S E R V I C E M A N U A L
SIMPLE MANUAL
•Replace this Service Manual with ”Revision Publishing” when it is issued.
CA-DW345
• TYPE: LH
COMPACT DISC STEREO SYSTEM
• BASIC TAPE MECHANISM:TN-21ZSW-1694
S/M Code No. 09–98C–402–2T1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICALPARTSLIST-1/5
NOTE: The characters in the suffix column indicate the part usage.
LHSCC ..................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 218 87-010-400-080 0E CAP, ELECT 0.47-50V A...................
C 217 87-010-400-080 0E CAP, ELECT 0.47-50V A...................
C 228 87-010-401-080 0E CAP, ELECT 1-50V A...................
C 229 87-010-401-080 0E CAP, ELECT 1-50V A...................
C 238 87-010-263-080 0E CAP, ELECT 100-10V A...................
C 237 87-010-380-080 0E CAP, ELECT 47-16V A...................
C 236 87-010-544-080 0E CAP, ELECT 0.1-50V A...................
C 235 87-010-544-080 0E CAP, ELECT 0.1-50V A...................
C 234 87-010-546-080 0E CAP, ELECT 0.33-50V A...................
C 233 87-010-546-080 0E CAP, ELECT 0.33-50V A...................
C 247 87-010-404-080 0E CAP, ELECT 4.7-50V A...................
C 248 87-010-404-080 0E CAP, ELECT 4.7-50V A...................
C 245 87-010-405-080 0E CAP, ELECT 10-50V A...................
C 242 87-010-405-080 0E CAP, ELECT 10-50V A...................
C 244 87-010-405-080 0E CAP, ELECT 10-50V A...................
C 241 87-010-405-080 0E CAP, ELECT 10-50V A...................
C 243 87-010-405-080 0E CAP, ELECT 10-50V A...................
C 246 87-010-405-080 0E CAP, ELECT 10-50V A...................
C 261 87-010-402-080 0E CAP, ELECT 2.2-50V A...................
C 262 87-010-402-080 0E CAP, ELECT 2.2-50V A...................
C 291 87-010-404-080 0E CAP, ELECT 4.7-50V A...................
D 281 87-A40-466-080 0E ZENER,MTZJ2.7A A...................
IC 203 87-A21-111-040 1C C-IC,M62495FP A...................
C 208 87-010-402-080 0E CAP, ELECT 2.2-50V A...................
C 207 87-010-408-080 0E CAP, ELECT 47-50V A...................
C 209 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 212 87-010-401-080 0E CAP, ELECT 1-50V A...................
C 211 87-010-401-080 0E CAP, ELECT 1-50V A...................
C 210 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 223 87-010-405-080 0E CAP, ELECT 10-50V A...................
C 222 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 226 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 223 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 2202 87-010-405-080 0E CAP, ELECT 10-50V A...................
IC 201 87-A20-946-040 1D C-IC,MM1434XF A...................
C 251 87-010-401-080 0E CAP, ELECT 1-50V A...................
C 268 87-010-380-080 0E CAP, ELECT 47-16V A...................
C 267 87-010-380-080 0E CAP, ELECT 47-16V A...................
C 265 87-010-383-080 0E CAP, ELECT 33-25V A...................
C 266 87-010-383-080 0E CAP, ELECT 33-25V A...................
C 263 87-018-131-080 0E CAP, CER 1000P-50V A...................
C 264 87-018-131-080 0E CAP, CER 1000P-50V A...................
C 279 87-010-112-080 0E CAP, ELECT 100-16V A...................
C 271 87-010-221-080 0E CAP, ELECT 470-10V A...................
C 272 87-010-221-080 0E CAP, ELECT 470-10V A...................
C 277 87-010-260-080 0E CAP, ELECT 47-25V A...................
C 278 87-010-384-080 0E CAP, ELECT 100-25V A...................
C 280 87-010-401-080 0E CAP, ELECT 1-50V A...................
C 281 87-010-401-080 0E CAP, ELECT 1-50V A...................
CN 201 88-CT6-621-010 SP TERMINAL 4P LEVER A...................
IC 202 87-A20-591-010 1C IC,BA5417 A...................
J 251 87-009-216-010 1A JACK, DIA 3.5 A...................
Q 243 89-320-011-010 0E TR,2SC2001 (0.6W) A...................
Q 244 89-320-011-010 0E TR,2SC2001 (0.6W) A...................
C 508 87-010-221-080 0E CAP, ELECT 470-10V A...................
C 509 87-010-263-080 0E CAP, ELECT 100-10V A...................
C 507 87-010-401-080 0E CAP, ELECT 1-50V A...................
C 506 87-010-404-080 0E CAP, ELECT 4.7-50V A...................
C 501 87-010-453-010 1C CAP, ELECT 4700-25V A...................
C 510 87-010-248-080 0E CAP, ELECT 220-10V A...................
C 514 87-010-248-080 0E CAP, ELECT 220-10V A...................
C 511 87-010-384-080 0E CAP, ELECT 100-25V A...................
C 512 87-010-385-080 0E CAP, ELECT 220-25V A...................
C 533 87-010-221-080 0E CAP, ELECT 470-10V A...................
C 531 87-010-401-080 0E CAP, ELECT 1-50V A...................
C 543 87-010-221-080 0E CAP, ELECT 470-10V A...................
C 541 87-010-401-080 0E CAP, ELECT 1-50V A...................
C 544 87-010-405-080 0E CAP, ELECT 10-50V A...................
D 507 87-017-148-080 0E ZENER,HZS6A1L A...................
D 504 87-017-161-080 0E ZENER,HZS7C2L A...................
D 508 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 509 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 505 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 503 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 506 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 511 87-017-139-010 0E ZENER,HZS15-2 A...................
IC 510 87-070-416-010 1B IC,NJU7201 L55 A...................
PN 501 87-049-919-010 0E CONN,3P EH V WHT A...................
Q 503 87-026-291-010 1A TR,DTC124XS A...................
Q 507 87-026-462-010 0E TR,2SC1740S A...................
Q 505 87-026-462-010 0E TR,2SC1740S A...................
Q 502 87-026-463-010 0E TR,2SA933S,RS A...................
Q 506 88-NF9-637-010 TR,2SA1318T/U A...................
Q 501 89-112-965-010 0E TR,2SA1296GR A...................
Q 504 89-213-702-010 1A TR,2SB1370 (1.8W) A...................
Q 510 87-026-462-010 0E TR,2SC1740S A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICALPARTSLIST-2/5
Q 532 87-026-291-010 1A TR,DTC124XS A...................
Q 531 87-026-463-010 0E TR,2SA933S,RS A...................
Q 542 87-026-291-010 1A TR,DTC124XS A...................
Q 541 89-112-965-010 0E TR,2SA1296GR A...................
88-CT6-632-010 TERMINAL,ASSY MECHA 1P A...................
C 305 87-010-374-080 0E CAP, ELECT 47-10V A...................
C 306 87-010-374-080 0E CAP, ELECT 47-10V A...................
C 307 87-010-382-080 0E CAP, ELECT 22-25V A...................
C 308 87-010-405-080 0E CAP, ELECT 10-50V A...................
C 309 87-010-545-080 0E CAP, ELECT 0.22-50V A...................
C 301 87-018-131-080 0E CAP, CER 1000P-50V A...................
C 302 87-018-131-080 0E CAP, CER 1000P-50V A...................
C 303 87-018-131-080 0E CAP, CER 1000P-50V A...................
C 304 87-018-131-080 0E CAP, CER 1000P-50V A...................
C 311 87-010-248-080 0E CAP, ELECT 220-10V A...................
C 312 87-010-374-080 0E CAP, ELECT 47-10V A...................
C 318 87-010-382-080 0E CAP, ELECT 22-25V A...................
C 317 87-010-382-080 0E CAP, ELECT 22-25V A...................
C 315 87-010-401-080 0E CAP, ELECT 1-50V A...................
C 316 87-010-401-080 0E CAP, ELECT 1-50V A...................
C 319 87-010-405-080 0E CAP, ELECT 10-50V A...................
C 310 87-010-545-080 0E CAP, ELECT 0.22-50V A...................
C 327 87-010-404-080 0E CAP, ELECT 4.7-50V A...................
C 320 87-010-405-080 0E CAP, ELECT 10-50V A...................
C 321 87-018-125-080 0E CAP, CER 330P-50V A...................
C 322 87-018-125-080 0E CAP, CER 330P-50V A...................
C 328 87-018-131-080 0E CAP, CER 1000P-50V A...................
C 329 87-018-132-080 0E CAP, CER 2200P-16V A...................
C 325 87-018-196-080 0E CAP, CER 1500P-16V A...................
C 326 87-018-196-080 0E CAP, CER 1500P-16V A...................
C 331 87-010-374-080 0E CAP, ELECT 47-10V A...................
C 334 87-018-122-080 0E CAP 180P-50 B A...................
C 342 87-018-125-080 0E CAP, CER 330P-50V A...................
C 341 87-018-125-080 0E CAP, CER 330P-50V A...................
C 344 87-018-125-080 0E CAP, CER 330P-50V A...................
C 343 87-018-125-080 0E CAP, CER 330P-50V A...................
C 765 87-018-209-080 0E CAP, CER 0.1-50V A...................
D 762 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 761 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 764 87-A40-465-010 0E DIODE,FR202 A...................
IC 302 87-001-440-010 0E IC,BA15218N A...................
IC 301 87-020-828-010 1C IC,BA3416BL * A...................
L 330 88-CT6-620-010 REC OSC A...................
PN 301 87-A60-110-010 0E CONN,4P V S2M-4W A...................
PN 302 87-A60-111-010 0E CONN,5P V S2M 5W A...................
PN 751 87-099-832-010 0E CONN,8P S2M-8W A...................
Q 308 87-026-462-080 0E TR,2SC1740 S(RS 0.3W) A...................
Q 306 89-320-011-080 0E TR,2SC2001 (15W) A...................
Q 311 87-026-291-080 1A TR,DTC124XS A...................
Q 762 87-026-291-080 1A TR,DTC124XS A...................
Q 761 87-026-463-080 0E TR,2SA933S (0.3W) A...................
Q 771 87-026-291-080 1A TR,DTC124XS A...................
Q 770 89-112-965-080 0E TR,2SA1296 (0.75W) A...................
R 761 87-029-019-010 0E RES, FUSEIBLE 1/2W-2.2 A...................
SFR 761 87-024-239-010 0E SFR,2.2K V RH0632C A...................
SW 301 88-CT6-619-010 BACK SLIDE SW 6P2T SHORTIN A...................
8Z-CT6-201-010 HLDR,LCD A...................
8Z-CT6-205-010 HLDR,LED FUNC A...................
8Z-CT7-202-010 HLDR,LED GEQ A...................
C 601 89-654-185-080 0E CAP,TC 18P-50 J CH UP125 A...................
C 604 89-654-215-080 0E CAP,TC 22P-50 J CH UP125 A...................
C 602 89-654-235-080 0E CAP TC 27P-50J CH A...................
C 605 89-654-275-080 0E CAP,TC 39P-50 J CH UP125 A...................
C 603 89-654-275-080 0E CAP,TC 39P-50 J CH UP125 A...................
C 612 87-010-248-080 0E CAP, ELECT 220-10V A...................
C 618 87-010-263-080 0E CAP, ELECT 100-10V A...................
C 615 87-010-400-080 0E CAP, ELECT 0.47-50V A...................
C 616 87-010-401-080 0E CAP, ELECT 1-50V A...................
C 613 87-010-402-080 0E CAP, ELECT 2.2-50V A...................
C 611 87-018-209-080 0E CAP, CER 0.1-50V A...................
C 614 87-018-209-080 0E CAP, CER 0.1-50V A...................
C 621 87-010-263-080 0E CAP, ELECT 100-10V A...................
C 699 87-010-371-080 0E CAP, ELECT 470-6.3V A...................
CN 601 87-A60-109-010 0E CONN,2P V S2M-2W A...................
CN 602 87-A60-110-010 0E CONN,4P V S2M-4W A...................
D 602 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 605 87-020-465-080 0E DIODE,1SS133 (110MA) ....................
D 608 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 601 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 611 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 615 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 612 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 616 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 614 87-027-607-080 0E ZENER,HZ7B3L A...................
IC 602 87-A20-914-010 1B IC,SPS-442-1-F A...................
IC 601 8Z-CH4-636-010 2A IC,LC867132V-**** A...................
L 601 87-003-171-010 0E COIL,15UH TROIDAL A...................
LCD 601 8Z-CT6-610-010 LCD,HLC7374 ZCT-6 A...................
LED 603 8Z-CT6-632-010 LED,L-934LID A...................
LED 602 8Z-CT6-632-010 LED,L-934LID A...................
LED 601 8Z-CT6-632-010 LED,L-934LID A...................
LED 606 8Z-CT6-637-010 LED,L-474SRT A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICALPARTSLIST-3/5
LED 607 8Z-CT6-637-010 LED,L-474SRT A...................
LED 605 8Z-CT6-637-010 LED,L-474SRT A...................
LED 610 8Z-CT6-632-010 LED,L-934LID A...................
Q 603 87-026-291-010 1A TR,DTC124XS A...................
Q 601 87-026-291-010 1A TR,DTC124XS A...................
Q 602 87-026-463-010 0E TR,2SA933S,RS A...................
Q 607 87-026-464-010 0E TR,DTC114TS A...................
Q 609 87-026-464-010 0E TR,DTC114TS A...................
Q 605 87-026-464-010 0E TR,DTC114TS A...................
Q 608 87-026-464-010 0E TR,DTC114TS A...................
Q 606 87-026-464-010 0E TR,DTC114TS A...................
Q 615 87-026-291-010 1A TR,DTC124XS A...................
Q 616 87-026-291-010 1A TR,DTC124XS A...................
Q 614 87-026-463-010 0E TR,2SA933S,RS A...................
Q 612 87-026-464-010 0E TR,DTC114TS A...................
Q 611 87-026-464-010 0E TR,DTC114TS A...................
Q 610 87-026-464-010 0E TR,DTC114TS A...................
Q 613 89-318-154-080 0E TR,2SC1815 (0.4W) A...................
S 609 8Z-CT6-636-010 SW,TACT EVQJAC04M A...................
S 605 8Z-CT6-636-010 SW,TACT EVQJAC04M A...................
S 604 8Z-CT6-636-010 SW,TACT EVQJAC04M A...................
S 607 8Z-CT6-636-010 SW,TACT EVQJAC04M A...................
S 608 8Z-CT6-636-010 SW,TACT EVQJAC04M A...................
S 606 8Z-CT6-636-010 SW,TACT EVQJAC04M A...................
S 603 8Z-CT6-636-010 SW,TACT EVQJAC04M A...................
S 616 8Z-CT6-636-010 SW,TACT EVQJAC04M A...................
S 611 8Z-CT6-636-010 SW,TACT EVQJAC04M A...................
S 612 8Z-CT6-636-010 SW,TACT EVQJAC04M A...................
S 615 8Z-CT6-636-010 SW,TACT EVQJAC04M A...................
S 610 8Z-CT6-636-010 SW,TACT EVQJAC04M A...................
S 613 8Z-CT6-636-010 SW,TACT EVQJAC04M A...................
S 614 8Z-CT6-636-010 SW,TACT EVQJAC04M A...................
X 601 87-030-273-010 1A VIB,XTAL 32.768K5PPM A...................
X 602 87-A70-070-080 1A VIB,CER 5.76MHZ CRHF A...................
C 839 87-010-401-080 0E CAP, ELECT 1-50V A...................
C 838 87-010-401-080 0E CAP, ELECT 1-50V A...................
C 834 87-010-404-080 0E CAP, ELECT 4.7-50V A...................
C 835 87-010-544-080 0E CAP, ELECT 0.1-50V A...................
C 840 87-010-221-080 0E CAP, ELECT 470-10V A...................
C 844 87-010-401-080 0E CAP, ELECT 1-50V A...................
C 841 87-010-401-080 0E CAP, ELECT 1-50V A...................
C 842 87-018-127-080 0E CAP, CER 470P-50V A...................
D 821 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 820 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 822 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
J 801 87-009-216-010 1A JACK, DIA 3.5 A...................
Q 823 87-026-291-080 1A TR,DTC124XS A...................
Q 824 87-026-462-080 0E TR,2SC1740 S(RS 0.3W) A...................
Q 821 87-026-610-080 0E TR,KTC3198GR A...................
Q 820 87-026-610-080 0E TR,KTC3198GR A...................
Q 822 87-026-610-080 0E TR,KTC3198GR A...................
Q 821 89-322-405-080 0E TR,2SC2240GR A...................
VR 801 87-A91-154-010 VR,RTRY 10KAX1 H A...................
C 409 87-010-248-080 0E CAP, ELECT 220-10V A...................
C 404 87-010-248-080 0E CAP, ELECT 220-10V A...................
C 403 87-010-263-080 0E CAP, ELECT 100-10V A...................
C 406 87-010-374-080 0E CAP, ELECT 47-10V A...................
C 401 87-010-403-080 0E CAP, ELECT 3.3-50V A...................
C 402 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 405 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 410 87-010-263-080 0E CAP, ELECT 100-10V A...................
C 414 87-010-405-080 0E CAP, ELECT 10-50V A...................
C 412 87-010-544-080 0E CAP, ELECT 0.1-50V A...................
C 416 87-010-545-080 0E CAP, ELECT 0.22-50V A...................
C 417 87-018-125-080 0E CAP, CER 330P-50V A...................
C 427 87-018-123-080 0E CAP, CER 220P-50V A...................
C 425 87-018-129-080 0E CAP, CER 680P-50V A...................
C 436 87-010-374-080 0E CAP, ELECT 47-10V A...................
C 432 87-010-374-080 0E CAP, ELECT 47-10V A...................
C 431 87-010-400-080 0E CAP, ELECT 0.47-50V A...................
C 433 87-010-401-080 0E CAP, ELECT 1-50V A...................
C 437 87-010-404-080 0E CAP, ELECT 4.7-50V A...................
C 430 87-018-123-080 0E CAP, CER 220P-50V A...................
C 435 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 438 87-018-209-080 0E CAP, CER 0.1-50V A...................
C 448 87-018-111-080 0E CAP, CERA-SOL SS 27P A...................
C 440 87-018-139-080 0E CAP,TC-U 1P-50 CH A...................
C 442 87-018-149-080 0E CAP,TC-U 15P-50 CH A...................
C 446 87-018-209-080 0E CAP, CER 0.1-50V A...................
C 447 87-018-209-080 0E CAP, CER 0.1-50V A...................
C 445 87-018-209-080 0E CAP, CER 0.1-50V A...................
C 459 87-010-263-080 0E CAP, ELECT 100-10V A...................
C 458 87-018-113-080 0E CAP, CER 33P-50V A...................
C 457 87-018-113-080 0E CAP, CER 33P-50V A...................
C 453 87-018-119-080 0E CAP, CER 100P-50V A...................
C 454 87-018-120-080 0E CAP, CERA-SOL SS 120P A...................
C 451 87-018-123-080 0E CAP, CER 220P-50V A...................
C 452 87-018-127-080 0E CAP, CER 470P-50V A...................
C 450 87-018-127-080 0E CAP, CER 470P-50V A...................
C 462 87-010-248-080 0E CAP, ELECT 220-10V A...................
C 467 87-010-263-080 0E CAP, ELECT 100-10V A...................
C 465 87-010-404-080 0E CAP, ELECT 4.7-50V A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICALPARTSLIST-4/5
C 469 87-018-121-080 0E CAP, CER 150P-50V A...................
C 466 87-018-209-080 0E CAP, CER 0.1-50V A...................
C 461 87-018-209-080 0E CAP, CER 0.1-50V A...................
C 460 87-018-209-080 0E CAP, CER 0.1-50V A...................
C 476 87-010-236-080 0E CAP,E 1000-10 SME A...................
C 478 87-010-263-080 0E CAP, ELECT 100-10V A...................
C 470 87-010-544-080 0E CAP, ELECT 0.1-50V A...................
C 475 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 479 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 477 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 480 87-010-221-080 0E CAP, ELECT 470-10V A...................
C 481 87-010-405-080 0E CAP, ELECT 10-50V A...................
C 482 87-010-405-080 0E CAP, ELECT 10-50V A...................
C 484 87-018-123-080 0E CAP, CER 220P-50V A...................
C 483 87-018-123-080 0E CAP, CER 220P-50V A...................
C 489 87-018-209-080 0E CAP, CER 0.1-50V A...................
C 493 87-018-119-080 0E CAP, CER 100P-50V A...................
C 503 87-018-119-080 0E CAP, CER 100P-50V A...................
C 502 87-018-119-080 0E CAP, CER 100P-50V A...................
C 505 87-018-119-080 0E CAP, CER 100P-50V A...................
C 504 87-018-119-080 0E CAP, CER 100P-50V A...................
C 501 87-018-119-080 0E CAP, CER 100P-50V A...................
C 500 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 506 87-018-209-080 0E CAP, CER 0.1-50V A...................
C 510 87-018-209-080 0E CAP, CER 0.1-50V A...................
CN 401 87-A60-424-010 0E CONN,16P V TOC-B A...................
CNA 402 8Z-CT6-631-010 CONN ASSY,6P CD MO A...................
D 402 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 401 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 403 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
IC 401 87-A20-446-010 1E C-IC,LA9241ML A...................
IC 402 87-A20-459-010 2A C-IC,LC78622ED A...................
IC 404 87-A21-093-010 1C IC,LA6541D A...................
L 405 81-NWB-655-010 1A COIL,10UH TROIDAL A...................
L 407 81-NWB-655-010 1A COIL,10UH TROIDAL A...................
L 401 87-003-102-080 0E COIL, 10UH A...................
L 412 81-NWB-655-010 1A COIL,10UH TROIDAL A...................
Q 401 87-026-463-080 0E TR,2SA933S (0.3W) A...................
Q 402 89-113-184-080 0E TR,2SA1318T A...................
Q 426 87-026-502-080 0E DTC144TS A...................
Q 482 87-026-486-080 0E TR,DTA144TS A...................
Q 481 87-026-486-080 0E TR,DTA144TS A...................
Q 483 87-026-502-080 0E DTC144TS A...................
Q 484 87-026-502-080 0E DTC144TS A...................
X 401 81-592-641-010 1A CERAMIC FILTER, 16.93MHZ A...................
C 491 87-010-197-080 0E CAP, CHIP 0.01 DM A...................
C 492 87-010-221-080 0E CAP, ELECT 470-10V A...................
D 494 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 492 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 491 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
Q 401 87-026-463-080 0E TR,2SA933S (0.3W) A...................
Q 492 87-026-291-080 1A TR,DTC124XS A...................
Q 491 89-112-965-080 0E TR,2SA1296 (0.75W) A...................
88-CT6-624-010 SPR,BATT A...................
C 904 87-A10-577-080 CAP,CER 0.022-50 Z YF A...................
C 902 87-A10-577-080 CAP,CER 0.022-50 Z YF A...................
C 903 87-A10-577-080 CAP,CER 0.022-50 Z YF A...................
C 901 87-A10-577-080 CAP,CER 0.022-50 Z YF A...................
D 901 87-A40-465-010 0E DIODE,FR202 A...................
D 902 87-A40-465-010 0E DIODE,FR202 A...................
D 905 87-A40-465-010 0E DIODE,FR202 A...................
D 904 87-A40-465-010 0E DIODE,FR202 A...................
D 903 87-A40-465-010 0E DIODE,FR202 A...................
FC 0 87-A90-160-080 0E FUSE CLAMP,FC 51F A...................
* 8Z-CT7-207-010 HLDR,LED A...................
LED 608 8Z-CT6-632-010 LED,L-934LID A...................
LED 609 8Z-CT6-635-010 LED,L-934LGD A...................
C 6 87-010-378-080 0E CAP, ELECT 10-16V A...................
C 3 87-018-059-080 0E CAP TC-S 22P-50CH A...................
C 1 87-018-059-080 0E CAP TC-S 22P-50CH A...................
C 2 87-018-062-080 0E CAP,TC-S 33P-50 CH A...................
C 8 87-018-132-080 0E CAP, CER 2200P-16V A...................
C 8 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 9 87-018-161-080 0E TC CAP 12P A...................
C 9 87-018-162-080 0E CAP 15P SS RH ....................
C 7 87-018-208-080 0E CAP 0.047-50F A...................
C 14 87-010-400-080 0E CAP, ELECT 0.47-50V A...................
C 19 87-010-544-080 0E CAP, ELECT 0.1-50V A...................
C 17 87-010-544-080 0E CAP, ELECT 0.1-50V A...................
C 12 87-018-059-080 0E CAP TC-S 22P-50CH A...................
C 16 87-018-131-080 0E CAP, CER 1000P-50V ....................
C 15 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 10 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 13 87-018-142-080 0E CAP,TC-U 3.9P-50 CH A...................
C 11 87-018-151-080 0E CAP, CERA-SOL SS 20P CH ....................
C 11 87-018-163-080 CAP,TC U 18P-50 J RH UP050 A...................
C 18 87-018-205-080 0E CAP, CERA-SOL 0.022 A...................
C 20 87-010-400-080 0E CAP, ELECT 0.47-50V A...................
C 21 87-010-403-080 0E CAP, ELECT 3.3-50V A...................
C 26 87-010-545-080 0E CAP, ELECT 0.22-50V A...................
C 27 87-010-545-080 0E CAP, ELECT 0.22-50V A...................
C 22 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICALPARTSLIST-5/5
C 28 87-018-208-080 0E CAP 0.047-50F A...................
C 29 87-018-208-080 0E CAP 0.047-50F A...................
C 30 87-010-248-080 0E CAP, ELECT 220-10V A...................
C 31 87-010-379-080 0E CAP, ELECT 22-16V A...................
C 35 87-018-059-080 0E CAP TC-S 22P-50CH ....................
C 32 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 34 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 33 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................
C 44 87-018-122-080 0E CAP 180P-50 B ....................
C 46 87-018-128-080 0E CAP, CERA-SOL SS 560P ....................
C 45 87-018-131-080 0E CAP, CER 1000P-50V ....................
CF 2 87-008-261-010 1A FILTER, SFE10.7MA5-A A...................
CF 3 87-008-261-010 1A FILTER, SFE10.7MA5-A A...................
CF 1 87-A91-150-010 FLTR, CFAL-455(TOKO) A...................
D 4 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 2 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 1 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 3 87-A40-226-080 0E VARI-CAP,SVC251SPA A...................
IC 1 87-A20-955-010 1C IC,LA1828 A...................
L 9 87-A50-334-010 1A COIL,FM DET (TOKO) A...................
L 8 87-A50-335-010 1A COIL,FM IFT (TOKO) A...................
L 7 87-A50-336-010 1A COIL,AM IFT (TOKO) A...................
L 6 87-A50-337-010 1A COIL,AM OSC (TOKO) A...................
L 5 87-A50-343-010 COIL,FM OSC EX A...................
L 4 87-A50-345-010 0E COIL,FM RF EX A...................
L 2 87-A50-347-010 COIL,FM BPF EX A...................
L 3 87-A50-348-010 COIL,BAR ANT LW/MW (COI) ....................
L 3 87-A50-349-010 COIL,BAR ANT AMW (COI) A...................
L 10 87-003-102-080 0E COIL, 10UH A...................
L 17 87-A50-340-010 COIL,SW OSC (TOKO) ....................
L 11 87-A50-341-010 COIL,SW ANT (TOKO) ....................
L 16 87-A50-420-010 1E COIL,MW OSC(SYN) ....................
L 41 87-003-143-080 0E COIL 4.7 UH ....................
Q 3 87-026-215-080 0E TR,DTC114YS A...................
Q 5 87-026-291-080 1A TR,DTC124XS A...................
Q 2 87-026-572-080 0E TR,DTA114TS A...................
Q 4 89-109-521-080 0E TR,2SA952 (0.6W) ....................
Q 1 89-319-233-080 0E TR,2SC1923 (0.1W) A...................
SW 2 88-CT6-618-010 SLIDE SW 4P3T ....................
SW 1 88-CT7-602-010 SLIDE SW 2P2T A...................
TC 6 87-011-220-080 1A TRIMMER CAP 20P VTC ....................
TC 5 87-011-221-080 1A CAP, TRIMMER 30P ....................
VC 1 87-A90-984-010 TUN-CAP,20P-160P AL-U(TOKO) A...................
VC 1 87-A90-985-010 TUN-CAP,20P-335P L-H(TOKO) ....................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
MECHANICAL PARTS LIST-1/2
NOTE: The characters in the suffix column indicate the part usage.
LHSCC ..................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-CT6-002-010 CABI,REAR A...................
8Z-CT6-003-010 BOX,CD A...................
8Z-CT6-004-010 CHAS,CD A...................
8Z-CT6-005-010 BOX,CASS L A...................
8Z-CT6-006-010 BOX,CASS R A...................
8Z-CT6-007-010 WINDOW,CASS L A...................
8Z-CT6-008-010 WINDOW,CASS R A...................
8Z-CT6-010-010 PANEL,FR A...................
8Z-CT6-018-010 RING,Q A...................
8Z-CT6-022-010 LENS,Q A...................
8Z-CT6-025-010 LID,BATT A...................
8Z-CT6-026-010 HANDL,ARM A...................
8Z-CT6-027-010 HANDL,GRIP A...................
8Z-CT7-001-010 CABI,FR A...................
8Z-CT7-005-010 POINTER,TU A...................
8Z-CT7-006-010 LENS,GEQ A...................
8Z-CT7-008-010 LENS,LED A...................
8Z-CT7-009-010 WINDOW,DISP A...................
8Z-CT7-020-010 WINDOW,DISP HE ....................
8Z-CT7-027-010 CABI,FR HR ....................
8Z-CT6-011-010 BTN,VOL A...................
8Z-CT6-014-010 BTN,FUNC A...................
8Z-CT6-015-010 BTN,PLAY A...................
8Z-CT6-017-010 BTN,Q A...................
8Z-CT6-019-010 KNOB,RTRY MIC A...................
8Z-CT6-023-010 KEY,CASS A A...................
8Z-CT6-024-010 KEY,CASS B A...................
8Z-CT6-028-010 BTN,STOP A...................
8Z-CT6-030-010 BTN,BACK SKIP A...................
8Z-CT6-031-010 BTN,FWD SKIP A...................
8Z-CT7-002-010 KNOB,RTRY BAND ....................
8Z-CT7-003-010 BTN,GEQ ....................
8Z-CT7-004-010 KNOB,RTRY TU A...................
8Z-CT7-017-010 KNOB,RTRY BAND A A...................
8Z-CT7-018-010 BTN,GEQ LH A...................
86-CT9-026-010 PLATE,AC A...................
88-CT6-031-010 PLATE,BATT A...................
88-CT6-046-010 PANEL,CD A...................
8Z-CT6-029-010 WINDOW,CD A...................
S 0 87-036-389-010 1B SW,PUSH LOCK A...................
86-CD4-225-010 CHUCK(A) A...................
86-CT9-210-010 SPR-T,CASS A...................
86-CT9-211-010 SPR-T,CD A...................
86-CT9-212-010 SPR-C,BATT LINK A...................
86-CT9-213-010 SPR-C,BATT(-) A...................
86-CT9-219-110 OIL-DMPR,GEAR A...................
86-CT9-220-110 OIL-DMPR,BRACKET A...................
86-CT9-222-010 PLATE,MAGNET A...................
86-CT9-223-010 CUSH,FOOT A...................
87-036-368-010 0E MAGNET A...................
8Z-CT6-202-010 BTN,FUNC BASE A...................
8Z-CT6-203-010 BTN,GEQ BASE A...................
8Z-CT6-204-010 BTN,CD BASE A...................
8Z-CT6-207-010 SPR-P,REC A...................
8Z-CT6-208-010 HLDR,KEY A...................
8Z-CT6-213-010 BASE,CHUCK A...................
8Z-CT6-214-010 RING,CHUCK A...................
8Z-CT7-201-010 LEVER,BAND A...................
8Z-CT7-203-010 CAP,BAND SW A...................
8Z-CT7-204-010 DRUM,TU A...................
8Z-CT7-206-010 SPR-P,BAND A...................
81-CD5-204-010 0E SCREW CD A...................
87-067-520-010 0E TAPPING SCREW, VFTT+2-6 A...................
87-493-100-410 0E VWWS+3-16 BLK A...................
87-571-033-410 0E TAPPING SCREW, VIT+2-4 A...................
87-651-073-410 0E VT1+2.6-6 A...................
87-651-075-210 0E VT1+2.6-10 A...................
87-651-104-410 0E VT1+3-30 A...................
87-751-097-410 0E SCREW 3X12 A...................
87-A90-086-010 0E COVER,AC-SOCKET A...................
88-CT6-606-010 FFC WIRE 16P(1.0 ) A...................
ANT 0 88-CT6-633-010 ANT,ROD A...................
CN 0 88-CT6-605-010 CONN ASSY,5P RPH A...................
CN 0 88-CT6-608-010 CONN ASSY,8P MO A...................
F 901 87-035-139-010 0E FUSE, 2.5A T 250V A...................
J 0 87-A60-178-010 JACK,AC E W/SW A...................
PT 901 88-CT6-631-010 POWER TRANS,EI-57/25 A...................
86-CT9-040-010 BADGE,AIWA - A...................
87-CT7-154-010 CAP,SPKR A...................
8Z-CT6-044-010 GRILLE,SPKR A...................
8Z-CT6-101-010 CABI,SPKR FR A...................
8Z-CT6-102-010 CABI,SPKR REAR R A...................
8Z-CT6-103-010 CABI,SPKR REAR L A...................
87-651-100-410 0E VT1+3-16 A...................
88-CT6-627-010 SPEAKER,5’4OHM 5W A...................
88-CT6-628-010 PIEZO TWEETWR 27MM A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
MECHANICAL PARTS LIST-2/2
88-CT6-632-010 TERMINAL,ASSY MECHA 1P A...................
8Z-CT6-201-010 HLDR,LCD A...................
8Z-CT6-205-010 HLDR,LED FUNC A...................
8Z-CT7-202-010 HLDR,LED GEQ A...................
88-CT6-624-010 SPR,BATT A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ACCESSORIES / PACKAGE LIST-1/1
NOTE: The characters in the suffix column indicate the part usage.
LHSCC ..................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-CT7-906-010 IB,LH(ESP)FM A...................
8Z-CT7-907-010 IB,HE(ECA)FM ....................
87-050-076-010 1C AC CORD SET ASSY,E A...................
87-A90-312-010 PLUG,CONVERSION WTN-1157R1 A...................
8Z-CK4-952-010 1F RC UNIT,RC-ZAT04 A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
Other Aiwa Stereo System manuals
