AKG SOUNDS BETTER

Recording Microphones
Perception 420
■Back-to-back large-diaphragm multi-pattern transducer
■True condenser technology
■High sensitivity and 155 dB maximum SPL capability
■Switchable 20 dB preattenuation pad
■Switchable bass cut filter
■Legendary, pristine AKG sound quality
■Complete with spider-type shock mount and aluminium
carrying case
A/B, X/Y, and M/S stereo recording
Ambient recording
Classical music recording
Drums
Grand piano, woodwinds, brass
Percussions
Studio applications
AKG’s PERCEPTION microphones have built a strong
following among musicians and engineers, proving to be
one of the best high-value true condenser microphones
on the market today. Building on this reputation, AKG now
introduces four new PERCEPTION models providing superb
audio quality and stellar performance at very competitive prices.
The entire PERCEPTION line has been designed and
engineered by AKG in Vienna, Austria. The microphones
are manufactured in China under strict quality control by
AKG. The result is unique, innovative Austrian technology
and exceptional build quality at uniquely reasonable prices.

Recording Microphones
Perception 220 Perception 170 Perception 120
Studio applications
Live sound
Vocals
Drums
Percussions
Guitar and bass amps
Acoustic instruments
■One-inch large-diaphragm, true condenser
cardioid transducer
■Rugged all-metal body
■Roadworthy construction
■Switchable 20 dB preattenuation pad
■Switchable bass cut filter
■Legendary AKG sound quality
■Designed and engineered by AKG in Vienna, Austria
■Comes with spider-type shock mount
and aluminium carrying case
Live sound
Studio applications
Acoustic instruments
Drums
Percussions
Ensemble recording
A/B and X/Y stereo miking
Musical instruments
Live sound
Vocals
Podcasting
Home recording
■Professional small-diaphragm,
true condenser cardioid microphone
■Switchable 20 dB preattenuation pad
■Heavy-duty, roadworthy,
all-metal construction
■AKG sound quality
■Designed and engineered by AKG
in Vienna, Austria
■General-purpose cardioid
recording microphone
■Extended frequency response
■Roadworthy construction
■Switchable 20 dB preattenuation pad
■Switchable bass cut filter
■Designed and engineered by AKG
in Vienna, Austria
AKG SOUNDS BETTER

D40
The D 40 with its solid all-metal body will
stand up to the hardships of night-after-night
on stage use “with a smile”.
The Varimotion™ diaphragm deep-drawing
process allows the diaphragm itself to be
fine-tuned with no need for tuning resonators,
leading to a quantum leap in audio performance.
The transducer is protected by a sturdy wire-mesh
cap and takes extremely high sound pressure
levels with ease. An integrated stand adapter
and standard H 440 mounting bracket for snare
drums, tom-toms, etc. make the D 40 a highly
versatile tool for use on drums, percussions,
wind instruments, and guitar amps.
■Dynamic microphone designed for drums
and percussions, wind instruments,
and guitar amps
■Patented AKG Varimotion™ diaphragm
■Custom built capsule mounting
■Spring steel wire-mesh cap
■Rugged all-metal body withstands typical
tough handling on stage
Instrument Microphone
Instruments
Live sound

K99 K77
■Closed-back circumaural headphones
■Excellent comfort
The newly designed K 77 are cost-efficient headphones for various
applications.
These closed-back headphones are an all-round performer with solid
bass and clean highs at a valuable price.
A self-adjusting headband, leatherette earpads, and gimbal suspen-
sion ensure excellent comfort.
Monitoring
Home recording
Musical instruments
Home recording
Musical instruments
Monitoring
Headphones
■Semi-open, circumaural hi-fi stereo headphones
■Low weight for excellent comfort
■Skin compatible leatherette ear pads
■Excellent price/performance
The newly designed K 99 are semi-open stereo headphones
which combine excellent sound and optimum price/performance.
Self-adjusting headband, soft leatherette circumaural earpads,
and low weight ensure pleasant fit.
Large, high-performance
1.6-inch (40-mm) speakers provide a natural, uncolored sound.
AKG SOUNDS BETTER

■Professional circumaural
hi-fi stereo studio headphones
■Self-adjusting headband
for optimum fit
■Patented Varimotion™ speakers
■High noise attenuation
■For onstage and studio use
■Automute feature mutes headphones when they are taken off
■Leatherette and additional velvet ear pads
■Single-sided, detachable 3 m cable and additional
5 m coiled cable
The newly designed AKG legend, K 271 MK II combines the benefits
of AKG’s circumaural design for extreme comfort and a closed-back
design for maximum isolation from ambient noise. Thanks to its XXL
transducers, the K 271 MK II sounds clean, smooth and very rich.
The K 271 MK II is the perfect choice for any application where sonic
bleed could cause problems such as broadcast work.
Another important feature of the K 271 MK II is the addition of a switch
in the headband that mutes the audio just as soon as the headphones
are taken off.
■Professional hi-fi stereo
studio headphones
■Self-adjusting headband
for optimum fit
■Patented Varimotion™ speakers
■High ambient noise attenuation
■For broadcast and DJ use
■Rugged construction for tough handling
■Leatherette ear pads and additional velvet ear pads
■Single-sided, detachable 3 m cable and additional
5 m coiled cable
The newly designed K 171 MK II combines the benefits of a closed-back
design with the lightweight and comfort of supra-aural headphones.
The K 171 MK II is an excellent choice for DJ and broadcast applications
where no sound can bleed from the headphones into live microphones.
The closed-back, loud and rugged design gives the K 171 MK II
a different low-frequency character and maintains its comfort and
flexibility.
Studio Studio
Headphones
K271 MK II K171 MK II

■Professional hi-fi stereo
studio headphones
■Semi-open supraaural
earphones
■Self-adjusting headband for
optimum fit
■Patented Varimotion™ speakers
■Undistorted sound even at high volume levels
■Leather ear pads and velvet ear pads
■Single-sided, detachable 3 m cable and additional
5 m coiled cable
The K 141 MK II is a newly updated version of the AKG legend with
XXL transducers with Varimotion™ technology to deliver higher sensi-
tivity, wide dynamic range and higher SPL, plus its lower impedance
also allows it to be used with computers and other devices with low-
power output.
The gimbalsuspended earcups and self-adjusting headband makes
these comfortable to wear. The detachable OFC cables have gold-
plated plugs for easy transportation and years of loss-free signal
transfer.
■Professional hi-fi stereo
studio headphones
■Semi-open, circumaural design
■Self-adjusting headband
for optimum fit
■Patented Varimotion™ speakers
■Leatherette ear pads and velvet ear pads
■Single-sided, detachable 3 m cable and additional
5 m coiled cable
The K 240 MK II is a newly updated version of AKG’s most success-
ful headphones with Varimotion™ technology and XXL transducers.
The K 240 MK II’s semi-open ear cups have around-the-ear coupling
to deliver solid bass, accurate mids and crystal-clear highs.
Thanks to its lower impedance and improved sensitivity, it can be
used with low-output audio sources to deliver its incredible sound.
The detachable OFC cable has gold-plated plugs for optimum audio
quality and exceptional ease of service.
Studio Studio
Headphones
K240 MK II K141 MK II
AKG SOUNDS BETTER

WMS 40 PRO – The plug & play wireless solution
Wireless Systems
■SR 40 DUAL: Two single-frequency receivers
in a single case, balanced TRS output jacks,
multichannel capability up to seven* channels
operating simultaneously
■SR 40 SINGLE: Single fixed frequency,
balanced TRS output jack, multichannel
capability up to seven* channels operating
simultaneously
Live sound
Houses of Worship
Conference
Sound/AV company
Gyms
The new WMS 40 PRO Series is the optimum solution for small stages,
clubs, places of worship, hotels, and gyms. With their plug and play
concept and fixed frequencies, these systems set up quickly and are
easy to use. The transmitters will operate for more than 30 hours off
a single AA size battery.
The WMS 40 PRO systems are available in three versions to match any
application and budget: free reception, adjustable transmitter input gain.
SR 40 PRO
■SR 40 FLEXX: Three selectable frequencies,
balanced XLR and unbalanced jack outputs,
adjustable squelch, multichannel capability
up to nine* channels operating simultaneously
DUAL: Two receivers in a single unit for exceptionally cost efficient two-
channel systems.
SINGLE: The easy-to-use single-channel wireless systems.
Also compatible with the Microtool GB 40 transmitter.
WMS 40 PRO Series products are available in several complete systems
and can be used in many countries without paying any fees or obtaining
permits. All SR 40 PRO versions provide an output level control for
optimally matching the receiver’s output level to the connected equip-
ment and feature a rugged metal case for freestanding or rack
mounted use.
•Instrumental Set SINGLE
SR 40 SINGLE
PT 40 PRO
MKG L cable
•Vocal Set SINGLE
SR 40 SINGLE
HT 40 PRO
Vocal Instrumental
•Instrumental Set DUAL
SR 40 DUAL
2 x PT 40 PRO
MKG L cable
•Vocal Set DUAL
SR 40 DUAL
2 x HT 40 PRO
•Instrumental Set FLEXX
SR 40 FLEXX
PT 40 FLEXX
MKG L cable
•Vocal Set FLEXX
SR 40 FLEXX
HT 40 FLEXX
* Depending on local frequency plans. For details, please contact your dealer or visit www.akg.com/wms40pro
FLEXXDUALSINGLE
Maximum flexibility
Three selectable frequencies for interference-free
reception, adjustable transmitter input gain
•Three selectable frequencies
•Diversity receiver
•Adjustable squelch
1 handheld transmitter or 1 bodypack transmitter, 1 receiver
•Multichannel capability: up to nine*
channels operating simultaneously
•Rugged bodies
2 in 1 receiver saves cost
Two receivers in a single unit for exceptionally
cost efficient two-channel systems
•Two single-frequency receivers
in a single unit
•Metal case
•Miniature transmitters
2 handheld transmitters or 2 bodypack transmitters, 1 receiver
•Single-battery powering
•Multichannel capability: up to seven*
channels operating simultaneously
Easy to use.
The easy-to-use single-channel wireless systems.
Unpack and get going.
•Single, fixed frequency
•Metal case
•Miniature transmitters
•Single-battery powering
1 handheld transmitter or 1 bodypack transmitter, 1 receiver
•Multichannel capability:
multichannel capability up to seven*
channels operating simultaneously

Wireless Systems
HT 40 PRO PT 40 PRO
■Operates for more than 30 hours
off a single AA size battery
■Ergonomic styling and anti-slip finish
for confident and easy handling
■Built-in contacts for charging batteries
inside the transmitter on optional
CU 400 charger
■HT 40 FLEXX:
three selectable frequencies
■HT 40 PRO:
single fixed frequency
The WMS 40 PRO Series handheld trans-
mitters feature exceptional ruggedness, anti-
slip finish for ease of handling, and elegant
styling. They are available in two versions:
the HT 40 FLEXX is included in the FLEXX
systems, the HT 40 PRO in the DUAL and
SINGLE systems. Operating for more than
30 hours off a single AA size battery, the
transmitters save money due to their re-
duced battery replacement need. Recharge-
able batteries can be charged inside the
transmitter on the optional CU 400 charger.
A noiseless on/mute/off switch and
a status LED add to user-friendliness.
The WMS 40 PRO Series bodypack transmitters are rugged,
extremely compact, and light. A mini XLR connector allows you
to connect many AKG microphones or portable instruments.
The PT 40 PRO bodypack transmitter is available in two versions:
the PT 40 FLEXX is included in the FLEXX systems,
the PT 40 PRO in the DUAL and SINGLE systems.
PT 40 PRO works with all microphones from AKG MicroMic Series.
■Extremely compact, light bodypack
transmitter
■Operates for more than 30 hours
off a single AA size battery
■Built-in contacts for charging
batteries inside the transmitter
on optional CU 400 charger
■PT 40 FLEXX:
three selectable frequencies
■PT 40 PRO:
single fixed frequency
CU 400
•Transformer Set SINGLE
SR 40 SINGLE
SO 40 Snapon Transmitter
•Presenter Set SINGLE
SR 40 SINGLE
PT 40 PRO
CK 55 L
•Sports Set SINGLE
SR 40 SINGLE
PT 40 PRO
C 555 L
Sports Presenter Special
•Presenter Set DUAL
SR 40 DUAL
PT 40 PRO
C 555 L, HT 40 PRO
•Presenter Set FLEXX
SR 40 FLEXX
PT 40 FLEXX
CK 55 L
•Sports Set FLEXX
SR 40 FLEXX
PT 40 FLEXX
C 555 L
Please note that some of these products may not be available in your country. For details, please contact your local dealer or national AKG distributor.
AKG SOUNDS BETTER
•Guitar/Vocal Set DUAL
SR 40 DUAL
PT 40 PRO
C 555 L, GB 40

Wireless Systems Accessories
Multi-Coupler
■Extended operating frequency range, 500 - 865 MHz
■Supplies antenna signal and DC power for four
SR 4000 receivers
■Two expansion outputs allow signal cascading up to
3 additional PS 4000 Ws from one antenna feed
High quality, high comfort earphones
■High performance, full spectrum sound for professional
in-ear-monitoring
■Total ambient isolation to block out stage noise
■Dark grey finish
■Individual fit with three different sleeves (S, M, L)
■Protective carrying case and bag included
The IP 2 earphones are included in the IVM 4 Sets and in the
SPR 4 Sets. The IP 2 earphones connect to the SPR 4 bodypack
receiver and are also available single packed.
These high quality earphones provide a wide-range sound with
sharply contoured bass reproduction as well as excellent isolation
to suppress high ambient noise levels encountered, e.g., on a
loud concert stage.
An integrated sliding cable tie and the supplied soft-rubber ear-
molds in three different sizes enable the earphones to adapt to
every shape of ear.
The New WMS 4000/450 Accessories
Perfect for flexible solutions.
Prepared for challenging wireless frequency environments.
Active, wideband
directional antenna
■Extended operating
frequency range,
500 - 865 MHz
■Improved mechanics for indoor and outdoor use
■Constant gain for complete wideband operating range
Omnidirectional wideband
booster antenna
PS 4000 W
IP 2
SRA 2 B/W
RA 4000 B/W

Wireless Systems
The New
HUB 4000 Q
System Architect
Plug In
System Architect Plug In with SST 4 and SR 4000 Stripes
Device Manager for multiple HUB 4000 Qs
Frequency Graph shows Environment Scan data
■NEW: Supports AKG SST 4 (IVM 4)
■NEW: Grouping of multiple HUB 4000 Qs for monitoring
and controlling large Wireless Systems from a single
window
■NEW: Easy and fast setup of Frequency Management
of Wireless Systems with Auto Setup, Environment Scan
and Device Manager
■NEW: Fast and accurate Environment Scan (7 seconds
for 30 MHz)
■NEW: Saving and Loading of all device parameters
■NEW: Convert to Custom possible
■NEW: Offline configuration of Wireless Systems
■Ethernet interface for connecting up to eight AKG devices
to a HiQnet™ network
■Full HiQnet™ protocol compatibility
■All AKG device parameters can be controlled and
monitored with the HUB 4000 Q System Architect Plug In
■Supports AKG SR 4000 (WMS 4000)
connect. configure. control.
HUB 4000 Q
AKG SOUNDS BETTER

www.akg.com
AKG Acoustics GmbH
Lemböckgasse 21–25, 1230 Vienna /AUSTRIA, phone: + 43 1 86654 0
e-mail: [email protected]
AKG Acoustics, U.S.
8400 Balboa Boulevard, Northridge, CA 91329, U.S.A., phone: + 1 818 920 3212
e-mail: [email protected]
For other products and distributors worldwide visit www.akg.com
Specifications subject to change without notice.
01/08 PROA 1566
A Harman International Company
