SERVICE MANUAL
CDC-R227
YZ(S)
STEREO CAR CD STEREO
S/M Code No. 09-026-458-8T1
BASIC CD MECHANISM : BZG-3 BNF

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-2-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
ACCESSORIES PARTS LIST -1/1
CDC-R227
YZSF
O AS1001 87-253-033-410 U+2-4 BLK a
O AS1002 87-B10-141-010 NUT,5 TYPE-2 a
O AS1003 87-B10-143-010 UT1+5-15 W/O SLOT a
O AS1004 87-B10-144-010 W,5.2-10-0.5 a
O AS1005 87-B10-145-010 W-SPR,5.3-8.5-1.5 a
X AS1006 87-B40-178-010 BAG,PV 0.04-100-250 a
X AS1007 87-B40-179-010 BAG,PV 0.04-50-100 a
X AS1008 87-B40-242-010 BAG,PV 0.04-70-100 a
O AS1009 8C-KCG-060-110 CASE,DFP C BLK a
X AS1010 8C-KCG-233-010 CUSHION,DFP-CASE a
O AS1011 8Z-KC1-231-110 HLDR,HALF -C a
O AS1012 8Z-KC1-232-010 KEY,REMOVE -C a
O AS1013 8Z-KC1-235-010 HLDR,REAR MTG a
O AS1014 8Z-KC1-244-010 S-SCREW,5*6 TH+ TAPPING ST a
O AS1015 8Z-KC1-250-010 S-SCREW,HEXAGON a
X AS1016 87-B40-087-010 BAG,PV 0.04-250-350 PL a
X AS1017 8C-KCA-851-010 CTN,PRINTED 227 YZSF a
X AS1018 8C-KCA-852-010 CTN,OUTER 227 YZSF a
X AS1019 8C-KCF-851-010 CUSHION,LEFT AIS a
X AS1020 8C-KCF-852-010 CUSHION,RIGHT AIS a
CDC-R227
YZSF
X AS1021 8C-KCF-854-010 PAD,A a
X AS1022 8Z-KC1-871-010 CUSHION,DFP-GUARD a
X AS1023 87-056-168-010 SH,CAUTION INF-WARR(EC) a
X AS1024 87-B40-454-010 BAG,PP 0.04-230-350 PL a
X AS1025 87-B50-079-010 LIST,FACILITY(B)-0007 a
X AS1026 8B-KCF-907-110 SH,CD-R/RW YZ,YV (9L,R)-I a
X AS1027 8C-KC4-920-010 SH,STOPPER (14L)F a
O AS1028 8C-KCA-901-010 IB,YZ (9L)F R227 a
X AS1029 8C-KCA-907-010 SH,DEMO YZ(9L)F R227 a
X AS1030 8C-KCG-906-010 SH,SCREW DFP (14L)F a
O AS1031 8C-KCG-913-010 IB,INST YZ,YV (9L,R)F a

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-3-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
ELECTRICAL PARTS LIST -1/9
CDC-R227
YZSF
CD O C 0201 87-010-552-040 CAP,E 22-16 M 5L SRE a
CD O C 0202 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
CD O C 0203 87-A10-189-040 CAP,E 220-10 M 5L a
CD O C 0221 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
CD O C 0222 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
CD O C 0223 87-012-337-080 C-CAP,U 56P-50 J CH GRM a
CD O C 0224 87-012-162-080 C-CAP,U 1P-50 C CH GRM a
CD O C 0225 87-A10-260-080 C-CAP,U 0.1-16 K B a
CD O C 0226 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0227 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
CD O C 0228 87-A10-260-080 C-CAP,U 0.1-16 K B a
CD O C 0229 87-A10-353-080 C-CAP,U 0.22-10 K B a
CD O C 0230 87-A10-353-080 C-CAP,U 0.22-10 K B a
CD O C 0232 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
CD O C 0233 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0234 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0235 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0237 87-012-285-080 C-CAP,U 8200P-50 K B GRM a
CD O C 0241 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0242 87-010-555-040 CAP,E 100-10 M 5L SRE a
CDC-R227
YZSF
CD O C 0245 87-012-270-080 C-CAP,U 470P-50 K B GRM a
CD O C 0246 87-012-270-080 C-CAP,U 470P-50 K B GRM a
CD O C 0247 87-A10-504-080 C-CAP,U 0.047-16 K B a
CD O C 0248 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
CD O C 0250 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0251 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0252 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
CD O C 0253 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
CD O C 0254 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
CD O C 0258 87-A10-504-080 C-CAP,U 0.047-16 K B a
CD O C 0259 87-A10-504-080 C-CAP,U 0.047-16 K B a
CD O C 0260 87-A10-504-080 C-CAP,U 0.047-16 K B a
CD O C 0261 87-012-282-080 C-CAP,U 4700P-50 K B GRM a
CD O C 0262 87-012-279-080 C-CAP,U 2700P-50 K B GRM a
CD O C 0263 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
CD O C 0264 87-010-785-080 C-CAP,U 0.015-25 K B GRM a
CD O C 0265 87-010-553-040 CAP,E 47-16 M 5L SRE a
CD O C 0268 87-012-188-080 C-CAP,U 47P-50 J CH GRM a
CD O C 0269 87-010-553-040 CAP,E 47-16 M 5L SRE a
CD O C 0270 87-010-553-040 CAP,E 47-16 M 5L SRE a
CDC-R227
YZSF
CD O C 0271 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
CD O C 0272 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
CD O C 0273 87-012-199-080 C-CAP,U 220P-50 J CH GRM a
CD O C 0274 87-012-199-080 C-CAP,U 220P-50 J CH GRM a
CD O C 0276 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0278 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0279 87-A10-260-080 C-CAP,U 0.1-16 K B a
CD O C 0281 87-012-275-080 C-CAP,U 1200P-50 K B GRM a
CD O C 0282 87-012-275-080 C-CAP,U 1200P-50 K B GRM a
CD O C 0283 87-010-498-040 CAP,E 10-16 M 5L SRE a
CD O C 0284 87-010-498-040 CAP,E 10-16 M 5L SRE a
CD O C 0298 87-010-555-040 CAP,E 100-10 M 5L SRE a
CD O C 0299 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
CD O CON0201 87-A61-220-080 C-CONN,20P H 52271-2090 a
CD S IC 0201 87-A22-080-040 C-IC,LA6557H a
CD S IC 0221 87-A22-081-040 C-IC,TA2153FN a
CD S IC 0241 8C-ZA5-611-030 C-IC,TC94A09F-301 a
CD X JR 0102 88-108-000-080 C-JUMPER,U a
CD X JR 0201 88-108-000-080 C-JUMPER,U a
CD X JR 0203 88-108-000-080 C-JUMPER,U a
CDC-R227
YZSF
CD O L 0221 87-003-102-080 COIL,10UH J LAL02 a
CD O L 0241 87-003-143-080 COIL,4.7UH K LAL02 a
CD O L 0242 87-003-143-080 COIL,4.7UH K LAL02 a
CD S Q 0201 87-A30-299-080 TR,2SB1326 a
CD S Q 0202 87-A30-287-040 C-TR,DTC114TKA a
CD S Q 0221 87-A30-289-040 C-TR,2SA1037AK(Q) a
CD X R 0201 88-108-000-080 C-JUMPER,U a
CD X R 0202 88-108-683-080 C-RES,U 68K-1/16W J a
CD O R 0203 88-108-822-080 C-RES,U 8.2K-1/16W J a
CD O R 0204 88-108-822-080 C-RES,U 8.2K-1/16W J a
CD X R 0205 88-108-000-080 C-JUMPER,U a
CD X R 0206 88-108-561-080 C-RES,U 560-1/16W J a
CD X R 0207 88-108-000-080 C-JUMPER,U a
CD O R 0208 88-108-101-080 C-RES,U 100-1/16W J a
CD O R 0209 88-108-562-080 C-RES,U 5.6K-1/16W J a
CD X R 0210 88-108-000-080 C-JUMPER,U a
CD X R 0211 88-108-820-080 C-RES,U 82-1/16W J a
CD X R 0212 88-108-393-080 C-RES,U 39K-1/16W J a
CD X R 0213 88-108-000-080 C-JUMPER,U a
CD X R 0214 88-108-000-080 C-JUMPER,U a

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-4-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
CDC-R227
YZSF
CD X R 0215 88-108-154-080 C-RES,U 150K-1/16W J a
CD O R 0221 88-108-102-080 C-RES,U 1K-1/16W J a
CD X R 0222 88-108-683-080 C-RES,U 68K-1/16W J a
CD O R 0223 88-108-473-080 C-RES,U 47K-1/16W J a
CD X R 0224 88-108-222-080 C-RES,U 2.2K-1/16W J a
CD X R 0225 88-108-221-080 C-RES,U 220-1/16W J a
CD X R 0226 88-108-000-080 C-JUMPER,U a
CD X R 0227 88-108-104-080 C-RES,U 100K-1/16W J a
CD O R 0228 88-108-103-080 C-RES,U 10K-1/16W J a
CD O R 0229 88-108-103-080 C-RES,U 10K-1/16W J a
CD O R 0230 88-108-103-080 C-RES,U 10K-1/16W J a
CD O R 0231 88-108-563-080 C-RES,U 56K-1/16W J a
CD O R 0232 88-108-563-080 C-RES,U 56K-1/16W J a
CD O R 0233 88-108-563-080 C-RES,U 56K-1/16W J a
CD O R 0234 88-108-563-080 C-RES,U 56K-1/16W J a
CD X R 0235 88-108-273-080 C-RES,U 27K-1/16W J a
CD X R 0236 88-108-273-080 C-RES,U 27K-1/16W J a
CD X R 0237 88-108-683-080 C-RES,U 68K-1/16W J a
CD O R 0238 88-108-102-080 C-RES,U 1K-1/16W J a
CD X R 0239 88-108-000-080 C-JUMPER,U a
CDC-R227
YZSF
CD X R 0240 88-118-100-080 C-RES,S 10-1/10W J a
CD O R 0241 88-108-101-080 C-RES,U 100-1/16W J a
CD X R 0243 88-108-000-080 C-JUMPER,U a
CD X R 0244 88-108-333-080 C-RES,U 33K-1/16W J a
CD X R 0245 88-108-474-080 C-RES,U 470K-1/16W J a
CD O R 0246 88-108-473-080 C-RES,U 47K-1/16W J a
CD O R 0247 88-108-103-080 C-RES,U 10K-1/16W J a
CD O R 0249 88-108-102-080 C-RES,U 1K-1/16W J a
CD O R 0250 88-108-102-080 C-RES,U 1K-1/16W J a
CD X R 0251 88-108-000-080 C-JUMPER,U a
CD O R 0253 88-108-103-080 C-RES,U 10K-1/16W J a
CD X R 0254 88-108-474-080 C-RES,U 470K-1/16W J a
CD X R 0255 88-108-474-080 C-RES,U 470K-1/16W J a
CD X R 0256 88-108-104-080 C-RES,U 100K-1/16W J a
CD X R 0281 88-108-222-080 C-RES,U 2.2K-1/16W J a
CD X R 0282 88-108-222-080 C-RES,U 2.2K-1/16W J a
CD X R 0298 88-108-472-080 C-RES,U 4.7K-1/16W J a
CD X R 0299 88-108-472-080 C-RES,U 4.7K-1/16W J a
CD O X 0241 87-A70-376-080 VIB,CER 16.934MHZ CSTLS16M9X55 a
CONNECTION O C 0702 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
CDC-R227
YZSF
CONNECTION O C 0703 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
CONNECTION O C 0705 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
CONNECTION O C 0706 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
CONNECTION O C 0707 87-010-495-040 CAP,E 2.2-50 M 5L SRE a
CONNECTION O C 0708 87-010-495-040 CAP,E 2.2-50 M 5L SRE a
CONNECTION O C 0709 87-010-805-080 C-CAP,S 1-16 Z F GRM a
CONNECTION O C 0710 87-010-805-080 C-CAP,S 1-16 Z F GRM a
CONNECTION O C 0731 87-010-498-040 CAP,E 10-16 M 5L SRE a
CONNECTION O CON0701 87-A61-219-010 CONN,20P H 52089-2020 a
CONNECTION O CON0702 88-KTA-603-010 CONN,15P CAM-B68 a
CONNECTION S D 0705 87-A40-337-080 ZENER,MTZJ6.8B a
CONNECTION S D 0706 87-A40-337-080 ZENER,MTZJ6.8B a
CONNECTION S D 0707 87-A40-337-080 ZENER,MTZJ6.8B a
CONNECTION S D 0708 87-A40-337-080 ZENER,MTZJ6.8B a
CONNECTION S D 0709 87-A40-337-080 ZENER,MTZJ6.8B a
CONNECTION S D 0710 87-A40-337-080 ZENER,MTZJ6.8B a
CONNECTION S D 0711 87-A40-337-080 ZENER,MTZJ6.8B a
CONNECTION S D 0712 87-A40-337-080 ZENER,MTZJ6.8B a
CONNECTION S D 0713 87-A40-337-080 ZENER,MTZJ6.8B a
CONNECTION S D 0777 87-020-331-040 C-DIODE,DAN202K a
CDC-R227
YZSF
CONNECTION X JR 0101 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0102 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0103 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0104 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0105 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0106 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0108 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0109 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0110 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0111 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0113 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0114 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0115 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0116 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0117 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0118 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0120 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0127 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0129 88-118-000-080 C-JUMPER,S a
CONNECTION X JR 0501 88-129-000-080 C-JUMPER, 3216 a
ELECTRICAL PARTS LIST -2/9

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-5-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
CDC-R227
YZSF
CONNECTION X JR 0502 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0503 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0504 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0505 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0506 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0508 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0509 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0510 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0511 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0512 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0513 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0514 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0515 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0516 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0517 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0518 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0520 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0521 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0522 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0523 88-129-000-080 C-JUMPER, 3216 a
CDC-R227
YZSF
CONNECTION X JR 0529 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JR 0530 88-129-000-080 C-JUMPER, 3216 a
CONNECTION X JW 0102 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0103 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0104 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0105 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0106 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0107 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0108 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0110 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0111 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0113 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0114 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0115 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0116 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0117 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0118 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0119 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0120 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0121 88-100-000-010 PLATING-JW, 0.58 SN95 a
CDC-R227
YZSF
CONNECTION X JW 0122 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0123 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0124 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0125 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0126 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0127 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0128 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0129 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0130 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0131 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0132 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0133 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0134 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0135 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0136 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0137 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0138 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0139 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0140 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0141 88-100-000-010 PLATING-JW, 0.58 SN95 a
CDC-R227
YZSF
CONNECTION X JW 0142 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0143 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0144 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0145 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0146 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0147 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0148 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0149 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0150 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0151 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0152 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0153 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0154 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0155 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0156 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0157 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0158 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0159 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0160 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0161 88-100-000-010 PLATING-JW, 0.58 SN95 a
ELECTRICAL PARTS LIST -3/9

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-6-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
CDC-R227
YZSF
CONNECTION X JW 0162 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0163 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0164 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0165 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0166 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0167 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0168 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0169 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0170 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0171 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0172 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0173 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0174 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0175 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0176 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0177 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0178 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0179 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0180 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0181 88-100-000-010 PLATING-JW, 0.58 SN95 a
CDC-R227
YZSF
CONNECTION X JW 0182 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0183 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0184 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0185 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0186 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0187 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0188 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0189 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0190 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0191 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0192 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0193 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0194 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0195 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0196 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0197 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0198 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0199 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0200 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0201 88-100-000-010 PLATING-JW, 0.58 SN95 a
CDC-R227
YZSF
CONNECTION X JW 0203 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0204 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0205 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0206 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0207 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0208 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0209 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0210 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0211 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0212 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0213 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0214 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0215 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0216 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0217 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0218 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0220 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0223 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0225 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0226 88-100-000-010 PLATING-JW, 0.58 SN95 a
CDC-R227
YZSF
CONNECTION X JW 0229 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0230 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0231 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0232 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0233 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0234 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0236 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0237 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0238 88-100-000-010 PLATING-JW, 0.58 SN95 a
CONNECTION X JW 0239 88-121-560-080 RES,56-1/8W J a
CONNECTION O L 0701 87-005-906-080 C-COIL,S 10UH K LK2125 a
CONNECTION O L 0702 87-003-102-080 COIL,10UH J LAL02 a
CONNECTION X R 0125 88-118-000-080 C-JUMPER,S a
CONNECTION X R 0129 88-118-000-080 C-JUMPER,S a
CONNECTION X R 0713 88-108-472-080 C-RES,U 4.7K-1/16W J a
CONNECTION X R 0714 88-108-472-080 C-RES,U 4.7K-1/16W J a
CONNECTION O R 0715 88-108-562-080 C-RES,U 5.6K-1/16W J a
CONNECTION O R 0716 88-108-562-080 C-RES,U 5.6K-1/16W J a
CONNECTION O R 0717 88-108-102-080 C-RES,U 1K-1/16W J a
CONNECTION O R 0719 88-108-102-080 C-RES,U 1K-1/16W J a
ELECTRICAL PARTS LIST -4/9

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-7-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
CDC-R227
YZSF
CONNECTION O R 0721 88-108-102-080 C-RES,U 1K-1/16W J a
CONNECTION O R 0722 88-108-102-080 C-RES,U 1K-1/16W J a
CONNECTION O R 0723 88-108-102-080 C-RES,U 1K-1/16W J a
CONNECTION O R 0724 88-108-102-080 C-RES,U 1K-1/16W J a
CONNECTION O R 0725 88-108-102-080 C-RES,U 1K-1/16W J a
CONNECTION O R 0726 88-108-102-080 C-RES,U 1K-1/16W J a
CONNECTION O R 0727 88-108-562-080 C-RES,U 5.6K-1/16W J a
CONNECTION O R 0728 88-108-562-080 C-RES,U 5.6K-1/16W J a
CONNECTION X R 0729 88-108-472-080 C-RES,U 4.7K-1/16W J a
CONNECTION X R 0730 88-128-472-080 C-RES, 4.7K-1/8W J a
CONNECTION O R 0731 88-108-223-080 C-RES,U 22K-1/16W J a
ELECTRICAL O C 0601 87-A10-047-080 C-CAP,U 1-10 Z F a
ELECTRICAL O C 0602 87-A10-504-080 C-CAP,U 0.047-16 K B a
ELECTRICAL O C 0603 87-A10-504-080 C-CAP,U 0.047-16 K B a
ELECTRICAL O C 0604 87-012-273-080 C-CAP,U 820P-50 K B GRM a
ELECTRICAL O C 0605 87-A10-260-080 C-CAP,U 0.1-16 K B a
ELECTRICAL O C 0621 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
ELECTRICAL O C 0622 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
ELECTRICAL O CON0601 88-KTA-602-010 C-CONN,15P CAM-B67 a
ELECTRICAL S D 0601 87-A40-817-040 C-ZENER,STZ6.8N a
CDC-R227
YZSF
ELECTRICAL S D 0602 87-A40-817-040 C-ZENER,STZ6.8N a
ELECTRICAL S IC 0601 88-KT1-608-010 C-IC,LC75854W a
ELECTRICAL O J 0601 85-HRL-623-010 JACK,3.5 BLK ST BLK a
ELECTRICAL O LCD0601 8C-KCA-620-010 LCD,CKC-A a
ELECTRICAL O LED0641 87-A91-355-040 C-LED,BR1112H-TR-RED a
ELECTRICAL O LED0642 87-A91-355-040 C-LED,BR1112H-TR-RED a
ELECTRICAL O LED0643 87-A91-355-040 C-LED,BR1112H-TR-RED a
ELECTRICAL O LED0651 87-A91-355-040 C-LED,BR1112H-TR-RED a
ELECTRICAL O LED0652 87-A91-355-040 C-LED,BR1112H-TR-RED a
ELECTRICAL O LED0653 87-A91-355-040 C-LED,BR1112H-TR-RED a
ELECTRICAL O LED0661 87-A41-085-010 LED,NSPW315BS WHT a
ELECTRICAL O LED0671 87-A41-118-040 C-LED,SEC1E01C-1 BLU a
ELECTRICAL O LED0672 87-A41-118-040 C-LED,SEC1E01C-1 BLU a
ELECTRICAL O LED0673 87-A41-118-040 C-LED,SEC1E01C-1 BLU a
ELECTRICAL S Q 0651 89-324-122-040 C-TR,2SC2412KR a
ELECTRICAL S Q 0661 89-324-122-040 C-TR,2SC2412KR a
ELECTRICAL S Q 0671 89-324-122-040 C-TR,2SC2412KR a
ELECTRICAL O R 0601 88-108-103-080 C-RES,U 10K-1/16W J a
ELECTRICAL O R 0602 88-108-103-080 C-RES,U 10K-1/16W J a
ELECTRICAL O R 0603 88-108-103-080 C-RES,U 10K-1/16W J a
CDC-R227
YZSF
ELECTRICAL X R 0604 88-108-683-080 C-RES,U 68K-1/16W J a
ELECTRICAL O R 0605 88-108-102-080 C-RES,U 1K-1/16W J a
ELECTRICAL O R 0606 88-108-102-080 C-RES,U 1K-1/16W J a
ELECTRICAL O R 0607 88-108-102-080 C-RES,U 1K-1/16W J a
ELECTRICAL O R 0608 88-108-102-080 C-RES,U 1K-1/16W J a
ELECTRICAL O R 0609 88-108-102-080 C-RES,U 1K-1/16W J a
ELECTRICAL O R 0610 88-108-103-080 C-RES,U 10K-1/16W J a
ELECTRICAL X R 0621 88-108-104-080 C-RES,U 100K-1/16W J a
ELECTRICAL X R 0622 88-108-104-080 C-RES,U 100K-1/16W J a
ELECTRICAL X R 0641 88-108-391-080 C-RES,U 390-1/16W J a
ELECTRICAL X R 0651 88-108-561-080 C-RES,U 560-1/16W J a
ELECTRICAL X R 0652 88-108-561-080 C-RES,U 560-1/16W J a
ELECTRICAL X R 0653 88-108-561-080 C-RES,U 560-1/16W J a
ELECTRICAL X R 0654 88-108-682-080 C-RES,U 6.8K-1/16W J a
ELECTRICAL X R 0661 88-118-331-080 C-RES,S 330-1/10W J a
ELECTRICAL X R 0662 88-108-682-080 C-RES,U 6.8K-1/16W J a
ELECTRICAL O R 0663 88-108-102-080 C-RES,U 1K-1/16W J a
ELECTRICAL X R 0671 88-108-391-080 C-RES,U 390-1/16W J a
ELECTRICAL X R 0672 88-108-391-080 C-RES,U 390-1/16W J a
ELECTRICAL X R 0673 88-108-391-080 C-RES,U 390-1/16W J a
CDC-R227
YZSF
ELECTRICAL X R 0674 88-108-682-080 C-RES,U 6.8K-1/16W J a
ELECTRICAL O SW 0601 87-A90-164-080 SW,TACT SKQNAB(N) a
ELECTRICAL O SW 0602 87-A90-164-080 SW,TACT SKQNAB(N) a
ELECTRICAL O SW 0603 87-A90-164-080 SW,TACT SKQNAB(N) a
ELECTRICAL O SW 0604 87-A91-987-080 SW,TACT SKQCAB a
ELECTRICAL O SW 0605 87-A91-987-080 SW,TACT SKQCAB a
ELECTRICAL O SW 0606 87-A91-987-080 SW,TACT SKQCAB a
ELECTRICAL O SW 0607 87-A90-164-080 SW,TACT SKQNAB(N) a
ELECTRICAL O SW 0608 87-A91-987-080 SW,TACT SKQCAB a
ELECTRICAL O SW 0609 87-036-339-080 C-SW,TACT SKQM a
ELECTRICAL O SW 0610 87-A91-987-080 SW,TACT SKQCAB a
ELECTRICAL O SW 0611 87-036-339-080 C-SW,TACT SKQM a
ELECTRICAL O SW 0612 87-A90-164-080 SW,TACT SKQNAB(N) a
ELECTRICAL O SW 0613 87-A90-164-080 SW,TACT SKQNAB(N) a
ELECTRICAL O SW 0614 87-A90-164-080 SW,TACT SKQNAB(N) a
ELECTRICAL O SW 0615 87-A90-164-080 SW,TACT SKQNAB(N) a
ELECTRICAL O SW 0616 87-A90-164-080 SW,TACT SKQNAB(N) a
ELECTRICAL O SW 0617 87-A91-987-080 SW,TACT SKQCAB a
ELECTRICAL O SW 0621 87-A92-329-010 SW,RTRY SRP-1211VD a
E-VOL O C 0401 87-010-401-040 CAP,E 1-50 M 11L SME a
ELECTRICAL PARTS LIST -5/9

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-8-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
CDC-R227
YZSF
E-VOL O C 0402 87-010-498-040 CAP,E 10-16 M 5L SRE a
E-VOL O C 0403 87-A10-047-080 C-CAP,U 1-10 Z F a
E-VOL O C 0405 87-012-280-080 C-CAP,U 3300P-50 K B GRM a
E-VOL O C 0406 87-012-280-080 C-CAP,U 3300P-50 K B GRM a
E-VOL O C 0407 87-010-787-080 C-CAP,U 0.022-25 K B GRM a
E-VOL O C 0408 87-010-787-080 C-CAP,U 0.022-25 K B GRM a
E-VOL O C 0409 87-010-498-040 CAP,E 10-16 M 5L SRE a
E-VOL O C 0410 87-010-498-040 CAP,E 10-16 M 5L SRE a
E-VOL O C 0411 87-A10-781-080 C-CAP,U 0.15-10 K B a
E-VOL O C 0412 87-A10-781-080 C-CAP,U 0.15-10 K B a
E-VOL O C 0413 87-A10-781-080 C-CAP,U 0.15-10 K B a
E-VOL O C 0414 87-A10-781-080 C-CAP,U 0.15-10 K B a
E-VOL O C 0415 87-010-498-040 CAP,E 10-16 M 5L SRE a
E-VOL O C 0416 87-010-498-040 CAP,E 10-16 M 5L SRE a
E-VOL O C 0417 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
E-VOL O C 0418 87-010-498-040 CAP,E 10-16 M 5L SRE a
E-VOL O C 0419 87-010-498-040 CAP,E 10-16 M 5L SRE a
E-VOL O C 0421 87-010-555-040 CAP,E 100-10 M 5L SRE a
E-VOL O C 0422 87-010-787-080 C-CAP,U 0.022-25 K B GRM a
E-VOL O C 0431 87-010-498-040 CAP,E 10-16 M 5L SRE a
CDC-R227
YZSF
E-VOL O C 0432 87-010-498-040 CAP,E 10-16 M 5L SRE a
E-VOL O C 0433 87-010-498-040 CAP,E 10-16 M 5L SRE a
E-VOL O C 0434 87-010-498-040 CAP,E 10-16 M 5L SRE a
E-VOL O C 0439 87-010-498-040 CAP,E 10-16 M 5L SRE a
E-VOL O C 0440 87-010-498-040 CAP,E 10-16 M 5L SRE a
E-VOL O C 0442 87-012-270-080 C-CAP,U 470P-50 K B GRM a
E-VOL O C 0444 87-012-270-080 C-CAP,U 470P-50 K B GRM a
E-VOL O C 0451 87-A10-707-080 C-CAP,U 0.47-10 Z F a
E-VOL O C 0452 87-A10-707-080 C-CAP,U 0.47-10 Z F a
E-VOL O C 0453 87-A10-707-080 C-CAP,U 0.47-10 Z F a
E-VOL O C 0454 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
E-VOL O C 0455 87-010-498-040 CAP,E 10-16 M 5L SRE a
E-VOL O C 0456 87-A10-047-080 C-CAP,U 1-10 Z F a
E-VOL S D 0401 87-020-331-040 C-DIODE,DAN202K a
E-VOL S D 0402 87-020-465-080 DIODE,1SS133 a
E-VOL X D 0403 88-121-101-080 RES,100-1/8W J a
E-VOL S D 0451 87-A40-250-040 C-DIODE,DAN217 a
E-VOL S IC 0401 8Z-KT1-622-010 C-IC,LC75374E a
E-VOL O J 0401 87-A61-225-110 JACK,PIN 2P XR-401 a
E-VOL O L 0401 87-003-102-080 COIL,10UH J LAL02 a
CDC-R227
YZSF
E-VOL S Q 0401 87-A30-287-040 C-TR,DTC114TKA a
E-VOL S Q 0402 87-A30-287-040 C-TR,DTC114TKA a
E-VOL S Q 0403 87-A30-287-040 C-TR,DTC114TKA a
E-VOL S Q 0404 87-A30-287-040 C-TR,DTC114TKA a
E-VOL S Q 0405 87-A30-283-040 C-TR,DTA114YKA a
E-VOL S Q 0406 87-A30-287-040 C-TR,DTC114TKA a
E-VOL S Q 0451 89-324-122-040 C-TR,2SC2412KR a
E-VOL O R 0401 88-108-562-080 C-RES,U 5.6K-1/16W J a
E-VOL X R 0402 88-108-222-080 C-RES,U 2.2K-1/16W J a
E-VOL O R 0403 88-108-332-080 C-RES,U 3.3K-1/16W J a
E-VOL O R 0404 88-108-332-080 C-RES,U 3.3K-1/16W J a
E-VOL O R 0405 88-108-332-080 C-RES,U 3.3K-1/16W J a
E-VOL O R 0406 88-108-332-080 C-RES,U 3.3K-1/16W J a
E-VOL X R 0431 88-121-102-080 RES,1K-1/8W J a
E-VOL X R 0432 88-121-102-080 RES,1K-1/8W J a
E-VOL X R 0433 88-121-102-080 RES,1K-1/8W J a
E-VOL X R 0434 88-121-102-080 RES,1K-1/8W J a
E-VOL O R 0439 88-108-102-080 C-RES,U 1K-1/16W J a
E-VOL O R 0440 88-108-102-080 C-RES,U 1K-1/16W J a
E-VOL O R 0441 88-108-102-080 C-RES,U 1K-1/16W J a
CDC-R227
YZSF
E-VOL O R 0442 88-108-102-080 C-RES,U 1K-1/16W J a
E-VOL X R 0443 88-108-104-080 C-RES,U 100K-1/16W J a
E-VOL X R 0444 88-108-104-080 C-RES,U 100K-1/16W J a
E-VOL X R 0445 88-108-104-080 C-RES,U 100K-1/16W J a
E-VOL X R 0446 88-108-104-080 C-RES,U 100K-1/16W J a
E-VOL X R 0451 88-108-104-080 C-RES,U 100K-1/16W J a
E-VOL X R 0452 88-108-104-080 C-RES,U 100K-1/16W J a
E-VOL X R 0453 88-108-105-080 C-RES,U 1M-1/16W J a
E-VOL X R 0454 88-108-472-080 C-RES,U 4.7K-1/16W J a
E-VOL O R 0455 88-108-103-080 C-RES,U 10K-1/16W J a
E-VOL O R 0456 88-108-102-080 C-RES,U 1K-1/16W J a
E-VOL X R 0457 88-108-105-080 C-RES,U 1M-1/16W J a
MICON O C 0912 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MICON O C 0913 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MICON O C 0914 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MICON O C 0921 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MICON O C 0923 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MICON O C 0924 87-010-154-080 C-CAP,S 10P-50 D CH GRM a
MICON O C 0925 87-010-154-080 C-CAP,S 10P-50 D CH GRM a
MICON O C 0927 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
ELECTRICAL PARTS LIST -6/9

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-9-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
CDC-R227
YZSF
MICON O C 0928 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
MICON O C 0929 87-A10-707-080 C-CAP,U 0.47-10 Z F a
MICON O C 0930 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
MICON O C 0931 87-012-199-080 C-CAP,U 220P-50 J CH GRM a
MICON O C 0932 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
MICON O C 0933 87-016-039-090 CAP,DL 0.022F-5.5 Z 70 FM a
MICON O C 0934 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
MICON S D 0903 87-020-465-080 DIODE,1SS133 a
MICON S D 0906 87-020-465-080 DIODE,1SS133 a
MICON S D 0907 87-070-136-080 ZENER,MTZJ5.1B a
MICON S D 0910 87-070-136-080 ZENER,MTZJ5.1B a
MICON S D 0911 87-A40-620-080 ZENER,MTZJ6.2A a
MICON S D 0912 87-070-136-080 ZENER,MTZJ5.1B a
MICON S IC 0901 8C-KCA-611-030 C-IC,UPD178078GF-566-3BA a
MICON S IC 0902 88-KT1-606-080 IC,PST994D a
MICON O L 0901 87-003-149-080 COIL,47UH J LAL02 a
MICON X R 0904 88-121-563-080 RES,56K-1/8W J a
MICON O R 0905 88-108-153-080 C-RES,U 15K-1/16W J a
MICON O R 0908 88-108-473-080 C-RES,U 47K-1/16W J a
MICON O R 0911 88-108-473-080 C-RES,U 47K-1/16W J a
CDC-R227
YZSF
MICON O R 0912 88-108-223-080 C-RES,U 22K-1/16W J a
MICON X R 0914 88-129-000-080 C-JUMPER, 3216 a
MICON X R 0915 88-128-104-080 C-RES, 100K-1/8W J a
MICON X R 0916 88-108-104-080 C-RES,U 100K-1/16W J a
MICON X R 0918 88-128-473-080 C-RES, 47K-1/8W J a
MICON O R 0919 88-108-473-080 C-RES,U 47K-1/16W J a
MICON X R 0920 88-128-473-080 C-RES, 47K-1/8W J a
MICON X R 0921 88-121-222-080 RES,2.2K-1/8W J a
MICON X R 0922 88-121-222-080 RES,2.2K-1/8W J a
MICON X R 0923 88-121-222-080 RES,2.2K-1/8W J a
MICON X R 0924 88-121-222-080 RES,2.2K-1/8W J a
MICON X R 0925 88-108-222-080 C-RES,U 2.2K-1/16W J a
MICON X R 0926 88-108-222-080 C-RES,U 2.2K-1/16W J a
MICON X R 0927 88-108-222-080 C-RES,U 2.2K-1/16W J a
MICON X R 0928 88-108-104-080 C-RES,U 100K-1/16W J a
MICON X R 0929 88-108-104-080 C-RES,U 100K-1/16W J a
MICON X R 0930 88-108-222-080 C-RES,U 2.2K-1/16W J a
MICON X R 0931 88-108-222-080 C-RES,U 2.2K-1/16W J a
MICON X R 0932 88-108-222-080 C-RES,U 2.2K-1/16W J a
MICON X R 0933 88-108-222-080 C-RES,U 2.2K-1/16W J a
CDC-R227
YZSF
MICON X R 0935 88-108-104-080 C-RES,U 100K-1/16W J a
MICON X R 0936 88-108-104-080 C-RES,U 100K-1/16W J a
MICON X R 0937 88-121-104-080 RES,100K-1/8W J a
MICON O R 0938 88-108-473-080 C-RES,U 47K-1/16W J a
MICON X R 0939 88-108-104-080 C-RES,U 100K-1/16W J a
MICON O R 0940 88-108-224-080 C-RES,U 220K-1/16W J a
MICON O R 0942 88-108-102-080 C-RES,U 1K-1/16W J a
MICON O R 0944 88-108-272-080 C-RES,U 2.7K-1/16W J a
MICON X R 0945 88-108-104-080 C-RES,U 100K-1/16W J a
MICON X R 0946 88-108-104-080 C-RES,U 100K-1/16W J a
MICON X R 0947 88-108-222-080 C-RES,U 2.2K-1/16W J a
MICON X R 0948 88-121-104-080 RES,100K-1/8W J a
MICON X R 0949 88-108-104-080 C-RES,U 100K-1/16W J a
MICON X R 0950 88-108-104-080 C-RES,U 100K-1/16W J a
MICON X R 0951 88-108-104-080 C-RES,U 100K-1/16W J a
MICON O R 0952 88-108-473-080 C-RES,U 47K-1/16W J a
MICON O R 0955 88-108-473-080 C-RES,U 47K-1/16W J a
MICON O SW 0901 87-A91-070-010 SW,TACT SKHHLV a
MICON O X 0901 87-A70-372-080 VIB,XTAL 6.3MHZ HC-49/U-S a
POWER AMP O C 0501 87-010-805-080 C-CAP,S 1-16 Z F GRM a
CDC-R227
YZSF
POWER AMP O C 0502 87-010-805-080 C-CAP,S 1-16 Z F GRM a
POWER AMP O C 0503 87-010-805-080 C-CAP,S 1-16 Z F GRM a
POWER AMP O C 0504 87-010-805-080 C-CAP,S 1-16 Z F GRM a
POWER AMP O C 0505 87-012-271-080 C-CAP,U 560P-50 K B GRM a
POWER AMP O C 0506 87-012-271-080 C-CAP,U 560P-50 K B GRM a
POWER AMP O C 0507 87-012-271-080 C-CAP,U 560P-50 K B GRM a
POWER AMP O C 0508 87-012-271-080 C-CAP,U 560P-50 K B GRM a
POWER AMP O C 0509 87-010-497-040 CAP,E 4.7-35 M 5L SRE a
POWER AMP O C 0510 87-010-380-040 CAP,E 47-16 M 11L SME a
POWER AMP O C 0511 87-A12-317-080 C-CAP,U 0.1-50 Z F a
POWER AMP O C 0512 87-A12-317-080 C-CAP,U 0.1-50 Z F a
POWER AMP O C 0513 87-A12-317-080 C-CAP,U 0.1-50 Z F a
POWER AMP O C 0514 87-A12-317-080 C-CAP,U 0.1-50 Z F a
POWER AMP O C 0515 87-010-805-080 C-CAP,S 1-16 Z F GRM a
POWER AMP O C 0516 87-A12-317-080 C-CAP,U 0.1-50 Z F a
POWER AMP O C 0517 8A-KC7-623-000 CAP,E 2200-16 125 BT a
POWER AMP O C 0519 87-010-497-040 CAP,E 4.7-35 M 5L SRE a
POWER AMP O C 0521 87-A12-317-080 C-CAP,U 0.1-50 Z F a
POWER AMP O C 0526 87-010-495-040 CAP,E 2.2-50 M 5L SRE a
POWER AMP S D 0501 87-001-783-080 DIODE,1N4002 a
ELECTRICAL PARTS LIST -7/9

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-10-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
CDC-R227
YZSF
POWER AMP S D 0502 87-001-783-080 DIODE,1N4002 a
POWER AMP S D 0503 87-001-783-080 DIODE,1N4002 a
POWER AMP S D 0504 87-001-783-080 DIODE,1N4002 a
POWER AMP S D 0505 87-001-783-080 DIODE,1N4002 a
POWER AMP S D 0506 87-001-783-080 DIODE,1N4002 a
POWER AMP S D 0507 87-001-783-080 DIODE,1N4002 a
POWER AMP S D 0508 87-001-783-080 DIODE,1N4002 a
POWER AMP S D 0522 87-070-334-080 ZENER,MTZJ10B a
POWER AMP S D 0523 87-020-465-080 DIODE,1SS133 a
POWER AMP S IC 0501 87-A22-157-010 IC,LA4743J a
POWER AMP S Q 0501 87-A30-272-040 C-TR,DTA124EKA a
POWER AMP O R 0501 88-108-123-080 C-RES,U 12K-1/16W J a
POWER AMP O R 0502 88-108-123-080 C-RES,U 12K-1/16W J a
POWER AMP O R 0503 88-108-123-080 C-RES,U 12K-1/16W J a
POWER AMP O R 0504 88-108-123-080 C-RES,U 12K-1/16W J a
POWER AMP X R 0505 88-108-183-080 C-RES,U 18K-1/16W J a
POWER AMP X R 0506 88-108-183-080 C-RES,U 18K-1/16W J a
POWER AMP X R 0507 88-108-183-080 C-RES,U 18K-1/16W J a
POWER AMP X R 0508 88-108-183-080 C-RES,U 18K-1/16W J a
POWER AMP X R 0509 88-121-103-080 RES,10K-1/8W J a
CDC-R227
YZSF
POWER AMP O R 0510 87-010-805-080 C-CAP,S 1-16 Z F GRM a
POWER AMP X R 0521 88-108-100-080 C-RES,U 10-1/16W J a
POWER SUPPLY O C 0804 87-010-498-040 CAP,E 10-16 M 5L SRE a
POWER SUPPLY O C 0805 87-010-380-040 CAP,E 47-16 M 11L SME a
POWER SUPPLY O C 0806 87-010-787-080 C-CAP,U 0.022-25 K B GRM a
POWER SUPPLY O C 0807 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
POWER SUPPLY O C 0808 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
POWER SUPPLY O C 0809 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
POWER SUPPLY O C 0811 87-010-787-080 C-CAP,U 0.022-25 K B GRM a
POWER SUPPLY O C 0816 87-010-787-080 C-CAP,U 0.022-25 K B GRM a
POWER SUPPLY O C 0819 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
POWER SUPPLY O C 0820 87-010-380-040 CAP,E 47-16 M 11L SME a
POWER SUPPLY O C 0852 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
POWER SUPPLY O CNA0801 8A-KT1-646-010 CONN ASSY,8P ISO-WHITE-B X a
POWER SUPPLY O CNA0802 8A-KT1-645-010 CONN ASSY,8P ISO-BLACK-B X a
POWER SUPPLY S D 0801 87-070-334-080 ZENER,MTZJ10B a
POWER SUPPLY S D 0802 87-020-331-040 C-DIODE,DAN202K a
POWER SUPPLY S D 0804 87-A40-523-080 ZENER,MTZJ9.1B a
POWER SUPPLY S D 0805 87-017-932-080 ZENER,MTZJ6.2B a
POWER SUPPLY S D 0806 87-020-330-040 C-DIODE,DAP202K a
CDC-R227
YZSF
POWER SUPPLY S D 0851 87-A40-798-010 DIODE,1N5402 (3A/200V) a
POWER SUPPLY O L 0851 8B-KCF-615-010 FLTR,AMORPHOUS -CHOKE a
POWER SUPPLY S Q 0801 89-213-750-010 TR,2SB1375 a
POWER SUPPLY S Q 0802 89-324-122-040 C-TR,2SC2412KR a
POWER SUPPLY S Q 0803 89-324-122-040 C-TR,2SC2412KR a
POWER SUPPLY S Q 0804 87-A30-287-040 C-TR,DTC114TKA a
POWER SUPPLY S Q 0805 89-213-750-010 TR,2SB1375 a
POWER SUPPLY S Q 0806 89-420-120-010 TR,2SD2012 a
POWER SUPPLY S Q 0807 87-A30-289-040 C-TR,2SA1037AK(Q) a
POWER SUPPLY S Q 0808 87-A30-287-040 C-TR,DTC114TKA a
POWER SUPPLY O Q 0809 89-418-580-080 TR,2SD1858TV2 a
POWER SUPPLY O R 0801 88-108-103-080 C-RES,U 10K-1/16W J a
POWER SUPPLY X R 0802 88-148-681-080 C-RES, 680-1/2W J a
POWER SUPPLY X R 0804 88-148-229-080 C-RES, 2.2-1/2W J a
POWER SUPPLY X R 0808 88-108-273-080 C-RES,U 27K-1/16W J a
POWER SUPPLY O R 0809 88-108-103-080 C-RES,U 10K-1/16W J a
POWER SUPPLY O R 0810 88-108-102-080 C-RES,U 1K-1/16W J a
POWER SUPPLY X R 0811 88-108-681-080 C-RES,U 680-1/16W J a
POWER SUPPLY X R 0814 88-118-680-080 C-RES,S 68-1/10W J a
POWER SUPPLY X R 0815 88-108-472-080 C-RES,U 4.7K-1/16W J a
CDC-R227
YZSF
POWER SUPPLY X W 0801 8A-KCG-615-010 WIRE,400 P-MUTE a
RDS O C 0151 87-012-183-080 C-CAP,U 30P-50 J CH GRM a
RDS O C 0152 87-012-182-080 C-CAP,U 27P-50 J CH GRM a
RDS O C 0153 87-010-495-040 CAP,E 2.2-50 M 5L SRE a
RDS O C 0154 87-012-268-080 C-CAP,U 330P-50 K B GRM a
RDS O C 0155 87-012-271-080 C-CAP,U 560P-50 K B GRM a
RDS O C 0156 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
RDS O C 0157 87-010-380-040 CAP,E 47-16 M 11L SME a
RDS S D 0151 87-070-136-080 ZENER,MTZJ5.1B a
RDS S IC 0151 88-KT1-607-080 C-IC,SAA6579T a
RDS X R 0128 88-121-331-080 RES,330-1/8W J a
RDS X R 0151 88-108-222-080 C-RES,U 2.2K-1/16W J a
RDS O X 0151 87-A70-091-010 VIB,XTAL 4.332MHZ CSA-309 a
TUNER O ANT0101 8Z-KT1-614-010 ANT,AW-002 a
TUNER O C 0101 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
TUNER O C 0102 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
TUNER O C 0103 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
TUNER O C 0104 87-012-282-080 C-CAP,U 4700P-50 K B GRM a
TUNER O C 0105 87-010-490-040 CAP,E 0.1-50 M 5L MA a
TUNER O C 0107 87-010-380-040 CAP,E 47-16 M 11L SME a
ELECTRICAL PARTS LIST -8/9
