Confidential Akai Service Manual
AKAI
MPK mini
[AD07]
Service Manual
RevA
2011.07.08
The information in this document contains privileged and confidential information. It is intended
only for the use of those authorized by Akai Professional. If you are not the authorized, intended
recipient, you are hereby notified that any review, dissemination, distribution or duplication of this
document is strictly prohibited. If you are not authorized, please contact Akai Professional and
destroy all copies of this document. You may contact Akai Professional at
[email protected].
Copyright Akai Professional
ATTENTION!
THIS DOCUMENT CONTAINS SENSITIVE
PROPRIETARY INFORMATION.
ALL RECIPIENTS MUST HAVE A CURRENT
NON-DISCLOSURE AGREEMENT ON FILE
WITH AKAI PROFESSIONAL.
DO NOT MAKE ILLEGAL
COPIES OF THIS DOCUMENT

Confidential Akai Service Manual
PREFACE
This document is intended to assist the service technician in the operation, maintenance and
repair of the Akai device. Together with the User Reference Manual, this document provides a
complete description of the functionality and serviceability of the Device. Any comments or
suggestions you may have pertaining to the document are welcome and encouraged.
READ THIS!
In addition to any purchase price that Akai may charge as consideration for Akai selling or
otherwise transferring this service manual (“Manual”) to you, if you are not a service and repair
facility (“Service Center”) authorized by Akai in writing to be an authorized Service Center, Akai
sells or transfers the Manual to you on the following terms and conditions:
Only Service Centers authorized by Akai in writing are authorized to perform service and repairs
covered by an Akai warranty (if any), and transfer of the Manual to you does not authorize you to
be an authorized Service Center. Therefore, if you perform, or if the Manual is used to
perform, any service or repairs on any Akai product or part thereof, any and all warranties
of Akai as to that product and any service contract with Akai for that product shall be
voided and shall no longer apply for such product, even if your services or repairs were
done in accordance with the Manual.
All service or repairs done by you or with reference to the Manual shall be solely your
responsibility, and Akai shall have no liability for any such repairs or service work. All such
service or repairs are performed at the sole risk of the person performing the service or
repairs. You agree that all such work will be performed in a competent, professional and safe
manner at all times and to indemnify and fully hold Akai and its successors and assigns harmless
in the event of any failure to so perform.
Your purchase of the Manual shall be for your own ultimate use and shall not be for purposes of
resale or other transfer.
As the owner of the copyright to the Manual, Akai does not give you the right to copy the Manual,
and you agree not to copy the Manual without the written authorization of Akai. Akai has no
obligation to provide to you any correction of, or supplement to, the Manual, or any new or
superseding version thereof.
Akai shall have the right to refuse to sell or otherwise transfer repair parts or materials to you in
its sole discretion. You shall not use, sell or otherwise transfer spare or replacement parts
supplied by Akai to you (i) to repair or be used in products manufactured for or by third parties or
(ii) to any third parties for any purpose.
You shall not make any warranties or guarantees with respect to the products of Akai or the use
thereof on behalf of Akai or in your own name.
The foregoing describes the entire understanding related to sale or transfer of the Manual to you,
and no other terms shall apply unless in a writing signed by an authorized representative of Akai.
All Trademarks are property of their respective companies.

Confidential Akai Service Manual
WARNINGS
TO REDUCE THE RISK OF ELECTRIC SHOCK OR FIRE, DO NOT EXPOSE
THIS PRODUCT TO WATER OR MOISTURE.
The arrowhead symbol on a lightning flash inside a triangle is
intended to alert the user to the presence of uninsulated "dangerous
voltage" within the enclosed product which may be of sufficient
magnitude to constitute a risk of electric shock to persons.
The exclamation point inside a triangle is intended to alert the user
to the presence of important operating, maintenance and servicing
instructions in the literature which accompanies the product.
REPAIR BY ANY PERSON OR ENTITY OTHER THAN AN AUTHORIZED
AKAI SERVICE CENTER WILL VOID THE AKAI WARRANTY.
PROVISION OF THIS MANUAL DOES NOT AUTHORIZE THE RECIPIENT TO
COMPETE WITH ANY AKAI DISTRIBUTOR OR AUTHORIZED REPAIR
SERVICE CENTER IN THE PROVISION OF REPAIR SERVICES OR TO BE
OR MAKE REPAIRS AS AN AUTHORIZED SERVICE CENTER.
ALL REPAIRS DONE BY ANY ENTITY OTHER THAN AN AUTHORIZED AKAI
SERVICE CENTER SHALL BE SOLELY THE RESPONSIBILITY OF THAT
ENTITY, AND AKAI SHALL HAVE NO LIABILITY TO THAT ENTITY OR TO
ANY OTHER PARTY FOR ANY REPAIRS BY THAT ENTITY.
Regarding the Power Supply Fuse
CAUTION: The product under service may employ the use of a
replaceable fuse. Danger of fire or electrocution if fuse is incorrectly
replaced. Replace with only the same type or equivalent type
recommended by the equipment manufacturer.
Regarding the Internal Battery
CAUTION: The product under service may employ the use of a
internal battery. Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type
recommended by the manufacturer. Dispose of used batteries
according to the manufacturer's instruction.

Confidential Akai Service Manual
Safety Instructions
Carefully read the applicable items of the operating instructions and these safety suggestions
before using this product. Use extra care to follow the warnings written on the product itself and in
the operating instructions. Keep the operating instructions and safety suggestions for reference in
the future.
1. Power Source. The product should only be connected to a power supply which is described
either in the operating instructions or in markings on the product.
2. Power Cord Protection. AC power supply cords should be placed such that no one is likely to
step on the cords and such that nothing will be placed on or against them.
3. Periods of Non-use. If the product is not used for any significant period of time, the product's
AC power supply cord should be unplugged from the AC outlet.
4. Foreign Objects and Liquids. Take care not to allow liquids to spill or objects to fall into any
openings of the product.
5. Water or Moisture. The product should not be used near any water or in moisture.
6. Heat. Do not place the product near heat sources such as stoves, heat registers, radiators or
other heat producing equipment.
7. Ventilation. When installing the product, make sure that the product has adequate
ventilation. Improperly ventilating the product may cause overheating, which may damage the
product.
8. Mounting. The product should only be used with a rack which the manufacturer
recommends. The combination of the product and rack should be moved carefully. Quick
movements, excessive force or uneven surfaces may overturn the combination which may
damage the product and rack combination.
9. Cleaning. The product should only be cleaned as the manufacturer recommends.
10. Service. The user should only attempt the limited service or upkeep specifically described in
the operating instructions for the user. For any other service required, the product should be
taken to an authorized service center as described in the operating instructions.
11. Damage to the Product. Qualified service personnel should service the unit in certain
situations including without limitation when:
a. Liquid has spilled or objects have fallen into the product,
b. The product is exposed to water or excessive moisture,
c. The AC power supply plug or cord is damaged,
d. The product shows an inappropriate change in performance or does not operate
normally, or
e. The enclosure of the product has been damaged.

BOM for AD07
ITEM Level P/N Description Q'ty MOQ
1 1 105-AD07-90 SHIPPING ASSY AD07 "ROHS" 1.00
2 632100100 BATTRERY 7# 1.5V "ROHS" 0.00 30K
3 NEW P/N Out carton FOR AD03 "ROHS" 0.10 5K
4 NEW P/N PLASTIC TOP COVER PS 0.7MM 305*280*33 MM FOR AD03 "ROHS" 1.00 5K
6 NEW P/N GIFT CARTON 350G 4C UV 365*280*70 MM FOR AD03 "ROHS" 1.00 5K
7 042232000 INSTRUCTION FOR AD03 "ROHS" 1.00 5K
8 NEW P/N LABLE1 FOR AD03 "ROHS" 1.00
9 NEW P/N LABLE2 FOR AD03 "ROHS" 1.00
10 NEW P/N LABLE3 70*50MM FOR AD03 "ROHS" 1.00
11 052232000 CLAPBOARD FOR AD03 "ROHS" 1.00
12 NEW P/N CD FOR AD07 "ROHS" 1.00
13 061184000 CABLE USB W/FERRITE 1 METER L=1500mm BLACK "HONGYUN" USBAM-MINI5P "ROHS" 1.00
14 105-AD07-70 SUB FINAL ASSY AD07 "ROHS" 1.00
15 020185000 FABRIC GASKET W=7mm FOR AD02 "ROHS" 2.00
16 021184200 KNOB ROTARY ABS FOR AD01 "ROHS" 8.00
17 021184400 BUTTON SQUARE 8-KEY SILICON RUBBER FOR AD01 "ROHS" 1.00
18 021184500 HIGH-RESISTANCE CARBON FILM PVC FOR AD01 "ROHS" 1.00
19 021184600 FOOT RUBBER BLACK FOR AD01 "ROHS" 4.00
20 021184700 KEY STROKE SILICON RUBBER 13-KEY "ROHS" 1.00
21 021185400 KEY ABS AS 7-KEY WHITE FOR AD02 "ROHS" 2.00
22 021185500 KEY ABS AS 5-KEY BLACK FOR AD02 "ROHS" 2.00
23 021185600 REAR KEY WHITE ABS FOR AD02 "ROHS" 1.00
24 021185700 KEY STROKE SILICON RUBBER 12-KEY "ROHS" 1.00
25 021243000 TOP COVER ABS FOR AD07 "ROHS" 1.00
26 021243100 BOTTOM COVER ABS FOR AD07 "ROHS" 1.00
27 021243200 BUTTON SQUARE 10-KEY SILICON RUBBER FOR AD07 "ROHS" 1.00
28 030185000 SHEET BRACKET METAL SHEET "ROHS" 1.00
29 054185000 FOAM GASKET 294*11*2mm FOR AD02 "ROHS" 1.00
30 061243000 CABLE FFC P=1mm 16PIN L=200mm CONTACT ON DIFFRENT SIDE "BINGCHUANG" 1.0*16P*200mm*A "ROHS" 1.00 1000
31 105-AD03-64 PCB ASSY KEYBOARD FOR AD03 "ROHS" 1.00
32 105-AD03-54 PCB SMD ASSY KEYBOARD FOR AD03 "ROHS" 1.00
33 3 023232302 PCB CEM 1L 1.6mm 291x36mm REV.0.01 KEY "ROHS" 1.00 5k
34 112210000 RES SMD 0805 1/10W 1% 0R "TAD" CJ10-000F "ROHS" 6.00 5000
35 411024148 DIODE SMD SOD-80 MINIMELF 75V 150mA "GOOD-ARK" LL4148 "ROHS" 50.00 2500

36 711048401 CONNECTOR SMD 5943XXOHDOR-16P 16PIN P=1.0mm "MEILI" 1.0-16PX "ROHS" 1.00
37 105-AD07-61 PCB ASSY MAINBOARD FOR AD07 "ROHS" 1.00
38 105-AD07-51 PCB SMD ASSY MAIN FOR AD07 "ROHS" 1.00
39 023243005 PCB FR4 2L 300.5*76.5mm MAINBOARD V0.06 FOR AD07 "ROHS" 1.00
40 110008000 FERRITE BEAD SMD 1806 800R @100MHz 1A "FENGHUA" CBW451616U851 "ROHS" 1.00
41 113004602 FERRITE BEAD SMD 0603 4*600R 100MHz 300mA "FENG HUA" CBA321609-4U-601B "ROHS" 8.00 4000
42 113016000 FERRITE BEAD SMD 0603 600R GZ1608U601 "SUNLORD" "ROHS" 1.00 4000
43 113111002 RES SMD 0603 1/16W 1% 10K "ROHS" 2.00 5000
44 113131501 RES SMD 0603 1/16W 5% 1.5K "FENGHUA" "ROHS" 1.00 5000
45 113230220 RES SMD 0603 1/10W 5% 22R "ROHS" 2.00
46 133130472 RES NETWORK SMD 0603*4 4.7K 1/16W 5% "ROHS" 4.00 5000
47 134130470 RES NETWORK SMD 0603*4 1/16W 5% 47R "FENGHUA" "ROHS" 4.00 5000
48 134131002 RES NETWORK SMD 0603*4 1/16W 5% 10K "FENG HUA" "ROHS" 2.00 5000
49 134134104 RES NETWORK SMD 0603*4 1/16W 5% 100K "FENGHUA" "ROHS" 2.00 5000
50 210201106 CAP SMD ELEC 10UF 4*5.5mm 16V 20% "ROHS" 2.00 4000
51 210211107 CAP SMD ELEC ALUMINUM 100UF 16V 20% 6.3*5.4mm "ROHS" 2.00 4000
52 210226016 CAP SMD ELEC 50V 20% 1UF 4*5.5mm "ROHS" 2.00 4000
53 213102200 CAP SMD 0603 CER 20PF 20% 25V "ROHS" 2.00 4000
54 213102391 CAP SMD 0603 CER 20% 25V 390PF "ROHS" 16.00 4000
55 213104103 CAP SMD 0603 CER 10NF 10% 50V X7R "FENG HUA" "ROHS" 1.00 4000
56 213119104 CAP SMD 0603 0.1UF 10% 25V X7R "ROHS" 10.00 4000
57 3 310611171B IC SOT-223 "N.S" LM1117IMPX-3.3V/ LM1117MPX-3.3 "ROHS" 1.00 2500
58 311807416B IC SO14 "PHILIPS" 74HC164D "ROHS" 2.00
59 411024148 DIODE SMD SOD-80 MINIMELF 75V 150mA "GOOD-ARK" LL4148 "ROHS" 10.00 2500
60 411060000 LED RED 15mA SMD 0603 HIGHILIGHT "JASIONAL" JX-SP190URC "ROHS" 20.00 3000
61 421013904 TRANS SMD SOT-23 XTR SS NPN 250MHz "PHILIPS" 404 MMBT3904 "ROHS" 16.00 3000
62 511071009 INDUCTOR SMD 1206 10uH 10% "FENGHUA" CMI321609X100KT "ROHS" 1.00 4000
63 551038004 CRYSTAL 8MHz+/-25PPM 22PF HC-49/S-SMD "DONGGUANG" CXSD-008000000-D200GD75 "ROHS" 1.00 1000
64 711048401 CONNECTOR SMD 5943XXOHDOR-16P 16PIN P=1.0mm "MEILI" 1.0-16PX "ROHS" 1.00
65 721509900 USB JACK SMD MUSB-BSF-105 5PIN "CHUNSHENG" MUSB-B-105-EP "ROHS" 1.00 1000
66 Y324710386 IC MPU PROGRAMMING 32-BIT 64K FLASH 3.3V 48MHZ W/USB LQFP-64 "ST" STM32F103R8T6TR CONSIGN "ROHS" 1.00
67 Y314710386 IC MPU 32-BIT 64K FLASH 3.3V 48MHZ W/USB LQFP-64 "ST" STM32F103R8T6 CONSIGN "ROHS" 1.00
68 152132103 POT 10K B "POLYSHINE" F-09KH B10K L15FCX6 "ROHS" 8.00 1000
69 812121000 SCREW ST2.5*12mm +P/B D=5mm BLACK ZINC "ROHS" 7.00
70 812127000 SCREW ST2.5*8mm +P/B D=5mm BLACK ZINC "ROHS" 33.00

1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
版本
日期
日期
制图
复核
页码
位置
地址
图名
公司
2011- 7- 8V0. 06
第页共页
AD07_MPK8_V0. 03
广州宁辉电子科技有限公司
广州市天河区天河东路240号广州高新技术创业服务中心206室
C: \ Document s and Setti ngs\Admi ni strator\桌面\ AD07_V0. 11_20101117\ AD07\ AD07_MPK8_V0. 011. Sch
修改
版本 内容 日期 批核
1 1
C4
104
R1 22R
R2 22R
+5V
C6
104
C7
104
VBUS 1
D- 2
D+ 3
ID 4
MP M2
SHIELD 5
MP M1
MP M3
MP M4
CN1
USB_MINI
C8
104
Y1
8MHz
C14
20p
C15
20p NRST
OSC_IN
OSC_OUT
VIN
3VOUT 2
1
GND/ADJ
U1
LM1117-3.3
C5
104
+3.3V
A+3.3V
+3.3V
+3.3V
+3.3V
USB_DP
USB_DM
SWDIO
SWCLK
USART1_RX
USART1_TX
USB_UP
USB_DM
USB_DP
R3
1.5K
USB_UP
SW_JATG
NRST
SWCLK
SWDIO
R4
10K
C13
104
+3.3V
C9 104
BOOT0
R5
10K
+3.3V
C1
100uF/10V
C2
100uF/10V
LED1
Amber
BOOT0
LED2
Amber
LED3
Amber
LED4
Amber
+3.3V
Version History:
V0.01 20100410 first designed by HWY;
V0.02 20100428 modified;
a. Add the Driver for the 74HC164 to the LEDs(Q1-Q20,RP10-RP19);
b. Add D1-D12 for the SW1-SW12 scanning;
c. Add caps(C18,C19) to U3 and U4;
d. Delect the FB1 & FB2(No need and current limited);
e. Moving C10 from U2.32 to U2.48;
V0.03 20100428 modified:
a. Use only one GND, delect AGND
V0.04 20100513 modified:
Del LED17, LED18, RP18,RP19, Q17 & Q18
V0.011 20101117 modified:
D1-D10 SOD-80
VBAT
1
PC13/TAMPER-RTC
2
PC14/OSC32_IN
3
PC15/OSC32_OUT
4
PD0/OSC_IN
5
PD1/OSC_OUT
6
NRST
7
PC0/ADC12_IN10
8
PC1/ADC12_IN11
9
PC2/ADC12_IN12
10
PC3/ADC12_IN13
11
VSSA
12
VDDA
13
PA0/WKUP/ADC12_IN0
14
PA1/ADC12_IN1
15
PA2/ADC12_IN2
16
PA3/ADC12_IN3
17
VSS_4
18
VDD_4
19
PA4/ADC12_IN4
20
PA5/ADC12_IN5
21
PA6/ADC12_IN6
22
PA7/ADC12_IN7
23
PC4/ADC12_IN14
24
PC5/ADC12_IN15
25
PB0/ADC12_IN8
26
PB1/ADC12_IN9
27
PB2/BOOT1
28
PB10/USART3_TX
29
PB11/USART3_RX
30
VSS_1
31
VDD_1
32
SPI2_NSS/PB12 33
SPI2_SCK/PB13 34
SPI2_MISO/PB14 35
SPI2_MOSI/PB15 36
TIM3_CH1/PC6 37
TIM3_CH2/PC7 38
TIM3_CH3/PC8 39
TIM3_CH4/PC9 40
TIM1_CH1/PA8 41
USART1_TX/PA9 42
USART1_RX/PA10 43
USBDM/CANRX/PA11 44
USBDP/CANTX/PA12 45
JTMS/SWDIO/PA13 46
VSS_2 47
VDD_2 48
JTCK/SWCLK/PA14 49
JTDI/PA15 50
PC10 51 PC11 52 PC12 53
TIM3_ETR/PD2 54
JTDO/PB3 55
JNTRST/PB4 56
I2C1_SMBAl/PB5 57
I2C1_SCL/PB6 58
I2C1_SDA/PB7 59
BOOT0 60
TIM4_CH3/PB8 61 TIM4_CH4/PB9 62
VSS_3 63
VDD_3 64
U2
STM32F103R8T6
L2
10uH
C12
103
C11
104
A+3.3V
ADC0
ADC1
ADC2
ADC3 ADC4 ADC5 ADC6 ADC7 ADC8 ADC9
ADC10
ADC11
ADC12
ADC13
ADC14 ADC15
+3.3V
SW1
RUBBERKEY-AD07
SW2
RUBBERKEY-AD07
SW3
RUBBERKEY-AD07
SW4
RUBBERKEY-AD07
LED5
Amber
LED6
Amber
LED7
Amber
LED8
Amber
RP10
47R
RP12
47R
A+3.3V
C21
391
C22
391
C23
391
C24
391
C25
391
C26
391
C27
391
VR8
10KB
VR7
10KB
VR6
10KB
VR5
10KB
VR4
10KB
VR3
10KB
VR2
10KB
VR1
10KB
8KNOBS
C28
391
ADC0
ADC1
ADC2
ADC3
ADC4
ADC5
ADC6
ADC7
RP8
10K
RP7
10K
PAD7
DumpPAD
PAD8
DumpPAD
PAD3
DumpPAD
PAD4
DumpPAD
PAD5
DumpPAD
PAD6
DumpPAD
PAD1
DumpPAD
PAD2
DumpPAD
A+3.3V
8 Dump PADs
ADC8
ADC9
ADC10
ADC11
ADC12
ADC13
ADC14
ADC15
FBP4
CBA321609-4U-601
FBP5
CBA321609-4U-601
FBP7
CBA321609-4U-601
FBP8
CBA321609-4U-601
+3.3V
Jumper in PCB to select Boot
C10
10uF/10V
C16
1uF/10V
C17
1uF/10V
+3.3V
Benj ami n_t an 20100410
1
2
JP1
SMD_JP2
C41
391
C42
391
C43
391
C44
391
C45
391
C46
391
C47
391
C48
391
1
2
3
4
CN3
SIP4(No stuff)
FB1
CBW451616U851
KEY_RD#0
KEY_RD#1
KEY_RD#2
KEY_RD#3
KEY_RD#4
KEY_RD#5
KEY_RD#6
KEY_RD#7
KEY_SEL#0
KEY_SEL#1
KEY_SEL#2
KEY_SEL#3
KEY_SEL#4
KEY_SEL#5
KEY_SEL#6
RP5
100K
RP6
100K
+3.3V
To keyboard
FBP11
CBA321609-4U-601
FBP12
CBA321609-4U-601
FBP9
CBA321609-4U-601
FBP10
CBA321609-4U-601
KEY_SEL#0
KEY_SEL#1
KEY_SEL#2
KEY_SEL#3
KEY_SEL#4
KEY_SEL#5
KEY_SEL#6
KEY_RD#0
KEY_RD#1
KEY_RD#2
KEY_RD#3
KEY_RD#4
KEY_RD#5
KEY_RD#6
KEY_RD#7
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
CN2
FPC1.0-4-16PB
LED9
Amber
LED10
Amber
LED11
Amber
LED12
Amber
RP14
47R
LED13
Amber
LED14
Amber
LED15
Amber
LED16
Amber
RP16
47R
A
1
B
2
QA 3
QB 4
QC 5
QD 6
GND
7
CLK
8CLR
9
QE 10
QF 11
QG 12
QH 13
VCC
14
U3
74HC164
+3.3V
+3.3V
S_DAT0
A
1
B
2
QA 3
QB 4
QC 5
QD 6
GND
7
CLK
8CLR
9
QE 10
QF 11
QG 12
QH 13
VCC
14
U4
74HC164
+3.3V
S_DAT1
S_CLK
KEY_SEL#7
SW9
RUBBERKEY-AD07
SW10
RUBBERKEY-AD07
SW5
RUBBERKEY-AD07
SW6
RUBBERKEY-AD07
SW7
RUBBERKEY-AD07
SW8
RUBBERKEY-AD07
KEY_RD#0
KEY_RD#1
KEY_RD#2
KEY_RD#3
KEY_RD#4
KEY_RD#5
KEY_RD#0
KEY_RD#1
KEY_RD#2
KEY_RD#3
KEY_SEL#8
FB3
CBG160808U601
KEY_RD0
KEY_RD1
KEY_RD2
KEY_RD3
KEY_RD4
KEY_RD5
KEY_RD6
KEY_RD7
KEY_RD0 KEY_RD1
KEY_RD2 KEY_RD3
KEY_RD4
KEY_RD5
KEY_RD6
KEY_RD7
KEY_SEL0
S_CLK S_DAT0 S_DAT1 S_DAT2 S_DAT3
KEY_SEL0
KEY_SEL1
KEY_SEL2
KEY_SEL3
KEY_SEL4
KEY_SEL5
KEY_SEL6
KEY_SEL7
KEY_SEL8
KEY_SEL1
KEY_SEL2
KEY_SEL3 KEY_SEL4 KEY_SEL5
KEY_SEL6
KEY_SEL7
KEY_SEL8
S_DAT4 S_DAT5
D1
1N4148
D2
1N4148
D3
1N4148
D4
1N4148
D5
1N4148
D6 1N4148
D7 1N4148
D8 1N4148
D9 1N4148
D10 1N4148
Q13
2N3904
Q14
2N3904
Q15
2N3904
Q16
2N3904
RP17
4.7K
Q9
2N3904
Q10
2N3904
Q11
2N3904
Q12
2N3904
RP15
4.7K
Q5
2N3904
Q6
2N3904
Q7
2N3904
Q8
2N3904
RP13
4.7K
Q1
2N3904
Q2
2N3904
Q3
2N3904
Q4
2N3904
RP11 4.7K
C18
104
+3.3V
C19
104
C3
10uF/10V
P0C101P0C102 P0C201P0C202 P0C301P0C302
P0C401P0C402 P0C501P0C502
P0C601P0C602
P0C701P0C702
P0C801 P0C802
P0C901P0C902
P0C1001P0C1002
P0C1101P0C1102
P0C1201P0C1202
P0C1301 P0C1302
P0C1401 P0C1402
P0C1501 P0C1502
P0C1601 P0C1602 P0C1701P0C1702
P0C1801P0C1802
P0C1901P0C1902
P0C2101P0C2102
P0C2201 P0C2202 P0C2301 P0C2302
P0C2401P0C2402
P0C2501 P0C2502 P0C2601 P0C2602 P0C2701 P0C2702 P0C2801 P0C2802
P0C4101P0C4102
P0C4201 P0C4202 P0C4301 P0C4302
P0C4401P0C4402
P0C4501 P0C4502 P0C4601 P0C4602 P0C4701 P0C4702 P0C4801 P0C4802
P0CN101
P0CN102
P0CN103
P0CN104
P0CN105
P0CN10M1
P0CN10M2
P0CN10M3
P0CN10M4
P0CN201
P0CN202
P0CN203
P0CN204
P0CN205
P0CN206
P0CN207
P0CN208
P0CN209
P0CN2010
P0CN2011
P0CN2012
P0CN2013
P0CN2014
P0CN2015
P0CN2016
P0CN301
P0CN302
P0CN303
P0CN304
P0D101 P0D102
P0D201 P0D202
P0D301 P0D302
P0D401 P0D402
P0D501 P0D502
P0D601 P0D602
P0D701 P0D702
P0D801 P0D802
P0D901 P0D902
P0D1001 P0D1002
P0FB101P0FB102
P0FB301 P0FB302
P0FBP401
P0FBP402
P0FBP403
P0FBP404P0FBP405
P0FBP406
P0FBP407
P0FBP408
P0FBP501
P0FBP502
P0FBP503
P0FBP504P0FBP505
P0FBP506
P0FBP507
P0FBP508
P0FBP701
P0FBP702
P0FBP703
P0FBP704 P0FBP705
P0FBP706
P0FBP707
P0FBP708
P0FBP801
P0FBP802
P0FBP803
P0FBP804 P0FBP805
P0FBP806
P0FBP807
P0FBP808
P0FBP901
P0FBP902
P0FBP903
P0FBP904P0FBP905
P0FBP906
P0FBP907
P0FBP908
P0FBP1001
P0FBP1002
P0FBP1003
P0FBP1004P0FBP1005
P0FBP1006
P0FBP1007
P0FBP1008
P0FBP1101
P0FBP1102
P0FBP1103
P0FBP1104P0FBP1105
P0FBP1106
P0FBP1107
P0FBP1108
P0FBP1201
P0FBP1202
P0FBP1203
P0FBP1204P0FBP1205
P0FBP1206
P0FBP1207
P0FBP1208
P0JP101
P0JP102
P0L201P0L202
P0LED101P0LED102 P0LED201P0LED202 P0LED301P0LED302 P0LED401P0LED402 P0LED501P0LED502 P0LED601P0LED602 P0LED701P0LED702 P0LED801P0LED802 P0LED901P0LED902
P0LED1001P0LED1002 P0LED1101P0LED1102 P0LED1201P0LED1202 P0LED1301P0LED1302 P0LED1401P0LED1402 P0LED1501P0LED1502 P0LED1601P0LED1602
P0PAD101 P0PAD102
P0PAD201 P0PAD202
P0PAD301 P0PAD302
P0PAD401 P0PAD402
P0PAD501 P0PAD502
P0PAD601 P0PAD602
P0PAD701 P0PAD702
P0PAD801 P0PAD802
P0Q10B
P0Q10CP0Q10E
P0Q20B
P0Q20CP0Q20E
P0Q30B
P0Q30CP0Q30E
P0Q40B
P0Q40CP0Q40E
P0Q50B
P0Q50CP0Q50E
P0Q60B
P0Q60CP0Q60E
P0Q70B
P0Q70CP0Q70E
P0Q80B
P0Q80CP0Q80E
P0Q90B
P0Q90CP0Q90E
P0Q100B
P0Q100CP0Q100E
P0Q110B
P0Q110CP0Q110E
P0Q120B
P0Q120CP0Q120E
P0Q130B
P0Q130CP0Q130E
P0Q140B
P0Q140CP0Q140E
P0Q150B
P0Q150CP0Q150E
P0Q160B
P0Q160CP0Q160E
P0R101P0R102
P0R201P0R202
P0R301 P0R302
P0R401 P0R402
P0R501P0R502
P0RP501 P0RP502 P0RP503 P0RP504 P0RP505
P0RP506 P0RP507 P0RP508
P0RP601 P0RP602 P0RP603 P0RP604 P0RP605
P0RP606 P0RP607 P0RP608
P0RP701 P0RP702 P0RP703 P0RP704P0RP705
P0RP706 P0RP707 P0RP708
P0RP801 P0RP802 P0RP803 P0RP804P0RP805
P0RP806 P0RP807 P0RP808
P0RP1001 P0RP1002 P0RP1003 P0RP1004P0RP1005
P0RP1006 P0RP1007 P0RP1008
P0RP1101
P0RP1102
P0RP1103
P0RP1104P0RP1105
P0RP1106
P0RP1107
P0RP1108
P0RP1201 P0RP1202 P0RP1203 P0RP1204 P0RP1205
P0RP1206 P0RP1207 P0RP1208
P0RP1301
P0RP1302
P0RP1303
P0RP1304 P0RP1305
P0RP1306
P0RP1307
P0RP1308
P0RP1401 P0RP1402 P0RP1403 P0RP1404 P0RP1405
P0RP1406 P0RP1407 P0RP1408
P0RP1501
P0RP1502
P0RP1503
P0RP1504 P0RP1505
P0RP1506
P0RP1507
P0RP1508
P0RP1601 P0RP1602 P0RP1603 P0RP1604 P0RP1605
P0RP1606 P0RP1607 P0RP1608
P0RP1701
P0RP1702
P0RP1703
P0RP1704P0RP1705
P0RP1706
P0RP1707
P0RP1708
P0SW101 P0SW102
P0SW201 P0SW202
P0SW301 P0SW302
P0SW401 P0SW402
P0SW501 P0SW502
P0SW601 P0SW602
P0SW701 P0SW702
P0SW801 P0SW802
P0SW901 P0SW902
P0SW1001 P0SW1002
P0U101
P0U102
P0U103
P0U201
P0U202
P0U203
P0U204
P0U205
P0U206
P0U207
P0U208
P0U209
P0U2010
P0U2011
P0U2012
P0U2013
P0U2014
P0U2015
P0U2016
P0U2017
P0U2018
P0U2019
P0U2020 P0U2021 P0U2022 P0U2023
P0U2024 P0U2025
P0U2026 P0U2027
P0U2028
P0U2029
P0U2030
P0U2031
P0U2032
P0U2033
P0U2034
P0U2035
P0U2036
P0U2037
P0U2038
P0U2039
P0U2040
P0U2041
P0U2042
P0U2043
P0U2044
P0U2045
P0U2046
P0U2047
P0U2048
P0U2049
P0U2050
P0U2051 P0U2052 P0U2053
P0U2054
P0U2055
P0U2056
P0U2057
P0U2058
P0U2059
P0U2060
P0U2061 P0U2062
P0U2063
P0U2064
P0U301
P0U302
P0U303
P0U304
P0U305
P0U306
P0U307
P0U308
P0U309
P0U3010
P0U3011
P0U3012
P0U3013
P0U3014
P0U401
P0U402
P0U403
P0U404
P0U405
P0U406
P0U407
P0U408
P0U409
P0U4010
P0U4011
P0U4012
P0U4013
P0U4014
P0VR101
P0VR102
P0VR103
P0VR201
P0VR202
P0VR203
P0VR301
P0VR302
P0VR303
P0VR401
P0VR402
P0VR403
P0VR501
P0VR502
P0VR503
P0VR601
P0VR602
P0VR603
P0VR701
P0VR702
P0VR703
P0VR801
P0VR802
P0VR803
P0Y101 P0Y102
