Alberici Timebox S User manual

ACTIVE ONE ALBERICI Istruzioni Originali
Rev. 1.00 Pagina 1
Operator’s manual
A
B
Timebox S 1-line pay-for-time system
Operator
’
s
manual
Rev. 1.03

2
This manual has been prepared with the utmost care. Nevertheless, it is not
possible to assure at any time the exact correspondence of the descriptions to the product features.
Alberici SpA shall not be held liable by the User for any damage, losses, or third party claims
arising from any uses of the manual or of the product.
NOTICE

ACTIVE ONE ALBERICI Istruzioni Originali
Rev. 1.00 Pagina 3
CONTENT
1. Package content............................................................................................................................4
2. Product description ......................................................................................................................4
3. Size...............................................................................................................................................5
4. Electrical connections..................................................................................................................5
5. Operation......................................................................................................................................7
6. Disposal of the product ................................................................................................................7
7. Terms of Guarantee......................................................................................................................7
8. Customer Service.........................................................................................................................7
STORICO REVISIONI
Revisione n°
Data
Modifica
Note
Creazione 1.00 06.11.08 Creazione
Rev. 1.01 12.03.10 Aggiunto comando a contatto pulito
Rev. 1.02 23.06.14 Scheda MKII
Rev. 1.03 22.07.15 Cambio frontespizio

4
Dear Customer,
we would like to thank you and congratulate for your choice. We trust that you will appreciate the quality and
performace of the Alberici TIMEBOX S.
This unit operates by cctalk protocol, the serial communication mode that provides security and precision.
1. Package content
The set includes:
1. Timebox unit
2. This manual
This product has been packed with the utmost care. If you receive it damaged or incomplete, please notify immediately
your findings to the Carrier, and collect it only under conditional signature.
2. Product description
2.1 Intended use
The TIMEBOX allows to purchase a pay-for-time service. Price for service can be set at any time, by programming the
included electronic coin acceptor, by using K-P2C-000002 programming kit. In the same way, service time can be set
from 100 msec (pulse) up to several hours (time span). The programming software allows to set the time as fixed time
span against credit, or as time accumulator according to the additional coins introduced during operation.
The unit can be installed outdoor, provided it is located in a position conveniently sheltered from unfavourable weather
conditions.
2.2 Available functions
- Payment and automatic activation of service
- Accounts audits from coin acceptor software
- Ad libitum Custom configuration of price and time
2.3 General specs
Size:
Weigh:
Power supply:
Highest current at relay contacts:
Working temperature:
Installation:
Components:
Coin acceptor
Interface service board
125 mm x 116 mm x 390 mm
5,50 Kg.
230Vac or 24Vac or +24Vdc or 12Vdc (must be detailed when placing the order)
8 Amps
+10°C ÷ +50°C (humidity 10% ÷ 70% non-condensed)
Wall-mount, indoor or outdoor (sheltered against water, sprays, direct sunlight
AL55S, programmed as Timer (one-shot or progressive)
Servo-board MKII
2.4 Caution
1 - Comply with the instructions in this manual
2 - Switch power off before any maintenance operation
3 - Use only within the recommended temperature/humidity range
4 - Do not expose the machine to direct sun light,
5 - Do not favour contact with dusts or chemical moisture or sprays, water or other liquids
8 - Wipe clean by a dry piece of cloth (or slightly wet with alcohol)
9 - Do not use thinners or organic solvents
Please read carefu
lly this handbook, to obtain the most from your
TIMEBOX S Unit

ACTIVE ONE ALBERICI Istruzioni Originali
Rev. 1.00 Pagina 5
3. Size
4. Electrical connections
Electrical cables must not be powered during installation!
The TIMEBOX S is available for 4 different power supply values: 230Vac, 24Vac, 24Vdc, 12Vdc. When
placing your orders, please specify which presetting you need: the interface Servo-board shall be prepared
accordingly.
The interface Servo-board is used to produce 12Vdc power to the coin acceptor, and to provide as well the relay dry
contact when the coin acceptor sends out the credit signal.
A 10p flat cable connects the acceptor to the Servo-board.
This one is also connected to the Timebox chassis by a Ground terminal.
Power the Servo-board on the 3p socket J1, according to the following pattern:
230 Vac 24Vac 24Vdc 12Vdc
Pin 3: line 230Vac line24Vac +24Vdc +12Vdc
Pin 2: neutral neutral 0Vdc 0Vdc
Pin 1: GND GND
It is possible to disable coin acceptance in any of the following two ways:
a) Electronically - Pins 7/8 of green connector J2: provide any Vdc (+) or Vac (line value) to pin 7, and
respectively 0Vdc (-) or Neutral Vac to pin 8.
b) Mechanically - move to OFF the dip-switches located on the coin acceptor. Move them back to ON when
you want to resume coin acceptance.

6
Connections to start the equipment by relay transmission of power supply:
Connect one end from power supply straight to the actuator i.e electrical motor, solenoid, a.s.o.). Connect the other one
to pin 1 (COM 1) of J2 connector.
If operation mode is “normally open”, take a wire to the actuator from pin 2 (N.O. 1). These wires must be able to
sustain 10 Amps current draw.
If operation mode must be “normally closed”, take a wire to the actuator from pin 3 (N.C. 1).
Connections to start the equipment by one clean relay switch:
Take a wire to the actuator from pin 1 (COM 1) of the J2 connector.
If operation mode is “normally open”, take another wire to the actuator from pin 2 (N.O. 1).
If operation mode must be “normally closed”, take such wire from pin 3 (N.C. 1).
To/from pulse
coin validator
signal on PIN10
OUT 1: LINE A, N.O.
IN 1: C1 LINE A
OUT 2: LINE B, N.O.
IN 2: C2 LINE B
DISABLE: Vac L or Vcc +
DISABLE: Vac N or Vcc -
POWER IN:
GND
(ac)
POWER IN: 230Vac, or
24Vac, or +24Vdc, or +12Vdc
POWER IN: N (ac) or - (dc)
OUT 2: LINE B, N.
C
.
OU
T
1
: LINE
A
, N.
C
.
POWER TO
EQUIPMENT:
230Vac, or 24Vac, or
+24Vdc, or +12Vdc
To/from pulse
coin validator:
signal on PIN10
OUT 1: LINE A, N.O.
IN 1: C1 LINE A
OUT 2: LINE B, N.O.
IN 2: C2 LINE B
POWER IN:
GND
(ac)
POWER IN: 230Vac, or
24Vac, or +24Vdc, or +12Vdc
POWER IN: N (ac) or - (dc)
OUT 2: LINE B, N.
C
.
OUT
1
: LINE
A
,
N.
C
.
EQUIP
MENT
INH –
INH +
N.C. 2
N.O. 2
COM 2
N.C. 1
N.O. 1
COM 1
INH –
INH +
N.C. 2
N.O. 2
COM 2
N.C. 1
N.O. 1
COM 1
+ / L
- / N
GND
+ / L
- / N
GND
DISABLE: Vac L or Vcc +
DISABLE: Vac N or Vcc -
EQUIPMENT

ACTIVE ONE ALBERICI Istruzioni Originali
Rev. 1.00 Pagina
5. Operation
Drop coins in until the credit value demanded for starting service is obtained.
When totalizing the requested amount, the coin accepot will start a pulse signal that will generate current
passage between COM1 and N.O.1, while switching open between COM1 and N.C.1.
The pulse will last as long as the time programmed in the coin acceptor, corresponding to the service price
set. The relay contacts will remain activated as long as such pulse lasts.
6. Disposal of the product
WARNING! DISPOSE OF ACCORDING TO THE GOVERNING LAW IN YOUR
COUNTRY!
This equipment may not be treated as household waste. Instead, it must be handed over to
the applicable collection point for the recycling of electric and electronic equipment. By
ensuring that this product is dised of correctly, you will help to prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product.
For more detailed information about recycling of this product, please contact the Dealer
where you purchased this product.
7. Terms of Guarantee
The manufacturer will fix malfunctions arising from production faults in this machine or parts of it within 12 months
from the date of sale.
All communications referring to guarantee repairs or replacements must be accompanied by the product serial number
and the copy of the sale invoice.
To obtain your guarantee repair, please send the part to the Dealer where you purchased the machine, together with the
following documents:
- copy of the sale invoice
- delivery note stating “returned for guarantee repair”
- detailed report of the problem found and the circumstances in which it occurs.
Before sending the product, please get in touch with your Dealer or with Alberici S.p.a. ([phone]); very
malfunctions can be fixed via a simple phone call, saving you costs and time.
Alberici S.p.a. will verify that warranty is applicable, i.e. that problem is not caused by:
- transport damages
- damages from incorrect installation or wrong configuration
- installation in premises or areas not complying with the prescribed safety requirements
- intentional or unwilled tampering
- wrong or careless use or maintenance
- non-compliance with precautions prescribed (see Chapter 4. Caution)
- natural disasters, vandalisms, intentional or unintentional damage
Guarantee is considered automatically expired if outer and inner labels are missing.
Transport costs of repaired products are at the Customer’s charge.
8. Customer Service
Alberici S.p.a. will be pleased to offer all the necessary information on use, ordinary maintenance and technical service.
Please call ([phone] and specify if your request concerns information on use or technical support.

8

ACTIVE ONE ALBERICI Istruzioni Originali
Rev. 1.00 Pagina 9

10

ACTIVE ONE ALBERICI Istruzioni Originali
Rev. 1.00 Pagina 11
Alberici S.p.A. reserves the right to modify at any time and without notice the
technical specs of the unit, to the aim of continually pursuing the improvement of the product.
NOTICE

12
®
Progettazione e produzione di sistemi di pagamento, accessori per videogames e macchine vending
Design and manufacture of payment systems, accessories for videogames and vending machines
Via Ca’ Bianca 421
40024 Castel San Pietro
Terme (BO) – ITALY
Tel. + 39 051 944 300
Fax. + 39 051 944 594
http://www.alberici.net
[email protected]
