S E R V I C E M A N U A L

SIMPLE MANUAL

• Replace this Service Manual with ”Revision Publishing” when it is issued.

CT-X429M

• TYPE:

S/M Code No. 09–992–326–50A

STEREO CAR CASSETTE

RECEIVER

HJB,HJW(207)HJB,HJW(207)

YUST,YHJST,

YZST

• BASIC TAPE MECHANISM:CDS-36SCH-94

ELECTRICAL MAIN PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

USTC ...................XX..................................A...................

ZSTC ...................XX...................................B..................

HJSC ...................XX....................................C.................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

C 634 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 704 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 703 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 701 87-010-314-080 C-CAP,S 22P-50V ABC.................

C 702 87-010-315-080 C-CAP,S 27P-50 CH ABC.................

C 705 87-010-490-040 CAP, ELECT 0.1-50 ABC.................

C 751 87-010-178-080 CHIP CAP 1000P ABC.................

C 753 87-010-178-080 CHIP CAP 1000P ABC.................

C 754 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 752 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

D 701 87-020-331-080 CHIP-DIODE,DAN202K ABC.................

D 702 87-027-262-010 LEDE,TLR-124(RED) ABC.................

D 755 87-020-331-080 CHIP-DIODE,DAN202K ABC.................

D 757 87-020-331-080 CHIP-DIODE,DAN202K .B..................

D 752 87-020-331-080 CHIP-DIODE,DAN202K ABC.................

D 754 87-020-331-080 CHIP-DIODE,DAN202K A.C.................

IC 701 87-A21-194-010 C-IC,UPD178016AGC-527-3B9 ABC.................

L 631 87-003-149-080 COIL,47UH ABC.................

Q 703 87-A30-287-040 C-TR,DTC114TKA ABC.................

SW 701 87-A91-155-010 SW,TACT SKHHLQ ABC.................

SW 751 87-A91-152-010 SW,SL 1-1-2 SSSS212-11-A ABC.................

X 701 87-A70-175-010 VIB,XTAL 4.5MHZ AT-49 ABC.................

C 202 87-010-178-080 CHIP CAP 1000P ABC.................

C 201 87-010-178-080 CHIP CAP 1000P ABC.................

C 212 87-010-494-040 CAP,E 1-50 GAS ABC.................

C 211 87-010-494-040 CAP,E 1-50 GAS ABC.................

C 228 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 226 87-010-555-040 CAP,E 100-10 GAS ABC.................

C 238 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 237 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 234 87-010-498-040 CAP,E 10-16 GAS ABC.................

C 233 87-010-498-040 CAP,E 10-16 GAS ABC.................

C 231 87-010-553-040 CAP,E 47-16 GAS ABC.................

C 236 87-010-555-040 CAP,E 100-10 GAS ABC.................

C 235 87-010-555-040 CAP,E 100-10 GAS ABC.................

CNA 253 8Z-KTA-608-010 CONN ASSY,8P DECK-2 ABC.................

CON 251 87-009-031-010 CONNECTOR, 3P ABC.................

CON 253 87-099-408-010 CONN,8P EH V WHT ABC.................

IC 202 87-A21-191-010 IC,KIA6225S ABC.................

Q 232 87-A30-287-040 C-TR,DTC114TKA ABC.................

Q 231 87-A30-295-010 TR,KRA226M ABC.................

C 401 87-010-494-040 CAP,E 1-50 GAS ABC.................

C 402 87-010-494-040 CAP,E 1-50 GAS ABC.................

D 415 87-017-932-080 ZENER,MTJ6.2B ABC.................

D 414 87-017-932-080 ZENER,MTJ6.2B ABC.................

D 417 87-017-932-080 ZENER,MTJ6.2B ABC.................

D 412 87-017-932-080 ZENER,MTJ6.2B ABC.................

D 416 87-017-932-080 ZENER,MTJ6.2B ABC.................

D 413 87-017-932-080 ZENER,MTJ6.2B ABC.................

J 401 8Z-KT1-618-010 JACK,DIN 13 P TCS5116 ABC.................

Q 411 87-A30-283-040 C-TR,DTA114YKA ABC.................

Q 412 87-A30-287-040 C-TR,DTC114TKA ABC.................

C 101 87-010-178-080 CHIP CAP 1000P ABC.................

C 102 87-010-186-080 CAP,CHIP 4700P ABC.................

C 104 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 106 87-010-198-080 CAP, CHIP 0.022 ABC.................

ELECTRICAL MAIN PARTS LIST - 2

C 108 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 103 87-010-490-040 CAP, ELECT 0.1-50 ABC.................

C 105 87-010-495-040 CAP,E 2.2-50 GAS ABC.................

C 107 87-010-552-040 CAP,E 22-16 GAS ABC.................

C 109 87-010-553-040 CAP,E 47-16 GAS ABC.................

C 114 87-010-178-080 CHIP CAP 1000P ABC.................

C 119 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 115 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 111 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 116 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 117 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 110 87-010-553-040 CAP,E 47-16 GAS ABC.................

C 123 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 122 87-010-213-080 C-CAP,S 0.015-50 B ABC.................

C 121 87-010-213-080 C-CAP,S 0.015-50 B ABC.................

C 131 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 132 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 133 87-010-553-040 CAP,E 47-16 GAS ABC.................

C 144 87-010-182-080 C-CAP,S 2200P-50 B .BC.................

C 143 87-010-182-080 C-CAP,S 2200P-50 B .BC.................

C 145 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 146 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 148 87-010-494-040 CAP,E 1-50 GAS ABC.................

C 147 87-010-494-040 CAP,E 1-50 GAS ABC.................

C 141 87-010-498-040 CAP,E 10-16 GAS ABC.................

C 142 87-010-498-040 CAP,E 10-16 GAS ABC.................

D 101 87-020-331-080 CHIP-DIODE,DAN202K ABC.................

D 102 87-020-331-080 CHIP-DIODE,DAN202K ABC.................

D 131 87-070-334-080 ZENER,MTZJ10B ABC.................

J 101 8Z-KT1-614-010 ANT,AW-002 ABC.................

L 101 87-003-143-080 COIL 4.7 UH ABC.................

L 102 8Z-KT1-619-010 COIL,68MH K7-D ABC.................

Q 109 87-A30-287-040 C-TR,DTC114TKA ABC.................

Q 107 87-A30-288-040 C-TR,DTC114YKA ABC.................

Q 105 87-A30-289-040 C-TR,2SA1037AK(R) ABC.................

Q 102 89-324-122-080 TR,2SC2412K ABC.................

Q 101 89-324-122-080 TR,2SC2412K ABC.................

Q 103 89-324-122-080 TR,2SC2412K ABC.................

Q 104 89-324-122-080 TR,2SC2412K ABC.................

Q 106 89-324-122-080 TR,2SC2412K ABC.................

Q 131 87-A30-293-010 TR,KTC2804(Y) ABC.................

TU 101 8Z-KT1-631-010 TU UNIT, FAE347-A02 ABC.................

C 305 87-010-184-080 CHIP CAPACITOR 3300P(K) ABC.................

C 306 87-010-184-080 CHIP CAPACITOR 3300P(K) ABC.................

C 308 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 307 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 301 87-010-494-040 CAP,E 1-50 GAS ABC.................

C 302 87-010-494-040 CAP,E 1-50 GAS ABC.................

C 304 87-010-498-040 CAP,E 10-16 GAS ABC.................

C 309 87-010-498-040 CAP,E 10-16 GAS ABC.................

C 303 87-010-498-040 CAP,E 10-16 GAS ABC.................

C 316 87-010-498-040 CAP,E 10-16 GAS ABC.................

C 315 87-010-498-040 CAP,E 10-16 GAS ABC.................

C 310 87-010-498-040 CAP,E 10-16 GAS ABC.................

C 311 87-A11-177-080 C-CAP,S 0.15-16 K B ABC.................

C 314 87-A11-177-080 C-CAP,S 0.15-16 K B ABC.................

C 312 87-A11-177-080 C-CAP,S 0.15-16 K B ABC.................

C 313 87-A11-177-080 C-CAP,S 0.15-16 K B ABC.................

C 321 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 323 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 324 87-010-552-040 CAP,E 22-16 GAS ABC.................

C 322 87-010-555-040 CAP,E 100-10 GAS ABC.................

C 356 87-010-491-040 CAP,E 0.22-50 GAS ABC.................

C 355 87-010-491-040 CAP,E 0.22-50 GAS ABC.................

ELECTRICAL MAIN PARTS LIST - 3

C 354 87-010-498-040 CAP,E 10-16 GAS ABC.................

C 351 87-010-498-040 CAP,E 10-16 GAS ABC.................

C 353 87-010-498-040 CAP,E 10-16 GAS ABC.................

C 352 87-010-498-040 CAP,E 10-16 GAS ABC.................

C 367 87-010-175-080 CAP 560P ABC.................

C 365 87-010-175-080 CAP 560P ABC.................

C 366 87-010-175-080 CAP 560P ABC.................

C 368 87-010-175-080 CAP 560P ABC.................

C 363 87-010-494-040 CAP,E 1-50 GAS ABC.................

C 361 87-010-494-040 CAP,E 1-50 GAS ABC.................

C 362 87-010-494-040 CAP,E 1-50 GAS ABC.................

C 364 87-010-494-040 CAP,E 1-50 GAS ABC.................

C 551 87-010-553-040 CAP,E 47-16 GAS ABC.................

C 590 87-010-178-080 CHIP CAP 1000P ABC.................

D 551 87-020-331-080 CHIP-DIODE,DAN202K ABC.................

IC 301 8Z-KT1-622-010 C-IC,LC75374E ABC.................

Q 351 87-A30-287-040 C-TR,DTC114TKA ABC.................

Q 352 87-A30-287-040 C-TR,DTC114TKA ABC.................

Q 554 87-A30-281-040 C-TR,DTC363TK ABC.................

Q 552 87-A30-281-040 C-TR,DTC363TK ABC.................

Q 553 87-A30-281-040 C-TR,DTC363TK ABC.................

Q 551 87-A30-281-040 C-TR,DTC363TK ABC.................

Q 559 87-A30-282-040 C-TR,DTA114TKA ABC.................

Q 560 87-A30-287-040 C-TR,DTC114TKA ABC.................

C 501 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 507 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 508 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 502 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 506 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 505 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 503 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 504 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 512 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 513 87-010-498-040 CAP,E 10-16 GAS ABC.................

C 511 8Z-KT1-633-090 CAP,E 3300U-16 PW ABC.................

IC 501 87-A20-876-010 IC,HA13158 ABC.................

* 8Z-KT1-620-010 CONN ASSY,8P ISO-BLACK .B..................

* 8Z-KT1-621-010 CONN ASSY,8P ISO-WHITE .B..................

C 601 87-010-935-040 CAP,E 220-16 M VR ABC.................

C 611 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 612 87-016-459-040 CAP,E 470-10 SMG ABC.................

C 621 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 622 87-010-555-040 CAP,E 100-10 GAS ABC.................

C 631 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 633 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 635 87-010-553-040 CAP,E 47-16 GAS ABC.................

C 632 87-016-039-090 CAP,DL 0.022F-5.5 Z 70 FM ABC.................

C 641 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 653 87-010-555-040 CAP,E 100-10 GAS ABC.................

C 652 87-A11-177-080 C-CAP,S 0.15-16 K B ABC.................

C 651 87-A11-177-080 C-CAP,S 0.15-16 K B ABC.................

C 671 87-010-553-040 CAP,E 47-16 GAS A...................

C 883 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 881 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 882 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

CON 881 8Z-KT1-611-010 CONN,16P CAM-B51 A.C.................

D 611 87-070-334-080 ZENER,MTZJ10B ABC.................

D 621 87-017-931-080 ZENER,MTZJ5.6B ABC.................

D 632 87-001-783-080 DIODE,1N4002 ABC.................

D 631 87-001-783-080 DIODE,1N4002 ABC.................

D 634 87-017-931-080 ZENER,MTZJ5.6B ABC.................

D 633 87-A40-002-080 ZENER,MTZJ5.1C ABC.................

D 635 87-A40-620-080 ZENER,MTZJ6.2A ABC.................

D 641 87-070-136-080 ZENER,MTZJ5.1B ABC.................

ELECTRICAL MAIN PARTS LIST - 4

D 671 87-070-136-080 ZENER,MTZJ5.1B A...................

D 882 87-001-783-080 DIODE,1N4002 ABC.................

D 881 87-001-783-080 DIODE,1N4002 ABC.................

F 881 8Z-KT1-617-010 FUSE,10A 32V A.C.................

IC 641 88-KT1-606-080 IC,PST994D ABC.................

IC 651 88-KTD-604-010 IC,BA09T ABC.................

L 881 8Z-KT1-615-010 FLTR,AMORPHOUS -CHOKE ABC.................

Q 604 87-A30-287-040 C-TR,DTC114TKA ABC.................

Q 603 87-A30-287-040 C-TR,DTC114TKA ABC.................

Q 601 87-A30-290-010 TR,KTA1658(Y) ABC.................

Q 602 87-A30-290-010 TR,KTA1658(Y) ABC.................

Q 611 87-A30-291-010 TR,KTC4369(Y) ABC.................

Q 621 87-A30-292-010 TR,KTC3205(Y) ABC.................

Q 632 87-A30-287-040 C-TR,DTC114TKA ABC.................

Q 633 87-A30-287-040 C-TR,DTC114TKA ABC.................

Q 631 87-A30-292-010 TR,KTC3205(Y) ABC.................

R 605 88-148-102-080 C-RES, 1K-1/2W J ABC.................

C 862 87-010-494-040 CAP,E 1-50 GAS ABC.................

C 861 87-010-494-040 CAP,E 1-50 GAS ABC.................

D 855 87-017-932-080 ZENER,MTJ6.2B ABC.................

D 854 87-017-932-080 ZENER,MTJ6.2B ABC.................

D 853 87-017-932-080 ZENER,MTJ6.2B A...................

D 857 87-017-932-080 ZENER,MTJ6.2B ABC.................

D 851 87-017-932-080 ZENER,MTJ6.2B ABC.................

D 856 87-017-932-080 ZENER,MTJ6.2B ABC.................

D 852 87-017-932-080 ZENER,MTJ6.2B ABC.................

C 451 87-010-498-040 CAP,E 10-16 GAS A.C.................

C 453 87-010-498-040 CAP,E 10-16 GAS ABC.................

C 454 87-010-498-040 CAP,E 10-16 GAS ABC.................

C 452 87-010-498-040 CAP,E 10-16 GAS A.C.................

C 457 87-012-140-080 CAP 470P ABC.................

C 458 87-012-140-080 CAP 470P ABC.................

C 456 87-012-140-080 CAP 470P A.C.................

C 455 87-012-140-080 CAP 470P A.C.................

J 451 88-KTA-604-010 JACK,PIN 4P V-TYPE A.C.................

J 451 88-KTA-605-010 JACK,PIN 2P V-TYPE .B..................

C 901 87-010-176-080 C-CAP,S 680P-50 SL ABC.................

C 903 87-010-194-080 CAP, CHIP 0.047 ABC.................

C 902 87-010-194-080 CAP, CHIP 0.047 ABC.................

C 904 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 906 87-010-805-080 CAP, S 1-16 ABC.................

C 905 87-010-805-080 CAP, S 1-16 ABC.................

D 902 87-020-585-080 CHIP-ZENER,02CZ6.2Y ABC.................

D 907 87-020-585-080 CHIP-ZENER,02CZ6.2Y .BC.................

D 906 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................

D 904 87-020-585-080 CHIP-ZENER,02CZ6.2Y ABC.................

D 903 87-020-585-080 CHIP-ZENER,02CZ6.2Y ABC.................

D 901 87-020-585-080 CHIP-ZENER,02CZ6.2Y ABC.................

IC 902 87-A90-951-010 RCR UNIT,SBX1971-52 A...................

IC 901 88-KT1-608-010 C-IC,LC75854W ABC.................

J 901 87-A60-249-010 JACK,MOJ-B32 ABC.................

LCD 901 8Z-KTA-606-010 LCD,ZKT-10COLOR ABC.................

PL 907 8Z-KT1-641-010 LAMP,T-3 ABC.................

PL 902 8Z-KT1-641-010 LAMP,T-3 ABC.................

PL 904 8Z-KT1-641-010 LAMP,T-3 ABC.................

PL 901 8Z-KT1-641-010 LAMP,T-3 ABC.................

PL 905 8Z-KT1-641-010 LAMP,T-3 ABC.................

PL 906 8Z-KT1-641-010 LAMP,T-3 ABC.................

PL 903 8Z-KT1-641-010 LAMP,T-3 ABC.................

S 901 87-A90-001-080 C-SW,TACT SKQMAL ABC.................

S 906 87-A91-159-010 SW,TACT SKHLAD ABC.................

S 909 87-A91-159-010 SW,TACT SKHLAD ABC.................

S 908 87-A91-159-010 SW,TACT SKHLAD ABC.................

S 904 87-A91-159-010 SW,TACT SKHLAD ABC.................

S 903 87-A91-159-010 SW,TACT SKHLAD ABC.................

S 902 87-A91-159-010 SW,TACT SKHLAD ABC.................

S 907 87-A91-159-010 SW,TACT SKHLAD ABC.................

S 905 87-A91-159-010 SW,TACT SKHLAD ABC.................

S 919 87-A90-001-080 C-SW,TACT SKQMAL ABC.................

S 910 87-A90-001-080 C-SW,TACT SKQMAL ABC.................

S 918 87-A90-001-080 C-SW,TACT SKQMAL ABC.................

S 917 87-A91-159-010 SW,TACT SKHLAD ABC.................

S 911 87-A91-159-010 SW,TACT SKHLAD ABC.................

S 913 87-A91-159-010 SW,TACT SKHLAD ABC.................

S 916 87-A91-159-010 SW,TACT SKHLAD ABC.................

S 914 87-A91-159-010 SW,TACT SKHLAD ABC.................

S 915 87-A91-159-010 SW,TACT SKHLAD ABC.................

S 912 87-A91-159-010 SW,TACT SKHLAD ABC.................

S 920 87-A90-001-080 C-SW,TACT SKQMAL ABC.................

S 921 87-A91-159-010 SW,TACT SKHLAD ABC.................

ELECTRICAL MAIN PARTS LIST - 5

MECHANICAL PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

USTC ...................XX..................................A...................

ZSTC ...................XX...................................B..................

HJSC ...................XX....................................C.................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-KT1-023-010 DOOR,CASS ABC.................

8Z-KTA-002-010 CABI,REAR -T10 ABC.................

8Z-KTA-011-010 CABI,BASE -T10 ABC.................

8Z-KTA-012-010 CABI,TRIM -T10 ABC.................

8Z-KTA-013-010 RING,OVAL TD -T ABC.................

8Z-KTF-001-010 WINDOW,LCD X429M IR A...................

8Z-KTF-002-010 WINDOW,LCD X4029M ....................

8Z-KTF-004-010 CABI,FRONT -T15 ABC.................

8Z-KTF-005-010 WINDOW,LCD X429M .BC.................

8Z-KT1-007-010 BTN,+/- -T ABC.................

8Z-KT1-008-010 BTN,SEL -T ABC.................

8Z-KT1-009-010 BTN,MUTE -T ABC.................

8Z-KT1-010-010 BTN,H-BASS -T ABC.................

8Z-KT1-011-010 BTN,U/D -T ABC.................

8Z-KT1-012-010 BTN,DRV -T ABC.................

8Z-KT3-002-010 BTN,P.SET -T3 ABC.................

8Z-KT5-019-010 BTN,M.INF -T ABC.................

8Z-KTA-005-010 BTN,EJ -T10 ABC.................

8Z-KTA-006-010 BTN,FF -T10 ABC.................

8Z-KTA-007-010 BTN,REW -T10 ABC.................

8Z-KTA-008-010 BTN,DETACH -T10 ABC.................

8Z-KTA-009-010 BTN,TWIN C/T -T ABC.................

8Z-KTF-003-010 BTN,TETRA BALD -T ABC.................

87-KTE-205-010 SPR-C,EJ/FF/REW ABC.................

8Z-KT1-209-010 LENS,IR -T A...................

8Z-KT1-211-010 COVER, TOP -T ABC.................

8Z-KT1-212-010 COVER, BOTTOM -T ABC.................

8Z-KT1-215-010 HLDR,P-IC -T ABC.................

8Z-KT1-218-010 HLDR,CD -T ABC.................

8Z-KT1-219-010 HLDR,TR -T ABC.................

8Z-KT1-220-010 HLDR,JACK F -T A.C.................

8Z-KT1-235-010 COVER, CONN.BLIND -T .B..................

8Z-KT1-236-010 CAP,LAMP BLU ABC.................

8Z-KT1-237-010 CAP,LAMP GRN ABC.................

8Z-KT1-244-010 SPR-T,DOOR Z ABC.................

8Z-KT1-255-010 HLDR,TR -TA ABC.................

8Z-KT1-257-010 HLDR,ISO-WIRE -T .B..................

8Z-KT5-020-010 HLDR,M.INF -T ABC.................

8Z-KT5-201-010 COVER, ISO BLIND -T A.C.................

8Z-KTA-202-010 HLDR,DECK CDS36 ABC.................

8Z-KTA-203-010 LEVER,DFP LOCK -T10 ABC.................

8Z-KTA-204-010 LEVER,DEF HOOK -T10 ABC.................

8Z-KTA-205-010 HLDR,JACK -T10 .B..................

8Z-KTA-210-010 HLDR,LCD -T10 ABC.................

8Z-KTA-211-010 CASE,LCD LENS -T10 ABC.................

8Z-KTA-212-010 LENS,LCD -T10 ABC.................

8Z-KTA-213-010 LENS,L -T10 ABC.................

8Z-KTA-214-010 LENS,R -T10 ABC.................

8Z-KTA-221-010 SPR-C,DETACH LOCK-T10 ABC.................

8Z-KTA-222-010 SPR-T,DETACH LOCK-T10 ABC.................

8Z-KTA-223-010 SPR-C,RELEASE -T10 ABC.................

87-251-073-410 SCREW,U+2.6-6 ABC.................

87-251-075-410 U+2.6-10 ABC.................

87-251-096-410 U+3-10 ABC.................

87-B10-210-010 UT2+3.0-6.0 W/0 SLOT (BH TAP) ABC.................

88-KT1-250-010 S-SCREW,THIN HEAD+2.6-4 BLK ABC.................

MECHANICAL PARTS LIST - 2

8Z-KT1-253-010 S-SCREW,PT 2*8 BH+ BLK ABC.................

8Z-KT1-254-010 S-SCREW,PT 2*5 BH+ BLK ABC.................

ACCESSORIES LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

USTC ...................XX..................................A...................

ZSTC ...................XX...................................B..................

HJSC ...................XX....................................C.................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-KTF-901-010 IB,YU(3L) 429M A...................

8Z-KTF-902-010 IB,INST,YU (3L)429M A...................

8Z-KTF-904-010 IB,YL(3L) 4029M ....................

8Z-KTF-905-010 IB,INST,YL (3L)4029M ....................

8Z-KTF-906-010 IB,YZ(9L) 429M .B..................

8Z-KTF-907-010 IB,INST,YZ (6L)429M .B..................

8Z-KTF-908-010 IB,INST,YZ (CZ-PO-H)429M .B..................

8Z-KTF-909-010 IB,YH(E CK) 429M ..C.................

8Z-KTF-910-010 IB,INST,YH (E CK)429M ..C.................

86-KT1-237-010 HLDR,REAR MTG ABC.................

87-B10-141-010 NUT,5 TYPE-2 ABC.................

87-B10-144-010 W,5.2-10-0.5 ABC.................

87-B10-145-010 W-SPR,5.3-8.5-1.5 ABC.................

88-KT1-250-010 S-SCREW,THIN HEAD+2.6-4 BLK ABC.................

8Z-KT1-030-010 CASE,DFP -T ABC.................

8Z-KT1-231-010 HLDR,HALF -T ABC.................

8Z-KT1-232-010 KEY,REMOVE -T ABC.................

* 87-B10-143-010 UT1+5-15 W/O SLOT ABC.................

* 88-KT1-247-010 S-SCREW,HEXAGON ABC.................

* 8Z-KT1-251-010 S-SCREW,5*6 TH+ TAPPING ST ABC.................

* 8Z-KT1-616-010 CONN ASSY,16P B52 A.C.................

Printed in Singapore

Tokyo Japan

737004

Table of contents

Popular Car Receiver manuals by other brands

Linear Series

Linear Series LS5050 Operation and installation manual

Kenwood

Kenwood KRC-160 instruction manual

Sony

Sony XR-CA430X Service manual

T+A Elektroakustik

T+A Elektroakustik K1 CD-RECEIVER operating instructions

SoundMax

SoundMax SM-CDM1052 instruction manual

Xtrons

Xtrons HD107HD user manual

Mopar

Mopar RB3 manual

Clarion

Clarion ADDZEST DMZ615 owner's manual

Sony

Sony XAV-601BT Specifications

PIE

PIE GM12-POD/S Operation manual

Hyundai

Hyundai H-910H instruction manual

Sony

Sony XR-C6100 Service manual

Sony

Sony CDX-L600X - Fm/am Compact Disc Player Installation/connections

Motorola

Motorola VWA63 Service manual

Sound Storm

Sound Storm STM93R user manual

Nextar

Nextar D3201 instruction manual

Alpine

Alpine CDE-163BT owner's manual

Kenwood

Kenwood KDC-X303 quick start guide

Aiwa CT-X429M User manual

Popular Car Receiver manuals by other brands
