OmniSwitch 10K
OmniSwitch 10K Front Panel
The Alcatel-Lucent O niSwitch 10K (OS10K) is a high-
capacity, high-perfor ance odular Ethernet LAN switch
based on the state-of-the-art Alcatel Operating Syste (AOS).
The OS10K’s class-leading low-power consu ption, front-to-
back cooling, co pact for -factor, and all front-accessible
co ponents ake it a perfect fit for data center applications,
as well as a long-ter upgrade for legacy core platfor s.

2 OmniSwitch 10K October 2010
Related Documentation
The following user docu entation is provided for the
O niSwitch 10K.
• OmniSwitch 10K Getting Started Guide
Describes the procedures for getting an O niSwitch
10K up and running. Also provides infor ation on
funda ental aspects of hardware co ponents and
basic setup co ands.
• OmniSwitch 10K Hardware Users Guide
Technical specifications and procedures for the
O niSwitch 10K chassis, power supplies, fans,
Chassis Manage ent Modules (CMMs), Chassis
Fabric Modules (CFMs) and Network Interface (NI)
odules.
• OmniSwitch CLI Reference Guide
Co plete reference to all CLI co ands supported on
the O niSwitch 10K. Includes syntax definitions,
default values, exa ples, usage guidelines, and
CLI-to-MIB variable appings.
• OmniSwitch AOS Release 7 Switch anagement Guide
Includes procedures for readying an individual switch
for integration into a network. Topics include software
directory architecture, i age rollback protections,
authenticated switch access, anaging switch files,
syste configuration, SNMP, and WebView
anage ent software.
• OmniSwitch AOS Release 7 Network Configuration
Guide
Includes network configuration procedures and
descriptive infor ation on all the ajor software
features and protocols included in the base software
package. Chapters cover Layer 2 infor ation (Ethernet
and VLAN configuration), Layer 3 infor ation
(routing protocols, such as RIP and VRRP), security
options (authenticated switch access), Quality of
Service (QoS), link aggregation, and server load
balancing.
• OmniSwitch AOS Release 7 Advanced Routing
Configuration Guide
Includes network configuration procedures and
descriptive infor ation on advanced routing protocols
such as OSPF, BGP, DVMRP and PIM-SM.
• OmniSwitch AOS Release 7 Transceivers Guide
Includes infor ation on S all For Factor Pluggable
(SFP) and 10 Gbps S all For Factor Pluggable
(SFP+) transceivers.

October 2010 Installing the Hardware 3
Items Required
• Grounding wrist strap (included)
• Phillips screwdriver
• Flat-blade screwdriver
• Serial cable
Site Preparation
Environmental Requirements
O niSwitch 10K switches have the following environ ental
and airflow require ents:
• The installation site ust aintain a te perature
between 0° and 45° Celsius (32° and 113° Fahrenheit)
and not exceed 95 percent axi u hu idity (non-
condensing) at any ti e.
• Be sure to allow adequate roo for proper air
ventilation at the front, back, and sides of the switch.
Refer to “Mounting the Switch” on page 5 for
ini u clearance require ents. No clearance is
necessary at the top or botto of the chassis.
Electrical Requirements
O niSwitch 10K switches have the following general
electrical require ents:
• Each switch requires one grounded electrical outlet for
each power supply installed in the chassis.
O niSwitch 10K switches offer both AC and DC
power supply support. Refer to the OmniSwitch 10K
Hardware Users Guide for ore infor ation.
• For switches using AC power connections, each
supplied AC power cord is 2 eters (approx. 6.5 feet).
Do not use extension cords.
Redundant AC Power. It is reco ended that each AC
outlet resides on a separate circuit. With redundant AC, if
a single circuit fails, the switch’s re aining power
supplies (on separate circuits) can re ain operational.
• For switches using DC power, refer to the OmniSwitch
10K Hardware Users Guide for ore infor ation.
Installing the Hardware

4 Installing the Hardware October 2010
Unpacking and Installing the Switch
To protect your switch co ponents fro da age, read all
unpacking reco endations and instructions carefully before
beginning.
Unpack your O niSwitch 10K chassis as close as possible to
the location where it will be installed.
Items Included
Your O niSwitch 10K includes the following ite s:
• O niSwitch chassis with factory-installed power
supplies, per order
• CMM odule(s), per order
• CFM odule(s), per order
• NI odules, per order
• Transceivers, per order
• Blank cover panels, if applicable
• Grounding wrist strap
• RJ45-to-DB9 console adapter
• Country-specific power cord(s)
• Hard copy of the OmniSwitch 10K Getting Started
Guide
Weight Considerations
The e pty O niSwitch 10K chassis weighs approxi ately
46 lbs (21 Kgs). When fully populated (i.e., with co ponents
installed in all available chassis slots), the O niSwitch 10K
can weigh up to approxi ately 200 lbs (90.5 Kgs).
Lifting the Chassis
Lifting the chassis requires two people. When lifting, use the
recessed hand grip provided on the rear panel and the
reinforced area i ediately under the front air intake plenu .
Chassis Cross Section
Note. Lifting the O niSwitch 10K chassis i properly can
cause personal injury and/or da age to the unit.
Grip
Grip

October 2010 Installing the Hardware 5
Airflow Considerations
To ensure proper airflow, be sure that your switch is placed in
a well-ventilated area and provide ini u reco ended
clearance at the front, back and sides of the switch.
Chassis Top View
Never obstruct the air intake vents located at the botto -front
and botto -sides of the chassis or the fan unit’s air output
vents located at the rear of the chassis.
Note. Clearance is not required at the top and botto of
the chassis.
Mounting the Switch
Rack Mounting
Refer to the following i portant guidelines before installing
the chassis in a rack:
• Three people are required to rack ount the switch:
Two people to lift the chassis into position and one
person to secure the chassis to the rack using the rack
ount screws.
• The chassis has two integral rack- ount flanges that
support standard 19-inch rack ount installations.
• Alcatel-Lucent does not provide rack- ount screws.
Use the screws supplied by the rack vendor.
• To prevent a rack fro beco ing top heavy, it is
reco ended that you install the switch at the botto
of the rack whenever possible.
• If you are installing the switch in a relay rack, be sure
to install and secure the rack per rack anufacturer’s
specifications.
Note. Due to its weight and airflow require ents, the
O niSwitch 10K cannot be wall- ounted.
}
}
Rear. 6 inches ini u
at rear of chassis.
Front. 6 inches ini u
at front of chassis.
Sides. 2 inches ini u
at left and right sides.

6 Installing the Hardware October 2010
To rack ount the switch, follow the steps below.
1 Mark the holes on the rack where the chassis is to be
installed.
2 Using two people, lift and position the chassis until the
rack- ount flanges are flush with the rack post. Refer to
page 4 for infor ation on properly lifting the chassis.
3 Align the holes in the flanges with the rack holes
arked in step 1.
4 Once the holes are aligned, use a third person to insert
a screw through the bottom hole on each flange. Tighten
both screws until they are secure.
5 Once the screws at the botto of each flange are
secure, install the re aining screws. Be sure that all
screws are securely tightened.
Optional Rack-Mounting Hardware
All O niSwitch 10K switches are shipped with integral front
rack ount flanges. These flanges support standard 19” rack
ount installations. If you have non-standard rack ount
require ents, contact your Alcatel-Lucent representative for
infor ation on optional hardware availability.
Standalone (Non-Rack Mounted)
Installations
The chassis can also be placed un ounted on a stable, flat
surface as a standalone unit. Be sure that the surface can
acco odate the full, populated weight of all switches
being installed. Approxi ate chassis weights are provided
on page 4.
For a standalone unit, use two or ore people to ove and
position the unpopulated chassis upright on the surface
where it is to be installed. Be sure that adequate clearance
has been provided for chassis airflow and that you have
placed the chassis within reach of all required AC outlets.
For reco ended airflow allowances, refer to page 5.
Note. Chassis ust be placed “right side up.” Never
atte pt to operate a switch while it is lying on its side or
back.

October 2010 Installing the Hardware 7
Installing Chassis Components
lectrostatic Discharge ( SD) Notice. Be sure to follow
proper procedures to eli inate electrostatic discharge
(ESD) fro your person and the surrounding area before
installing chassis co ponents.
Blank Cover Plates
Blank cover plates are factory-installed in the chassis and are
used to cover e pty CMM, CFM and NI slots, as well as
e pty power supply and fan bays. These cover plates play an
i portant role in chassis airflow and te perature anage ent.
They also provide protection for odule processor boards and
other sensitive internal switch co ponents by closing off a
chassis that is not fully populated.
Because they regulate airflow and help protect internal chassis
co ponents, blank cover plates should re ain in place at all
ti es.
Installing CMM, CFM and NI Modules
Before installing odules in the O niSwitch 10K, locate their
slot positions in the chassis. Slot nu bers are clearly arked
on the O niSwitch 10K front panel.
CMM odules ay be installed in slots A and B. If two CMM
odules are installed in a chassis, the CMM occupying slot A
is the pri ary CMM by default. CFM odules ay be
installed in slots C and D. NI odules ay be installed in slots
1 through 8.
To install an CMM, CFM or NI odule, follow the steps
below:
1 Insert the odule into the slot along the chassis card
guides. The co ponent side of the board should face right.
The odule should slide in easily.

8 Installing the Hardware October 2010
Note. Do not force the odule into the slot. If any
resistance is encountered, ake sure the odule is aligned
properly in the card guides.
2 When the odule is nearly seated in the slot, be sure
that the two extractor levers—one on top of the odule
and one on the botto —are open (approxi ately 90
degrees). This allows the notch on each extractor lever to
grasp the rail on the chassis.
3 Once the notches have grasped the rail, press both
extractor levers inward si ultaneously until the odule is
fir ly seated.
4 Once the odule is fir ly seated, secure the odule to
the chassis by tightening the two captive screws.
Installing Transceivers
For detailed infor ation on installing transceivers, refer to the
OmniSwitch AOS Release 7 Transceivers Guide.
Installing Fan Trays
1 Insert the tray into the chassis slot and slide it straight
back until it eets the chassis backplane connectors.
2 When the fan tray is fir ly seated, tighten the two
captive screws at the left and right sides of the fan tray’s
front panel.

October 2010 Installing the Hardware 9
Installing Power Supplies
1 Orient the power supply so that the power cord socket
is situated at the right of the power supply. Also, for the
power supply to seat properly, ake sure that the handle is
in the open (horizontal) position as shown.
2 Slide the power supply back until its connector eets
the chassis backplane.
3 When the power supply is fully seated, rotate the
handle 90 degrees to the closed (vertical) position.
4 Tighten the captive screw, located at the top-left of the
power supply’s front panel.
5 Plug the power cord (provided) into the power supply’s
socket.
6 Place the cord retainer bracket over the power supply.

10 Installing the Hardware October 2010
7 Secure the bracket to the botto rail of the chassis
using the captive screw. The bracket’s prongs should hold
the power cord securely in place.
8 Repeat steps 1 though 7 for any additional power
supplies being installed.
Important. Do not plug any power cords into a power
source at this ti e as this will boot the chassis.
Connecting the power cord(s) to a power source and the
switch’s boot sequence are covered on page 12.

October 2010 Connections and Cabling 11
Once your switch is properly installed, you should connect all
network and anage ent cables required for your network
applications. Connections ay include:
• RJ-45 straight-through cable to the console port
• Ethernet cable to the Ethernet Manage ent Port
(EMP) on the CMM
• Cables to NIs or transceivers
Serial Connection to the Console Port
The console port, located on the CMM odule, provides a
serial connection to the switch and is required when logging
into the switch for the first ti e. By default, this RJ-45
connector provides a DCE console connection.
Serial Connection Default Settings
For infor ation on odifying these settings, refer to the
OmniSwitch AOS Release 7 Switch anagement Guide.
Ethernet Management Port (EMP)
Cable Requirements
There are specific cable type require ents (i.e., straight-
through or crossover) based on the location of the Ethernet
Manage ent Port (EMP) and the type of device to which it is
connecting. Refer to the infor ation below:
For infor ation on anually configuring Ethernet ports for
cabling require ents, refer to the OmniSwitch AOS Release 7
Network Configuration Guide.
For detailed infor ation on all port types, including console,
EMP, Gigabit Ethernet, and 10 Gigabit Ethernet, refer to the
OmniSwitch 10K Hardware Users Guide.
Connections and Cabling
baud rate 9600
parity none
data bits (word size) 8
stop bits 1
MP to a Switch Straight-through
MP to a Computer or
Workstation
Crossover

12 Booting the Switch October 2010
Now that you have installed the switch co ponents and
connected network and anage ent cables, you can boot the
switch. To boot the switch, plug all power supply cords into
easily-accessible, properly grounded power outlets. (Do not
use extension cords.) The switch will power on and boot
auto atically.
Note. If you have ore than one power supply installed,
be sure to plug in each power supply in rapid succession,
(i.e., within a few seconds of each other). This ensures that
there will be adequate power for all odules throughout
the boot process.
Component LEDs
During the boot process, co ponent LEDs will flash and
change color, indicating different stages of the boot. Following
a successful boot, the LEDs on all switch co ponents,
including power supplies, should display as follows:
Note. If a secondary CMM is installed in the chassis
(typically in slot B), its CMM CONTROL LED should be
blinking green.
If the LEDs do not display as indicated, ake sure the boot
process is co pleted. If the LEDs do not display as indicated
following a co plete boot sequence, contact Alcatel-Lucent
Custo er Support. For infor ation on fan tray LED states,
refer to the OmniSwitch 10K Hardware Users Guide.
Once the switch has co pletely booted and you have accessed
your co puter’s ter inal e ulation software via the console
port, you are ready to log in to the switch’s Co and Line
Interface (CLI) and configure basic infor ation. Continue to
“Your First Login Session” on page 13.
Booting the Switch
CMM OK1 Solid Green
CMM OK2 Blinking Green
CMM CONTROL Solid Green
CMM FABRIC Solid Green
CMM T MP Solid Green
CFM OK1 Solid Green
CFM OK2 Blinking Green
NI OK1 Solid Green
NI OK2 Blinking Green
Power Supply AC Solid Green
Power Supply DC Solid Green

October 2010 Your First Login Session 13
In order to co plete the setup process for the switch, you ust
co plete the following steps during your first login session:
• Log in to the switch
• Set IP address infor ation for the Ethernet
Manage ent Port (EMP)
• Unlock session types
• Change the login password
• Set the date and ti e
• Set optional syste infor ation
• Save your changes
Important. You ust be connected to the switch via the
console port before initiating your first login session.
Logging In to the Switch
When you first log in to the switch, you will be pro pted for a
CMM login na e and password. Use the switch’s default
settings:
• CMM login: admin
• Password: switch
The default welco e banner, which includes infor ation such
as the current software version and syste date, is displayed
followed by the CLI co and pro pt:
+++ WARNING! Switch Access Vulnerability.
+++ WARNING! Admin user authentication using
de ault password.
Welcome to the Alcatel-Lucent OS10K
7.1.1.1198.R01, October 15, 2010.
Copyright (c) 1994-2010 Alcatel-Lucent. All
Rights Reserved.
OmniSwitch(tm) is a trademark o Alcatel-Lucent,
registered in the United States Patent and
Trademark O ice.
->
Your First Login Session

14 Your First Login Session October 2010
More Information On User Accounts. A user account
includes a login na e, password, and user privileges.
Privileges deter ine whether the user has read or write
access to the switch and which co ands the user is
authorized to execute. For detailed infor ation on setting
up and odifying user accounts, refer to the OmniSwitch
AOS Release 7 Switch anagement Guide
Setting IP Address Information for
the EMP
The Ethernet Manage ent Port (EMP) is located on the CMM
odule. The EMP allows you to bypass the Network Interface
(NI) odules and anage the switch over the network directly
through the CMM.
In order to ping the switch through the EMP Ethernet
connection, you ust change the port’s default IP and gateway
addresses.
Note. You ust be connected to the switch via the console
port before atte pting to change IP address infor ation.
Otherwise, an error essage will display.
To change the default IP and gateway addresses, use the
ip interface co and. For exa ple:
-> ip inter ace emp address 168.22.2.120 mask
255.255.255.0
Verify your settings using the show ip interface co and.
Note. Although you have configured the EMP with valid
IP address infor ation, you will not be able to access the
switch through this port for Telnet, FTP, WebView, or
SNMP sessions until you have unlocked these re ote
session types. See “Unlocking Session Types” on page 14
for ore infor ation.
