Akai AL2415TC User manual

P1-P17
P18-P37

1
Table Of Contents
1
2
Important Safety Instruction
Warnings and Cautions 3
4
Functional Parts(TV)
ATV Source 8-10
Rear View Of TV Set 5
Operation-Remote Control 6
Select Input Source
7
Basic Operation
7
Other Source 11
PC Source 11
DTV Source 11-12
USB Source 12
PVR Source 13-15
Table of Contents
Troubleshooting Tips 16

2
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT EXPOSE THIS
APPARATUS TO RAIN OR MOISTURE AND OBJECTS FILLED WITH LIQUIDS,
SUCH AS VASES, SHOULD NOT BE PLACED ON THIS APPARATUS.
The lighting flash with arrow head within a triangle is intended to tell the user that
parts inside the product are a risk of electric shock to persons.
The exclamation point within a triangle is intended to tell the user that important
operating and servicing instructions are in the papers with the appliance.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT
REMOVE COVER OR BACK. NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Important Safety Instruction

3
Warnings And Cautions
Caution
Do not drop or push objects into the television cabinet slots
or openings. Never spill any kind of liquid on the television
receiver.
Caution
Do not insert anything in the ventilation holes. If metal or
something flammable enters, it may result in fire or electric shock.
Caution
Do not place your television on an unstable cart , stand , shelf or
table. Serious injury to an individual, and damage to the television,
may result if it should fall.
Caution
Do not block the ventilation holes in the back cover.
Adequate ventilation is essential to prevent failure of electrical
component.
To prevent fire or electrical shock hazard, Do not expose the
television receiver to rain or moisture.
Warning

4
12
Functional Parts( TV )
To turn the TV power ON
Put the TV set on the correct place, then connect the DC plug of the AC-DC adaptor to the DC 12V socket
at the back of the TV set. Connect the adaptor main cord to the wall outlet ,then the LED indicator lamp
turns red/blue and the TV set is at Standby/work Mode. At Standby Mode, if Standby Button is pressed
the power indicator will change to blue. It will flash a few seconds before the picture appears.
To turn the TV power OFF
Press the Standby Button to make the TV set in Standby Mode, then disconnect the power plug from the
wall outlet.
NOTE:
If TV is the selected input without signal received and NO operation is performed for about 5 minutes
continuously, the TV set will enter standby mode. For any inputs other than TV, the TV set will not enter
standby mode automatically without users instruction. If you are not going to use this TV set for a long
time, switch off the set and disconnect the power plug from the wall outlet.
Front View of LED Set
1.
2. LED indicator lamp
Remote Sensor
