S E R V I C E M A N U A L

SIMPLE MANUAL

•Replace this Service Manual with "Revision Publishing" when it is issued.

CSD-SL20

• TYPE : U

S/M Code No. 09–992–410–5T1

COMPACT DISC STEREO

CASSETTE RECORDER

ELECTRICAL MAIN PARTS LIST - 1/4

NOTE: The characters in the suffix column indicate the part usage.

U ......................XX..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

88-CD7-609-010 CONN,4P V A...................

8Z-CD7-613-010 CONN,2P V WHT A...................

C 456 87-010-197-080 0E CAP, CHIP 0.01 DM A...................

C 457 87-010-198-080 0E CAP, CHIP 0.022 A...................

C 459 87-010-198-080 0E CAP, CHIP 0.022 A...................

C 458 87-010-198-080 0E CAP, CHIP 0.022 A...................

C 455 87-010-248-080 0E CAP, ELECT 220-10V A...................

C 453 87-010-384-080 0E CAP, ELECT 100-25V A...................

C 454 87-010-385-080 0E CAP, ELECT 220-25V A...................

C 464 87-010-198-080 0E CAP, CHIP 0.022 A...................

C 460 87-010-198-080 0E CAP, CHIP 0.022 A...................

C 463 87-010-198-080 0E CAP, CHIP 0.022 A...................

C 468 87-010-235-080 0E CAP,E 470-16 SME A...................

C 465 87-010-260-080 0E CAP, ELECT 47-25V A...................

C 467 87-010-401-080 0E CAP, ELECT 1-50V A...................

C 466 87-010-404-080 0E CAP, ELECT 4.7-50V A...................

C 462 87-010-405-080 0E CAP, ELECT 10-50V A...................

C 461 87-010-453-090 1C CAP ELECT 4700-25V SME A...................

C 473 87-010-197-080 0E CAP, CHIP 0.01 DM A...................

C 472 87-010-248-080 0E CAP, ELECT 220-10V A...................

C 471 87-010-263-080 0E CAP, ELECT 100-10V A...................

C 474 87-010-263-080 0E CAP, ELECT 100-10V A...................

D 402 87-017-139-010 0E ZENER,HZS15-2 A...................

D 409 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 408 87-070-136-080 0E ZENER,MTZJ5.1B A...................

D 404 87-A40-465-010 0E DIODE,FR202 A...................

D 407 87-A40-465-010 0E DIODE,FR202 A...................

D 406 87-A40-465-010 0E DIODE,FR202 A...................

D 405 87-A40-465-010 0E DIODE,FR202 A...................

D 403 87-A40-465-010 0E DIODE,FR202 A...................

D 413 87-017-148-080 0E ZENER,HZS6A1L A...................

D 410 87-017-161-080 0E ZENER,HZS7C2L A...................

D 416 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 412 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 417 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 414 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 415 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 411 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 418 87-027-607-080 0E ZENER,HZ7B3L A...................

IC 403 87-070-416-010 1B IC,NJU7201 L55 A...................

Q 406 87-026-291-080 1A TR,DTC124XS A...................

Q 403 87-026-462-080 0E TR,2SC1740 S(RS 0.3W) A...................

Q 408 87-026-462-080 0E TR,2SC1740 S(RS 0.3W) A...................

Q 405 87-026-463-080 0E TR,2SA933S (0.3W) A...................

Q 404 89-112-965-080 0E TR,2SA1296 (0.75W) A...................

Q 409 89-113-184-080 0E TR,2SA1318T A...................

Q 407 89-213-702-010 1A TR,2SB1370 (1.8W) A...................

Q 412 87-026-291-080 1A TR,DTC124XS A...................

Q 412 87-026-462-080 0E TR,2SC1740 S(RS 0.3W) A...................

Q 411 87-026-463-080 0E TR,2SA933S (0.3W) A...................

Q 413 89-318-154-080 0E TR,2SC1815 (0.4W) A...................

R 453 87-029-124-090 0E RESISTOR, FUSE 1/4W 2.2 A...................

88-CD7-610-010 CONN,3P V A...................

C 206 87-010-177-080 0E C-CAP,S 820P-50 SL A...................

C 201 87-010-177-080 0E C-CAP,S 820P-50 SL A...................

C 202 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 203 87-010-374-080 0E CAP, ELECT 47-10V A...................

C 207 87-010-379-080 0E CAP, ELECT 22-16V A...................

C 205 87-010-379-080 0E CAP, ELECT 22-16V A...................

C 204 87-010-402-080 0E CAP, ELECT 2.2-50V A...................

C 208 87-010-404-080 0E CAP, ELECT 4.7-50V A...................

C 209 87-012-158-080 0E C-CAP,S 390P-50 CH A...................

C 217 87-010-177-080 0E C-CAP,S 820P-50 SL A...................

C 219 87-010-198-080 0E CAP, CHIP 0.022 A...................

C 218 87-010-374-080 0E CAP, ELECT 47-10V A...................

C 211 87-010-402-080 0E CAP, ELECT 2.2-50V A...................

C 216 87-010-402-080 0E CAP, ELECT 2.2-50V A...................

C 212 87-010-402-080 0E CAP, ELECT 2.2-50V A...................

C 213 87-010-404-080 0E CAP, ELECT 4.7-50V A...................

C 215 87-012-158-080 0E C-CAP,S 390P-50 CH A...................

C 220 87-010-186-080 0E CAP,CHIP 4700P A...................

C 227 87-010-197-080 0E CAP, CHIP 0.01 DM A...................

C 228 87-010-197-080 0E CAP, CHIP 0.01 DM A...................

C 229 87-010-401-080 0E CAP, ELECT 1-50V A...................

C 226 87-010-401-080 0E CAP, ELECT 1-50V A...................

C 223 87-010-404-080 0E CAP, ELECT 4.7-50V A...................

C 225 87-010-405-080 0E CAP, ELECT 10-50V A...................

C 222 87-012-153-080 0E C-CAP,S 120P-50 CH A...................

C 236 87-010-186-080 0E CAP,CHIP 4700P A...................

C 234 87-010-374-080 0E CAP, ELECT 47-10V A...................

C 239 87-010-379-080 0E CAP, ELECT 22-16V A...................

C 235 87-010-400-080 0E CAP, ELECT 0.47-50V A...................

C 237 87-010-404-080 0E CAP, ELECT 4.7-50V A...................

C 230 87-010-405-080 0E CAP, ELECT 10-50V A...................

C 232 87-012-153-080 0E C-CAP,S 120P-50 CH A...................

C 243 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

ELECTRICAL MAIN PARTS LIST - 2/4

C 244 87-010-248-080 0E CAP, ELECT 220-10V A...................

C 246 87-010-374-080 0E CAP, ELECT 47-10V A...................

C 245 87-010-405-080 0E CAP, ELECT 10-50V A...................

CN 2 88-CD7-609-010 CONN,4P V A...................

D 208 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 201 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 204 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 202 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 207 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 209 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 203 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 206 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 205 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 211 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 210 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 212 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

IC 202 87-A21-145-040 C-IC,BA4560F-E2 A...................

IC 201 87-A21-145-040 C-IC,BA4560F-E2 A...................

L 201 87-007-342-010 0E COIL,OSC 85K BIAS A...................

Q 201 87-026-496-080 0E FET,2SJ103GR A...................

Q 202 87-026-496-080 0E FET,2SJ103GR A...................

Q 208 89-110-155-080 0E TR,2SA1015(0.4W) A...................

Q 206 89-110-155-080 0E TR,2SA1015(0.4W) A...................

Q 204 89-318-155-010 0E TR,2SC1815(GR) A...................

Q 205 89-318-155-010 0E TR,2SC1815(GR) A...................

Q 203 89-318-155-010 0E TR,2SC1815(GR) A...................

Q 207 89-318-155-010 0E TR,2SC1815(GR) A...................

Q 209 89-318-155-010 0E TR,2SC1815(GR) A...................

Q 211 89-318-154-080 0E TR,2SC1815 (0.4W) A...................

Q 210 89-318-154-080 0E TR,2SC1815 (0.4W) A...................

C 608 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 601 87-010-197-080 0E CAP, CHIP 0.01 DM A...................

C 605 87-010-313-080 0E CAP, CHIP 18P A...................

C 604 87-010-315-080 0E C-CAP,S 27P-50 CH A...................

C 603 87-010-317-080 0E C-CAP,S 39P-50 CH A...................

C 602 87-010-317-080 0E C-CAP,S 39P-50 CH A...................

C 609 87-010-385-080 0E CAP, ELECT 220-25V A...................

C 606 87-010-400-080 0E CAP, ELECT 0.47-50V A...................

C 607 87-010-401-080 0E CAP, ELECT 1-50V A...................

D 602 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 601 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 604 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 603 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 606 87-A40-622-010 LED,L-34HDSL RED A...................

D 601 87-A40-623-010 LED,L-34GDSL GRN A...................

D 603 87-A40-623-010 LED,L-34GDSL GRN A...................

D 605 87-A40-623-010 LED,L-34GDSL GRN A...................

D 602 87-A40-623-010 LED,L-34GDSL GRN A...................

D 604 87-A40-623-010 LED,L-34GDSL GRN A...................

IC 601 8Z-CD5-636-010 1H IC,LC865508A-**** A...................

LED 2 87-A91-172-010 LED, SA36-11HWA-11.0MM RED A...................

Q 28 87-026-464-080 0E TR,DTC114TS (0.3W) A...................

Q 606 87-026-291-080 1A TR,DTC124XS A...................

Q 608 87-026-291-080 1A TR,DTC124XS A...................

Q 607 87-026-463-080 0E TR,2SA933S (0.3W) A...................

Q 609 87-026-463-080 0E TR,2SA933S (0.3W) A...................

Q 603 87-026-464-080 0E TR,DTC114TS (0.3W) A...................

Q 605 87-026-464-080 0E TR,DTC114TS (0.3W) A...................

Q 604 87-026-464-080 0E TR,DTC114TS (0.3W) A...................

Q 601 87-026-464-080 0E TR,DTC114TS (0.3W) A...................

S 605 87-A90-770-080 SW,TACT TRT134-L4.3 A...................

S 601 87-A90-770-080 SW,TACT TRT134-L4.3 A...................

S 609 87-A90-770-080 SW,TACT TRT134-L4.3 A...................

S 606 87-A90-770-080 SW,TACT TRT134-L4.3 A...................

S 603 87-A90-770-080 SW,TACT TRT134-L4.3 A...................

S 608 87-A90-770-080 SW,TACT TRT134-L4.3 A...................

S 607 87-A90-770-080 SW,TACT TRT134-L4.3 A...................

S 604 87-A90-770-080 SW,TACT TRT134-L4.3 A...................

S 602 87-A90-770-080 SW,TACT TRT134-L4.3 A...................

S 612 87-A90-770-080 SW,TACT TRT134-L4.3 A...................

S 611 87-A90-770-080 SW,TACT TRT134-L4.3 A...................

S 610 87-A90-770-080 SW,TACT TRT134-L4.3 A...................

S 613 87-A90-770-080 SW,TACT TRT134-L4.3 A...................

X 601 87-030-273-010 1A VIB,XTAL 32.768K5PPM A...................

X 602 87-030-376-080 1A VIB,CER CSA5.76MG200 A...................

88-CD7-609-010 CONN,4P V A...................

88-CD7-610-010 CONN,3P V A...................

8Z-CD7-616-010 CONN,13P V 5124NBHPB A...................

8Z-CD7-617-010 CONN,13P H 3094 A...................

C 401 87-010-401-080 0E CAP, ELECT 1-50V A...................

C 402 87-010-401-080 0E CAP, ELECT 1-50V A...................

C 407 87-010-401-080 0E CAP, ELECT 1-50V A...................

C 408 87-012-141-080 0E CHIP-CAPACITOR,0.22-16F A...................

C 418 87-010-197-080 0E CAP, CHIP 0.01 DM A...................

C 416 87-010-380-080 0E CAP, ELECT 47-16V A...................

C 411 87-010-400-080 0E CAP, ELECT 0.47-50V A...................

C 410 87-010-400-080 0E CAP, ELECT 0.47-50V A...................

C 414 87-010-401-080 0E CAP, ELECT 1-50V A...................

C 415 87-010-402-080 0E CAP, ELECT 2.2-50V A...................

C 419 87-010-403-080 0E CAP, ELECT 3.3-50V A...................

C 417 87-010-405-080 0E CAP, ELECT 10-50V A...................

C 413 87-012-141-080 0E CHIP-CAPACITOR,0.22-16F A...................

C 426 87-010-112-080 0E CAP, ELECT 100-16V A...................

C 427 87-010-112-080 0E CAP, ELECT 100-16V A...................

C 425 87-010-112-080 0E CAP, ELECT 100-16V A...................

C 428 87-010-112-080 0E CAP, ELECT 100-16V A...................

C 429 87-010-235-080 0E CAP,E 470-16 SME A...................

C 424 87-010-235-080 0E CAP,E 470-16 SME A...................

C 423 87-010-235-080 0E CAP,E 470-16 SME A...................

C 420 87-010-403-080 0E CAP, ELECT 3.3-50V A...................

C 430 87-010-112-080 0E CAP, ELECT 100-16V A...................

C 433 87-010-401-080 0E CAP, ELECT 1-50V A...................

C 434 87-010-402-080 0E CAP, ELECT 2.2-50V A...................

C 435 87-010-402-080 0E CAP, ELECT 2.2-50V A...................

C 439 87-010-404-080 0E CAP, ELECT 4.7-50V A...................

C 436 87-010-544-080 0E CAP, ELECT 0.1-50V A...................

C 437 87-010-546-080 0E CAP, ELECT 0.33-50V A...................

C 443 87-010-263-080 0E CAP, ELECT 100-10V A...................

C 444 87-010-380-080 0E CAP, ELECT 47-16V A...................

C 448 87-010-404-080 0E CAP, ELECT 4.7-50V A...................

C 442 87-010-405-080 0E CAP, ELECT 10-50V A...................

C 449 87-010-405-080 0E CAP, ELECT 10-50V A...................

C 441 87-010-405-080 0E CAP, ELECT 10-50V A...................

C 440 87-010-405-080 0E CAP, ELECT 10-50V A...................

C 446 87-010-544-080 0E CAP, ELECT 0.1-50V A...................

C 445 87-010-546-080 0E CAP, ELECT 0.33-50V A...................

C 451 87-010-405-080 0E CAP, ELECT 10-50V A...................

C 450 87-010-405-080 0E CAP, ELECT 10-50V A...................

D 401 87-A40-466-080 0E ZENER,MTZJ2.7A A...................

IC 401 87-A20-946-040 1D C-IC,MM1434XF A...................

IC 404 87-A21-111-040 1C C-IC,M62495FP A...................

IC 402 87-A21-193-010 1B IC,TA8227P A...................

J 601 8Z-CD7-610-010 JACK,3.5 ST W/SW A...................

Q 401 89-320-011-080 0E TR,2SC2001 (15W) A...................

Q 402 89-320-011-080 0E TR,2SC2001 (15W) A...................

C 101 87-010-403-080 0E CAP, ELECT 3.3-50V A...................

C 102 87-010-545-080 0E CAP, ELECT 0.22-50V A...................

C 111 87-010-176-080 0E C-CAP,S 680P-50 SL A...................

C 119 87-010-184-080 0E CHIP CAPACITOR 3300P(K) A...................

C 113 87-010-186-080 0E CAP,CHIP 4700P A...................

C 117 87-010-374-080 0E CAP, ELECT 47-10V A...................

C 115 87-010-400-080 0E CAP, ELECT 0.47-50V A...................

C 118 87-010-401-080 0E CAP, ELECT 1-50V A...................

C 116 87-012-140-080 0E CAP 470P A...................

C 114 87-012-156-080 0E C-CAP,S 220P-50 CH A...................

C 121 87-010-145-080 0E C-CAP,S 1P-50 CH A...................

C 128 87-010-263-080 0E CAP, ELECT 100-10V A...................

C 122 87-010-312-080 0E C-CAP,S 15P-50 CH A...................

C 126 87-010-374-080 0E CAP, ELECT 47-10V A...................

C 125 87-010-404-080 0E CAP, ELECT 4.7-50V A...................

C 127 87-010-405-080 0E CAP, ELECT 10-50V A...................

C 123 87-010-544-080 0E CAP, ELECT 0.1-50V A...................

C 138 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 139 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 136 87-010-197-080 0E CAP, CHIP 0.01 DM A...................

C 133 87-010-198-080 0E CAP, CHIP 0.022 A...................

C 132 87-010-248-080 0E CAP, ELECT 220-10V A...................

C 134 87-010-248-080 0E CAP, ELECT 220-10V A...................

C 135 87-010-374-080 0E CAP, ELECT 47-10V A...................

C 137 87-010-401-080 0E CAP, ELECT 1-50V A...................

C 130 87-010-544-080 0E CAP, ELECT 0.1-50V A...................

C 142 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 140 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 148 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 149 87-010-316-080 0E C-CAP,S 33P-50 CH A...................

C 147 87-010-374-080 0E CAP, ELECT 47-10V A...................

C 146 87-010-405-080 0E CAP, ELECT 10-50V A...................

C 145 87-010-405-080 0E CAP, ELECT 10-50V A...................

C 141 87-012-154-080 0E C-CAP,S 150P-50 CH A...................

C 154 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 151 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 153 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 152 87-010-263-080 0E CAP, ELECT 100-10V A...................

C 150 87-010-316-080 0E C-CAP,S 33P-50 CH A...................

C 158 87-010-545-080 0E CAP, ELECT 0.22-50V A...................

C 178 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 179 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 171 87-010-197-080 0E CAP, CHIP 0.01 DM A...................

C 174 87-010-197-080 0E CAP, CHIP 0.01 DM A...................

C 177 87-010-221-080 0E CAP, ELECT 470-10V A...................

C 176 87-010-221-080 0E CAP, ELECT 470-10V A...................

C 173 87-010-248-080 0E CAP, ELECT 220-10V A...................

C 172 87-010-401-080 0E CAP, ELECT 1-50V A...................

C 181 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 180 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 182 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 196 87-010-178-080 0E CHIP CAP 1000P A...................

C 199 87-010-197-080 0E CAP, CHIP 0.01 DM A...................

C 192 87-010-315-080 0E C-CAP,S 27P-50 CH A...................

C 194 87-010-322-080 0E C-CAP,S 100P-50 CH A...................

C 193 87-012-140-080 0E CAP 470P A...................

C 195 87-012-153-080 0E C-CAP,S 120P-50 CH A...................

C 197 87-012-156-080 0E C-CAP,S 220P-50 CH A...................

C 191 87-012-156-080 0E C-CAP,S 220P-50 CH A...................

ELECTRICAL MAIN PARTS LIST - 3/4

CN 102 87-A60-248-010 0E CONN,16P H CFF1416 A...................

CN 601 87-009-030-010 0E CONNECTOR 2P PH M _ A...................

D 48 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 101 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 102 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 106 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

IC 101 87-A20-446-010 1E C-IC,LA9241ML A...................

IC 102 87-A20-459-010 2A C-IC,LC78622ED A...................

IC 104 87-A20-856-010 1D IC,BA6898S A...................

L 101 87-005-730-080 0E COIL,10UH J SP02 A...................

Q 105 87-026-291-080 1A TR,DTC124XS A...................

Q 101 87-026-463-080 0E TR,2SA933S (0.3W) A...................

Q 108 87-026-464-080 0E TR,DTC114TS (0.3W) A...................

Q 106 89-112-965-080 0E TR,2SA1296 (0.75W) A...................

Q 107 89-113-184-080 0E TR,2SA1318T A...................

X 101 81-592-641-080 1A CERALOCK 16.93MHZ A...................

C 709 87-010-188-080 0E CAP,CHIP 6800P A...................

C 703 87-010-194-080 0E CAP, CHIP 0.047 A...................

C 702 87-010-194-080 0E CAP, CHIP 0.047 A...................

C 707 87-010-197-080 0E CAP, CHIP 0.01 DM A...................

C 706 87-010-197-080 0E CAP, CHIP 0.01 DM A...................

C 708 87-010-197-080 0E CAP, CHIP 0.01 DM A...................

C 704 87-010-248-080 0E CAP, ELECT 220-10V A...................

C 701 87-010-378-080 0E CAP, ELECT 10-16V A...................

C 705 87-010-379-080 0E CAP, ELECT 22-16V A...................

C 710 87-010-188-080 0E CAP,CHIP 6800P A...................

C 719 87-010-197-080 0E CAP, CHIP 0.01 DM A...................

C 718 87-010-198-080 0E CAP, CHIP 0.022 A...................

C 717 87-010-314-080 0E C-CAP,S 22P-50V A...................

C 716 87-010-544-080 0E CAP, ELECT 0.1-50V A...................

C 715 87-010-545-080 0E CAP, ELECT 0.22-50V A...................

C 712 87-010-545-080 0E CAP, ELECT 0.22-50V A...................

C 720 87-010-194-080 0E CAP, CHIP 0.047 A...................

C 729 87-010-197-080 0E CAP, CHIP 0.01 DM A...................

C 725 87-010-314-080 0E C-CAP,S 22P-50V A...................

C 724 87-010-314-080 0E C-CAP,S 22P-50V A...................

C 723 87-010-316-080 0E C-CAP,S 33P-50 CH A...................

C 727 87-010-400-080 0E CAP, ELECT 0.47-50V A...................

C 728 87-010-403-080 0E CAP, ELECT 3.3-50V A...................

C 726 87-010-544-080 0E CAP, ELECT 0.1-50V A...................

C 733 87-010-148-080 0E CAP, CHIP S 75P SL A...................

C 737 87-010-154-080 0E CAP CHIP 10P A...................

C 735 87-010-182-080 0E C-CAP,S 2200P-50 B A...................

C 738 87-010-182-080 0E C-CAP,S 2200P-50 B A...................

C 734 87-010-400-080 0E CAP, ELECT 0.47-50V A...................

C 750 87-010-178-080 0E CHIP CAP 1000P A...................

C 751 87-010-318-080 0E C-CAP,S 47P-50 CH A...................

C 752 87-012-155-080 0E C-CAP 180P-50CH A...................

CF 701 87-008-261-010 1A FILTER, SFE10.7MA5-A A...................

CF 702 87-008-261-010 1A FILTER, SFE10.7MA5-A A...................

CF 703 87-A91-150-010 FLTR, CFAL-455(TOKO) A...................

D 701 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 710 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 711 87-020-465-080 0E DIODE,1SS133 (110MA) A...................

D 712 87-A40-226-080 0E VARI-CAP,SVC251SPA A...................

IC 702 87-A20-955-010 1C IC,LA1828 A...................

L 709 87-A50-334-010 1A COIL,FM DET (TOKO) A...................

L 703 87-A50-335-010 1A COIL,FM IFT (TOKO) A...................

L 704 87-A50-336-010 1A COIL,AM IFT (TOKO) A...................

L 705 87-A50-337-010 1A COIL,AM OSC (TOKO) A...................

L 707 87-A50-347-010 COIL,FM BPF EX A...................

L 706 87-A50-349-010 COIL,BAR ANT AMW (COI) A...................

L 710 87-A50-343-010 COIL,FM OSC EX A...................

L 711 87-A50-345-010 COIL,FM RF EX A...................

L 720 87-003-102-080 0E COIL, 10UH A...................

Q 703 87-026-215-080 0E TR,DTC114YS A...................

Q 702 87-026-572-080 0E TR,DTA114TS A...................

Q 701 89-110-155-080 0E TR,2SA1015(0.4W) A...................

Q 704 89-318-155-010 0E TR,2SC1815(GR) A...................

Q 705 89-319-233-080 0E TR,2SC1923 (0.1W) A...................

S 201 88-CD7-629-010 SW,SL-2-3 MO/ST A...................

S 702 88-CD7-628-010 SW,SL-2-2 BAND A...................

VC 701 87-A90-984-010 TUN-CAP,20P-160P U (TOKO) A...................

ELECTRICAL MAIN PARTS LIST - 4/4

MECHANICAL PARTS LIST - 1/1

NOTE: The characters in the suffix column indicate the part usage.

U ......................XX..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-CS7-002-010 CABI,REAR A...................

8Z-CS7-004-010 LID,CASS A...................

8Z-CS7-014-010 HANDL, A...................

8Z-CS7-016-010 GRILLE,SPKR(L) A...................

8Z-CS7-017-010 GRILLE,SPKR(R) A...................

8Z-CS7-021-010 WINDOW,CASS EX A...................

8Z-CS7-022-010 CABI,FRONT EX A...................

8Z-CS7-023-010 PANEL,TOP EX A...................

8Z-CS7-027-010 LID,BATT A...................

8Z-CS7-006-010 KEY,Q-SOUND A...................

8Z-CS7-007-010 KEY,CASS STOP A...................

8Z-CS7-008-010 KEY,CASS FFWD A...................

8Z-CS7-009-010 KEY,CASS REW A...................

8Z-CS7-010-010 KEY,CASS PLAY A...................

8Z-CS7-011-010 KEY,CASS REC A...................

8Z-CS7-012-010 KNOB,SL FUNCTION A...................

8Z-CS7-013-010 KNOB,RTRY VOLUME A...................

8Z-CS7-015-010 BTN,TUNING A...................

8Z-CS7-018-010 BTN,PRESET A...................

8Z-CS7-019-010 BTN,BAND A...................

86-CS9-207-010 SPR-P,CASS A...................

88-CS7-203-010 COVER, BATT(L) A...................

88-CS7-204-010 COVER, BATT(R) A...................

88-CS7-209-010 SPR-P,DOOR CASS A...................

88-CS7-211-010 SPR,BATT A(-) A...................

88-CS7-215-010 SPR-P,REC A...................

88-CS8-213-010 HLDR,SPEAKR A...................

88-CS8-214-010 HLDR,BAR ANT A...................

8Z-CS7-201-010 HLDR,DISPLAY A...................

8Z-CS7-202-010 COVER, PCB A...................

* 88-CS7-212-010 PLATE,CONTACT A...................

87-254-094-410 U+3-6 CR A...................

87-741-033-410 UT2+2-4 GLD W/O SLOT A...................

87-741-073-410 UT2+2.6-6 GLD A...................

87-741-074-410 UT2+2.6-8 A...................

87-741-095-410 UT2+3-8 GLD A...................

87-741-096-410 UT2+3-10 A...................

87-741-097-410 UT2+3-12 A...................

87-B10-114-010 VT2+2-12 CR A...................

88-CS7-626-010 ANT,ROD P7 TYPE A...................

88-CS8-625-010 MIC,ECM A...................

SP 1 88-CS7-625-010 SPKR,55MM 4OHM A...................

SP 2 88-CS7-625-010 SPKR,55MM 4OHM A...................

87-A60-420-010 JACK,3.5 ST (MSC) A...................

ACCESSORIES / PACKAGE LIST - 1/1

NOTE: The characters in the suffix column indicate the part usage.

U ......................XX..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-CS7-905-010 IB,U(ESF) A...................

8Z-CS7-907-010 IB,HE(ECA) ....................

8Z-CS7-908-010 IB,EZ(9L) ....................

87-B30-163-010 AC ADAPTOR,AC-D602U A...................

87-B30-164-010 AC ADAPTOR,AC-D602E ....................

87-B30-165-010 AC ADAPTOR,AC-D602K ....................

87-B30-166-010 AC ADAPTOR,AC-D602H ....................

SCHEMATIC DIAGRAM _1

PrintedinSingapore

Tokyo Japan

9301896

Other manuals for CSD-SL20

Table of contents

Popular Cassette Player manuals by other brands

Ahuja

Ahuja CPA-360 Operation manual

Sony

Sony Pressman TCS-60DV Specifications

Philips

Philips AQ6485/14 Product information

Sony

Sony TCM-200DV - Cassette Recorder operating instructions

Nakamichi

Nakamichi BX-300 Service manual

Panasonic

Panasonic RQ-E25V operating instructions

Yamaha

Yamaha MT8X Operation manual

Sherwood

Sherwood Newcastle D-480 operating instructions

Manta

Manta MA408 user manual

GPO

GPO W0162B user guide

Marantz

Marantz CP230 Service manual

Sony

Sony HST-471 Service manual

Sharp

Sharp JC-AV1 Operation manual

Pioneer

Pioneer CT-W103 Service manual

Sony

Sony CFS-B15 - Am/fm Stereo Cassette Recorder operating instructions

Sony

Sony WMFS220 - Portable Sports AM/FM Cassette... operating instructions

Sanyo

Sanyo MCD-ZX700F Service manual

Sony

Sony Pressman TCM-465V operating instructions

Aiwa CSD-SL20 Specification sheet

Popular Cassette Player manuals by other brands
