Aiwa CSD-TD310 User manual

SERVICE MANUAL
DATA
BASIC TAPE MECHANISM : ZZM-1 R4NF
BASIC CD MECHANISM : KSM-213CDM
COMPACT DISC STEREO RADIO
CASSETTE RECORDER
CSD-TD310
S/M Code No. 09-003-342-8N4
U(S)
CSD-TD320
U(W)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

-2-
SPECIFICATIONS
•
Design and specifications are subject to change without
notice.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

-3-
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING
VAROITUS!
Laiteen Käyttäminen muulla kuin tässäkäyttöohjeessa mainit-
ulla tavalla saattaa altistaa käyt-täjän turvallisuusluokan 1 ylit-
tävälle näkymättömälle lasersäteilylle.
VARNING!
Om apparaten används påannat sätt än vad som specificeras i
denna bruksanvising, kan användaren utsättas för osynling
laserstrålning, som överskrider gränsen för laserklass 1.
Caution: Invisible laser radiation when
open and interlocks defeated avoid expo-
sure to beam.
Advarsel:Usynling laserståling ved åbning,
når sikkerhedsafbrydere er ude af funktion.
Undgåudsættelse for stråling.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
ATTENTION
L'utilisation de commandes, réglages ou procédures autres que
ceux spécifiés peut entraîner une dangereuse exposition aux
radiations.
ADVARSEL!
Usynlig laserståling ved åbning, når sikkerhedsafbrydereer ude
af funktion. Undgåudsættelse for stråling.
This Compact Disc player is classified as a CLASS 1 LASER
product.
The CLASS 1 LASER PRODUCT label is located on the rear
exterior.
This set employs laser. Therefore, be sure to follow carefully the
instructions below when servicing.
WARNING!
WHEN SERVICING, DO NOT APPROACH THE LASER EXIT
WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO
CONFIRM LASER BEAM EMISSION. BE SURE TO OBSERVE
FROM A DISTANCE OF MORE THAN 30cm FROM THE
SURFACE OF THE OBJECTIVE LENS ON THE OPTICAL
PICK-UP BLOCK.
CLASS 1
KLASSE 1
LUOKAN 1
KLASS 1
LASER PRODUCT
LASER PRODUKT
LASER LAITE
LASER APPARAT
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

-4-
Precaution to replace Optical block
(KSS-213C)
1) After the connection, remove solder shown in
the right figure.
Body or clothes electrostatic potential could ruin
laser diode in the optical block. Be sure ground
body and workbench, and use care the clothes
do not touch the diode.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

-5-
REF. NO PART NO. KANRI DESCRIPTION
NO. REF. NO PART NO. KANRI DESCRIPTION NO.
ELECTRICAL MAIN PARTS LIST-1/4
IC
87-A21-550-010 IC,TA2149N
87-A21-928-010 IC,LC72131D-N
87-A21-064-010 IC,LA4227
87-A21-520-040 C-IC,M61509FP
87-A20-446-010 C-IC,LA9241ML
87-A20-459-010 C-IC,LC78622ED
87-A21-891-010 C-IC,MM1469XH
8B-CT5-625-010 IC,LC867132V5T98
87-A21-607-010 IC,NJM14558LD
TRANSISTOR
89-327-143-080 TR,2SC2714 (0.1W)
87-026-447-080 TR,2SC1740S R
89-111-624-080 TR,2SA1162Y
87-A30-288-040 C-TR,DTC114YKA
87-A30-216-080 TR,2SA933AS(R)
89-327-125-080 CHIP TR,2SC2712GR
89-318-154-080 TR,2SC1815 (0.4W)
89-112-965-080 TR,2SA1296 (0.75W)
87-A30-623-080 TR,DTC124XSA
87-A30-226-010 TR,2SB1655E
87-026-462-080 TR,2SC1740 S(RS 0.3W)
87-A30-515-080 TR,2SA1979O/Y
87-A30-287-040 C-TR,DTC114TKA
87-026-464-080 TR,DTC114TS (0.3W)
87-A30-621-080 TR,DTC114TSA
DIODE
87-070-345-080 DIODE,IN4148
87-A40-616-070 VARI-CAP,SVC384(S/T)
87-A40-916-040 C-VARI-CAP,HVC202A
87-017-090-080 ZENER,HZS5B3
87-A41-028-080 ZENER,DZ6.8BSC
87-A40-648-080 ZENER,MTZJ8.2A
87-A40-992-080 ZENER,DZ5.6BSA
87-017-978-080 DIODE,1N4003
87-A40-751-080 ZENER,UZ6.2BSB
87-020-465-080 DIODE,1SS133 (110MA)
87-A40-465-010 DIODE,FR202
MAIN C.B
C30 87-010-260-080 CAP, ELECT 47-25V
C251 87-010-404-080 CAP, ELECT 4.7-50V
C263 87-010-178-080 CHIP CAP 1000P
C264 87-010-178-080 CHIP CAP 1000P
C265 87-010-263-080 CAP, ELECT 100-10V
C266 87-010-263-080 CAP, ELECT 100-10V
C267 87-010-112-080 CAP, ELECT 100-16V
C268 87-010-112-080 CAP, ELECT 100-16V
C271 87-010-221-080 CAP, ELECT 470-10V
C272 87-010-221-080 CAP, ELECT 470-10V
C278 87-010-247-080 CAP, ELECT 100-50V
C279 87-A12-073-080 CAP,E 220-25 SMG
! C301 87-016-495-090 CAP,E 3300-25 SMG
C306 87-010-404-080 CAP, ELECT 4.7-50V
C307 87-010-401-080 CAP, ELECT 1-50V
C308 87-010-221-080 CAP, ELECT 470-10V
C311 87-010-384-080 CAP, ELECT 100-25V
C312 87-A12-073-080 CAP,E 220-25 SMG
C321 87-010-197-080 CAP, CHIP 0.01 DM
C322 87-010-384-080 CAP, ELECT 100-25V
C324 87-010-260-080 CAP, ELECT 47-25V
C325 87-010-405-080 CAP, ELECT 10-50V
C401 87-010-403-080 CAP, ELECT 3.3-50V
C402 87-010-197-080 CAP, CHIP 0.01 DM
C403 87-010-263-080 CAP, ELECT 100-10V
C404 87-010-248-080 CAP, ELECT 220-10V
C405 87-010-197-080 CAP, CHIP 0.01 DM
C406 87-010-374-080 CAP, ELECT 47-10V
C407 87-A11-112-080 CAP,TC U 1000P-50 J CH
C408 87-010-198-080 CAP, CHIP 0.022
C409 87-010-248-080 CAP, ELECT 220-10V
C410 87-010-263-080 CAP, ELECT 100-10V
C411 87-A11-177-080 C-CAP,S 0.15-16 K B
C412 87-010-401-080 CAP, ELECT 1-50V
C413 87-016-369-080 C-CAP,S 0.033-25 B K
C414 87-010-405-080 CAP, ELECT 10-50V
C416 87-010-545-080 CAP, ELECT 0.22-50V
C417 87-012-157-080 C-CAP,S 330P-50 CH
C418 87-010-213-080 C-CAP,S 0.015-50 B
C419 87-A10-201-080 C-CAP,S0.33-16 KB
C420 87-016-369-080 C-CAP,S 0.033-25 B K
C421 87-A11-177-080 C-CAP,S 0.15-16 K B
C422 87-010-183-080 C-CAP,S 2700P-50 B
C423 87-010-992-080 C-CAP,S 0.047-25 B
C424 87-010-220-080 C-CAP,S 0.018-25 B
C425 87-A11-108-080 CAP,TC U 680P-50 J CH
C426 87-A10-201-080 C-CAP,S0.33-16 KB
C428 87-010-426-080 C-CAP,S 0.012-25 B
C429 87-010-186-080 CAP,CHIP 4700P
C430 87-012-156-080 C-CAP,S 220P-50 CH
C431 87-010-545-080 CAP, ELECT 0.22-50V
C432 87-010-374-080 CAP, ELECT 47-10V
C433 87-010-401-080 CAP, ELECT 1-50V
C434 87-010-184-080 CHIP CAPACITOR 3300P(K)
C435 87-010-197-080 CAP, CHIP 0.01 DM
C436 87-010-374-080 CAP, ELECT 47-10V
C437 87-010-404-080 CAP, ELECT 4.7-50V
C438 87-016-669-080 C-CAP,S 0.1-25 K B
C439 87-010-178-080 CHIP CAP 1000P
C440 87-018-139-080 CAP,TC-U 1P-50 CH
C441 87-010-197-080 CAP, CHIP 0.01 DM
C442 87-018-148-080 CAP,TC-U 12P-50 CH
C445 87-012-368-080 C-CAP,S 0.1-50 F
C446 87-012-368-080 C-CAP,S 0.1-50 F
C447 87-012-368-080 C-CAP,S 0.1-50 F
C448 87-010-315-080 C-CAP,S 27P-50 CH
C451 87-012-156-080 C-CAP,S 220P-50 CH
C455 87-010-247-080 CAP, ELECT 100-50V
C457 87-010-316-080 C-CAP,S 33P-50 CH
C458 87-010-316-080 C-CAP,S 33P-50 CH
C459 87-010-263-080 CAP, ELECT 100-10V
C460 87-015-819-080 CAPACITOR,0.01
C461 87-010-197-080 CAP, CHIP 0.01 DM
C462 87-010-248-080 CAP, ELECT 220-10V
C463 87-A11-132-080 CAP,TC U 0.01-50 K B
C465 87-010-404-080 CAP, ELECT 4.7-50V
C466 87-012-368-080 C-CAP,S 0.1-50 F
C467 87-010-263-080 CAP, ELECT 100-10V
C469 87-012-154-080 C-CAP,S 150P-50 CH
C471 87-A11-148-080 CAP,TC U 0.1-50 Z F
C472 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C473 87-012-368-080 C-CAP,S 0.1-50 F
C474 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C475 87-A11-132-080 CAP,TC U 0.01-50 K B
C476 87-010-236-080 CAP,E 1000-10 SME
C477 87-010-197-080 CAP, CHIP 0.01 DM
C478 87-010-263-080 CAP, ELECT 100-10V
C479 87-010-197-080 CAP, CHIP 0.01 DM
C480 87-010-221-080 CAP, ELECT 470-10V
C481 87-010-405-080 CAP, ELECT 10-50V
C482 87-010-405-080 CAP, ELECT 10-50V
C489 87-012-368-080 C-CAP,S 0.1-50 F
C490 87-012-368-080 C-CAP,S 0.1-50 F
C491 87-A11-132-080 CAP,TC U 0.01-50 K B
C492 87-010-221-080 CAP, ELECT 470-10V
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

-6-
REF. NO PART NO. KANRI DESCRIPTION
NO. REF. NO PART NO. KANRI DESCRIPTION NO.
ELECTRICAL MAIN PARTS LIST-2/4
C493 87-010-180-080 C-CER 1500P
C501 87-012-368-080 C-CAP,S 0.1-50 F
C502 87-010-322-080 C-CAP,S 100P-50 CH
C503 87-018-119-080 CAP, CER 100P-50V
C504 87-010-322-080 C-CAP,S 100P-50 CH
C505 87-010-322-080 C-CAP,S 100P-50 CH
C506 87-010-322-080 C-CAP,S 100P-50 CH
C510 87-016-669-080 C-CAP,S 0.1-25 K B
C831 87-010-198-080 CAP, CHIP 0.022
C4001 87-018-120-080 CAP, CERA-SOL SS 120P
CN202 87-049-919-010 CONN,3P EH V WHT
CN205 87-A60-109-010 CONN,2P V S2M-2W
CN301 87-049-919-010 CONN,3P EH V WHT
CN401 87-A60-424-010 CONN,16P V TOC-B
CN403 87-099-196-010 CONN,8P 6216 V
CN802 87-049-469-010 CONN,4P V
CNA402 8A-CDB-622-010 CONN ASSY,6P CD-MOTOR
L401 87-003-102-080 COIL, 10UH
L402 87-003-098-080 COIL,2.2UH
L404 87-003-152-080 COIL, 100UH
R840 87-029-124-090 RESISTOR, FUSE 1/4W 2.2
SFR430 87-024-437-080 SFR100K,RH063EC
X401 87-A70-046-010 VIB,XTAL 16.934MHZ
TAPE C.B
C211 87-010-805-080 CAP, S 1-16
C212 87-010-805-080 CAP, S 1-16
C215 87-016-460-080 C-CAP,S 0.22-16 B
C216 87-016-460-080 C-CAP,S 0.22-16 B
C231 87-010-213-080 C-CAP,S 0.015-50 B
C232 87-010-213-080 C-CAP,S 0.015-50 B
C233 87-A10-201-080 C-CAP,S0.33-16 KB
C234 87-A10-201-080 C-CAP,S0.33-16 KB
C235 87-016-669-080 C-CAP,S 0.1-25 K B
C236 87-016-669-080 C-CAP,S 0.1-25 K B
C237 87-010-221-080 CAP, ELECT 470-10V
C239 87-A11-132-080 CAP,TC U 0.01-50 K B
C240 87-A11-132-080 CAP,TC U 0.01-50 K B
C247 87-010-401-080 CAP, ELECT 1-50V
C248 87-010-401-080 CAP, ELECT 1-50V
C309 87-010-197-080 CAP, CHIP 0.01 DM
C310 87-010-248-080 CAP, ELECT 220-10V
C316 87-010-384-080 CAP, ELECT 100-25V
C317 87-010-197-080 CAP, CHIP 0.01 DM
C801 87-010-248-080 CAP, ELECT 220-10V
C805 87-012-365-080 C-CAP,S 0.027-25VBK
C806 87-012-365-080 C-CAP,S 0.027-25VBK
C807 87-010-405-080 CAP, ELECT 10-50V
C808 87-010-405-080 CAP, ELECT 10-50V
C809 87-010-401-080 CAP, ELECT 1-50V
C810 87-010-401-080 CAP, ELECT 1-50V
C811 87-010-178-080 CHIP CAP 1000P
C812 87-010-178-080 CHIP CAP 1000P
C816 87-010-180-080 C-CER 1500P
C817 87-010-180-080 C-CER 1500P
C821 87-010-401-080 CAP, ELECT 1-50V
C822 87-010-401-080 CAP, ELECT 1-50V
C823 87-010-178-080 CHIP CAP 1000P
C824 87-010-178-080 CHIP CAP 1000P
C829 87-010-178-080 CHIP CAP 1000P
C830 87-010-178-080 CHIP CAP 1000P
C834 87-010-248-080 CAP, ELECT 220-10V
C843 87-A11-132-080 CAP,TC U 0.01-50 K B
C844 87-A11-098-080 CAP,270PF-50 CH
C845 87-010-178-080 CHIP CAP 1000P
C846 87-010-263-080 CAP, ELECT 100-10V
C851 87-A11-125-080 CAP,TC U 2700P-50 K B
C852 87-A11-112-080 CAP,TC U 1000P-50 J CH
C853 87-A11-132-080 CAP,TC U 0.01-50 K B
CN201 87-099-018-010 CONN,16P
CN801 87-A60-110-010 CONN,4P V S2M-4W
CNA302 8A-CDB-627-010 CONN ASSY,6P MA-TUNER
JW108 87-003-097-080 COIL,1UH
JW132 87-003-141-080 CHOKE COIL 1.2
JW133 87-003-097-080 COIL,1UH
L801 87-007-342-010 COIL,OSC 85K BIAS
SW801 8Z-CD9-609-010 SW,SL 1-6-2 PS62D01
FRONT C.B
C601 87-010-313-080 CAP, CHIP 18P
C602 87-010-315-080 C-CAP,S 27P-50 CH
C603 87-010-319-080 C-CAP,S 56P-50 CH
C604 87-010-312-080 C-CAP,S 15P-50 CH
C605 87-010-317-080 C-CAP,S 39P-50 CH
C606 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C607 87-010-196-080 CHIP CAPACITOR,0.1-25
C608 87-010-196-080 CHIP CAPACITOR,0.1-25
C610 87-010-555-040 CAP,E 100-10 GAS
C611 87-010-196-080 CHIP CAPACITOR,0.1-25
C612 87-010-248-080 CAP, ELECT 220-10V
C613 87-010-402-080 CAP, ELECT 2.2-50V
C614 87-010-196-080 CHIP CAPACITOR,0.1-25
C615 87-010-400-080 CAP, ELECT 0.47-50V
C616 87-010-401-080 CAP, ELECT 1-50V
C620 87-010-555-040 CAP,E 100-10 GAS
C625 87-A11-566-080 C-CAP,S 0.01-25 K B
C630 87-010-196-080 CHIP CAPACITOR,0.1-25
C631 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C632 87-010-322-080 C-CAP,S 100P-50 CH
C633 87-010-322-080 C-CAP,S 100P-50 CH
C634 87-010-297-080 CAP CHIO 100P
C661 87-010-378-080 CAP, ELECT 10-16V
CN601 87-099-018-010 CONN,16P
CN602 87-099-201-010 CONN,8P 6216 H
CNA603 8A-CHB-616-010 CONN ASSY,4P TU-FR(DIGITAL)
CNA604 8A-CHB-617-010 CONN ASSY,2P VOL-KEY
CNA606 8A-CHB-621-010 CONN ASSY,8P FUNCT-KEY
JW606 87-003-098-080 COIL,2.2UH
L601 87-003-146-080 COIL,15UH LAL02
LCD601 8A-CHB-626-010 LCD,AIW4239-32P5N ACH-B24
LED608 88-CD6-630-010 LED,934ID RED
S601 87-A91-704-080 SW,TACT EVQ 214 05R
S604 87-A92-170-080 SW,TACT EVQPAD05R
S605 87-A92-170-080 SW,TACT EVQPAD05R
S606 87-A91-704-080 SW,TACT EVQ 214 05R
S607 87-A92-170-080 SW,TACT EVQPAD05R
X601 87-030-273-010 VIB,XTAL 32.768K5PPM
X602 87-A70-070-080 VIB,CER 5.76MHZ CRHF
TU C.B
C1 87-010-312-080 C-CAP,S 15P-50 CH
C2 87-010-316-080 C-CAP,S 33P-50 CH
C3 87-010-312-080 C-CAP,S 15P-50 CH
C5 87-016-669-080 C-CAP,S 0.1-25 K B
C6 87-010-313-080 CAP, CHIP 18P
C7 87-012-140-080 CAP 470P
C8 87-012-349-080 C-CAP,S 1000P-50 CH
C10 87-A11-566-080 C-CAP,S 0.01-25 K B
C11 87-A11-566-080 C-CAP,S 0.01-25 K B
C12 87-A11-566-080 C-CAP,S 0.01-25 K B
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

-7-
REF. NO PART NO. KANRI DESCRIPTION
NO. REF. NO PART NO. KANRI DESCRIPTION NO.
ELECTRICAL MAIN PARTS LIST-3/4
C13 87-010-150-080 C-CAP,S 6P-50 CH
C14 87-010-303-080 C-CAP,S 330P-50CH
C15 87-012-349-080 C-CAP,S 1000P-50 CH
C16 87-010-374-080 CAP, ELECT 47-10V
C17 87-010-198-080 CAP, CHIP 0.022
C18 87-015-835-080 C-CAP,0.047 D
C19 87-010-263-080 CAP, ELECT 100-10V
C20 87-010-404-080 CAP, ELECT 4.7-50V
C21 87-A11-566-080 C-CAP,S 0.01-25 K B
C22 87-A11-566-080 C-CAP,S 0.01-25 K B
C23 87-A11-566-080 C-CAP,S 0.01-25 K B
C24 87-010-303-080 C-CAP,S 330P-50CH
C25 87-016-460-080 C-CAP,S 0.22-16 B
C27 87-A11-067-080 C-CAP,S 1-10 K B
C28 87-016-669-080 C-CAP,S 0.1-25 K B
C29 87-016-669-080 C-CAP,S 0.1-25 K B
C30 87-012-365-080 C-CAP,S 0.027-25VBK
C31 87-012-365-080 C-CAP,S 0.027-25VBK
C33 87-016-461-080 C-CAP,S 0.47-16F
C34 87-016-461-080 C-CAP,S 0.47-16F
C35 87-015-819-080 CAPACITOR,0.01
C36 87-010-263-080 CAP, ELECT 100-10V
C37 87-A11-566-080 C-CAP,S 0.01-25 K B
C38 87-010-263-080 CAP, ELECT 100-10V
C39 87-010-404-080 CAP, ELECT 4.7-50V
C40 87-A11-566-080 C-CAP,S 0.01-25 K B
C41 87-012-349-080 C-CAP,S 1000P-50 CH
C42 87-012-349-080 C-CAP,S 1000P-50 CH
C43 87-012-349-080 C-CAP,S 1000P-50 CH
C44 87-010-312-080 C-CAP,S 15P-50 CH
C45 87-010-312-080 C-CAP,S 15P-50 CH
C46 87-A11-566-080 C-CAP,S 0.01-25 K B
C47 87-A11-566-080 C-CAP,S 0.01-25 K B
C48 87-A11-566-080 C-CAP,S 0.01-25 K B
C49 87-012-140-080 CAP 470P
C50 87-A11-566-080 C-CAP,S 0.01-25 K B
C71 87-A11-566-080 C-CAP,S 0.01-25 K B
C72 87-010-263-080 CAP, ELECT 100-10V
C73 87-A11-566-080 C-CAP,S 0.01-25 K B
C75 87-A11-566-080 C-CAP,S 0.01-25 K B
C80 87-A11-566-080 C-CAP,S 0.01-25 K B
C92 87-A11-566-080 C-CAP,S 0.01-25 K B
C93 87-A11-566-080 C-CAP,S 0.01-25 K B
CF1 87-A91-094-010 FLTR,CDA10.7 MG80A
CF2 87-008-261-010 FILTER, SFE10.7MA5-A
CF3 87-008-261-010 FILTER, SFE10.7MA5-A
CN2 87-009-034-010 CONN,6P PH V
CN3 87-009-032-010 CONNECTOR,4P YEL
L2 87-A50-560-010 COIL,FM BPF(ACD)
L3 8A-CH4-670-010 BAR-ANT,MW 2B-ACH(COI)
L4 87-A50-420-010 COIL,MW OSC(SYN)
L5 87-A50-566-010 COIL,FM RF EX(ACH)
L6 87-A50-567-010 COIL,FM OSC(ACH)
L7 87-A91-308-010 FLTR,PCFAZH- 450T (TOK)
L8 87-005-849-080 COIL,10UH(CECS)
TC1 87-011-254-080 TRIMER,20P LAR
X1 87-A70-306-010 VIB,XTAL 4.500MHZ CSA-309ST
HP C.B
CN201 8A-CDB-624-010 CONN ASSY,3P H.P
CN203 87-A60-685-010 CONN,4P H WHT EH
J251 87-A60-420-010 JACK,3.5 ST (MSC)
LED C.B
CN607 87-009-236-010 CONN 8P PH H
LED605 88-CD6-630-010 LED,934ID RED
LED606 88-CD6-630-010 LED,934ID RED
LED611 88-CD6-630-010 LED,934ID RED
S608 87-A92-171-080 SW,TACT EVQPAG05R
S609 87-A92-171-080 SW,TACT EVQPAG05R
S610 87-A92-171-080 SW,TACT EVQPAG05R
S611 87-A92-170-080 SW,TACT EVQPAD05R
S613 87-A92-170-080 SW,TACT EVQPAD05R
VOL C.B
CN608 87-009-345-010 CONN,2P PH H
S614 87-A92-170-080 SW,TACT EVQPAD05R
S615 87-A92-170-080 SW,TACT EVQPAD05R
PWR C.B
C901 87-A11-146-080 CAP,TC U 0.022-50 Z F
C902 87-A11-146-080 CAP,TC U 0.022-50 Z F
C903 87-A11-146-080 CAP,TC U 0.022-50 Z F
C904 87-A11-146-080 CAP,TC U 0.022-50 Z F
CNA901 8A-CDB-621-010 CONN ASSY,3P POWER
! PR901 87-A90-092-080 PROTECTOR,2.5A 491
MOTOR C.B
M2 S0-M10-A09-700 MOTOR SLED ASSY
PIN3 S2-369-750-000 PLUG,6P
SW1 S4-S13-A01-600 SW,LEAF
BATT C.B
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

-8-
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ 1.0 0.5 0.35 104
Lt
W
•Regarding connectors, they are not stocked as they are not the initial order items.
The connectors are available after they are supplied from connector manufacturers upon the order is received.
ELECTRICAL MAIN PARTS LIST-4/4
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

-9-
TRANSISTOR ILLUSTRATION-1/1
ECB ECB ECB
ECB
E
B
C
DTC114TS
2SB1655E 2SA1162Y
2SC2712
2SC2714
DTC114TK
DTC114YK
2SC1740S R
2SA1296
2SA1979O/Y
2SC1740 S
2SC1815
E C B
2SA933AS
DTC114TSA
G OUT IN
DTC124XSA
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

-10-
FL (AIW4239-32P5N) GRID ASSIGNMENT/ANODE CONNECTION-1/1
GRID ASSIGNMENT
ANODE CONNECTION
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
