Airzone ST-1010G User manual

FOOSBALL TABLE
Play
Model: ST-1010G
ASSEMBLY INSTRUCTIONS
Not recommended for children under 8 years of age.
WARNING:
C H O K I N G H A Z A R D
Not for children under 3 years
Small parts
ADVERTENCIA:
P E L I G R O D E A S F I X I A
No apto para niño menores de 3 años
Partes pequeñas
CONTACT INFO
Distributed by Airzone Ltd.
Questions or Comments? Call 1-800-775-6524 or Mail [email protected]
Made in China.

IMPORTANT
After receiving the shipment, inspect the product thoroughly to ensure
that it has been shipped with care.
Before assembly make sure that the packaging contains all parts.
For service or parts replacement under warranty, the official sales
receipt is required. Please keep your official sales receipt for future
reference
Please contact us for any questions at 1-800-775-6524 before returning
this product.
Use a soft, clean and level surface to begin the assembly of your game table.
(Such as the inside of the cardboard box, carpet, etc.). This will prevent the
table surface from getting damaged. Make sure to remove any staples from
the cardboard box before using it as an underground.
This game table will be partially assembled upside down and then
turned over onto its legs.
When installing parts that have more than one screw or bolt, hand
tighten all screws or bolts in place before tightening with screwdriver
or allen key.
Electric screwdrivers may be helpful during assembly. However, please
set a low torque and use extreme caution because screws may be
stripped or over tightened if the electric screwdriver's torque is set too
high.
OFFICIAL SALES RECEIPT
CAN BE ATTACHED HERE
Service or parts under warranty
only available with show of receipt

Save these IMPORTANT
Safety Instructions
Warning
This product is intended for indoor use in a climate controlled environment only.
Excessive temperatures and humidity may have an influence on the play quality
and durability of this table.
This table should only be used by adults or under the supervision of adults.
This table is NOT a toy.
Do not sit or lean on the table. Do not place anything on the top of the
play field.
Do not drag the table when moving it, as this could damage the legs or unit
beyond repair.
Do not place any food or drinks on the table or play field
Only use the table for its intended purpose
Check all screws, bolts, etc. with regular intervals to ensure that they are in
good working condition and have not loosened overtime.
Age Grade 8+:
This product is not recommended for children under 8 years of age.
:
Care and Maintenance
Clean your table periodically. It is sufficient to wipe its surfaces with mild soap
and water using a damp cloth. The bearings normally do not require any
lubrication. However, should you wish to enhance their smoothness, you may
spray the play rods near the bearings with a good quality silicone spray.

TOOLS
Required Recommended
Phillips head screwdriver
(Not included)
Allen key
(Included)
Electric screwdriver
Level
PARTS IDENTIFIER
How to use
To assure a smooth assembly we recommend to ensure yourself that you
have received all parts listed and in the correct quantities.
Leg Panel
STEP 1
12
Parts ID
Used in Parts Description
x2
Parts Quantity
Parts Image

PARTS IDENTIFIER
Pre-installed Parts
Panel-Side
STEP 1
x2
1
Panel-End
STEP 1
x2
2
Playfield
STEP 2
x1
3
Support Beam
STEP 3
x2
4
Leg
STEP 4
x4
5
Player-A
STEP 6
x9
6
Player-B
STEP 6
x9
7
Rod-Bumper
STEP 6
x12
8
Rod-Washer-Molded
STEP 6
x12
9
Rod-Handle
STEP 8
x6
10
Rod end-cap
STEP 8
x6
11
Rod-3 Player
STEP 6
x6
12
Corner
STEP 1
x4
13
Goal bottom and top part
STEP 5
x2
14
Copper nut
STEP 3
x4
15
Plastic Rod Bushing
x12
20
Plastic Ball Entry Rim
x2
21
Plastic Ball Entry Rim
x2
22
ST-1010G-001 ST-1010G-002 ST-1010G-003 ST-1010G-004
ST-1010G-005 ST-1010G-006 ST-1010G-007 ST-1010G-008
ST-1010G-009 ST-1010G-010 ST-1010G-011 ST-1010G-012
ST-1010G-013 ST-1010G-014 ST-1010G-015
ST-1010G-020 ST-1010G-021 ST-1010G-022

Accessories
Soccer ball
x3
90
Hardware
Pre-installed Hardware
Bolt
STEP 7
x18
60
Nut
STEP 7
x18
61
Washer
STEP 4
x8
62
Bolt
STEP 4
x8
63
Screw
STEP 1, 3, 5
x24
64
Screw
STEP 3
x4
65
Allen Key
STEP 4
x1
66
T-nut
x8
80
ST-1010G-060 ST-1010G-061 ST-1010G-062 ST-1010G-063
ST-1010G-064 ST-1010G-065 ST-1010G-066
ST-1010G-080
ST-1010G-090

ASSEMBLY INSTRUCTIONS
All parts can be identified on the parts and accessories identifier
Please inspect your play field before assembling this product. It is not
possible to replace or repair the play field under warranty. Therefore, if
the play field is damaged, the complete table needs to be returned to
the place of purchase to be exchanged for a new table
Before assembly make sure that all parts
are available and sorted
STEP 1
NOTE
COMPONENTS Q.TY HARDWARE Q.TY
1
2
13
x1
x2
x2
64 x8
STEP 2
NOTE
ScrewPanel-Side
Panel-End
Corner
3
1
2
2
64
64
13
13
COMPONENTS Q.TY HARDWARE Q.TY
3x1
Playfield

ASSEMBLY INSTRUCTIONS
STEP 3
NOTE
COMPONENTS Q.TY HARDWARE Q.TY
1
4
13
15
x1
x2
x2
x4
64
65
x8
x4
STEP 4
NOTE
ScrewPanel-Side
Screw
Support Beam
Corner
Copper nut
STEP 5
NOTE
1
13
64
64
64
4
15
65
65
65
65
64
14
COMPONENTS Q.TY HARDWARE Q.TY
5x4 62
63
x8
x8
WasherLeg
Bolt
COMPONENTS Q.TY HARDWARE Q.TY
14 x2 64 x8
ScrewGoal bottom and top part
5
5
5
62
63
62
63
66
66 x1
Allen Key

ASSEMBLY INSTRUCTIONS
STEP 6
NOTE
COMPONENTS Q.TY HARDWARE Q.TY
6
7
8
9
x9
x9
x12
x12
12 x6
Rod-3 Player
Player-A
Player-B
Rod-Bumper
Rod-Washer-Molded
STEP 7
NOTE
7
6
9
8
12 12 12
12 12 12
COMPONENTS Q.TY HARDWARE Q.TY
60
61
x18
x18
Bolt
Nut
61
60

ASSEMBLY INSTRUCTIONS
STEP 8
NOTE
COMPONENTS Q.TY HARDWARE Q.TY
10
11
x6
x6
Rod-Handle
Rod-Cap
11
10

Limited Warranty
This product is warranted to the original owner to be free from defects in workmanship and
materials when used for the intended purpose under normal use and conditions for a period
of 90 days from the date of original retail purchase. Proof of purchase is required when
requesting for parts or service.
This Limited Warranty covers all defects in materials and workmanship but will be void
if the product is:
- Damaged due to transportation, improper usage, storage, negligence, misuse, abuse,
acts of nature or accidents (including for not following the instructions supplied with
this product).
- Used in a commercial environment such as schools, correctional facilities, recreational centers,
camps, churches, day-cares or any other public facility and/or as rentals.
- Modified or repaired by unauthorized persons.
This Limited Warranty does not cover:
- Nonessential items such as accessories, cosmetic parts and any other items showing wear
due to normal usage.
- Any transportation, delivery, installation costs incurred by the consumer from original place
of purchase to home, or back to the original place of purchase.
- Items purchased from a third party or from an unauthorized retailer.
This warranty is nontransferable and is expressly limited to the repair or replacement of the
defective product. During the warranty period, the manufacturer shall repair or replace
defective parts at no cost to the purchaser. Shipping charges and insurance are not covered
and are the responsibility of the purchaser. Labor charges and related expenses for removal,
installation or replacement of the product or components are not covered under this warranty.
The manufacturer reserves the right to make substitutions to warranty claims if parts are
unavailable or obsolete.
Distributed by Airzone Ltd.
Questions, Comments or Warranty Claims:
CALL 1-800-775-6524
or
MAIL [email protected]
