S E R V I C E M A N U A L

SIMPLE MANUAL

• Replace this Service Manual with ”Revision Publishing” when it is issued.

RM-67

• TYPE:

S/M Code No. 09–997–333–6T1

RADIO CASSETTE RECORDER

• BASIC TAPE MECHANISM : TN-21ZVC-1145 HEJ(S), SHJ(S)

ELECTRICAL MAIN PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

HEJ(S) .................XX....................................C.................

SHJ(S) .................XX.....................................D................

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-CM1-608-010 JACK, EP ZCM-1 ABCD................

C 209 87-010-221-080 CAP, ELECT 470-10V ABCD................

C 207 87-010-380-080 CAP, ELECT 47-16V ABCD................

C 202 87-010-404-080 CAP, ELECT 4.7-50V ABCD................

C 206 87-010-544-080 CAP, ELECT 0.1-50V ABCD................

C 203 87-A10-860-080 CAP,CER 470P-2K K R ABCD................

C 204 87-A10-860-080 CAP,CER 470P-2K K R ABCD................

C 211 87-010-221-080 CAP, ELECT 470-10V ABCD................

C 213 87-010-380-080 CAP, ELECT 47-16V ABCD................

C 212 87-010-400-080 CAP, ELECT 0.47-50V ABCD................

C 217 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 216 87-A10-170-010 CAP,CER 330P-50 K B ABCD................

C 219 87-A10-182-010 CAP,CER 0.01-50 Z F ABCD................

C 218 87-A10-860-080 CAP,CER 470P-2K K R ABCD................

C 226 87-010-263-080 CAP, ELECT 100-10V ABCD................

C 220 87-010-380-080 CAP, ELECT 47-16V ABCD................

C 223 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 227 87-010-403-080 CAP, ELECT 3.3-50V ABCD................

C 225 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 221 87-A10-182-010 CAP,CER 0.01-50 Z F ABCD................

C 222 87-A10-182-010 CAP,CER 0.01-50 Z F ABCD................

C 228 87-A10-840-010 CAP,CER 220P-1K K R LONG ABCD................

C 224 87-A10-860-080 CAP,CER 470P-2K K R ABCD................

C 229 87-A10-860-080 CAP,CER 470P-2K K R ABCD................

C 232 87-010-221-080 CAP, ELECT 470-10V ABCD................

C 238 87-010-248-080 CAP, ELECT 220-10V ABCD................

C 234 87-010-380-080 CAP, ELECT 47-16V ABCD................

C 230 87-010-402-080 CAP, ELECT 2.2-50V ABCD................

C 237 87-010-544-080 CAP, ELECT 0.1-50V ABCD................

C 236 87-A10-211-010 CAP,CER 0.1-50 M ABCD................

C 235 87-A10-211-010 CAP,CER 0.1-50 M ABCD................

C 239 87-A10-411-010 CAP,CER 0.047-16 K SR ABCD................

C 305 87-010-221-080 CAP, ELECT 470-10V ABCD................

C 306 87-010-221-080 CAP, ELECT 470-10V ABCD................

C 308 87-010-248-080 CAP, ELECT 220-10V ABCD................

C 303 87-015-997-090 CAP,E 2200-16 SME ABCD................

C 309 87-A10-211-010 CAP,CER 0.1-50 M ABCD................

C 307 87-A10-411-010 CAP,CER 0.047-16 K SR ABCD................

C 304 87-A10-411-010 CAP,CER 0.047-16 K SR ABCD................

C 302 87-A10-577-010 CAP,CER 0.022-50 Z YF ABCD................

C 301 87-A10-577-010 CAP,CER 0.022-50 Z YF ABCD................

C 311 87-010-248-080 CAP, ELECT 220-10V ABCD................

C 310 87-A10-161-010 CAP,CER 56P-50 K SL ABCD................

D 201 86-CM3-601-080 DIODE,CDG-24 ABCD................

D 203 87-002-850-080 ZENER,HZ4B2 ABCD................

D 202 8Z-CM1-657-010 DIODE, IN60 ABCD................

D 303 87-A91-052-080 LED,SEL6227S RED ABCD................

D 302 8Z-CM1-656-010 DIODE, 1N4001 ABCD................

D 301 8Z-CM1-656-010 DIODE, 1N4001 ABCD................

IC 202 88-CM2-608-010 IC,TA7628 HP ABCD................

L 201 87-003-149-080 COIL,47UH ABCD................

L 301 87-003-149-080 COIL,47UH ABCD................

Q 201 87-CD7-603-080 TR,SS8050 ABCD................

R 306 87-A00-436-050 RES,100-1/2W J RP ABCD................

SW 201 8Z-CM2-647-010 SW,SL 2-4-2 FUNC ABCD................

SW 202 8Z-CM2-648-010 SW,SL 2-2-2 BEAT ABCD................

SW 203 8Z-CM2-650-010 SW,PUSH 2-6-2 REC ABCD................

T 201 8Z-CM1-605-010 COIL, BIAS ABCD................

VR 201 8Z-CM1-603-010 VR,RTRY 50K A MAIN ABCD................

VR 202 8Z-CM1-604-010 VR,RTRY 10K B TONE ABCD................

8Z-CM1-635-010 TUN-CAP, D/H AB..................

8Z-CM1-636-010 TUN-CAP, EZ ....................

8Z-CM1-638-010 TUN-CAP, SH ...D................

BPF 101 8Z-CM2-657-010 FLTR,BPF GFWB4SE A...................

C 107 87-A10-136-010 CAP,CER 10P-50K CH ABC.................

C 106 87-A10-136-010 CAP,CER 10P-50K CH ABC.................

C 107 87-A10-162-010 CAP CER 68P-50 KSL ....................

C 100 87-A10-176-010 CAP,CER 1000P-50 M D ABCD................

C 105 87-A10-176-010 CAP,CER 1000P-50 M D ABCD................

C 109 87-A10-180-010 CAP,CER 4700P M E A...................

C 108 87-A10-496-010 CAP,CER 18P-50 J CH ...D................

C 104 87-A10-577-010 CAP,CER 0.022-50 Z YF ABCD................

C 113 87-010-263-080 CAP, ELECT 100-10V A...................

C 110 87-010-380-080 CAP, ELECT 47-16V A...................

C 119 87-010-380-080 CAP, ELECT 47-16V A...................

C 114 87-010-404-080 CAP, ELECT 4.7-50V .BCD................

C 115 87-A10-166-010 CAP,CER 150P-50 K B ....................

C 117 87-A10-170-010 CAP,CER 330P-50 K B ....................

C 115 87-A10-171-010 CAP,CER 390P-50 K B ...D................

C 113 87-A10-176-010 CAP,CER 1000P-50 M D ABCD................

C 115 87-A10-277-080 CAP,M 330P-50 J .BC.................

C 117 87-A10-409-010 CAP,CER 1500P-25 K SR ...D................

C 124 87-010-400-080 CAP, ELECT 0.47-50V ABCD................

C 126 87-010-402-080 CAP, ELECT 2.2-50V .BCD................

C 121 87-010-404-080 CAP, ELECT 4.7-50V .BCD................

C 128 87-010-405-080 CAP, ELECT 10-50V ABCD................

ELECTRICAL MAIN PARTS LIST - 2

C 122 87-A10-182-010 CAP,CER 0.01-50 Z F ABCD................

C 133 87-010-221-080 CAP, ELECT 470-10V ABCD................

C 135 87-A10-176-010 CAP,CER 1000P-50 M D ABCD................

C 132 87-A10-182-010 CAP,CER 0.01-50 Z F ABCD................

C 134 87-A10-411-010 CAP,CER 0.047-16 K SR ABCD................

C 131 87-A10-413-010 CAP,CER 2200P-4K M E KX ABCD................

C 138 87-A10-577-010 CAP,CER 0.022-50 Z YF ABCD................

C 137 87-A10-577-010 CAP,CER 0.022-50 Z YF ABCD................

CF 102 87-008-261-010 FILTER, SFE10.7MA5-A ABCD................

CF 101 87-008-582-010 FLTR,SFU455B ABCD................

CF 103 87-A90-420-010 FLTR,CF CDA10.7MG1 .BCD................

D 105 87-002-850-080 ZENER,HZ4B2 ABCD................

D 108 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 103 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 104 87-020-605-080 DIODE,1SS135 A...................

D 106 87-020-605-080 DIODE,1SS135 A...................

D 107 87-020-605-080 DIODE,1SS135 A...................

D 109 87-020-605-080 DIODE,1SS135 A...................

D 103 87-A40-246-080 DIODE,IN4148 T-72 ABCD................

D 102 87-A40-246-080 DIODE,IN4148 T-72 ABCD................

D 101 87-A40-246-080 DIODE,IN4148 T-72 ABCD................

D 104 87-CD8-614-010 VARI-CAP,1S2638 .B..................

D 104 8Z-CM1-655-010 VARI-CAP, FV1043 ...D................

D 110 87-020-465-080 DIODE,1SS133 (110MA) A...................

IC 102 8Z-CM2-645-010 IC,TA7640AP A...................

IC 101 8Z-CM2-646-010 IC,TA2132 .BCD................

L 106 87-005-692-080 COIL,47UH ...D................

L 103 8Z-CM2-625-010 COIL,FM RF1.5T3.2MM A...................

L 102 8Z-CM2-626-010 COIL,FM RF1.5T1.7MM A...................

L 101 8Z-CM2-627-010 COIL,FM RF6.5T4.5MM A...................

L 102 8Z-CM2-628-010 COIL,FM RF4.5T5MM .BC.................

L 104 8Z-CM2-629-010 COIL,FM OSC3.5T A...................

L 105 8Z-CM2-630-010 COIL,FM OSC1.5T2.5MM A...................

L 106 8Z-CM2-631-010 COIL,FM OSC1.5T3.2MM A...................

L 103 8Z-CM2-632-010 COIL,FM OSC4T4.5MM .B..................

L 107 8Z-CM2-641-010 COIL,BAR ANTAMW A...................

L 104 8Z-CM2-642-010 COIL,BAR ANTMW .BCD................

L 105 8Z-CM2-643-010 COIL,BAR ANTSW .BCD................

L 103 8Z-CM2-660-010 COIL,FM OSC3T5.5MM ..C.................

L 102 8Z-CM2-661-010 COIL,FM RF4T5MM ...D................

L 103 8Z-CM2-662-010 COIL,FM OSC3T5MM ...D................

L 105 8Z-CM2-668-010 COIL,BAR ANTLW ....................

Q 101 8Z-CM2-658-010 TR,2SC9018F A...................

S 101 8Z-CM2-649-010 SW,SL 2-6-3 BAND ABC.................

S 101 8Z-CM2-659-010 SW,SL 2-6-4 BAND ...D................

T 104 8Z-CM2-633-010 COIL,FM DET A...................

T 101 8Z-CM2-634-010 COIL,FM IFT A...................

T 102 8Z-CM2-635-010 COIL,AM OSC A...................

T 103 8Z-CM2-636-010 COIL,AM IFT1 A...................

T 104 8Z-CM2-637-010 COIL,AM IFT2 ABCD................

T 101 8Z-CM2-638-010 COIL,MW OSC .BCD................

T 102 8Z-CM2-639-010 COIL,SW OSC .BC.................

T 102 8Z-CM2-663-010 COIL,SW1 OSC ...D................

T 103 8Z-CM2-664-010 COIL,SW2,OSC ...D................

T 105 8Z-CM2-665-010 COIL,SW2 ANT ...D................

T 101 8Z-CM2-667-010 COIL,LWOSC ....................

TC 104 87-011-252-080 TRIMMMER 10P LAR ABCD................

TC 101 87-011-252-080 TRIMMMER 10P LAR ABCD................

TC 103 87-011-252-080 TRIMMMER 10P LAR ABCD................

TC 102 87-011-252-080 TRIMMMER 10P LAR ABCD................

VR 101 8Z-CM2-666-010 VR,RTRY 50KAX1 1 V FINE TUNE ...D................

MECHANICAL PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

HEJ(S) .................XX....................................C.................

SHJ(S) .................XX.....................................D................

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-CM2-002-010 CABI,REAR D (RM-65) A...................

8Z-CM2-006-010 POINTER, ABCD................

8Z-CM2-008-010 COVER, CASS (RM-65) A...................

8Z-CM2-009-010 HLDR,CASS A.CD................

8Z-CM2-010-010 WINDOW,TUNING (RM-65) A...................

8Z-CM2-017-010 HANDL, A...................

8Z-CM2-018-010 COVER, HANDLE A...................

8Z-CM2-019-010 LID,BATT A...................

8Z-CM2-021-010 CABI,REAR HE ..C.................

8Z-CM2-022-010 CABI,REAR SH ...D................

8Z-CM2-023-010 CABI,REAR EZ ....................

8Z-CM2-024-010 COVER, CASS EX ..CD................

8Z-CM2-025-010 WINDOW,TUNING HE ..C.................

8Z-CM2-026-010 WINDOW,TUNING SH ...D................

8Z-CM2-027-010 WINDOW,TUNING EZ ....................

8Z-CM2-036-010 HANDL,EX ..CD................

8Z-CM2-037-010 COVER, HANDLE EX ..CD................

8Z-CM2-038-010 LID,BATT EX ..CD................

8Z-CM2-042-010 CABI,REAR D (ST) .B..................

8Z-CM2-047-010 COVER, CASS (RM-61) .B..................

8Z-CM2-048-010 HLDR,CASS (ST) .B..................

8Z-CM2-049-010 WINDOW,TUNING (RM-61) .B..................

8Z-CM2-056-010 HANDL,(ST) .B..................

8Z-CM2-057-010 COVER, HANDLE (ST) .B..................

8Z-CM2-058-010 LID,BATT (ST) .B..................

8Z-CM2-061-010 CABI,FR D ASSY (ST) ....................

8Z-CM2-062-010 CABI,FR D ASSY (S) ....................

8Z-CM2-063-010 CABI,FR EX ASSY (S) ..CD................

8Z-CM2-003-010 KNOB,SL FUNCTION A.CD................

8Z-CM2-004-010 KNOB,SL BAND A.CD................

8Z-CM2-005-010 KNOB,RTRY VOLUME A.CD................

8Z-CM2-007-010 KNOB,RTRY TUNING A.CD................

8Z-CM2-011-010 KEY,CASS PAUSE A.CD................

8Z-CM2-012-010 KEY,CASS STOP A.CD................

8Z-CM2-013-010 KEY,CASS FF A.CD................

8Z-CM2-014-010 KEY,CASS REW A.CD................

8Z-CM2-015-010 KEY,CASS PLAY A.CD................

8Z-CM2-016-010 KEY,CASS REC A.CD................

8Z-CM2-032-010 KNOB,SL BEAT A.CD................

8Z-CM2-033-010 KNOB,RTRY FINE TU ...D................

8Z-CM2-043-010 KNOB,SL FUNCTION (ST) .B..................

8Z-CM2-044-010 KNOB,SL BAND (ST) .B..................

8Z-CM2-045-010 KNOB,RTRY VOLUME (ST) .B..................

8Z-CM2-046-010 KNOB,RTRY TUNING (ST) .B..................

8Z-CM2-050-010 KEY,CASS PAUSE (ST) .B..................

8Z-CM2-051-010 KEY,CASS STOP (ST) .B..................

8Z-CM2-052-010 KEY,CASS FF (ST) .B..................

8Z-CM2-053-010 KEY,CASS REW (ST) .B..................

8Z-CM2-054-010 KEY,CASS PLAY (ST) .B..................

8Z-CM2-055-010 KEY,CASS REC (ST) .B..................

8Z-CM2-060-010 KNOB,SL BEAT (ST) .B..................

85-CM1-211-010 SPR,BATT(-) ABCD................

85-CM1-212-010 SPR,BATT(+/-) ABCD................

86-CM2-212-010 SPR-T,CASS ABCD................

8Z-CM2-201-010 GEAR,TUNING ABCD................

8Z-CM2-202-010 HLDR,BAR-ANT ABCD................

8Z-CM2-203-010 BLIND,CASS ABCD................

8Z-CM2-204-010 HLDR,BAND ABCD................

8Z-CM2-205-010 COVER, POINTER ABCD................

8Z-CM2-206-010 SPR,BATT (+) ABCD................

8Z-CM2-208-010 GEAR,CASS ABCD................

8Z-CM2-209-010 HLDR,GEAR CASS ABCD................

8Z-CM2-210-010 COVER, AC SOCKET ABCD................

8Z-CM2-211-010 COVER, VOLTAGE ..CD................

* 8Z-CM2-207-010 PLATE,REC ABCD................

87-261-073-410 V+2.6-6 ABCD................

87-741-095-410 UT2+3-8 GLD ABCD................

87-741-100-410 UT2+3-16(W/O) SLOT ABCD................

87-751-074-410 VT2+2.6-8 W/0 CUT ABCD................

87-A60-178-010 JACK,AC E W/SW ..CD................

87-A60-179-010 JACK,AC D W/SW AB..................

87-A90-086-010 COVER,AC-SOCKET ..CD................

87-A90-146-010 SW,SL 1-1-2 ..CD................

88-CS8-625-010 MIC,ECM ABCD................

8Z-CM2-604-010 PT,D ZCM-2 AB..................

8Z-CM2-605-010 PT,E ZCM-2 ....................

8Z-CM2-606-010 PT,H ZCM-2 ..CD................

8Z-CM2-607-010 SPKR,F 4 4OHM ABCD................

8Z-CM2-608-010 ANT,ROD FM ZCM-2 ABCD................

8Z-CM2-640-010 BAR-ANT,AM ABCD................

8Z-CM1-608-010 JACK, EP ZCM-1 ABCD................

8Z-CM1-635-010 TUN-CAP, D/H AB..................

8Z-CM1-636-010 TUN-CAP, EZ ....................

8Z-CM1-638-010 TUN-CAP, SH ...D................

ACCESSORIES LIST

NOTE: The characters in the suffix column indicate the part usage.

HEJ(S) .................XX....................................C.................

SHJ(S) .................XX.....................................D................

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-CM2-901-010 IB,D(J)A,65 A...................

8Z-CM2-907-010 IB,H(ECA)A ..CD................

8Z-CM2-908-010 IB,EZ(9L)A ....................

8Z-CM2-911-010 IB,D(J)A,61 .B..................

87-099-789-010 PLUG,ADPTR IR44 ..CD................

87-A80-033-010 AC CORD SET,D BLK AB..................

87-A80-081-010 AC CORD SET ASSY,EZ BLK ..CD................

Printed in Singapore

Tokyo Japan

931196

Other manuals for RM-67

Table of contents

Popular Cassette Player manuals by other brands

Goodmans

Goodmans MICRO1461 instructions

Pioneer

Pioneer XR-P260F Service manual

Teac

Teac AD-850-SE owner's manual

Philips

Philips AQ6601/00 user manual

Technics

Technics RS-TR474 operating instructions

Rotel

Rotel RD-850 owner's manual

Sony

Sony TC-K909ES operating instructions

Sony

Sony cfs-ew60s Service manual

Philips

Philips AW 7530 user manual

Philips

Philips AQ6542/01 user manual

Magnavox

Magnavox AZ 1602 owner's manual

Sherwood

Sherwood DS-7C operating instructions

Sony

Sony Walkman WM-EX910 operating instructions

Technics

Technics RS-TR979 operating instructions

Sony

Sony Pressman TCM-465V Operation manual

Panasonic

Panasonic RC-X260 operating instructions

Crosley

Crosley CT200A instruction manual

Philips

Philips AQ6581/14 Product information

Aiwa RM-67 User manual

Popular Cassette Player manuals by other brands
