AIO ROBOTICS Zeus User manual

ZEUS
QUICK-START GUIDE
Getting started
Insert power cable in back, switch on 6Unwrap lament and feed through tube
5Press front on button for 1 second
Open door by lifting up and back 3Place turnable 3 pins facing down
2Remove interior packaging
4
4
Remove
test printout
7Wind excess back onto spool 9Press park button
8Press control button
Select a le 14 If .STL is selected you’ll be asked to slice
Feed lament all the way down 12 Press print to access les
11 Prep plate with thin layer of glue
10
13
Squeeze tabs with
thumb and index
A
1
Recommended: start with a Gcode preloaded test
Select OK 18 Lift glass plate and carefully remove object
from plate when printing is complete.
17 Print with lid open for best results
16
NB: “Box” test le print time:
> 8 mins
Printing starts with automated bed leveling
14 Select print
Refer to manual for on-board slicing
Printing starts after extruder hits target temperature
Extruder will rst print a stripe at front of plate
Spool feeds clockwise

Included Accessories
Filament Scanner Calibration Pattern Scan powder + applicator Spatula (printout remover)
Glue Stick Wi dongle Power supply Turn table
B
Connecting ZEUS to the web
Insert wi dongle Optional:ethernet Select WIFI icon Select your local
wireless network.
Enter password.
C
A. Wi is connected
B. Ethernet is
connected (defaults
to ethernet if
connected)
AB
USB 3Ethernet
2Wi
1
NB: “Box” test le print time:
> 8 mins
When ZEUS is off line
File Transfer Options (refer to manual for details)D
For le transfer via wi or ethernet, enter IP address (A or B) in computer browser to access Pydio. Login: aio Password: aiorobotics
Home Control System menu
ZEUS UI - the basicsE
Online settings
Use caution when handling the Thunderbolt Extruder. Do not touch when extruder lights are blue.
Never remove the extruder during or immediately after printing.
WarningsF
