AirLive Live-2TX501 User manual

SOHO 2.5G Switch with 10G SFP+
Quick Setup Guide
Declaration of Conformity
We, Manufacturer/Importer
Declare that the product
6-Port SOHO 2.5G Switch with 1x10G SPF+
Live-2TX501
is in conformity with
In accordance with 2014/30/EU and 2014/35/EU Directive
Clause
Manufacturer/Importer
Description
AirLive Technology Corporation
4F, No.132, Lane 235, Baoqian Rd., Xindian Dist.,
New Taipei City 23145, Taiwan
■
■CE marking
Name : A van Rossem Position/ Title : Product Manager
EN 55032:2015+A11:2020 Electromagnetic compatibility (EMC)
■EN 62368-1:2014+A11:2017 Electromagnetic compatibility (LVD)
Date : June 2022Place : Republic of China (Taiwan)
/ po
ter
Live-2TX501, Live-2TX801
Live-2TX501
Tested To Comply
With FCC Standards.
FOR HOMEOR OFFICE USE
FCC 47 CFR Part 15 Subpart B (Class A), ANSI C63.4:2014
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his own expense.
AirLive Technology Corporation declares that thisdevice
is in compliance with the essential requirements and
other relevantprovisionsofdirective 2014/30/EU.
Regulatory Approvals
CE Marking Warning
This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
CE Statement
This product complies with the 2014/30/EU and 2014/35/EU directives,
including the following safety and EMC standards:
EN 55032:2015+A11:2020
■
Electromagnetic compatibility (EMC)
EN IEC 61000-3-2:2019
■
Electromagnetic compatibility (EMC)
EN 61000-3-3:2013+A1:2019
■
Electromagnetic compatibility (EMC)
EN 55035:2017+A11:2020
■
Electromagnetic compatibility (EMC)
EN 62368-1:2014+A11:2017
■
Electromagnetic compatibility (LVD) - Safety
RoHS Statement
This product complies with RoHS directive 2011/65/EU and amendment
Commission Delegated Directive (EU)2015/863.
IEC 62321-3-1:2013
■
IEC 62321-5:2013
■
IEC 62321-4:2013+AMD1:2017
■
IEC 62321-7-1:2015
■
IEC 62321-7-2:2017
■
IEC 62321-6:2015
■
IEC 62321-8:2017
■
9-Port SOHO 2.5G Switch with 1x10G SPF+
Live-2TX801
Live-2TX501
Live-2TX801
Live-2TX801

Quick Setup Guide
Installation Step:
English
EN
Installation Steps
Figure A
LED DEFINITIONS
Power
Port RJ-45
Port Fiber
Red ON
Red Off
Green
Green ON
Power is on and normal.
The switch is not receiving power.
10/100/1000M Link/Act.
Link connected.
1. Remove the switch and accessories from the package.
2. Connect power to the switch. Make sure that “Power” LED is on.
3. Check the Port LED indicator status. When a device is
connected the port light up.
4. For more product information visit www.airlive.com.
SOHO 2.5G Switch with 10G SFP+
Live-2TX501, Live-2TX801
Yellow 2.5G Link/Act.
Live-2TX801
