Aiwa RM-P33 User manual
BASIC TAPE MECHANISM : TN-9ZR-215
RADIO CASSETTE RECORDER
RM-P33
S/M Code No. 09-997-333-7R1
AHRJ(S),AHKJ(S)
AEZ(S)
SERVICE MANUAL
REVISION
DATA
This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
(S/M Code No. 09-997-333-7T1).
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
2
SPECIFICATIONS
Tuner section
Frequency range: FM: 87.5 - 108.0 MHz
AM: 530 - 1,605 kHz
Antenna: FM: Rod antenna
AM :Ferrite bar antenna
Deck section
Track format 2tracks, 1 channel
Frequency range Normal tape: 50 - 8,000 Hz (EIAJ)
Recording system AC bias
Erasing system Magnet erase
Heads Recording playback head (1)
Erasure head (1)
General
Speaker 58 mm cone type (1)
Output Earphone jack (monaural mini-jack)
Power output 0.5 W (EIAJ 8 ohms, T.H.D. 10%)
0.3 W (DIN 1% Rated Power)
Power requirements DC 6 V using for size AA (R6P) batteries
Domestic AC power using the supplied
AC adaptor
Dimensions 207 (W) x 93 (H) x 56 (D) mm
Weight 480 g (excluding batteries)
REF. NO PART NO. KANRI DESCRIPTION
NO.
ACCESSORIES LIST
1 8Z-CM3-907-010 IB,H(ECA)A<AHR,AHK>
1 8Z-CM3-908-010 IB,EZ(9L)A<AEZ>
2 87-B30-164-010 AC ADAPTOR,AC-D602E<AEZ>
2 87-B30-165-010 AC ADAPTOR,AC-D602K<AHK>
2 87-B30-166-010 AC ADAPTOR,AC-D602H<AHR>
AC adaptor
<AC-D602 K> (AHK)
Rated input AC 230 V, 50 Hz
Rated output DC 6 V, 500 mA
<AC-D602 H> (AHR)
Rated input AC 110 - 120 V/220 - 240 V, 50/60 Hz
Rated output DC 6 V, 500 mA
<AC-D602 E> (AEZ)
Rated input AC 230 V, 50 Hz
Rated output DC 6 V, 500 mA
• Design and specifications are subject to change without notice.
w
w
w
.
x
i
a
