Aimco AcraDyne AB-CTA User manual

AB-CTA, AB-MTA, & AB-MCA CORDLESS TOOL
OPERATING INSTRUCTIONS
10000 SE Pine St., Portland, Oregon 97216
Phone: [phone]
www.aimco-global.com
ABP Model ABS Model ABN Model ABT Model

- 2 -
1. IMPORTANT INFORMATION 6
2. GENERAL INFORMATION 6
2.1.0. Importance of the operating instructions . . . . . . . . . . . . . . . . . 6
2.2.0. Proper intended use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.3.0. Improper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.4.0. Guarantee and liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3. BASIC SAFETY INSTRUCTIONS 9
3.1.0. Notices in the operating instructions . . . . . . . . . . . . . . . . . . . . 9
3.2.0. Operator‘s responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2.1. Personnel‘s responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2.2. Personnel training . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.3.0. Risks when working with the tool . . . . . . . . . . . . . . . . . . . . . . 9
3.4.0. Danger from electrical energy . . . . . . . . . . . . . . . . . . . . . . . 10
3.4.1. Fundamental safety measures . . . . . . . . . . . . . . . . . . . . . . . 10
3.4.1. Workplace safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.4.2. Electrical safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.4.3. Personal safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.4.4. Using and handling the power tool . . . . . . . . . . . . . . . . . . . . 11
3.4.5. Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.5.0. Lithium-ion battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.6.0. Cleaning and disposing of the tool . . . . . . . . . . . . . . . . . . . . 14
3.7.0. Risk of injury and damage to the tool . . . . . . . . . . . . . . . . . . . 14
4. START-UP 15
4.1.0. Installing or removing the battery . . . . . . . . . . . . . . . . . . . . . 15
4.1.1. Trigger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1.2. Rotating direction switch. . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1.3. LED / Barcode scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1.4. Multi-color LED control light . . . . . . . . . . . . . . . . . . . . . . . . 17
4.2.0. Setting the tightening torque. . . . . . . . . . . . . . . . . . . . . . . . 18
4.3.0. Cancel job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.4.0. Back-up strategy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.5.0. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5. DISPLAY 22
5.1.0. Status Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6. ACCESSORIES 29
7. TECHNICAL DATA 30
7.1.0. CTA Model Specications . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.2.0. MTA Model Specications . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7.3.0. MCA Model Specications . . . . . . . . . . . . . . . . . . . . . . . . . . 34
TABLE OF CONTENTS

- 3 -
Disposal
Power tools, batteries, accessories and
packaging must be disposed of at an
environmentally-compatible recycling
facility. Power tools and batteries do not go into the household trash.
Transport
Li-Ion batteries are subject to specications in the laws pertaining to
hazardous goods. The batteries can be transported on roads by the
user without further constraints.
When shipping with third parties (e.g.: freight forwarders), special
requirements must be observed for packaging and labeling.
Only ship batteries if the casing is not damaged. Cover the contacts
with tape and package the battery so it cannot move around in
the packaging. Please comply with other national and international
requirements.
This warning symbol indicates additional information that
will make your work easier.
General warning to prevent operating errors and failures.
This indicates a direct hazard for the worker or the tool.
This warning symbol is especially important and must
be observed.

- 4 -
13
8
7
6
5
1
2
3
4
12
11
10
9
14
1
2
4
13a
7
6
5
1
3
11
10
9
12
Straight Tool
13b Angle Tool
8
14
1OLED Display
2Multi-color LED control light
3Brushless high-powered
motor
4Color index
5CW / CCW switch
6 Large trigger
7Ergonomical handle
8USB interface (in battery
compartment)
9Powerful LED
10 Optional WiFi module
11 Optional scanner
12 Premium Li-Ion battery
13 1/4“ hex socket adapter (Pistol
Tool)
13a 1/4” hex socket adapter (Straight
Tool)
13b 3/8” square adapter (Angle Tool)
14 Clutch Access (MTA & MCA
models)
Pistol Tool Features Stranght and Angle Tool Features
1

- 5 -
Tool conguration determines which functions can
be used. Furthermore each basic function has many
subfunctions.
FEATURE MTA
MODEL
CTA
MODEL
MCA
MODEL
Clutch Shut-Off Tool that Measures Torque and
Reports Angle
Transducer Shut-Off Tool that Controls Torque
and Angle
Clutch Shut-Off Tool that Monitors Torque as
Determined by Current and Reports Angle
Five Programmable Configurations with only
one tool:
• Torque
• Angle
• RPM
• Time
• Fastening Directions
Six step, 100 job functionality
Free Software
Interchangeable Battery, USB, Charger
Brushless Motor
Maintenance Indicators
100 Parameter Sets
Operator Feedback and Battery Status on LED
display module
Large Storage Capacity – 150,000 data results
w/curves on the tool
Can run with iBC ACE Controller
Tactile Feedback
Barcode Scanner
Tool Programming Software loadable through
USB cable interface
Long lasting Lithium-Ion Battery
Wireless Communication
Ergonomic

- 6 -
2. GENERAL INFORMATION
2.1.0. IMPORTANCE OF THE OPERATING INSTRUCTIONS
This information was written with the intention of being read, understood
and complied with in all points by persons responsible for the operation
of the AIMCO tool.
Prior to start-up, please read the operating instructions and comply
with the safety instructions. Work station faults can only be prevented
if the contents of these operating instructions are known and fault-free
operation can be ensured.
We are not liable for damages and operational errors that result from
non-compliance with these operating instructions. If difculties arise ,
please contact us and we will gladly provide assistance.
2.2.0. PROPER INTENDED USE
The tool may only be used, as described in these instructions, to create
fastener joints suitable for the type of tool.
Proper intended use also includes:
• complying with all of the the operating instructions
• complying with inspection and maintenance work.
Before you put the tool down, wait until it has come to
a complete stop; otherwise, the tool can jam and you
may lose control of the tool.
1. IMPORTANT INFORMATION
When tightening and loosening fasteners, high reaction
torques can occur. Therefore, always keep a tight grip
on the tool.
Switch the electrical device off immediately if the
tool used locks up and be prepared for high reaction
torques that can cause kickback. The tool locks up
when it is overloaded or jams in the workpiece.

- 7 -
2.4.0. GUARANTEE AND LIABILITY
NEW TOOL AND ACCESSORY WARRANTY
Any new tool or accessory branded with the AIMCO, Uryu, AcraDyne
or Eagle Industries name, and purchased from AIMCO, or through one
of its authorized distributors or agents, is warranted to the original buyer
against defects in materials and workmanship for a period of one (1)
year* from date of delivery. Under the terms of this warranty, AIMCO
will repair or replace any product or accessory warranted hereunder
and returned freight prepaid proving to AIMCO’s satisfaction to be
defective as a result of workmanship or materials. In order to qualify for
this warranty, written notice to AIMCO must be given immediately upon
discovery of such defect, at which time AIMCO will issue an authorization
to return the tool. The defective item must be promptly returned to an
authorized AIMCO service center with all freight charges prepaid.
REPAIRED TOOL WARRANTY
Once a tool is beyond the new product warranty period as detailed
above, AIMCO repairs are subject to the following warranty periods:
pneumatic tools: 90 days*; electric tools and Acra-Feed: 90 days;
battery tools: 30 days*; DC Electric tools: 90 days*
EXCLUSION FROM WARRANTY
This warranty is valid only on products purchased from AIMCO,
or thru its authorized distributors or agents. AIMCO shall have no
obligation pursuant to the AIMCO Warranty with respect to any tools
or accessories which in AIMCO’s sole judgment have been altered,
damaged, misused, abused, badly worn, lost or improperly maintained.
This Warranty is null and void if the customer, or any other person other
than an authorized representative of AIMCO, has made any attempt
to service or modify the tool or accessory prior to its return to AIMCO
under this Warranty.
Any other use beyond this is not considered proper intended use.
AIMCO is not liable for any damages resulting from non-compliance.
2.3.0. IMPROPER USE
AIMCO is not liable for damages and operational errors that result from
non-compliance with these operating instructions or improper use.
The tool is not a torque wrench. This tool cannot be
used for already tightened connections because very
high reaction torques can cause the motor control and
the motor to overheat.

- 8 -
The warranty provision with respect to each such product may be
amended by AIMCO from time to time in its sole discretion. The liability
of AIMCO hereunder shall be limited to replacing or repairing, at its
option, any products which are returned freight prepaid to AIMCO
and which AIMCO determines to be defective as described above or,
at AIMCO’s option, refunding the purchase price of such products.
AIMCO reserves the right to make periodic changes in construction or
tool design at any time. AIMCO specically reserves the right to make
these changes without incurring any obligation or incorporating such
changes or updates in tools or parts previously distributed.
THE AIMCO WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES,
EXPRESSED OR IMPLIED, AND AIMCO EXPRESSLY DISCLAIMS ANY
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. THIS WARRANTY SETS FORTH THE SOLE AND EXCLUSIVE
REMEDY IN CONTRACT, TORT, STRICT LIABILITY, OR OTHERWISE.
THIS WARRANTY IS THE ONLY WARRANTY MADE BY AIMCO WITH RESPECT
TO THE GOODS DELIVERED HEREUNDER, AND MAY BE MODIFIED
OR AMENDED ONLY BY A WRITTEN INSTRUMENT SIGNED BY A DULY
AUTHORIZED OFFICER OF AIMCO.
LIMITATION OF LIABILITY
AIMCO’S LIABILITY PURSUANT TO WARRANTY OF THE PRODUCTS
COVERED HEREUNDER IS LIMITED TO REFUND OF THE PURCHASE PRICE.
IN NO EVENT SHALL AIMCO BE LIABLE FOR COSTS OF PROCUREMENT
OF SUBSTITUTE GOODS BY THE BUYER. IN NO EVENT SHALL AIMCO BE
LIABLE FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL OR OTHER
DAMAGES (INCLUDING WITHOUT LIMITATION, LOSS OF PROFIT)
WHETHER OR NOT AIMCO HAS BEEN ADVISED OF THE POSSIBILITY
OF SUCH LOSS, HOWEVER CAUSED, WHETHER FOR BREACH OR
REPUDIATION OF CONTRACT, BREACH OF WARRANTY, NEGLIGENCE
OR OTHERWISE. THIS EXCLUSION ALSO INCLUDES ANY LIABILITY WHICH
MAY ARISE OUT OF THIRD PARTY CLAIMS AGAINST BUYER. THE ESSENTIAL
PURPOSE OF THIS PROVISION IS TO LIMIT THE POTENTIAL LIABILITY OF
AIMCO ARISING OUT OF THIS AGREEMENT AND/OR SALE.
Note: The AIMCO Warranty confers specic legal rights, however
some states or jurisdictions may not allow certain exclusions or
limitations within this warranty.
* All warranty periods addressed herein are determined using a
standard shift, eight-hour work day.

- 9 -
3. BASIC SAFETY INSTRUCTIONS
3.1.0. NOTICES IN THE OPERATING INSTRUCTIONS
• The basic requirement for safe and proper use and fault-free
operation is knowledge of the basic safety instructions and safety
regulations.
• In addition, the rules and regulations for the place of use must be
followed.
3.2.0. OPERATOR‘S RESPONSIBILITY
The operator is obligated to only allow persons to work with this tool
who are familiar with the basic regulations for work safety and accident
prevention and are trained in how to use the tool. Safety-conscious
work of the personnel must be checked at regular intervals.
3.2.1. PERSONNEL‘S RESPONSIBILITY
All persons working with this tool are obligated to comply with the basic
regulations for work safety and accident prevention prior to starting
work.
3.2.2. PERSONNEL TRAINING
Only trained and qualied personnel may work with this tool. The
responsibilities of the personnel for the assembly, start-up, operation,
maintenance, and servicing must be clearly dened. Personnel-in-
training may only operate the tool in the presence of an experienced
person.
3.3.0. RISKS WHEN WORKING WITH THE TOOL
Faults that may hinder safety must be immediately rectied.
The tool was built in accordance with state-of-the-
art technology and approved safety regulations. Still,
when using it, risks to life and limb of the user or third
parties or other material assets may arise.
Only use the tool
• for the proper intended use
• in working order with regard to safety

- 10 -
Only allow a qualied electrician to perform work on
this tool. The electrical equipment of the tool must be
regularly inspected. Loose connections and charred
cables must be immediately repaired. If work must be
performed with the tool, remove the battery prior to
opening the device.
The terms "tool" and "power tool" used in the safety
instructions pertain to mains-operated power tools
(with power cable) and battery operated power
tools (without power cord).
The tool must be kept closed at all times. Access is
only permitted for authorized persons with a tool.
3.4.0. DANGER FROM ELECTRICAL ENERGY
3.4.1. FUNDAMENTAL SAFETY MEASURES
3.4.1. WORKPLACE SAFETY
a) Keep your workspace clean and well lit. Disorder or poorly lit
workspaces can lead to accidents.
b) Do not use the tool in an explosive environment, in which
ammable liquids, gases or dusts are located. Power tools can
generate sparks which can ignite the dust of vapors.
c) Takeenvironmentalinuencesintoaccount.Never subject tools to
rain. Do not use in moist or wet environments.
d) Keep other persons away from tool while in use. If you are
distracted, you can lose control of the device.
3.4.2. ELECTRICAL SAFETY
a) Avoid physical contact with grounded surfaces such a pipes,
heaters, etc. There is an increased risk of electrical shock if your
body is grounded.

- 11 -
b) Keep the device away from rain or moisture. Water penetrating
into the tool increases the risk of electrical shock.
c) Keep tool away from heat, oil, sharp edges, or moving device parts.
3.4.3. PERSONAL SAFETY
a) Be careful, pay attention to what you are doing, and use power
tools responsibly. Do not use power tools when you are tired or
under the inuence of drugs, alcohol, or medication. One moment
of carelessness when using the tool can lead to severe injuries.
b) Always wear personal safety equipment and protective eyewear.
Wearing protective safety equipment such as a dust mask, safety
shoes, a protective helmet, and hearing protection, depending
on the type and use of of the tool, decreases the risk of injuries.
c) Avoid unintended start-up. Ensure that the power tool is shut off
before you connect it to the battery, pick it up, or carry it. If you have
your nger on the trigger while carrying the power tool, or the device
is connected to the power supply, this can lead to accidents.
d) Avoid non-ergonomic posture. Make sure you are standing stably
and always maintain your balance. You can then control the power
tool in unexpected situations.
e) Wear suitable clothing. Do not wear loose clothing or jewelry.
Keep your hair, clothing and gloves away from moving parts. Loose
clothing, jewelry, or long hair can get caught in moving parts.
3.4.4. USING AND HANDLING THE POWER TOOL
a) Do not overload the tool. Use the proper tool for your work . You
work better and more safely in the dened output range when
using the proper tool .
b) Do not use power tools with defective switches. A tool that cannot
be shut off is dangerous and must be repaired.
c) Remove the battery before you change tool settings, replace
accessories, or lay the tool down. This prevents the power tool from
starting unintentionally.
d) Store unused tools out of reach of children. Do not allow persons
to use the device who are not familiar with it or have not read
these instructions. Power tools are dangerous if they are used by
inexperienced persons.

- 12 -
e) Take good care of the power tool. Check that moving parts work
properly and do not jam, that there are no broken or damaged
parts, and that the functionality is not hindered. Have damaged
parts repaired prior to using the device. Many accidents are
caused by poorly maintained power tools.
f) Keep the tools clean. Carefully maintained tools jam less often and
are easier to use.
g) Use the tool, accessories, etc. in accordance with these instructions.
Take the working conditions and task to be executed into
account. The use of power tools for other purposes than the
intended use can lead to hazardous situations.
h) Use the right tool. Do not use low-output tools for heavy loads. Do
not use the tool for purposes and work for which it is not intended.
i) Check your tool for damage. Prior to further use of the tool, the
safety equipment or damaged parts must be inspected to ensure
proper functionality.
Check to ensure the functionality of moving parts, that they don’t
jam, that no parts are broken, and that all parts are properly and
correctly installed and all conditions required for the operation of
the device have been fullled.
Damaged safety equipment and parts should be properly repaired
or replaced by trained and qualied personnel unless otherwise
indicated in the operating instructions . Damaged switches must be
replaced by trained and qualied personnel. Do not use tools on
which the trigger cannot be easily switched on and off .
3.4.5. SERVICE
Only allow your power tool to be repaired by a
qualied technician using only original spare parts,
available from AIMCO. This ensures that the safety of
your device is maintained.
3.5.0. LITHIUM-ION BATTERY
Please make sure to follow the following instructions
for using lithium-ion batteries.

- 13 -
a) Only charge the batteries in chargers recommended by the
manufacturer. If the battery is not charged on a suitable charger,
it can be permanently damaged .
b) Only use the provided battery for power tools. The use of other
batteries can lead to injuries and re hazards.
c) If the battery is unused for an extended period of time, it must not
remain on the charger or on the tool. If a work break of more than
3 hours is expected, the battery must be removed from the tool.
Otherwise, the battery may be permanently damaged.
d) The lithium-ion battery should not remain on the charger for longer
than 36 hours for safety reasons. Remove the battery from the
charger immediately after the charging process is completed.
e) An empty battery should not be in contact with the tool or a
charger that is disconnected from the mains for an extended
period of time. In both cases, currents are owing that deep
discharge the battery and can permanently damage it.
f) Recharge the lithium-ion batteries immediately and never store
them when empty. If the battery is stored while disconnected from
the tool and the charger, it will maintain a constant capacity over
a long period of time. (Loss approx. 5% per year.)
g) Always transport the battery separately from the tool. This prevents the
tool from accidentally switching on and deep discharging the battery.
h) Do not subject the lithium-ion battery to high temperatures
(+ 50° C) or direct sunlight. If the battery gets warmer than 50° C
during operation (charging or discharging), it must be removed
from the charger or tool immediately.
i) Keep the unused battery away from paper clips, coins, keys, nails,
screws or other small metal objects which might bridge the contacts.
Do not open the battery and do not short-circuit it. A short-circuit
between the battery contacts can lead to burns, re, or explosions.
j) Under extreme use or temperature conditions, batteries can
leak. Avoid contact with the skin or eyes if the battery leaks.
The battery uid is acidic and can cause chemical burns. If the
uid comes into contact with skin, immediately wash it with soap
and water and then rinse it with lemon juice or vinegar. If the uid
gets into the eyes, ush with water for at least 10 minutes and
immediately go to the doctor.
k) Make sure that the Li-Ion battery does not fall down or is subject
to vibration and impact.
l) Clean the contacts regularly with a cotton swab soaked in a high-
percent alcohol.

- 14 -
Lithium-ion batteries have nearly no self-discharge and
do not have a memory effect. If properly used, they
will reliably supply your tool with power for several
years (approx. 700 - 1000 charge cycles).
In general, avoid deep discharging or overcharging
the lithium-ion battery under any circumstances. It will
be permanently damaged from this.
3.6.0. CLEANING AND DISPOSING OF THE TOOL
Use and dispose of used materials and substances properly, in
particular cleaning agents and solvents.
Donotthrowtheusedbatteryinthehouseholdtrash,are,orinwater.
Have it properly disposed of by a specialist shop or the manufacturer.
3.7.0. RISK OF INJURY AND DAMAGE TO THE TOOL
1. Make sure that none of the tool parts are
damaged. All damaged parts must be repaired
prior to using the device. If you work with
damaged tool parts, you risk injury.
2. If you work on raised platforms, wear a safety belt and avoid
letting the tool fall down. Non-compliance may lead to injury
and signicant damage.
3. First remove the battery before you clean the device or perform
general maintenance.
4. Never hold your face near the exhaust holes.
5. Avoid skin contact with substances such as lubricating grease
and oil. These substances are ammable on skin. If you do come
into contact with them, thoroughly wash the area.
6. Avoid unstable working positions. You might fall and injure
yourself.
7. Maintain your tool carefully. Follow the operating instructions for
maintenance and cleaning.
- Keep the handle free of lubrication greases and dirt.
8. Use the tool carefully and pay attention to proper use. Always
concentrate while working.

- 15 -
4. START-UP
Do not let the tool fall or allow other objects to fall on the device.
Protect it from impact damage. Make sure that the device does not
come into contact with sprayed water or oil.
• To remove the battery, set the
rotational direction switch to the
center position, slide the clip on the
front side of the battery back, and
pull it forward away from the tool.
• To install the battery, align the tongue
of the battery with the groove in the
casing so it can easily slide into place.
• Always slide it on completely until
it locks with a click. Check that the
battery is correctly locked in place
before starting to work.
If the battery is not installed properly, it can fall out of the tool and
lead to injuries.
• Never use force when installing the battery. If the battery
cannot be easily slide in, it has not been correctly installed.
1 – Clip
2 – Remove battery
2
1
4.1.0. INSTALLING OR REMOVING THE BATTERY
4.1.1. TRIGGER
Trigger
Trigger

- 16 -
Before you remove the battery or install it on the
tool, please check that the rotating direction switch
is in the neutral position. Always check the rotating
direction switch prior to operation.
4.1.2. ROTATING DIRECTION SWITCH
To change the rotating direction, the tool is equipped with a rotating
direction switch.
• Only use the rotating direction switch after the tool has come to a
complete stop. Changing the rotating direction during operation
damages the device.
• If you are not using the tool, set the rotating direction switch to the
neutral position.
• To change or set the direction, press the rotating direction switch
out to the left for clockwise rotation
out to the right for counter-clockwise rotation
If the rotating direction switch is set to the center position, the trigger
cannot be activated.
4.1.3. LED / BARCODE SCANNER
Never look directly at the LED or barcode scanner!
Rotating
direction
switch
Rotating
direction
switch

- 17 -
After pressing the trigger, the LED and the barcode scanner will switch
on. The afterrun illumination of the LED after the trigger has been
pressed can be dened in the AcraDyne Tool Manager under Settings
- General. The released barcode scanner goes off after a barcode is
successfully scanned and/or the trigger has been released.
Do not clean the LED with aggressive cleaning agents!
4.1.4. MULTI-COLOR LED CONTROL LIGHT
The AcraDyne cordless series
has a LED control function that is
near the display and spans the
circumference of the tool. The
light indicates tool status:
The time-length of the light can
be programmed as glowing,
ashing, or pulsating for each LED
signal.
More information about LED
Control Light programming can
be found in the AcraDyne Tool
Manager manual.
The optional barcode scanner musut be activated
in the hardware settings of AcraDyne Tool Manager
software.
Color Indicator:
Screwdriver is released
Tool is on reverse mode;
counter-clockwise rotation
Tightening was successful
(OK)
Error at tightening (NOK)
Tool needs acknowledgement
of the result or action of the
worker

- 18 -
RISK OF INJURY
If a low torque is expected and a very high torque is
set unintentionally.
For the CTA Series, the tool will be programmed with AcraDyne
Tool Manager software. Make sure that the tool is congured and
parameterized correctly. See the AcraDyne Tool Manager user
manual for operating instructions.
4.2.0. SETTING THE TIGHTENING TORQUE
For the MTA and MCA Series, the tightening torque is adjusted with a
mechanical clutch.
To adjust the clutch, the protective
covering needs to slide open.
1) Carefully press down the rear of
the covering.
2) The clip will easily slide backward.
3) The clutch will be visible. Now the
clutch can be adjusted with a
torque adjustment tool.
– counter-clockwise: lower torque
– clockwise: higher torque
After the adjustment, slide the
cover back into its initial position. It
will close and lock automatically.
Check the torque with a torque
measurement unit. If the requested
value isn´t reached, adjust the
clutch again.
1
23
Clutch
adjustment
If you want to execute a job later or you have
scanned the wrong barcode, you can cancel
this after the release.
To do this, hold down the display button for
approx. 3 seconds. The cancel symbol will
appear. Conrm this by pressing the left side
display button.
4.3.0. CANCEL JOB

- 19 -
If the connection to the controller (process controls) via wireless
connection through an access point is interrupted and a job has
already been released in the tool, it should be further processed
if possible. After completing the job, the tool will try to send the
fastening process results. If the connection to the process controls
cannot be restored, the fastening process results must be manually
secured (read out of the tool using the AcraDyne Tool Manager
software and saved).
Then, after removing the battery, the back-up strategy can be used
to continue working.
To do this, hold down the trigger and slide the battery back on. After
approx. 3 seconds, the set-up symbol will appear on the display. You
can now release the trigger and will be in the set-up menu.
By pressing the menu button, you can go to the next menu point.
By pressing the trigger, you can select a menu point. Using the left
button, conrm your selection; with the right button, cancel the
selection.
To activate the back-up strategy, the "Set-up" menu
must be activated in the software under the general
settings. Also activate "scanner selectable" so the set-
up menu point "Scanner" can be selected. If you also
activate "Manual mode selectable," the set-up menu
points "M" and "Scanner M" will be released. So you can
select different programs per display, the check mark
next to "Manual mode active" must also be selected.
4.4.0. BACK-UP STRATEGY
Menu Button
Go to the next menu point
Conrm the
entry / selection
Cancel/decline the
entry / selection

- 20 -
To conrm the back-up strategy with scanning function, press the left
button on the display.
Press the trigger to select the setting.
Go forward with the menu button until the "Scanner M" logo appears.
The tool has to be programmed accordingly with AcraDyne Tool
Manager.
In the "Scanner M" menu, select the scan mode for scanning barcodes
for program selection. Scan the barcodes for the fastening job as
in regular mode. You will receive the release for the corresponding
program with the number of fasteners.
The fastening results are not transmitted to the process controls for
central storage. You can, however, read the fastening process results
with AcraDyne Tool Manager software and save them as a le.
