tightening is OK
None required
LED Blinks YELLOW five times.
Five short beeps Battery power is low
Recharge battery
or replace with
fully charged
battery
LED lights YELLOW for five seconds.
A long beep for five second.
Battery power is too
low for tool operation
and tool will not run
Recharge battery
or replace with
fully charged
battery
LED lights BLUE The tool is set to run in
reverse operation None required
LED lights RED twice
Tool temperature is too
hot. Warning to protect
tool from damage
Remove battery
and allow tool to
cool
LED lights RED three times The motor has a failure Send tool in for
service
LED lights RED four times Internal connector wire
has failed
Send tool in for
service

12
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com
- 12 -
CHARGING THE BATTERY PACK
Li-ion Battery Pack
NOTE: Your battery pack is not fully
charged at the time of purchase. Be
sure to charge battery before first use.
• Batteries should be charged in
ambient temperatures between 0° C
(32° F) and 40° C (104° F). Charging
outside this range will result in either
less than full charge or damage to
the battery pack.
• Allow the charger to cool when
charging more than two battery
packs consecutively.
• Do not insert finger/body parts or
foreign objects into contact area of
charger.
1. Place charger in a relatively cool and
well-ventilated area.
2. Plug charger into the AC outlet.
CAUTION: Ensure that the power
source to be utilized conforms to the
power requirement specified on the
charger nameplate.
3. Turn the battery upside-down and
slide the battery into charger while
keeping the alignment marks line
up. Slide the forward in the direction
of the arrow. Do not force battery:
It should slide easily into place with
nominal force. Any difficulty doing so
indicates incorrect alignment.
4. If the power lamp (RED) does
not light immediately or goes out
soon after the charger is plugged
in, consult a Signature Series
authorized dealer.
5. During charging, the charging lamp
(GREEN) will start flashing. When
charging is completed, an internal
electronic switch will automatically
be triggered to prevent overcharging.
- Charging will not start if the
battery pack is warm. For example,
immediately after high duty cycle
operation. The YELLOW standby
lamp will flash until the battery
temperature drops to where safe
charging is possible.
6. If the temperature of the battery
pack is 0° C (32° F) or less, charging
will take longer to fully charge the
battery pack than standard charging
time. At this low temperature, even
when the battery is fully charged, it
will have approximately 50% of the
power of a fully charged battery at
normal operation temperatures.
7. Once the battery is fully charged, the
GREEN lamp will light to indicate
the charger has entered into a trickle
charge mode.

13
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com - 13 -
Red Light
Charger is plugged into the AC outlet. Ready to charge.
Yellow Flashing Light
(1) When the temperature of the battery is too low (<0° C (<32° F)), it
is in a trickle charge mode until the temperature of the battery
goes up to over 0° C (<32° F). The lamp will change from
the Yellow Flashing to Green Flashing automatically and start
to charge. (If after 70 minutes, the lamp changes from yellow
flashing to yellow lit, consult an authorized dealer.)
(2) When the temperature of the battery is too high (>40° C
(104° F)), it is in a trickle charge mode until the temperature of
the battery drops to under 40° C (104° F). The lamp will change
from the Yellow Flashing to Green Flashing automatically and
start to charge. (If after 70 minutes, the lamp changes from yellow
flashing to yellow lit, consult an authorized dealer.)
(3) When the voltage of the battery is too low (below 14.4 voltage),
it is in a trickle charge mode until the voltage of the battery
reaches to the standard value. The lamp will change from the
Yellow Flashing to Green Flashing automatically and start to
charge. (If after 20 minutes, the lamp changes from yellow
flashing to yellow lit, consult an authorized dealer.)
Yellow Light
The battery and the charger are not connected. If the yellow lit still on
after trying re-attach the battery, consult an authorized dealer.
Green Flashing Light
Now start charging Light
Green Flashing Light
Battery is approximately 50% charged.
Green Flashing Light
Battery is approximately 80% charged.
Green Light
Charging is complete. (Fully charged.)
LAMP INDICATIONS

14
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com
- 14 -
SPECIFICATIONS
MODEL MODEL MODEL
SPC-A21025Q SPC-A21025 SPC-A21038
Voltage 18 VDC 18 VDC 18 VDC
Drive Size 6.35 mm Hex. (1/4”) 6.35 mm Sq. (1/4”) 9.5 mm Sq. (3/8”)
Torque Range 3 ~ 12 Nm 3 ~ 12 Nm 3 ~ 12 Nm
Free Speed 400 ~ 1000 rpm 400 ~ 1000 rpm 400 ~ 1000 rpm
Weight w/o Battery 1.6 kg (3.5 lb) 1.6 kg (3.5 lb) 1.6 kg (3.5 lb)
Vibration (m/s2) 2.63 2.63 2.63
Sound level (dBA) <75 <75 <75
Battery Type Li-Ion 2.0A.h Li-Ion 2.0A.h Li-Ion 2.0A.h
Charge Time Approx. 45 min Approx. 45 min Approx. 45 min
SPC-A21625Q SPC-A21625 SPC-A21638
Voltage 18 VDC 18 VDC 18 VDC
Drive Size 6.35 mm Hex. (1/4”) 6.35 mm Sq. (1/4”) 9.5 mm Sq. (3/8”)
Torque Range 5 ~ 18 Nm 5 ~ 18 Nm 5 ~ 18 Nm
Free Speed 300 ~ 600 rpm 300 ~ 600 rpm 300 ~ 600 rpm
Weight w/o Battery 1.6 kg (3.5 lb) 1.6 kg (3.5 lb) 1.6 kg (3.5 lb)
Vibration (m/s2) 2.63 2.63 2.63
Sound level (dBA) <75 <75 <75
Battery Type Li-Ion 2.0A.h Li-Ion 2.0A.h Li-Ion 2.0A.h
Charge Time Approx. 45 min Approx. 45 min Approx. 45 min
SPC-A23038 SPC-A23538 SPC-A25038
Voltage 18 VDC 18 VDC 18 VDC
Drive Size 9.5 mm Sq. (3/8”) 9.5 mm Sq. (3/8”) 9.5 mm Sq. (3/8”)
Torque Range 8 ~ 30 Nm 10 ~ 35 Nm 10 ~ 50 Nm
Free Speed 250 ~ 480 rpm 200 ~ 330 rpm 200 rpm
Weight W/O Battery 1.6 kg (3.5 lb) 1.6 kg (3.5 lb) 1.6 kg (3.5 lb)
Vibration (m/s2) 2.55 2.55 2.55
Sound level (dBA) <75 <75 <75
Battery Type Li-Ion 2.0A.h Li-Ion 2.0A.h Li-Ion 2.0A.h
Charge Time Approx. 45 min Approx. 45 min Approx. 45 min
SPC-A27038 SPC-A210050
Voltage 18 VDC 18 VDC
Drive Size 9.5 mm Sq. (3/8”) 12.7 mm Sq. (1/2”)
Torque Range 20 ~ 70 Nm 35 ~ 100 Nm
Free Speed 170 rpm 119 rpm
Weight w/o Battery 2.9 kg (6.3 lb) 3.4 kg (7.4 lb)
Vibration (m/s2) 2.55 2.55
Sound level (dBA) <75 <75
Battery Type Li-Ion 2.0Ah Li-Ion 2.0Ah
Charge Time Approx. 45 min Approx. 45 min

15
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com - 15 -
NOISE AND VIBRATION LEVEL DECLARATION (Max. value) EN 60745-2-2
Models: 16 Nm and below
Sound pressure level (no load) LpA: 66.7 dBA Uncertainty K: 1.5 dB
Sound power level (no load) LwA: 77.7 dBA Uncertainty K: 1.5 dB
Vibration total value (no load) ahd: 0.6 m/s2Uncertainty K: 1.5 m/s2
Models: 30 Nm and above
Sound pressure level (no load) LpA: 67.8 dBA Uncertainty K: 1.5 dB
Sound power level (no load) LwA: 78.8 dBA Uncertainty K: 1.5 dB
Vibration total value (no load) ahd: 0.3 m/s2Uncertainty K: 1.5 m/s2
The declared noise levels and vibration total value has been measured in accor-
dance with a standard test method and may be used for comparing one tool with
another. The declared noise levels and vibration total value may also be used in a
preliminary assessment of exposure.
WARNING:
− The noise and vibration emission during actual use of the power tool can differ
from the declared total value depending on the ways in which the tool is used; and
− Need to identify safety measures to protect the operator that are based on an
estimation of exposure in the actual conditions of use (taking account of all parts
of the operating cycle such as the times when the tool is switched off and when
it is running idle in addition to the trigger time).

16
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com
- 16 -
ANGLE HOUSING UNITS
For models: SPC-A21025 SPC-A21625 SPC-A21038
SPC-A21638 SPC-A23038 SPC-A23538
Index # Description Q’ty Index # Description Q’ty
a Collar 1 f Angle Housing Assembly 1
b Lock Nut 1 g O-Ring 1
c Lock Nut 1 h Screw 1
d Main Bevel Gear Assembly 1 i Bevel Gear Assembly 1
e Washer 1 j Lock Nut 1
For models: SPC-A25038 SPC-A27038
Index # Description Q’ty Index # Description Q’ty
a Lock Nut f Screw 1
b Collar 1 g O-Ring 1
c Lock Nut 1 h Bevel Gear Assembly 1
d Main Bevel Gear Assembly 1 i Lock Nut 1
e Angle Housing Assembly 1
Specific Part Numbers may be obtained by review of the correct Signature Series tool
breakdown. Consult your Signature Series dealer for details.

17
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com - 17 -
For model: SPC-210050
For Models: SPC-A21025Q SPC-A21625Q
Index # Description Q'ty Index # Description Q’ty
a Collar 1 i Bevel Gear Assembly 1
b Lock Nut 1 j Steel Ball 2
c Lock Nut 1 k Lock Nut 1
d Main Bevel Gear Assembly 1 l Snap Ring 1
e Washer 1 m Quick Change Holder 1
f Angle Housing Assembly 1 n Spring 1
g O-Ring 1 o Hold Spacer 1
h Screw 1 p Anvil Collar 1
c
b
d
e
a
f
Index # Description Q’ty Index # Description Q’ty
a Collar 1 d Belleville Washer 1
b Lock Nut 1 e Angle Head Assembly 1
c Angle Head Adapter 1 f Retaining Pin 2
Specific Part Numbers may be obtained by review of the correct Signature Series tool
breakdown. Consult your Signature Series dealer for details.
ANGLE HOUSING UNITS

18
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com
- 18 -
CLUTCH UNITS
For Models: SPC-A21025Q SPC-A21025 SPC-A21038
SPC-A21625Q SPC-A21625 SPC-A21638
SPC-A23038 SPC-A23538 SPC-A25038
SPC-A27038 SPC-A210050
Index # Description Q'ty Index # Description Q'ty
a Clutch Assembly 1 f Washer 1
b Steel Ball 4 g Adjust Washer 1
c Washer 1 h Adjust Nut 1
d Washer 1 i Snap Ring 1
e Spring 1
Specific Part Numbers may be obtained by review of the correct Signature Series tool
breakdown. Consult your Signature Series dealer for details.

19
10000 SE Pine St. Portland, Oregon 97216
Phone: [phone] www.aimco-global.com - 19 -
GEAR BOX UNITS
For Models: SPC-A21025Q SPC-A21025 SPC-A21038
SPC-A21625Q SPC-A21625 SPC-A21638
SPC-A23038 SPC-A23538
For Models: SPC-A25038 SPC-A27038 SPC-A210050
Index
#
Description Q’ty Index
#
Description Q’ty Index
#
Description Q’ty
a Snap Ring 1 d Gear Cage Ass’y 1 g Gear Box Ass’y 1
b Washer 1 e Washer 1 (1) O-ring 1
c Planet Gear 6 f Gear Plate Ass’y 1
Index
#
Description Q’ty Index
#
Description Q’ty Index
#
Description Q’ty
a Snap Ring 1 d Gear Cage Ass’y 1 g Gear Plate Ass’y 1
b Washer 1 e Washer 1 h Gear Box Ass’y 1
cPlanet Gear 3 f Planet Gear 3 h (1) O-ring 1
Specific Part Numbers may be obtained by review of the correct Signature Series tool
breakdown. Consult your Signature Series dealer for details.

LIT-MAN253 Rev. 07/2020
Printed in USA ©2020 AIMCO
CORPORATE HEADQUARTERS
10000 SE Pine Street
Portland, Oregon 97216
Phone: [phone]
Toll Free: 1-800-852-1368
AIMCO CORPORATION DE MEXICO SA DE CV
Ave. Cristobal Colon 14529
Chihuahua, Chihuahua. 31125
Mexico
Phone: [phone]
Fax: [phone]
WWW.AIMCO-GLOBAL.COM
