INSTRUCTION
MANUAL
AIR08-B
www.aivituvin.com

Please retain these instructions for future reference.
NOTICE
Firmly secure all bolts,screws and knobs before use.
Reconfirm that all bolts,screws,and knobs are secure every 90
days.
Fasten screws loosely during initial assembly. Do not fully
tighten screws until the item is completely assembled.
Do not use or store this item in the proximity of open flame or
flammable/combustible chemicals.
Be aware that some parts are heavy and have sharp edges.
Be aware that moving parts can injure,crush and cut.
If any parts are missing,broken,damaged,or worn,stop using
this product until repairs are made and/or factory replacement
parts are installed.
Do not use this item in a way inconsistent with the
manufacturer’ s instructions as this could void the product
warranty.
01

TOOLS REQUIRED
PHILLIPS
SCREWDRIVER
DRILL
(RECOMMENDED)
2PERSON
ASSEMBLY
APPROXIMATELY
45MIN. ASSEMBLY
HARDWARE
8PCS+1spare 17PCS+1 spare
P1 P2
P3
02
M3.5x40mm SCREW
M3.5x35mm SCREW
6PCS+1spare
M3.5x25mm SCREW
P4
2PCS+1spare
M3.0x16mm SCREW
P5
1PC

PARTS
A B C
C1 D E
F
Side panel
1PC
Bottom panel
1PC
Bottom panel
1PC
Asphalt roof
1PC
1PC 1PC 1PC
A B C
DEF
G
Left side panel
1PC
Floor-Upper
1PC
Floor-Bottom
Little Back fence
Front panel
1PC Back panel 1PC Right side panel 1PC
03
HI
1PC
Ramp frame-Left
1PC
2PCS
1PC Little Left side fence

PARTS
A B C
C1 D E
F
Side panel
1PC
Bottom panel
1PC
Bottom panel
1PC
Asphalt roof
1PC
1PC 1PC 1PC
JK
04
Ramp frame-Right
1PC
Ramp steps
3PCS

PRODUCT ASSEMBLY
01
02
05
Attach the panel Parts A, B, C & D by 4XP1srews.
C
D
B
P1 X8
Put the 2 pieces bottom floor part E inside the house.
A
Ex2

PRODUCT ASSEMBLY
03
04
06
Attach the upper floor parts F to the house by 4xP3 screws.
F
P3X4
P4X2
P5X1
P2 X1
G
Attach the little Back fence part G to the upper floor with 1xP5 by 2xP4
screws and 1xP2 screws.

PRODUCT ASSEMBLY
05
06
07
Attach Little Left side fence part H to the upper floor by 3xP2 screws
as show on pictures.
P2 X3
H
Attach the ramp.
Attach the part I ,J and 3 pieces of ramp steps part K by 12xP2
screws.
①
②
P2X12
I
J
Kx3

PRODUCT ASSEMBLY
07
08
P2X1
Attach the ramp to the house by 1xP2 & 2xP3 screws as show on
pictures.
P3X2
Finish

WARNING
Manufacturer and seller expressly disclaim any and all liability for personal injury,property
damage or loss,whether direct,indirect,or incidental,resulting from the incorrect
attachment,improper use,inadequate miantenance,or neglect of this product.
