Albany R-BAC UltraSmart User manual
UltraSmart
2
CONTENTS
Setting door travel limits Page 3
Setting System Options Page 4
SettingTimers Page 4
Instructions for Viewing fault history Page 5
Instructions for turning on Automatic
Close feature for front Open button Page 6
Instructions for De-activating Breakaway Page 7
Wireless
Instructions for Re-Activating Breakaway Page 8
Wireless
Instructions for De-Activating Reversing
Edge Wireless Page 9
Instructions for Re-Activating Reversing
Edge wireless Page 10
Instructions for De-Activating PE 1
Front Photo Eye Page 11
Instructions for Re-Activating PE 1
Front Photo Eye Page 12
Instructions for De-Activating PE 2
Rear Photo Eye Page 13
Instructions for Re-Activating PE 2
Rear Photo Eye Page 14
Instructions for Adjusting Defrost
Heat Cycle Time Page 15,16
Instructions for Operating Blower
Only when the door is Closed Page 17
3
SETTING THE DOOR TRAVEL LIMITS
1) Press and hold until “LIMIT SETUP” is shown on the display; Press
2) “Closed Limit” should be displayed; Press
3) Use and/or to bring the door to the full closed position; Press
4) Press “Full Open Limit” should be displayed; Press
5) Use and/or to bring the door to the full open position; Press
6) Press “Partial Open Limit” should be displayed; Press
7) Use and/or to bring the door to the partial open position; Press
8) Press “Breakaway/Reset Limit” should be displayed; Press
9) Use and/or to bring the door to the breakaway reset position; Press
10)Press until “DOOR READY” is displayed
The Open, Partial, and Breakaway Limit are all relative to the Closed
Limit. If the Closed Limit is reset to a different position, all other limit
settings will change relative to the new Closed Limit setting.
4
Setting System Options
1) Press and hold until “LIMIT SETUP” is shown on the display.
2) Press until “SYSTEM OPTIONS” is shown; Press
⇒ Use and/or to cycle through the available options; Press to edit that
option.
⇒ Use and/or to change the value; Press to store that value
3) When finished—press until “DOOR READY” is displayed
Commonly changed SYSTEM OPTIONS: Rev Edge Auto Close?, Photoeye Auto Close,
Panel Open Man 1 Auto Close?
Setting Timers
1) Press and hold until “LIMIT SETUP” is shown on the display.
2) Press until “SET TIMERS” is shown; Press
⇒ Use and/or to cycle through the available options; Press to edit an
option.
⇒ Use and/or to change the value; Press to store that value
3) When finished—press until “DOOR READY” is displayed
Commonly changed TIMERS: Close Delay Auto 1, Door Open Alarm Timer, Delay To Close Output
Defrost Cycle On, Defrost Cycle Off
5
Instructions for Viewing Fault History
1. Press and hold the Reset/Menu button for 3-5 seconds.
2. The display will read LIMIT SETUP. Press the UP ARROW button until the
Display reads VIEW FAULT HISTORY. Press the ENTER button
3. The display will show the following:
A. Top Line
1. Fault #/# of total faults (left hand corner of display screen). The
maximum number of faults saved is 64. after 64 faults, the oldest fault
Will be deleted. The newest fault will be 1 /# of faults.
2. Cycle cont (RH corner of display screen). This will display the cycle
count when the fault occurred.
B. Bottom Line
Fault description. This is the fault or error code.
4. Use the UP ARROW and DOWN ARROW buttons to scroll through the
fault history.
5. Once done, push the RESET button once to get back to the main menu.
Push the RESET button again to get the door ready to run. The display will read
DOOR READY and the cycle count.
6
Instructions for Turning On automatic close feature for front Open button
1. Press and hold the Reset/Menu button for 3-5 seconds.
2. The display will read LIMIT SETUP. Press the UP ARROW button until
the display reads SYSTEM OPTIONS. Press the ENTER button.
3. The display will read:
a. PanelOpen&Close
Disable? NO
4. Press the DOWN ARROW button until the display reads:
a. PanelOpen
Man1 Auto Close? NO
5. Press the UP ARROW button to change NO to YES.
6. Press the ENTER button once.
7. Push the RESET button once to get back to the System Options menu,
Push the RESET button once to get back to the main menu. Push the
RESET button again to get the door ready to run. The display will read
DOOR READY and the cycle count
.
7
Instructions for De – Activating Breakaway (Wireless)
1. Press and hold the Reset/Menu button for 3 to 5 seconds.
2. The display will read LIMIT SETUP. Press the UP ARROW button until
the display reads MODULE CONFIGURATION.
3. Press the ENTER button.
4. Press the UP ARROW button until the display reads MOD Z…
5. Press the ENTER button two times.
Note: there are two breakaway inputs, Breakaway I 1 and Breakaway I 2
I 1 should be left side and I 2 should be right side. Determine which one you
wish to disable.
6. The display will read Breakaway I 1. Press the UP ARROW button if you
want breakaway I 2. Press the ENTER button. The cursor will be flashing
underneath the word Breakaway. Press the UP ARROW button to change
this to Not Assigned. Press Enter . The second line should read NO .
7. Press the ENTER button Twice. The cursor will go away.
8. Press the RESET button once to get back to the main menu. 9.
Push the RESET button again to get the door ready to run. The display will
read DOOR READY and the cycle count.
8
InstructionsforRe‐activatingBreakaway(WireLess)
1. PressandholdtheReset/Menubuttonfor3‐5seconds.
2. ThedisplaywillreadLIMITSETUP.PresstheUPARROWbutton
untilthedisplayreadsMODULECONFIGURATION.PresstheENTER
button.
3. PresstheUPARROWbuttonuntilthedisplayreadsMODZ…pressthe
ENTERbuttontwotimes.Note:therearetwobreakawayinputsI1andI
2.I1shouldbetheleftsideandI2shouldbetherightside,determinewhich
oneyouwishtoactivate.
4. ThedisplaywillreadBreakawayI1orNOTASSIGNEDI1,presstheuparrow
buttonifyouwantBreakawayI2orNOTASSIGNEDI2presstheENTER
Button.ThecursorwillbeflashingunderneaththewordNOTASSIGNED.
PresstheUPARROWbuttontochangethistoBREAKAWAY.Pressthe
ENTERbutton.ThesecondlineshouldreadNO.PresstheENTER
buttonTwice.Thecursorwillgoaway.
5. PresstheRESETbuttononcetogetbacktothemainmenu.
6. PresstheRESETbuttononceagainthedisplaywillreadDOORREADY.
7. Thedoorisnowreadytorun.
9
Instructions for De -Activating the Reversing Edge (Wireless)
1. Press and hold the Reset/Menu button for 3 to 5 seconds.
2. The display will read LIMIT SETUP. Press the UP ARROW button until the
display reads MODULE CONFIGURATION. Press the ENTER button.
3. Press the UP ARROW button until the display reads MOD Z… Press the
ENTER button two times.
4. The display will read Breakaway. Press the UP ARROW button until the
display reads Reversing Edge .. I 3. Press the ENTER button. The cursor will
be flashing underneath the word Reversing edge. Press the UP ARROW button
to change this to Not assigned. Press Enter button. The second line should
read NO.
5. Press the ENTER button Twice. The cursor will go away.
6. Press the RESET button once to get back to the main menu. Push the RESET
button again to get the door ready to run. The display will read DOOR READY
and the cycle count.
7. The door is now ready to run.
10
InstructionsforActivatingtheReversingEdge(Wireless)
1.PressandholdtheRESET/MENUbuttonfor3–5seconds.
2.ThedisplaywillreadLIMITSETUP.PresstheUPARROW buttonuntilthe
displayreadsMODULECONFIGURATION.PresstheENTERbutton.
3.PresstheUPARROW buttonuntilthedisplayreadsMODZ…presstheENTER
buttontwotimes.
4.ThedisplaywillreadBREAKAWAY.PresstheUPARROWbuttonuntilthedisplay
readsNOTASSIGNEDI3.PresstheENTERbutton.Thecursorwillbeflashing
underneaththewordNOTASSIGNED.PresstheUPARROW buttontochangethisto
REVERSINGEDGE.PressENTER button.ThesecondlineshouldreadNOSecure.
5.PresstheENTERbuttontwice.Thecursorwillgoaway.
6.PresstheRESET buttononcetogetbacktothemainmenu.PushtheRESET
buttonagain.ThedisplaywillreadDOORREADY.
7.Thedoorisnowreadytorun.
11
InstructionsforDe‐ActivatingthePE1input(FrontPhotoeye)
1.PressandholdtheRESET/MENUButtonfor3–5seconds.
2.ThedisplaywillreadLIMITSETUP.PresstheUPARROW buttonuntilthedisplay
readsMODULECONFIFURATION.PresstheENTER button.PresstheUPARROW
buttonuntilthedisplayreadsMODB…presstheENTER buttontwotimes.
3.ThedisplaywillreadPHOTO1(Front).
4.PresstheENTER buttonuntilthecursorisflashingunderneaththewordPHOTO
1(FRONT).PresstheUPARROWbuttonuntilthedisplayreadsNOTASSIGNED.
5.PresstheENTER button
6.Thecursorwillbeblinkinginthelowerlefthandcorner.
‐IfthedisplayreadsNCatthecursor,presstheUPARROW buttontochange
thistoNO.
‐IfthedisplayreadsNOatthecursor,gotothenextstep
7.PresstheENTER button.ThecursorwillgoawayandthedisplaywillreadNOT
ASSIGNEDandNOinlowerleftcorner.
8.PresstheRESETbuttontwotimestogetbacktothemainmenu.PushtheRESET
buttonagaintogetthedoorreadytorun.ThedisplaywillreadDOORREADY.
9.ThedoorisnowreadytoRUN.
12
Instructions for re-activating the PE1 (FRONT)
1. Press and hold the Reset/Menu button for 3-5 seconds.
2. The display will read LIMIT SETUP. Press the UP ARROW button until the
display reads MODULE CONFIGURATION. Press the ENTER button.
3. Press the UP ARROW button until the display reads MOD B… Press the
ENTER button two times.
4. The display will read Not Assigned. Press the ENTER button.
5. Press the UP arrow button until Photo 1(front) is displayed. Press enter
.
6. The cursor will be flashing under the NO in lower left hand corner, press the UP
ARROW button and change to. NC. Press Enter .
7. Press the RESET button two times to get back to the main menu. Push the
RESET button again to get the door ready to run. The display will read
DOOR READY and the cycle count.
13
InstructionsforDe‐ActivatingthePE2(RearPhotoeye)
1.PressandholdtheRESET/MENUbuttonfor3‐5seconds.
2.ThedisplaywillreadLIMITSETUP.PresstheUPARROWbuttonuntilthedisplay
readsMODULECONFIGURATION.PresstheENTERbutton.
3.PresstheUPARROWbuttonuntilthedisplayreadsMODB…PresstheENTER
buttontwotimes.
4.ThedisplaywillreadPHOTO1(FRONT).PresstheUPARROWbuttontochange
thistoPHOTO2(REAR).
5.PresstheENTERbuttonuntilthecursorisflashingunderneaththewordPHOTO2
(REAR).PresstheUP buttontochangethistoNOTASSIGNED.PressENTER .
6.Thecursorwillbeblinkinginthelowerlefthandcorner.
IfthedisplayreadsNCatthecursor,presstheUParrowbuttontochangethisto
NO.
IfthedisplayreadsNOatthecursor,gotothenextstep.
7.PresstheENTERbutton.ThecursorwillgoawayandthedisplaywillreadNOT
ASSIGNEDandNOinthelowerleftcorner.
8.PresstheRESETbuttontwotimestogetbacktomainmenu.PushtheRESET
buttonagaintogettothedoorreadytorun.ThedisplaywillreadDOORREADY.The
doorisnowreadytorun.
14
Instructions for re-activating the PE2 input
1. Press and hold the Reset/Menu button for 3-5 seconds.
2. The display will read LIMIT SETUP. Press the UP ARROW
b
utton until the
display reads MODULE CONFIGURATION. Press the ENTER button.
3. Press the UP ARROW button until the display reads MOD B… Press the
ENTER button two times.
4. The display will read Photo 1 (Front).
5. Press the UP ARROW button until Not Assigned I2 is displayed. Press
ENTER .
6. Press the UO ARROW button until the display reads Photo 2 (REAR) Press
ENTER .
7. The lower left hand corner The cursor will be flashing under NO. Press the UP
ARROW button and change to NC, press ENTER .
8. Press the RESET button two times to get back to the main menu. Push the
RESET button again to get the door ready to run. The display will read
DOOR READY and the cycle count. The door is now ready to run.
15
Instructions for adjusting defrost heat cycle time
1. Press and hold the Reset/Menu button for 3-5 seconds.
2. The display will read LIMIT SETUP. Press the UP ARROW button until
the display reads MODULE CONFIGURATION. Press the ENTER
b
utton.
3. The display will read MOD A SAFETY. Press the DOWN ARROW button
until the display reads MOD H DEFROST. Press the ENTER button 2
times.
4. The display will read DEFROST INHIBIT. Press the UP ARROW button
until the display reads DEFROST HEATER. Press the ENTER button 3
times.
5. You want the word that the cursor is blinking underneath to be CYCLE. Press the
UP ARROW button until you get to CYCLE. Press the ENTER
button.
6. Press the RESET button until the display reads MODULE
CONFIGURATION.
7. Press the UP ARROW button until the display reads SET TIMERS. Press
the ENTER button.
8. The display will read OPEN RUN TIMER. Press the DOWN ARROW
button until the display reads DEFROST CYCLE ON. Press the ENTER
button.
9. The cursor will be flashing on the number in the lower RH corner of the display.
This is the time in minutes that the defrost heat will stay on. Pressing the UP
ARROW and DOWN ARROW buttons will change the time. Press
the ENTER button once the desired time is reached.
16
10. The display will read DEFROST CYCLE ON. Press the UP ARROW button.
Until the display reads DEFROST CYCLE OFF. Press the ENTER button.
11. The cursor will be flashing on the number in the lower RH corner of the display.
This is the time in minutes that the defrost heat will stay off.
Pressing the UP ARROW and DOWN ARROW will change the time.
Press the ENTER button once the desired time is reached.
12. Push the RESET button once to get back to the main menu.
Push the RESET button again to get the door ready to run. The display will read
DOOR READY and the cycle count. The door is now ready to run.
17
Instructions for operating the blower only when the door is closed
1. Press and hold the Reset/Menu button for 3-5 seconds.
2. The display will read LIMIT SETUP. Press the UP ARROW button until
the display reads MODULE CONFIGURATION. Press the ENTER
button. The display will read MOD A…
3. Press the UP ARROW button until the display reads MOD H DEFROST.
Press the ENTER button 2 times.
4. Press the UP ARROW button until the display reads O3…. in the upper right
hand corner. Press the ENTER button.
5. The cursor will be flashing underneath the first letter of the first word in the upper
left hand corner. Press the UP ARROW button until the display reads
DOOR NOT CLOSED.
6. Press the ENTER button, the cursor will be flashing under NO. Press the
UP ARROW button to change this to NC.
7. Press the ENTER button, the cursor should not be flashing.
8. Press the RESET button until the display reads DOOR READY.
18
Table of contents
