SERVICE MANUAL

DATA

RADIO RECEIVER

CR-DX501

S/M Code No. 09-003-343-8T1

YU(S)

SIMPLE

• Replace this Service Manual with ”Revision Publishing” when it is issued.

ELECTRICAL MAIN PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

YU<S> ..................XX....................................C.................

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

D 501 87-001-553-080 0E C-DIODE 1SS322 ABC.................

D 502 87-001-553-080 0E C-DIODE 1SS322 ABC.................

D 503 87-001-553-080 0E C-DIODE 1SS322 ABC.................

D 504 87-001-553-080 0E C-DIODE 1SS322 ABC.................

D 505 87-001-553-080 0E C-DIODE 1SS322 ABC.................

C 503 87-010-831-080 0E C-CAP,U,0.1-16F ABC.................

C 508 87-010-831-080 0E C-CAP,U,0.1-16F ABC.................

C 509 87-010-831-080 0E C-CAP,U,0.1-16F ABC.................

C 510 87-010-831-080 0E C-CAP,U,0.1-16F ABC.................

C 511 87-010-831-080 0E C-CAP,U,0.1-16F ABC.................

C 506 87-012-176-080 0E CAP 15P ABC.................

C 507 87-012-176-080 0E CAP 15P ABC.................

C 512 87-012-273-080 0E C-CAP,U 820P-50 B ABC.................

C 513 87-012-273-080 0E C-CAP,U 820P-50 B ABC.................

C 514 87-012-273-080 0E C-CAP,U 820P-50 B ABC.................

C 515 87-012-273-080 0E C-CAP,U 820P-50 B ABC.................

C 501 87-012-286-080 0E CAP, U 0.01-25 ABC.................

Q 501 89-341-165-080 0E CHIP TRANSISTOR 2SC4116GR ABC.................

Q 505 89-341-165-080 0E CHIP TRANSISTOR 2SC4116GR ABC.................

Q 502 89-508-804-080 1A CHIP FET 2SK880Y ABC.................

L 110 87-003-231-080 0E C-COIL 1UH ABC.................

L 111 87-003-231-080 0E C-COIL 1UH ABC.................

L 112 87-003-231-080 0E C-COIL 1UH ABC.................

C 170 87-010-162-080 0E CAP, CHIP 47P ABC.................

C 172 87-010-188-080 0E CAP,CHIP 6800P ABC.................

C 151 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 114 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 140 87-010-785-080 0E C-CAP,U0.015-25BK ABC.................

C 141 87-010-785-080 0E C-CAP,U0.015-25BK ABC.................

C 113 87-010-787-080 0E CAP, U 0.022-25 ABC.................

C 124 87-010-787-080 0E CAP, U 0.022-25 ABC.................

C 106 87-010-805-080 0E CAP, S 1-16 ABC.................

C 171 87-010-805-080 0E CAP, S 1-16 ABC.................

C 103 87-010-831-080 0E C-CAP,U,0.1-16F ABC.................

C 121 87-010-831-080 0E C-CAP,U,0.1-16F ABC.................

C 123 87-010-831-080 0E C-CAP,U,0.1-16F ABC.................

C 128 87-010-831-080 0E C-CAP,U,0.1-16F ABC.................

C 134 87-010-831-080 0E C-CAP,U,0.1-16F ABC.................

C 150 87-010-831-080 0E C-CAP,U,0.1-16F ABC.................

C 105 87-010-871-080 0E C-CAP,U 390-50 SL ABC.................

C 104 87-010-873-080 0E C-CAP,U 560-50 SL ABC.................

C 109 87-010-873-080 0E C-CAP,U 560-50 SL ABC.................

C 111 87-012-162-080 0E C-CAP,U 1P-50 CK ABC.................

C 108 87-012-167-080 0E C-CAP,U 5P-50 CH ABC.................

C 107 87-012-172-080 0E CAPACITOR CHIP U 10P CH ABC.................

C 115 87-012-172-080 0E CAPACITOR CHIP U 10P CH ABC.................

C 117 87-012-174-080 0E CAP CHIP CERA SS 12P CHJ ABC.................

C 101 87-012-199-080 0E CAP 220P ABC.................

C 118 87-012-268-080 0E C-CAP,U 330P-50 B ABC.................

C 116 87-012-272-080 0E C-CAP,U 680P-50 B ABC.................

C 148 87-012-274-080 0E CHIP CAP,U 1000P-50B ABC.................

C 149 87-012-274-080 0E CHIP CAP,U 1000P-50B ABC.................

C 102 87-012-286-080 0E CAP, U 0.01-25 ABC.................

C 112 87-012-286-080 0E CAP, U 0.01-25 ABC.................

C 125 87-012-286-080 0E CAP, U 0.01-25 ABC.................

C 130 87-012-286-080 0E CAP, U 0.01-25 ABC.................

C 131 87-012-286-080 0E CAP, U 0.01-25 ABC.................

C 132 87-012-286-080 0E CAP, U 0.01-25 ABC.................

IC 102 87-017-642-080 1D IC,CXA1622M ABC.................

D 171 87-020-339-080 0E CHIP DIODE,1SS226 ABC.................

Q 106 87-026-467-080 0E TR,HN1C01F (0.3W) ABC.................

C 119 87-A10-047-080 0E C-CAP,U 1-10 Z F ABC.................

C 120 87-A10-047-080 0E C-CAP,U 1-10 Z F ABC.................

C 122 87-A10-047-080 0E C-CAP,U 1-10 Z F ABC.................

C 126 87-A10-463-080 0E C-CAP,U 0.47-10 Z F ABC.................

C 146 87-A10-463-080 0E C-CAP,U 0.47-10 Z F ABC.................

C 147 87-A10-463-080 0E C-CAP,U 0.47-10 Z F ABC.................

IC 101 87-A21-407-040 C-IC,TA2104BFN ABC.................

VC 101 87-A40-462-040 1B C-VARI-CAP,SVC347(S) ABC.................

VC 102 87-A40-471-070 1A C-VARI-CAP,KV1435 ABC.................

VC 103 87-A40-471-070 1A C-VARI-CAP,KV1435 ABC.................

Q 105 89-113-625-080 0E TR,2SA1362GR(120MHZ,0. ABC.................

Q 103 89-341-165-080 0E CHIP TRANSISTOR 2SC4116GR ABC.................

Q 104 89-341-165-080 0E CHIP TRANSISTOR 2SC4116GR ABC.................

Q 107 89-341-165-080 0E CHIP TRANSISTOR 2SC4116GR ABC.................

Q 108 89-341-165-080 0E CHIP TRANSISTOR 2SC4116GR ABC.................

Q 101 89-342-153-080 0E TR,2SC4215 ABC.................

Q 102 89-342-153-080 0E TR,2SC4215 ABC.................

Q 109 89-342-153-080 0E TR,2SC4215 ABC.................

C 502 87-010-132-010 0E CAP, ELECT 1-50V ABC.................

C 504 87-010-501-010 0E CAP GAS 47UF 4V ABC.................

X 501 87-A70-187-010 1B VIB,XTAL 75KHZ CFV206 ABC.................

SW 511 87-A91-152-010 1A SW,SL 1-1-2 SSSS212-11-A ABC.................

SW 512 87-A91-152-010 1A SW,SL 1-1-2 SSSS212-11-A ABC.................

L 104 87-003-152-080 0E COIL, 100UH ABC.................

C 158 87-010-031-010 CAP,E 3.3-25 M BK ABC.................

C 159 87-010-031-010 CAP,E 3.3-25 M BK ABC.................

ELECTRICAL MAIN PARTS LIST - 2

C 135 87-010-033-010 0E CAP,E 10-16 ABC.................

C 136 87-010-033-010 0E CAP,E 10-16 ABC.................

C 129 87-010-082-010 0E CAPACITOR, 220MF 4V/87-0 ABC.................

C 133 87-010-082-010 0E CAPACITOR, 220MF 4V/87-0 ABC.................

C 138 87-010-082-010 0E CAPACITOR, 220MF 4V/87-0 ABC.................

C 152 87-010-082-010 0E CAPACITOR, 220MF 4V/87-0 ABC.................

C 153 87-010-082-010 0E CAPACITOR, 220MF 4V/87-0 ABC.................

C 127 87-010-419-010 0E CAP,E 4.7-16 SRE ABC.................

C 173 87-016-627-010 0E CAP,E 47-16 M SSL ABC.................

BPF 101 87-A90-336-010 1B FLTR,GFEB4 ABC.................

CF 102 87-A90-991-010 0E FLTR,SFE10.7 MS239-A ABC.................

CF 103 87-A91-094-010 1A FLTR,CDA10.7 MG80A ABC.................

SW 102 87-A91-152-010 1A SW,SL 1-1-2 SSSS212-11-A ABC.................

CF 101 87-A91-162-010 0E FLTR,PFS450A7 ABC.................

IFT 101 87-A91-366-010 1A IFT,MW 5PLG ABC.................

TC 101 87-A91-657-010 TRIMMER,20P 4.0X4.5 ECRL ABC.................

VR 101 87-A91-741-010 VR,RTRY 20KBX2 H XV0102GPV1NB ABC.................

L 102 8A-RC4-604-010 COIL,D-D CON ABC.................

L 102 8A-RC7-601-010 COIL,FM RF ABC.................

L 103 8A-RC7-602-010 COIL,FM OSC ABC.................

L 105 8A-RC7-603-010 COIL,BAR-ANT ABC.................

LCD 101 8A-RC7-605-010 LCD,ARC-7 ABC.................

J 101 8A-RCL-608-010 JACK,TC38 ST W/O SW ABC.................

IC 502 87-A20-755-080 1B C-IC,AK93C45AF ABC.................

IC 501 87-A21-605-010 C-IC,TC9318FA-056 ABC.................

MECHANICAL PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

YU<S> ..................XX....................................C.................

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8A-RC7-001-010 CABI,FRONT YU ABC.................

8A-RC7-002-010 CABI,REAR YU .BC.................

8A-RC7-003-010 LID,BATT YU ..C.................

8A-RC7-005-010 WINDOW,LCD ABC.................

8A-RC7-006-010 KEY,BAND ABC.................

8A-RC7-007-010 KEY,POW ABC.................

8A-RC7-008-010 KEY,PRE/TUNE ABC.................

8A-RC7-009-010 KNOB,SL HOLD ABC.................

8A-RC7-010-010 KNOB,SL FM MODE ABC.................

8A-RC7-011-010 CABI,REAR YZ A...................

8A-RC7-012-010 LID,BATT YZ AB..................

8A-RC7-201-010 HLDR,ANT ABC.................

8A-RC7-202-010 BASE,LCD ABC.................

8A-RC7-203-010 HLDR,PRESET ABC.................

8A-RC7-204-010 HLDR,POW/BAND ABC.................

8A-RC7-205-010 HLDR,LCD ABC.................

8A-RC7-206-010 BAT-CONTACT,(+) ABC.................

8A-RC7-207-010 BAT-CONTACT,(-) ABC.................

8A-RC7-208-010 BAT-CONTACT,(+/-) ABC.................

8A-RC7-209-010 CONN, RUBBER LCD ABC.................

8A-RC7-210-010 HLDR,JACK ABC.................

8A-RC7-211-010 HLDR,BAND ABC.................

87-354-529-310 0E VT2+1.7-4 ABC.................

87-B10-026-010 0E VT2+1.7-8 CR HL ABC.................

87-B10-304-010 VT2+1.7-10 W/O CR ABC.................

ACCESSORIES LIST

NOTE: The characters in the suffix column indicate the part usage.

YU<S> ..................XX....................................C.................

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8A-RC7-901-010 IB,YU(3L) ..C.................

8A-RC7-904-010 IB,YL(ESP) .B..................

8A-RC7-905-010 IB,YZ(EGF) A...................

8A-RC7-906-010 IB,YZ(SID) A...................

8A-RC7-907-010 IB,YZ(PHC) A...................

87-B30-319-010 HEADPHONE,HP-M046(S) NECK-BAND ABC.................

8A-RC7-004-010 CLIP,BELT ABC.................

2-11, IKENOHATA 1-CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111

931196 Printed in Singapore
