AirLive POE-GSH2404M-400 User manual

28-Port Gigabit L2+ Managed PoE+ Switch
Including 4 TP/SFP Combo ports, 400W
Quick Setup Guide
Declaration of Conformity
We, Manufacturer/Importer
Declare that the product
28-Port Gigabit L2+ Managed PoE+ Switch
Including 4 TP/SFP Combo ports, 400W
POE-GSH2404M-400
is in conformity with
In accordance with 2014/30/EU and 2014/35/EU Directive
Clause
Manufacturer/Importer
Description
AirLive Technology Corporation
4F, No.132, Lane 235, Baoqian Rd., Xindian Dist.,
New Taipei City 23145, Taiwan
■
■CE marking
Name : A van Rossem Position/ Title : Product Manager
EN 55032:2015+A11:2020 Electromagnetic compatibility (EMC)
■EN 62368-1:2014+A11:2017 Electromagnetic compatibility (LVD)
Date : June 2021Place : Republic of China (Taiwan)
/ po
ter
AirLive Technology Corporation declares that thisdevice
is in compliance with the essential requirements and
other relevantprovisionsofdirective 2014/30/EU.
Regulatory Approvals
CE Marking Warning
This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
CE Statement
This product complies with the 2014/30/EU and 2014/35/EU directives, including
the following safety and EMC standards:
EN 55032:2015+A11:2020
■
Electromagnetic compatibility (EMC) - Electromagnetic compatibility of multimedia
equipment - Emission requirments
EN IEC 61000-3-2:2019
■
Electromagnetic compatibility (EMC) - Part 3-2: Limits - Limits for harmonic current emissions
(equipment input current ≤ 16 A per phase)
POE-GSH2404M-400
EN 61000-3-3:2013+A1:2019
■
Electromagnetic compatibility (EMC) - Part 3-3: Limits - Limitation of voltage changes, voltage
fluctuations and flicker in public low-voltage supply systems, for equipment with rated
current <= 16 A per phase and not subject to conditonal connection
EN 55035:2017+A11:2020
■
Electromagnetic compatibility (EMC) - Electromagnetic compatibility of multimedia
equipment - Immunity requirments
EN 62368-1-2014+A11-2017
■
Electromagnetic compatibility (LVD) - Safety, Audio/Video, Information and Communication
technology equipment Part 1: Safety requirments
10 Ports Gigabit Managed PoE+ Switch
POE-GSH802M

Quick Setup Guide
Important Information
The default IP address: 192.168.2.1
The default username / password is admin
The content of user’s guide and associated software can be downloaded from the website
(www.airlive.com)
Installation Step:
1. Connect your device's PoE port to the switch's POE port
2. Your PoE device should get the power from the switch now. If you want to change settings
via web management. Please follow the instructions below.
3. Set your PC's IP address to 192.168.2.50.
4. Open your web browser and enter "192.168.2.1" to get into the switch's web management.
5. Enter "admin" for username, "admin" for password.
English
EN
Deutsch
DE
Wichtige Information
Die voreingestellte IP Adresse: 192.168.2.1
Das voreingestellte Passwort lautet admin
Das Benutzerhandbuch und die benötigte Software kann auf unserer Webseite
(www.airlive.com)
Installationsschritte:
1. Verbinden Sie den PoE Port ihres Gerätes mit dem PoE Port vom Switch.
2. Ihr PoE Gerät sollte jetzt den Strom vom Switch beziehen. Wenn Sie Einstellungen via
Webbrowser ändern möchten, dann folgen Sie bitte den unten angegebenen Schritten:
3. Stellen Sie die IP des PC’s auf 192.168.2.50.
4. Öffnen Sie ihren Browser und geben "192.168.2.1" ein. Die gelangen zur Web-Management
Oberfläche.
5. Geben Sie "admin" als Benutzernamen und "admin" als Passwort ein.
Español
ES
Información importante
Default IP: 192.168.2.1
Contraseña default: admin
El contenido de la Guía de Usuario y el software asociado puede descargarse desde el sitio
web (www.airlive.com)
Pasos de instalación:
1. Conecte el puerto PoE de su dispositivo al puerto PoE del switch .
2. En este momento su dispositivo PoE debe recibir energía desde el switch. Si usted desea
cambiar los parámetros vía web, por favor siga las siguientes instrucciones.
3. Configure la dirección IP de su PC en 192.168.2.50.
4. Abra su navegador web e ingrese "192.168.2.1" para acceder al administrador web del switch.
5. Ingrese "admin" como nombre de usuario, "admin" como contraseña
Português
PT
Informação Importante
O endereço IP padrão: 192.168.2.1
A palavra-chave padrão é admin
O conteúdo do guia do utilizador e software associado podem ser carregados através do
website (www.airlive.com)
Passos de Instalação:
1. Conecte a porta do seu dispositivo PoE à porta POE do switch
2. Seu dispositivo PoE deve obter agora a energia através do switch. Se desejar alterar as
configurações através do gestor web. Siga por favor as instruções em baixo.
3. Defina o endereço IP do seu PC para 192.168.2.50.
4. Abra o seu explorador web e digite "192.168.2.1" para entrar no gestor web do switch.
5. Digite "admin" para o username, "admin" para a password.
28-Port Gigabit L2+ Managed PoE+ Switch
Including 4 TP/SFP Combo ports, 400W
POE-GSH2404M-400
Installation Steps
PoE Port
Figure A
PoE Port
10/100/1000Mbps PoE Port
10 Ports Gigabit Managed PoE+ Switch
POE-GSH802M
LED DEFINITIONS
Power
Act (Link for Combo)
Sys
Link (PoE Mode)
Red ON
Red Off
Green ON
Green ON
Green ON
Power is on and normal.
The switch is not receiving power.
The port Status LEDs ON Link Connection, LEDs Blinking Data transmission.
System is Runnig, Only Blinking at Start-up
Port is enabled and supplying power to PD.
