S E R V I C E M A N U A L
SIMPLE MANUAL
•Replace this Service Manual with ”Revision Publishing” when it is issued.
HS-TA293
• TYPE: YH,YL,YZ
S/M Code No. 09–98B–312–90A
STEREO RADIO CASSETTE PLAYER

ELECTRICAL MAIN PARTS LIST - 1/2
NOTE: The characters in the suffix column indicate the part usage.
YL .....................XX..................................A...................
YH .....................XX...................................B..................
YZ1B ...................XX....................................C.................
YZ1 ....................XX.....................................D................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 2 87-010-181-080 CAP,CHIP S 1800P ABCD................
C 1 87-010-181-080 CAP,CHIP S 1800P ABCD................
C 9 87-010-193-080 CHIP CAPACITOR,0.033 ABCD................
C 7 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 8 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 3 87-010-501-040 E/CAP GAS 47-4 ABCD................
C 4 87-010-501-040 E/CAP GAS 47-4 ABCD................
C 5 87-010-992-080 C-CAP,S 0.047-25 B ABCD................
C 6 87-010-992-080 C-CAP,S 0.047-25 B ABCD................
C 18 87-010-175-080 CAP 560P ABCD................
C 17 87-010-175-080 CAP 560P ABCD................
C 19 87-010-178-080 CHIP CAP 1000P ABCD................
C 14 87-010-178-080 CHIP CAP 1000P ABCD................
C 10 87-010-193-080 CHIP CAPACITOR,0.033 ABCD................
C 12 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 15 87-010-496-040 CAP,E 3.3-50 GAS ABCD................
C 16 87-010-498-040 CAP,E 10-16 GAS ABCD................
C 11 87-010-503-040 CAP,E 220-4 GAS ABCD................
C 13 87-010-503-040 CAP,E 220-4 GAS ABCD................
C 20 87-010-178-080 CHIP CAP 1000P ABCD................
C 21 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 22 87-010-498-040 CAP,E 10-16 GAS ABCD................
C 24 87-010-503-040 CAP,E 220-4 GAS ABCD................
C 23 87-016-462-080 C-CAP,S 1-16 F ABCD................
IC 1 87-A20-852-040 C-IC,LAG668FT2 ABCD................
J 1 85-HRL-623-010 JACK,3.5 ST BLK ABCD................
J 2 87-A60-849-010 JACK,DC DIA 2.75 BLK ABCD................
L 2 87-005-849-080 COIL,10UH(CECS) ABCD................
L 1 87-A50-038-010 COIL,RF CHOKE ABCD................
Q 2 87-026-261-080 CHIP-TR,RN1407 ABCD................
Q 4 87-026-264-080 C-TR,RN1411 ABCD................
Q 3 87-026-264-080 C-TR,RN1411 ABCD................
Q 5 87-026-264-080 C-TR,RN1411 ABCD................
Q 1 87-A30-159-080 C-TR,KTA1298Y ABCD................
R 16 87-A00-330-080 RES,M/F 220-1/8W 3900PPM ABCD................
SFR 1 87-A90-775-010 SFR 3K H VZ066L3 ABCD................
SW 3 87-A90-050-010 SW, SL 2-2-2 NS (BLK) ABCD................
SW 1 87-A90-133-010 SW LEAF LSA1120JAU ABCD................
SW 2 87-A90-216-010 SW SL 2-2-3 SK230 ABCD................
TH 1 87-026-256-090 THERMISTOR, HT-100 ABCD................
VR 1 87-A90-981-010 VR,RTRY 20KBX1 ABCD................
C 301 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCD................
C 302 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCD................
C 309 87-010-189-080 C-CAP,S 8200P-50 B ABCD................
C 307 87-010-195-080 C-CAP,S 0.068-25 F ABCD................
C 308 87-010-195-080 C-CAP,S 0.068-25 F ABCD................
C 304 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 303 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 306 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 305 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 311 87-010-188-080 CAP,CHIP 6800P ABCD................
C 312 87-010-188-080 CAP,CHIP 6800P ABCD................
C 310 87-010-189-080 C-CAP,S 8200P-50 B ABCD................
C 313 87-010-501-040 E/CAP GAS 47-4 ABCD................
C 314 87-010-503-040 CAP,E 220-4 GAS ABCD................
C 315 87-012-365-080 C-CAP,S 0.027-25VBK ABCD................
C 316 87-012-365-080 C-CAP,S 0.027-25VBK ABCD................
C 318 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 317 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 319 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 320 87-016-462-080 C-CAP,S 1-16 F ABCD................
D 301 87-020-027-080 CHIP-DIODE 1SS184 ABCD................
Q 301 87-026-264-080 C-TR,RN1411 ABCD................
Q 302 87-026-264-080 C-TR,RN1411 ABCD................
Q 303 87-026-264-080 C-TR,RN1411 ABCD................
Q 304 87-026-264-080 C-TR,RN1411 ABCD................
Q 306 89-327-125-080 CHIP TR,2SC2712GR ABCD................
Q 305 89-327-125-080 CHIP TR,2SC2712GR ABCD................
Q 307 89-327-125-080 CHIP TR,2SC2712GR ABCD................
Q 308 89-327-125-080 CHIP TR,2SC2712GR ABCD................
BPF 101 87-A90-336-010 FLTR,GFEB4 ....................
BPF 101 87-A90-749-010 FLTR,GFMB5 ABCD................
C 101 87-010-147-080 C-CAP,S 3P-50 CH A...................
C 104 87-010-148-080 CAP, CHIP S 75P SL A...................
C 101 87-010-149-080 C-CAP,S 5P-50 CH .BCD................
C 104 87-010-151-080 C-CAP,S 7P-50 CH .BCD................
C 102 87-010-154-080 CAP CHIP 10P ....................
C 103 87-010-154-080 CAP CHIP 10P ....................
C 108 87-010-178-080 CHIP CAP 1000P ABCD................
C 105 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 102 87-010-313-080 CAP, CHIP 18P ABCD................
C 103 87-010-315-080 C-CAP,S 27P-50 CH AB..................
C 103 87-012-149-080 C-CAP,S 30P-50 CH ..CD................

ELECTRICAL MAIN PARTS LIST - 2/2
C 109 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 107 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 119 87-010-178-080 CHIP CAP 1000P ABCD................
C 114 87-010-194-080 CAP, CHIP 0.047 ABCD................
C 115 87-010-194-080 CAP, CHIP 0.047 ABCD................
C 111 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 110 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 113 87-010-213-080 C-CAP,S 0.015-50 B ABCD................
C 112 87-010-213-080 C-CAP,S 0.015-50 B ABCD................
C 117 87-010-452-080 CAPACITOR,1-16 ABCD................
C 118 87-010-497-040 CAP,E 4.7-35 GAS ABCD................
C 116 87-010-503-040 CAP,E 220-4 GAS ABCD................
C 120 87-016-461-080 C-CAP,S 0.47-16F ABCD................
CF 102 87-A90-812-010 FLTR,KIT ABCD................
CF 101 87-A91-030-010 FLTR,CFAL 450KHZ LB ABCD................
IC 101 87-A20-851-040 C-IC,TA2111F ABCD................
L 104 87-A50-279-010 COIL,AM OSC ABCD................
L 105 87-A91-088-010 IFT,AM 45OKHZ 5PYH6.2 ABCD................
L 101 8Z-HRJ-603-010 BAR-ANT,MW(CECS) ABCD................
L 102 8Z-HRJ-604-010 COIL,FM RF ABCD................
L 103 8Z-HRJ-607-010 COIL,FM OSC ABCD................
L 102 8Z-HRJ-608-010 COIL,RF FM V ....................
L 103 8Z-HRJ-609-010 COIL,OSC FM V ....................
VC 101 87-A91-029-010 TUN-CAP,20P-160P 16X16 450KHZ AB..................
VC 101 87-A91-082-010 TUN-CAP,20P-160P 16X16 A450KHZ ..CD................
VC 101 87-A91-160-010 TUN-CAP,40P-160P 16X16 450KHZ ....................
SW 301 87-036-146-080 C-SLIDE SWITCH 1-1-4 ABCD................
C 451 87-016-462-080 C-CAP,S 1-16 F ABCD................
IC 451 87-017-643-080 IC,MM1206XF ABCD................
LED 453 87-A90-276-080 C-LED,SML-210MT GRN ABCD................
LED 451 87-A90-278-080 C-LED,SML-210VT RED ABCD................
LED 452 87-A90-711-080 C-LED,SML-210YTT YEL ABCD................

MECHANICAL PARTS LIST - 1/1
NOTE: The characters in the suffix column indicate the part usage.
YL .....................XX..................................A...................
YH .....................XX...................................B..................
YZ1B ...................XX....................................C.................
YZ1 ....................XX.....................................D................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
86-HRM-005-110 WINDOW,TUN ABCD................
86-HRM-009-110 POINTER,TUN ABCD................
8Z-HRJ-001-010 LID,CASS A...................
8Z-HRJ-002-010 WINDOW,MSP ABCD................
8Z-HRJ-004-010 LID,CASS YJ SIL .B..................
8Z-HRJ-005-010 LID,CASS YZ SIL ..CD................
8Z-HRJ-006-010 LID,CASS YV SIL ....................
8Z-HRJ-003-010 KNOB,RTRY MSP ABCD................
87-067-732-010 TAPPING SCREW, VT1.4-3 ABCD................
8Z-HRJ-201-010 GEAR,MSP ABCD................
87-HRR-037-010 LID,BATT SIL A..D................
88-HKA-033-010 FRAME,CENTRE J034 ABCD................
8Z-HRL-008-010 CABI,REAR .BC.................
8Z-HRL-010-010 LID,BATT .BC.................
8Z-HRL-021-010 CABI,REAR SIL A..D................
86-HRM-006-010 KNOB,RTRY TUN ABCD................
87-067-691-010 SCREW VT+1.7-6 ABCD................
87-B10-044-010 V+1.7-6.5 ABCD................
81-HK9-208-210 SPR-P,CASS A ABCD................
86-HRM-202-010 BAT-CONTACT,(+) ABCD................
86-HRM-203-110 BAT-CONTACT,(-) ABCD................
86-HRM-205-010 SPR-T,CLICK ABCD................
87-HRR-206-010 PLATE,HEAD J034 ABCD................

ACCESSORIES / PACKAGE LIST - 1/1
NOTE: The characters in the suffix column indicate the part usage.
YL .....................XX..................................A...................
YH .....................XX...................................B..................
YZ1B ...................XX....................................C.................
YZ1 ....................XX.....................................D................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-HRJ-904-010 IB,YJ(ESC) -C .B..................
8Z-HRJ-905-010 IB,Y(EGFSI) -C ..C.................
8Z-HRJ-907-010 IB,Y(EDPOHCZ) -C ..C.................
8Z-HRJ-909-010 IB,YL (ESP)-IN A...................
8Z-HRJ-910-010 IB,Y (EGFSI)-IN ...D................
8Z-HRJ-911-010 IB,Y (EDPOHCZ)-IN ...D................
84-447-019-310 CLIP,BELT ABCD................
87-B30-139-010 HEADPHONE,HP-M007(TL) ABCD................

SCHEMATIC DIAGRAM - 1 (MAIN)
