Aimco Signature Series User manual

MODEL NO.: SPC-A21025Q
SPC-A21025
SPC-A21038
SPC-A21625Q
SPC-A21625
SPC-A21638
SPC-A23038
SPC-A23538
SPC-A25038
SPC-A27038
SPC-A210050
18V Cordless Precision Clutch
Shut Off Angle Nutrunner

2

3
(A) (B)
(C)
(D)
(G)
(E)
(H)
(I)
(F)
(J)
(A) The angled head is indexable for multiple head positions.
(B) User can distinguish wrench model with color ring.
(C) Covered Torque Adjustment.
(D) LED light for workpiece illumination.
(E) LED indicator provides simple process information to the operator.
The signal is visible from any angle.
(F) Easy Press button for simple Forward/Reverse selection.
(G) Tool Trigger with repeat protection feature to avoid double hits on al-
ready seated fastener.
(H) Ergonomic handle design provides optimal balance.
( I ) Easy attached sliding battery system.
(J) Lightweight Li-Ion battery pack delivers long tool operating times.

4
(A) (C)
(D)
(E)
(H)
(F)
(I)
(J)
(G)
(K)
(B)
(A) The angled head is indexable for multiple head positions.
(B) 1/4” Hex with quick change chuck.
(C) User can distinguish wrench model with color ring.
(D) Covered Torque Adjustment.
(E) LED light for workpiece illumination.
(F) LED indicator provides simple process information to the operator.
The signal is visible from any angle.
(G) Easy Press button for simple Forward/Reverse selection.
(H) Tool Trigger with repeat protection feature to avoid double hits on already
seated fastener.
( I ) Ergonomic handle design provides optimal balance.
(J) Easy attached sliding battery system.
(K) Lightweight Li-Ion battery pack delivers long tool operating times.

5
Work Area Safety
●Keep your work area clean and
well lit. Cluttered benches and
dark areas invite accidents.
●Do not operate power tools in
explosive atmospheres, such
as in the presence of flamma-
ble liquids, gases, or dust.
Power tools create sparks which
may ignite the dust or fumes.
●Keep bystanders, children, and
visitors away while operating a
power tool. Distractions can
cause you to lose control.
Personal Safety
●Stay alert, watch what you are
doing and use common sense
when operating a power tool. Do
not use tool while tired or under
the influence of drugs, alcohol,
or medication. A moment of inat-
tention while operating power tools
may result in serious personal
injury.
●Dress properly. Do not wear
loose clothing or jewelry. Con-
tain long hair. Keep your hair,
clothing, and gloves away from
moving parts. Loose clothes, jew-
elry, or long hair can be caught in
moving parts.
●Do not overreach. Keep proper
footing and balance at all
times. Proper footing and bal-
ance enables better control on
the tool in unexpected situations.
General Safety Rules ●Use safety equipment. Always
wear eye protection. Dust mask,
non-skid safety shoes, hard hat,
or hearing protection must be
used for appropriate conditions.
Tool Use and Care
●Use clamps or other practical
ways to secure and support the
work piece to a stable platform.
Holding the work piece by hand
or against your body is unstable
and may lead to loss of control.
●Do not force tools. Use the cor-
rect tool for your application. The
correct tool will do the job better and
safer at the rate for which it is de-
signed.
●Do not use tool if switch does
not turn it on or off. Any tool
that cannot be controlled with the
switch is dangerous and must be
repaired.
●Store idle tools out of reach of
children and other untrained
persons. Tools are dangerous in
the hands of untrained users.
●Check for misalignment or bind-
ing of moving parts, breakage of
parts, and any other condition
that may affect the tool opera-
tion. If damaged, have the tool
serviced before using. Many acci-
dents are caused by poorly main-
tained tools.
• Use only Signature Series rec-
ommended accessories for
your model tool. Accessories
that may be suitable for one tool,
may become hazardous when
used on another tool.
WARNING! READ ALL INSTRUCTIONS. Always observe the safety regulations
applicable in your country to reduce the risk of fire, electric shock, and personal
injury. Understand the following safety instructions before attempting to operate
this product. Always wear eye protection when working with power tools. Keep
these instructions in a safe place.
SAVE THESE INSTRUCTIONS

6
Service
●Tool service must be per-
formed only by qualified repair
personnel. Service or mainte-
nance performed by unqualified
personnel could result in a risk of
injury.
●When servicing an AIMCO Sig-
nature Series Precision Clutch
tool it is important to use
AIMCO Signature Series parts
and all work should be under-
taken by a qualified AIMCO
Signature Series Authorized
Technician. Use of unauthorized
parts or work performed by a non
-authorized technician will void
warranty and may create a risk of
damage to the tool, risk of electric
shock, or injury to a user.
Battery Charger
●Caution: To reduce risk of injury,
charge only the authorized batteries.
Other types of batteries may burst,
causing personal injury and dam-
age.
●Before using battery charger, read
all instructions and cautionary
markings on batteries, chargers,
and products using batteries.
●Do not allow anything to cover or
clog the charger vents.
●Do not expose charger to rain,
snow, or wet conditions.
●To reduce the risk of damage to
electric plug and cord, pull by plug
rather than cord when disconnect-
ing charger.
●Use of an attachment not recom-
mended or sold by the manufac-
turer may result in a risk of fire,
electric shock, or injury to per-
sons.
●Make sure cord for charger is lo-
cated so that it will not be stepped
on, tripped on, tripped over, or
otherwise subjected to damage or
stress.
Additional Safety Rules
●Do not abuse the power cord. Nev-
er use the cord to carry the charger.
Keep cord away from heat, oil,
water, sharp edges, or moving
parts. Replace damaged cords im-
mediately.
●Do not operate charger if it has
been damaged in any way. Take it
to a qualified service center for
repair.
●To reduce risk of electric shock,
unplug charger from outlet before
attempting any maintenance or
cleaning. Turning off controls will
not reduce this risk.
●Do not disassemble charger or bat-
tery cartridge. Take it to a qualified
service center when repair is re-
quired. Incorrect reassembly may
result in a risk of electric shock or
fire.
Battery Pack
●Do not charge battery pack when
temperature is below 0°C (32°F)
or above 40°C (104°F).
●Do not attempt to use a step-down
transformer, an engine generator,
or DC power receptacle.
●Do not short the battery pack: Do
not touch the terminals with any
conductive material. Avoid storing
battery cartridge in a container
with other metal objects such as
nails, coins, paper clips, etc.
●Do not expose battery cartridge to
water or rain. A battery short can
cause large current flow, over-
heating, possibly burns, and even
a breakdown.
●Do not store the machine and
battery pack in locations where
the temperature may reach or
exceed 50°C (122°F).
●Do not incinerate the battery pack
even if it is severely damaged or
completely worn out. The battery
pack can explode in a fire.
●Be careful not to drop, shake, or
strike the battery.

7
●Do not charge inside a box or
container of any kind. The battery
must be placed in a well-
ventilated area during charging.
●Do not dispose of battery packs
into household waste, fire or wa-
ter. Battery packs should be col-
lected, recycled or disposed of
in an environmentally-friendly
manner. Call authorized warranty
centers for locations to dispose of
damaged or inoperable batteries.
The Signature Series Precision
Clutch industrial shut off wrench is
designed for nut tightening/loosening
and screw driving/loosening. It is not
appropriate to use for wood/mild
steel drilling. Please refer to the Fig-
ure 1 on this page to familiarize
yourself with the major components
of this tool before use.
1. Power Switch
Depressing the power switch will
energize the LED light (2) in front
and the tool starts to rotate. When
released, power to the motor ceas-
es and the tool stops working im-
mediately. The LED light will re-
main on for 5 seconds, then shut
off.
2. LED Light
3. Forward/Reverse Button
The tool is always in forward op-
eration unless the Forward/
Reverse button is pressed. When
the button is pressed, the blue
LED shows and the tool will be in
reverse operation. To switch tool
back to forward operation, simply
press the button again. The blue
LED disappears and the tool is
back in forward operation.
4. Anvil (Drive Shaft)
The anvil will accept any 1/4” hex
bit or 1/2”square drive hex socket
depending on specific model. Be
sure the bit/socket is fully en-
Functional Description
gaged before operating the tool.
Otherwise, the bit/socket may
detach and cause property dam-
age or personal injury. Use only
impact-type sockets or industrial
grade bits.
5. Angle Head Orientation
Adjust the angle head kit to the
degree you wish. (in 45° incre-
ments for a total of eight posi-
tions for head orientation).
6. Torque Adjustment Cover
Open the torque adjustment cap.
Use the supplied torque adjust-
ment tool to either tighten or loos-
en the spring until the desired
torque is reached.
7. Li-Ion Battery
This battery provides electrical
power to the motor. Please
charge it according to the charg-
ing instructions listed in this man-
ual.
WARNING: Use the tool to either
tighten or loosen nuts and screws
ONLY in stipulated torque and volt-
age ranges.
5
6
2
4
3
1
7
Figure 1

8
This product has been carefully
inspected prior to leaving the facto-
ry. It should provide you with years
of satisfying service under normal
operating conditions. Do not, how-
ever, force the tool to perform out-
side its design parameters. Such
usage will void the warranty.
1. Slide battery into the bottom of
the housing handle until a click
sound occurs. Do not force bat-
tery: It should slide easily into
place with nominal force. Any
difficulty doing so indicates in-
correct alignment.
2. Tool speed is preset to the maxi-
mum range of the tool. With an
SPC-2PGM External Program-
ming Module (optional accesso-
ry), tool speeds may be reset to
a lower speed within the range
of the tool.
3. Select a proper size socket/drive
bit and insert into the quick
change holder or install onto the
square drive of the tool.
4. Depress the trigger to engage
the LED light and start the tool.
5. When the pre-set torque is
reached, the tool’s precision clutch
will shut off the tool automatically.
6. Prior to using on an application,
it is advised to verify the output
torque of the tool as set. Check
the torque on an Auditor™ Dig-
ital Tester (or comparable sys-
tem).
Operations
WARNING! Read the instruc-
tion manual before operating
the tool. Always wear safety
glasses or face shields when
operating this product. Failure
to do so can result in injury.
Check for damage to the tool, parts,
or accessories that may have oc-
curred during transport. Take the
time to thoroughly read and under-
stand this manual prior to operation.
This tool kit contains:
1 -
1 - 18V Li-Ion Battery Pack
1 - Torque Adjustment Tool
1 - Angle Head Adjustment Tool
4 - Color Rings for tool Identification
1 - Instruction Manual
Attaching or Removing Battery
Pack
1. To connect battery, line up the
tracks and attach the battery
pack. Slide toward the battery
pack until it locks into position
with a click.
2. To remove the battery pack,
press the red button on the top of
the battery pack and release the
battery pack.
Assembly
1. PRESS
2. RELEASE
SLIDE

9
1. Open the cover and use an
open end wrench (or torque ad-
justment tool on quick change
models) to rotate the square
drive until the adjust hole posi-
tion appears below the cover.
2. Turn the torque adjustment tool
clockwise to increase the torque
and counterclockwise to de-
crease the torque.
Press
Increase
Decrease
Adjust Hole Cover
Square Hole
7. Delivered torque to the applica-
tion may vary due to the type of
joint the tool is tightening. Good
practice is to perform periodic
audits of the application. Audi-
tor™ Torque Wrenches or
Rotary Transducers are ideally
suited to make these checks.
Forward/Reverse Rotation
Switch Operation
To prevent damage, do not press
Forward/Reverse button until the
tool comes a complete stop.
Forward Rotation Operation
The tool is in forward operation if
the blue light is not on.
Reverse Rotation Operation
By long pressing the F/R switch,
users are able to choose the mode
of reverse operation, either auto-
matic or manual.
Mode 1: Automatic – Tool re-
turns to forward operation auto-
matically after reverse operation.
Mode 2: Manual – Tool needs to
be adjusted manually to return to
forward operation after reverse
operation.
Steps for Torque Adjustment
NOTE: Remove the battery pack
before adjusting the torque to avoid
injury.

10
2. Adjust the angle head assembly
to the degree you wished then
put it back on the tool (in 45°
increments for a total of eight
positions for head orientation).
1. Use an open end wrench and
the supplied adjustment wrench
to loosen the nut by turning in
the opposite direction to remove
the angle head assembly.
Steps for Angle Head Position Indexing
3. Use an open end wrench and
the supplied adjustment wrench
to tighten the nut by turning in
opposite direction to complete
angle adjustment.

11
Status of the LED indicator and
Beep Status of the Tool Action to be Taken
LED lights RED, YELLOW, and
GREEN together for one second.
A long beep for one second.
The motor is switched
on. None required.
The preset torque is not
reached (NOK).
The application
should be re-
worked.
LED lights RED for one second.
A long beep for one second. The screw has been
refastened after already
tight-Double Hit (NOK).
The application
should be
reworked.
LED lights GREEN.
The preset torque is
reached and the tighten-
ing is OK.
None required.
LED Blinks YELLOW five times.
Five short beeps. Battery power is low.
Recharge battery
or replace with
fully charged
battery.
A long beep for five second.
Battery power is too low
for tool operation and
tool will not run,
Recharge battery
or replace with
fully charged
battery.
LED lights BLUE, The tool is set to run in
reverse operation, None required.
LED lights RED twice,
Tool temperature is too
hot. Warning to protect
tool from damage,
Remove battery
and allow tool to
cool.
LED lights RED three times The motor has a failure, Send tool in for
service.
LED lights RED four times, Internal connector wire
has failed.
Send tool in for
service.
TOOL LED INDICATIONS

12
Li-ion Battery Pack
NOTE: Your battery pack is not
fully charged at the time of pur-
chase. Be sure to charge battery
before first use.
●Batteries should be charged in
ambient temperatures between 0°
C (32°F) and 40°C (104°F). Charg-
ing outside this range will result in
either less than full charge or dam-
age to the battery pack.
●Allow the charger to cool when
charging more than two battery
packs consecutively.
●Do not insert finger/body parts or
foreign objects into contact area
of charger.
1. Place charger in a relatively cool
and well-ventilated area.
2. Plug charger into the AC outlet.
CAUTION: Ensure that the pow-
er source to be utilized conforms
to the power requirement speci-
fied on the charger nameplate.
3. Turn the battery upside-down
and slide the battery into charger
while keeping the alignment
marks line up. Slide the forward
in the direction of the arrow. Do
not force battery: It should slide
easily into place with nominal
force. Any difficulty doing so
indicates incorrect alignment.
4. If the power lamp (RED) does
not light immediately or goes out
soon after the charger is
plugged in, consult a Signature
Series authorized dealer.
5. During charging, the charging
lamp (GREEN) will start flash-
ing. When charging is complet-
ed, an internal electronic switch
will automatically be triggered to
prevent overcharging.
- Charging will not start if the
battery pack is warm. For exam-
ple, immediately after high duty
cycle operation. The YELLOW
standby lamp will flash until the
battery temperature drops to
where safe charging is possible.
6. If the temperature of the battery
pack is 0oC (320F) or less,
charging will take longer to fully
charge the battery pack than
standard charging time. At this
low temperature, even when the
battery is fully charged, it will
have approximately 50% of the
power of a fully charged battery
at normal operation tempera-
tures.
7. Once the battery is fully
charged, the GREEN lamp will
light to indicate the charger has
entered into a trickle charge
mode.
CHARGING THE BATTERY PACK

13
Red Light
Charger is plugged into the AC outlet. Ready to charge.
Yellow Flashing Light
(1) When the temperature of the battery is too low (<0oC(<32oF)),
it is in a trickle charge mode until the temperature of the bat-
tery goes up to over 0oC(<32oF). The lamp will change from
the Yellow Flashing to Green Flashing automatically and
start to charge. (If after 70 minutes, the lamp changes from
yellow flashing to yellow lit, consult an authorized dealer.)
(2) When the temperature of the battery is too high (>40oC
(104oF)), it is in a trickle charge mode until the temperature
of the battery drops to under 40oC (104oF). The lamp will
change from the Yellow Flashing to Green Flashing auto-
matically and start to charge. (If after 70 minutes, the lamp
changes from yellow flashing to yellow lit, consult an author-
ized dealer.)
(3) When the voltage of the battery is too low (below 14.4
voltage), it is in a trickle charge mode until the voltage of
the battery reaches to the standard value. The lamp will
change from the Yellow Flashing to Green Flashing auto-
matically and start to charge. (If after 20 minutes, the lamp
changes from yellow flashing to yellow lit, consult an author-
ized dealer.)
Yellow Light
The battery and the charger are not connected. If the yellow lit
still on after trying re-attach the battery, consult an authorized
dealer.
Green Flashing Light
Now start charging Light
Green Flashing Light
Battery is approximately 50% charged.
Green Flashing Light
Battery is approximately 80% charged.
Green Light
Charging is complete. (Fully charged.)
LAMP INDICATIONS

14
MODEL
SPC-A21038 SPC-A21625Q
Voltage 18 VDC 18 VDC
Drive Size 9.5 mm Sq. (3/8”) 6.35 mm Hex. (1/4”)
Torque Range 3 ~ 12 Nm 5 ~ 18 Nm
Free Speed 400 ~ 1000 rpm 300 ~ 600 rpm
Weight w/o Battery 1.6 kg (3.5 lb) 1.6 kg (3.5 lb)
Vibration (m/s2)2.63 2.63
Sound level (dB(A)) <75 <75
Battery Type Li-Ion 2.0A.h Li-Ion 2.0A.h
Charge Time Approx. 45 min Approx. 45 min
MODEL
SPC-A21025Q SPC-A21025
Voltage 18 VDC 18 VDC
Drive Size 6.35 mm Hex. (1/4”) 6.35 mm Sq. (1/4”)
Torque Range 3 ~ 12 Nm 3 ~ 12 Nm
Free Speed 400 ~ 1000 rpm 400 ~ 1000 rpm
Weight w/o Battery 1.6 kg (3.5 lb) 1.6 kg (3.5 lb)
Vibration (m/s2)2.63 2.63
Sound level (dB(A)) <75 <75
Battery Type Li-Ion 2.0A.h Li-Ion 2.0A.h
Charge Time Approx. 45 min Approx. 45 min
SPECIFICATIONS

15
MODEL
SPC-A21625 SPC-A21638
Voltage 18 VDC 18 VDC
Drive Size 6.35 mm Sq. (1/4”) 9.5 mm Sq. (3/8”)
Torque Range 5 ~ 18 Nm 5 ~ 18 Nm
Free Speed 300 ~ 600 rpm 300 ~ 600 rpm
Weight w/o Battery 1.6 kg (3.5 lb) 1.6 kg (3.5 lb)
Vibration (m/s2)2.63 2.63
Sound level (dB(A)) <75 <75
Battery Type Li-Ion 2.0A.h Li-Ion 2.0A.h
Charge Time Approx. 45 min Approx. 45 min
MODEL
SPC-A23038 SPC-A23538 SPC-A25038
Voltage 18 VDC 18 VDC 18 VDC
Drive Size 9.5 mm Sq. (3/8”) 9.5 mm Sq. (3/8”) 9.5 mm Sq. (3/8”)
Torque Range 8 ~ 30 Nm 10 ~ 35 Nm 10 ~ 50 Nm
Free Speed 250 ~ 480 rpm 200 ~ 330 rpm 200 rpm
Weight W/O
Battery 1.6 kg (3.5 lb) 1.6 kg (3.5 lb) 1.6 kg (3.5 lb)
Vibration (m/s2)2.55 2.55 2.55
Sound level
(dB(A)) <75 <75 <75
Battery Type Li-Ion 2.0A.h Li-Ion 2.0A.h Li-Ion 2.0A.h
Charge Time Approx. 45 min Approx. 45 min Approx. 45 min
SPECIFICATIONS

16
NOISE AND VIBRATION LEVEL DECLARATION (Max. value) EN 60745-2-2
Models: 16 Nm and below
Sound pressure level (no load) LpA: 66.7 dBA Uncertainty K: 1.5 dB
Sound power level (no load) LwA: 77.7 dBA Uncertainty K: 1.5 dB
Vibration total value (no load) ahd: 0.6 m/s2 Uncertainty K: 1.5 m/s2
Models: 30 Nm and above
Sound pressure level (no load) LpA: 67.8 dBA Uncertainty K: 1.5 dB
Sound power level (no load) LwA: 78.8 dBA Uncertainty K: 1.5 dB
Vibration total value (no load) ahd: 0.3 m/s2 Uncertainty K: 1.5 m/s2
The declared noise levels and vibration total value has been measured in
accordance with a standard test method and may be used for comparing one
tool with another. The declared noise levels and vibration total value may also be
used in a preliminary assessment of exposure.
WARNING:
− The noise and vibration emission during actual use of the power tool can differ
from the declared total value depending on the ways in which the tool is used;
and
− Need to identify safety measures to protect the operator that are based on an
estimation of exposure in the actual conditions of use (taking account of all parts
of the operating cycle such as the times when the tool is switched off and when it
is running idle in addition to the trigger time).
MODEL
SPC-A27038 SPC-A210050
Voltage 18 VDC 18 VDC
Drive Size 9.5 mm Sq. (3/8”) 12.7 mm Sq. (1/2”)
Torque Range 20 ~ 70 Nm 35 ~ 100 Nm
Free Speed 170 rpm 119 rpm
Weight w/o Battery 2.9 kg (6.3 lb) 3.4 kg (7.4 lb)
Vibration (m/s2)2.55 2.55
Sound level (dB(A)) <75 <75
Battery Type Li-Ion 2.0Ah Li-Ion 2.0Ah
Charge Time Approx. 45 min Approx. 45 min

17
ANGLE HOUSING UNITS
Index
No
Description Q'ty Index
No
Description Q'ty
aCollar 1fAngle Housing Assembly 1
bLock Nut 1gO-Ring 1
cLock Nut 1hScrew 1
dMain Bevel Gear Assembly 1iBevel Gear Assembly 1
eWasher 1jLock Nut 1
For models: SPC-A25038 SPC-A27038 SPC-210050
Index
No
Description Q'ty Index
No
Description Q'ty
aLock Nut fScrew 1
bCollar 1gO-Ring 1
cLock Nut 1hBevel Gear Assembly 1
dMain Bevel Gear Assembly 1iLock Nut 1
eAngle Housing Assembly 1
Specific Part Numbers may be obtained by review oif the correct Signature Series tool
breakdown. Consult your Signature Series dealer for details.
For models: SPC-A21025 SPC-A21625 SPC-A21038
SPC-A21638 SPC-A23038 SPC-A23538

18
Index
No
Description Q'ty Index
No
Description Q'ty
aCollar 1iBevel Gear Assembly 1
bLock Nut 1jSteel Ball 2
cLock Nut 1kLock Nut 1
dMain Bevel Gear Assembly 1lSnap Ring 1
eWasher 1mQuick Change Holder 1
fAngle Housing Assembly 1nSpring 1
gO-Ring 1oHold Spacer 1
hScrew 1pAnvil Collar 1
For Models: SPC-A21025Q SPC-A21625Q
ANGLE HOUSING UNITS
Specific Part Numbers may be obtained by review of the correct Signature Series tool
breakdown. Consult your Signature Series dealer for details.

19
CLUTCH UNITS
For Models:SPC-A21025Q SPC-A21025 SPC-A21038
SPC-A21625Q SPC-A21625 SPC-A21638
SPC-A23038 SPC-A23538 SPC-A25038
SPC-A27038 SPC-A210050
Index
No
Description Q'ty Index
No
Description Q'ty
aClutch Assembly 1fWasher 1
bSteel Ball 4gAdjust Washer 1
cWasher 1hAdjust Nut 1
dWasher 1iSnap Ring 1
eSpring 1
Specific Part Numbers may be obtained by review of the correct Signature Series tool
breakdown. Consult your Signature Series dealer for details.

20
Specific Part Numbers may be obtained by review of the correct Signature Series tool
breakdown. Consult your Signature Series dealer for details.
Index
No
Description Q’ty Index
No
Description Q’ty Index
No
Description Q’ty
aSnap Ring 1dGear Cage
Assembly 1gGear Plate Assembly 1
bWasher 1eWasher 1Gear Box
Assembly 1
h
cPlanet Gear 3fPlanet Gear 3(1) O-ring 1
GEAR BOX UNITS
For Models: SPC-A21025Q SPC-A21025 SPC-A21038
SPC-A21625Q SPC-A21625 SPC-A21638
SPC-A23038 SPC-A23538
Index
No
Description Q’ty Index
No
Description Q’ty Index
No
Description Q’ty
aSnap Ring 1dGear Cage
Assembly 1Gear Box
Assembly 1
g
bWasher 1eWasher 1(1) O-ring 1
cPlanet Gear 6fGear Plate
Assembly 1
For Models:SPC-A25038 SPC-A27038 SPC-A210050
