SERVICE MANUAL
DATA
STEREO RADIO
CASSETTE PLAYER
BASIC TAPE MECHANISM : 8ZM-3 P9NF,
8ZM-3 P11NF
HS-TX516
HS-TX519
YU,YL,YZ
YZ
S/M Code No. 09-00C-438-8N1
Design and specifications are subject to change without notice.
SPECIFICATIONS
Frequency range: For using in Europe and other countries
AM: 531 - 1,6 2 kHz (9 kHz step)
FM1, FM2: 87.5 - 1 8 MHz (5 kHz step)
For using in North and South America
AM: 53 - 1,71 kHz (1 kHz step)
FM1, FM2: 87.5 - 1 8.1 MHz (2 kHz step)
For using in Japan<YU,YL>
AM : 531 - 1,629 kHz (9 kHz step)
FM1, FM2 : 76 - 1 8 MHz (1 kHz step in 76 - 9 MHz, 5 kHz step in 9 - 1 8 MHz)
aximum output: 4 mW + 4 mW (EIAJ 16 ohms)<YZ>
12 mW + 12 mW (EIAJ 32 ohms)<YU,YL>
Load impedance: 16 - 8 ohms<YZ>
Power source: DC 3V using two R6 (AA) dry cell batteries
Battery life (EIAJ, 1 mW output Playback):
Approx. 7 hours using R6P (size AA) manganese batteries
Approx. 24 hours using LR6 (size AA) alkaline batteries
aximum dimensions: 111.3 (W) x 83 (H) x 29 (D) mm (excluding projecting parts and controls)<YZ,YL>
111.3 (W) x 83 (H) x 29 (D) mm (4 1/2 x 3 3/8 x 1 3/16 in.)
(excluding projecting parts and controls)<YU>
Weight Approx. 138g excluding batteries<YZ,YL>
Approx. 138g (4.8 oz) excluding batteries<YU>
2
1 8B-HRE-904-010 IB,YL(3L)S<[S]516YL>
1 8B-HRE-901-010 IB,YU(3L)S<[S]516YU>
1 8B-HRE-905-010 IB,YZ(EGF)S 516<[L]516YZ,[S]516YZ>
1 8B-HRE-915-010 IB,YZ(EGF)S 519<[S]519YZ1B,[S]519YZ>
1 8B-HRE-907-010 IB,YZ(PH CZ)S 516<[L]516YZ,[S]516YZ>
1 8B-HRE-917-010 IB,YZ(PH CZ)S 519<[S]519YZ1B,[S]519YZ>
1 8B-HRE-906-010 IB,YZ(SID)S 516<[L]516YZ,[S]516YZ>
1 8B-HRE-916-010 IB,YZ(SID)S 519<[S]519YZ1B,[S]519YZ>
2 8Z-HRB-050-310 CLIP,BELT ASSY
3 87-B30-080-210 HEADPHO E,HP-M009(F)<[S]516YU>
3 87-B30-397-110 HEADPHO E,HP-M029(T2)<[S]516YL,[L]516YZ,[S]516YZ>
3 87-B30-250-010 HEADPHO E,HP-M042 (T)<[S]519YZ1B,[S]519YZ>
4 8A-HRE-951-010 RC U IT,RC606<[S]519YZ1B,[S]519YZ>
DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
ACCESSORIES / PACKAGE LIST
DESCRIPTION
REF. NO. KANRI
NO.
PART NO. DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
ELECTRICAL MAIN PARTS LIST 1 / 1
3
IC
87-A21-684-040 C-IC,TA2145AF
87-A20-851-040 C-IC,TA2111F
87-A21-846-030 C-IC,LC72348G-9A01
TRA SISTOR
87-026-418-080 TR,R 1311
87-026-411-080 C-TR R 1304
87-A30-085-040 C-TR,CSA1362GR
87-026-429-080 TR,R 2311
89-342-153-080 TR,2SC4215O
87-026-417-080 TR,R 1310
DIODE
87-A40-957-040 C-VARI-CAP,HVC200A
87-A40-462-040 C-VARI-CAP,SVC347(S)
87-A40-260-080 C-ZE ER,UDZ2.0B
87-A40-883-040 C-ZE ER,02DZ13-Y
87-001-553-080 C-DIODE 1SS322
87-A40-360-080 C-DIODE,MA786
MAI C.B
87-A91-728-110 FLTR,KIT KMFC5184-A
BPF200 87-A91-682-010 FLTR,GFWB7-C1
C101 87-012-276-080 CAP, CHIP SS 1500 PBK
C102 87-012-276-080 CAP, CHIP SS 1500 PBK
C103 87-A10-418-080 C-CAP,T 22-4 A TCF
C104 87-A10-418-080 C-CAP,T 22-4 A TCF
C105 87-012-273-080 C-CAP,U 820P-50 B
C106 87-012-273-080 C-CAP,U 820P-50 B
C107 87-010-805-080 CAP, S 1-16
C108 87-010-805-080 CAP, S 1-16
C109 87-A10-489-040 CAP,E 220-4 7L SR<519YZ>
C110 87-010-853-080 C-CAP,220-4V H5.5<519YZ>
C112 87-016-296-080 C-CAP,T 22-4SV(A)
C113 87-010-831-080 C-CAP,U,0.1-16F
C114 87-A11-056-080 C-CAP,U 1-10 Z F
C115 87-012-274-080 CHIP CAP,U 1000P-50B
C116 87-012-274-080 CHIP CAP,U 1000P-50B
C117 87-A11-056-080 C-CAP,U 1-10 Z F
C118 87-A11-056-080 C-CAP,U 1-10 Z F
C119 87-A11-056-080 C-CAP,U 1-10 Z F
C120 87-010-503-040 CAP,E 220-4 GAS
C121 87-010-503-040 CAP,E 220-4 GAS
C122 87-010-503-040 CAP,E 220-4 GAS
C124 87-A11-056-080 C-CAP,U 1-10 Z F<EXCEPT 519YZ>
C125 87-A11-056-080 C-CAP,U 1-10 Z F
C126 87-A11-056-080 C-CAP,U 1-10 Z F
C127 87-A11-056-080 C-CAP,U 1-10 Z F
C128 87-A11-056-080 C-CAP,U 1-10 Z F
C150 87-012-271-080 CAP, U 560P-50
C200 87-A10-707-080 C-CAP,U 0.47U-16 F Z
C201 87-010-420-080 C-CAP,T 4.7-4 A TCF
C202 87-A11-056-080 C-CAP,U 1-10 Z F
C203 87-010-785-080 C-CAP,U0.015-25BK
C204 87-010-785-080 C-CAP,U0.015-25BK
C205 87-010-831-080 C-CAP,U,0.1-16F
C206 87-010-831-080 C-CAP,U,0.1-16F
C207 87-010-831-080 C-CAP,U,0.1-16F
C208 87-A11-056-080 C-CAP,U 1-10 Z F
C209 87-010-831-080 C-CAP,U,0.1-16F
C210 87-A11-056-080 C-CAP,U 1-10 Z F
C211 87-A11-056-080 C-CAP,U 1-10 Z F
C212 87-012-274-080 CHIP CAP,U 1000P-50B
C213 87-012-286-080 CAP, U 0.01-25
C214 87-012-172-080 CAPACITOR CHIP U 10P CH
C216 87-012-178-080 C-CAP,U 18P-50 CH
C217 87-012-162-080 C-CAP,U 1P-50 CK
C218 87-012-162-080 C-CAP,U 1P-50 CK
C219 87-010-831-080 C-CAP,U,0.1-16F
C220 87-012-199-080 CAP 220P
C221 87-012-286-080 CAP, U 0.01-25
C222 87-A11-056-080 C-CAP,U 1-10 Z F
C224 87-012-286-080 CAP, U 0.01-25
C225 87-A12-790-080 C-CAP,U 560P-50 J CH
C227 87-012-193-080 C-CAP,U 82P-50 CH
C228 87-012-271-080 CAP, U 560P-50
C229 87-010-829-080 CAP, U 0.047-16
C230 87-010-831-080 C-CAP,U,0.1-16F
C231 87-012-274-080 CHIP CAP,U 1000P-50B
C232 87-010-853-080 C-CAP,220-4V H5.5
C251 87-A11-056-080 C-CAP,U 1-10 Z F
C300 87-012-170-080 C-CAP,U 8P-50 CH
C301 87-012-170-080 C-CAP,U 8P-50 CH
C304 87-012-274-080 CHIP CAP,U 1000P-50B
C305 87-A11-056-080 C-CAP,U 1-10 Z F
C306 87-A11-056-080 C-CAP,U 1-10 Z F
C307 87-010-831-080 C-CAP,U,0.1-16F
C308 87-016-396-080 C-CAP,U 0.22-16F
C309 87-010-831-080 C-CAP,U,0.1-16F
C310 87-012-286-080 CAP, U 0.01-25
C311 87-A11-056-080 C-CAP,U 1-10 Z F
C312 87-010-831-080 C-CAP,U,0.1-16F
C313 87-A11-282-080 C-CAP,S 1-16 K B
C314 87-012-286-080 CAP, U 0.01-25
C315 87-012-286-080 CAP, U 0.01-25
C316 87-A10-489-040 CAP,E 220-4 7L SR
C400 87-010-831-080 C-CAP,U,0.1-16F
C401 87-010-831-080 C-CAP,U,0.1-16F
C500 87-012-274-080 CHIP CAP,U 1000P-50B
C550 87-012-277-080 C-CAP, U 1800P-50 B
C590 87-012-270-080 CAP, U 470P-50<EXCEPT 519YZ>
C592 87-012-286-080 CAP, U 0.01-25<EXCEPT 519YZ>
C950 87-A11-056-080 C-CAP,U 1-10 Z F
CF200 87-A90-710-010 FLTR,AM IF PFS450A3
IFT200 87-A90-663-010 IFT,MW 5L H6.4
J100 87-A60-438-010 JACK,3.5BLKSTW/OSW<EXCEPT 519YZ>
J100 87-A60-437-010 JACK,3.5BLKSTW/OSW 4P<519YZ>
L100 87-A50-605-010 COIL,RF CHOKE CECS
L101 87-003-240-080 C-COIL,S 3.3UH K MLF2012<519YZ>
L200 87-005-742-080 COIL,100UH J SP02
L201 8B-HRC-603-010 COIL, FM OSC
L202 8B-HRC-604-010 COIL, FM RF
L203 8Z-HRC-605-010 BAR-A T,MW
L301 87-005-575-080 C-COIL, 220UH K FLC32
L591 87-A50-189-080 C-COIL,S BLM21B272S<EXCEPT 519YZ>
LCD300 8B-HRC-602-010 LCD,ASSY(BHR-C) 17P
R113 87-012-172-080 C-CAP U 10P CH<EXCEPT 519YZ>
R122 87-A00-530-080 C-RES,S 180-1/10W F
R310 87-022-289-080 C-RES U180K 1/16WF<519YZ>
R316 87-022-294-080 C-RES,U 470K 1-16W F
R317 87-022-287-080 C-RES,U 120K-1/16W F
S100 87-A91-077-010 SW,LEAF
S102 87-A91-191-010 SW,SL 2-2-2 SK22D04
S300 87-A90-050-010 SW, SL 2-2-2 S (BLK)
SFR100 87-A92-045-040 C-SFR,K 1K H RH03AEC
TC200 87-A91-762-180 C-TRIMMER,10P TZVY2Z100A
VR100 87-A90-981-010 VR,RTRY 20KBX1
X300 87-A70-173-010 VIB,XTAL 75KHZ DT-261
TRANSISTOR ILLUSTRATION
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form
LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ
1.0 0.5 0.35 104
Lt
W
2SC4215
CSA1362
RN1304
RN1310
RN1311
RN2311
B
E
C
4
WIRING
16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
5
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
SCHEMATIC DIAGRAM
6
VT
LCD DISPLAY
7
LCD, ASSY (BHR-C) 17P
8
Pin No. Pin Name I/O Descri tion
IC, LC72348G-9A01
1 XOUT O Crystal oscillator (75kHz pin.
2 TEST2 I Connected to ground.
3~6 PA3~PA0 I Key input. H:Key exist, L:No Key. (Not Used
7~8 PB3~PB2 O Not used.
9~10 PB1~PB0 O Key output. H:Scan, L:Standby. (Not used
11 PC3(FM/AM O Output band. H:FM band, L:AM band.
12 PC2(TV OUT O Output band. H:FM/TV band, L:AM band. (Not used
13 PC1(S-Bass O Output S-Bass. H:Flat, L:S-Bass.
14 PC0(DES 1 I Input destination.
Destination 14Pin 15Pin 16Pin
USA L H L
15 PD3(DES 2 I EUROPE L L H
EAST EUROPE L L L
GENERAL L H H
16 PD2(DES 3 I USA WIDE 1 H H H
USA WIDE 2 H H L
JAPAN H L H
17 PD1(TAPE I Input tape display. H:Display ON, L:Dispaly OFF.
18 INT/PD0 I Input backup while HACT status. H:Normal, L:Backup.
19 VC/PE1 - Not used.
20 BEEP/PE0 O Output beep sound.
21 PF2 I Input backup. H:Normal, L:Backup.
22 AD11/PF1(POW CH I Input power check (A/D .
23 AD10/PF0(REMOTE I Input remote controller (A/D .
24 VSS - Connected to ground..
25 PG3(POW SW /S20 O Output power. H:OFF, L:ON.
26 PG2(HOLD /S19 I Input hold key. H:Hold OFF, L:Hold ON.
27 PG1(MUTE /S18 O Output mute. H:Mute OFF, L:Mute ON.
28 PG0(TU OUT /S17 O Output tuner/tape. H:Tape, L:Radio.
29 PH3(TU IN /S16 I Input [TUNED] display. H:Display OFF, L:Dispaly ON.
30 PH2(PRE OFF /S15 O Output PRE OFF. H:PRE OFF, L:PRE ON.
31 PH1(NC /S14 O Not connected.
32~44 PH0,S12~1/S13 O Output LCD segment.
45~48 COM1~4 O Output LCD common.
49~52 DBR4~1 - LCD power supply.
53 RES I Input reset.
54 HCTR O DC-DC convertor.
55 VDD - Positive power supply.
56 FMIN I Input FM broadcast.
57 AMIN I Input AM broadcast.
58 VSS - Connected to ground.
IC DESCRIPTION
Pin No. Pin Name I/O Descri tion
59 EO O Output error.
60 AIN I Output low pass filter.
61 VT O VT input.
62 AGND - Connected to ground.
63 TEST1 I Connected to ground.
64 XIN I Crystal oscillator (75kHz pin.
9
ADJUSTMENT
<RADIO SECTION>
1. AM IF Adjustment
IFT200 ............................................................................... 450kHz
2. AM Tracking Adjustment
L203 ................................................................................. 630kHz
TC200 ............................................................................. 1440kHz
3. FM VT Adjustment
Settings: Test point TP1 (VT
Adjustment location ............................................................... L201
Method: Set to FM 65MHz, and adjust L201 so that the test
point becomes 1.0V ± 0.1V. Then set to FM108.1MHz
and check that the test point is 7.6V ± 0.6V.
4. FM Tracking Adjustment
L202 .................................................................................. 76MHz
<TAPE PLAYER SECTION>
5. Tape Speed Adjustment
Settings: Test tape : TTA100
Test point : PHONES (J100
Adjustment location : SFR100
Super Bass: OFF
Volume: MAX
Method: Play back the test tape and adjust SFR100 for
3000Hz ± 10Hz (FWD .
Then confirm WOW is less than 0.50%.
10
MECHANICAL E PLODED VIEW 1 / 1
11
1
2
BAR ANT,MW
8ZM-3
3
4
PWB
5
6
A
BBE
F
C
7
8
9
10
11
D
HS-TX516 YUBSF,YL1BSF,YL1SF,YZ1BLF,YZ1SF
DESCRIPTION
REF. NO. KANRI
NO.
PART NO. DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
MECHANICAL PARTS LIST 1 / 1
12
1 8B-HRE-001-010 LID,CASS<[S]516YU,[S]516YL>
1 8B-HRE-018-010 LID,CASS BLU EG<[L]516YZ>
1 8B-HRE-012-010 LID,CASS EG<[S]519YZ,[S]516YZ>
2 8A-HRH-209-010 SPR-T,CASS
3 8Z-HRB-201-110 HLDR,BAR-A T
4 8Z-HRB-208-010 BAT-CO TACT,P
5 8Z-HRB-209-010 BAT-CO TACT,M
6 8B-HRC-015-010 LID,BAT BLU<[L]516YZ>
6 8Z-HRB-005-110 LID,BAT SIL<EXCEPT [L]516YZ>
7 8B-HRE-013-010 CABI,REAR 516 EG<[S]516YZ>
7 8B-HRE-015-010 CABI,REAR 519 EG<[S]519YZ>
7 8B-HRE-002-010 CABI,REAR<[S]516YU,[S]516YL>
7 8B-HRE-017-010 CABI,REAR BLU 516 EG<[L]516YZ>
8 8B-HRE-006-010 BT ,RBR
9 8B-HRE-005-010 KEY,PRESET
10 8B-HRE-003-010 PA EL,REAR
11 8B-HRE-004-010 KEY,BA D
A 87-B10-048-010 VT2+1.4-3 (3) CR HL
B 87-B10-196-010 VT2+1.4-4 BLK (3) HL
C 87-264-527-310 V 1.7-3 SCREW
D 8Z-HRB-223-010 W,2-9-0.5 W/ADH
E 87-067-384-010 SCREWVT1.4-3.5HL
F 87-067-732-010 VT2+1.4-3 CR BLK HL
COLOR NAME TABLE
Basic color symbol Color Basic color symbol Color Basic color symbol Color
B Black C Cream D Orange
G Green H Gray L Blue
LT Transparent Blue N Gold P Pink
R Red S Sil er ST Titan Sil er
T Brown V Violet W White
WT Transparent White Y Yellow YT Transparent Yellow
LM Metallic Blue LL Light Blue GT Transparent Green
LD Dark Blue DT Transparent Orange GM Metallic Green
YM Metallic Yellow DM Metallic Orange PT Transparent Pink
LA Aqua Blue GL Light Green
TAPE MECHANISM E PLODED VIEW 1 / 1
13
8ZM-3 P9NF : E CEPT HS-T 516<YZ1BLF>
24
26
25 W-P,1.16-2.8-0.4
31
32
27 30
34 36
35
37 39
28
38
29
21
22 23
20
1
918
17
15
14
16
13
12
11
10
23
8
42
41 43
40
7
5
6
44
45
46
47
48
49
50
33
2
1
3
4
A
8ZM-3 P9NF,P11NF
(FileName:MECH.EPS)
9
HEAD ASSY,
PH 8ZM-3
DESCRIPTION
REF. NO. KANRI
NO.
PART NO. DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
TAPE MECHANISM PARTS LIST 1 / 1
8ZM-3 P9NF : E CEPT HS-T 516<YZ1BLF>
14
1 8A-HRE-010-110 FRAME,CE TER GRY
2 8Z-HRB-207-110 SPR-P,CASS
3 88-ZM3-253-110 SPR-C,BT L
4 88-ZM3-274-010 GEAR,REEL A
5 87-A91-379-010 MOT,BCY3B-13
6 88-ZM3-236-010 PULLEY,MOT S
7 88-ZM3-263-210 BELT,S
8 88-ZM3-243-010 SPR-T,PLAY BACK
9 88-ZM3-217-210 ARM,PI CH L
10 88-ZM3-241-110 SPR-T,PI CH L
11 88-ZM3-009-010 LEVER,REW P9
12 88-ZM3-246-110 SPR-T,FF REW
13 87-A80-115-010 F-CABLE,5P P2
14 8Z-HRB-202-110 HLDR,DC JACK
15 88-ZM3-211-010 LEVER,DIR
16 88-ZM3-007-010 LEVER,PLAY P9
17 88-ZM3-213-310 LEVER,T-UP
18 88-ZM3-225-110 GEAR,PLAY
19 88-ZM3-224-210 GEAR,TRA SMIT
20 88-ZM3-008-010 LEVER,FF P9
21 88-ZM3-242-210 SPR-T,PI CH R
22 88-ZM3-218-110 ARM,PI CH R
23 88-ZM3-271-010 ROLLER ASSY,PI CH
24 88-ZM3-220-110 BT ,MODE SEL
25 88-ZM3-267-010 SHAFT,PULLEY TWI
26 88-ZM3-234-010 PULLEY,BELT TWI
27 88-ZM3-212-110 LEVER,LOCK
28 88-ZM3-245-110 SPR-T,LOCK
29 88-ZM3-201-410 CHAS ASSY,OUTSERT P
30 88-ZM3-216-110 LEVER,SW
31 88-ZM3-221-110 GEAR,AUTO
32 09-001-453-010 FLY-WHL,R S
33 88-ZM3-223-010 GEAR,SLIP SLOW
34 88-ZM3-248-010 SPR-T,AUTO CHOOSE
35 88-ZM3-215-110 LEVER,AUTO KICK
36 88-ZM3-262-010 BELT,L
37 88-ZM3-244-010 SPR-T,DIR
38 88-ZM3-219-010 BT ,DIR K OB
39 88-ZM3-280-010 FLY-WHL ASSY,L2
40 88-ZM3-226-010 GEAR,IDLE
41 88-ZM3-010-110 LEVER,STOP P9
42 88-ZM3-255-210 SPR-C,STOP
43 88-ZM3-214-110 LEVER,AUTO FI D
44 88-ZM3-238-010 CAP,SLIP
45 88-ZM3-252-010 SPR-C,SHIFT
46 88-ZM3-251-310 SPR-C,SLIP
47 88-ZM3-222-110 GEAR,SLIP FAST
48 88-ZM3-269-110 FELT,SLIP
49 88-ZM3-237-110 CLR,SLIP
50 88-ZM3-247-010 SPR-T,AUTO FI D
A 87-B10-196-010 VT2+1.4-4 BLK (3) HL
8ZM-3 P11NF : HS-T 516<YZ1BLF>
TAPE MECHANISM E PLODED VIEW 1 / 1
15
24
26
25 W-P,1.16-2.8-0.4
31
32
27 30
34 36
35
37 39
28
38
29
21
22 23
20
1
918
17
15
14
16
13
12
11
10
23
8
42
41 43
40
7
5
6
44
45
46
47
48
49
50
33
2
1
3
4
A
8ZM-3 P9NF,P11NF
(FileName:MECH.EPS)
9
HEAD ASSY,
PH 8ZM-3
DESCRIPTION
REF. NO. KANRI
NO.
PART NO. DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
TAPE MECHANISM PARTS LIST 1 / 1
16
8ZM-3 P11NF : HS-T 516<YZ1BLF>
1 8B-HRE-019-110 FRAME,CE TER BLU
2 8Z-HRB-207-110 SPR-P,CASS
3 88-ZM3-253-110 SPR-C,BT L
4 88-ZM3-274-010 GEAR,REEL A
5 87-A91-379-010 MOT,BCY3B-13
6 88-ZM3-236-010 PULLEY,MOT S
7 88-ZM3-263-210 BELT,S
8 88-ZM3-243-010 SPR-T,PLAY BACK
9 88-ZM3-217-210 ARM,PI CH L
10 88-ZM3-241-110 SPR-T,PI CH L
11 88-ZM3-009-010 LEVER,REW P9
12 88-ZM3-246-110 SPR-T,FF REW
13 87-A80-115-010 F-CABLE,5P P2
14 8Z-HRB-202-110 HLDR,DC JACK
15 88-ZM3-211-010 LEVER,DIR
16 88-ZM3-007-010 LEVER,PLAY P9
17 88-ZM3-213-310 LEVER,T-UP
18 88-ZM3-225-110 GEAR,PLAY
19 88-ZM3-224-210 GEAR,TRA SMIT
20 88-ZM3-008-010 LEVER,FF P9
21 88-ZM3-242-210 SPR-T,PI CH R
22 88-ZM3-218-110 ARM,PI CH R
23 88-ZM3-271-010 ROLLER ASSY,PI CH
24 88-ZM3-220-110 BT ,MODE SEL
25 88-ZM3-267-010 SHAFT,PULLEY TWI
26 88-ZM3-234-010 PULLEY,BELT TWI
27 88-ZM3-212-110 LEVER,LOCK
28 88-ZM3-245-110 SPR-T,LOCK
29 88-ZM3-201-410 CHAS ASSY,OUTSERT P
30 88-ZM3-216-110 LEVER,SW
31 88-ZM3-221-110 GEAR,AUTO
32 09-001-453-010 FLY-WHL ASSY,R S
33 88-ZM3-223-010 GEAR,SLIP SLOW
34 88-ZM3-248-010 SPR-T,AUTO CHOOSE
35 88-ZM3-215-110 LEVER,AUTO KICK
36 88-ZM3-262-010 BELT,L
37 88-ZM3-244-010 SPR-T,DIR
38 88-ZM3-219-010 BT ,DIR K OB
39 88-ZM3-280-010 FLY-WHL ASSY,L2
40 88-ZM3-226-010 GEAR,IDLE
41 88-ZM3-010-110 LEVER,STOP P9
42 88-ZM3-255-210 SPR-C,STOP
43 88-ZM3-214-110 LEVER,AUTO FI D
44 88-ZM3-238-010 CAP,SLIP
45 88-ZM3-252-010 SPR-C,SHIFT
46 88-ZM3-251-310 SPR-C,SLIP
47 88-ZM3-222-110 GEAR,SLIP FAST
48 88-ZM3-269-110 FELT,SLIP
49 88-ZM3-237-110 CLR,SLIP
50 88-ZM3-247-010 SPR-T,AUTO FI D
A 87-B10-196-010 VT2+1.4-4 BLK (3) HL
211, IKENOHATA 1CHOME, TAITO-KU, TOKYO 110, APAN TEL:03 (3827) 3111
Printed in Singapore9630472 0251431
Other manuals for HS-TX516
2
This manual suits for next models
3
Table of contents
Other Aiwa Cassette Player manuals
