Akai ACR-220MMU User manual
0
CC0R10215540-00-00 PCS 6.00CHIP CAP 0603 102P NPO 50V +/-5% C54.56.117.131.132.194
CC0R10310540-00-00 PCS 10.00CHIP CAP 0603 103P 50V X7R +/-10% C72.116.181.185.211.209.203.60.61.2
17
CC0R10410540-00-00 PCS 54.00CHIP CAP 0603 104P 25V X7R +/-10% C94.58.67.53.82.80.136.128.76.55.18
4.189.190.177.206.178.195
CC0R10510540-00-00 PCS 26.00CHIP CAP 0603 1UF X7R 16V +/-10% C10-13.84.47.30.23.28.25.64.65.87-90
.46.6.7.16.17.21.22.14(C
CC0R10650110-00-00 PCS 1.00TANTALUM CAP 1206 (SIEZE A) 10UF 10V +/-20% RJ1
CC0R12010540-00-00 PCS 1.00CHIP CAP 0603 12P NPO 50V +/-5% C77
CC0R12210540-00-00 PCS 3.00CHIP CAP 0603 122P X7R 50V +/-10% C172.173.174
CC0R15210540-00-00 PCS 4.00CHIP CAP 0603 152P 50V X7R +/-10% C151.150.199.C208
CC0R15310540-00-00 PCS 3.00CHIP CAP 0603 153P 50V X7R +/-10% C63.62.207
CC0R22015540-00-00 PCS 2.00CHIP CAP 0603 22P NPO 50V +/-5% C212.113
CC0R22210540-00-00 PCS 1.00CHIP CAP 0603 222P 50V X7R +/-10% C187
CC0R22310540-00-00 PCS 0.00CHIP CAP 0603 223P X7R 50V +/-10% (C36.C35.C38 WOOF )0
CC0R22410540-00-00 PCS 1.00CHIP CAP 0603 224P 50V X7R +/-10% C138
CC0R27210540-00-00 PCS 2.00CHIP CAP 0603 272P X7R 50V +/-10% C44.45
CC0R30010540-00-00 PCS 3.00CHIP CAP 0603 30P NPO 50V +/-5% C114.170.171
CC0R30810540-00-00 PCS 1.00CHIP CAP 0603 3P NPO 50V +/-5% C201
CC0R33310540-00-00 PCS 2.00CHIP CAP 0603 333P 25V X7R +/-10% C191.149
CC0R39010540-00-00 PCS 1.00CHIP CAP 0603 39P NPO 50V +/-5% C111
CC0R39115540-00-00 PCS 1.00CHIP CAP 0603 391P NPO 50V +/-5% C188
CC0R47110540-00-00 PCS 4.00CHIP CAP 0603 471P NPO 50V +/-5% C5.8.15.18
CC0R47310540-00-00 PCS 1.00CHIP CAP 0603 473P X7R 25V +/-10% C83
CC0R47410540-00-00 PCS 4.00CHIP CAP 0603 474P 25V X7R +/-10% C68.112.81.148
CC0R50810540-00-00 PCS 1.00CHIP CAP 0603 5P NPO 50V +/-5% C198
CC0R56110540-00-00 PCS 2.00CHIP CAP 0603 561P X7R 50V +/-10% C95.109
CC0R68210540-00-00 PCS 1.00CHIP CAP 0603 682P X7R 50V +/-10% C200
CC0R68310540-00-00 PCS 1.00CHIP CAP 0603 683P 25V X7R +/-10% C183
Part Code Name/Description Unit Qty Location
CC0R82115540-00-00 PCS 1.00CHIP CAP 0603 821P NPO 50V +/-5% C145
CF0R11200301-01-00 PCS 1.00CRYSTAL 12.0MHZ/20PF/30PPM 2LEG 49S XT4
CF0R11693401-00-01 PCS 1.00X-TAL 16.9344MHZ 2LEG ( )FG XT3
CF0R19000300-00-00 PCS 1.00CRYSTAL 49-S 9.0MHZ 2LEG 20PF XT1
CH0R01248001-01-00 PCS 1.00CHIP INDUCTOR COIL (0805) 2.4UH +/-10% L14
CH0R01338001-00-00 PCS 1.00CHIP INDUCTOR COLL 321611(1206) 3.3UH +/-10% L2
CH0R04310000-00-00 PCS 1.00CHIP FERRITE BEED 1206 FB-310 L11
CH0R09100000-00-00 PCS 8.00CHIP INDUCTANCE 1206 10UH+\-10% L3-7.9.10.13
CH0R09100000-01-00 PCS 1.00CHIP INDUCTANCE 0805 10UH+\-10% L12
CH0R09220000-00-00 PCS 1.00CHIP INDUCTANCE 1206 22UH +/-10% L8
CR0R00050410-00-00 PCS 6.00CHIP RESISTOR 0603 0 OHM 1/10W 50V +/-5% R142.143.293.294(R53.RJ2
WOOF ;R313.3140
CR0R00051210-00-00 PCS 2.00CHIP RESISTOR 0805 0 1/8W 100V +/-5% ( CU5010-U2 2PCS)0 "LMN
CR0R00051510-00-00 PCS 2.00CHIP RESISTOR 1206 0 OHM 1/4W 200V +/-5% (D13.14 AUX )0
CR0R10050410-00-00 PCS 3.00CHIP RESISTOR 0603 10 OHM 1/10W 50V +/-5% R212.211.260
CR0R10051000-00-00 PCS 1.00RESISTOR 10 OHM 1/4W +/-5% R155
CR0R10150410-00-00 PCS 7.00CHIP RESISTOR 0603 100 OHM 1/10W 50V +/-5% R78.57.58.202.195.201.218
CR0R10151000-00-00 PCS 2.00RESISTOR 100 OHM 1/4W +/-5% R88.111
CR0R10250410-00-00 PCS 37.00CHIP RESISTOR 0603 1K OHM 1/10W 50V +/-5% R61.82.63.75.109.76.86.72.102.292.7
4.234.235.281.191.192.180
CR0R10350410-00-00 PCS 27.00CHIP RESISTOR 0603 10K OHM 1/10W 50V +/-5% R60.309.230.258.245.246.301.161.31
1.77.14-17.289.156.95.286.
CR0R10450410-00-00 PCS 13.00CHIP RESISTOR 0603 100K OHM 1/10W 50V +/-5% R271.310.9.100.101.232.233.94.159.2
55.134.71.253(R49.50.51.5
CR0R10550410-00-00 PCS 7.00CHIP RESISTOR 0603 1M OHM 1/10W 50V +/-5% R228.62.8.7.6.236.279
CR0R12250410-00-00 PCS 4.00CHIP RESISTOR 0603 1K2 OHM 1/10W 50V +/-5% R240.242.244.237
CR0R12350410-00-00 PCS 2.00CHIP RESISTOR 0603 12K OHM 1/10W 50V +/-5% R68.69
CR0R12450410-00-00 PCS 2.00CHIP RESISTOR 0603 120K OHM 1/10W 50V +/-5% R250.R254
CR0R15250410-00-00 PCS 1.00CHIP RESISTOR 0603 1K5 OHM 1/10W 50V +/-5% R92
CR0R15350410-00-00 PCS 6.00CHIP RESISTOR 0603 15K OHM 1/10W 50V +/-5% R197.198.166.R126.R127.R249(R126.
127
Part Code Name/Description Unit Qty Location
CR0R18350410-00-00 PCS 5.00CHIP RESISTOR 0603 18K OHM 1/10W 50V +/-5% R30.25.35.291.20
CR0R20350410-00-00 PCS 1.00CHIP RESISTOR 0603 20K OHM 1/10W 50V +/-5% R312
CR0R22050410-00-00 PCS 15.00CHIP RESISTOR 0603 22 OHM 1/10W 50V +/-5% R203-206.196.217.219.220-227
CR0R22051000-00-00 PCS 1.00RESISTOR 22 OHM 1/4W +/-5% R190
CR0R22250410-00-00 PCS 23.00CHIP RESISTOR 0603 2K2 OHM 1/10W 50V +/-5% R65.66.67.73.85.139.1.241.216.300.3
02-306.208.209.299.174.29
CR0R22350410-00-00 PCS 18.00CHIP RESISTOR 0603 22K OHM 1/10W 50V +/-5% R168.214.173.27.26.29.28.18.19.229.
147.148.87.(R261 96789
CR0R22450410-00-00 PCS 4.00CHIP RESISTOR 0603 220K OHM 1/10W 50V +/-5% R215.238.252.138
CR0R22850410-00-00 PCS 1.00CHIP RESISTOR 0603 2.2 OHM 1/10W 50V +/-5% R110
CR0R27250410-00-00 PCS 1.00CHIP RESISTOR 0603 2K7 OHM 1/10W 50V +/-5% R270
CR0R27450410-00-00 PCS 2.00CHIP RESISTOR 0603 270K OHM 1/10W 50V +/-5% R262.R266
CR0R30350410-00-00 PCS 2.00CHIP RESISTOR 0603 30K OHM 1/10W 50V +/-5% R186.251
CR0R33150410-00-00 PCS 0.00CHIP RESISTOR 0603 331 OHM 1/10W 50V +/-5% 1(R48 WOOF )0
CR0R33250410-00-00 PCS 2.00CHIP RESISTOR 0603 3K3 OHM 1/10W 50V +/-5% R179.R307
CR0R33450410-00-00 PCS 1.00CHIP RESISTOR 0603 330K OHM 1/10W 50V +/-5% R149
CR0R33851000-00-00 PCS 1.00RESISTOR 3.3 OHM 1/4W +/-5% R90
CR0R33852000-00-00 PCS 1.00RESISTOR 3.3 OHM 1/2W +/-5% R54
CR0R39050410-00-00 PCS 2.00CHIP RESISTOR 0603 39 OHM 1/10W 50V +/-5% R199.200
CR0R39350410-00-00 PCS 1.00CHIP RESISTOR 0603 39K OHM 1/10W 50V +/-5% R91(R40.43 WOOF )0
CR0R47150410-00-00 PCS 4.00CHIP RESISTOR 0603 471 OHM 1/10W 50V +/-5% R84.89.162.79
CR0R47250410-00-00 PCS 7.00CHIP RESISTOR 0603 4K7 OHM 1/10W 50V +/-5% R99.93.272.154.153.151.280
CR0R47350410-00-00 PCS 14.00CHIP RESISTOR 0603 47K OHM 1/10W 50V +/-5% R213.163.170.169.133.268.269.23.22.
32.33.283.248.256(R38.42.
CR0R47450410-00-00 PCS 1.00CHIP RESISTOR 0603 470K OHM 1/10W 50V +/-5% R284
CR0R47550410-00-00 PCS 1.00CHIP RESESTOR 0603 4M7 OHM 1/10W 50V +/-5% R106
CR0R56150410-00-00 PCS 1.00CHIP RESISTOR 0603 561 OHM 1/10W 50V +/-5% R160
CR0R56250410-00-00 PCS 7.00CHIP RESISTOR 0603 5K6 OHM 1/10W 50V +/-5% R231.55.56.288.259(R124.125
AUX )0
CR0R56450410-00-00 PCS 2.00CHIP RESESTOR 0603 560K OHM 1/10W 50V +/-5% R98.285
Part Code Name/Description Unit Qty Location
CR0R68150410-00-00 PCS 1.00CHIP RESISTOR 0603 681 OHM 1/10W 50V +/-5% R193
CR0R68250410-00-00 PCS 7.00CHIP RESISTOR 0603 6K8 OHM 1/10W 50V +/-5% R21.31.24.34.97.273.276(R41.45
WOOF )0
CR0R68350410-00-00 PCS 4.00CHIP RESISTOR 0603 68K OHM 1/10W 50V +/-5% R263.264.265.267
CR0R82250410-00-00 PCS 4.00CHIP RESISTOR 0603 8K2 OHM 1/10W 50V +/-5% R4.5.10.11
CR0R82350410-00-00 PCS 3.00CHIP RESISTOR 0603 82K OHM 1/10W 50V +/-5% R177.70.R247
CR0R82450410-00-00 PCS 1.00CHIP RESESTOR 0603 820K OHM 1/10W 50V +/-5% R64
DI0R14007020-00-00 PCS 3.00RECTIFIER SILICON FOR 1N4007 D25.D2.D51
DI0R24148080-00-00 PCS 29.00SIGNAL DIODE 1N4148 (1206) SMD (LL34) D4.5.6.7.15.16.17.18.21.22.26.27.28.2
9.48.49.50.37.42.33.43.
DI0R30602081-00-00 PCS 1.00CHIP ZENER SILICON 1206 6V2 1/2W SMD +/-2% ZD2
DI0R30901080-00-00 PCS 2.00ZENER SILICON 9V1 1/2W (1206) SMD +/-2% ZD1.4
DI0R31005080-00-00 PCS 1.00ZENER SILICON 10V 1206 1/2W SMD +/-2% ZD5
EC0R10509051-01-00 PCS 1.001UF 50V +/-10% -40+105 (4X7MM) I=0.004CV OR 0.4(VC115(C39 WOOF )0
EC0R10609031-01-00 PCS 5.0010UF 25V +/-10% -40+105 4X7MM I=0.004CV or 0.4(VC153.155.20.182.215(C40.41.98WOO
F)0
EC0R10704020-01-00 PCS 3.00100UF 16V+/-20% -40+105 (5X11MM) I=0.004CV or 0.VC70.126.129
EC0R10709011-01-00 PCS 19.00100UF 10V +/-20% -40+105 (5X7MM) I=0.004CV or 0.VC142.140.146.161.163.165.159.214.1
34.225.43.26.29.24.27.71.7
EC0R22509051-01-00 PCS 0.002.2UF 50V +/-10% -40+105 4X7MM I=0.004CV or 0.4V(C42 WOOF )0
EC0R22604031-00-00 PCS 3.0022UF 25V +/-20% -40+105 4X7MM I=0.004CV or 0.4VC33.1.3
EC0R22704009-00-00 PCS 2.00220UF 6.3V +/-10% 6X5MM -40+105VC179.204
EC0R22704010-01-00 PCS 1.00220UF 10V +/-20% -40+105 6X12MMVC78
EC0R33809020-01-00 PCS 1.003300UF 16V +/-20% -40+105 (13X22MM) I=0.004CV orVC2
EC0R47409051-01-00 PCS 1.000.47UF 50V +/-10% -40+105 4X7MM I=0.004CV or 0.VC73
EC0R47509051-01-00 PCS 4.004U7 50V +/-10% 40+105 4X7MM I=0.004CV or 0.4( uVC157.156.197.19
EC0R47604011-01-00 PCS 8.0047UF 10V +/-20% 4X7MM -40+105VC175.93.205.59.57.210.91.97
FS0R01000050-00-01 PCS 1.00FUSE VALUE 0.5A (6X30)MM
IC0R11117000-00-00 PCS 1.00IC AMS1117-3.3 SOT-223 3PIN IC16
IC0R11117000-00-03 PCS 1.00IC AMS1117-1.2V SOT-223 3PIN IC19
Part Code Name/Description Unit Qty Location
IC0R17805500-00-00 PCS 1.00IC 78L05J TO-92 3PIN IC7
IC0R17805802-00-00 PCS 1.00IC KA78R05 TO220F-4L 4PIN 1A IC6
IC0R17808802-00-00 PCS 1.00IC KA78R08 TO220F-4L 4PIN IC8
IC0R30831703-02-00
(CD+ESP+MP3+RDS+USB/FLASH)
PCS 1.00
A
UTO__831UR 100PIN QFP(CPU) YELLEOW IC4
IC0R34001000-00-00 PCS 1.00IC IP4001D SOP-28 IC13
IC0R34558300-00-00 PCS 2.00IC YM4558M SO-8PIN IC9.10(IC2 WOOF )0
IC0R35101700-00-00 PCS 1.00IC TMC51F01M TQFP48 IC17
IC0R37032500-00-00 PCS 1.00IC RESET KIA-7032P TO-92 IC5
IC0R37313300-00-00 PCS 1.00IC TDA7313D SOP 28PIN IC1
IC0R37388800-00-00 PCS 1.00IC TDA7388 FIEXIWATTIS 25PIN IC11
IC0R38310300-00-00 PCS 1.00IC S5L8310X 100-TQFP-1414 IC18
IC0R91922700-00-00 PCS 1.00IC S1L9226 TQFP48 IC12
IC0R95716300-00-00 PCS 1.00IC SDRAM UT57L1616MC,16M,TSOP 50PIN IC14
LE0R12035420-00-00 PCS 1.00LED ROUND 3MM (RED) LEG.L=30MM D3
PB0-CU501075-00-U1
USB
PCS 0.00P.C.B CU5010-U1 51.5X39 SS HB TH=1.6MM 1 tu0
PB0-CU501075-00-U2
USB ( MMC )
PCS 1.00P.C.B CU5010-U2 52.0X39.4 SS HB TH=1.6MM
PB0-CU501075-00-U3
USB ( MMC )
PCS 0.00P.C.B CU5010-U3 52.0X39.4 SS HB TH=1.6MM 1 tu0
PB0RCU507175-01-A1 PCS 1.00P.C.B CU5071-A1 172+10X159.60MM FR4 HB TH=1.6MM
SK0R02030010-00-00 PCS 1.00D TYPE CONNECTOR MALE 3P NONE WIRE PH=2.54MM CN12
SK0R02100020-00-02 PCS 1.00D TYPE CONNECTOR MALE 10P NONE WIRE PH=2.0MM CN11
SK0R06080000-00-00 PCS 1.00CONNECTOR 8P PH=2.54MM 90! 7.17X3.6MM CN13
SK0R14180000-00-04 PCS 1.0018PIN CONNECTOR FEMALE 2.5mm z CN5
SK0R15161110-00-00 PCS 1.00CONNECT SOCKET 1.0-11S-16PW PH=1.0MM CN6
SK0R28000000-00-00
USB
PCS 1.00USB SOCKET SERIES CN14
SK0R29412000-00-00
MMC ( CU5010-U2 )
PCS 1.00MMC SOCKET 412D06-09PCSA13
SW0R10040501-01-00 PCS 1.00TACT SWITCH 4P L=5MM SW3
Part Code Name/Description Unit Qty Location
SW0R50020200-00-00 PCS 0.00DIP SWITCH DC 6P 1 SW
TR0R10435000-00-00 PCS 1.00TRANSISTOR BD435 NPN TO-126ML Q30
TR0R18050002-00-00 PCS 1.00TRANSISTOR C8050C NPN TO-92 Q16
TR0R20772000-00-00 PCS 1.00TRANSISTOR KSB772-Y PNP TO-126ML Q18
TR0R61015806-00-00 PCS 11.00CHIP TRANSISTOR HMBT1015 SOT-23 PNP (M6) Q9.36.39.37.38.10.32.35.34.26.42(Q2
5
TR0R61815824-00-00 PCS 17.00CHIP TRANSISTOR HMBT1815 SOT-23 NPN (L6) Q6.12.13.14.7.11.33.40.29.28.8.19.1.3
1.17.15.27(Q20.21.41
TR0R68050002-00-00 PCS 4.00CHIP TRANSISTOR ZX8050 SOT-23 NPN Q2-5
TU0R50070200-00-00
A
M/FM (FM64-108MHZ
)
647
PCS 1.00
A
M/FM TUNER OIRT 7020 (OIRT VERSION)
:89 138
Part Code Name/Description Unit Qty Location
CR0R00051210-00-00 PCS 3.00CHIP RESISTOR 0805 0 1/8W 100V +/-5% J1.2.3
CR0R22150000-00-00 PCS 2.00RESISTOR 221 OHM 1/8W +/-5% R3.4
CR0R82050000-00-00 PCS 1.00RESISTOR 82 OHM 1/8W +/-5% J4
DI0R80023000-00-00 PCS 2.00DIODE-IR EMITTING 4X4MM ST-23G D103.104
DK0R30300007-00-00 PCS 1.00CD DECK SCD-300( C20 )`A q7
FC0R41609043-00-00 PCS 1.00FLAT CABLE 16P L=90MM PH=1.0MM g7D
IM0-12010011-00-00
DEF
G 1.10 04 SMT:0.55G;05 SMT:0.55G""
IM0-17000000-00-00 G 4.00SOLDERING WIRE D=1.0MM 1H04 FC:2G;05 FC:2G""
IM0R21120010-00-00
1/2IJCK
M 6.00TAPE ADHESIVE 1/2 04 FC:3CM;05 FC:3CM""
PB0R96000400-25-04 PCS 1.00P.C.B AS-9600-04 44X91.5MM SS HB TH=1.2MM
PB0R96000400-25-05 PCS 1.00P.C.B AS-9600-05 74X35MM SS HB TH=1.2MM
SK0R02040020-00-02 PCS 1.00D TYPE CONNECTOR WAFER 4PIN PH=2.0MM CON103
SK0R15170001-00-00 PCS 1.00CONNECT SOCKET 17P PH=1.0MM
SW0R10001110-00-00
PCS 1.00SWITCH-TACT (CHECK S/W SW-111) SW2
TB0R01010000-00-00
UVWXC S
CM 16.00PVC TUBE D=1MM 04 FC:8CM;05 FC:8CM""
:89 15
Part Code Name/Description Unit Qty Location
CC0R10115500-00-00 PCS 2.00CHIP CAP 0805 =0.8MM 101P NPO 50V +/-5%ZC6.C7
CC0R10215500-00-00 PCS 1.00CHIP CAP 0805 =0.8MM 102P X7R 50V +/-10%ZC1
CC0R10415500-00-00 PCS 3.00CHIP CAP 0805 =1.25MM 104P X7R 50V +/-10%ZC2.C3.C4
CC0R10510300-00-00 PCS 0.00CHIP CAP 0805 =1.25MM 1UF X7R 25V +/-10%ZC5( Y )NL0
CR0R00051210-00-00 PCS 2.00CHIP RESISTOR 0805 0 1/8W 100V +/-5% RJ1.RJ2
CR0R10050210-00-00 PCS 1.00CHIP RESISTOR 0805 10 1/8W 100V +/-5% R4
CR0R10150210-00-00 PCS 0.00CHIP RESISTOR 0805 101 OHM 1/8W 100V +/-5% R1( Y )NL0
CR0R10250210-00-00 PCS 11.00CHIP RESISTOR 0805 1K OHM 1/8W 100V +/-5% R11.R12.R13.R14.R15.R16.R22.R33.
R52.R48.R54
CR0R15250210-00-00 PCS 3.00CHIP RESISTOR 0805 1K5 OHM 1/8W 100V +/-5% R21.R32.R43
CR0R18150210-00-00 PCS 2.00CHIP RESISTOR 0805 181 OHM 1/8W 100V +/-5% R27.R38
CR0R22150210-00-00 PCS 2.00CHIP RESISTOR 0805 221 OHM 1/8W 100V +/- 5% R26.R37
CR0R22250210-00-00 PCS 4.00CHIP RESISTOR 0805 2K2 OHM 1/8W 100V +/-5% R20.R31.R39.R42
CR0R33150210-00-00 PCS 2.00CHIP RESISTOR 0805 331 OHM 1/8W 100V +/-5% R24.R36
CR0R33250210-00-00 PCS 2.00CHIP RESISTOR 0805 3K3 OHM 1/8W 100V +/-5% R19.R30
CR0R47150210-00-00 PCS 2.00CHIP RESISTOR 0805 471 OHM 1/8W 100V +/-5% R25.R35
CR0R47250210-00-00 PCS 9.00CHIP RESISTOR 0805 4K7 OHM 1/8W 100V +/-5% R2.R3.R5.R7.R8.R9.R10.R18.R29
CR0R47350210-00-00 PCS 2.00CHIP RESISTOR 0805 47K OHM 1/8W 100V +/-5% R6.R44
CR0R68150210-00-00 PCS 3.00CHIP RESISTOR 0805 681 OHM 1/8W 100V +/-5% R23.R34.R53
CR0R82150210-00-00 PCS 3.00CHIP RESISTOR 0805 821 OHM 1/8W 100V +/-5% R49.R50.R51
CR0R82250210-00-00 PCS 2.00CHIP RESISTOR 0805 8K2 OHM 1/8W 100V +/-5% R17.R28
CR0R82350210-00-00 PCS 1.00CHIP RESISTOR 0805 82K OHM 1/8W 100V +/-5% R45
DI0R24148080-00-00 PCS 6.00SIGNAL DIODE 1N4148 (1206) SMD (LL34) D1.D2.D3.D4.D5.D6
IC0R36523701-00-00 PCS 1.00IC PT6523 LQFP64 10X10mm IC1
LD0R0CU50206-02-00 PCS 1.00BLACK MASK DISPLAY CU5020 80X21MM 55PIN
LE0R50080591-00-00 PCS 3.00CHIP ULTRA (WHITE) LED 0805 (17-21/W1D-ANPHY/3T*) LED1.LED2.LED3
LE0R56120680-00-00 PCS 22.00CHIP LED (ORANGE) 0805 (HT-170D) LD1.LD2.LD3.LD4.LD5.LD6.LD7.LD8.
LD9.LD10 LD11.LD12.
Part Code Name/Description Unit Qty Location
PB0RCI507474-00-H1 PCS 1.00P.C.B CI5074-H1 14X11.6MM FR4 HB TH=1.2MM
PB0RCU507375-07-D1 PCS 1.00P.C.B CU5073-D1 143.8X41.5MM FR4.HB TH=1.6MM
SK0R05000000-01-00 PCS 1.00
A
UDIO INPUT CONNECT SOCKET
SK0R13180000-00-04
PCS 1.0018PIN CONNECTOR MALE HFS 2.5MM z B
SW0R10020500-00-00 PCS 2.00TACT SWITCH 2PIN 5MM
SW0R10020501-00-00 PCS 17.00TACT SWITCH 2PIN 5MM SMD
VR0R80001150-00-00 PCS 1.00ENCODER VOLUME L=11.5MM EC110201MRB-HAE-020
ZE0R93CU5010-00-00 PCS 1.00ZEBRA CONNECTOR PINK COLOR 76X8.3X2.0MM
:89 34
Part Code Name/Description Unit Qty Location
Other Akai Car Receiver manuals
