SHOR-LINE Feline LS Exam Table User manual

Save This Guide For Future Reference
PN: 006.4122.00 NOVEMBER 2020
Feline LS Exam Table
PRODUCT GUIDE
Blue Line - Feline LS Exam Table
Shown (Colors/Models May Vary)

Shor-Line.com
ii
INTRODUCTION
Introduction
Thank you for purchasing Shor-Line products. As a leader in animal care equipment, our
commitment to provide quality products and personable customer service is the same as it
was in 1927.
This Guide provides information regarding the installation, use, and care of your Shor-Line
product. Keep this Guide in a safe and convenient place for reference.
For further questions, to purchase additional products, or to replace a lost or damaged
Guide, please feel free to contact Shor-Line:
SHOR-LINE
Schroer Manufacturing Company
511 Osage Ave.
Kansas City, Kansas 66105, USA
PHONE: [phone]
LOCAL: 913.281.1500
FAX: [phone]
EMAIL: [email protected]
WEB ADDRESS: shor-line.com
SHOR-LINE LIMITED
Vale Business Park Llandow,
Vale of Glamorgan CF71 7PF
United Kingdom
PHONE: [phone]
FAX: [phone]
EMAIL: [email protected]
WEB ADDRESS: shor-line.co.uk
Shor-Line may provide instructions that supplement or supersede this Guide at any time.
Contact Shor-Line to ensure the Guide is the latest version.
During installation, if a contradiction between this Guide, existing conditions, or local
regulations arise, contact a Shor-Line representative before proceeding with installation.
The Blue Line Feline LS Exam Table and Standard Feline Exam Table are also referred to
as "Table" in this document.
Visit Shor-line.com for a full list of TERMS AND CONDITIONS.
© Copyright 2020 Schroer Manufacturing Company. All rights reserved.
READ THIS GUIDE COMPLETELY BEFORE INSTALLATION AND USE AND
THOROUGHLY UNDERSTAND AND FOLLOW ALL SAFETY INSTRUCTIONS.
WEAR PERSONAL PROTECTIVE EQUIPMENT, such as, but not limited to, eye
protection, back support brace, and gloves during installation. Failure to do so could
result in SERIOUS INJURY.
This product is intended to be used for animals only. Do not use for anything other than
the intended purpose.
DANGER
WARNING
CAUTION
INTRODUCTION

iii
Shor-Line.com
INTRODUCTION
Introduction .................................................................................................... ii
GENERAL INFORMATION
General information........................................................................................1
Safety Alert Symbol ............................................................................................................ 1
Personal Protective Equipment (PPE)................................................................................ 1
Safety Warnings Included In This Guide ............................................................................ 2
Safety Decal Locations....................................................................................................... 3
SECTION ONE, PRE-ASSEMBLY
Shipment Inventory And Inspection................................................................4
Shipment Inventory............................................................................................................. 4
Shipment Inspection ........................................................................................................... 4
Damage Reporting ............................................................................................................. 4
Table Base.......................................................................................................................... 4
Continuum Table Base.................................................................................................. 4
Component Parts List ......................................................................................................... 5
SECTION TWO, ASSEMBLY PROCEDURES
Installation......................................................................................................6
Feline LS Exam Table......................................................................................................... 6
SECTION THREE, USE AND CARE
Use And Care.................................................................................................7
Table Safe Use Practices ................................................................................................... 7
Table Lift Function .............................................................................................................. 7
General Maintenance & Care ............................................................................................. 8
Maintenance Recommendations .................................................................................. 8
Care Recommendations .............................................................................................. 8
SECTION FOUR, TERMS & CONDITIONS
Terms And Conditions ....................................................................................9
Damaged Freight Procedures ............................................................................................ 9
Limited Warranty ........................................................................................10
Contact Information...................................................................................... 11
CONTENTS

Shor-Line.com
1
GENERAL INFORMATION
General information
Refer to the Guide, images and content to assist with the installation of the product.
Throughout the Guide, safety notices provide help for a successful installation.
SAFETY FIRST!
Shor-Line uses the following symbols and signal words to identify potential hazards or
unsafe practices:
Safety Alert Symbol
Indicates a potential personal injury hazard exists. It is important to heed any
safety warning information associated with this alert symbol.
Signal Words for Hazard Alerting Safety Messages
Indicates a hazardous situation which, if not avoided, WILL result in serious injury
or death.
Indicates a hazardous situation which, if not avoided, COULD result in serious injury
or death.
Indicates a hazardous situation which, if not avoided, COULD result in minor or
moderate injury.
Important Information Symbol
Indicates information considered important but not directly hazard related.
Personal Protective Equipment (PPE)
PPE refers to protective clothing or other equipment designed to protect against injury. It
is the responsibility of the client/installer to ensure all local and federal codes are adhered
to during the installation and assembly of this product. Included is a list of PPE items
suggested, but not limited to, protective equipment to help complete the installation safely.
• Back Support Brace • Gloves
• Metatarsal, foot protection
Shor-Line makes no guarantee, implied or otherwise, that the information included in
this Guide will be complete or failsafe, or that the information will prevent an injury from
occurring. Standard measures described may not reect the full extent of all steps that may
need to be taken in any given emergency instance.
California Proposition 65 Warning
This product can expose you to chemicals
including chromium, which are known to the
state of California to cause cancer. For more
information go to: www.P65Warnings.ca.gov
DANGER
WARNING
CAUTION
NOTICE
WARNING
SAFETY

2
Shor-Line.com
Safety Warnings Included In This Guide
Do NOT plug-in the power cord until the installation is complete and the equipment is
ready for use. Ensure the power cord is free of kinks and not bound/pinched.
WEAR PERSONAL PROTECTIVE EQUIPMENT (PPE), such as, but not limited to, eye
protection, protective gloves and Metatarsal/foot protection during installation. Failure
to do so could result in SERIOUS INJURY or DEATH.
Always maintain full control of patients when using the table or its operable functions.
Failure to do so could result in SERIOUS INJURY or DEATH.
This product is intended to be used for animals only. Do not use for anything other than
the intended purpose.
Keep hands clear of possible pinch areas during installation, which if not avoided,
could result in MINOR to MODERATE INJURY.
Do NOT exceed the weight limitations (250 lbs) of the table. Exceeding the weight limit
may cause equipment failure.
Stainless steel panels have sharp edges, stay clear of and DO NOT TOUCH exposed
edges which, if not avoided, could result in MINOR to MODERATE INJURY.
Enlist help and USE SAFE LIFTING PRACTICES during assembly, installation and while
moving equipment.
DANGER
WARNING
CAUTION
SAFETY

Shor-Line.com
3
SAFETY
Safety Decal Locations
Table Safety Decals Location
02
01
LOCATE ON BACKSIDE
Safety Decal List
Item Part # Description Qty
01 059.4120.00 SAFETY DECAL, Caution - No Sitting, Standing. Animal Use Only 1
02 SAFETY DECAL, Warning - Proposition 65 1
Read all warning, danger and caution decals before equipment is operated. Never use
equipment if decals are missing, hidden, improperly placed, damaged or altered. Keep
safety decals clean and legible.
Contact Shor-Line (800.444.1579) for replacement safety decals.

4
Shor-Line.com
SECTION ONE, PRE-ASSEMBLY
Shipment Inventory And Inspection
Shipment Inventory
Upon arrival, unpack and inspect the shipment to ensure it is complete and free of any
damages that may have occurred during shipping. Compare the packing list with the
shipment to ensure all parts/components have been received.
This Guide can be used to identify parts and their associated part numbers listed on the
packing slip.
Shipment Inspection
While verifying the shipment contents, take a moment to inspect each component for
damage. This should be done before the shipment is signed received and accepted.
If damaged components are apparent, follow the instructions within Shor-Line’s Damage
and Freight Procedures.
Damage Reporting
Follow the instructions within Shor-Line’s Damage and Freight Procedures.
Contact Shor-Line (800.444.1579) immediately to expedite replacements or repairs.
After fteen (15) calendar days of receipt of merchandise, this policy becomes void.
Table Base
Continuum Table Base
The Continuum table base utilizes a non-rotational
hydraulic cylinder to lift the table top from 29" up to 41".
The height of the table top can be raised by partially
depressing the foot operated pedal, repeating to
gradually raise the top.
Depress and hold the foot operated pedal to lower the
table top surface.
Enlist help and USE SAFE LIFTING PRACTICES during assembly, installation and while
moving equipment.
NOTICE
NOTICE
FIGURE 1.1 - Continuum Table Base
CAUTION
SECTION
ONE

Shor-Line.com
5
SECTION ONE
Component Parts List
FIGURE 1.3 - Feline LS Exam Table (Blue Line Model Shown)
01
OR
02 09
07
08
03
05
06
04
30"
40"
SIDE VIEW TOP VIEW
Item Part # Description Qty
01 See Below Blue Line Table Top
02 See Below Standard Table Top (Not Shown)
03 803.4100.11 Continuum Table Base (Hydraulic Lift) 1
04 • 062.3715.20 • Adjustable Foot Screw 4
05 • 064.3700.10 • Adjustable Foot Position Lock Nut (3/8-16 Hex Nut) 4
06 • 051.0000.00 • Adjustable Foot Scu󰀨 Pad 4
07 062.2515.02 Table Top Fastener Screw (1/4-20x1.5" Truss Head Phil SS) 4
08 065.2500.12 Table Top Fastener (Lock Washer SS) 4
09 065.2500.10 Table Top Fastener (Flat Washer SS) 4
Part # Description
Blue Line Series Feline LS Exam Table Tops
803.4122.00 • Blue Accent
803.4122.01 • Jade Green Accent
803.4122.02 • Taupe Gray Accent
803.4122.03 • Black Accent
Standard Feline LS Exam Table Tops
803.4123.00 • Blue Accent
803.4123.01 • Black Accent

6
Shor-Line.com
SECTION TWO, ASSEMBLY PROCEDURES
Installation
Feline LS Exam Table
Typical table orders will arrive in two containers, one box containing the table base
weighing up to 175 lbs (80 kg) and another containing the table top weighing up to 50 lbs
(23 kg), weights vary.
Enlist help and USE SAFE LIFTING PRACTICES during assembly, installation and
moving equipment.
Keep hands clear of possible pinch areas during installation, which if not avoided,
could result in MINOR to MODERATE INJURY.
Stainless steel panels have sharp edges, stay clear of and DO NOT TOUCH exposed
edges which, if not avoided, could result in MINOR to MODERATE INJURY.
STEP 1: Remove the table from the shipping material and locate near its preferred
destination, leaving enough space to install the top. Note the location of the foot
operated pedal for orientation and accessibility.
STEP 2: Remove the top from its shipping material, align the four mounting holes
with the table base mounting plate holes.
STEP 3: Move the table to its desired location. Use the adjustable feet to level the table
from side-to-side and back-to-front to compensate for ooring imperfections.
Do NOT lift or move the unit by its table top. Support and move the table by the base
using enough personnel and safe lifting procedures.
Always maintain full control of patients when using the table or its operable functions.
Failure to do so could result in SERIOUS INJURY or DEATH.
STEP 4: Use the foot operated pedal to test the up and down functions of the table:
A: Raise the table top by partially depressing the foot operated pedal, repeating to
gradually raise the top.
B: Depress and hold the foot operated pedal to lower the table surface.
FIGURE 2.1 - Feline LS Exam Table (Blue Line Model Shown)
Table Top
Adjustable Foot/
Scuff Pad Assembly
Lift/Release
Foot Operated Pedal
Continuum
Table Base
WARNING
CAUTION
NOTICE
WARNING
SECTION
TWO

Shor-Line.com
7
SECTION THREE, USE AND CARE
Use And Care
Table Safe Use Practices
Always use safe practices during loading and unloading patients from the table. All
procedures should be created by the facility owner and followed. Common sense and being
aware of safe practices should always drive procedures. Below is a list of recommendations
and situational conditions that require attention, heed all warnings.
• Do NOT operate the lift table before checking to ensure the unit and surrounding area is clear of
personnel, animals and obstructions.
• Do NOT operate the lift table on uneven ooring. Adjust leveling feet to ensure the unit is stable.
• Always balance the load on the table surface, center patient on the table.
• Do NOT allow animals to jump o󰀨 the table.
• Do NOT sit, stand or lean on the table. Animal use ONLY.
Table Lift Function
The table may be equipped with a Continuum Table Base which has a hydraulic lift feature
that utilizes a foot actuated mechanism to raise and lower the table approximately 12 inches.
The table top surface is 29 inches above the oor in the lower position. The top can be
raised to 41 inches above the oor.
Always maintain full control of patients when using the table or its operable functions.
Failure to do so could result in SERIOUS INJURY or DEATH.
FIGURE 3.1 - Table Top Height (Down)
29" ABOVE
FLOOR
FIGURE 3.2 - Table Top Height (Up)
41"
ABOVE
FLOOR
Do NOT exceed the weight limitations (250 lbs) of the table. Exceeding the weight limit
may cause equipment failure.
WARNING
CAUTION
THREE
SECTION

8
Shor-Line.com
SECTION THREE
General Maintenance & Care
Maintenance Recommendations
Routine maintenance will extend the quality and life of Shor-Line products.
It is the owners responsibility to set-up scheduled maintenance programs, depending on
use of the equipment. Scheduled preventive maintenance should include, but not limited
to daily or weekly inspections and maintenance of products to prolong its longevity and
to help maintain proper product functions.
• Follow manufacturers cleaning and maintenance recommendations outlined in product literature
provided for components not included in these recommendations. Congurations/component parts
may vary.
• Check alignment of operable panels, doors and components to ensure operation is free of
obstructions. Adjust as required.
• Check any battery compartments to ensure the batteries are not failing, corroding the
contacts or damaging the equipment. A pencil eraser can be used to clean electrical contacts
in battery compartments.
• Check any wiring for kinks or exposed inner wiring. If damage exist, stop equipment use and
contact Shor-Line Technical Services for direction.
• Check any hydraulic lift components for leaking uid. If uid is present, stop equipment use and
contact Shor-Line Technical Services for direction. Do NOT attempt to repair hydraulic leaks.
Care Recommendations
Routine product care will extend the quality and life of Shor-Line products and aids in
protecting animals from transmittable diseases and infections.
It is the owners responsibility to set-up scheduled cleaning programs, depending on
use of the equipment. Scheduled preventive cleaning should include, but not limited to
daily or weekly inspections and cleaning of products to prolong its longevity and to help
maintain nishes.
Safe Cleaning Practices
• Use the mildest cleaning procedure that will complete the job e󰀨ectively. Ordinary waste deposits
and uids can usually be removed with soap and water, using a soft cloth or sponge. Rinse
thoroughly with clear water and dry completely with a soft cloth to discourage hard-water spotting.
• Minor scale build up and some hard water spotting can be removed by washing with a vinegar
diluted mixture followed by a clear water rinse and thorough drying.
• Bleach, deodorizing agents, disinfectants, and sanitizers can corrode stainless steel, thoroughly
rinse all surfaces treated with these chemicals with a clear water rinse and dry with a soft cloth.
• If scrubbing is required, use only polymer or nylon ber products made for use with polymer or
nylon materials.
• Always rinse with clear water and dry of all surfaces treated with cleaning, sterilization solutions.
Unsafe Cleaning Practices (NOT Recommended)
• Do NOT use a dry cloth to wipe clear polymer surfaces which can scratch if dust/dirt is wiped with
the hand or dry cloth.
• Polymer materials can discolor if exposed to sunlight, ultraviolet rays. Avoid direct sun exposure.
• Do NOT use ammonia or bleaches to clean polymer surfaces.
• Do NOT allow uids to accumulate, puddle without removing and completely drying the
surfaces and components. Standing water/uids are a hazard and can cause damage to
component materials.
• Do NOT use scouring powders that will scratch polymer nishes.
Steel wool or steel brushes should never be used to clean stainless steel or polymer
surfaces, avoid abrasive cleaning techniques/supplies.
NOTICE
NOTICE
NOTICE

Shor-Line.com
9
SECTION FOUR, TERMS & CONDITIONS
Terms And Conditions
Shor-Line's TERMS AND CONDITIONS can be found at shor-line.com
Damaged Freight Procedures
Freight Claim - Contact the technical services department toll-free at 1.800.444.1579
To le a freight claim:
Inspect ALL packages upon arrival. If containers show evidence of damage when delivered, the
packages should be opened and inspected before the carrier leaves. The shipment should be
inventoried and inspected jointly by the customer and the carrier. The driver will then make proper
notation on the delivery receipt.
Customer must inspect all materials for shortages, damages, conformity with the order, and defects
before signing any documentation requested by the carrier. Customer must immediately complete
such inspection and shall not accept delivery of goods that are damaged or not in accordance with
the bill of lading or packing slip without proper notication to the carrier and Shor-Line. If products
are damaged, defective, shorted or appear not to conform to the order, Customer shall discontinue
their use and immediately notify the carrier and Shor-Line of such condition and a󰀨ord a reasonable
opportunity to inspect the same.
Customer shall make, or provide Shor-Line in writing with all information necessary to make a claim
against such carrier for any shortage, damage, or discrepancy of the shipment within fteen (15) days
after receipt of the products. Claims or written information thereon not so presented within fteen (15)
days after receipt of the products will not be allowed. No returned products will be accepted, credited
or replaced, unless arrangements for their return have been made in compliance with Shor-Line's
Return Policy.
If containers do not show evidence of damage, there may be "concealed damage". Customer must
report any concealed damage within 15 days after receipt of the shipment. Such report is to be made
directly to Shor-Line's Tra󰀩c Department who will le a claim with the carrier. All packaging and
contents must be held for this inspection.
STEP 1: Customer must check goods, contents against packing slip, weight against bill of lading,
containers, etc.
STEP 2: Customer lls out "Inspection Report of Loss or Damage Discovered After Delivery".
STEP 3: Customer is to sign the report form. A copy is left with the customer and should be
forwarded to Shor-Line's tra󰀩c department to le a claim.
STEP 4: Call Shor-Line's Tra󰀩c Department to le a claim (1.800.444.1579). Shor-Line will arrange
pick-up, return shipment, and replacement of the product.
Return Policy & Repairs - All products being returned for any reason or delivered for repair service
(whether or not pursuant to the Limited Warranty) must receive advance authorization from Shor-
Line. Customer must contact Shor-Line's Technical Service Department at 1.800.444.1579 to receive
a Return Authorization Number. All products returned, except for warranty service or pursuant to
the Product Satisfaction policy, are subject to a minimum 15% restocking charge. Customer will be
responsible for all freight charges on returns.
Return Product Authorization - To assure e󰀩cient handling on damaged or defective equipment,
or repairs, please contact our Technical Service Department for Return Product Authorization
(1.800.444.1579). Failure to obtain Return Product Authorization will only delay processing and may
result in the denial of any repair, replacement or credit.
Repairs - It is mandatory to contact Technical Service Department at 1.800.444.1579 prior to sending
product for repair.
SECTION
FOUR

10
Shor-Line.com
SECTION FOUR
Limited Warranty
In the event the Customer is not fully satised with the quality or workmanship of a product, Shor-Line in its sole
discretion may arrange either to credit Customer's account (excluding shipping and handling costs) or replace the
product. However, Customer must notify Shor-Line in writing of its dissatisfaction within fteen (15) days of receipt
of the product from Shor-Line. Customer must also return the rejected product to Shor-Line (freight paid) within thirty
(30) days of its receipt in compliance with Shor-Line's Return Policy (See Section 4). Shor-Line's obligation is limited to
providing the applicable credit or product replacement, which will be processed only after receipt of the returned product.
In addition, this Product Satisfaction Policy does not apply to specially designed, discontinued, used, factory second or
repaired products.
SHOR-LINE warrants to the initial purchaser only of products manufactured by it that such products are free from defects
in materials or labor for varying periods depending on the particular product and subject to the limitations and conditions
set forth herein. SHOR-LINE's stainless steel products are warranted to be free from such defects for their normal useful
life. SHOR-LINE's mechanical and electrical products, parts, devices and components (including such parts, devices
and components of stainless steel products), and other non-stainless steel products are warranted to be free from such
defects for one year. SHOR-LINE disclaims any express or implied warranty for products not manufactured by SHOR-LINE
and the only warranty available therefor to customer is that offered by the products' manufacturers.
The warranty period shall run from the date of delivery to customer. If within the applicable warranty period a product
proves to be defective as described herein, SHOR-LINE will repair or replace the product, at SHOR-LINE's sole discretion,
conditional upon customer's written notice of the defect within fteen (15) days after its discovery and compliance
with applicable return procedures. Upon receipt of customer's notice including substantiation of customer's status as
the initial purchaser and details of the defect, SHOR-LINE shall advise customer whether it plans to repair or replace
the product. SHOR-LINE's obligation is solely limited to repair or replacement of a defective product and in no event
shall SHOR-LINE be liable for transportation from or to SHOR-LINE's ofces or any other expense which may arise in
connection with this limited warranty or the aforementioned product satisfaction policy.
SHOR-LINE makes no other warranty or guarantee of any kind whatsoever, whether expressed or implied, statutory or
otherwise including, but not limited to implied warranties of tness and or merchantability. The above limited warranty
constitutes SHOR-LINE's only warranty and no person or entity is authorized, on behalf of SHOR-LINE, to modify or
expand upon the provisions expressed in the limited warranty statement. SHOR-LINE's liability under this limited warranty
shall be limited as provided for above and the foregoing shall be the customers sole remedy and recourse under this
contract. There are no warranties, which extend beyond the description on the face here\of and goods are sold as-is.
SHOR-LINE's limited warranty is only available to the initial purchaser of its products.
Customer agrees to comply with all instructions and specications furnished by SHOR-LINE relating to installation,
care and application of products sold. Customer agrees that it will not modify, misapply, or misuse such products in any
manner including one that would deviate from the products' intended use. Any repairs, alterations or service provided
by parties other than SHOR-LINE, or its authorized representative may void this limited warranty. This limited warranty
shall not apply to normal wear and tear, damage caused by accident, negligence, improper operation, or the use of the
corrosive material (including without limitation bleach-sodium hypochlorite) on stainless steel surfaces. SHOR-LINE's
limited warranty made in connection with this sale shall not be effective and shall be void unless such goods are applied
and used in accordance with SHOR-LINE's instructions.
Limitation Of Liability
Under no circumstances shall SHOR-LINE be liable to buyer or any other person for any special liquidated, incidental
or consequential damages, including, without limitation, damages based upon lost goodwill, lost sales or prots, work
stoppage, delay, product failure, impairment of goods or otherwise and whether arising out of breach of warranty, breach
of contract, negligence or otherwise, and in any case, SHOR-LINE's liability for any and all losses and damages sustained
by buyer and others, rising out of or by reason of this contract, shall not exceed the original purchase price of the
products upon which liability is founded. In no event shall any action be commenced against SHOR-LINE more than one
year after the cause of action with respect to which the claim is made has occurred. SHOR-LINE shall not be responsible
for expenses for repairs not made by SHOR-LINE without the prior written consent of SHORE-LINE. Product specications
are subject to change without any notice or obligation on the part of SHOR-LINE.
NOVEMBER 2020

Shor-Line.com
…
Contact Information
SHOR-LINE
Schroer Manufacturing Company
511 Osage Ave.
Kansas City, Kansas 66105, USA
PHONE: [phone]
LOCAL: 913.281.1500
FAX: [phone]
EMAIL: [email protected]
WEB ADDRESS: SHOR-LINE.com
SHOR-LINE LIMITED
Vale Business Park Llandow,
Vale of Glamorgan CF71 7PF
United Kingdom
PHONE: [phone]
FAX: [phone]
EMAIL: [email protected]
WEB ADDRESS: SHOR-LINE.co.uk
