Aiwa CS-P700 User manual

SERVICE MANUAL
DATA
BASIC TAPE MECHANISM : TN-9ZR-215
STEREO RADIO
CASSETTE RECORDER
CS-P700
S/M Code No. 09-003-340-7S1
SUPPLEMENT
This Service manual contains information about the difference between
CS-P700<AHRJ(S)> and CS-P700<AHRJ(L)>.
If requiring the other information, Service manual of CS-P700<AHRJ(S)>
(S/M Code No. 09-003-340-7R2).
AHRJ(L)

2-11, IKENOHATA 1-CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:[phone]
931196 Printed in Singapore
2 8A-CS7-045-010 LID,CASS BLUE
8 8A-CS7-041-010 CABI,FR ASSY BLUE
11 8A-CS7-046-010 KNOB,SL BLUE
12 8A-CS7-048-010 KNOB,RTRY VOL BLUE
18 8A-CS7-052-010 KEY,CASS PLAY BLUE
19 8A-CS7-050-010 KEY,CASS FF BLUE
20 8A-CS7-051-010 KEY,CASS REW BLUE
21 8A-CS7-049-010 KEY,CASS STOP BLUE
26 8A-CS7-043-010 CABI,REAR BLUE
28 8A-CS7-053-010 LID,BATT BLUE
29 8A-CS7-047-010 HANDL,BLUE
30 8A-CS7-058-010 PANEL,TOP EX BLUE
MECHANICAL PARTS LIST 1/1
ALTERRATION LIST
DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
