SERVICE MANUAL
HS-JS790 D
STEREO RADIO
CASSETTE RECORDER BASIC TAPE MECHANISM : 6ZM–2 R3NF
S/M Code No. 09-99B-418-5R2
REVISION
MODEL CODE : 8ZHJ8-0134<S>

SPECIFICATIONS
2

DESCRIPTIONREF.NO. KANRI
NO.
PART NO. KANRI
NO.
REF.NO. DESCRIPTIONPART NO.
ELECTRICAL MAIN PARTS LIST
3
IC
87-002-677-080 1E IC,TA2002F
8Z-HJ8-610-010 2M C-IC,TC9327AF-501
87-A20-638-080 1A C-IC,PST9120
87-A21-407-040 1E C-IC,TA2104BFN
87-A20-904-080 1B C-IC,TK11823MTL
87-A20-580-040 1E C-IC,BA3641FV
87-A20-532-040 1D IC,LB1977M
TRANSISTOR
87-026-299-080 0E C-TR FMG4
87-026-467-080 0E TR,HN1C01F (0.3W)
89-115-884-080 0E C-TR,2SA1588Y
87-026-429-080 0E TR,RN2311
89-327-143-080 0E TR,2SC2714 (0.1W)
89-113-625-080 0E TR,2SA1362GR
87-026-295-080 0E TR,DTC144TK
87-026-424-080 0E C-TR,RN2306
89-327-125-080 0E C-TR,2SC2712GR
89-342-153-080 0E TR,2SC4215
87-026-482-080 0E TR,RN4610
89-502-094-080 1A C-FET,2SK209Y
89-508-804-080 1A C-FET,2SK880Y
87-026-679-080 0E C-TR,FMA8A
87-026-678-080 0E C-TR FMG5A
87-026-470-080 1A TR,HN1C03FB(0.3W)
87-A30-125-080 0E C-TR,IMB3A
89-413-284-080 0E TR,2SD1328T
87-026-418-080 0E TR,RN1311 (0.1W)
89-333-266-080 0E C-TR,2SC3326B
DIODE
87-017-779-080 0E C-DIODE,1SS355
87-001-167-080 0E DIODE,1SS302 (100MA)
87-017-366-080 0E DIODE,DAN 202U
87-A40-395-080 0E C-ZENER,UDZ2.2B
87-017-367-080 0E DIODE,DAP 202U
87-A40-630-040 1A C-DIODE,RB411D
87-A40-360-080 0E C-DIODE,MA786
MAIN C.B
BPF201 87-A90-601-010 0E FLTR,BPF GFWB7
C1 87-012-272-080 0E C-CAP,U 680P-50 B
C2 87-012-272-080 0E C-CAP,U 680P-50 B
C3 87-012-272-080 0E C-CAP,U 680P-50 B
C4 87-012-272-080 0E C-CAP,U 680P-50 B
C5 87-012-286-080 0E CAP, U 0.01-25
C6 87-012-286-080 0E CAP, U 0.01-25
C7 87-A10-952-080 0E C-CAP,TN 22-4 M A MCM
C8 87-A10-952-080 0E C-CAP,TN 22-4 M A MCM
C9 87-010-787-080 0E CAP, U 0.022-25
C10 87-010-787-080 0E CAP, U 0.022-25
C21 87-A11-056-080 0E C-CAP,U 1-10 Z F
C22 87-A11-056-080 0E C-CAP,U 1-10 Z F
C23 87-A10-707-080 0E C-CAP,U 0.47U-16 F Z
C24 87-A10-707-080 0E C-CAP,U 0.47U-16 F Z
C25 87-A11-282-080 0E C-CAP,S 1-16 K B
C26 87-A11-282-080 0E C-CAP,S 1-16 K B
C27 87-A11-056-080 0E C-CAP,U 1-10 Z F
C28 87-A11-056-080 0E C-CAP,U 1-10 Z F
C41 87-012-278-080 0E C-CAP,U 2200P-50 B
C42 87-012-278-080 0E C-CAP,U 2200P-50 B
C43 87-010-424-080 0E CAPACTOR,TANTAL 4.7-4
C45 87-010-831-080 0E C-CAP,U,0.1-16F
C46 87-010-831-080 0E C-CAP,U,0.1-16F
C47 87-010-502-010 0E CAP GAS 100-4
C48 87-010-502-040 0E CAP ELECT GAS 100/4
C49 87-A11-056-080 0E C-CAP,U 1-10 Z F
C51 87-A11-056-080 0E C-CAP,U 1-10 Z F
C52 87-010-503-040 0E CAP,E 220-4 GAS
C53 87-A10-025-080 0E C-CAP,U 0.22-16Z F
C54 87-010-943-180 1A C-CAP,E 100-4 M MV
C55 87-010-502-040 0E CAP ELECT GAS 100/4
C56 87-012-286-080 0E CAP, U 0.01-25
C151 87-012-274-080 0E CHIP CAP,U 1000P-50B
C152 87-012-274-080 0E CHIP CAP,U 1000P-50B
C153 87-012-274-080 0E CHIP CAP,U 1000P-50B
C154 87-012-274-080 0E CHIP CAP,U 1000P-50B
C155 87-012-274-080 0E CHIP CAP,U 1000P-50B
C201 87-012-195-080 0E C-CAP,U 100P-50CH
C202 87-010-829-080 0E CAP, U 0.047-16
C203 87-A11-062-080 0E C-CAP,S 2.2-16 Z F
C204 87-010-746-080 1A CAP, TANTAL 10-4
C205 87-012-274-080 0E CHIP CAP,U 1000P-50B
C206 87-A10-031-080 0E C-CAP,U 0.01-25 KB
C207 87-A10-031-080 0E C-CAP,U 0.01-25 KB
C208 87-A10-263-080 0E C-CAP,U 0.1-16ZF
C209 87-A11-056-080 0E C-CAP,U 1-10 Z F
C210 87-A10-263-080 0E C-CAP,U 0.1-16ZF
C211 87-A10-025-080 0E C-CAP,U 0.22-16Z F
C212 87-012-274-080 0E CHIP CAP,U 1000P-50B
C213 87-A10-031-080 0E C-CAP,U 0.01-25 KB
C215 87-A10-031-080 0E C-CAP,U 0.01-25 KB
C216 87-A10-031-080 0E C-CAP,U 0.01-25 KB
C217 87-A10-031-080 0E C-CAP,U 0.01-25 KB
C218 87-012-195-080 0E C-CAP,U 100P-50CH
C219 87-012-162-080 0E C-CAP,U 1P-50 CK
C221 87-012-165-080 0E CAP 3P
C222 87-012-274-080 0E CHIP CAP,U 1000P-50B
C223 87-010-829-080 0E CAP, U 0.047-16
C224 87-012-168-080 0E C-CAP,U 6P-50 CH
C225 87-012-267-080 0E C-CAP,U 270P-50 J CH
C226 87-012-167-080 0E C-CAP,U 5P-50 CH
C227 87-010-575-080 0E C-CAP,S 560P-50 UJ
C228 87-A10-263-080 0E C-CAP,U 0.1-16ZF
C230 87-A10-263-080 0E C-CAP,U 0.1-16 ZF
C231 87-A10-263-080 0E C-CAP,U 0.1-16ZF
C232 87-012-251-080 0E C-CAP,U 27P-50 UJ
C233 87-A11-056-080 0E C-CAP,U 1-10 Z F
C234 87-A11-056-080 0E C-CAP,U 1-10 Z F
C235 87-A10-952-080 0E C-CAP,TN 22-4 M A MCM
C236 87-A10-031-080 0E C-CAP,U 0.01-25 KB
C237 87-A11-062-080 0E C-CAP,S 2.2-16 Z F
C238 87-A10-031-080 0E C-CAP,U 0.01-25 KB
C401 87-012-274-080 0E CHIP CAP,U 1000P-50B
C402 87-012-274-080 0E CHIP CAP,U 1000P-50B
C403 87-012-274-080 0E CHIP CAP,U 1000P-50B
C404 87-012-274-080 0E CHIP CAP,U 1000P-50B
C405 87-A11-056-080 0E C-CAP,U 1-10 Z F
C406 87-A11-056-080 0E C-CAP,U 1-10 Z F
C407 87-A11-056-080 0E C-CAP,U 1-10 Z F
C408 87-A11-056-080 0E C-CAP,U 1-10 Z F
C409 87-A11-056-080 0E C-CAP,U 1-10 Z F
C410 87-A11-056-080 0E C-CAP,U 1-10 Z F
C411 87-A11-056-080 0E C-CAP,U 1-10 Z F
C412 87-A11-056-080 0E C-CAP,U 1-10 Z F
C413 87-010-831-080 0E C-CAP,U,0.1-16F
C414 87-010-831-080 0E C-CAP,U,0.1-16F
C451 87-A10-422-080 0E C-CAP,TN 10-4 A TCF
C452 87-A10-704-080 1A C-CAP,TN 100-2.5 M B2
C453 87-A11-056-080 0E C-CAP,U 1-10 Z F
C454 87-A11-056-080 0E C-CAP,U 1-10 Z F
C455 87-010-787-080 0E CAP, U 0.022-25
C456 87-010-787-080 0E CAP, U 0.022-25
C457 87-015-923-080 0E C-CAP,TN 0.22-35
C458 87-015-923-080 0E C-CAP,TN 0.22-35

DESCRIPTIONREF.NO. KANRI
NO.
PART NO. KANRI
NO.
REF.NO. DESCRIPTIONPART NO.
4
C459 87-A10-952-080 0E C-CAP,TN 22-4 M A MCM
C460 87-A10-952-080 0E C-CAP,TN 22-4 M A MCM
C461 87-012-286-080 0E CAP, U 0.01-25
C462 87-A10-952-080 0E C-CAP,TN 22-4 M A MCM
C463 87-A11-056-080 0E C-CAP,U 1-10 Z F
C464 87-A11-056-080 0E C-CAP,U 1-10 Z F
C601 87-A10-952-080 0E C-CAP,TN 22-4 M A MCM
C602 87-012-286-080 0E CAP, U 0.01-25
C603 87-012-279-080 0E C-CAP,U 2700P-50 B
C604 87-012-286-080 0E CAP, U 0.01-25
C605 87-012-278-080 0E C-CAP,U 2200P-50 B
C606 87-012-267-080 0E C-CAP,U 270P-50 B
C607 87-012-267-080 0E C-CAP,U 270P-50 B
C608 87-012-271-080 0E CAP, U 560P-50
C609 87-012-271-080 0E CAP, U 560P-50
C610 87-012-286-080 0E CAP, U 0.01-25
C611 87-012-286-080 0E CAP, U 0.01-25
C701 87-A11-062-080 0E C-CAP,S 2.2-16 Z F
C702 87-010-503-040 0E CAP,E 220-4 GAS
C703 87-010-944-180 1A C-CAP,E 220-4 M MV
C708 87-012-195-080 0E C-CAP,U 100P-50CH
C710 87-012-274-080 0E CHIP CAP,U 1000P-50B
C801 87-A10-828-080 0E C-CAP,U 0.33-6.3 K B
C802 87-A10-263-080 0E C-CAP,U 0.1-16ZF
C803 87-A10-827-080 0E C-CAP,U 0.47-6.3 K B
C804 87-A10-504-080 0E C-CAP,U 0.047-16 K B
C805 87-A10-504-080 0E C-CAP,U 0.047-16 K B
C806 87-A10-504-080 0E C-CAP,U 0.047-16 K B
C807 87-A10-504-080 0E C-CAP,U 0.047-16 K B
C809 87-A10-263-080 0E C-CAP,U 0.1-16ZF
C901 87-010-787-080 0E CAP, U 0.022-25
CF201 87-A91-162-010 0E FLTR,PFS450A7
CF202 87-A90-991-010 0E FLTR,SFE10.7 MS239-A
CF203 87-A90-991-010 0E FLTR,SFE10.7 MS239-A
CN151 8Z-HJ8-615-080 1B C-CONN,34P 6210
D201 87-A40-462-040 1B C-VARI-CAP,SVC347(S)
D202 87-A40-655-080 0E C-VARI-CAP,HVU200A
D203 87-A40-655-080 0E C-VARI-CAP,HVU200A
D951 87-017-883-010 0E LED,SLC22 VR3F RED
IFT201 87-A91-496-010 1A IFT,MW P-5DJ
J1 87-A60-437-010 1B JACK,3.5 BLK ST W/O SW 4P(1637
J451 87-A60-438-010 0E JACK,3.5 BLK ST W/O SW (1537)
J701 87-A60-849-010 0E JACK,DC DIA 2.75 BLK
L1 87-A50-322-080 0E C-COIL,S BK2125 LM252
L2 87-A50-322-080 0E C-COIL,S BK2125 LM252
L3 87-A50-322-080 0E C-COIL,S BK2125 LM252
L4 87-A50-322-080 0E C-COIL,S BK2125 LM252
L201 87-HRA-603-010 0E BAR-ANT,MW
L202 8Z-HJ8-619-010 0E COIL,FM RF(D)
L203 8Z-HJ8-618-010 0E COIL,FM OSC(D)
L204 87-003-226-080 0E MICRO INDUCTOR 100UJ
L601 87-HJ3-605-080 1B C-COIL,OSC BIAS
PS901 87-A90-440-010 1A SNSR,PHOTO GP2S24N2-B
S151 87-A91-421-010 1A SW,LEAF 6ZM-2(H)
S152 87-A90-361-010 1A SW,PUSH SPPB51-H11.3
S154 87-HJ3-608-010 1B SW,LEAF REC ASSY
S155 87-HJ3-608-010 1B SW,LEAF REC ASSY
S601 87-A91-345-010 0E SW,SL 2-2-3 SSAC
SFR801 87-A90-734-080 0E C-SFR,33K B RH03AXAN4X
TC201 87-011-252-080 1A TRIMMMER 10P LAR
TH801 87-A90-542-080 0E C-THMS,NTH5G2M35A472K04TE
VR1 83-HRC-609-010 1B VOL 20KAX2
X201 87-A91-094-010 1A FLTR,CDA10.7 MG80A
FRONT C.B
C101 87-A11-056-080 0E C-CAP,U 1-10 Z F
C102 87-A11-056-080 0E C-CAP,U 1-10 Z F
C103 87-A10-263-080 0E C-CAP,U 0.1-16ZF
C104 87-A10-263-080 0E C-CAP,U 0.1-16ZF
C105 87-A10-263-080 0E C-CAP,U 0.1-16ZF
C106 87-A10-025-080 0E C-CAP,U 0.22-16Z F
C107 87-012-176-080 0E CAP 15P
C108 87-012-176-080 0E CAP 15P
C109 87-A10-048-080 1A C-CAP,TN 22-4 M F95 S
C110 87-A10-031-080 0E C-CAP,U 0.01-25 KB
C111 87-012-274-080 0E CHIP CAP,U 1000P-50B
C112 87-012-274-080 0E CHIP CAP,U 1000P-50B
C114 87-012-274-080 0E CHIP CAP,U 1000P-50B
C115 87-A10-263-080 0E C-CAP,U 0.1-16ZF
C131 87-A11-056-080 0E C-CAP,U 1-10 Z F
C301 87-012-191-080 0E CHIP CAP 68 PF
C302 87-012-167-080 0E C-CAP,U 5P-50 CH
C303 87-012-170-080 0E C-CAP,U 8P-50 CH
C304 87-A10-263-080 0E C-CAP,U 0.1-16ZF
C305 87-A11-056-080 0E C-CAP,U 1-10 Z F
C306 87-010-787-080 0E CAP, U 0.022-25
C307 87-A11-282-080 0E C-CAP,S 1-16 K B
C308 87-012-195-080 0E C-CAP,U 100P-50CH
L301 87-A50-230-080 1A C-COIL,D-D(CP4LBM)
L302 87-003-243-080 0E C-COIL,S 10UH
LCD101 8Z-HJ8-609-010 1B LCD,AIW4188
R110 87-022-245-080 0E C-RES U 18K-1/16WF
R111 87-022-245-080 0E C-RES U 18K-1/16WF
R112 87-022-223-080 0E CHIP RES 2.2K 1/16W F
R113 87-022-223-080 0E CHIP RES 2.2K 1/16W F
R114 87-022-223-080 0E CHIP RES 2.2K 1/16W F
R115 87-022-227-080 0E C-RES,U 3.3K-1/16W F
R116 87-022-227-080 0E C-RES,U 3.3K-1/16W F
R117 87-022-231-080 0E C-RES,U 4.7K-1/16W F
S101 87-A90-665-280 0E C-SW,TACT LS7A2M
S102 87-A90-665-280 0E C-SW,TACT LS7A2M
S103 87-A90-665-280 0E C-SW,TACT LS7A2M
S104 87-A90-665-280 0E C-SW,TACT LS7A2M
S105 87-A90-665-280 0E C-SW,TACT LS7A2M
S106 87-A90-665-280 0E C-SW,TACT LS7A2M
S107 87-A90-665-280 0E C-SW,TACT LS7A2M
S108 87-A90-665-280 0E C-SW,TACT LS7A2M
S109 87-036-379-180 0E C-SW,SL1-1-2 SS350
S110 87-A90-665-280 0E C-SW,TACT LS7A2M
S111 87-A90-378-080 0E C-SW,PUSH PT035C1T
S112 87-A90-378-080 0E C-SW,PUSH PT035C1T
X101 87-A70-064-110 1B VIB,XTAL 75KHZ VTC-200
FLEX C.B
8Z-HJ8-607-010 1C PWB,FLEX 34P
SW C.B
S153 87-A91-365-080 1A C-SW,PUSH 1-1-1 SPVG21
HEAD FLEX C.B
PH1 8Z-HKE-619-110 1H HEAD ASSY, 6ZM-2(P10)
EH FLEX C.B
86-ZM2-326-010 1C HEAD ASSY, EH 6ZM-2 R2

TRANSISTOR ILLUSTRATION
RN1311
RN2311
RN2306
2SC2714
2SC4215
2SD1328
IMB3A
RN4610
HN1C01F
HN1C03FB
2SK880
2SK209
B
C
E
S
G
D
C1
C2
E1
B2
E2
B1
2SA1588
2SC3226
DTC144TK
2SC2712
2SA1362
C1
C2
EB2
B1
FMG4
FMG5A
FMA8A
LCD DIAGRAM
LCD,AIW4188
GRID ASSIGNMENT
65
ANODE CONNECTION
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ 1.0 0.5 0.35 104
Lt
W

WIRING-1 (MAIN)
7 8
14 13 12 11 10 9 8 7 6 5 4 3 2 1 1 2 3 4 5 6 7 8 9 10 11 12 13 14
AA
BB
CC
DD
EE
FF
GG
HH
II
JJ
KK
LL
MM
NN
OO
PP
QQ
RR
SS
TT
UU

SCHEMATIC DIAGRAM–1 (MAIN)
109

11 12
WIRING-2 (FRONT)
28272625242322212019181716151413121110987654321
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U

13 14
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28

SCHEMATIC DIAGRAM–2 (FRONT)
1615

IC BLOCK DIAGRAM
IC, PST9120
IC,TA2104BFN
17

IC, BA3641FV
18
IC,TK11823MTL

IC, LB1977M
19

IC DESCRIPTION
20
IC,TC9327AF-501

21

22
ADJUSTMENT
7
VR1
VOLUME
TC201
6
IC801
13
5
4
2
7
L202 L203
IFT201
TP1(VT)
MAIN C.B
A
PHONES
J001
SFR801
5
L201
(BAR ANT)
3015
/108.0MHz

DESCRIPTIONREF. NO. KANRI
NO.
PARTNO. KANRI
NO.
REF. NO. DESCRIPTIONPARTNO. DESCRIPTIONREF. NO. KANRI
NO.
PARTNO. KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
23 24
MECHANICAL EXPLODED VIEW 1 / 1 MECHANICAL PARTS LIST 1 / 1
Basic color Color Basic color Color Basic color Color
symbol symbol symbol
B Black C Cream D Orange
G Green H Gray L Blue
LT Transparent Blue N Gold P Pink
R Red S Silver ST Titan Silver
T Brown V Violet W White
WT Transparent White Y Yellow YT Transparent Yellow
LM Metallic Blue LL Light Blue GT Transparent Green
LD Dark Blue DT Transparent Orange
COLOR NAME TABLE
1 8Z-HJ8-005-010 1B WINDOW,LCD J
2 8Z-HJ8-021-010 1B LID,CASS JS790 S
3 8Z-HR8-204-010 0E SPR-T,OPEN
4 8Z-HJ8-008-010 1B KEY,BAND
5 8Z-HR8-207-010 0E PLATE,STOPPER
6 8Z-HJ8-007-010 0E KEY,TUNING
7 8Z-HJ8-004-010 1C KNOB,SL HOLD J
8 8Z-HJ8-012-010 1C PANEL,CONT S
9 8Z-HJ8-003-010 1D PANEL,CONT J
10 8Z-HJ8-006-010 1B KEY,REC
11 8Z-HJ8-002-010 1C KEY,CONT J
12 8Z-HJ8-205-010 0E HLDR,LCD J
13 8Z-HR8-214-010 1A CONN, RUBBER1.3-30.5
14 8Z-HJ8-202-010 0E COVER, PWB J
15 8Z-HR8-208-010 0E SPR-P,POP UP
16 8Z-HJ8-201-010 0E HLDR,REC SW
17 87-HJ3-608-010 1B SW,LEAF REC ASSY
18 8Z-HJ8-607-010 1C PWB,FLEX 34P
19 87-HG6-204-010 0E SPR-P,CASS
20 8Z-HJ8-022-010 1C FRAME,CENTER J D
21 87-HRA-603-010 0E BAR-ANT,MW
22 8Z-HJ8-203-010 0E HLDR,ANTENNA J
23 8Z-HR8-012-010 1B KNOB,SL OPEN
24 8Z-HR8-203-010 1A PLATE,LOCK
25 8Z-HR8-215-010 0E SPR-E,OPEN
26 8Z-HR8-206-010 0E TERMINAL,BAT-
27 8Z-HR8-205-010 0E TERMINAL,BAT+
28 8Z-HR8-202-110 0E HLDR,SW
29 8Z-HJ8-017-010 1B CABI,ASSY J
A 88-HJ3-219-010 0E S-SCREW,+1.4-2.5 B HL(0.3)
B 87-067-359-010 0E SCREW+1.4-2.5
C 87-067-706-010 0E S-SCREW +1.4-1.8 (BLK)
D 87-HK5-235-010 0E S-SCREW,1.4-0.6-2.5
E 87-067-430-010 0E VT1.4-5 BLK
F 8Z-HR8-212-010 0E S-SCREW,+1.4-4.5 CR HL
G 87-067-384-010 0E SCREWVT1.4-3.5HL
H 8Z-HR8-211-010 0E S-SCREW,+1.4-8 BLK HL
I 8Z-HJ8-208-010 0E S-SCREW,+1.4-4 B HL(0.3)
14
I
15
13
LCD
6
10
7
8
9
11
1
12
5A4
2
3
20
21
22
23
24
26
P.C.B
D27
E
F
29
G
F
H
LID.BATT J
6ZM-2
R3NF
28
P.C.B
AI
19
16
17
B
C
P.C.B
18
25
LCD101

DESCRIPTIONREF. NO. KANRI
NO.
PARTNO. KANRI
NO.
REF. NO. DESCRIPTIONPARTNO. DESCRIPTIONREF. NO. KANRI
NO.
PARTNO. KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
TAPE MECHANISM EXPLODED VIEW 1 / 1 TAPE MECHANISM PARTS LIST 1 / 1
25 26
1 86-ZM2-255-010 0E SPR-T,PIN BACK L
2 86-ZM2-286-310 0E GUIDE,TAPE REC
3 86-ZM2-220-210 0E SPR-T,HEAD
4 86-ZM2-285-210 0E LEVER,HEAD REC
5 86-ZM2-347-010 0E LEVER,MS EJECT
6 86-ZM2-226-110 0E ROLLER ASSY,PINCH
7 86-ZM2-254-010 0E SPR-T,PIN BACK
8 86-ZM2-230-110 0E SPR-T,PINCH L
9 86-ZM2-229-110 0E SPR-T,PINCH R
10 86-ZM2-240-110 0E CAP,REEL
11 86-ZM2-234-110 0E SHAFT,REEL R
12 86-ZM2-251-310 0E SHAFT,GEAR B
13 86-ZM2-361-110 1C CHAS ASSY,OUT-SERT P10
14 86-ZM2-268-310 0E SHAFT,PULLEY BELT 2
15 86-ZM2-232-310 0E LEVER,REEL R
16 86-ZM2-306-010 0E SPR-C,BT 2
17 86-ZM2-243-310 0E SPR-C,BT
18 86-ZM2-329-210 0E BELT,P5
19 86-ZM2-209-310 0E GEAR,B
20 86-ZM2-238-710 0E GEAR,FF
21 86-ZM2-245-410 0E SPR-C,SLIP L
22 86-ZM2-237-010 0E GEAR,PLAY
23 86-ZM2-241-310 0E SPR-C,SLIP R
24 86-ZM2-272-010 0E LEVER,SW P 8.4
25 86-ZM2-236-510 0E CAP,SLIP
26 86-ZM2-235-210 0E SHAFT,REEL L
27 86-ZM2-223-310 0E LEVER,PIN UP L
28 86-ZM2-233-310 0E LEVER,REEL L
29 86-ZM2-208-310 0E GEAR,A
30 86-ZM2-217-210 0E SPR-E,CAM L
31 86-ZM2-216-510 0E LEVER,CAM L
32 86-ZM2-276-010 0E PULLEY,COUPLER
33 86-ZM2-212-310 0E SHAFT,FR
34 86-ZM2-214-510 0E LEVER,CAM R
35 86-ZM2-215-210 0E SPR-E,CAM R
36 86-ZM2-222-410 0E LEVER,PIN UP R
37 86-ZM2-218-310 0E LEVER,HEAD UP
38 86-ZM2-221-010 0E CLR,BRG N
39 86-ZM2-330-010 1A FLY-WHL,R2
40 86-ZM2-239-010 0E FELT,
41 86-ZM2-225-310 0E ARM,PINCH L
42 86-ZM2-224-210 0E ARM,PINCH R
43 86-ZM2-283-210 0E CAP,SHAFT
44 86-ZM2-275-310 0E CAP,SLIP R
45 86-ZM2-210-710 0E LEVER,FR
46 86-ZM2-211-210 0E GEAR,FR
47 86-ZM2-213-210 0E SPR-C,FR
48 86-ZM2-314-110 1A FLY-WHL,L2
49 86-ZM2-282-010 0E SH,AUTO 2
50 86-ZM2-342-010 1B LEVER ASSY,EJECT
51 86-ZM2-349-010 0E SPR-E,EJECT
52 8Z-HKE-619-010 1H HEAD,ASSY 6ZM-2(P10)
53 86-ZM2-326-010 1C HEAD ASSY,EH 6ZM-2 R2
54 M8-6ZS-393-000 -- ABL-63 D
A 86-ZM2-338-010 0E W-L,1.47-2.4-0.125 W/ADH
B 86-ZM2-296-110 0E S-SCREW,+1.4-8.45
C 87-067-516-010 0E PW,3-1.58-0.25,SLIT
D 87-067-860-010 0E PW,3-0.95-0.4
E 86-ZM2-364-010 0E W-L,1.47-2.4-0.188 W/ADH 0.05
F 86-ZM2-319-010 0E W-L,0.95-3-0.35
G 88-HK5-228-010 0E S-SCREW,+1.4-2 CR
H 86-ZM2-278-010 0E W-P,1.36-4-0.2 SLT
I 87-261-500-310 0E SCREW V+1.4-1.4 (BK)
D
41
a
1
10
11
43
d
SH,1.2-2.9-0.25SL
SH,1.2-2.9-0.25SL
W1.76-4-0.3
W1.57-3-0.3
W0.8-3.0-1.25
W-L,1.31-3-0.2
b
c
e
a
b
c
d
CAPSTAN
e
F
D
F
SHAFT CAPSTAN
SHAFT
H
F
C
45
46
47
f
f
42
52
53
HEAD FLEX C.B
A
E
B
B
EH FLEX C.B
G
G
I
5
6
7
9
6
8
3
4
43
30
54
2
50
51
13
20 27
28
29
40
25
21
22
49
14
17
26 37
38
31
32
34
35
38
33
36
12
39
16
19
18
23
22
40
44
15
48
20
24

DESCRIPTIONREF.NO. KANRI
NO.
PART NO. KANRI
NO.
REF.NO. DESCRIPTIONPART NO.
27
ACCESSORIES / PACKAGE LIST
1 8Z-HJ8-901-010 -- IB,D
2 87-B30-251-010 2A HEADPHONE,HP-M042 (F)
3 84-447-019-310 0E CLIP,BELT
4 8Z-HJ8-951-010 -- RC UNIT, RC704
5 87-041-083-110 1H CM-S40A

2–11,IKENOHATA1–CHOME,TAITO-KU,TOKYO110,JAPAN TEL:[phone]
L
PrintedinSingapore
A4
2-11, IKENOHATA 1-CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:[phone]
9630469 0251431
