Aiwa CSD-MD50 User manual

8Z-CK3-903-01
990220AYK-H-U-0
For assistance and information,
call toll free I-800 -WY+WVA.
(United States and Puerto Rico)
\

WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
Miiiiiu
“CAUTION TO REDUCE THE RISK OF
ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL “
Explanation of Graphical Symbols:
AThe lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s en-
closure that may be of sufficient magnitude to
constitute arisk of electric shock to persons.
A
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and mainte-
nance (servicing) instructions in the literature
●accompanying the appliance.
PRECAUTIONS
Read the Operating Instructions carefully and completely before
operating the unit. Be sure to keep the Operating Instructions for
future reference. All warnings and cautions in the Operating
Instructions and on the unit should be strictly followed, as well as
the safety suggestions below.
Installation
1
2
3
4
5
6
Water and moisture –Do not use this unit near water, such as
near abathtub, washbowl, kitchen sink, laundry tub, in awet
basement, swimming pool, or the like.
Heat –Do not use this unit near sources of heat, including
heating vents, stoves, or other appliances that generate heat.
It also should not be placed in temperatures less than 5°C
(41 ‘F) or greater than 35-C (95”F).
Mounting surface –Place the unit on a flat, even surface.
Ventilation –The unit should be situated with adequate space
around itsothat proper heatventilation is assured. Allow 10cm
(4 in.) clearance from the rear and the top of the unit, and 5 cm
(2 in.) from the each side,
-Do not place the unit on a bed, rug, orsimilarsurface that may
block the ventilation openings.
-Do not install the unit in abookcase, cabinet, or airtight rack
where ventilation may be impeded.
Objects and liquid entry –Take care that objects or liquids do
not get inside the unit through the ventilation openings.
Carts and stands –When placed or
mounted on a stand or cart, the unit
should be moved with care.
Quick stops, excessive force, and un-
m
●L
even surfaces may cause the unit or
cart to overturn or fall. 3
AL*
7
8
Condensation –Moisture may form on the CD pickup lens
when:
-The unit is moved from acold spot to awarm spot
-The heating system has just been turned on
-The unit is used in avery humid room
-The unit is cooled by an air conditioner
When this unit has condensation inside, it may not function
normally. Should this occur, leave the unit for afew hours, then
try to operate again.
Wall orceilina mountina– The unit should not be mounted on
awall or ceilin~, unless s~ecified in the Operating Instructions.
Electric Power
1
2
3
4
5
Power sources –Connect this unit only to power sources
specified in the Operating Instructions, and as marked on the
unit.
Polarization –As asafety feature, some units are equipped
with polarized AC power plugs which can only be inserted one
way into apower outlet. If it is difficult orimpossibleto insert the
AC power plug into an outlet, turn the plug over and try again.
If it still does not easily inserf into the outlet, please call a
qualified service technician to service or replace the outlet. To
avoid defeating the safety feature of the polarized plug, do not
force it into apower outlet,
AC power cord
-When disconnecting the AC power cord, pull it out by the AC
power plug. Do not pull the cord itself.
-Never handle the AC power plug with wet hands, asthiscould
result in fire or shock.
-Power cords should be routed to avoid being severely bent,
pinched, or walked upon. Pay particular attention to the cord
from the unit to the power socket.
-Avoid overloading AC power plugs and extension cords
beyond their capacity, as this could result in fire or shock.
Extension cord –To help prevent electric shock, do not use a
polarized AC power plug with an extension cord, receptacle, or
other outlet unless the polarized plug can be completely in-
serted to prevent exposure of the blades of the plug.
When not in use –Un~lug the AC Dower cord from the AC
outlet if the unit will not “be-used for several months or more.
When the cord is plugged in, asmall amount of current
continues to flow to the unit, even when the power is turned off.
Maintenance
Clean the unit only as recommended in the Operating Instructions.
Damage Rectuirinc! Service
Have the unit serviced by aqualified service technician if:
-The AC power cord or plug has been damaged
-Foreign objects or liquid have gotten inside the unit
-The unit has been exposed to rain or water
-The unit does not seem to operate normally
-The unit exhibits amarked change in performance
-The unit has been dropped, or the cabinet has been damaged
DO NOT ATTEMPT TO SERVICE THE UNIT YOURSELF.
Owner’s record
For your convenience, record the model number and serial number
(you will find them on the rear of your set) in the space provided
below, Please refer to them when you contact your Aiwa dealer in
case of difficulty.
Model No. Serial No. (Lot No.)
CSD-MD50
2ENGLISH

TABLE OF CONTENTS
PREPARATIONS
CONNECTIONS ..................................................................4
REMOTE CONTROL ...........................................................5
BEFORE OPERATION ........................................................5
SETTING THE CLOCK ........................................................6
SOUND
ADJUSTING THE SOUND ..................................................7
RADIO RECEPTION
MANUAL TUNING ...............................................................8
PRESETTING STATIONS ...................................................9
REGISTERING STATION NAME ......................................10
CD PLAYING
OPERATION ......................................................................11
TAPE PLAYBACK
OPERATION ......................................................................13
MD PLAYING
WHAT IS AN MD (MINI DISC)? ........................................ 14
OPERATION ......................................................................15
TAPE RECORDING
OPERATION ......................................................................17
MD RECORDING
ABOUT THE INDEX MARK ..............................................18
RECORDING AWHOLE CD ............................................. 19
RECORDING ONLY ONE TRACK OF A CD ....................20
PROGRAMMED RECORDING OF A CD .........................20
RECORDING FROM ATAPE, CD OR THE RADIO
MANUALLY .................................................................21
EXTENDED (MONAURAL) RECORDING ........................21
MD EDITING
REGISTERING THE DISC TITLE AND TRACK TITLE .....22
DIVIDING ATRACK ................................................m ......... 23
COMBINING TWO TRACKS .............................................24
CHANGING THE ORDER OFTHETRACKS ....................24
ERASING TRACKS ...........................................................25
TIMER
TIMER PLAY AND TIMER RECORDING .........................26
SETTING THE SLEEP TIMER ..........................................27
GENERAL
CARE AND MAINTENANCE ............................................28
MD GUIDE MESSAGES ....................................................29
SPECIFICATIONS .............................................................30
TROUBLESHOOTING GUIDE ..........................................31
PARTS INDEX ...................................................................32
ENGLISH 3

CONNECTIONS
%1
0
2L--
IMPORTANT
Be sure to connect the AM antenna first, then connect the AC
cord.
CAUTION
Use only the supplied AC cord. Use of other cords may result in
the risk of fire.
To stand the AM antenna on asurface
Fix the claw to the slot.
7Connect the supplied AM antenna to the AM
LOOP terminal.
2Connect the unit to an AC outlet using the
supplied AC cord.
-~~
G. @to an AC outlet
CONCERNING THE DISPLAY WINDOW’S DEMO
DISPLAY
When the AC cord is plugged into an electrical outlet for the first
time after purchase, ademo display will appear in the display
window. When the power is turned on, the demo display will
end. When the power is turned off, the demo display will appear
again. Until the clock is set, the demo display will appear
whenever the power is turned off. (For setting the clock, see
page 6.)
m
●Do not disconnect the AC cord while the power is on. Otherwise,
the data concerning the contents of the MD recording may not
be registered properly.
●Do not bring the AM antenna near the AC cord since noise will
be picked up.
.Do not unwind the AM antenna wire.
ABOUT THE POWER ECONOMIZING
MODE
You can turn on or off the power economizing mode of this unit.
When the power economizing mode is turned on
Power will be turned off automatically if 10 minutes have elapsed
while no MD, CD or tape is being played and no operation is
performed. (Power will not be turned off automatically, however,
while listening to radio broadcast.) The power economizing mode
is set to off when you purchase the unit.
To turn onloff the power economizing mode
1
2
3
4
POWER
l-r
■
~=
[3
.,, : —.,L._+___
.. . :J!&~:~;~;,t-s;
,,:’,~:,,- ~:jf:~\l[l\f&ij:
,. ~.-,.,.,,,,,
.,:.,::”’; ~“
..,. ;!”
,.; ~,*+ -E
[~
,,;~$T&j
!-’,~$.~,”
,.-,- “’”% CD @... -*P: .i: ;’iii’r
:.‘.,*+SI’J1,”. ~ ~ .,~:Fd;ggg,,tt :
,8-,,>,.,*A.......;
JL
.“w:’”:!’=r=>c
~~&}#;,:;j,;;::7,
~-.y~~l,,,,,
=
—
MODE ENTER
Press the POWER button to turn on the unit.
While pressing the ●button, press the POWER
button.
Press the MODE button to select “ECO ON” or
“ECO OFF.”
To activate the power economizing mode, select “ECO ON.”
To deactivate the power economizing mode, select “ECO
OFF.”
Within 5seconds, press the ENTER button.
Or simply leave the unit without pressing the ENTER button
for more than 5seconds.
4ENGLISH

REMOTE CONTROL IBEFORE OPERATION
Inserting batteries
Detach the battery cover on the rear of the remote control and
insert two R6 (size AA) batteries.
R6’(AA)
When to replace the batteries
The maximum operational distance between the remote control
and the sensor on the main unit should be approximately 5meters
(16 feet). When this distance decreases, replace the batteries
with new ones.
To use the remote control
Some operations can be performed using the buttons on the
remote control only, or those on the main unit only, while others
can be performed using the buttons on the main unit as well as
on the remote control. This instructions manual clearly describes
the buttons available for each operation.
●The >button on the remote control starts play of the MD, CD
or the tape, if the corresponding function is selected.
●If the unit is not going to be used for an extended period of
time, remove the batteries to prevent possible electrolyte
leakage.
●The remote control may not operate correctly when:
-The line of sight between the remote control and the unit is
exposed to intense light, such as direct sunlight.
-Other remote controls are used nearby (television, etc.)
FUNCTION
To use the FUNCTION button
Each time the FUNCTION button is pressed while power is on,
one of the functions is selected cyclically, as follows.
10 turn the unit on
F’ress the POWER button.
The unit can also be turned on by the following ways:
-Pressing the CD bbutton turns the unit on and starts play of
the inserted CD.
-Pressing the MD >button turns the unit on and starts play of
the inserted MD.
-Pressing the TUNER/BAND button turns the unit on and tunes
in to the previously tuned station.
-Pressing the TAPE +> button turns the unit on and starts
play of the loaded tape.
10 turn the unit off
F’ress the POWER button.
To use the headphones
Connect the headphones with astereo mini plug (03.5 mm, ‘/8
inch) to the PHONES jack. No sound will be heard from the
speakers while the headphones are plugged in.
~MD +CD +TUNER (FM or AM) +TAPE 1
ENGLISH 5

ISETTING THE CLOCK When the power is turned off after setting the clock
If the power economizing mode is off, the clock remains displayed.
If the power economizing mode is on, the clock also clears.
To display the clock when another display is shown
ENTER Press the TIMER/CLOCK button. The clock is displayed for 5
IcMULTI JOG seconds.
1
2
3
4
5
6
7
8
or
turn the MULTI JOG dial to set the year.
The year can be set between 1999 and 2040.
Within 1minute, press the ENTER button.
The month flashes on the display.
Within 1minute, press the ++ or ➤>button, or
turn the MULTI JOG dial to set the month, then
within 1minute, press the ENTER button.
The day flashes on the display.
Within 1minute, press the ++ or ➤-button, or
turn the MULTI JOG dial to set the day, then within
1minute, press the ENTER button.
The hour flashes on the display.
Within 1minute, press the +or >button, or
turn the MULTI JOG dial to set the hour, then
within 1minute, press the ENTER button.
The minute flashes on the display.
Within 1minute, press the ++ or ➤-button, or
turn the MULTI JOG dial to set the minute, then
within 1minute, press the ENTER button.
The clock starts from 00 seconds.
6ENGLISH

ADJUSTING THE SOUND EQ (EQUALIZER)
ADJUSTING THE VOLUME
Press the VOLUME UP/DOWN buttons (or the VOL A/
Vbuttons on the remote control.)
The volume level is shown on the display for 5seconds. It can
be set from O(minimum) to 23, and then MAX (maximum).
The volume remains memorized even after the power is turned
off. However, if the power is turned off when the volume is set to
more than 15, it is automatically set to 15 the next time the power
is turned on.
ENHANCING THE BASS SOUND
The T-BASS system enhances the realism of low-frequency
sound.
1
2
3
Press the SOUND button repeatedly until
T-BASS ?appears on the display.
Within 5seconds, press the ENTER button.
Within 5seconds, turn the MULTI JOG dial.
Select one of the three levels, or off position,
I
T-BASS T-BASS ... I1I
(OFF)
m
Low frequency sound may be distorted when the T-BASS system
is used for adisc or tape in which Iowfrequency sound is originally
emphasized. In this case, cancel the T-BASS system.
This unit provides the following three different equalization curves.
F1OCK: Powerful sound emphasizing treble and bass
F’OP: More presence in the vocals and midrange
JAZZ: Accented lower frequencies for jazz-type music
Press the SOUND button repeatedly until EQ ?
appears on the display.
Within 5seconds, press the ENTER button.
Within 5seconds, turn the MULTI JOG dial.
Select one of the three equalization curves, or off position.
~m”m ~fi:~ “mJ
-T
When using the remote control, press the EQ button repeatedly.
C!SURROUND SYSTEM
Tl?e QSURROUND system built into this unit uses only two
speakers at the left and right to create an atmosphere that sound
as if you are surrounded by two front speakers and two rear
speakers.
1
2
3
Press the SOUND button repeatedly until
QSURROUND ? appears on the display.
Within 5seconds, press the ENTER button. m
Within 5seconds, turn the MULTI JOG dial.
Select either “Q SURROUND on” or “Q SURROUND off”
according to your preference.
When the QSURROUND system is turned on:
Em
.;[he QSURROUND system does not work in monaural mode.
●At higher volumes, turning QSURROUND on may cause sound
distortion. In this case, turn the volume down.
SOUND ADJUSTMENT DURING
RECORDING
Thle output volume and tone of the speakers or headphones may
be freely varied without affecting the level of the recording.
ENGLISH 7

For better reception
MANUAL TUNING
1
2
I
DISP
~MULTI JOG r
aI
00. MODE
000
000
000
000
~BAND
?~
o
II +4, *
Press the TUNER/BAND button on the main unit
or the BAND button on the remote control
repeatedly to select the desired band.
n
If the power is turned off, the previously tuned station will be
played (Direct Play Function).
Press the 44 or ➤-button or turn the MULTI
JOG dial to select astation.
When astation is received, “TUNE” is displayed for 2seconds.
During FM stereo reception, [(1~)1] is displayed.
MD)))
.-
●FM
Extend the FM antenna and orient it for the best reception.
●AM
Keep the AM antenna away from other electrical appliances
and orient it for the best reception.
When an FM stereo broadcast contains noise
Press the MODE button.
MONO appears on the display.
Noise is reduced, although reception is monaural.
MOINO
To restore stereo reception, repeat the above again
To change the AM tuning interval
The default setting of the AM tuning interval is 10 kHz/step. If
you use this unit in an area where the frequency allocation system
is 9kHz/step, change the tuning interval.
Press the TUNER/BAND button while pressing the DISP button.
To reset the interval, repeat this procedure.
m
When the AM tuning interval is changed, all preset stations (see
“PRESETTING STATIONS”) are cleared. The preset stations
To search for astation quickly (Auto Search) have to be set again.
Keep the +< or >button pressed until the tuner starts
searching for astation. After tuning in to astation, the search
stops.
To stop the Auto Search manually, press the +< or -button.
●The Auto Search may not stop at stations with very weak
signals.
8ENGLISH

PRESETTING STATIONS PRESETTING STATIONS MANUALLY
2-_._l L3,4
The unit can store 15 preset stations for each band.
When astation is stored, apreset number is assigned to the
station. Use the preset number to tune in to apreset station
directly.
PRESETTING STATIONS AUTOMATICALLY
The unit scans through the receivable frequency range and stores
stations automatically.
m
Presetting stations automatically will clear all previously preset
stations.
1
2
3
4
Press the TUNER/BAND button on the main unit
or the BAND button on the remote control to
select aband.
Press the EDIT button repeatedly until
AUTO SET ?appears.
Within 5seconds, press the ENTER button.
AUTO START ?appears on the display.
Within 5seconds, press the ENTER button.
The unit searches for astation within the band selected at
step 1.
When atuned station is stored, the preset number assigned
to the station flashes.
1Press the TUNER/BAND button on the main unit
or the BAND button on the remote control to
select aband.
2Press the ++ or ➤>button or turn the MULTI
JOG dial to select astation.
3Press the EDIT button repeatedly until MANUAL
SET ?appears.
4Within 5seconds, press the ENTER button.
The station is stored and assigned apreset number.
IPRESET NUMBER TUNING
1
42
Press the TUNER/BAND button on the main unit
or the BAND button on the remote control to
select aband.
Press the II button.
Each time the button is pressed, the next ascending preset
number is selected.
Once apreset station is tuned in, the MULTI JOG dial is also
available to select the desired preset station.
“runing by preset number
“1
:!
Press the BAND button on the remote control to select aband.
(Or, use the TUNER/BAND button on the main unit.)
Press the numbered buttons on the remote control to select
apreset number:
Example:
To select preset number 10, press the +1 Oand Obuttons.
To select preset number 15, press the +10 and 5 buttons. ❑
lrO clear apreset station
1Select the preset number of the station to be cleared.
:! Press and hold the II button until CLEAR OK? appears.
3Within 5seconds, press the ENTER button.
The preset numbers of all other stations in the band with higher
numbers are also decreased by one.
II there is along period of power failure or disconnection of AC
cord, the presetting of the stations is canceled. In this case, preset
again.
When automatic presetting has been completed, the display
returns to the first preset station.
ENGLISH 9

To change acharacter
REGISTERING STATION NAME
#------7
You can register adesired name to astation which has already
been stored in memory.
The registered name appears on the display when the station is
tuned in.
1
2
3
4
5
6
7
8
9
Press the TUNER/BAND button on the main unit
or the BAND button on the remote control to
select aband.
Press the 11 button or turn the MULTI JOG dial
to select apreset station.
Press the EDIT button repeatedly until NAME
EDIT ?appears.
Within 5seconds, press the ENTER button.
The unit turns into character entry mode.
Press the MODE button repeatedly to select the
kind of character.
Capital letters +Smal[ letters
Number/symbol <
Turn the MULTI JOG dial to select adesired
character.
Press the ›~ button.
Repeat steps 5to 7to enter all the required
characters (up to 12 characters).
If you leave the unit without performing any operation for one
minute in steps 5to 7, the character entry mode will be
canceled. If this happens, repeat from step 3.
Press the ENTER button.
The entered station name is displayed.
Press the <+ or -button repeatedly until the character to
be changed flashes. Then enter the desired character again.
To delete characters
Press the 4+ or -button repeatedly until the character to
be deleted flashes. Then press the II button.
To insert aspace between the characters
Press the <or -button repeatedly until the part to be
entered as aspace flashes. Then press the DISP button.
To add acharacter between two characters
First, insert aspace between two characters as described above.
Then change the space to the desired character by entering it.
1() ENGLISH

OPERATION
LD,SP
ACD EJECT ~++ ➤>
LOADING ADISC
Press the A CD EJECT button to open the disc
compartment. Load adisc with the label side up
and close the disc compartment.
{—ACD EJECT
Depending on the unit’s status, TOC READING may appear while
the unit reads the data of the inserted disc.
PLAYING ADISC
Load a disc.
Press the CD ~button.
TOC READING appears on the display while the unit reads the
data of the loaded CD, then play begins with the first track.
Number of track being played
Elapsed playing time
To stop play, press the ■button.
To pause play, press the II button. To resume play, press the
CD -button.
To search for aparticular point during playback, keep the
44 or ➤Fbutton pressed and release the button at the desired
point.
To skip to the beginning of atrack during playback, press
the 4+ or ➤-button repeatedly or turn the MULTI JOG dial.
The unit skips forward through the tracks when turning it right,
and skips back when turning it left.
To remove the disc, press the ~CD EJECT button.
Selecting atrack with the remote control
Press the numbered buttons and the +1 Obutton to select atrack.
Example:
To select the 25th track, press the +1 O, +10 and 5 buttons.
To select the 10th track, press the +10 and Obuttons.
The selected track starts to play and play continues to the end
of that disc.
Display in stop mode
“The display shows the following information.
Music calender (only the first
Total number of tracks 20 tracks are displayed)
I
Total playing time
To change the display during playback
lPress the DISP button (or the DISPLAY button on the remote
control) during playback.
“The display changes in the following order.
+@Elapsed playing time of the track being played
@] Remaining playback time of the current track
—@Total remaining playback time of the loaded CD
“Fhe total remaining playback time cannot be displayed when
random play or single track repeat play (page 12) is performed.
,, DO not use irregular shape CDs (example: heart-shaped,
octagonal ones). It may result in malfunction,
t, When loadingan%xn (3-inch) disc, put it onto the inner circle
of the tray.
~,DO not place more than one compact disc on the disc tray.
To start play when the power is off (Direct Play
Function)
Press the CD -button. The power is turned on and play of the
loaded disc begins.
To replace the disc before play, press the ~CD EJECT button
to open the disc compartment. ENGLISH I I

CDF~ rMULTl JOG
u“”,, .
k
II L-#-.._,
All the tracks on the disc can be played randomly.
In stop mode, press the MODE button on the main unit
repeatedly until RANDOM? appears on the display, and
within 5seconds, press the ENTER button.
To cancel random play
In stop mode, press the MODE button on the main unit repeatedly
until OFF appears on the display. Then, within 5seconds, press
the ENTER button.
m
●Even if the << button is pressed, apreviously played track
cannot be skipped. The unit returns to the beginning of the
current track only.
●When you select atrack with the numbered buttons on the
remote control during the random play mode, the selected track
starts to play and the random play mode is canceled.
REPEAT PLAY
Asingle track or all tracks can be played back repeatedly,
Press the REPEAT button on the remote control repeatedly.
“~1” lights up when the single track repeat play is selected,
and “~” lights up when the all tracks repeat play is selected,
To cancel repeat play, press the REPEAT button repeatedly until
“~” and “1” disappear.
To select repeat play with the MODE button on the main unit
In playback or playback pause mode, press the MODE button
repeatedly to select the desired repeat play mode.
To repeat random play
First activate random play.
Then press the REPEAT button so that “%” lights up.
PROGRAMMED PLAY
Up to 20 tracks can be programmed from the inserted disc.
1
2
3
4
5
In stop mode, press the MODE button on the main
unit repeatedly until PROGRAM? appears on the
display.
Within 5seconds, press the ENTER button.
Turn the MULTI JOG dial to select atrack to
programmed, and press the ENTER button.
Total number of Total playing time of
selected tracks the selected tracks
be
Selected track number
Repeat step 3to program other tracks.
Press the CD >button (or the >button on the
remote control) to start play.
To check the program
Each time the -button is pressed in stop mode, atrack
number and program number will be displayed.
To clear the program
Press the ■button in stop mode,
To add tracks to the program
Before playing, repeat step 3. The track will be programmed after
the last track.
To change the programmed tracks
Clear the program and repeat all the steps again
m
●During the programmed play, the MODE and numbered buttons
do not function.
●Repeating programmed play is also possible.
●If the programmed time exceeds 99 minutes 59 seconds, or
the disc track number 31 or above is programmed, the display
shows --:-- as the total playing time.
I2ENGLISH

OPERATION
P
00::
I
MODE
000
000
000
000
p
‘o *:M :
VII
II “
MODEJ L‘TAPE+>
44, b-
LOADING ATAPE
●You can select areverse mode to play back one or both sides.
●Use Type I(normal) tapes only for playback.
Press the PUSH OPEN button to open the cassette
holder.
Load a tape with the exposed side facing downward.
Push the cassette holder to close.
PLAYING BACK A TAPE
Load atape and press the TAPE +➤button to start
play.
Playback side of the tape
}: “The front side is being played (forward)
~: The rear side is being played (reverse)
Tape counter indicates the tape
running length,
To stop play, press the ■button.
To pause play, press the II button. To resume play, press the
TAPE <› button.
To change the playback side in play mode, press the TAPE
<› button.
To change the playback side in stop mode, press the ENTER
button.
To fast forward or rewind, press the <4 or >button in stop
mode. Then press the 9button to stop the tape.
To set the tape counter to 0000
Press the ■button in stop mode.
The counter is also set to 0000 when the cassette holder is
opened.
Selecting areverse mode
In stop mode, press the MODE button repeatedly.
Each time the button is pressed, the reverse mode changes.
r=-+=)+(=)
To play one side only, select 1.
To play from front side to back side once only, select Z).
To play both sides repeatedly, select C=).
About cassette tapes
●To prevent accidental erasure, break off the plastic tabs on
the cassette tape after recording with ascrewdriver or other
pointed tool.
Side A
e
Q
,<Q;;g Tab for side A
To record on the tape again, cover the tab openings with
adhesive tape, etc.
●120-minute or longer tapes are extremely thin and easily
deformed or damaged. They are not recommended.
●Take up any slack in the tape with apencil or similar tool
before use. Slack tape may break or jam in the mechanism.
To start play when the power is off (Direct Play
Function)
Press the TAPE +> button. The power is turned on and play
of the loaded tape begins.
ENGLISH13

WHAT IS Ahl MD (MINI DISC)?
An MD is only 64 mm (2 5/s inches) in diameter, about half the
size of aconventional CD. But MD can be used to store and play
back afull 74 minutes of data such as aCD. Unlike aCD, MD
comes in aplastic cartridge, so that it can be handled with ease.
The cartridge also protects the disc inside from shocks, dust
and scratches. Unlike cassette tapes, which can become
stretched or tangled, an MD is an excellent durable media.
TYPE OF MD
There are two types of MDs: “Optical discs” and “Magneto-optical
discs”. Both types use laser beams and optical pick-up technology
to read recorded data during playback.
Optical discs
These are playback only discs. Like CDs, they are used as
prerecorded music discs. You cannot record on or edit them.
+
El
Label The shutter covers
the opening only on
the non-labeled
side of the MD.
Recordable MO*’ discs
These are recordable discs which can be recorded on again and
again, like cassette tapes. The recording method called magneto-
optical technology employs alaser and magnetism to record
signals. Therefore, the quality of recorded sound does not
deteriorate even after many playbacks and recordings.
4m
l!i-”-
Label The shutter covers
the opening on the
both sides of the MD.
*1 MO: An abbreviation of Magneto Optical
Ultra compact size made possible by ATRAC*2
technology
Anewly developed digital audio compression technology called
the ATRAC system automatically extracts only the frequencies
that are actually audible to the human ear and cuts the
frequencies which are inaudible. This compresses the amount
of data to be recorded to 1/5 of the normal amount. The ATRAC
system is based upon studies carried out in the field of auditory
psychology and does not impair the quality of the audible sound.
*2 ATRAC: An abbreviation of Adaptive TRansform Acoustic
Coding
Quick random access
One of the great features of the MD is that you can search for
desired tracks quickly. There are also quick and easy functions
for random playback in which the order of the tracks can be
rearranged at random, and for renumbering tracks which enables
them to be played in any order.
14 ENGLISH
THE LIMITATIONS OF MD
Recording on the MD is performed differently from that of a
cassette tape or aDAT. Therefore, the MD system is subject to
the following restrictions.
“TOC* Full” is displayed even if the recording time
does not reach the maximum recordable time of the
disc (60-minute or 74-minute).
“TOC Full”is displayed when 254 tracks are already recorded
on adisc, without respect of the recording time.
*TOC: An abbreviation of Table Of Contents
“TOC Full” is displayed even if adisc is not fully
recorded on.
If there are lots of emphasis data in aparticular track, the unit
handles the data as index codes, and tracks are counted, in
addition, without respect of the time and number of tracks.
The remaining time on adisc is not increased even
after some short tracks have been erased.
When the remaining time on a disc is displayed, which may not
be increased even after erasing short tracks because the sections
less than eight seconds are not counted.
Certain tracks cannot be joined (the COMBINE function
does not function).
●Tracks created by editina mav not be ioined.
●It is not possible _tocom~ine atrack re”corded in monaural and
atrack recorded in stereo.
The total of the recorded time and the remaining time
on adisc does not match with the maximum
recordable time of the disc (60-minute or 74-minute).
Recording is performed by the minimum unit of one cluster (two
seconds). Even if the recorded section is shorter than two
seconds, atwo-second space is needed in recording. Therefore,
the available time becomes shorter. If there are scratches on a
disc, the available time becomes shorter as well, because the
sections which are scratched are automatically erased.
Track numbers may not be registered properly.
When recording from aCD through digital inputs (using the CD
>MD button), small tracks may be created depending on the
contents of aCD.
When using the AUTO MARK function, track numbers may not
be registered properly depending on the contents of the CD.
Digital inputs may not be acceptable.
When digital recording is attempted from recorded material with
copyrights,digital dubbing cannot be performed to arecordable
MD from another MD recorded in digital, because of the built-in
record restriction function which complies with the SCMS*
standard.
*SCMS (Serial Copy Management System) is the standard to
restrict single digital dubbing between the digital audio system
thus protecting copyrights.
(prerecorded”s~und source) Digital dubbina

OPERATION
—DISPLAY
r
INSERTING AN MD
Insert adisc into the disc drive fully with the label side up
and in the direction of the arrow.
If you insert adisc while the unit is turned off, the unit is turned
on.
Depending on the unit’s status, TOC READING may appear while
the unit reads the data of the inserted disc.
Direction guide
Iky
,,,,,,,
,,
L— ●J
PLAYING AN MD
Insert an MD.
Press the MD >button.
Playback begins.
Number of track being played
Elapsed playing time
To stop play, press the ❑button.
To pause, press the 11 button. To resume play, press the MD *
button.
To search for aparticular point during playback, keep the
<< or ➤>button pressed and release the button at the desired
point.
To skip to the beginning of atrack during playback, press
the ●+or -button repeatedly or turn the MULTI JOG dial.
The unit skips forward through the tracks when turning it right,
and skips back when turning it left.
To eject adisc, press the ~MD EJECT button
Do not hold the disc when ejecting the disc.
!,, ,,, ,,,, ,-,:$,:...:
Pull the disc out.
Selecting atrack with the remote control
Press the numbered buttons and the +1 Obutton to select atrack.
Example:
To select the 25th track, press the +1O,+1Oand 5buttons.
To select the 10th track, press the +10 and Obuttons.
The selected track starts to play and play continues to the end
of that disc.
To start play when the power is off (Direct Play
Function)
Press the MD >button. The power is turned on and play of the
Inserted disc begins.
‘Toplay adisc at the double speed
During play, keep the MD >button pressed for more than two
:seconds.
“Toresume normal play, press the MD ~button again.
Stopping play with the 9button also releases the double-speed
Iplayback mode.
lDisplay in stop mode
“The display shows the following information.
Total playing time
Total number of tracks Music calender (only the first
20 tracks are displayed)
To change the displav during playback
Press th; DISP butt~n ~or the blSP~AY button on the remote
control) during playback.
The display changes in the following order. ❑
+@Elapsed playing time of the track being played
@Remaining playback time of the current track
‘@ Total remaining playback time of the inserted MD
-@Date (year, month and day) at which the track was
recorded (displayed only when the date was registered*)
The total remaining playback time cannot be displayed when
random play or single track repeat play (page 16) is performed.
‘When recording on an MD is made using this unit, the recording
date will be registered automatically for the recorded track.
Note, however, that the date will be registered only when the
clock of this unit is set.
Lnn
●Nothing other than an MD should be inserted in the disc drive,
otherwise the disc may become scratched, causing a
malfunction or asafety hazard such as an electric shock.
●Do not attempt to insert another MD while adisc is already
inside the drive,
●Do not tilt the unit with adisc inserted. Doing so may cause
malfunctions.
ENGLISH 15

■-l
MD>= ~MULTl JOG
.,””,,.
All the tracks on the disc can be played randomly.
In stop mode, press the MODE button on the main unit
repeatedly until RANDOM? appears on the display, and
within 5seconds, press the ENTER button.
To cancel random play
Instopmode, pressthe MODE buttononthe main unitrepeatedly
untilOFF appears on the display. Then, within 5seconds, press
the ENTER button.
m
●Even if the <+ button is pressed, apreviously played track
cannot be skipped. The unit returns to the beginning of the
current track only.
●When you select atrack with the numbered buttons on the
remote control during the random play mode, the selected track
starts to play and the random play mode is canceled.
REPEAT PLAY
Asingle track or all tracks can be played back repeatedly.
Press the REPEAT button on the remote control repeatedly.
“=1” lights up when the single track repeat play is selected,
and “G” lights up when the all tracks repeat play is selected.
To cancel repeat play, press the REPEAT button repeatedly until
“=” and “1” disappear.
To select repeat play with the MODE button on the main unit
[n playback or playback pause mode, press the MODE button
repeatedly to select the desired repeat play mode.
To repeat random play
First activate random play.
Then press the REPEAT button so that “=” lights up.
PROGRAMMED PLAY
Up to 20 tracks can be programmed from the inserted disc.
1
2
3
4
5
In stop mode, press the MODE button on the main
unit repeatedly until PROGRAM? appears on the
display.
Within 5seconds, press the ENTER button.
Turn the MULTI JOG dial to select atrack to
programmed, and press the ENTER button.
Total number of Total playing time of
selected tracks the selected tracks
be
Selected track number
Repeat step 3to program other tracks.
Press the MD >button (or the -button on the
remote control) to start play.
To check the program
Each time the -button is pressed in stop mode, atrack
number and program number will be displayed.
To clear the program
Press the ■button in stop mode.
To add tracks to the program
Before playing, repeat step 3. The track will be programmed after
the last track.
To change the programmed tracks
Clear the program and repeat all the steps again.
m
●During the programmed play, the MODE and numbered buttons
do not function.
●Repeating programmed play is also possible.
●If the programmed time exceeds 199 minutes 59 seconds, or
the disc track number 31 or above is programmed, the display
shows --:-- as the total playing time.
16 EArGL/SH

OPERATION
F
oDL—
000 I3
000
000
000
0L2
@
<,
[T
+H
II
●Set the tape to the point where recording will start,
●Use Type 1(normal) tapes only for recording.
Load the tape to be recorded on into the deck.
Load the tape with the side to be recorded on first facing
toward you and the exposed side facing downward.
Press the FUNCTION button on the remote
control repeatedly until tape is selected.
Press the MODE button on the remote control
repeatedly to select the reverse mode.
To record on one side only, select =.
To record on both sides, select 1) or (Z).
When recording from the rear of the tape, the tape stops at
the end of recording of the rear side, even if the reverse mode
is set to 1) or (1).
Prepare the source to be recorded.
To record from aradio broadcast, press the TUNER/BAND
button and tune in to astation.
To record from aCD or MD, first press the CD Por MD F
button and load the disc, then press the <+ or ➤*button
or turn the MULTI JOG dial to select the track to be recorded
first.
Press the ●TAPE REC button to start recording.
TAPE~ appears on the display.
When the selected source is CD or MD, playback and
recording start simultaneously.
To stop recording, press the ❑button. When recording from a
CD or an MD, press the ■button again to stop playback.
To pause recording, press me II button. (Applicable when the
source is the radio.) To resume recording, press again.
m
If squealing or beating sounds occur when recording an AM
broadcast, press the MODE button repeatedly and select one of
the two modes, BEAT 1or BEAT 2, which eliminates the noise
better.
RECORDING AWHOLE CD OR MD ONTO
ATAPE
Use the CD/MD~TAPE button to record all the tracks of aCD
or MD onto atape from the beginning.
If the tape reaches its end of the front side while atrack is being
played, recording of this track starts from the beginning on the
opposite side of the tape,
Prepare atape having alength longer than the total playing time
of
1
2
3
4
the CD or MD to be recorded.
Load the tape to be recorded on into the deck.
Press the TAPE +➤button to select the side to
be recorded, then set the tape to the position to
start recording.
When recording aCD :
Load the disc and press the FUNCTION button
on the remote control to select CD.
When recording an MD:
Load the disc and press the FUNCTION button
on the remote control to select MD.
Press the CIWMD>TAPE button.
Playback and recording starts simultaneously.
If recording was started from the front side of the tape, and
when recording on the front side ends, recording on the rear
side starts.
If recording was started from the rear side, and when recording
on the rear side ends, recording stops.
To stop recording
Press the ■button.
To stop playback, press the ■button again.
To erase arecording
1Insert the tape to be erased into the deck.
2Press the TAPE +E button to select the side to be erased,
then set the tape to the point where the erasure is to be
started.
3Press the ●TAPE REC button to start the erasure.
ENGLISH ~7

ABOUT THE INDEX MARK
The unit registers index marks while recording on an MD.
Index marks allow you to easily locate the desired tracks.
When recording from aCD
The index mark information recorded on the CD is copied as it
is.
CD 2nd track I3rd track I4th track I
Recording
(MD) 2nd track 3rd track 4th track
., AAAA
A:Index mark
When recording from atape
An index mark is registered automatically when asound signal
is input after ablank section lasting more than 3seconds.
Recording
(MD) 2nd track 3rd track 4th track
AA A A
A:Index mark
When recording from radio
The index mark information is registered every 5minutes.
m
There may be a case where index marks are not registered
accurately.
MANUAL MARK FUNCTION
To record on apreviously recorded MD
If there is an unrecorded section left on the MD, the new recording
automatically starts from where the previous recording finished.
If you want to start recording from the beginning of apreviously
recorded MD, erase the previous recording completely. (See
page 25.)
To check the recordable time of the MD
Pressthe FUNCTION buttononthe remotecontrolto select other
than MD, and load an MD. Then mess the DISPLAY button on
the remote control (or the DISP button on the main unit).
The recordable time on the MD is displayed for 5seconds.
\
To prevent accidental erasure of recorded material
Slide the record-protect tab as shown below.
Slide the tab so that it is completely locked.
To protect recorded contents
If arecording is attempted when the tab is set to the ~rotected
position, “Protected” appears on the display. Move the protect-
tab to the original position.
When recording using the ●MD REC button (page 21), you
can record index mark information anytime you want by pressing
the ENTER button.
18 ENGLISH

RECORDING AWHOLE CD RECORDING A CD ONTO ATAPE AND AN
MD SIMULTANEOUSLY
■---y rCD/MD}TAPE ~DISpLAY 1
I
D
.1Oo
000 2
000
000
OOQ 3
00
@
o4
F( ■
Load aCD and press the FUNCTION button on
the remote control to select CD.
Load atape to be recorded.
Insert arecordable MD into the disc drive.
Press the CD - MD button and the CD/MD -
TAPE button simultaneously.
Recording onto the tape starts, while the CD enters playback
pause mode and the MD enters the recording pause mode.
After 8seconds (nothing will be recorded onto the tape in this
period), the CD starts to play and the recording onto the MD
also starts.
1Insert arecordable MD into the disc drive with -
the label side up and in the direction of the arrow. Iostop recording
Press the ■button.
Direction guide
7!!!52!
●
I“
2Load aCD and press the CD P
stop mode.
Recording starts.
If the tape reaches its end of the front side while a
track is being played
This track will be recorded onto the tape and the MD as follows:
@Recording side of the tape changes from the front side to the
opposite side, and the tape enters the recording pause mode.
@This track is recorded to its end onto the MD, and the MD
enters the recording pause mode.
MD button in @,Thetape enters the recording mode and the recording of this
track starts from the beginning.
@When this track is recorded to its end onto the tape, the MD
re-enters the recording mode, and the subsequent tracks will
When the last track of the CD finishes playing, the recording
stops automatically.
When recording stops, TOC-EDIT flashes on the display and
the contents (TOC) of the recording are recorded on the MD.
To stop recording before the end of the CD
Press the 1button. Recording to the MD stops, and the contents
(TOC) of the recording are recorded on the MD.
To stop play of the CD, press the ■button again.
To change the display during recording
Pressing the DISP button (or the DISPLAY button on the remote
control) changes the information shown on the lower part of the
display as follows.
r
~] Elapsed playing time of the track being recorded
@Remaining playback time of the current track
@, Total remaining playback time of the inserted CD
lfT. OVER appears
The remaining recordable time of the MD is not enough to record
awhole CD.
Press the Hbutton and replace the MD with another one.
Or press the CD FMD button again to start recording if it does
not matter whether recording is cut short or not.
ENGLISH 19

RECORDING ONLY ONE TRACK
OF A CD
2T
9---)
rMULTl JOG P
000
000
000 I0-9,+10
000
000
Oa
@!gq---
++, ➤>
0 L, II
1
2
3
4
Insert arecordable MD into the disc drive with
the label side up and in the direction of the arrow.
Load aCD and press the CD ~button.
Playback starts.
Select the desired track.
Use the 4+ or ➤>button, the MULTI JOG dial, or the
numbered buttons on the remote control to play back the
desired track.
Press the CD FMD button to start recording.
The CD returns to the beginning of the track and recording
starts.
When the track of the CD finishes playing, the recording stops
automatically, while the CD goes to the next track.
When recording stops, TOC-EDIT flashes on the display and
the contents (TOC) of the recording are recorded on the MD.
To stop recording before the end of the track
Press the ■button. Recording to the MD stops, and the contents
(TOC) of the recording are recorded on the MD.
To stop play of the CD, press the ■button again.
PROGRAMMED RECORDING OF
A CD
Up to 20 tracks can be programmed and recorded on an MD.
1
2
3
4
5
6
7
31!5 VDISPLAY
b’
@
.lOcl
000
000
000
I
5
000
0Lt?
@l
0Lm II
Insert arecordable MD into the disc drive with
the label side up and in the direction of the arrow.
Load aCD and press the FUNCTION button on
the remote control to select CD.
In stop mode, press the MODE button repeatedly
until PROGRAM? appears on the display.
Within 5seconds, press the ENTER button.
Turn the MULTI JOG dial to select atrack to be
programmed, and press the ENTER button.
Repeat step 5to program other tracks.
For detailed explanations on how to program the tracks, see
page 12.
Press the CD *MD button to start recording.
Recording begins.
When the programmed tracks finish playing, the recording
stops automatically.
When recording stops, TOC-EDIT flashes on the display and
the contents (TOC) of the recording are recorded on the MD.
To stop recording halfway
Press the ■button. Recording to the MD stops, and the contents
(TOC) of the recording are recorded on the MD.
To stop play of the CD, press the ■button again.
To change the display during recording
Pressing the DISP button(orthe DISPLAY buttonon the remote
control) changes the informationshown on the lower part of the
display as follows.
r
@Elapsed playing time of the track being recorded
@Remaining playback time of the current track
Q) Remaining recording time
20 ENGLISH
