SERVICE MANUAL
DATA
CDC-MP32 YU
SIMPLE
S/M Code No. 09-014-443-9T1
• Replace this Service manual with “Revision Publishing” when it is issued.
STEREO CAR CD RECEIVER BASIC TAPE MECHANISM: CDC02AW1
BASIC CD MECHANISM: BZA-8 MP3NF

– 2 –
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O ACCESSORY 87-B10-141-010 0E NUT,5 TYPE-2 YUSTF CDC-MP32
O ACCESSORY 87-B10-143-010 0E UT1+5-15 W/O SLOT YUSTF CDC-MP32
O ACCESSORY 87-B10-144-010 0E W,5.2-10-0.5 YUSTF CDC-MP32
O ACCESSORY 87-B10-145-010 0E W-SPR,5.3-8.5-1.5 YUSTF CDC-MP32
X ACCESSORY 87-B40-178-010 0E BAG,PV 0.04-100-250 YUSTF CDC-MP32
X ACCESSORY 87-B40-179-010 0E BAG,PV 0.04-50-100 YUSTF CDC-MP32
O ACCESSORY 8Z-KC1-231-110 1C HLDR,HALF -C YUSTF CDC-MP32
O ACCESSORY 8Z-KC1-232-010 0E KEY,REMOVE -C YUSTF CDC-MP32
O ACCESSORY 8Z-KC1-235-010 0E HLDR,REAR MTG YUSTF CDC-MP32
O ACCESSORY 8Z-KC1-244-010 0E S-SCREW,5*6 TH+ TAPPING ST YUSTF CDC-MP32
O ACCESSORY 8Z-KC1-250-010 0E S-SCREW,HEXAGON YUSTF CDC-MP32
O ACCESSORY 8Z-KT1-616-010 1F CONN ASSY,16P B52 YUSTF CDC-MP32
O APPEARANCE 8B-KC6-001-010 1B WINDOW,LCD MP32 YU YUSTF CDC-MP32
O APPEARANCE 8B-KC7-025-010 1A PANEL,BOARD YUSTF CDC-MP32
O APPEARANCE * 8B-KC6-002-010 1E CABI,FRONT AL MP3 YUSTF CDC-MP32
O APPEARANCE * 8B-KC7-001-010 1A CABI,FRONT HIGH YUSTF CDC-MP32
O APPEARANCE * 8B-KC7-002-010 1B CABI,REAR YUSTF CDC-MP32
O APPEARANCE * 8B-KC7-008-010 1A CABI,BTN PANEL B YUSTF CDC-MP32
O APPEARANCE * 8B-KC7-015-010 0E LENS,BER YUSTF CDC-MP32
O APPEARANCE * 8B-KC7-021-010 1A CABI,BASE MAIN YUSTF CDC-MP32
O APPEARANCE * 8B-KC7-022-010 0E LENS,CD YUSTF CDC-MP32
O APPEARANCE * 8B-KC7-023-010 1B CABI,BASE AROUND YUSTF CDC-MP32
O APPEARANCE * 8B-KC7-024-010 1A CABI,TRIM YUSTF CDC-MP32
O CD 88-KC4-641-010 1A FF-CABLE, 20P 1.0 90MM YUSTF CDC-MP32
O CD 88-ZG5-317-010 0E S-SCREW,8ZG5S+2-4 W/O YUSTF CDC-MP32
X CD 89-920-030-110 0E WIRE,UD0-3-3 YUSTF CDC-MP32
O CD 8A-KC7-255-010 0E SPR-C,WIRE YUSTF CDC-MP32
X CD A8-BZA-890-040 -- BZA-8 MP3NF YUSTF CDC-MP32
X CD M8-AZK-E90-070 3M CDC02AW1 YUSTF CDC-MP32
O CD C 0402 87-A10-369-080 0E C-CAP,S 0.47-16 K B YUSTF CDC-MP32
O CD C 0403 87-A10-369-080 0E C-CAP,S 0.47-16 K B YUSTF CDC-MP32
O CD C 0409 87-010-494-040 0E CAP,E 1-50 M 5L SRE YUSTF CDC-MP32
O CD C 0410 87-010-494-040 0E CAP,E 1-50 M 5L SRE YUSTF CDC-MP32
X CD R 0435 88-108-000-080 0E C-JUMPER,U YUSTF CDC-MP32
X CD R 0436 88-108-000-080 0E C-JUMPER,U YUSTF CDC-MP32
O CONNECTION 8B-KC1-603-010 0E F-CABLE,2P (PWB LED) YUSTF CDC-MP32
O CONNECTION * 8B-KC7-617-010 0E CONN ASSY,6P EMP YUSTF CDC-MP32
O CONNECTION * 8B-KC7-618-010 0E F-CABLE,2P MOT YUSTF CDC-MP32
O CONNECTION ANT0101 8Z-KT1-614-010 1A ANT,AW-002 YUSTF CDC-MP32
O CONNECTION CON0401 87-A61-219-010 1A CONN,20P H 52089-2020 YUSTF CDC-MP32
O CONNECTION CON0402 87-A61-584-010 1B CONN,24P H 52089-2420 YUSTF CDC-MP32
O CONNECTION CON0403 87-A61-583-010 1A CONN,16P H 52089-1620 YUSTF CDC-MP32
O CONNECTION CON0701 8Z-KT1-611-010 1B CONN,16P CAM-B51 YUSTF CDC-MP32
O CONNECTION CON0751 87-A60-670-010 0E CONN,6P H 2MM JMT YUSTF CDC-MP32
O CONNECTION J 0401 87-A61-224-110 1A JACK,PIN 4P XR-401 YUSTF CDC-MP32
O CONNECTION J 0402 8A-KC7-620-010 1B JACK,DIN 13 P SKDS1302 YUSTF CDC-MP32
O E-VOL C 0301 87-010-497-040 0E CAP,E 4.7-35 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0302 87-010-497-040 0E CAP,E 4.7-35 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0303 87-010-494-040 0E CAP,E 1-50 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0304 87-010-494-040 0E CAP,E 1-50 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0305 87-012-280-080 0E C-CAP,U 3300P-50 K B YUSTF CDC-MP32
O E-VOL C 0306 87-012-280-080 0E C-CAP,U 3300P-50 K B YUSTF CDC-MP32
O E-VOL C 0307 87-010-787-080 0E C-CAP,U 0.022-25 K B YUSTF CDC-MP32
O E-VOL C 0308 87-010-787-080 0E C-CAP,U 0.022-25 K B YUSTF CDC-MP32
O E-VOL C 0309 87-010-494-040 0E CAP,E 1-50 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0310 87-010-494-040 0E CAP,E 1-50 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0311 87-A12-308-080 0E C-CAP,S 0.15-25 K B YUSTF CDC-MP32
O E-VOL C 0312 87-A12-308-080 0E C-CAP,S 0.15-25 K B YUSTF CDC-MP32
O E-VOL C 0313 87-A12-308-080 0E C-CAP,S 0.15-25 K B YUSTF CDC-MP32
O E-VOL C 0314 87-A12-308-080 0E C-CAP,S 0.15-25 K B YUSTF CDC-MP32
O E-VOL C 0315 87-010-494-040 0E CAP,E 1-50 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0316 87-010-494-040 0E CAP,E 1-50 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0317 87-010-831-080 0E C-CAP,U 0.1-16 Z F YUSTF CDC-MP32
O E-VOL C 0318 87-010-498-040 0E CAP,E 10-16 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0321 87-010-555-040 0E CAP,E 100-10 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0322 87-010-787-080 0E C-CAP,U 0.022-25 K B YUSTF CDC-MP32
O E-VOL C 0323 87-010-498-040 0E CAP,E 10-16 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0324 87-010-498-040 0E CAP,E 10-16 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0325 87-010-498-040 0E CAP,E 10-16 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0326 87-010-498-040 0E CAP,E 10-16 M 5L SRE YUSTF CDC-MP32

– 3 –
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O E-VOL C 0341 87-010-491-040 0E CAP,E 0.22-50 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0342 87-010-491-040 0E CAP,E 0.22-50 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0401 87-010-498-040 0E CAP,E 10-16 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0423 87-010-497-040 0E CAP,E 4.7-35 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0424 87-010-497-040 0E CAP,E 4.7-35 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0425 87-010-497-040 0E CAP,E 4.7-35 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0426 87-010-497-040 0E CAP,E 4.7-35 M 5L SRE YUSTF CDC-MP32
O E-VOL C 0427 87-012-270-080 0E C-CAP,U 470P-50 K B YUSTF CDC-MP32
O E-VOL C 0428 87-012-270-080 0E C-CAP,U 470P-50 K B YUSTF CDC-MP32
O E-VOL C 0429 87-012-270-080 0E C-CAP,U 470P-50 K B YUSTF CDC-MP32
O E-VOL C 0430 87-012-270-080 0E C-CAP,U 470P-50 K B YUSTF CDC-MP32
O E-VOL C 0451 87-012-358-080 0E C-CAP,S 0.47-10 Z F CM/CB YUSTF CDC-MP32
O E-VOL C 0452 87-012-358-080 0E C-CAP,S 0.47-10 Z F CM/CB YUSTF CDC-MP32
O E-VOL C 0453 87-010-831-080 0E C-CAP,U 0.1-16 Z F YUSTF CDC-MP32
O E-VOL C 0454 87-012-286-080 0E C-CAP,U 0.01-25 K B YUSTF CDC-MP32
S E-VOL D 0301 87-020-331-040 0E C-DIODE,DAN202K YUSTF CDC-MP32
S E-VOL D 0401 87-020-331-040 0E C-DIODE,DAN202K YUSTF CDC-MP32
S E-VOL D 0451 87-A40-250-040 0E C-DIODE,DAN217 YUSTF CDC-MP32
S E-VOL IC 0301 8Z-KT1-622-010 2A C-IC,LC75374E YUSTF CDC-MP32
X E-VOL JR 0007 88-108-000-080 0E C-JUMPER,U YUSTF CDC-MP32
X E-VOL JR 0008 88-108-000-080 0E C-JUMPER,U YUSTF CDC-MP32
X E-VOL JR 0009 88-108-000-080 0E C-JUMPER,U YUSTF CDC-MP32
X E-VOL JR 0010 88-108-000-080 0E C-JUMPER,U YUSTF CDC-MP32
O E-VOL L 0401 87-003-102-080 0E COIL,10UH J LAL02 YUSTF CDC-MP32
S E-VOL Q 0341 87-A30-287-040 0E C-TR,DTC114TKA YUSTF CDC-MP32
S E-VOL Q 0342 87-A30-287-040 0E C-TR,DTC114TKA YUSTF CDC-MP32
S E-VOL Q 0401 87-A30-283-040 0E C-TR,DTA114YKA YUSTF CDC-MP32
S E-VOL Q 0402 87-A30-287-040 0E C-TR,DTC114TKA YUSTF CDC-MP32
S E-VOL Q 0403 87-A30-287-040 0E C-TR,DTC114TKA YUSTF CDC-MP32
S E-VOL Q 0404 87-A30-287-040 0E C-TR,DTC114TKA YUSTF CDC-MP32
S E-VOL Q 0405 87-A30-287-040 0E C-TR,DTC114TKA YUSTF CDC-MP32
S E-VOL Q 0406 87-A30-287-040 0E C-TR,DTC114TKA YUSTF CDC-MP32
S E-VOL Q 0451 89-324-122-040 0E C-TR,2SC2412KR YUSTF CDC-MP32
X E-VOL R 0301 88-108-332-080 0E C-RES,U 3.3K-1/16W J YUSTF CDC-MP32
X E-VOL R 0302 88-108-332-080 0E C-RES,U 3.3K-1/16W J YUSTF CDC-MP32
X E-VOL R 0303 88-108-332-080 0E C-RES,U 3.3K-1/16W J YUSTF CDC-MP32
X E-VOL R 0304 88-108-332-080 0E C-RES,U 3.3K-1/16W J YUSTF CDC-MP32
X E-VOL R 0305 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X E-VOL R 0306 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X E-VOL R 0307 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X E-VOL R 0308 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X E-VOL R 0311 88-108-223-080 0E C-RES,U 22K-1/16W J YUSTF CDC-MP32
X E-VOL R 0312 88-108-223-080 0E C-RES,U 22K-1/16W J YUSTF CDC-MP32
X E-VOL R 0313 88-108-223-080 0E C-RES,U 22K-1/16W J YUSTF CDC-MP32
X E-VOL R 0314 88-108-223-080 0E C-RES,U 22K-1/16W J YUSTF CDC-MP32
X E-VOL R 0315 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X E-VOL R 0316 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X E-VOL R 0317 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X E-VOL R 0318 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X E-VOL R 0321 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X E-VOL R 0322 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X E-VOL R 0323 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X E-VOL R 0341 88-108-335-080 0E C-RES,U 3.3M-1/16W J YUSTF CDC-MP32
X E-VOL R 0342 88-108-335-080 0E C-RES,U 3.3M-1/16W J YUSTF CDC-MP32
X E-VOL R 0343 88-108-104-080 0E C-RES,U 100K-1/16W J YUSTF CDC-MP32
X E-VOL R 0344 88-108-104-080 0E C-RES,U 100K-1/16W J YUSTF CDC-MP32
X E-VOL R 0345 88-108-104-080 0E C-RES,U 100K-1/16W J YUSTF CDC-MP32
X E-VOL R 0346 88-108-104-080 0E C-RES,U 100K-1/16W J YUSTF CDC-MP32
X E-VOL R 0401 88-108-562-080 0E C-RES,U 5.6K-1/16W J YUSTF CDC-MP32
X E-VOL R 0402 88-108-222-080 0E C-RES,U 2.2K-1/16W J YUSTF CDC-MP32
X E-VOL R 0437 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X E-VOL R 0438 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X E-VOL R 0439 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X E-VOL R 0440 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X E-VOL R 0451 88-108-104-080 0E C-RES,U 100K-1/16W J YUSTF CDC-MP32
X E-VOL R 0452 88-108-104-080 0E C-RES,U 100K-1/16W J YUSTF CDC-MP32
X E-VOL R 0453 88-108-105-080 0E C-RES,U 1M-1/16W J YUSTF CDC-MP32
X E-VOL R 0454 88-108-472-080 0E C-RES,U 4.7K-1/16W J YUSTF CDC-MP32
X E-VOL R 0455 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
X E-VOL R 0456 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32

– 4 –
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X E-VOL R 0457 88-108-105-080 0E C-RES,U 1M-1/16W J YUSTF CDC-MP32
O ELECTRICAL C 0602 87-010-831-080 0E C-CAP,U 0.1-16 Z F YUSTF CDC-MP32
O ELECTRICAL C 0603 87-010-831-080 0E C-CAP,U 0.1-16 Z F YUSTF CDC-MP32
O ELECTRICAL C 0604 87-A10-504-080 0E C-CAP,U 0.047-16 K B YUSTF CDC-MP32
O ELECTRICAL C 0605 87-012-199-080 0E C-CAP,U 220P-50 J CH YUSTF CDC-MP32
O ELECTRICAL C 0606 87-A10-504-080 0E C-CAP,U 0.047-16 K B YUSTF CDC-MP32
O ELECTRICAL C 0607 87-A10-504-080 0E C-CAP,U 0.047-16 K B YUSTF CDC-MP32
O ELECTRICAL C 0608 87-A10-504-080 0E C-CAP,U 0.047-16 K B YUSTF CDC-MP32
O ELECTRICAL C 0609 87-A10-504-080 0E C-CAP,U 0.047-16 K B YUSTF CDC-MP32
O ELECTRICAL C 0610 87-010-805-080 0E C-CAP,S 1-16 Z F YUSTF CDC-MP32
O ELECTRICAL C 0611 87-010-831-080 0E C-CAP,U 0.1-16 Z F YUSTF CDC-MP32
O ELECTRICAL C 0612 87-010-831-080 0E C-CAP,U 0.1-16 Z F YUSTF CDC-MP32
O ELECTRICAL C 0613 87-012-286-080 0E C-CAP,U 0.01-25 K B YUSTF CDC-MP32
O ELECTRICAL C 0621 87-010-831-080 0E C-CAP,U 0.1-16 Z F YUSTF CDC-MP32
O ELECTRICAL CON0601 87-A61-585-080 1B C-CONN,24P H 54548-2490 YUSTF CDC-MP32
O ELECTRICAL CON0603 87-A61-586-080 1A C-CONN,16P V FLZT-SM1 YUSTF CDC-MP32
S ELECTRICAL D 0601 87-A40-250-040 0E C-DIODE,DAN217 YUSTF CDC-MP32
S ELECTRICAL IC 0601 87-A21-532-030 2M C-IC,LC75817W-8720 YUSTF CDC-MP32
X ELECTRICAL JR 0601 88-108-000-080 0E C-JUMPER,U YUSTF CDC-MP32
X ELECTRICAL JR 0602 88-108-000-080 0E C-JUMPER,U YUSTF CDC-MP32
O ELECTRICAL L 0601 87-005-906-080 0E C-COIL,S 10UH K LK2125 YUSTF CDC-MP32
O ELECTRICAL L 0602 87-005-906-080 0E C-COIL,S 10UH K LK2125 YUSTF CDC-MP32
O ELECTRICAL L 0603 87-005-906-080 0E C-COIL,S 10UH K LK2125 YUSTF CDC-MP32
O ELECTRICAL LED0601 87-A91-355-040 0E C-LED,BR1112H-TR-RED YUSTF CDC-MP32
O ELECTRICAL LED0602 87-A91-355-040 0E C-LED,BR1112H-TR-RED YUSTF CDC-MP32
O ELECTRICAL LED0603 87-A91-355-040 0E C-LED,BR1112H-TR-RED YUSTF CDC-MP32
O ELECTRICAL LED0604 87-A91-355-040 0E C-LED,BR1112H-TR-RED YUSTF CDC-MP32
O ELECTRICAL LED0611 87-A91-355-040 0E C-LED,BR1112H-TR-RED YUSTF CDC-MP32
O ELECTRICAL LED0612 87-A91-355-040 0E C-LED,BR1112H-TR-RED YUSTF CDC-MP32
O ELECTRICAL LED0613 87-A91-355-040 0E C-LED,BR1112H-TR-RED YUSTF CDC-MP32
O ELECTRICAL LED0614 87-A91-355-040 0E C-LED,BR1112H-TR-RED YUSTF CDC-MP32
O ELECTRICAL LED0615 87-A91-355-040 0E C-LED,BR1112H-TR-RED YUSTF CDC-MP32
O ELECTRICAL LED0616 87-A91-355-040 0E C-LED,BR1112H-TR-RED YUSTF CDC-MP32
O ELECTRICAL LED0617 87-A91-355-040 0E C-LED,BR1112H-TR-RED YUSTF CDC-MP32
O ELECTRICAL LED0619 87-A40-813-340 1E C-LED,SEC1E01C BLU YUSTF CDC-MP32
O ELECTRICAL LED0620 87-A40-813-340 1E C-LED,SEC1E01C BLU YUSTF CDC-MP32
O ELECTRICAL LED0621 87-A40-813-340 1E C-LED,SEC1E01C BLU YUSTF CDC-MP32
O ELECTRICAL LED0622 87-A40-813-340 1E C-LED,SEC1E01C BLU YUSTF CDC-MP32
O ELECTRICAL LED0625 87-A91-355-040 0E C-LED,BR1112H-TR-RED YUSTF CDC-MP32
O ELECTRICAL LED0626 87-A91-355-040 0E C-LED,BR1112H-TR-RED YUSTF CDC-MP32
S ELECTRICAL Q 0611 89-324-122-040 0E C-TR,2SC2412KR YUSTF CDC-MP32
S ELECTRICAL Q 0612 87-A30-287-040 0E C-TR,DTC114TKA YUSTF CDC-MP32
S ELECTRICAL Q 0613 87-A30-287-040 0E C-TR,DTC114TKA YUSTF CDC-MP32
S ELECTRICAL Q 0614 89-324-122-040 0E C-TR,2SC2412KR YUSTF CDC-MP32
S ELECTRICAL Q 0615 89-324-122-040 0E C-TR,2SC2412KR YUSTF CDC-MP32
X ELECTRICAL R 0601 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X ELECTRICAL R 0602 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X ELECTRICAL R 0603 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X ELECTRICAL R 0604 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X ELECTRICAL R 0605 88-108-333-080 0E C-RES,U 33K-1/16W J YUSTF CDC-MP32
X ELECTRICAL R 0606 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
X ELECTRICAL R 0607 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
X ELECTRICAL R 0608 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
X ELECTRICAL R 0609 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
X ELECTRICAL R 0612 88-118-471-080 0E C-RES,S 470-1/10W J YUSTF CDC-MP32
X ELECTRICAL R 0613 88-118-471-080 0E C-RES,S 470-1/10W J YUSTF CDC-MP32
X ELECTRICAL R 0615 88-108-331-080 0E C-RES,U 330-1/16W J YUSTF CDC-MP32
X ELECTRICAL R 0616 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X ELECTRICAL R 0617 88-108-180-080 0E C-RES,U 18-1/16W J YUSTF CDC-MP32
X ELECTRICAL R 0618 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X ELECTRICAL R 0619 88-108-332-080 0E C-RES,U 3.3K-1/16W J YUSTF CDC-MP32
X ELECTRICAL R 0620 88-118-331-080 0E C-RES,S 330-1/10W J YUSTF CDC-MP32
X ELECTRICAL R 0621 88-118-331-080 0E C-RES,S 330-1/10W J YUSTF CDC-MP32
X ELECTRICAL R 0651 88-118-471-080 0E C-RES,S 470-1/10W J YUSTF CDC-MP32
X ELECTRICAL R 0652 88-118-471-080 0E C-RES,S 470-1/10W J YUSTF CDC-MP32
X ELECTRICAL R 0653 88-118-471-080 0E C-RES,S 470-1/10W J YUSTF CDC-MP32
X ELECTRICAL R 0654 88-118-331-080 0E C-RES,S 330-1/10W J YUSTF CDC-MP32
X ELECTRICAL R 0655 88-108-152-080 0E C-RES,U 1.5K-1/16W J YUSTF CDC-MP32
X ELECTRICAL R 0656 88-108-152-080 0E C-RES,U 1.5K-1/16W J YUSTF CDC-MP32
X ELECTRICAL R 0657 88-118-331-080 0E C-RES,S 330-1/10W J YUSTF CDC-MP32

– 5 –
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X ELECTRICAL R 0658 88-118-331-080 0E C-RES,S 330-1/10W J YUSTF CDC-MP32
X ELECTRICAL R 0659 88-118-331-080 0E C-RES,S 330-1/10W J YUSTF CDC-MP32
X ELECTRICAL R 0660 88-118-331-080 0E C-RES,S 330-1/10W J YUSTF CDC-MP32
X ELECTRICAL R 0661 88-118-331-080 0E C-RES,S 330-1/10W J YUSTF CDC-MP32
O ELECTRICAL SW 0601 87-A90-001-080 1A C-SW,TACT SKQMAL YUSTF CDC-MP32
O ELECTRICAL SW 0602 87-A90-001-080 1A C-SW,TACT SKQMAL YUSTF CDC-MP32
O ELECTRICAL SW 0603 87-A90-001-080 1A C-SW,TACT SKQMAL YUSTF CDC-MP32
O ELECTRICAL SW 0604 87-A90-001-080 1A C-SW,TACT SKQMAL YUSTF CDC-MP32
O ELECTRICAL SW 0605 87-A90-001-080 1A C-SW,TACT SKQMAL YUSTF CDC-MP32
O ELECTRICAL SW 0606 87-036-220-080 1A C-SW,TACT SKQDAA YUSTF CDC-MP32
O ELECTRICAL SW 0607 87-036-220-080 1A C-SW,TACT SKQDAA YUSTF CDC-MP32
O ELECTRICAL SW 0608 87-036-220-080 1A C-SW,TACT SKQDAA YUSTF CDC-MP32
O ELECTRICAL SW 0609 87-036-220-080 1A C-SW,TACT SKQDAA YUSTF CDC-MP32
O ELECTRICAL SW 0610 87-036-220-080 1A C-SW,TACT SKQDAA YUSTF CDC-MP32
O ELECTRICAL SW 0611 87-036-220-080 1A C-SW,TACT SKQDAA YUSTF CDC-MP32
O ELECTRICAL SW 0612 87-036-220-080 1A C-SW,TACT SKQDAA YUSTF CDC-MP32
O ELECTRICAL SW 0613 87-036-220-080 1A C-SW,TACT SKQDAA YUSTF CDC-MP32
O ELECTRICAL SW 0614 87-036-220-080 1A C-SW,TACT SKQDAA YUSTF CDC-MP32
O ELECTRICAL SW 0615 87-036-220-080 1A C-SW,TACT SKQDAA YUSTF CDC-MP32
O ELECTRICAL SW 0616 87-036-220-080 1A C-SW,TACT SKQDAA YUSTF CDC-MP32
O ELECTRICAL SW 0617 87-036-220-080 1A C-SW,TACT SKQDAA YUSTF CDC-MP32
O ELECTRICAL SW 0618 87-036-220-080 1A C-SW,TACT SKQDAA YUSTF CDC-MP32
O ELECTRICAL SW 0620 87-A90-001-080 1A C-SW,TACT SKQMAL YUSTF CDC-MP32
O KNOB 8B-KC7-004-010 1A BTN,+/- YUSTF CDC-MP32
O KNOB 8B-KC7-005-010 1A BTN,MUTE YUSTF CDC-MP32
O KNOB 8B-KC7-006-010 1A BTN,TWIN YUSTF CDC-MP32
O KNOB 8B-KC7-010-010 1D BTN,P-SET 7 YUSTF CDC-MP32
X MECHANISM M8-AZL-290-040 -- AZL-2 ANF YUSTF CDC-MP32
O MICON C 0461 87-010-787-080 0E C-CAP,U 0.022-25 K B YUSTF CDC-MP32
O MICON C 0901 87-016-039-090 1B CAP,DL 0.022F-5.5 Z 70 FM YUSTF CDC-MP32
O MICON C 0902 87-012-358-080 0E C-CAP,S 0.47-10 Z F CM/CB YUSTF CDC-MP32
O MICON C 0903 87-010-831-080 0E C-CAP,U 0.1-16 Z F YUSTF CDC-MP32
O MICON C 0904 87-010-787-080 0E C-CAP,U 0.022-25 K B YUSTF CDC-MP32
O MICON C 0905 87-012-180-080 0E C-CAP,U 22P-50 J CH YUSTF CDC-MP32
O MICON C 0906 87-012-182-080 0E C-CAP,U 27P-50 J CH YUSTF CDC-MP32
O MICON C 0907 87-010-831-080 0E C-CAP,U 0.1-16 Z F YUSTF CDC-MP32
O MICON C 0908 87-012-282-080 0E C-CAP,U 4700P-50 K B YUSTF CDC-MP32
O MICON C 0909 87-012-274-080 0E C-CAP,U 1000P-50 K B YUSTF CDC-MP32
O MICON C 0910 87-012-195-080 0E C-CAP,U 100P-50 J CH YUSTF CDC-MP32
O MICON C 0911 87-012-195-080 0E C-CAP,U 100P-50 J CH YUSTF CDC-MP32
O MICON C 0912 87-010-787-080 0E C-CAP,U 0.022-25 K B YUSTF CDC-MP32
O MICON C 0913 87-010-787-080 0E C-CAP,U 0.022-25 K B YUSTF CDC-MP32
O MICON C 0915 87-012-274-080 0E C-CAP,U 1000P-50 K B YUSTF CDC-MP32
O MICON C 0916 87-010-787-080 0E C-CAP,U 0.022-25 K B YUSTF CDC-MP32
S MICON D 0461 87-A40-817-040 0E C-ZENER,STZ6.8N YUSTF CDC-MP32
S MICON D 0462 87-A40-817-040 0E C-ZENER,STZ6.8N YUSTF CDC-MP32
S MICON D 0463 87-A40-817-040 0E C-ZENER,STZ6.8N YUSTF CDC-MP32
S MICON D 0708 87-020-330-040 0E C-DIODE,DAP202K YUSTF CDC-MP32
S MICON D 0713 87-070-136-080 0E ZENER,MTZJ5.1B YUSTF CDC-MP32
S MICON D 0901 87-020-331-040 0E C-DIODE,DAN202K YUSTF CDC-MP32
S MICON D 0902 87-020-331-040 0E C-DIODE,DAN202K YUSTF CDC-MP32
S MICON D 0904 87-020-331-040 0E C-DIODE,DAN202K YUSTF CDC-MP32
S MICON D 0907 87-020-331-040 0E C-DIODE,DAN202K YUSTF CDC-MP32
S MICON D 0908 87-020-331-040 0E C-DIODE,DAN202K YUSTF CDC-MP32
S MICON D 0909 87-020-331-040 0E C-DIODE,DAN202K YUSTF CDC-MP32
S MICON D 0911 87-020-331-040 0E C-DIODE,DAN202K YUSTF CDC-MP32
S MICON IC 0901 8B-KC6-621-030 2M C-IC,UPD178018AGC-598 YUSTF CDC-MP32
S MICON IC 0903 87-020-784-040 1B C-IC,TC4053BF YUSTF CDC-MP32
O MICON L 0702 87-003-149-080 0E COIL,47UH J LAL02 YUSTF CDC-MP32
S MICON Q 0461 87-A30-283-040 0E C-TR,DTA114YKA YUSTF CDC-MP32
S MICON Q 0462 87-A30-288-040 0E C-TR,DTC114YKA YUSTF CDC-MP32
X MICON R 0403 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0461 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0462 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0463 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0464 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0465 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0466 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0467 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0468 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32

– 6 –
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON R 0469 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0470 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0471 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0901 88-108-473-080 0E C-RES,U 47K-1/16W J YUSTF CDC-MP32
X MICON R 0902 88-108-104-080 0E C-RES,U 100K-1/16W J YUSTF CDC-MP32
X MICON R 0904 88-108-104-080 0E C-RES,U 100K-1/16W J YUSTF CDC-MP32
X MICON R 0905 88-108-104-080 0E C-RES,U 100K-1/16W J YUSTF CDC-MP32
X MICON R 0906 88-108-224-080 0E C-RES,U 220K-1/16W J YUSTF CDC-MP32
X MICON R 0907 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0908 88-108-152-080 0E C-RES,U 1.5K-1/16W J YUSTF CDC-MP32
X MICON R 0909 88-108-473-080 0E C-RES,U 47K-1/16W J YUSTF CDC-MP32
X MICON R 0910 88-108-104-080 0E C-RES,U 100K-1/16W J YUSTF CDC-MP32
X MICON R 0911 88-108-222-080 0E C-RES,U 2.2K-1/16W J YUSTF CDC-MP32
X MICON R 0912 88-108-222-080 0E C-RES,U 2.2K-1/16W J YUSTF CDC-MP32
X MICON R 0913 88-108-104-080 0E C-RES,U 100K-1/16W J YUSTF CDC-MP32
X MICON R 0914 88-108-223-080 0E C-RES,U 22K-1/16W J YUSTF CDC-MP32
X MICON R 0915 88-108-223-080 0E C-RES,U 22K-1/16W J YUSTF CDC-MP32
X MICON R 0916 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0917 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0918 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0919 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0920 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0921 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0922 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0923 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0924 88-108-224-080 0E C-RES,U 220K-1/16W J YUSTF CDC-MP32
X MICON R 0929 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X MICON R 0931 88-108-104-080 0E C-RES,U 100K-1/16W J YUSTF CDC-MP32
X MICON R 0932 88-108-104-080 0E C-RES,U 100K-1/16W J YUSTF CDC-MP32
X MICON R 0933 88-108-104-080 0E C-RES,U 100K-1/16W J YUSTF CDC-MP32
X MICON R 0934 88-108-223-080 0E C-RES,U 22K-1/16W J YUSTF CDC-MP32
X MICON R 0935 88-108-104-080 0E C-RES,U 100K-1/16W J YUSTF CDC-MP32
O MICON SW 0903 87-A91-152-010 1A SW,SL 1-1-2 SSSS212-11-A YUSTF CDC-MP32
O MICON X 0901 87-A70-175-010 1B VIB,XTAL 4.5MHZ AT-49 YUSTF CDC-MP32
O OTHERS 85-ZL3-203-010 0E MAGNET,ACU YUSTF CDC-MP32
O OTHERS 87-010-552-040 0E CAP,E 22-16 M 5L SRE YUSTF CDC-MP32
O OTHERS 87-018-119-080 0E CAP,TC U 100P-50 K B UP050 YUSTF CDC-MP32
S OTHERS 87-020-465-080 0E DIODE,1SS133 YUSTF CDC-MP32
X OTHERS 87-600-021-210 0E WIRE,P0-2-1 YUSTF CDC-MP32
X OTHERS 87-600-042-210 0E WIRE,P0-4-2 YUSTF CDC-MP32
X OTHERS 87-612-042-210 0E WIRE,B2-4-2 YUSTF CDC-MP32
X OTHERS 87-830-101-510 0E TUBE,UL 1-15 YUSTF CDC-MP32
X OTHERS 88-118-000-080 0E C-JUMPER,S YUSTF CDC-MP32
X OTHERS 88-121-104-080 0E RES,100K-1/8W J YUSTF CDC-MP32
X OTHERS 88-121-152-080 0E RES,1.5K-1/8W J YUSTF CDC-MP32
X OTHERS 88-121-224-080 0E RES,220K-1/8W J YUSTF CDC-MP32
X OTHERS 88-121-683-080 0E RES,68K-1/8W J YUSTF CDC-MP32
X OTHERS 8A-KC5-204-010 0E SH,5-10-1.65 YUSTF CDC-MP32
O OTHERS 8B-KC1-213-110 0E CHAS,SIDE L-BC YUSTF CDC-MP32
O OTHERS 8B-KC1-214-110 0E CHAS,SIDE R-BC YUSTF CDC-MP32
X OTHERS 8B-KC6-204-010 -- SH, 22.5-27-0.15 W/ADH BLK YUSTF CDC-MP32
O OTHERS 8B-KC7-201-010 0E PLATE,LENS BOTTOM YUSTF CDC-MP32
O OTHERS 8B-KC7-204-010 0E CASE,LCD YUSTF CDC-MP32
X OTHERS 8B-KC7-205-010 -- PLATE,PANEL-SW YUSTF CDC-MP32
X OTHERS 8B-KC7-206-010 -- SHAFT,PANEL-SW YUSTF CDC-MP32
O OTHERS 8B-KC7-207-010 1A PLATE,PANEL A’SSY YUSTF CDC-MP32
O OTHERS 8B-KC7-208-010 1A COVER, DUST YUSTF CDC-MP32
O OTHERS 8B-KC7-215-010 0E SHAFT,FLAP L/R YUSTF CDC-MP32
O OTHERS 8B-KC7-218-010 0E TERMINAL,PWB YUSTF CDC-MP32
X OTHERS 8B-KC7-221-010 1A SH,L-BT 18 YUSTF CDC-MP32
O OTHERS 8B-KC7-222-010 0E PLATE,MAGNET YUSTF CDC-MP32
X OTHERS 8B-KC7-224-010 0E SH, 5.5-10-0.7 W/ADH BLK YUSTF CDC-MP32
X OTHERS 8B-KC7-225-010 0E SH, 6-10-0.1 W/ADH BLK YUSTF CDC-MP32
X OTHERS 8B-KC7-226-010 0E SH,MIRROR 2-7-0.025 YUSTF CDC-MP32
X OTHERS 8B-KC7-230-010 0E SH,FLEX YUSTF CDC-MP32
X OTHERS 8B-KC7-232-010 0E SH,REMOTE YUSTF CDC-MP32
X OTHERS 8B-KC7-233-010 0E SH,TACT YUSTF CDC-MP32
X OTHERS 8B-KC7-234-010 0E SH,CABI YUSTF CDC-MP32
X OTHERS 8B-KC7-235-010 0E SH, 8-2.5-0.075 W/ADH BLK YUSTF CDC-MP32
X OTHERS 8B-KC7-236-010 0E SH, 20-7-0.05 W/ADH YUSTF CDC-MP32

– 7 –
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X OTHERS 8B-KC7-238-010 0E SH, 3-10-0.3 W/ADH BLK YUSTF CDC-MP32
O OTHERS 8B-KC7-251-010 1A COVER, BT-B YUSTF CDC-MP32
X OTHERS 8B-KC7-253-010 0E SH,BER YUSTF CDC-MP32
O OTHERS 8B-KC7-611-010 1B PWB,FLEX DISP YUSTF CDC-MP32
O OTHERS 8B-KC7-612-010 1A PWB,FLEX KEY YUSTF CDC-MP32
X OTHERS 8B-KCG-240-110 1C PANEL,HT-SINK -B YUSTF CDC-MP32
O OTHERS 8Z-KC1-256-010 1B COVER, BOTTOM RDS YUSTF CDC-MP32
O OTHERS * 8A-KC7-224-010 0E HLDR,P-IC -AC YUSTF CDC-MP32
O OTHERS * 8A-KC7-225-010 0E HLDR,CD-AC YUSTF CDC-MP32
O OTHERS * 8B-KC1-602-010 0E F-CABLE,4P (AUX-W/S) YUSTF CDC-MP32
O OTHERS * 8B-KC6-201-010 0E HLDR,STATIC MP3 YUSTF CDC-MP32
X OTHERS * 8B-KC6-202-010 0E SH,HLDR STATIC YUSTF CDC-MP32
O OTHERS * 8B-KC7-202-010 1A LENS,LCD YUSTF CDC-MP32
X OTHERS * 8B-KC7-203-010 0E SH,LCD YUSTF CDC-MP32
O OTHERS * 8B-KC7-209-010 0E HLDR,SP-L YUSTF CDC-MP32
O OTHERS * 8B-KC7-210-010 0E HLDR,SP-R YUSTF CDC-MP32
O OTHERS * 8B-KC7-211-010 0E HLDR,MECHA YUSTF CDC-MP32
O OTHERS * 8B-KC7-212-010 0E HLDR,TR2-B YUSTF CDC-MP32
X OTHERS * 8B-KC7-213-010 0E SH,ADH WINDOW YUSTF CDC-MP32
X OTHERS * 8B-KC7-214-010 0E SH,CABI REAR YUSTF CDC-MP32
O OTHERS * 8B-KC7-217-010 0E HLDR,MECHA FR YUSTF CDC-MP32
X OTHERS * 8B-KC7-220-010 0E SH,PANEL YUSTF CDC-MP32
X OTHERS * 8Z-KC1-234-210 1B SH,PWB YUSTF CDC-MP32
O OTHERS C 0366 87-010-555-040 0E CAP,E 100-10 M 5L SRE YUSTF CDC-MP32
O OTHERS C 0407 87-010-494-040 0E CAP,E 1-50 M 5L SRE YUSTF CDC-MP32
O OTHERS C 0408 87-010-494-040 0E CAP,E 1-50 M 5L SRE YUSTF CDC-MP32
O OTHERS C 0751 87-012-368-080 0E C-CAP,S 0.1-50 Z F YUSTF CDC-MP32
O OTHERS C 0752 87-012-368-080 0E C-CAP,S 0.1-50 Z F YUSTF CDC-MP32
O OTHERS C 0753 87-012-368-080 0E C-CAP,S 0.1-50 Z F YUSTF CDC-MP32
O OTHERS C 0754 87-010-553-040 0E CAP,E 47-16 M 5L SRE YUSTF CDC-MP32
S OTHERS D 0201 87-A30-287-040 0E C-TR,DTC114TKA YUSTF CDC-MP32
S OTHERS D 0709 87-070-136-080 0E ZENER,MTZJ5.1B YUSTF CDC-MP32
O OTHERS IC 0602 87-A90-951-010 1C RCR UNIT,SBX1971-52 YUSTF CDC-MP32
S OTHERS IC 0751 87-A20-712-040 1B C-IC,BA6417F YUSTF CDC-MP32
O OTHERS J 0601 87-A60-925-010 1A JACK,3.6 BLK ST W/SW YUSTF CDC-MP32
O OTHERS L 0402 87-003-102-080 0E COIL,10UH J LAL02 YUSTF CDC-MP32
O OTHERS LCD0701 8B-KC7-626-010 2M LCD,BKC-1/7 YUSTF CDC-MP32
O OTHERS LED0605 87-A41-085-010 1E LED,NSPW315BS WHT YUSTF CDC-MP32
O OTHERS LED0606 87-A41-085-010 1E LED,NSPW315BS WHT YUSTF CDC-MP32
O OTHERS LED0618 87-A41-096-010 1D LED,E1L31-3B0A2 BLU YUSTF CDC-MP32
O OTHERS LED0951 87-A40-228-010 0E LED,SLR-342MG T31 GREEN YUSTF CDC-MP32
O OTHERS PS 0671 87-A92-061-080 1A C-SNSR,GP1S092 HCPI YUSTF CDC-MP32
X OTHERS R 0405 88-108-152-080 0E C-RES,U 1.5K-1/16W J YUSTF CDC-MP32
X OTHERS R 0406 88-108-152-080 0E C-RES,U 1.5K-1/16W J YUSTF CDC-MP32
X OTHERS R 0407 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
X OTHERS R 0408 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
X OTHERS R 0475 88-108-224-080 0E C-RES,U 220K-1/16W J YUSTF CDC-MP32
X OTHERS R 0476 88-108-224-080 0E C-RES,U 220K-1/16W J YUSTF CDC-MP32
X OTHERS R 0671 88-118-331-080 0E C-RES,S 330-1/10W J YUSTF CDC-MP32
X OTHERS R 0671 88-118-391-080 0E C-RES,S 390-1/10W J YUSTF CDC-MP32
X OTHERS R 0674 88-108-000-080 0E C-JUMPER,U YUSTF CDC-MP32
X OTHERS R 0675 88-108-000-080 0E C-JUMPER,U YUSTF CDC-MP32
X OTHERS R 0751 88-108-123-080 0E C-RES,U 12K-1/16W J YUSTF CDC-MP32
X OTHERS R 0752 88-108-153-080 0E C-RES,U 15K-1/16W J YUSTF CDC-MP32
X OTHERS R 0753 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
X OTHERS R 0754 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
O OTHERS R 0755 87-010-831-080 0E C-CAP,U 0.1-16 Z F YUSTF CDC-MP32
O OTHERS R 0756 87-010-831-080 0E C-CAP,U 0.1-16 Z F YUSTF CDC-MP32
O OTHERS SW 0671 87-A92-039-080 0E C-SW,PUSH ESE22MH24XQ YUSTF CDC-MP32
O OTHERS(RC UNIT) R8-BZR-190-040 2M BZR-1 RC3YUNF YUSTF CDC-MP32
X PACKING DU 87-B40-087-010 0E BAG,PV 0.04-250-350 PL YUSTF CDC-MP32
X PACKING DU 8B-KC6-851-010 1B CTN,PRINTED 2 YUSTF YUSTF CDC-MP32
X PACKING DU 8B-KC6-852-010 1D CTN,OUTER 2 YUSTF YUSTF CDC-MP32
X PACKING DU 8B-KC7-851-010 0E CUSHION,LEFT 7 AIS YUSTF CDC-MP32
X PACKING DU 8B-KC7-852-010 0E CUSHION,RIGHT 7 AIS YUSTF CDC-MP32
X PLATE 87-B40-154-010 0E LBL,BAR-CODE CU YUSTF CDC-MP32
X PLATE 87-B40-282-010 0E LBL,BAR-CODE AU 35X8 YUSTF CDC-MP32
X PLATE 8B-KC6-020-010 0E LBL,SPEC MP32 YU YUSTF CDC-MP32
X PLATE 8Z-KC5-013-010 0E LBL,FCC YUSTF CDC-MP32
X PLATE 8Z-KC5-014-010 0E LBL,DHHS YUSTF CDC-MP32

– 8 –
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O POWER AMP C 0501 87-012-358-080 0E C-CAP,S 0.47-10 Z F CM/CB YUSTF CDC-MP32
O POWER AMP C 0502 87-012-358-080 0E C-CAP,S 0.47-10 Z F CM/CB YUSTF CDC-MP32
O POWER AMP C 0503 87-012-358-080 0E C-CAP,S 0.47-10 Z F CM/CB YUSTF CDC-MP32
O POWER AMP C 0504 87-012-358-080 0E C-CAP,S 0.47-10 Z F CM/CB YUSTF CDC-MP32
O POWER AMP C 0505 87-012-270-080 0E C-CAP,U 470P-50 K B YUSTF CDC-MP32
O POWER AMP C 0506 87-012-270-080 0E C-CAP,U 470P-50 K B YUSTF CDC-MP32
O POWER AMP C 0507 87-012-270-080 0E C-CAP,U 470P-50 K B YUSTF CDC-MP32
O POWER AMP C 0508 87-012-270-080 0E C-CAP,U 470P-50 K B YUSTF CDC-MP32
O POWER AMP C 0510 87-010-498-040 0E CAP,E 10-16 M 5L SRE YUSTF CDC-MP32
O POWER AMP C 0515 8A-KC7-623-000 1B CAP,E 2200-16 125 BT YUSTF CDC-MP32
O POWER AMP C 0516 87-012-368-080 0E C-CAP,S 0.1-50 Z F YUSTF CDC-MP32
O POWER AMP C 0517 87-012-368-080 0E C-CAP,S 0.1-50 Z F YUSTF CDC-MP32
O POWER AMP C 0519 87-010-494-040 0E CAP,E 1-50 M 5L SRE YUSTF CDC-MP32
O POWER AMP C 0522 87-012-368-080 0E C-CAP,S 0.1-50 Z F YUSTF CDC-MP32
S POWER AMP D 0501 87-001-783-080 0E DIODE,1N4002 YUSTF CDC-MP32
S POWER AMP D 0502 87-001-783-080 0E DIODE,1N4002 YUSTF CDC-MP32
S POWER AMP D 0503 87-001-783-080 0E DIODE,1N4002 YUSTF CDC-MP32
S POWER AMP D 0504 87-001-783-080 0E DIODE,1N4002 YUSTF CDC-MP32
S POWER AMP D 0505 87-001-783-080 0E DIODE,1N4002 YUSTF CDC-MP32
S POWER AMP D 0506 87-001-783-080 0E DIODE,1N4002 YUSTF CDC-MP32
S POWER AMP D 0507 87-001-783-080 0E DIODE,1N4002 YUSTF CDC-MP32
S POWER AMP D 0508 87-001-783-080 0E DIODE,1N4002 YUSTF CDC-MP32
S POWER AMP D 0513 87-020-331-040 0E C-DIODE,DAN202K YUSTF CDC-MP32
S POWER AMP IC 0501 8B-KCF-616-010 2P IC,TA8273H YUSTF CDC-MP32
X POWER AMP R 0501 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
X POWER AMP R 0502 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
X POWER AMP R 0503 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
X POWER AMP R 0504 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
X POWER AMP R 0505 88-108-223-080 0E C-RES,U 22K-1/16W J YUSTF CDC-MP32
X POWER AMP R 0506 88-108-223-080 0E C-RES,U 22K-1/16W J YUSTF CDC-MP32
X POWER AMP R 0507 88-108-223-080 0E C-RES,U 22K-1/16W J YUSTF CDC-MP32
X POWER AMP R 0508 88-108-223-080 0E C-RES,U 22K-1/16W J YUSTF CDC-MP32
X POWER AMP R 0509 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
O POWER SUPPLY C 0406 87-010-759-080 0E C-CAP,U 0.1-25 Z F YUSTF CDC-MP32
O POWER SUPPLY C 0701 87-012-278-080 0E C-CAP,U 2200P-50 K B YUSTF CDC-MP32
O POWER SUPPLY C 0704 87-012-368-080 0E C-CAP,S 0.1-50 Z F YUSTF CDC-MP32
O POWER SUPPLY C 0705 87-012-278-080 0E C-CAP,U 2200P-50 K B YUSTF CDC-MP32
O POWER SUPPLY C 0706 87-010-553-040 0E CAP,E 47-16 M 5L SRE YUSTF CDC-MP32
O POWER SUPPLY C 0707 87-010-787-080 0E C-CAP,U 0.022-25 K B YUSTF CDC-MP32
O POWER SUPPLY C 0708 87-010-553-040 0E CAP,E 47-16 M 5L SRE YUSTF CDC-MP32
O POWER SUPPLY C 0709 87-010-759-080 0E C-CAP,U 0.1-25 Z F YUSTF CDC-MP32
O POWER SUPPLY C 0713 87-010-759-080 0E C-CAP,U 0.1-25 Z F YUSTF CDC-MP32
O POWER SUPPLY C 0714 87-010-787-080 0E C-CAP,U 0.022-25 K B YUSTF CDC-MP32
O POWER SUPPLY C 0715 87-010-759-080 0E C-CAP,U 0.1-25 Z F YUSTF CDC-MP32
O POWER SUPPLY C 0716 87-010-759-080 0E C-CAP,U 0.1-25 Z F YUSTF CDC-MP32
O POWER SUPPLY C 0717 87-010-759-080 0E C-CAP,U 0.1-25 Z F YUSTF CDC-MP32
O POWER SUPPLY C 0718 87-010-759-080 0E C-CAP,U 0.1-25 Z F YUSTF CDC-MP32
O POWER SUPPLY C 0719 87-010-759-080 0E C-CAP,U 0.1-25 Z F YUSTF CDC-MP32
O POWER SUPPLY C 0720 87-010-787-080 0E C-CAP,U 0.022-25 K B YUSTF CDC-MP32
O POWER SUPPLY C 0723 87-010-759-080 0E C-CAP,U 0.1-25 Z F YUSTF CDC-MP32
O POWER SUPPLY C 0725 87-010-553-040 0E CAP,E 47-16 M 5L SRE YUSTF CDC-MP32
S POWER SUPPLY D 0701 87-A40-798-010 0E DIODE,1N5402 (3A/200V) YUSTF CDC-MP32
S POWER SUPPLY D 0706 87-A40-624-080 0E ZENER,MTZJ10A YUSTF CDC-MP32
S POWER SUPPLY D 0707 87-A40-344-080 0E ZENER,MTZJ6.2C YUSTF CDC-MP32
S POWER SUPPLY D 0710 87-A40-624-080 0E ZENER,MTZJ10A YUSTF CDC-MP32
S POWER SUPPLY D 0711 87-017-931-080 0E ZENER,MTZJ5.6B YUSTF CDC-MP32
S POWER SUPPLY D 0712 87-070-136-080 0E ZENER,MTZJ5.1B YUSTF CDC-MP32
S POWER SUPPLY D 0716 87-A40-620-080 0E ZENER,MTZJ6.2A YUSTF CDC-MP32
S POWER SUPPLY D 0717 87-020-331-040 0E C-DIODE,DAN202K YUSTF CDC-MP32
S POWER SUPPLY F 0701 8Z-KC1-621-010 1B FUSE,15A 32V YUSTF CDC-MP32
S POWER SUPPLY IC 0701 88-KT1-606-080 1A IC,PST994D YUSTF CDC-MP32
X POWER SUPPLY JR 0012 88-108-000-080 0E C-JUMPER,U YUSTF CDC-MP32
O POWER SUPPLY L 0403 87-003-102-080 0E COIL,10UH J LAL02 YUSTF CDC-MP32
O POWER SUPPLY L 0701 8B-KCF-615-010 1C FLTR,AMORPHOUS -CHOKE YUSTF CDC-MP32
X POWER SUPPLY L 0703 88-100-000-080 0E PLATING-JW, 0.58 SN95 YUSTF CDC-MP32
S POWER SUPPLY Q 0701 87-A30-290-010 1B TR,KTA1658(Y) YUSTF CDC-MP32
S POWER SUPPLY Q 0702 86-NFZ-664-040 0E C-TR,DTC143TKA YUSTF CDC-MP32
S POWER SUPPLY Q 0704 87-A30-291-010 1B TR,KTC4369(Y) YUSTF CDC-MP32
O POWER SUPPLY Q 0708 89-418-580-080 0E TR,2SD1858TV2 YUSTF CDC-MP32
S POWER SUPPLY Q 0709 87-A30-291-010 1B TR,KTC4369(Y) YUSTF CDC-MP32

– 9 –
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
S POWER SUPPLY Q 0710 89-324-122-040 0E C-TR,2SC2412KR YUSTF CDC-MP32
S POWER SUPPLY Q 0711 87-A30-289-040 0E C-TR,2SA1037AK(Q) YUSTF CDC-MP32
S POWER SUPPLY Q 0712 86-NFZ-664-040 0E C-TR,DTC143TKA YUSTF CDC-MP32
S POWER SUPPLY Q 0713 89-423-952-010 1A TR,2SD2395E YUSTF CDC-MP32
S POWER SUPPLY Q 0715 87-A30-287-040 0E C-TR,DTC114TKA YUSTF CDC-MP32
S POWER SUPPLY Q 0716 87-A30-283-040 0E C-TR,DTA114YKA YUSTF CDC-MP32
X POWER SUPPLY R 0701 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
X POWER SUPPLY R 0702 88-148-681-080 0E C-RES, 680-1/2W J YUSTF CDC-MP32
X POWER SUPPLY R 0703 88-118-391-080 0E C-RES,S 390-1/10W J YUSTF CDC-MP32
X POWER SUPPLY R 0706 88-118-391-080 0E C-RES,S 390-1/10W J YUSTF CDC-MP32
X POWER SUPPLY R 0707 88-108-680-080 0E C-RES,U 68-1/16W J YUSTF CDC-MP32
X POWER SUPPLY R 0708 88-108-682-080 0E C-RES,U 6.8K-1/16W J YUSTF CDC-MP32
X POWER SUPPLY R 0709 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X POWER SUPPLY R 0710 88-118-471-080 0E C-RES,S 470-1/10W J YUSTF CDC-MP32
X POWER SUPPLY R 0711 88-108-273-080 0E C-RES,U 27K-1/16W J YUSTF CDC-MP32
X POWER SUPPLY R 0712 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
X POWER SUPPLY R 0713 88-108-123-080 0E C-RES,U 12K-1/16W J YUSTF CDC-MP32
X POWER SUPPLY R 0714 88-108-563-080 0E C-RES,U 56K-1/16W J YUSTF CDC-MP32
X POWER SUPPLY R 0715 88-108-473-080 0E C-RES,U 47K-1/16W J YUSTF CDC-MP32
X POWER SUPPLY R 0716 88-108-473-080 0E C-RES,U 47K-1/16W J YUSTF CDC-MP32
X POWER SUPPLY R 0718 88-118-222-080 0E C-RES,S 2.2K-1/10W J YUSTF CDC-MP32
X POWER SUPPLY R 0720 88-148-229-080 0E C-RES, 2.2-1/2W J YUSTF CDC-MP32
X POWER SUPPLY R 0722 88-108-563-080 0E C-RES,U 56K-1/16W J YUSTF CDC-MP32
X POWER SUPPLY R 0725 88-118-222-080 0E C-RES,S 2.2K-1/10W J YUSTF CDC-MP32
X PRINTED DU 87-B40-085-010 0E BAG,PV 0.04-200-350 PL YUSTF CDC-MP32
X PRINTED DU 87-B50-055-010 -- IB,YU(3L) MP32 YUSTF CDC-MP32
O PRINTED DU 8B-KCF-902-110 -- IB,INST,YU,YL (3L,P)-I YUSTF CDC-MP32
X PRINTED DU 8B-KCF-904-110 0E SH,CD-R/RW YU,YL,YH,Y (7L)-I YUSTF CDC-MP32
X PRINTED DU 8B-KCF-905-010 0E SH,RC YU,YL(4L) -I YUSTF CDC-MP32
X PRINTED DU 8B-KCF-909-010 0E SH,DEMO (14L)-I YUSTF CDC-MP32
X PRINTED DU 8B-KCF-914-010 0E SH,MFP (14L)-I YUSTF CDC-MP32
X PWB 8B-KC7-601-010 2M PWB,COMB MAIN (BKC-1/7) YUSTF CDC-MP32
X PWB 8B-KC7-602-010 -- PWB,MAIN YUSTF CDC-MP32
X PWB 8B-KC7-603-010 -- PWB,LED YUSTF CDC-MP32
X PWB 8B-KC7-614-010 -- PWB,LED R YUSTF CDC-MP32
X PWB * 8B-KC7-606-010 1E PWB,COMB 3M FRONT (BKC-1/7) YUSTF CDC-MP32
X PWB * 8B-KC7-607-010 -- PWB,DISP YUSTF CDC-MP32
X PWB * 8B-KC7-608-010 -- PWB,KEY YUSTF CDC-MP32
X PWB * 8B-KC7-609-010 -- PWB,AUX YUSTF CDC-MP32
X PWB * 8B-KC7-610-010 -- PWB,SENS YUSTF CDC-MP32
X PWB * 8B-KC7-613-010 -- PWB,LED L YUSTF CDC-MP32
O SCREW 87-251-070-410 0E U+2.6-3 YUSTF CDC-MP32
O SCREW 87-251-073-410 0E U+2.6-6 YUSTF CDC-MP32
O SCREW 87-432-903-010 0E WTE,2.6 YUSTF CDC-MP32
O SCREW 8Z-KC1-251-010 0E S-SCREW,TH2.6-4.0-0.8 YUSTF CDC-MP32
O SCREW * 87-251-096-410 0E U+3-10 YUSTF CDC-MP32
O SCREW * 87-251-096-410 0E U+3-10 YUSTF CDC-MP32
O SCREW * 87-B10-216-010 0E U+2.6-4.0 ZINC BLK (BH M2.6) YUSTF CDC-MP32
O SCREW * 87-B10-216-010 0E U+2.6-4.0 ZINC BLK (BH M2.6) YUSTF CDC-MP32
O SCREW * 87-B10-216-010 0E U+2.6-4.0 ZINC BLK (BH M2.6) YUSTF CDC-MP32
O SCREW * 87-B10-216-010 0E U+2.6-4.0 ZINC BLK (BH M2.6) YUSTF CDC-MP32
O SCREW * 87-B10-216-010 0E U+2.6-4.0 ZINC BLK (BH M2.6) YUSTF CDC-MP32
O SCREW * 87-B10-216-010 0E U+2.6-4.0 ZINC BLK (BH M2.6) YUSTF CDC-MP32
O SCREW * 87-B10-259-010 0E UT2+3.0-10.0 W/O SLOT (BH TAP) YUSTF CDC-MP32
O SCREW * 87-B10-335-010 0E VTT+1.7-4 W/O YUSTF CDC-MP32
O SCREW * 87-B10-335-010 0E VTT+1.7-4 W/O YUSTF CDC-MP32
O SCREW * 87-B10-336-010 0E VTT+2.6-6 W/O YUSTF CDC-MP32
O SCREW * 87-B10-336-010 0E VTT+2.6-6 W/O YUSTF CDC-MP32
O SCREW * 87-B10-336-010 0E VTT+2.6-6 W/O YUSTF CDC-MP32
O SCREW * 8Z-KC1-253-010 0E S-SCREW,PT 2*8 BH+ BLK YUSTF CDC-MP32
O SCREW * 8Z-KC1-253-010 0E S-SCREW,PT 2*8 BH+ BLK YUSTF CDC-MP32
O SCREW * 8Z-KC1-253-010 0E S-SCREW,PT 2*8 BH+ BLK YUSTF CDC-MP32
O SCREW * 8Z-KC1-253-010 0E S-SCREW,PT 2*8 BH+ BLK YUSTF CDC-MP32
O SCREW * 8Z-KC1-254-010 0E S-SCREW,PT 2*5 BH+ BLK YUSTF CDC-MP32
O SCREW * 8Z-KC1-254-010 0E S-SCREW,PT 2*5 BH+ BLK YUSTF CDC-MP32
X TUNER 8Z-KC1-614-010 0E WIRE,ANT YUSTF CDC-MP32
O TUNER C 0101 87-012-274-080 0E C-CAP,U 1000P-50 K B YUSTF CDC-MP32
O TUNER C 0102 87-012-286-080 0E C-CAP,U 0.01-25 K B YUSTF CDC-MP32
O TUNER C 0103 87-012-282-080 0E C-CAP,U 4700P-50 K B YUSTF CDC-MP32
O TUNER C 0104 87-010-498-040 0E CAP,E 10-16 M 5L SRE YUSTF CDC-MP32

– 10 –
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O TUNER C 0105 87-010-787-080 0E C-CAP,U 0.022-25 K B YUSTF CDC-MP32
O TUNER C 0106 87-010-787-080 0E C-CAP,U 0.022-25 K B YUSTF CDC-MP32
O TUNER C 0107 87-012-274-080 0E C-CAP,U 1000P-50 K B YUSTF CDC-MP32
O TUNER C 0108 87-010-787-080 0E C-CAP,U 0.022-25 K B YUSTF CDC-MP32
O TUNER C 0109 87-010-831-080 0E C-CAP,U 0.1-16 Z F YUSTF CDC-MP32
O TUNER C 0110 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM YUSTF CDC-MP32
O TUNER C 0111 87-012-286-080 0E C-CAP,U 0.01-25 K B YUSTF CDC-MP32
O TUNER C 0112 87-010-831-080 0E C-CAP,U 0.1-16 Z F YUSTF CDC-MP32
O TUNER C 0114 87-010-831-080 0E C-CAP,U 0.1-16 Z F YUSTF CDC-MP32
O TUNER C 0115 87-010-831-080 0E C-CAP,U 0.1-16 Z F YUSTF CDC-MP32
O TUNER C 0116 87-010-495-040 0E CAP,E 2.2-50 M 5L SRE YUSTF CDC-MP32
O TUNER C 0117 87-012-286-080 0E C-CAP,U 0.01-25 K B YUSTF CDC-MP32
O TUNER C 0118 87-012-278-080 0E C-CAP,U 2200P-50 K B YUSTF CDC-MP32
O TUNER C 0123 87-012-286-080 0E C-CAP,U 0.01-25 K B YUSTF CDC-MP32
O TUNER C 0125 87-A11-228-080 0E C-CAP,U 0.027-25 K B YUSTF CDC-MP32
O TUNER C 0126 87-A11-228-080 0E C-CAP,U 0.027-25 K B YUSTF CDC-MP32
O TUNER C 0127 87-012-358-080 0E C-CAP,S 0.47-10 Z F CM/CB YUSTF CDC-MP32
O TUNER C 0128 87-012-358-080 0E C-CAP,S 0.47-10 Z F CM/CB YUSTF CDC-MP32
S TUNER D 0101 87-A40-250-040 0E C-DIODE,DAN217 YUSTF CDC-MP32
X TUNER JR 0001 88-108-000-080 0E C-JUMPER,U YUSTF CDC-MP32
X TUNER JR 0003 88-108-000-080 0E C-JUMPER,U YUSTF CDC-MP32
X TUNER JR 0004 88-108-000-080 0E C-JUMPER,U YUSTF CDC-MP32
O TUNER L 0101 87-003-143-080 0E COIL,4.7UH K LAL02 YUSTF CDC-MP32
O TUNER L 0102 8Z-KT1-619-010 1A COIL,68MH K7-D YUSTF CDC-MP32
S TUNER Q 0101 87-A30-287-040 0E C-TR,DTC114TKA YUSTF CDC-MP32
S TUNER Q 0102 87-A30-289-040 0E C-TR,2SA1037AK(Q) YUSTF CDC-MP32
S TUNER Q 0103 89-324-122-040 0E C-TR,2SC2412KR YUSTF CDC-MP32
S TUNER Q 0104 87-A30-287-040 0E C-TR,DTC114TKA YUSTF CDC-MP32
S TUNER Q 0105 89-324-122-040 0E C-TR,2SC2412KR YUSTF CDC-MP32
S TUNER Q 0106 89-324-122-040 0E C-TR,2SC2412KR YUSTF CDC-MP32
X TUNER R 0101 88-108-105-080 0E C-RES,U 1M-1/16W J YUSTF CDC-MP32
X TUNER R 0102 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X TUNER R 0103 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X TUNER R 0104 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
X TUNER R 0105 88-108-222-080 0E C-RES,U 2.2K-1/16W J YUSTF CDC-MP32
X TUNER R 0106 88-108-271-080 0E C-RES,U 270-1/16W J YUSTF CDC-MP32
X TUNER R 0107 88-108-223-080 0E C-RES,U 22K-1/16W J YUSTF CDC-MP32
X TUNER R 0108 88-108-821-080 0E C-RES,U 820-1/16W J YUSTF CDC-MP32
X TUNER R 0109 88-108-103-080 0E C-RES,U 10K-1/16W J YUSTF CDC-MP32
X TUNER R 0110 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X TUNER R 0111 88-108-333-080 0E C-RES,U 33K-1/16W J YUSTF CDC-MP32
X TUNER R 0112 88-108-473-080 0E C-RES,U 47K-1/16W J YUSTF CDC-MP32
X TUNER R 0114 88-118-100-080 0E C-RES,S 10-1/10W J YUSTF CDC-MP32
X TUNER R 0121 88-108-102-080 0E C-RES,U 1K-1/16W J YUSTF CDC-MP32
X TUNER R 0122 88-108-473-080 0E C-RES,U 47K-1/16W J YUSTF CDC-MP32
X TUNER R 0123 88-108-393-080 0E C-RES,U 39K-1/16W J YUSTF CDC-MP32
X TUNER R 0124 88-108-393-080 0E C-RES,U 39K-1/16W J YUSTF CDC-MP32
X TUNER R 0127 88-108-334-080 0E C-RES,U 330K-1/16W J YUSTF CDC-MP32
X TUNER R 0153 88-108-104-080 0E C-RES,U 100K-1/16W J YUSTF CDC-MP32
X TUNER R 0154 88-108-104-080 0E C-RES,U 100K-1/16W J YUSTF CDC-MP32
O TUNER TU 0101 8B-KCF-621-110 2Y TU UNIT, FAE347-A26 YUSTF CDC-MP32

– 11 –
SCHEMATIC DIAGRAM – 1 (MAIN)

– 12 –
SCHEMATIC DIAGRAM – 2 (FRONT)

2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:[phone]
Printed in Singapore9620450
