SERVICE MANUAL

DATA

CASSETTE RECORDER

TP-VS485

Y, YH, YHT,

YJ, YL

S/M Code No. 09-008-435-9R1

REVISION

• This Service Manual is the "Revision Publishing" and replaces "Simple Manual"

(S/M Code No. 09-007-435-9T1).

BASIC TAPE MECHANISM : ZZM-6 R2NF

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

– 2 –

Track system 2 tracks 1 channel, monaural

Frequency response 250 – 8,000 Hz EIAJ

Microphone Electret condenser microphone (monaural)

Maximum output 300 mW (EIAJ/DC)

Input jack EXT MIC jack (monaural mini-jack) (1)

Output jack EARPHONE jack (monaural mini-jack) (1)

Other jack DC 3 V jack

Speaker Diameter 50 mm, 8 ohms

Recording system DC bias

Erasing system Magnet erasure

Power sources DC 3 V using two R6 (size AA) dry cell batteries

AC house current using the AC adaptor Aiwa AC–D302

Battery life Battery EIAJ Recording EIAJ 10 mW

Manganese (R6P) batteries Approx. 5 hrs Approx. 4 hrs

Alkaline (LR6) batteries Approx. 19 hrs Approx. 15 hrs

Maximum outside dimensions

111.7 (W) x 84.3 (H) x 33.6 (D) mm

(excluding projecting parts and controls)

Weight Approx.152 g (excluding batteries)

SPECIFICATIONS
