SERVICE MANUAL

DATA

CSD-A280

LH

CD STEREO RADIO

CASSETTE RECORDER

SIMPLE

S/M Code No. 09-003-430-0T1

• Replace this Service manual with “Revision Publishing” when it is issued.

BASIC TAPE MECHANISM : TN-21ZVC-2000

BASIC CD MECHANISM : DA11T3C

ELECTRICAL MAIN PARTS LIST - 1/5

NOTE: The characters in the suffix column indicate the part usage.

LHSC ...................XX..................................A...................

ANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

C 605 87-010-264-040 CAP,E 100-10 5L A...................

C 601 87-010-313-080 CAP, CHIP 18P A...................

C 602 87-010-315-080 C-CAP,S 27P-50 CH A...................

C 604 87-010-317-010 CHIP CAP,S 39P CH A...................

C 603 87-010-319-080 C-CAP,S 56P-50 CH A...................

C 609 87-010-400-080 CAP, ELECT 0.47-50V A...................

C 608 87-010-405-080 CAP, ELECT 10-50V A...................

C 607 87-010-452-080 CAPACITOR,1-16 A...................

C 606 87-010-805-080 CAP, S 1-16 A...................

C 617 87-010-166-080 C-CAP,S 100P-50 SL A...................

C 618 87-010-166-080 C-CAP,S 100P-50 SL A...................

C 610 87-010-178-010 CAP, S 1000P-50 A...................

C 614 87-010-312-080 C-CAP,S 15P-50 CH A...................

C 612 87-010-405-080 CAP, ELECT 10-50V A...................

C 616 87-010-805-080 CAP, S 1-16 A...................

C 615 87-010-805-080 CAP, S 1-16 A...................

C 613 87-012-368-080 C-CAP,S 0.1-50 F A...................

C 611 87-A10-189-040 CAP,E 220-10 A...................

CN 601 87-099-033-010 16P 6216 H A...................

CN 602 87-099-201-010 CONN,8P 6216 H A...................

CNA 604 8A-CD9-623-010 CONN ASSY,4P EY A...................

D 608 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 602 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 604 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 607 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 601 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 605 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 606 87-070-345-080 DIODE,IN4148 A...................

IC 602 87-A20-650-010 IC,RPM6938-V11 A...................

IC 604 8A-CD9-610-010 C-IC,LC865516A-*** A...................

L 609 87-003-098-080 COIL,2.2UH A...................

L 604 87-003-098-080 COIL,2.2UH A...................

L 605 87-003-098-080 COIL,2.2UH A...................

L 601 87-003-098-080 COIL,2.2UH A...................

L 606 87-003-098-080 COIL,2.2UH A...................

L 603 87-003-098-080 COIL,2.2UH A...................

L 602 87-003-098-080 COIL,2.2UH A...................

L 608 87-003-098-080 COIL,2.2UH A...................

L 607 87-003-098-080 COIL,2.2UH A...................

LED 602 88-CD6-630-010 LED,934ID RED A...................

LED 606 88-CD6-630-010 LED,934ID RED A...................

LED 608 88-CD6-630-010 LED,934ID RED A...................

LED 607 88-CD6-630-010 LED,934ID RED A...................

LED 603 88-CD6-630-010 LED,934ID RED A...................

LED 611 87-CD8-616-010 LED,SA36-11 HWA-11.0 A...................

LED 610 88-CD6-631-010 LED,934GD GRN A...................

Q 603 87-026-237-080 CHIP-TR,DTC124X A...................

Q 606 87-026-464-010 TR,DTC114TS A...................

Q 608 87-026-464-010 TR,DTC114TS A...................

Q 607 87-026-464-010 TR,DTC114TS A...................

Q 604 89-317-403-080 TR,2SC1740S A...................

Q 610 87-026-463-080 TR,2SA933S (0.3W) A...................

Q 613 87-026-464-010 TR,DTC114TS A...................

Q 646 87-026-291-080 TR,DTC124XS A...................

S 609 87-A91-704-080 SW,TACT EVQ 214 05R A...................

S 604 87-A91-704-080 SW,TACT EVQ 214 05R A...................

S 602 87-A91-704-080 SW,TACT EVQ 214 05R A...................

S 601 87-A91-704-080 SW,TACT EVQ 214 05R A...................

S 605 87-A91-704-080 SW,TACT EVQ 214 05R A...................

S 603 87-A91-704-080 SW,TACT EVQ 214 05R A...................

S 611 87-A91-704-080 SW,TACT EVQ 214 05R A...................

X 601 87-030-273-010 VIB,XTAL 32.768 5PPM A...................

X 602 87-030-376-080 VIB,CER CSA5.76MG200 A...................

CN 204 87-A60-685-010 CONN,4P H WHT EH A...................

CN 605 87-A60-114-010 CONN,4P H S2M-4WR A...................

CNA 203 8A-CD9-628-010 CONN ASSY,3P MA-HP A...................

J 251 87-A60-569-010 JAC ,HTJ-035-18 A...................

S 607 87-A91-704-080 SW,TACT EVQ 214 05R A...................

S 608 87-A91-704-080 SW,TACT EVQ 214 05R A...................

S 606 87-A91-704-080 SW,TACT EVQ 214 05R A...................

S 615 87-A91-704-080 SW,TACT EVQ 214 05R A...................

S 614 87-A91-704-080 SW,TACT EVQ 214 05R A...................

C 902 87-010-192-080 C-CAP,S 0.022-50 F A...................

C 903 87-010-192-080 C-CAP,S 0.022-50 F A...................

C 901 87-010-192-080 C-CAP,S 0.022-50 F A...................

C 904 87-010-192-080 C-CAP,S 0.022-50 F A...................

CNA 901 8A-CD9-627-010 CONN ASSY,3P PWR A...................

D 904 87-A40-465-010 DIODE,FR202 A...................

D 903 87-A40-465-010 DIODE,FR202 A...................

D 902 87-A40-465-010 DIODE,FR202 A...................

D 901 87-A40-465-010 DIODE,FR202 A...................

ELECTRICAL MAIN PARTS LIST - 2/5

PR 901 87-A90-092-080 PROTECTOR,2.5A 491 A...................

SP 901 87-CD6-213-010 SPR-C,BATT (-) A...................

SP 904 87-CD6-213-010 SPR-C,BATT (-) A...................

SP 902 87-CD6-213-010 SPR-C,BATT (-) A...................

SP 903 87-CD6-213-010 SPR-C,BATT (-) A...................

C 211 87-010-805-080 CAP, S 1-16 A...................

C 212 87-010-805-080 CAP, S 1-16 A...................

C 215 87-016-460-080 C-CAP,S 0.22-16 B A...................

C 216 87-016-460-080 C-CAP,S 0.22-16 B A...................

C 239 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 232 87-010-213-080 C-CAP,S 0.015-50 B A...................

C 231 87-010-213-080 C-CAP,S 0.015-50 B A...................

C 237 87-010-408-080 CAP, ELECT 47-50V A...................

C 236 87-016-669-080 C-CAP,S 0.1-25 B A...................

C 235 87-016-669-080 C-CAP,S 0.1-25 B A...................

C 234 87-A10-201-080 C-CAP,S0.33-16 B A...................

C 233 87-A10-201-080 C-CAP,S0.33-16 B A...................

C 240 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 310 87-010-248-080 CAP, ELECT 220-10V A...................

C 483 87-012-156-080 C-CAP,S 220P-50 CH A...................

C 484 87-012-156-080 C-CAP,S 220P-50 CH A...................

C 819 87-010-426-080 C-CAP,S 0.012-25 B A...................

C 820 87-010-426-080 C-CAP,S 0.012-25 B A...................

D 310 87-020-465-080 DIODE,1SS133 (110MA) A...................

IC 203 87-A21-520-040 C-IC,M61509FP A...................

C 263 87-010-178-080 CHIP CAP 1000P A...................

C 264 87-010-178-080 CHIP CAP 1000P A...................

C 262 87-010-402-080 CAP, ELECT 2.2-50V A...................

C 261 87-010-402-080 CAP, ELECT 2.2-50V A...................

C 266 87-010-545-080 CAP, ELECT 0.22-50V A...................

C 267 87-010-545-080 CAP, ELECT 0.22-50V A...................

C 272 87-010-237-080 CAP, ELECT 1000-16V A...................

C 271 87-010-237-080 CAP, ELECT 1000-16V A...................

C 279 87-010-263-080 CAP, ELECT 100-10V A...................

C 278 87-010-263-080 CAP, ELECT 100-10V A...................

C 277 87-010-404-080 CAP, ELECT 4.7-50V A...................

CN 202 8A-CH4-689-010 CONN,3P V 2.5 A...................

IC 202 87-A21-090-010 IC,LA4600 A...................

C 308 87-010-221-080 CAP, ELECT 470-10V A...................

C 307 87-010-401-080 CAP, ELECT 1-50V A...................

C 306 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 301 87-016-495-000 CAP,E 3300-25 M SMG A...................

C 311 87-010-374-080 CAP, ELECT 47-10V A...................

C 312 87-010-385-080 CAP, ELECT 220-25V A...................

C 325 87-010-405-080 CAP, ELECT 10-50V A...................

CN 301 8A-CH4-689-010 CONN,3P V 2.5 A...................

D 306 87-070-345-080 DIODE,IN4148 A...................

D 305 87-070-345-080 DIODE,IN4148 A...................

D 303 87-070-345-080 DIODE,IN4148 A...................

D 304 87-A40-648-080 ZENER,MTZJ8.2A A...................

D 311 87-027-702-080 DIODE,ZENER HZ6C2L (200MA) A...................

Q 303 87-026-291-080 TR,DTC124XS A...................

Q 305 87-026-462-080 TR,2SC1740 S(RS 0.3W) A...................

Q 302 87-026-463-080 TR,2SA933S (0.3W) A...................

Q 301 89-112-965-080 TR,2SA1296 (0.75W) A...................

Q 304 89-213-702-080 TR,2SB1370E A...................

Q 310 89-318-154-080 TR,2SC1815 (0.4W) A...................

C 30 87-010-260-080 CAP, ELECT 47-25V A...................

C 801 87-010-248-080 CAP, ELECT 220-10V A...................

C 807 87-010-405-080 CAP, ELECT 10-50V A...................

C 809 87-010-405-080 CAP, ELECT 10-50V A...................

C 808 87-010-405-080 CAP, ELECT 10-50V A...................

C 805 87-012-365-080 C-CAP,S 0.027-25VB A...................

C 806 87-012-365-080 C-CAP,S 0.027-25VB A...................

C 812 87-010-178-080 CHIP CAP 1000P A...................

C 811 87-010-178-080 CHIP CAP 1000P A...................

C 816 87-010-180-080 C-CER 1500P A...................

C 817 87-010-180-080 C-CER 1500P A...................

C 810 87-010-405-080 CAP, ELECT 10-50V A...................

C 823 87-010-178-080 CHIP CAP 1000P A...................

C 829 87-010-178-080 CHIP CAP 1000P A...................

C 824 87-010-178-080 CHIP CAP 1000P A...................

C 821 87-010-401-080 CAP, ELECT 1-50V A...................

C 822 87-010-401-080 CAP, ELECT 1-50V A...................

C 830 87-010-178-080 CHIP CAP 1000P A...................

C 831 87-010-198-080 CAP, CHIP 0.022 A...................

C 834 87-010-248-080 CAP, ELECT 220-10V A...................

C 835 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 836 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 833 87-018-195-080 CAP, CER 1200P-16V A...................

C 845 87-010-178-080 CHIP CAP 1000P A...................

C 843 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 846 87-010-263-080 CAP, ELECT 100-10V A...................

C 844 87-018-124-080 CAP, CER 270P-50V A...................

C 852 87-010-178-080 CHIP CAP 1000P A...................

C 851 87-010-186-080 CAP,CHIP 4700P A...................

C 853 87-A11-145-080 CAP,TC U 0.01-50 Z F A...................

ELECTRICAL MAIN PARTS LIST - 3/5

CN 801 87-A60-110-010 CONN,4P V S2M-4W A...................

CN 802 8A-CH4-687-010 CONN,4P V 2.5 A...................

D 308 87-017-978-080 DIODE,1N4003 A...................

D 309 87-070-345-080 DIODE,IN4148 A...................

D 809 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 808 87-070-345-080 DIODE,IN4148 A...................

D 807 87-070-345-080 DIODE,IN4148 A...................

D 810 87-020-465-080 DIODE,1SS133 (110MA) A...................

IC 801 87-A21-431-010 IC,BA4560N A...................

L 801 87-007-342-010 COIL,OSC 85 BIAS A...................

Q 801 89-318-154-080 TR,2SC1815 (0.4W) A...................

Q 810 87-026-464-080 TR,DTC114TS (0.3W) A...................

R 840 87-029-124-010 RES,FUSE 2.2-1/4 A...................

SW 801 8Z-CD9-609-010 SW,SL 1-6-2 PS62D01 A...................

C 321 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 322 87-010-263-080 CAP, ELECT 100-10V A...................

CN 201 87-099-018-010 CONN,16P A...................

CN 302 8A-CD9-629-010 CONN ASSY,6P MA-TU A...................

D 32 87-027-607-080 ZENER,HZ7B3L A...................

D 323 87-070-345-080 DIODE,IN4148 A...................

Q 321 89-318-154-080 TR,2SC1815 (0.4W) A...................

Q 841 87-026-291-080 TR,DTC124XS A...................

C 407 87-010-178-080 CHIP CAP 1000P A...................

C 402 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 405 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 408 87-010-198-080 CAP, CHIP 0.022 A...................

C 404 87-010-248-080 CAP, ELECT 220-10V A...................

C 409 87-010-248-080 CAP, ELECT 220-10V A...................

C 403 87-010-263-080 CAP, ELECT 100-10V A...................

C 406 87-010-374-080 CAP, ELECT 47-10V A...................

C 401 87-010-403-080 CAP, ELECT 3.3-50V A...................

C 418 87-010-213-080 C-CAP,S 0.015-50 B A...................

C 410 87-010-263-080 CAP, ELECT 100-10V A...................

C 412 87-010-401-080 CAP, ELECT 1-50V A...................

C 414 87-010-405-080 CAP, ELECT 10-50V A...................

C 416 87-010-545-080 CAP, ELECT 0.22-50V A...................

C 417 87-012-157-080 C-CAP,S 330P-50 CH A...................

C 413 87-016-369-080 C-CAP,S 0.033-25 B A...................

C 411 87-A11-177-080 C-CAP,S 0.15-16 B A...................

C 419 87-A11-608-080 C-CAP,S 0.33-25 B A...................

C 425 87-010-176-080 C-CAP,S 680P-50 SL A...................

C 422 87-010-184-080 CHIP CAPACITOR 3300P( ) A...................

C 429 87-010-186-080 CAP,CHIP 4700P A...................

C 428 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 423 87-010-992-080 C-CAP,S 0.047-25 B A...................

C 420 87-016-369-080 C-CAP,S 0.033-25 B A...................

C 424 87-016-460-080 C-CAP,S 0.22-16 B A...................

C 421 87-A11-177-080 C-CAP,S 0.15-16 B A...................

C 426 87-A11-608-080 C-CAP,S 0.33-25 B A...................

C 439 87-010-178-080 CHIP CAP 1000P A...................

C 434 87-010-184-080 CHIP CAPACITOR 3300P( ) A...................

C 435 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 432 87-010-374-080 CAP, ELECT 47-10V A...................

C 436 87-010-374-080 CAP, ELECT 47-10V A...................

C 433 87-010-401-080 CAP, ELECT 1-50V A...................

C 437 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 431 87-010-545-080 CAP, ELECT 0.22-50V A...................

C 430 87-012-156-080 C-CAP,S 220P-50 CH A...................

C 438 87-016-669-080 C-CAP,S 0.1-25 B A...................

C 441 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 442 87-010-313-080 CAP, CHIP 18P A...................

C 448 87-010-315-080 C-CAP,S 27P-50 CH A...................

C 445 87-012-368-080 C-CAP,S 0.1-50 F A...................

C 447 87-012-368-080 C-CAP,S 0.1-50 F A...................

C 446 87-012-368-080 C-CAP,S 0.1-50 F A...................

C 455 87-010-247-080 CAP, ELECT 100-50V A...................

C 459 87-010-263-080 CAP, ELECT 100-10V A...................

C 458 87-010-312-080 C-CAP,S 15P-50 CH A...................

C 457 87-010-312-080 C-CAP,S 15P-50 CH A...................

C 450 87-012-140-080 CAP 470P A...................

C 451 87-012-156-080 C-CAP,S 220P-50 CH A...................

C 463 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 461 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 462 87-010-248-080 CAP, ELECT 220-10V A...................

C 467 87-010-263-080 CAP, ELECT 100-10V A...................

C 465 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 469 87-012-154-080 C-CAP,S 150P-50 CH A...................

C 466 87-012-368-080 C-CAP,S 0.1-50 F A...................

C 460 87-015-819-080 CAPACITOR,0.01 A...................

C 475 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 477 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 479 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 476 87-010-236-080 CAP,E 1000-10 SME A...................

C 478 87-010-263-080 CAP, ELECT 100-10V A...................

C 470 87-010-544-080 CAP, ELECT 0.1-50V A...................

C 473 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z A...................

C 474 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z A...................

ELECTRICAL MAIN PARTS LIST - 4/5

C 472 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z A...................

C 471 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z A...................

C 480 87-010-221-080 CAP, ELECT 470-10V A...................

C 482 87-010-405-080 CAP, ELECT 10-50V A...................

C 481 87-010-405-080 CAP, ELECT 10-50V A...................

C 489 87-012-368-080 C-CAP,S 0.1-50 F A...................

C 494 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 490 87-012-368-080 C-CAP,S 0.1-50 F A...................

C 506 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 505 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 502 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 503 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 504 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 501 87-012-368-080 C-CAP,S 0.1-50 F A...................

C 510 87-016-669-080 C-CAP,S 0.1-25 B A...................

CN 205 87-A60-109-010 CONN,2P V S2M-2W A...................

CN 403 87-099-201-010 CONN,8P 6216 H A...................

CN 401 87-A60-424-010 CONN,16P V TOC-B A...................

CNA 402 8A-CD9-625-010 CONN ASSY,6P CD-ME A...................

D 401 87-070-345-080 DIODE,IN4148 A...................

D 402 87-070-345-080 DIODE,IN4148 A...................

D 403 87-070-345-080 DIODE,IN4148 A...................

IC 401 87-A20-446-010 C-IC,LA9241ML A...................

IC 402 87-A20-459-010 C-IC,LC78622ED A...................

IC 404 87-A21-093-010 IC,LA6541D A...................

L 401 87-003-102-080 COIL, 10UH A...................

L 404 87-003-152-080 COIL, 100UH A...................

Q 408 87-026-295-080 TR,DTC144T A...................

Q 403 87-026-295-080 TR,DTC144T A...................

Q 407 87-026-295-080 TR,DTC144T A...................

Q 406 87-026-295-080 TR,DTC144T A...................

Q 401 89-109-332-380 TR,2SA933RS A...................

Q 402 89-113-187-080 TR,2SA1318TU A...................

SFR 430 87-024-437-080 SFR100 ,RH063EC A...................

X 401 8Z-CD5-633-010 VIB, CER16.93MHZ FCR16.93M2 A...................

C 491 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 492 87-010-221-080 CAP, ELECT 470-10V A...................

D 494 87-070-345-080 DIODE,IN4148 A...................

D 491 87-070-345-080 DIODE,IN4148 A...................

Q 492 87-026-291-080 TR,DTC124XS A...................

Q 491 89-112-965-080 TR,2SA1296 (0.75W) A...................

C 9 87-010-154-080 CAP CHIP 10P A...................

C 8 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 1 87-010-314-080 C-CAP,S 22P-50V A...................

C 3 87-010-317-080 C-CAP,S 39P-50 CH A...................

C 2 87-010-318-080 C-CAP,S 47P-50 CH A...................

C 6 87-010-378-080 CAP, ELECT 10-16V A...................

C 7 87-018-208-080 CAP 0.047-50F A...................

C 13 87-010-148-080 CAP, CHIP S 75P SL A...................

C 11 87-010-154-080 CAP CHIP 10P A...................

C 16 87-010-178-080 CHIP CAP 1000P A...................

C 19 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 15 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 10 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 12 87-010-314-080 C-CAP,S 22P-50V A...................

C 14 87-012-141-080 CHIP-CAPACITOR,0.22-16F A...................

C 17 87-016-669-080 C-CAP,S 0.1-25 B A...................

C 25 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 22 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 24 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 20 87-010-400-080 CAP, ELECT 0.47-50V A...................

C 21 87-010-403-080 CAP, ELECT 3.3-50V A...................

C 29 87-010-992-080 C-CAP,S 0.047-25 B A...................

C 28 87-010-992-080 C-CAP,S 0.047-25 B A...................

C 26 87-012-141-080 CHIP-CAPACITOR,0.22-16F A...................

C 27 87-012-141-080 CHIP-CAPACITOR,0.22-16F A...................

C 32 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 34 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 33 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 30 87-010-248-080 CAP, ELECT 220-10V A...................

C 31 87-010-379-080 CAP, ELECT 22-16V A...................

C 37 87-012-155-080 C-CAP 180P-50CH A...................

CF 1 87-008-261-010 FILTER, SFE10.7MA5-A A...................

CF 2 87-008-261-010 FILTER, SFE10.7MA5-A A...................

CF 1 87-A90-128-010 FLTR,AM IF CFAL-455 A...................

D 4 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 1 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 2 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 3 87-A40-128-080 C-VARI-CAP,HVU202A A...................

IC 1 87-A20-955-010 IC,LA1828 A...................

L 9 87-A50-334-010 COIL,FM DET (TO O) A...................

L 8 87-A50-335-010 COIL,FM IFT (TO O) A...................

L 7 87-A50-336-010 COIL,AM IFT (TO O) A...................

L 6 87-A50-337-010 COIL,AM OSC (TO O) A...................

L 5 87-A50-342-010 COIL,FM OSC D A...................

L 4 87-A50-345-010 COIL,FM RF EX A...................

L 2 87-A50-346-010 COIL,FM BPF D A...................

ELECTRICAL MAIN PARTS LIST - 5/5

L 3 87-A50-350-010 COIL,BAR ANT AMN (COI) A...................

L 10 87-005-849-080 COIL,10UH(CECS) A...................

Q 3 87-026-230-080 CHIP-TR,DTA114Y A...................

Q 2 89-327-125-080 CHIP TR,2SC2712GR A...................

Q 1 89-327-143-080 TR,2SC2714 (0.1W) A...................

S 1 87-A91-548-010 SW,SL-2-3 S 23E01G06 A...................

VC 1 87-A91-315-010 TUN-CAP,40P-140P D(TWD) A...................

MECHANICAL PARTS LIST - 1/1

NOTE: The characters in the suffix column indicate the part usage.

LHSC ...................XX..................................A...................

ANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

87-B00-010-010 BADGE,AIWA 30.5-5.2 S 2.5L A...................

8A-CD9-005-010 CHAS,CD A A...................

8A-CD9-007-010 WINDOW,CD A...................

8A-CD9-008-010 BOX,CASS A...................

8A-CD9-009-010 WINDOW,CASS A...................

8A-CD9-011-010 HANDL,ARM A...................

8A-CD9-012-010 HANDL,GRIP A...................

8A-CD9-013-010 PANEL,VOL A...................

8A-CD9-022-010 LENS,LED A...................

8A-CD9-023-010 POINTER,TU A...................

8A-CD9-024-010 EY,CASS TN21 A...................

8A-CD9-034-010 WINDOW,TU U A...................

8A-CD -001-010 WINDOW,LED RC A...................

8A-CD -003-010 BOX,CD -LH A...................

8Z-CDB-169-010 PANEL,CD SANYO A...................

* 8A-CD9-004-010 CABI,REAR B1 A...................

* 8A-CD9-010-010 LID,BATT A...................

* 8A-CD9-062-010 CABI,FR B1 ASSY A...................

8A-CD9-014-010 BTN,VOL A...................

8A-CD9-017-010 BTN,QSOUND A...................

8A-CD9-018-010 CAP, CD A A...................

8A-CD9-019-010 CAP, CD B A...................

8A-CD9-020-010 BTN,REPEAT A...................

8A-CD9-021-010 BTN,EQ A...................

8A-CD9-026-010 NOB,RTRY TU A...................

8A-CD9-027-010 NOB,SL BAND A...................

84-CD5-215-010 GEAR A...................

84-CD5-216-010 BRAC ET A...................

84-CD5-217-010 PLATE,MAGNET A...................

86-CT4-218-010 CUSHION,FOOT/PORON A...................

87-036-368-010 MAGNET A...................

87-CD6-213-010 SPR-C,BATT (-) A...................

8A-CD9-206-010 GEAR,TU A A...................

8A-CD9-207-010 GEAR,TU B A...................

8A-CD9-208-010 DRUM,TU A...................

8A-CD9-209-010 LEVER,BAND A A...................

8A-CD9-223-010 SPR-P,REC TN21 A...................

8A-CD9-231-010 SPR-T,CD A...................

8A-CD9-232-010 SPR-T,CASS A...................

8A-CH4-211-010 COVER, HLDR PT A...................

8Z-CH4-211-010 BASE,CHUC A...................

8Z-CH4-212-010 RING,CHUC A...................

8Z-CH4-225-010 HLDR,CHUC A(S) A...................

* 8A-CD9-201-010 HLDR,DISPLAY A...................

* 8A-CD9-202-010 GUIDE,LED A...................

* 8A-CD9-203-010 GUIDE,VOL A...................

* 8A-CD9-205-010 GUIDE,GEAR A...................

* 8A-CD9-211-010 HLDR,PWB L A...................

* 8A-CD9-212-010 HLDR,PWB R A...................

* 8A-CD9-221-010 HLDR,ANT A...................

* 8A-CD9-222-010 HLDR,SPEA ER A...................

* 8A-CH4-209-010 HLDR,PT A...................

87-067-566-010 TAPPING SCREW, VFTT+3-6 A...................

87-251-073-410 SCREW,U+2.6-6 A...................

87-255-096-410 U+3-10 NI A...................

87-342-074-010 UT2+2.6-8 A...................

87-352-075-210 VT2+2.6-10 A...................

87-571-032-410 VIT+2-3 A...................

87-571-033-410 TAPPING SCREW, VIT+2-4 A...................

87-661-095-410 VFT1+3-8 A...................

87-661-097-410 TAPPING SCREW, VFT1+3-12 A...................

87-741-096-410 UT2+3-10 A...................

87-B10-239-010 QT2+3-8 W/O CR A...................

87-B10-242-010 UT2+3-30 W/O CR A...................

87-B10-269-010 UT2+3-12 W/O CR A...................

87-WA5-253-010 W,3.3-10-0.8 A...................

* 87-751-094-410 VT2+3-6 W10SL0T A...................

* 87-035-347-010 FUSE,2.5A 250V T A...................

* 87-036-389-010 SW,PUSH LOC A...................

* 87-A60-178-010 JAC ,AC E W/SW A...................

* 87-A91-369-010 SW,AC SL 2 2 2 SD GA41700 A...................

* 8Z-CH4-640-010 ANT,ROD A...................

CNA 0 8A-CD9-626-010 CONN ASSY,2P DOOR A...................

CNA 0 8A-CD9-630-010 CONN ASSY,4P RPH A...................

CNA 0 8A-CD9-631-010 CONN ASSY,4P TP-ME A...................

CNA 0 8A-CD9-633-010 CONN ASSY,4P SP A...................

FC 902 87-033-213-010 CLAMP,FUSE SM A...................

FC 901 87-033-213-010 CLAMP,FUSE SM A...................

PT 0 8A-CD9-604-010 PT,H 4.5WT04541A A...................

SP 0 88-CD5-602-010 SP R 43.2 A...................

W 0 8A-CD9-620-010 FF-CABLE, 16P FR-MAIN A...................

W 0 8A-CD9-621-010 FF-CABLE, 16P CD-RF A...................

W 0 8A-CD9-622-010 FF-CABLE, 8P CD-FR A...................

ACCESSORIES / PACKAGE LIST - 1/1

NOTE: The characters in the suffix column indicate the part usage.

LHSC ...................XX..................................A...................

ANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8A-CD9-902-010 IB,LH(ESP)B A...................

87-A80-036-010 AC CORD SET ASSY,E W/FLTR VOL A...................

87-A90-312-010 PLUG,CONVERSION WTN-1157R1 A...................

8Z-CD5-634-010 COVER,AC SOC ET A...................

8Z-CD -962-010 RC UNIT,RC-ZAT02(VS) A...................

SCHEMATIC DIAGRAM - 1 (MAIN : AMP)

SCHEMATIC DIAGRAM - 2 (MAIN : CD)

Aiwa CSD-A280 User manual

Popular Cassette Player manuals by other brands
