S E R V I C E M A N U A L
SIMPLE MANUAL
•Replace this Service Manual with "Revision Publishing" when it is issued.
CSD-ED88
CSD-ED89
• TYPE: (89):HA,HR,LH,EZ,
(88): LH
S/M Code No. 09–993–409–2T2
COMPACT DISC STEREO RADIO
CASSETTE RECORDER

ELECTRICAL MAIN PARTS LIST - 1/6
NOTE: The characters in the suffix column indicate the part usage.
HR .....................XX..................................A...................
LH1 ....................XX...................................B..................
LH .....................XX....................................C.................
EZ .....................XX.....................................D................
HA .....................XX......................................E...............
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 218 87-010-400-080 CAP, ELECT 0.47-50V ABCDE...............
C 217 87-010-400-080 CAP, ELECT 0.47-50V ABCDE...............
C 228 87-010-401-080 CAP, ELECT 1-50V ABCDE...............
C 229 87-010-401-080 CAP, ELECT 1-50V ABCDE...............
C 232 87-010-213-080 C-CAP,S 0.015-50 B ABCDE...............
C 231 87-010-213-080 C-CAP,S 0.015-50 B ABCDE...............
C 238 87-010-263-080 CAP, ELECT 100-10V ABCDE...............
C 237 87-010-374-080 CAP, ELECT 47-10V ABCDE...............
C 235 87-010-544-080 CAP, ELECT 0.1-50V ABCDE...............
C 236 87-010-544-080 CAP, ELECT 0.1-50V ABCDE...............
C 234 87-010-546-080 CAP, ELECT 0.33-50V ABCDE...............
C 233 87-010-546-080 CAP, ELECT 0.33-50V ABCDE...............
C 248 87-010-404-080 CAP, ELECT 4.7-50V ABCDE...............
C 247 87-010-404-080 CAP, ELECT 4.7-50V ABCDE...............
C 246 87-010-405-080 CAP, ELECT 10-50V ABCDE...............
C 241 87-010-405-080 CAP, ELECT 10-50V ABCDE...............
C 245 87-010-405-080 CAP, ELECT 10-50V ABCDE...............
C 244 87-010-405-080 CAP, ELECT 10-50V ABCDE...............
C 243 87-010-405-080 CAP, ELECT 10-50V ABCDE...............
C 242 87-010-405-080 CAP, ELECT 10-50V ABCDE...............
C 262 87-010-402-080 CAP, ELECT 2.2-50V ABCDE...............
C 261 87-010-402-080 CAP, ELECT 2.2-50V ABCDE...............
D 281 87-A40-466-080 ZENER,MTZJ2.7A ABCDE...............
IC 203 87-A21-111-040 C-IC,M62495FP ABCDE...............
C 209 87-010-190-080 S CHIP F 0.01 ABCDE...............
C 208 87-010-402-080 CAP, ELECT 2.2-50V ABCDE...............
C 207 87-010-408-080 CAP, ELECT 47-50V ABCDE...............
C 210 87-010-190-080 S CHIP F 0.01 ABCDE...............
C 215 87-010-425-080 C-CAP,0.22-25 F ABCDE...............
C 216 87-010-425-080 C-CAP,0.22-25 F ABCDE...............
C 211 87-010-544-080 CAP, ELECT 0.1-50V ABCDE...............
C 212 87-010-544-080 CAP, ELECT 0.1-50V ABCDE...............
C 223 87-010-190-080 S CHIP F 0.01 ABCDE...............
C 226 87-010-190-080 S CHIP F 0.01 ABCDE...............
C 222 87-010-190-080 S CHIP F 0.01 ABCDE...............
C 220 87-010-405-080 CAP, ELECT 10-50V ABCDE...............
IC 201 87-A20-946-040 C-IC,MM1434XF ABCDE...............
C 251 87-010-401-080 CAP, ELECT 1-50V ABCDE...............
C 263 87-010-178-080 CHIP CAP 1000P ABCDE...............
C 264 87-010-178-080 CHIP CAP 1000P ABCDE...............
C 269 87-010-248-080 CAP, ELECT 220-10V ....................
C 265 87-010-260-080 CAP, ELECT 47-25V ....................
C 266 87-010-260-080 CAP, ELECT 47-25V ....................
C 268 87-010-380-080 CAP, ELECT 47-16V ABCDE...............
C 267 87-010-380-080 CAP, ELECT 47-16V ABCDE...............
C 265 87-010-383-080 CAP, ELECT 33-25V ABCDE...............
C 266 87-010-383-080 CAP, ELECT 33-25V ABCDE...............
C 268 87-015-953-080 CAP,E 4.7-35 LL ....................
C 267 87-015-953-080 CAP,E 4.7-35 LL ....................
C 264 87-018-124-080 CAP, CER 270P-50V ....................
C 263 87-018-124-080 CAP, CER 270P-50V ....................
C 279 87-010-112-080 CAP, ELECT 100-16V ABCDE...............
C 271 87-010-221-080 CAP, ELECT 470-10V ABCDE...............
C 272 87-010-221-080 CAP, ELECT 470-10V ABCDE...............
C 279 87-010-236-080 CAP,E 1000-10 SME ....................
C 277 87-010-260-080 CAP, ELECT 47-25V ABCDE...............
C 278 87-010-384-080 CAP, ELECT 100-25V ABCDE...............
C 273 87-010-628-080 CAP,E 3.3-16 M 5L BP SRE ABCDE...............
C 274 87-010-628-080 CAP,E 3.3-16 M 5L BP SRE ABCDE...............
C 274 87-018-209-080 CAP, CER 0.1-50V ....................
C 281 87-010-263-080 CAP, ELECT 100-10V ....................
C 281 87-010-401-080 CAP, ELECT 1-50V ABCDE...............
C 280 87-010-401-080 CAP, ELECT 1-50V ABCDE...............
C 293 87-010-628-080 CAP,E 3.3-16 M 5L BP SRE ....................
C 294 87-010-628-080 CAP,E 3.3-16 M 5L BP SRE ....................
C 291 87-010-628-080 CAP,E 3.3-16 M 5L BP SRE ....................
C 292 87-010-628-080 CAP,E 3.3-16 M 5L BP SRE ....................
IC 201 87-002-555-010 IC,TA8210AH * ....................
IC 201 87-A20-591-010 IC,BA5417 ABCDE...............
J 251 87-A60-569-010 JACK,HTJ-035-18 ABCDE...............
Q 244 89-320-011-010 TR,2SC2001 (0.6W) ABCDE...............
Q 243 89-320-011-010 TR,2SC2001 (0.6W) ABCDE...............
R 277 87-025-329-080 RESISTOR, 1/4W 2.2 ....................
R 275 87-025-329-080 RESISTOR, 1/4W 2.2 ....................
R 276 87-025-329-080 RESISTOR, 1/4W 2.2 ....................
R 278 87-025-329-080 RESISTOR, 1/4W 2.2 ....................
S 270 87-A91-377-010 SW,PUSH 2-2-2 SPUN192600 ....................
C 308 87-010-221-080 CAP, ELECT 470-10V ABCDE...............
C 309 87-010-263-080 CAP, ELECT 100-10V ABCDE...............
C 307 87-010-401-080 CAP, ELECT 1-50V ABCDE...............
C 306 87-010-404-080 CAP, ELECT 4.7-50V ABCDE...............
C 301 87-010-453-010 CAP, ELECT 4700-25V ABCDE...............

ELECTRICAL MAIN PARTS LIST - 2/6
C 301 87-016-452-090 CAP,E 6800-25 SKR ....................
C 315 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 312 87-010-248-080 CAP, ELECT 220-10V ABCDE...............
C 314 87-010-248-080 CAP, ELECT 220-10V ABCDE...............
C 310 87-010-248-080 CAP, ELECT 220-10V ABCDE...............
C 311 87-010-263-080 CAP, ELECT 100-10V ABCDE...............
C 904 87-018-209-080 CAP, CER 0.1-50V ....................
C 902 87-018-209-080 CAP, CER 0.1-50V ....................
C 901 87-018-209-080 CAP, CER 0.1-50V ....................
C 903 87-018-209-080 CAP, CER 0.1-50V ....................
C 903 87-A10-577-080 CAP,CER 0.022-50 Z YF ABCDE...............
C 904 87-A10-577-080 CAP,CER 0.022-50 Z YF ABCDE...............
C 901 87-A10-577-080 CAP,CER 0.022-50 Z YF ABCDE...............
C 902 87-A10-577-080 CAP,CER 0.022-50 Z YF ABCDE...............
D 307 87-017-148-080 ZENER,HZS6A1L ABCDE...............
D 304 87-017-161-080 ZENER,HZS7C2L ABCDE...............
D 309 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 306 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 308 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 305 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 303 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 311 87-017-139-010 ZENER,HZS15-2 ABCDE...............
D 901 87-070-178-090 DIODE,1N5402-BD54 ....................
D 902 87-070-178-090 DIODE,1N5402-BD54 ....................
D 904 87-070-178-090 DIODE,1N5402-BD54 ....................
D 903 87-070-178-090 DIODE,1N5402-BD54 ....................
D 903 87-A40-465-010 DIODE,FR202 ABCDE...............
D 902 87-A40-465-010 DIODE,FR202 ABCDE...............
D 901 87-A40-465-010 DIODE,FR202 ABCDE...............
D 904 87-A40-465-010 DIODE,FR202 ABCDE...............
FC 0 87-033-213-010 CLAMP,FUSE SMK ABCDE...............
IC 310 87-070-416-010 IC,NJU7201 L55 ABCDE...............
Q 303 87-026-291-010 TR,DTC124XS ABCDE...............
Q 307 87-026-462-010 TR,2SC1740S ABCDE...............
Q 305 87-026-462-010 TR,2SC1740S ABCDE...............
Q 302 87-026-463-010 TR,2SA933S,RS ABCDE...............
Q 306 88-NF9-637-010 TR,2SA1318T/U ABCDE...............
Q 301 89-112-965-010 TR,2SA1296GR ABCDE...............
Q 304 89-213-702-010 TR,2SB1370 (1.8W) ABCDE...............
Q 310 87-026-462-010 TR,2SC1740S ABCDE...............
C 803 87-010-177-080 C-CAP,S 820P-50 SL ABCDE...............
C 804 87-010-177-080 C-CAP,S 820P-50 SL ABCDE...............
C 801 87-010-402-080 CAP, ELECT 2.2-50V ABCDE...............
C 802 87-010-402-080 CAP, ELECT 2.2-50V ABCDE...............
C 809 87-010-406-010 CAP,E 22-50 SM ABCDE...............
C 805 87-012-158-080 C-CAP,S 390P-50 CH ABCDE...............
C 806 87-012-158-080 C-CAP,S 390P-50 CH ABCDE...............
C 815 87-010-374-010 CAP, ELECT 47-10V ABCDE...............
C 819 87-010-401-010 CAP, ELECT 1-50V ABCDE...............
C 818 87-010-401-010 CAP, ELECT 1-50V ABCDE...............
C 817 87-010-401-010 CAP, ELECT 1-50V ABCDE...............
C 814 87-010-402-080 CAP, ELECT 2.2-50V ABCDE...............
C 813 87-010-402-080 CAP, ELECT 2.2-50V ABCDE...............
C 812 87-010-404-010 CONDENSER 4.7-50 ABCDE...............
C 811 87-010-404-010 CONDENSER 4.7-50 ABCDE...............
C 810 87-010-406-010 CAP,E 22-50 SM ABCDE...............
C 823 87-010-213-080 C-CAP,S 0.015-50 B ABCDE...............
C 824 87-010-213-080 C-CAP,S 0.015-50 B ABCDE...............
C 820 87-010-401-010 CAP, ELECT 1-50V ABCDE...............
C 828 87-010-404-010 CONDENSER 4.7-50 ABCDE...............
C 827 87-010-404-010 CONDENSER 4.7-50 ABCDE...............
C 825 87-010-405-080 CAP, ELECT 10-50V ABCDE...............
C 826 87-010-405-080 CAP, ELECT 10-50V ABCDE...............
C 821 87-012-153-080 C-CAP,S 120P-50 CH ABCDE...............
C 822 87-012-153-080 C-CAP,S 120P-50 CH ABCDE...............
C 833 87-010-179-080 CAP,CHIP S B1200P ABCDE...............
C 839 87-010-186-080 CAP,CHIP 4700P ABCDE...............
C 831 87-010-198-080 CAP, CHIP 0.022 ABCDE...............
C 832 87-010-198-080 CAP, CHIP 0.022 ABCDE...............
C 834 87-010-248-080 CAP, ELECT 220-10V ABCDE...............
C 830 87-010-260-080 CAP, ELECT 47-25V ABCDE...............
C 835 87-010-374-010 CAP, ELECT 47-10V ABCDE...............
C 838 87-010-405-080 CAP, ELECT 10-50V ABCDE...............
C 845 87-010-178-080 CHIP CAP 1000P ABCDE...............
C 844 87-010-178-080 CHIP CAP 1000P ABCDE...............
C 849 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCDE...............
C 840 87-010-186-080 CAP,CHIP 4700P ABCDE...............
C 843 87-010-190-080 S CHIP F 0.01 ABCDE...............
C 842 87-010-194-080 CAP, CHIP 0.047 ABCDE...............
C 846 87-010-194-080 CAP, CHIP 0.047 ABCDE...............
C 841 87-010-194-080 CAP, CHIP 0.047 ABCDE...............
C 850 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCDE...............
C 851 87-010-186-080 CAP,CHIP 4700P ABCDE...............
CN 802 87-049-469-010 CONN,4P V ABCDE...............
CN 801 87-049-469-010 CONN,4P V ABCDE...............
D 9 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 8 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 2 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 1 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 4 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 3 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 5 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............

ELECTRICAL MAIN PARTS LIST - 3/6
D 7 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 6 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 10 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 41 87-070-136-080 ZENER,MTZJ5.1B ABCDE...............
D 807 87-017-437-080 DIODE,1N4148M ABCDE...............
D 805 87-017-437-080 DIODE,1N4148M ABCDE...............
D 808 87-017-437-080 DIODE,1N4148M ABCDE...............
D 803 87-017-437-080 DIODE,1N4148M ABCDE...............
D 801 87-017-437-080 DIODE,1N4148M ABCDE...............
D 806 87-017-437-080 DIODE,1N4148M ABCDE...............
D 802 87-017-437-080 DIODE,1N4148M ABCDE...............
D 804 87-017-437-080 DIODE,1N4148M ABCDE...............
D 809 87-017-437-080 DIODE,1N4148M ABCDE...............
D 810 87-017-437-080 DIODE,1N4148M ABCDE...............
D 841 87-070-136-080 ZENER,MTZJ5.1B ABCDE...............
IC 302 87-A21-145-040 C-IC,BA4560F-E2 ABCDE...............
IC 301 87-A21-145-040 C-IC,BA4560F-E2 ABCDE...............
IC 801 87-A21-145-040 C-IC,BA4560F-E2 ABCDE...............
IC 802 87-A21-145-040 C-IC,BA4560F-E2 ABCDE...............
L 1 87-007-342-010 COIL,OSC 85K BIAS ABCDE...............
L 801 87-007-342-010 COIL,OSC 85K BIAS ABCDE...............
Q 2 87-026-462-010 TR,2SC1740S ABCDE...............
Q 3 87-026-463-010 TR,2SA933S,RS ABCDE...............
Q 4 87-026-463-010 TR,2SA933S,RS ABCDE...............
Q 8 87-026-496-080 FET,2SJ103GR ABCDE...............
Q 9 87-026-496-080 FET,2SJ103GR ABCDE...............
Q 5 89-110-150-010 TR,2SA1015 ABCDE...............
Q 7 89-110-150-010 TR,2SA1015 ABCDE...............
Q 6 89-318-155-010 TR,2SC1815(GR) ABCDE...............
Q 1 89-318-155-010 TR,2SC1815(GR) ABCDE...............
Q 10 87-026-464-010 TR,DTC114TS ABCDE...............
Q 802 87-026-462-010 TR,2SC1740S ABCDE...............
Q 803 87-026-463-010 TR,2SA933S,RS ABCDE...............
Q 804 87-026-463-010 TR,2SA933S,RS ABCDE...............
Q 808 87-026-496-080 FET,2SJ103GR ABCDE...............
Q 809 87-026-496-080 FET,2SJ103GR ABCDE...............
Q 805 89-110-150-010 TR,2SA1015 ABCDE...............
Q 807 89-110-150-010 TR,2SA1015 ABCDE...............
Q 806 89-318-155-010 TR,2SC1815(GR) ABCDE...............
Q 801 89-318-155-010 TR,2SC1815(GR) ABCDE...............
Q 810 87-026-464-010 TR,DTC114TS ABCDE...............
R 40 87-029-124-010 RES,FUSE 2.2-1/4 ABCDE...............
R 840 87-029-124-010 RES,FUSE 2.2-1/4 ABCDE...............
C 299 87-010-190-080 S CHIP F 0.01 ABCDE...............
C 321 87-010-190-080 S CHIP F 0.01 ABCDE...............
C 322 87-010-263-080 CAP, ELECT 100-10V ABCDE...............
C 325 87-010-405-080 CAP, ELECT 10-50V ABCDE...............
CN 204 87-049-469-010 CONN,4P V ABCDE...............
CN 203 87-049-469-010 CONN,4P V ABCDE...............
CN 201 87-099-016-010 CONN,14P 6216V ABCDE...............
CN 207 87-099-186-010 CONN,6P EH V WHT ....................
CN 208 87-099-186-010 CONN,6P EH V WHT ....................
CN 205 87-A60-109-010 CONN,2P V S2M-2W ABCDE...............
CN 211 87-A60-111-010 CONN,5P V S2M 5W ....................
D 32 87-027-607-080 ZENER,HZ7B3L ABCDE...............
D 323 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 322 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
Q 323 87-026-291-080 TR,DTC124XS ABCDE...............
Q 322 87-026-463-080 TR,2SA933S (0.3W) ABCDE...............
Q 321 89-318-154-080 TR,2SC1815 (0.4W) ABCDE...............
C 608 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 609 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 606 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 607 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 601 87-010-313-080 CAP, CHIP 18P ABCDE...............
C 604 87-010-314-080 C-CAP,S 22P-50V ABCDE...............
C 602 87-010-315-080 C-CAP,S 27P-50 CH ABCDE...............
C 605 87-010-317-080 C-CAP,S 39P-50 CH ABCDE...............
C 603 87-010-317-080 C-CAP,S 39P-50 CH ABCDE...............
C 617 87-010-178-080 CHIP CAP 1000P ABCDE...............
C 614 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 611 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 612 87-010-248-080 CAP, ELECT 220-10V ABCDE...............
C 610 87-010-263-080 CAP, ELECT 100-10V ABCDE...............
C 615 87-010-400-080 CAP, ELECT 0.47-50V ABCDE...............
C 616 87-010-401-080 CAP, ELECT 1-50V ABCDE...............
C 613 87-010-402-080 CAP, ELECT 2.2-50V ABCDE...............
C 618 87-010-405-080 CAP, ELECT 10-50V ABCDE...............
CN 601 87-099-031-010 CONN,14P 6216 H ABCDE...............
CN 603 87-099-199-010 CONN,6P 6216 H ABCDE...............
CN 608 87-099-200-010 CONN,7P 6216H ABCDE...............
CN 604 87-099-200-010 CONN,7P 6216H ABCDE...............
CN 605 87-099-200-010 CONN,7P 6216H ABCDE...............
CN 602 87-099-200-010 CONN,7P 6216H ABCDE...............
CN 609 87-099-200-010 CONN,7P 6216H ABCDE...............
D 602 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 601 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 614 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 611 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 612 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
IC 602 87-A21-245-010 IC,RPM6938-V4 ABCDE...............
IC 601 8Z-CH4-636-010 IC,LC867132V-**** ABCDE...............

ELECTRICAL MAIN PARTS LIST - 4/6
L 601 87-003-171-010 COIL,15UH TROIDAL ABCDE...............
LCD 601 8Z-CH4-635-010 LCD,HLC7365 ZCH-4 ABCDE...............
LED 606 88-CD6-630-010 LED,934ID RED ABCDE...............
LED 602 88-CD6-630-010 LED,934ID RED ABCDE...............
LED 603 88-CD6-630-010 LED,934ID RED ABCDE...............
LED 601 88-CD6-630-010 LED,934ID RED ABCDE...............
LED 605 88-CD6-630-010 LED,934ID RED ABCDE...............
LED 604 88-CD6-630-010 LED,934ID RED ABCDE...............
LED 607 88-CD6-630-010 LED,934ID RED ABCDE...............
LED 609 88-CD6-630-010 LED,934ID RED ABCDE...............
LED 610 88-CD6-631-010 LED,934GD GRN ABCDE...............
Q 601 87-026-291-010 TR,DTC124XS ABCDE...............
Q 603 87-026-291-010 TR,DTC124XS ABCDE...............
Q 602 87-026-463-010 TR,2SA933S,RS ABCDE...............
Q 608 87-026-464-010 TR,DTC114TS ABCDE...............
Q 609 87-026-464-010 TR,DTC114TS ABCDE...............
Q 607 87-026-464-010 TR,DTC114TS ABCDE...............
Q 605 87-026-464-010 TR,DTC114TS ABCDE...............
Q 606 87-026-464-010 TR,DTC114TS ABCDE...............
Q 604 87-026-464-010 TR,DTC114TS ABCDE...............
Q 610 87-026-464-010 TR,DTC114TS ABCDE...............
Q 611 87-026-464-010 TR,DTC114TS ABCDE...............
Q 621 87-026-291-010 TR,DTC124XS ABCDE...............
S 606 87-A90-696-080 SW,TACT TS2103-03-430 ABCDE...............
S 608 87-A90-696-080 SW,TACT TS2103-03-430 ABCDE...............
S 601 87-A90-696-080 SW,TACT TS2103-03-430 ABCDE...............
S 609 87-A90-696-080 SW,TACT TS2103-03-430 ABCDE...............
S 602 87-A90-696-080 SW,TACT TS2103-03-430 ABCDE...............
S 604 87-A90-696-080 SW,TACT TS2103-03-430 ABCDE...............
S 607 87-A90-696-080 SW,TACT TS2103-03-430 ABCDE...............
S 605 87-A90-696-080 SW,TACT TS2103-03-430 ABCDE...............
S 603 87-A90-696-080 SW,TACT TS2103-03-430 ABCDE...............
S 614 87-A90-696-080 SW,TACT TS2103-03-430 ABCDE...............
S 616 87-A90-696-080 SW,TACT TS2103-03-430 ABCDE...............
S 612 87-A90-696-080 SW,TACT TS2103-03-430 ABCDE...............
S 615 87-A90-696-080 SW,TACT TS2103-03-430 ABCDE...............
S 611 87-A90-696-080 SW,TACT TS2103-03-430 ABCDE...............
S 610 87-A90-696-080 SW,TACT TS2103-03-430 ABCDE...............
S 613 87-A90-696-080 SW,TACT TS2103-03-430 ABCDE...............
X 602 87-030-273-010 VIB,XTAL 32.768K5PPM ABCDE...............
X 601 87-A70-070-080 VIB,CER 5.76MHZ CRHF ABCDE...............
C 400 87-010-178-080 CHIP CAP 1000P ABCDE...............
C 407 87-010-178-080 CHIP CAP 1000P ABCDE...............
C 402 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 405 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 409 87-010-248-080 CAP, ELECT 220-10V ABCDE...............
C 404 87-010-248-080 CAP, ELECT 220-10V ABCDE...............
C 403 87-010-263-080 CAP, ELECT 100-10V ABCDE...............
C 406 87-010-374-080 CAP, ELECT 47-10V ABCDE...............
C 401 87-010-403-080 CAP, ELECT 3.3-50V ABCDE...............
C 413 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 410 87-010-263-080 CAP, ELECT 100-10V ABCDE...............
C 412 87-010-401-080 CAP, ELECT 1-50V ABCDE...............
C 414 87-010-405-080 CAP, ELECT 10-50V ABCDE...............
C 416 87-010-545-080 CAP, ELECT 0.22-50V ABCDE...............
C 417 87-012-157-080 C-CAP,S 330P-50 CH ABCDE...............
C 425 87-010-176-080 C-CAP,S 680P-50 SL ABCDE...............
C 429 87-010-186-080 CAP,CHIP 4700P ABCDE...............
C 439 87-010-178-080 CHIP CAP 1000P ABCDE...............
C 438 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 435 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 432 87-010-374-080 CAP, ELECT 47-10V ABCDE...............
C 436 87-010-374-080 CAP, ELECT 47-10V ABCDE...............
C 433 87-010-401-080 CAP, ELECT 1-50V ABCDE...............
C 437 87-010-404-080 CAP, ELECT 4.7-50V ABCDE...............
C 431 87-010-545-080 CAP, ELECT 0.22-50V ABCDE...............
C 430 87-012-156-080 C-CAP,S 220P-50 CH ABCDE...............
C 440 87-010-147-080 C-CAP,S 3P-50 CH ABCDE...............
C 447 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 445 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 446 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 442 87-010-313-080 CAP, CHIP 18P ABCDE...............
C 448 87-010-315-080 C-CAP,S 27P-50 CH ABCDE...............
C 459 87-010-263-080 CAP, ELECT 100-10V ABCDE...............
C 457 87-010-316-080 C-CAP,S 33P-50 CH ABCDE...............
C 458 87-010-316-080 C-CAP,S 33P-50 CH ABCDE...............
C 450 87-012-140-080 CAP 470P ABCDE...............
C 463 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCDE...............
C 466 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 468 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 460 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 461 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 463 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 467 87-010-263-080 CAP, ELECT 100-10V ABCDE...............
C 462 87-010-370-080 CAP,E 330-6.3 SME ABCDE...............
C 465 87-010-404-080 CAP, ELECT 4.7-50V ABCDE...............
C 469 87-012-154-080 C-CAP,S 150P-50 CH ABCDE...............
C 473 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 474 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 471 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 472 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 475 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............

ELECTRICAL MAIN PARTS LIST - 5/6
C 477 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 479 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 476 87-010-236-080 CAP,E 1000-10 SME ABCDE...............
C 478 87-010-263-080 CAP, ELECT 100-10V ABCDE...............
C 489 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 480 87-010-221-080 CAP, ELECT 470-10V ABCDE...............
C 482 87-010-405-080 CAP, ELECT 10-50V ABCDE...............
C 481 87-010-405-080 CAP, ELECT 10-50V ABCDE...............
C 483 87-012-156-080 C-CAP,S 220P-50 CH ABCDE...............
C 484 87-012-156-080 C-CAP,S 220P-50 CH ABCDE...............
C 490 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 499 87-010-322-080 C-CAP,S 100P-50 CH ABCDE...............
C 495 87-010-322-080 C-CAP,S 100P-50 CH ABCDE...............
C 497 87-010-322-080 C-CAP,S 100P-50 CH ABCDE...............
C 498 87-010-322-080 C-CAP,S 100P-50 CH ABCDE...............
C 493 87-010-322-080 C-CAP,S 100P-50 CH ABCDE...............
C 496 87-010-322-080 C-CAP,S 100P-50 CH ABCDE...............
CN 403 87-099-195-010 CONN,7P 6216 V ABCDE...............
CN 401 87-A60-424-010 CONN,16P V TOC-B ABCDE...............
D 403 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 402 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 401 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 491 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 494 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
IC 401 87-A20-446-010 C-IC,LA9241ML ABCDE...............
IC 402 87-A20-459-010 C-IC,LC78622ED ABCDE...............
IC 404 87-A21-093-010 IC,LA6541D ABCDE...............
L 404 81-NWB-655-010 COIL,10UH TROIDAL .BC.E...............
L 405 81-NWB-655-010 COIL,10UH TROIDAL .BC.E...............
L 403 81-NWB-655-010 COIL,10UH TROIDAL .BC.E...............
L 401 87-003-102-080 COIL, 10UH ABCDE...............
L 402 87-005-847-080 COIL,2.2UH(CECS) ABCDE...............
L 406 87-005-847-080 COIL,2.2UH(CECS) ABCDE...............
L 404 87-008-372-010 FILTER, EMI BL OIRNI ...D................
L 403 87-008-372-010 FILTER, EMI BL OIRNI ...D................
L 405 87-008-372-010 FILTER, EMI BL OIRNI ...D................
Q 403 87-026-502-080 DTC144TS ABCDE...............
Q 402 89-113-184-080 TR,2SA1318T ABCDE...............
SFR 401 87-024-175-080 SEMI-FIXED RESISTOR, 47K ABCDE...............
X 401 81-592-641-010 VIB,CER 16.93MHZ ABCDE...............
X 401 87-A70-046-010 VIB,XTAL 16.934MHZ ABCDE...............
C 491 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 492 87-010-221-080 CAP, ELECT 470-10V ABCDE...............
D 492 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 491 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
D 494 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............
Q 401 87-026-463-080 TR,2SA933S (0.3W) ABCDE...............
Q 492 87-026-291-080 TR,DTC124XS ABCDE...............
Q 491 89-112-965-080 TR,2SA1296 (0.75W) ABCDE...............
C 5 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............
C 6 87-010-311-080 CAP 12P ABC.E...............
C 6 87-010-313-080 CAP, CHIP 18P ...D................
C 3 87-010-314-080 C-CAP,S 22P-50V ABCDE...............
C 1 87-010-314-080 C-CAP,S 22P-50V ABCDE...............
C 2 87-010-316-080 C-CAP,S 33P-50 CH ABCDE...............
C 7 87-012-158-080 C-CAP,S 390P-50 CH ABC.E...............
C 8 87-012-349-080 C-CAP,S 1000P-50 CH ABCDE...............
C 7 87-014-051-080 CAPACITOR (PP), 560P ...D................
C 19 87-010-112-080 CAP, ELECT 100-16V ABCDE...............
C 13 87-010-145-080 C-CAP,S 1P-50 CH ABCDE...............
C 17 87-010-194-080 CAP, CHIP 0.047 ABCDE...............
C 12 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 10 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 11 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 14 87-010-305-080 C-CAP 470P-50CH ABCDE...............
C 16 87-010-380-080 CAP, ELECT 47-16V ABCDE...............
C 15 87-012-349-080 C-CAP,S 1000P-50 CH ABCDE...............
C 18 87-015-819-080 CAPACITOR,0.01 ABCDE...............
C 22 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 21 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 26 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 23 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 20 87-010-404-080 CAP, ELECT 4.7-50V ABCDE...............
C 24 87-015-629-080 CHIP CAPACITOR, 0.0022 ABCDE...............
C 25 87-016-460-080 C-CAP,S 0.22-16 B ABCDE...............
C 29 87-016-669-080 C-CAP,S 0.1-25 K B ABCDE...............
C 28 87-016-669-080 C-CAP,S 0.1-25 K B ABCDE...............
C 27 87-A11-067-080 C-CAP,S 1-10 K B ABCDE...............
C 36 87-010-112-080 CAP, ELECT 100-16V ABCDE...............
C 37 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 31 87-010-198-080 CAP, CHIP 0.022 .BC.E...............
C 30 87-010-198-080 CAP, CHIP 0.022 .BC.E...............
C 30 87-010-213-080 C-CAP,S 0.015-50 B A..D................
C 31 87-010-213-080 C-CAP,S 0.015-50 B A..D................
C 38 87-010-380-080 CAP, ELECT 47-16V ABCDE...............
C 33 87-010-401-080 CAP, ELECT 1-50V ABCDE...............
C 34 87-010-401-080 CAP, ELECT 1-50V ABCDE...............
C 39 87-010-404-080 CAP, ELECT 4.7-50V ABCDE...............
C 35 87-015-819-080 CAPACITOR,0.01 ABCDE...............
C 48 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 47 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 46 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............

ELECTRICAL MAIN PARTS LIST - 6/6
C 40 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 44 87-010-311-080 CAP 12P ABCDE...............
C 45 87-010-312-080 C-CAP,S 15P-50 CH ABCDE...............
C 42 87-012-349-080 C-CAP,S 1000P-50 CH ABCDE...............
C 41 87-012-349-080 C-CAP,S 1000P-50 CH ABCDE...............
C 43 87-012-349-080 C-CAP,S 1000P-50 CH ABCDE...............
C 55 87-010-197-080 CAP, CHIP 0.01 DM ...D................
C 53 87-010-197-080 CAP, CHIP 0.01 DM ...D................
C 52 87-010-197-080 CAP, CHIP 0.01 DM ...D................
C 50 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............
C 51 87-010-316-080 C-CAP,S 33P-50 CH ...D................
C 54 87-014-055-080 CAP,PP 820P-100 J ...D................
CF 3 82-785-747-080 CF,MS2 GHY,R ABCDE...............
CF 2 82-785-747-080 CF,MS2 GHY,R ABCDE...............
CF 1 87-A91-094-010 FLTR,CDA10.7 MG80A ABCDE...............
CN 1 87-099-194-010 CONN,6P 6216V ABCDE...............
D 6 87-017-072-080 ZENER,HZS3B1 ABCDE...............
D 2 87-070-345-080 DIODE,IN4148 ABCDE...............
D 1 87-070-345-080 DIODE,IN4148 ABCDE...............
HD 2 88-CD6-661-010 HLDR,BAR ANT. ABCDE...............
HD 1 88-CD6-661-010 HLDR,BAR ANT. ABCDE...............
IC 1 87-A21-184-010 IC,TA2104AN ABCDE...............
IC 2 87-A21-185-040 C-IC,LC72121M ABCDE...............
L 9 87-005-849-080 COIL,10UH(CECS) ABCDE...............
L 8 87-005-849-080 COIL,10UH(CECS) ABCDE...............
L 2 87-A50-347-010 COIL,FM BPF EX ABCDE...............
L 4 87-A50-420-010 COIL,MW OSC(SYN) ABCDE...............
L 5 87-A50-424-010 COIL,FM RF EX(SYN) ABCDE...............
L 6 87-A50-427-010 COIL,FM OSC EX(SYN) ABCDE...............
L 6 87-A50-454-010 COIL,FM OSC U(SYN) ....................
L 3 87-A91-095-010 BAR-ANT,MW FOR 2B(SYN) ABC.E...............
L 3 87-A91-096-010 BAR-ANT,MW/LW FOR 3B(SYN) ...D................
L 7 87-A91-308-010 FLTR,PCFAZH- 450T (TOK) ABCDE...............
L 2 88-CD6-655-010 COIL,FM5MM*3.5T ABCDE...............
L 51 87-A50-421-010 COIL,LW OSC(SYN) ...D................
Q 1 89-319-233-080 TR,2SC1923 (0.1W) ABCDE...............
Q 54 87-026-214-080 TR,DTA114YS (0.3W) ...D................
Q 52 87-026-447-080 TR,2SC1740S R ...D................
Q 51 87-A30-092-080 FET,2SK439E/F ...D................
Q 53 89-320-011-080 TR,2SC2001 (15W) ...D................
SCR 4 87-A40-615-070 VARI-CAP,KV1311NT ABCDE...............
SCR 5 87-A40-615-070 VARI-CAP,KV1311NT ABCDE...............
SCR 3 87-A40-616-070 VARI-CAP,SVC384(S/T) ABCDE...............
TC 1 87-011-220-080 TRIMMER CAP 20P VTC ABCDE...............
TC 51 87-011-233-080 TRIMER,50P VCT54 ...D................
X 1 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 ABCDE...............

MECHANICAL PARTS LIST - 1/2
NOTE: The characters in the suffix column indicate the part usage.
HR .....................XX..................................A...................
LH1 ....................XX...................................B..................
LH .....................XX....................................C.................
EZ .....................XX.....................................D................
HA .....................XX......................................E...............
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
87-B00-020-010 BADGE,AIWA 30 GOLD ABCDE...............
88-CH6-019-010 PANEL,CD ABCDE...............
8Z-CH4-002-110 CABI,REAR ....................
8Z-CH4-003-010 CHAS,CD ABCDE...............
8Z-CH4-005-010 WINDOW,CD ABCDE...............
8Z-CH4-007-010 WINDOW,CASS ABCDE...............
8Z-CH4-008-010 LID,BATT ABCDE...............
8Z-CH4-009-010 HANDL,ARM ABCDE...............
8Z-CH4-010-010 HANDL,GRIP ABCDE...............
8Z-CH4-013-010 PANEL,LCD21 ....................
8Z-CH4-019-110 CABI,TOP 2L ABCDE...............
8Z-CH4-020-110 CABI,TOP 2R ABCDE...............
8Z-CH4-030-110 COVER, PH ABCDE...............
8Z-CH4-064-010 WINDOW,LCD EZ ....................
8Z-CHE-001-010 CABI,FR 14 ....................
8Z-CHE-002-010 CABI,FR 14A A.CDE...............
8Z-CHE-003-010 BOX,CASS 14 ABCDE...............
8Z-CHE-004-010 WINDOW,LED 14 ....................
8Z-CHE-006-010 WINDOW,LED 14LH .BC.E...............
8Z-CHE-007-010 CABI,REAR 10W ....................
8Z-CHE-008-010 BOX,CD 14 ABCDE...............
8Z-CHE-009-010 PANEL,LCD21 14 ABCDE...............
8Z-CHE-011-010 WINDOW,LCD 14 ABC.E...............
8Z-CHE-012-010 WINDOW,LCD 14EZ ...D................
8Z-CHE-014-010 GRILLE,FR L 14 ABCDE...............
8Z-CHE-015-010 GRILLE,FR R 14 ABCDE...............
8Z-CHE-016-010 GRILLE,TOP L 14 ABCDE...............
8Z-CHE-017-010 GRILLE,TOP R 14 ABCDE...............
8Z-CHE-018-010 WINDOW,LED 14A A..D................
8Z-CHE-019-010 CABI,FR 14B .B..................
8Z-CHE-020-010 CABI,FR 14C ....................
8Z-CHE-021-010 BOX,CD 14A ....................
8Z-CHE-022-010 BOX,CASS 14A ....................
8Z-CHE-024-010 CABI,TOP 2L A ....................
8Z-CHE-025-010 CABI,TOP 2R A ....................
8Z-CHE-026-010 COVER, PH A ....................
8Z-CHE-027-010 LID,BATT A ....................
8Z-CHE-028-010 HANDL,ARM A ....................
8Z-CHE-029-010 HANDL,GRIP A ....................
8Z-CHE-032-010 CABI,REAR LH ABCDE...............
8Z-CHG-011-010 WINDOW,LED 16A ....................
8Z-CHR-013-010 GRILLE,FR L 24 ....................
8Z-CHR-014-010 GRILLE,FR R 24 ....................
8Z-CHR-015-010 GRILLE,TOP L 24 ....................
8Z-CHR-016-010 GRILLE,TOP R 24 ....................
8Z-CH4-023-110 BTN,VOL ABCDE...............
8Z-CH4-024-010 BTN,CD ABCDE...............
8Z-CH4-025-010 BTN,REPEAT ABCDE...............
8Z-CH4-026-010 BTN,FUNC ABCDE...............
8Z-CH4-027-010 BTN,EQ ABCDE...............
8Z-CH4-028-010 KEY,CASS 21 ABCDE...............
8Z-CH4-031-010 BTN,POWER-SAVE ....................
87-CD6-041-010 PLATE,AC ...D................
84-CD5-215-010 GEAR ABCDE...............
84-CD5-216-010 BRACKET ABCDE...............
84-CD5-217-010 PLATE,MAGNET ABCDE...............
85-CD7-217-010 HLDR,CHUCK A ABCDE...............
86-CT4-218-010 CUSHION,FOOT/PORON ABCDE...............
87-036-368-010 MAGNET ABCDE...............
87-A91-151-010 SW,LEAF 1P2T/TC48-021 ABCDE...............
87-CD6-213-010 SPR-C,BATT (-) ABCDE...............
87-CD6-214-010 SPR-C,BATT LINK ABCDE...............
87-CD6-222-010 SPR-C,BATT (-) L ABCDE...............
87-CD6-223-010 SPR-C,BATT LINK L ABCDE...............
88-CH6-207-010 HLDR,ANT ABCDE...............
88-CH6-220-010 CUSHION,CD A ABCDE...............
8Z-CH4-201-010 HLDR,LCD ABCDE...............
8Z-CH4-204-010 HLDR,SPEAKER ABCDE...............
8Z-CH4-205-010 SPR-T,CASS ABCDE...............
8Z-CH4-206-010 SPR-T,CD ABCDE...............
8Z-CH4-207-010 HLDR,OIL-DMPR ABCDE...............
8Z-CH4-208-010 HLDR,PWB ABCDE...............
8Z-CH4-209-010 HLDR,PT ABCDE...............
8Z-CH4-210-010 HLDR,LED ABCDE...............
8Z-CH4-211-010 BASE,CHUCK ABCDE...............
8Z-CH4-212-010 RING,CHUCK ABCDE...............
8Z-CH4-214-010 HLDR,REC-SW 21 ABCDE...............
8Z-CH4-216-010 HLDR,FUNC-PWB ABCDE...............
8Z-CH4-217-010 HLDR,PT A ....................
87-067-566-010 TAPPING SCREW, VFTT+3-6 ABCDE...............
87-254-097-410 U+3-12 CR ABCDE...............
87-261-037-410 V+2-10 GLD ABCDE...............

MECHANICAL PARTS LIST - 2/2
87-342-074-010 UT2+2.6-8 ABCDE...............
87-571-032-410 VIT+2-3 ABCDE...............
87-644-096-410 UT1+3-10 CR ABCDE...............
87-661-100-410 VFT1+3-16 ABCDE...............
87-741-095-410 UT2+3-8 GLD ABCDE...............
87-751-094-410 VT2+3-6 W10SL0T ABCDE...............
* 87-751-075-410 VT2+2.6-10 ABCDE...............
* 87-B10-239-010 QT2+3-8 W/O CR ABCDE...............
* 87-B10-242-010 UT2+3-30 W/O CR ABCDE...............
87-035-192-010 FUSE, 4AT ....................
87-035-347-010 FUSE,2.5A 250V T ABC.E...............
87-036-389-010 SW,PUSH LOCK ABCDE...............
87-A60-177-010 JACK,AC U W/SW ....................
87-A60-178-010 JACK,AC E W/SW ABCDE...............
87-A90-092-080 PROTECTOR,2.5A 491 ...D................
87-A91-369-010 SW,AC SL 2 2 2 SDKGA41700 ABC.E...............
88-CH6-626-010 PT,U ....................
88-CH6-627-010 PT,E ...D................
88-CH6-628-010 PT,H ABC.E...............
8Z-CH4-614-010 CONN ASSY,6P CD-ME ABCDE...............
8Z-CH4-618-010 FF-CABLE, 16P CD-RF ABCDE...............
8Z-CH4-620-010 FF-CABLE, 7P FR-LED ABCDE...............
8Z-CH4-621-010 FF-CABLE, 7P CD-FR ABCDE...............
8Z-CH4-640-010 ANT,ROD ABCDE...............
8Z-CH4-645-010 SPKR,MAYLOR 8OHM SILVER ABCDE...............
8Z-CH4-663-010 PT,E (75-35) ....................
8Z-CH4-664-010 SPKR,10 6OHM ....................
8Z-CH4-665-010 SPKR,MAYLOR 8OHM (2.0W) ....................
8Z-CH4-667-010 CONN ASSY,6P I-AMP ....................
8Z-CH4-668-010 CONN ASSY,6P O-AMP ....................
8Z-CH4-669-010 CONN ASSY,5P S-PWR ....................
SP 0 88-CD5-602-010 SPKR 4’3.2 ABC.E...............
SP 0 88-CD5-603-010 SPKR,10 7OHM ...D................
W 0 8Z-CH4-619-010 FF-CABLE, 14P AF-FR ABCDE...............
W 0 8Z-CH4-622-010 FF-CABLE, 6P TU-FR ABCDE...............

ACCESSORIES / PACKAGE LIST - 1/1
NOTE: The characters in the suffix column indicate the part usage.
HR .....................XX..................................A...................
LH1 ....................XX...................................B..................
LH .....................XX....................................C.................
EZ .....................XX.....................................D................
HA .....................XX......................................E...............
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-CH4-908-010 IB,EZ(9L)B ...D................
8Z-CH4-918-010 IB,EZ(9L)FM ....................
8Z-CHE-905-010 IB,U(ESF)B ....................
8Z-CHE-907-010 IB,HR(ECA)B A...................
8Z-CHE-908-010 IB,EZ(9L)B,90 ....................
8Z-CHE-909-010 IB,K(E)B,90 ....................
8Z-CHE-915-010 IB,U(ESF)FM ....................
8Z-CHE-917-010 IB,HR(ECA)FM ....................
8Z-CHG-906-010 IB,LH(ESP)B ..C.E...............
8Z-CHG-916-010 IB,LH(ESP)FM ....................
87-A80-034-010 AC CORD SET ASSY,K W/F MAY-BG ....................
87-A80-036-010 AC CORD SET ASSY,E W/FLTR VOL ABCD................
87-A80-109-010 AC CORD,HK7281 BLK U ....................
87-A80-119-010 AC CORD SET ASSY,AZ ....E...............
87-A90-312-010 PLUG,CONVERSION WTN-1157R1 ABC.E...............
8Z-CK4-962-010 RC UNIT,RC-ZAT04 (VS) ABCDE...............

SCHEMATIC DIAGRAM _1 (MAIN 1/2)

SCHEMATIC DIAGRAM _2 (MAIN 2/2)

SCHEMATIC DIAGRAM _3 (CD)

SCHEMATIC DIAGRAM _4 (FRONT)

SCHEMATIC DIAGRAM _5 (EXCEPT EZ : TUNER)

SCHEMATIC DIAGRAM _6 (EZ : TUNER)

PrintedinSingapore
Tokyo Japan
4
9630472
