SERVICE MANUAL

DATA

COMPACT DISC STEREO RADIO

CASSETTE RECORDER

CSD-EL300

K(S) EZ(S)

BASIC TAPE MECHANISM : 2ZM-1YR7NC

BASIC CD MECHANISM : 3ZG-3 E2NC

S/M Code No. 09-003-344-1R1

REVISION

This Service Manual is the “Revision Publishing” and replaces “Simple Manual”

CSD-EL300 (S/M Code No.09-003-344-1T1)

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

SPECIFICATIONS

•

Design and specifications are subject to change without

notice.

REF. NO PART NO. KANRI DESCRIPTION

NO.

ACCESSORIES/PACKAGE LIST

1 8A-CH2-906-010 IB,EZ(9L)FM<EZS>

1 8A-CH2-905-010 IB,K(E)FM<KS>

2 87-050-076-010 AC CORD SET ASSY,E

3 87-099-726-010 PLUG,ADPTR CONV(K)<KS>

4 8Z-CK4-962-010 RC UNIT,RC-ZAT04 (VS)

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

PROTECTION OF EYES FROM LASER BEAM DURING SERVICING

VAROITUS!

Laiteen Käyttäminen muulla kuin tässä käyttöohjeessa mainit-

ulla tavalla saattaa altistaa käyt-täjän turvallisuusluokan 1 ylit-

tävälle näkymättömälle lasersäteilylle.

VARNING!

Om apparaten används på annat sätt än vad som specificeras i

denna bruksanvising, kan användaren utsättas för osynling

laserstrålning, som överskrider gränsen för laserklass 1.

Caution: Invisible laser radiation when

open and interlocks defeated avoid expo-

sure to beam.

Advarsel:Usynling laserståling ved åbning,

når sikkerhedsafbrydere er ude af funktion.

Undgå udsættelse for stråling.

CAUTION

Use of controls or adjustments or performance of procedures

other than those specified herein may result in hazardous

radiation exposure.

ATTENTION

L'utilisation de commandes, réglages ou procédures autres que

ceux spécifiés peut entraîner une dangereuse exposition aux

radiations.

ADVARSEL!

Usynlig laserståling ved åbning, når sikkerhedsafbrydereer ude

af funktion. Undgå udsættelse for stråling.

This Compact Disc player is classified as a CLASS 1 LASER

product.

The CLASS 1 LASER PRODUCT label is located on the rear

exterior.

This set employs laser. Therefore, be sure to follow carefully the

instructions below when servicing.

WARNING!

WHEN SERVICING, DO NOT APPROACH THE LASER EXIT

WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO

CONFIRM LASER BEAM EMISSION. BE SURE TO OBSERVE

FROM A DISTANCE OF MORE THAN 30cm FROM THE

SURFACE OF THE OBJECTIVE LENS ON THE OPTICAL

PICK-UP BLOCK.

CLASS 1

KLASSE 1

LUOKAN 1

KLASS 1

LASER PRODUCT

LASER PRODUKT

LASER LAITE

LASER APPARAT

Precaution to replace Optical block

(KSS-213F)

1) After the connection, remove solder shown in

the right figure.

Body or clothes electrostatic potential could ruin

laser diode in the optical block. Be sure ground

body and workbench, and use care the clothes

do not touch the diode.

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

REF. NO PART NO. KANRI DESCRIPTION

NO.

REF. NO PART NO. KANRI DESCRIPTION

NO.

ELECTRICAL MAIN PARTS LIST

87-A21-550-010 IC,TA2149N

87-A21-185-040 C-IC,LC72121M

87-A21-090-010 IC,LA4600

87-A21-416-040 C-IC,M61500FP

87-A21-607-010 IC,NJM14558LD

87-017-915-080 IC,BU4094BCF

87-A20-446-010 C-IC,LA9241ML

87-A20-459-010 C-IC,LC78622ED

87-A21-093-010 IC,LA6541D

8A-CH2-612-010 C-IC,LC867132V-5P07

87-A20-911-010 IC,RPM6938

87-001-982-010 IC,TA7291S

TRANSISTOR

89-327-143-080 TR,2SC2714 (0.1W)

87-026-447-080 TR,2SC1740S R

89-111-624-080 TR,2SA1162Y

87-026-213-080 CHIP-TR,DTC114YK

89-503-025-080 CHIP FET,2SK302 GR

89-320-011-080 TR,2SC2001 (15W)

87-026-230-080 CHIP-TR,DTA114YK

89-327-125-080 CHIP TR,2SC2712GR

89-318-155-080 TR,2SC1815 (0.4W)

87-A30-090-080 FET,2SK2541

87-A30-151-080 TR,2SA1993F

87-026-610-080 TR,KTC3198GR

87-A30-190-080 TR,CC5551

87-026-502-080 DTC144TS

87-A30-154-080 TR,RT1N441S

87-026-463-080 TR,2SA933S (0.3W)

89-109-332-380 TR,2SA933RS

89-113-184-080 TR,2SA1318T

87-026-464-080 TR,DTC114TS (0.3W)

87-026-218-080 TR,DTC144ES (0.2W)

89-112-965-080 TR,2SA1296 (0.75W)

87-026-291-080 TR,DTC124XS

89-213-702-010 TR,2SB1370 (1.8W)

87-026-462-080 TR,2SC1740 S(RS 0.3W)

87-026-237-080 CHIP-TR,DTC124XK

87-A30-075-080 C-TR,2SA1235F

87-026-235-080 CHIP-TR,DTC114EK

87-026-245-080 TR,DTC114ES

89-109-521-080 TR,2SA952 (0.6W)

DIODE

87-070-345-080 DIODE,IN4148

87-A40-616-070 VARI-CAP,SVC384(S/T)

87-A40-128-080 C-VARI-CAP,HVU202A

87-A40-574-080 ZENER,MTZJ3.0A

87-020-465-080 DIODE,1SS133 (110MA)

87-020-465-010 DIODE,1SS133 (110MA)

87-001-936-080 ZENER,HZS7A3L

87-017-149-080 ZENER,HZS6A2L

87-017-161-080 ZENER,HZS7C2L

87-017-148-080 ZENER,HZS6A1L

87-017-144-080 ZENER,HZS24 2

87-001-142-080 DIODE,1SS294 (100MA)

87-020-125-080 DIODE,1SS181 (100MA)

87-020-027-080 CHIP-DIODE 1SS184

87-A40-465-090 DIODE,FR202

MAIN C.B

C211 87-010-405-080 CAP, ELECT 10-50V

C212 87-010-405-080 CAP, ELECT 10-50V

C220 87-010-406-080 CAP, ELECT 22-50

C229 87-018-125-080 CAP, CER 330P-50V

C230 87-018-134-080 CAPACITOR,TC-U 0.01-16

C233 87-010-546-080 CAP, ELECT 0.33-50V

C234 87-010-546-080 CAP, ELECT 0.33-50V

C235 87-018-209-080 CAP, CER 0.1-50V

C236 87-018-209-080 CAP, CER 0.1-50V

C237 87-010-380-080 CAP, ELECT 47-16V

C238 87-010-263-080 CAP, ELECT 100-10V

C239 87-018-134-080 CAPACITOR,TC-U 0.01-16

C240 87-018-134-080 CAPACITOR,TC-U 0.01-16

C241 87-010-401-080 CAP, ELECT 1-50V

C242 87-010-401-080 CAP, ELECT 1-50V

C243 87-010-401-080 CAP, ELECT 1-50V

C244 87-010-401-080 CAP, ELECT 1-50V

C245 87-010-401-080 CAP, ELECT 1-50V

C246 87-010-401-080 CAP, ELECT 1-50V

C255 87-010-401-080 CAP, ELECT 1-50V

C263 87-018-131-080 CAP, CER 1000P-50V

C264 87-018-131-080 CAP, CER 1000P-50V

C265 87-010-545-080 CAP, ELECT 0.22-50V

C266 87-010-545-080 CAP, ELECT 0.22-50V

C271 87-010-221-080 CAP, ELECT 470-10V

C272 87-010-221-080 CAP, ELECT 470-10V

C277 87-010-404-080 CAP, ELECT 4.7-50V

C278 87-010-263-080 CAP, ELECT 100-10V

C279 87-010-263-080 CAP, ELECT 100-10V

C287 87-018-130-080 CAP,TC-U 820P-50 B

C288 87-018-130-080 CAP,TC-U 820P-50 B

C301 87-018-131-080 CAP, CER 1000P-50V

C302 87-018-131-080 CAP, CER 1000P-50V

C305 87-010-263-080 CAP, ELECT 100-10V

C306 87-010-263-080 CAP, ELECT 100-10V

C307 87-018-203-080 CAP, CER 8200P-16V

C308 87-018-203-080 CAP, CER 8200P-16V

C311 87-010-546-080 CAP, ELECT 0.33-50V

C312 87-010-546-080 CAP, ELECT 0.33-50V

C313 87-018-201-080 CAP,TC-U 5600P-16 X

C314 87-018-201-080 CAP,TC-U 5600P-16 X

C321 87-018-205-080 CAP, CERA-SOL 0.022

C323 87-018-041-080 CAP,TC-S 560P-50 B

C324 87-018-041-080 CAP,TC-S 560P-50 B

C331 87-018-126-080 CAP,TC-U 390P-50 B

C332 87-018-126-080 CAP,TC-U 390P-50 B

C333 87-018-128-080 CAP, CERA-SOL SS 560P

C334 87-018-131-080 CAP, CER 1000P-50V

C335 87-018-201-080 CAP,TC-U 5600P-16 X

C336 87-018-134-080 CAPACITOR,TC-U 0.01-16

C337 87-018-198-080 CAP,TC-U 2700P-16 X

C338 87-018-198-080 CAP,TC-U 2700P-16 X

C339 87-018-198-080 CAP,TC-U 2700P-16 X

C340 87-010-382-080 CAP, ELECT 22-25V

C341 87-018-205-080 CAP, CERA-SOL 0.022

C342 87-018-123-080 CAP, CER 220P-50V

C343 87-018-199-080 CAP, CER 3300P

C345 87-018-131-080 CAP, CER 1000P-50V

C346 87-018-131-080 CAP, CER 1000P-50V

C347 87-010-374-080 CAP, ELECT 47-10V

C348 87-018-131-080 CAP, CER 1000P-50V

C355 87-A11-131-080 CAP,TC U 8200P-50 K B

C356 87-A11-131-080 CAP,TC U 8200P-50 K B

C363 87-010-405-080 CAP, ELECT 10-50V

C364 87-010-405-080 CAP, ELECT 10-50V

C367 87-018-043-080 CAP,TC-S 820P-50 B

C368 87-018-043-080 CAP,TC-S 820P-50 B

C369 87-018-118-080 CAP,TC-U 82P-50 B

C370 87-018-118-080 CAP,TC-U 82P-50 B

C373 87-010-401-080 CAP, ELECT 1-50V

C374 87-010-401-080 CAP, ELECT 1-50V

C382 87-010-401-080 CAP, ELECT 1-50V

C383 87-010-248-080 CAP, ELECT 220-10V

C384 87-010-374-080 CAP, ELECT 47-10V

C387 87-018-123-080 CAP, CER 220P-50V

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

REF. NO PART NO. KANRI DESCRIPTION

NO.

REF. NO PART NO. KANRI DESCRIPTION

NO.

C513 87-018-134-080 CAPACITOR,TC-U 0.01-16

C514 87-010-248-080 CAP, ELECT 220-10V

C520 87-010-384-080 CAP, ELECT 100-25V

C521 87-016-495-000 CAP,E 3300-25 M SMG

C526 87-010-404-080 CAP, ELECT 4.7-50V

C527 87-010-401-080 CAP, ELECT 1-50V

C528 87-010-221-080 CAP, ELECT 470-10V

C529 87-010-263-080 CAP, ELECT 100-10V

C530 87-010-248-080 CAP, ELECT 220-10V

C531 87-010-265-080 CAP, ELECT 33-16V

C543 87-010-401-080 CAP, ELECT 1-50V

CN201 87-A60-054-010 CONN,14P V 9604S-14C

CN202 87-A60-058-010 CONN,10P V 9604S-10C

CN203 87-049-469-010 CONN,4P V

CN301 87-A60-112-010 CONN,7P V S2M-7W

CN501 87-099-827-010 CONN,3P S2M-3W

CNA1 8A-CH2-631-010 CONN ASSY,6P TU-AF

J201 87-009-216-010 JACK, DIA 3.5

L301 87-003-131-080 COIL, 10MH

L331 87-007-342-010 COIL,OSC 85K BIAS

CD C.B

C401 87-010-403-080 CAP, ELECT 3.3-50V

C402 87-018-134-080 CAPACITOR,TC-U 0.01-16

C403 87-010-263-080 CAP, ELECT 100-10V

C404 87-010-248-080 CAP, ELECT 220-10V

C405 87-018-134-080 CAPACITOR,TC-U 0.01-16

C406 87-010-374-080 CAP, ELECT 47-10V

C407 87-018-131-080 CAP, CER 1000P-50V

C409 87-010-248-080 CAP, ELECT 220-10V

C410 87-010-263-080 CAP, ELECT 100-10V

C412 87-010-401-080 CAP, ELECT 1-50V

C414 87-010-405-080 CAP, ELECT 10-50V

C416 87-010-545-080 CAP, ELECT 0.22-50V

C417 87-018-125-080 CAP, CER 330P-50V

C425 87-018-129-080 CAP, CER 680P-50V

C429 87-018-133-080 CAPACITOR,CER 4700P-16V

C430 87-018-123-080 CAP, CER 220P-50V

C431 87-010-545-080 CAP, ELECT 0.22-50V

C432 87-010-374-080 CAP, ELECT 47-10V

C433 87-010-401-080 CAP, ELECT 1-50V

C434 87-018-199-080 CAP, CER 3300P

C435 87-018-134-080 CAPACITOR,TC-U 0.01-16

C436 87-010-374-080 CAP, ELECT 47-10V

C437 87-010-404-080 CAP, ELECT 4.7-50V

C438 87-018-209-080 CAP, CER 0.1-50V

C439 87-018-131-080 CAP, CER 1000P-50V

C440 87-018-139-080 CAP,TC-U 1P-50 CH

C442 87-018-149-080 CAP,TC-U 15P-50 CH

C443 87-018-209-080 CAP, CER 0.1-50V

C444 87-018-134-080 CAPACITOR,TC-U 0.01-16

C445 87-018-209-080 CAP, CER 0.1-50V

C446 87-018-209-080 CAP, CER 0.1-50V

C447 87-018-209-080 CAP, CER 0.1-50V

C448 87-018-111-080 CAP, CERA-SOL SS 27P

C450 87-018-127-080 CAP, CER 470P-50V

C451 87-018-123-080 CAP, CER 220P-50V

C455 87-010-263-080 CAP, ELECT 100-10V

C457 87-018-113-080 CAP, CER 33P-50V

C458 87-018-113-080 CAP, CER 33P-50V

C459 87-010-263-080 CAP, ELECT 100-10V

C460 87-018-209-080 CAP, CER 0.1-50V

C461 87-018-209-080 CAP, CER 0.1-50V

C462 87-010-248-080 CAP, ELECT 220-10V

C465 87-010-404-080 CAP, ELECT 4.7-50V

C466 87-018-209-080 CAP, CER 0.1-50V

C467 87-010-263-080 CAP, ELECT 100-10V

C468 87-018-119-080 CAP, CER 100P-50V

C469 87-018-121-080 CAP, CER 150P-50V

C470 87-010-544-080 CAP, ELECT 0.1-50V

C475 87-018-134-080 CAPACITOR,TC-U 0.01-16

C476 87-A10-102-080 CAP,E 1000-10 REA

C477 87-018-134-080 CAPACITOR,TC-U 0.01-16

C478 87-010-263-080 CAP, ELECT 100-10V

C479 87-018-134-080 CAPACITOR,TC-U 0.01-16

C480 87-010-221-080 CAP, ELECT 470-10V

C481 87-010-405-080 CAP, ELECT 10-50V

C482 87-010-405-080 CAP, ELECT 10-50V

C483 87-018-123-080 CAP, CER 220P-50V

C484 87-018-123-080 CAP, CER 220P-50V

C487 87-018-134-080 CAPACITOR,TC-U 0.01-16

C489 87-018-209-080 CAP, CER 0.1-50V

C490 87-018-209-080 CAP, CER 0.1-50V

C491 87-018-134-080 CAPACITOR,TC-U 0.01-16

C492 87-010-221-080 CAP, ELECT 470-10V

C493 87-018-119-080 CAP, CER 100P-50V

C494 87-018-134-080 CAPACITOR,TC-U 0.01-16

C501 87-018-119-080 CAP, CER 100P-50V

C502 87-018-119-080 CAP, CER 100P-50V

C503 87-018-119-080 CAP, CER 100P-50V

C504 87-018-119-080 CAP, CER 100P-50V

C505 87-018-119-080 CAP, CER 100P-50V

C506 87-018-119-080 CAP, CER 100P-50V

C901 87-018-134-080 CAPACITOR,TC-U 0.01-16

C902 87-010-263-080 CAP, ELECT 100-10V

C903 87-018-209-080 CAP, CER 0.1-50V

CN401 87-A60-424-010 CONN,16P V TOC-B

CN402 87-A60-061-010 CONN,06P V 9604S-06C

CN403 87-A60-062-010 CONN,05P V 9604S-05C

L401 87-003-102-080 COIL, 10UH

X401 81-592-641-010 VIB,CER 16.93MHZ

TU C.B

C1 87-010-314-080 C-CAP,S 22P-50V

C2 87-010-316-080 C-CAP,S 33P-50 CH

C3 87-010-314-080 C-CAP,S 22P-50V

C5 87-012-360-080 CAP, CER 1-10

C7 87-014-049-080 CAP,PP 470P-100 J

C8 87-012-349-080 C-CAP,S 1000P-50 CH

C10 87-010-197-080 CAP, CHIP 0.01 DM

C11 87-010-197-080 CAP, CHIP 0.01 DM

C12 87-010-197-080 CAP, CHIP 0.01 DM

C13 87-010-150-080 C-CAP,S 6P-50 CH

C14 87-010-303-080 C-CAP,S 330P-50CH

C15 87-010-178-080 CHIP CAP 1000P

C16 87-010-374-080 CAP, ELECT 47-10V

C17 87-010-198-080 CAP, CHIP 0.022

C18 87-015-835-080 C-CAP,0.047 D

C19 87-010-263-080 CAP, ELECT 100-10V

C20 87-010-404-080 CAP, ELECT 4.7-50V

C21 87-010-197-080 CAP, CHIP 0.01 DM

C22 87-010-197-080 CAP, CHIP 0.01 DM

C23 87-010-197-080 CAP, CHIP 0.01 DM

C24 87-010-303-080 C-CAP,S 330P-50CH

C25 87-016-460-080 C-CAP,S 0.22-16 B

C27 87-A11-067-080 C-CAP,S 1-10 K B

C28 87-016-669-080 C-CAP,S 0.1-25 K B

C29 87-016-669-080 C-CAP,S 0.1-25 K B

C30 87-010-213-080 C-CAP,S 0.015-50 B

C31 87-010-213-080 C-CAP,S 0.015-50 B

C33 87-012-358-080 C-CAP,S 0.47-10 F Z

C34 87-012-358-080 C-CAP,S 0.47-10 F Z

C35 87-015-819-080 CAPACITOR,0.01

C36 87-010-263-080 CAP, ELECT 100-10V

C37 87-010-197-080 CAP, CHIP 0.01 DM

C38 87-010-374-080 CAP, ELECT 47-10V

C39 87-010-404-080 CAP, ELECT 4.7-50V

C40 87-010-197-080 CAP, CHIP 0.01 DM

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

REF. NO PART NO. KANRI DESCRIPTION

NO.

REF. NO PART NO. KANRI DESCRIPTION

NO.

C41 87-010-178-080 CHIP CAP 1000P

C42 87-010-178-080 CHIP CAP 1000P

C43 87-010-178-080 CHIP CAP 1000P

C44 87-010-311-080 CAP 12P

C45 87-010-312-080 C-CAP,S 15P-50 CH<EZS>

C46 87-010-197-080 CAP, CHIP 0.01 DM

C47 87-010-197-080 CAP, CHIP 0.01 DM

C48 87-010-197-080 CAP, CHIP 0.01 DM

C49 87-012-140-080 CAP 470P

C50 87-010-197-080 CAP, CHIP 0.01 DM

C51 87-010-316-080 C-CAP,S 33P-50 CH

C52 87-010-197-080 CAP, CHIP 0.01 DM

C53 87-010-197-080 CAP, CHIP 0.01 DM

C54 87-014-055-080 CAP,PP 820P-100 J

C55 87-010-197-080 CAP, CHIP 0.01 DM

C71 87-010-197-080 CAP, CHIP 0.01 DM

C72 87-010-263-080 CAP, ELECT 100-10V

C73 87-010-197-080 CAP, CHIP 0.01 DM

C75 87-010-197-080 CAP, CHIP 0.01 DM

C92 87-010-197-080 CAP, CHIP 0.01 DM

C93 87-010-197-080 CAP, CHIP 0.01 DM

CF1 87-A91-094-010 FLTR,CDA10.7 MG80A

CF2 87-008-261-010 FILTER, SFE10.7MA5-A

CF3 87-008-261-010 FILTER, SFE10.7MA5-A

CN2 87-099-854-010 CONN,6P S2M-6W

CN3 87-A60-110-010 CONN,4P V S2M-4W

HLD1 88-CD6-661-010 HLDR,BAR ANT.

HLD2 88-CD6-661-010 HLDR,BAR ANT.

L2 87-A50-560-010 COIL,FM BPF(ACD)

L3 8A-CH4-671-010 BAR-ANT,MW/LW 3B-ACH(COI)

L4 87-A50-420-010 COIL,MW OSC(SYN)

L5 87-A50-566-010 COIL,FM RF EX(ACH)

L6 87-A50-567-010 COIL,FM OSC(ACH)

L7 87-A91-308-010 FLTR,PCFAZH- 450T (TOK)

L8 87-005-849-080 COIL,10UH(CECS)

L51 87-A50-421-010 COIL,LW OSC(SYN)

TC1 87-011-254-080 TRIMER,20P LAR

TC51 87-A91-659-010 TRIMMER,50P 4.0X4.5 ECRL

X1 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309

FRONT C.B

C601 87-010-263-080 CAP, ELECT 100-10V

C601 87-010-555-040 CAP,E 100-10 GAS

C602 87-010-197-080 CAP, CHIP 0.01 DM

C603 87-015-696-080 CAP,E 2.2-50 7L

C603 87-010-495-040 CAP,E 2.2-50 GAS

C604 87-010-754-080 CAP,E220-10 SRA 7L

C605 87-010-196-080 CHIP CAPACITOR,0.1-25

C606 87-015-696-080 CAP,E 2.2-50 7L

C606 87-010-495-040 CAP,E 2.2-50 GAS

C607 87-015-694-080 CAP,E 0.47-50 7L

C607 87-010-493-040 CAP,E 0.47-50 GAS

C608 87-010-196-080 CHIP CAPACITOR,0.1-25

C609 87-010-313-080 CAP, CHIP 18P

C610 87-010-314-080 C-CAP,S 22P-50V

C611 87-010-317-080 C-CAP,S 39P-50 CH

C612 87-010-317-080 C-CAP,S 39P-50 CH

C613 87-010-312-080 C-CAP,S 15P-50 CH

C614 87-010-754-080 CAP,E220-10 SRA 7L

C616 87-010-322-080 C-CAP,S 100P-50 CH

C617 87-010-322-080 C-CAP,S 100P-50 CH

C618 87-010-197-080 CAP, CHIP 0.01 DM

C619 87-010-197-080 CAP, CHIP 0.01 DM

C620 87-018-044-080 CAP,TC-S 1000P-50 B

C620 87-010-178-080 CHIP CAP 1000P

C621 87-010-405-080 CAP, ELECT 10-50V

C622 87-012-154-080 C-CAP,S 150P-50 CH

C623 87-012-154-080 C-CAP,S 150P-50 CH

C625 87-010-322-080 C-CAP,S 100P-50 CH

C626 87-010-197-080 CAP, CHIP 0.01 DM

C627 87-010-196-080 CHIP CAPACITOR,0.1-25

C628 87-015-677-080 CAP,E 100-6.3 7L

C628 87-015-819-080 CAPACITOR,0.01

C629 87-010-318-080 C-CAP,S 47P-50 CH

C630 87-010-178-080 CHIP CAP 1000P

C631 87-010-322-080 C-CAP,S 100P-50 CH

C632 87-010-318-080 C-CAP,S 47P-50 CH

C633 87-010-322-080 C-CAP,S 100P-50 CH

C634 87-015-677-080 CAP,E 100-6.3 7L

C635 87-010-197-080 CAP, CHIP 0.01 DM

CN601 87-099-203-010 CONN,10P 6216 H

CN602 87-099-031-010 CONN,14P 6216 H

CNA602 8A-CH2-625-010 CONN ASSY,9P TA-ME

D601 87-A40-162-010 LED,L-1154SRD

L601 87-003-171-010 COIL,15UH TROIDAL

LCD601 8A-CH2-611-010 LCD,AIW4213

R668 87-029-124-010 RES,FUSE 2.2-1/4

S381 87-A91-636-010 SW,RTRY 1-2-24 EVEGA1F2024B

SW601 87-A90-095-080 SW,TACT EVQ11G04M

SW602 87-A90-095-080 SW,TACT EVQ11G04M

SW603 87-A90-095-080 SW,TACT EVQ11G04M

SW604 87-A90-095-080 SW,TACT EVQ11G04M

SW605 87-A90-095-080 SW,TACT EVQ11G04M

SW606 87-A90-095-080 SW,TACT EVQ11G04M

SW607 87-A90-095-080 SW,TACT EVQ11G04M

SW608 87-A90-095-080 SW,TACT EVQ11G04M

SW609 87-A90-095-080 SW,TACT EVQ11G04M

SW610 87-A90-095-080 SW,TACT EVQ11G04M

SW612 87-A90-095-080 SW,TACT EVQ11G04M

SW613 87-A90-095-080 SW,TACT EVQ11G04M

SW614 87-A90-095-080 SW,TACT EVQ11G04M

SW615 87-A90-095-080 SW,TACT EVQ11G04M

SW616 87-A90-095-080 SW,TACT EVQ11G04M

SW617 87-A90-095-080 SW,TACT EVQ11G04M

SW618 87-A90-095-080 SW,TACT EVQ11G04M

SW619 87-A90-095-080 SW,TACT EVQ11G04M

X601 87-030-273-010 VIB,XTAL 32.768K5PPM

X602 87-A70-070-080 VIB,CER 5.76MHZ CRHF

PWR C.B

C701 87-018-205-080 CAP, CERA-SOL 0.022

C702 87-018-205-080 CAP, CERA-SOL 0.022

C703 87-018-205-080 CAP, CERA-SOL 0.022

C704 87-018-205-080 CAP, CERA-SOL 0.022

F701 87-035-190-010 FUSE, 2AT

FC701 87-A90-160-080 FUSE CLAMP,FC 51F

FC702 87-A90-160-080 FUSE CLAMP,FC 51F

LED C.B

CNA601 8A-CH2-624-010 CONN ASSY,4P FR-TU

D651 87-A40-161-010 LED,L-1154SGD

D652 87-A40-161-010 LED,L-1154SGD

D653 87-A40-161-010 LED,L-1154SGD

D654 87-A40-161-010 LED,L-1154SGD

D655 87-A40-161-010 LED,L-1154SGD

D656 87-A40-161-010 LED,L-1154SGD

D657 87-A40-161-010 LED,L-1154SGD

D658 87-A40-161-010 LED,L-1154SGD

D659 87-A40-161-010 LED,L-1154SGD

D660 87-A40-161-010 LED,L-1154SGD

BATT C.B

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

TRANSISTOR ILLUSTRATION

• Regarding connectors, they are not stocked as they are not the initial order items.

The connectors are available after they are supplied from connector manufacturers upon the order is received.

Resistor Code

Chip Resistor Part Coding

Figure

Value of resistor

Chip resistor

Wattage Type Tolerance

1/16W

1/10W

1/8W

1608

2125

3216

Form

LW t

1.6 0.8 0.45

2 1.25 0.45

3.2 1.6

108

118

128

: A

CHIP RESISTOR PART CODE

0.55

Resistor Code

Dimensions (mm)

Symbol

1/16W 1005 5% CJ

1.0 0.5 0.35 104

ECB ECB

ECB

2SA1162

2SA1235

2SC2712

2SC2714

DTA114YK

DTC114YK

DTC124XK

DTC144EK

RT1N441S

2SA952

2SA1296

2SA1318

2SA1993

2SC1740

2SC1815

2SC2001

CC5551

KTC3198

DTC124XS2SA933

2SK2541

DTC114ES DTC114TS

2SK302GR

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

LCD DISPLAY

LCD, AIW4213

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

109

SCHEMATIC DIAGRAM-1 (MAIN)

470

K/EZ 230V 50Hz

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1211

SCHEMATIC DIAGRAM-2 (CD MAIN)

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

Other manuals for CSD-EL300 K(S)

Table of contents

Popular Cassette Player manuals by other brands

Ahuja

Ahuja CPA-360 Operation manual

Sony

Sony Pressman TCS-60DV Specifications

Philips

Philips AQ6485/14 Product information

Sony

Sony TCM-200DV - Cassette Recorder operating instructions

Nakamichi

Nakamichi BX-300 Service manual

Panasonic

Panasonic RQ-E25V operating instructions

Yamaha

Yamaha MT8X Operation manual

Sherwood

Sherwood Newcastle D-480 operating instructions

Manta

Manta MA408 user manual

GPO

GPO W0162B user guide

Marantz

Marantz CP230 Service manual

Sony

Sony HST-471 Service manual

Sharp

Sharp JC-AV1 Operation manual

Pioneer

Pioneer CT-W103 Service manual

Sony

Sony CFS-B15 - Am/fm Stereo Cassette Recorder operating instructions

Sony

Sony WMFS220 - Portable Sports AM/FM Cassette... operating instructions

Sanyo

Sanyo MCD-ZX700F Service manual

Sony

Sony Pressman TCM-465V operating instructions

Aiwa CSD-EL300 K(S) User manual

Popular Cassette Player manuals by other brands
