Akai ACR-3193 User manual

INSTRUCTION MANUAL
CLOCK RADIO
MODEL: ACR-3193

MODEL NO:
POWER:
ACR-3193
AC: 220-240V ~50HZ 5W
DC: 9V
(1X9V BATTERY)
We declare that this product conforms to the following product legislation
in accordance with the following directive(s):
2004/108/EC
2011/65/EU
2009/125/EC
Electromagnetic Compatibility Directive.
Restriction of Hazardous Substances Directive.
Eco-Design of Energy Related Products.
2
DECLARATION OF CONFORMITY
TECHNICAL DATA

SAFETY INFORMATION
Important safety instructions –read carefully before use.
It is important that this instruction manual should be retained with the
appliance for future reference. These warnings have been provided in
the interest of safety. You MUST read them carefully before installation
or use.
WARNING
•
Check that the voltage of the main circuit corresponds with the
rating of the appliance before operating.
Please ensure that the appliance is used on a stable, level, and heat
resistant surface.
Do not immerse cords, plugs or any part of the appliance in water
or any other liquid.
Do not leave the appliance unattended while it is operating.
Closesupervision is necessarywhenanyappliance is usedby or
near children or pets.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
Switch off at the wall socket then remove the plug from the socket
when not in use or before cleaning.
If the supply cord or appliance is damaged, stop using the appliance
immediatelyandseekadvicefromthemanufactureror its service
agent or a similarly qualified person.
Do not let the cord hang over the edge of a table or counter or let it
come into contact with any hot surfaces.
•
•
•
•
•
•
•
•
•
•
4
IMPORTANT INFORMATION–RETAIN FOR FUTURE USE

•
The use of accessory attachments is not recommended by the
appliance manufacturer, apart from those supplied with this
product.
Do not pull the plug out by the cord as this may damage the plug
and/orthecable.
Do not use this productfor anythingotherthanits intendeduse.
This appliance is for household use only.
Do not carry the appliance by the power cord.
Do not use the appliance outdoors.
Do not place anything containing liquid on top of the unit
Do not spill liquid onto the appliance. If this happens, mop up the
liquid and seek advice from a qualified technician.
Do not use next to a swimming pool.
Do not put objects into any of the openings.
Keep the unit free from dust, lint etc.
Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
Only use attachments/accessories specified by the manufacturer
Unplug this apparatus during lightning storms or when unused for
long periods of time.
Please ensure that the appliance has adequate ventilation
Battery shall not be exposed to excessive heat such as sunshine,
fire or the like.
Caution marking is located at the bottom of apparatus.
Do not play music at excessive level especially near children.
Ensure the battery compartments are secure.
Only use the batteries recommended.
Ensure correct fit of batteries, observing the plus and minus marks
on both the battery and the compartment.
Replace a full set of batteries at one time.
Store unused batteries in their packaging and keep away from
metal objects that may cause a short circuit.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
5

•
•
Remove dead batteries from equipment.
Remove batteries from equipment,if it is not to be used for a long
time.
Remember to keep button cell and AAA batteries away from
children as they can easily be swallowed.
Seek medical attention immediately if batteries are swallowed.
Never dispose of batteries in a fire.
Never attempt to recharge ordinary batteries.
•
•
•
•
6
IMPORTANT INFORMATION- RETAINFOR FUTURE USE
DISPOSAL OF WASTE ELECTRICAL AND ELECTRONIC
EQUIPMENT
This symbol on the product or packaging means that the product
should not be treated as household waste. Do not throw garbage at
the end of its life, but take it to a collection center for recycling. In
this way you will help to protect the environment and be able to
prevent any negative consequences that would have on the
environment and human health.
To find your nearest collection center:
- Contact local authorities;
- Access the website: www.mmediu.ro ;
- Request additional information from the store where you purchased
the product.

1.
2.
3.
INSTRUCTIONMANUAL
CLOCK RADIO
POWER CABLE
2
3
4
5
6 7
PART IDENTIFICATION
1.
2.
3.
4.
5.
6.
7.
8.
9.
ON/OFF/AM/FM
TU-/HOUR
TU+/MIN
BATTERYCOMPARTMENT
SLEEP / SNOOZE
AL1/VOL-
AL2/VOL+
SPEAKER
SET/PRE/M+
1
8
9
8
10
10. LED DISPLAY
FEATURES AND CONTROLS
PACKAGE CONTENTS
7

AC POWER SUPPLY
1.
Plug in the AC cord into the power socket, connect the AC power
cord to your AC household mains outlet. Make sure the voltage is
compatible.
Disconnect the power cord from the mains when not in use.
Mains plug is used as the disconnect device. It shall remain
readily operable and should not be obstructed during intended
use. To be completely disconnected the apparatus from supply
mains, the main plug of the apparatus shall be disconnected
from the mains socket outlet completely.
2.
3.
BATTERY OPERATION
1.
2.
3.
4.
The unit can also be operated by batteries during power failure.
Open the battery compartment, and install 1 x 9-Volt battery.
Remove battery from the unit if not be used for some time.
Flat batteries should be removed from the compartment avoid
leakage.
Batteries shall not be exposed to excessive heat such as
sunshine, fire or like.
5.
TIME SETTING
1.
Press and hold the time set/pre/m+, then the clock display will
blink.
Press the tu-/hour tu+/min or to set the hour and min of the
clock display respectively to the correct time.
Press set /pre/m+ again when finished the setting, the time
display will not blink.
2.
3.
RADIOOPERATION
1.
Press on/off/am/fm once, it will turn on the radio, press on/off/
am/fm again to select am band or fm band.
Press tu+/min or tu-/hour to adjust your desired frequency.
Press Al 2/vol + to increase the volume.
Press Al 1/vol- to decrease the volume.
2.
3.
8
USING YOUR APPLIANCE

MEMORY OPERATION
1.
2.
The clock radio can store 10am and 10fm presets.
On radio playing mode, select your desired band (fm/am), press
up tu+/min or tu-/hour to choose your desired frequency.
Long press set/pre/m+ to enter into preset mode, the preset
number will show and flash on the led display.
Short press tu-/hour or tu+/min to select your desired memory
numbers from p1 to p10.
Press the set/pre/m+ to confirm your memory setting.
Repeat the above steps, you can store your desired stations.
After setting is ok, press set/pre/m+ to select your preset
frequency to enjoy radio broadcasting.
Long press on/off/am/fm button to turn off the radio.
3.
4.
5.
6.
7.
8.
ALARM FUNCTION
SETTING ALARM 1or 2 BY BUZZER
1.
In clock display mode, press Al 1 or 2/vol- button once to select
alarm by buzzer.
The “buzzer Al1” icon light up and alarm time display will flash.
Using tu-/hour button and tu+/min button to set your desired
alarm hour.
2.
3.
SETTING ALARM 1 or 2 BY RADIO
1.
In clock display mode, press al 1 or 2/vol- button twice to select
alarm by radio.
The “radio Al1” icon light up and alarm time display will flash.
Using tu-/hour button and tu+/min button to set your desired
alarm hour.
2.
3.
SLEEPFUNCTION
1. If you want to listen to the radio while you fall asleep. You can use
sleep function by setting the sleep time.
2. With the radio on, press the sleep / snooze button to enter
into sleep mode, the 90 no. Shows on the led display. It states
90-minutes of sleep time and to be setted in sequence 90-80-70-
60-50-40-30-20-10-off.
9

3. Press the sleep / snooze button to choose your desired sleep
time, the sleep timer will change by 10 minutes each time you
press the sleep button.
4. The unit will stop playing when the timer countdowns from the
preset sleep time to the end and then switch off by itself.
SNOOZE FUNCTION
1.
On alarm sound mode, press on/off/am/fm to stop the alarm, the
alarm will not resume.
But if you press the sleep/snooze button to stop the alarm.
The Al icon of the led display will blink, and the alarm will
resume after 9 minutes.
2.
3.
BATTERY BACKUP
This clock has a backup power system to ensure continuous
operation during power failure. Insert one 9-volt battery and the
clock mechanism will continue to maintain the current time and
alarm program.
DRIPPING & VENTILATION WARNING
The product shall not be exposed to dripping or splashing and that
no objects filled with liquids, such as vases, shall be placed on the
product. The normal ventilation of the product shall not be impeded
for intended use.
I MPORTANT: Ensure that the unit has been disconnected from the
mains electricity supply before cleaning.
Use a soft slightly moistened with a mild detergent solution. Do not
use a solution containing alcohol, spirits, ammonia or abrasives.
10
CLEANING & MAINTENANCE
