Alcatel GO FLIP 4 User manual

USER MANUAL
www.us.alcatelmobile.com

2
About this Manual....................................................
Thank you for choosing the Alcatel GO FLIP4 device. In order to maintain your device in optimal
condition, please read this manual and keep it for future reference.

3
Table of Contents
1 Your Device ......................................................................................................................... 5
1.1 Overview................................................................................................................... 5
1.2 Setup.......................................................................................................................... 8
1.3 Home Screen .........................................................................................................10
2 About Your Phone ........................................................................................................... 11
2.1 Power on your phone ..........................................................................................11
2.2 Power off your phone..........................................................................................11
2.3 Charging..................................................................................................................12
2.4 Battery.....................................................................................................................12
3 Personalize Your Phone..................................................................................................13
3.1 Language.................................................................................................................13
3.2 Change font size ...................................................................................................13
3.3 Date & Time ...........................................................................................................13
3.4 Sounds.....................................................................................................................14
3.5 Wallpaper, Brightness and Screen Timeout....................................................15
4 Application ........................................................................................................................ 16
4.1 Phone.......................................................................................................................16
4.2 Contacts..................................................................................................................19
4.3 Messages ................................................................................................................23
4.4 Email.........................................................................................................................25
4.5 Camera ....................................................................................................................27

4
4.6 Gallery .....................................................................................................................28
4.7 Utilities ....................................................................................................................29
4.8 Clock ........................................................................................................................30
4.9 Music .......................................................................................................................31
4.10 Calendar..................................................................................................................31
4.11 Video........................................................................................................................33
4.12 Note .........................................................................................................................33
4.13 FM Radio ................................................................................................................34
4.14 File Manager ..........................................................................................................35
5 KaiOS Applications..........................................................................................................36
5.1 KaiOS-Store............................................................................................................36
6 Security ..............................................................................................................................37
6.1 Lock/Unlock your screen ....................................................................................37
6.2 SIM Security...........................................................................................................37
6.3 Anti-Theft ...............................................................................................................37
7 Account..............................................................................................................................38
7.1 KaiOS Account.......................................................................................................38
7.2 Software Update...................................................................................................39
8 Safety and Regulatory Information .............................................................................40
9 Troubleshooting ............................................................................................................... 50

5
1 Your Device.......................................................
1.1 Overview
Camera
Charging Port
Headset Connector Volume Key
Microphone
External display

6
Center Soft Key
Left Soft Key
Call Key
Favorite Contacts
Right Soft Key
End/Power Key
Back/Delete Key
Messages
Navigation Key
(up, down, left, right)
Internal display

7
Left Soft Key
• Press: access Notifications
Right Soft Key
• Press: access Contacts
Center Soft Key
• Press: access app list (from the Home screen)
• Confirm an option from the middle of the bottom of the screen
Navigation Key
• Menu selection moves up, down, right, and left
• Press Left: access Applications
• Press Right: access Camera
• Press Up: access Ringtones & Alerts settings
Call Key
• Answer / make a call
• Press: enter call log (from the Home screen)
End/Power Key
• Press: end a call, return to the Home screen
• Press and hold: Restart or Power on/off
Back/Delete Key
• Move backwards through Menus
• Delete entered number or letter
Volume Keys
• In call mode, adjusts the earpiece or headset volume
• In Music/Video/Streaming mode, adjusts the media volume
• In general mode, adjusts the ringtone volume
• Mutes the ringtone of an incoming call

8
1.2 Setup
Remove the back cover
With the device facing down, remove the back cover from the bottom left corner. Use your
fingernail to carefully lift the cover away from the device body.
Inserting or removing Nano SIM card and microSD™
You must insert your Nano SIM card to make phone calls using your network.
MicroSDTM cards (up to 32GB) may be purchased separately.
NOTE: Power off the device before opening the back cover to install a microSD or replace the
NANO SIM card.
Insert a SIM or microSD card into the card slot with the gold-colored contacts facing down.
SIM card
SD card
SIM card
SD card
SIM card
SD card
SIM card
SD card

9
To remove the SIM card or microSD card, press down on the small plastic tab (①), then slide out
the card (②). Do not use force or use any sharp objects.
SIM card
SD card
SIM card
SD card
SIM card
SD card
SIM card
SD card
Your phone only supports Nano SIM cards. Do not attempt to insert other SIM types,
otherwise you may damage your phone.
Insert the battery
Insert the battery by aligning the gold contact points of the battery with the gold contact points
of the device. It only fits one way. Press down to snap in place.

10
Replace the back cover
Carefully align the back cover with tabs and press into place. It only fits one direction.
1.3 Home Screen
Status bar
• Status/Notification indicators
Press the Right Soft Key
to enter Contacts
Press the Center Soft Key
to access app list
Press the Left Soft Key
to show Notifications
Status Bar
From the status bar, you can view both phone status (to the right side) and notification
information (to the left side).

11
2 About Your Phone ...........................................
2.1 Power on your phone
Press and hold the End/Power Key until the phone powers on.
Setup your phone for the first time
The first time you power on the phone, you will be guided through the following steps:
• Select the phone's language, then press the Right Soft Key to go to the next step.
• Select an available Wi-Fi network, then press the Right Soft Key to go to the next step.
• Select Scheduled Install, then press the Right Soft Key to go to the next step.
• Read the KaiOS Terms and Privacy Policy, press the Center Soft Key to learn more and/
or open URL; Use the Navigation Key and the Center Soft Key to set options, then press
the Right Soft Key to go to the next step.
• Finally press the Center Soft Key to enter the Home screen.
Note: Even if no SIM card is installed, your phone will still power on and you will be able to
connect to a Wi-Fi network and use some of the phone's features.
2.2 Power off your phone
Press and hold the End/Power Key until the phone displays: Lock, Restart and Power Off.
Use the Navigation Key to select Power Off, then press the Center Soft Key .

12
2.3 Charging
Insert the small end of the charging cable into the charge port, and connect the charger to a
power outlet.
To reduce power consumption and energy waste, when the battery is fully charged,
disconnect your charger; switch off Wi-Fi, GPS or Bluetooth when not in use; reduce the
backlight time, etc.
2.4 Battery
To optimize your battery life, you may do the following:
Turn on power saving mode
• Go to Settings > Device > Battery > Power Saving Mode > On
Lower screen brightness
• Go to Settings > Personalization > Display > Brightness
• Lower the brightness by pressing the left of the Navigation Key
Screen timeout
• Go to Settings > Personalization > Display > Screen Timeout > 30 seconds

13
3 Personalize Your Phone..................................
3.1 Language
Your device default language can be set to either English or Spanish.
To change the language:
• From the Home screen, press the Center Soft Key , select Settings > Personalization
> Language > Language.
• Press the Navigation Key to select the preferred language.
• Press the Center Soft Key to confirm.
3.2 Change font size
To change the device font size:
• From the Home screen, press the Center Soft Key , select Settings > Personalization
> Display > Large Text.
• Press the Center Soft Key to select On/Off to enable or disable large text.
3.3 Date & Time
To change the Date & Time:
• From the Home screen, press the Center Soft Key , select Settings > Personalization
> Date & time.
• Press Time option to adjust the time and minutes. You may also adjust the Time Zone as well
as Time Format on this page.

14
3.4 Sounds
To adjust volume:
• Press the Volume Up/Down button that is located on the right side of the device to adjust
the Ringtone & Alerts volume.
• From the Home screen, press the Center Soft Key , select Settings > Personalization >
Sound > Volume to adjust the volume for Media, Ringtones & Alerts and Alarm.
To adjust Tones
• From the Home screen, press the Center Soft Key , select Settings > Personalization
> Sound > Tones.
• Under Tones, you may select your preference on Vibrate, Ringtones, Notification Alerts as
well as Manage Tones.
• Press the Center Soft Key to confirm.
To adjust Other Sounds
All other sounds that are related to Dial Pad or Camera can be adjusted by doing the following:
• From the Home screen, press the Center Soft Key , select Settings > Personalization
> Sound > Other Sounds.

15
3.5 Wallpaper, Brightness and Screen Timeout
To change Wallpaper
• From the Home screen, press the Center Soft Key , select Settings > Personalization
> Display > Wallpaper.
• Press Gallery to select from Images that are stored on your device.
• Press Camera to take a picture for the Wallpaper you would like to use/store.
• Press Wallpaper to select from pre-loaded Wallpapers.
To adjust Brightness
• From the Home screen, press the Center Soft Key , select Settings > Personalization
> Display.
• Press the Navigation Key to highlight Brightness.
• Select desired brightness by pressing the Left or Right of the Navigation Key.
To adjust Screen timeout
• From the Home screen, press the Center Soft Key , select Settings > Personalization
> Display > Screen Timeout.
• Select when you would like your screen to turn off, then press the Center Soft Key to
confirm.

16
4 Application ........................................................
4.1 Phone..............................................................................................
4.1.1 Making a Call
Dial the desired number then press the Call Key or the Center Soft Key to make the call.
If you make a mistake, you can delete the incorrect digits by pressing the Back/Delete Key
.
Press the Right Soft Key
to show more Options
Press the Center Soft Key
to Call the entered number
Press the Left Soft Key
to enter Contacts
Press the Right Soft Key to display more Options:
• Add to existing contact: Add the entered number to replace the existing contact number.
• Create new contact: Create a new contact with the entered number.

17
Make a call from your call log
From the Home screen, press the Call Key , or press the Center Soft Key > Call Log to
access the call log and choose the contact you want to dial, press the Call Key or the Center
Soft Key to make the call.
Make a call from Contacts
From the Home screen, press the Right Soft Key , or press the Center Soft Key > Contacts.
Choose the contact you want to dial, press the Call Key or the Center Soft Key twice
to call.
Making an emergency call
If your phone has network coverage, dial emergency number and press the Call Key to make
an emergency call. This works even without a SIM card and without typing the PIN code.
Make an International call
To dial an international call, press twice to enter “+” in dial screen, enter the international
country prefix followed by the full phone number, then press the Call Key or the Center
Soft Key to call.
Calling your voicemail (1)
Press and hold key to call and listen to your voicemail.
Setting up voice mail
1. Dial *86 and press the Call Key or the Center Soft Key .
2. When you hear a greeting, press to interrupt.
3. Follow the setup instructions.
Checking voice mail
From your phone:
1. Dial *86 and press the Call Key or the Center Soft Key .
2. Follow the instructions.
(1) Contact your network operator to check service availability.

18
From other phones:
1. Dial your wireless number.
2. When you hear the greeting, press to interrupt.
3. Follow the instructions.
4.1.2 Answering or rejecting a call
During an incoming call:
• Open the flip to answer, if Settings > Personalization > Answer Mode > Flip open to
answer is On. Otherwise,
• Press the Left Soft Key or Call Key to answer.
• Press the Right Soft Key or the End/Power Key to decline.
• Press the Center Soft Key to reject the call by sending a preset message.
• To mute the ringtone volume of an incoming call, press the Volume Up/Down Key.
4.1.3 Hang up a call
During a call:
• Open the flip and press the End/Power Key to end the call.
• Open the flip and close the flip to end the call.

19
4.2 Contacts...............................................................................
Contacts enables quick and easy access to the contact you want to reach.
From the Home screen, press the Center Soft Key and select Contacts to enter Contact
list.
4.2.1 Add a Contact
On the contacts list screen, use the Navigation Key and press the Left Soft Key to create a
New Contact and input the contact information.
When finished, press the Center Soft Key to save.
4.2.2 View a Contact
On the contacts list screen, use the Navigation Key to select a Contact, then press the Center
Soft Key to access the detail screen.
Press the Left Soft Key to send an SMS/MMS to the contact you selected.
Press the Center Soft Key to make a call.

20
Press the Right Soft Key to access Options:
• Add as Favorite(1): Add the contact as a Favorite number. You can view it in Contacts >
Favorite contacts list. After added, the menu shows Unfavorite.
• Edit/Share/Delete: Edit/Share/Delete the contact.
• Find duplicate contacts: Press the Center Soft Key to find duplicate contacts.
• Block this number: Press the Center Soft Key to show Confirmation information, once
confirmed, press the Right Soft Key to Block.
4.2.3 Edit a Contact
On the contacts list screen, using the Navigation Key to select a Contact, then press the Right
Soft Key to access Options, select Edit contact and press the Center Soft Key to edit.
When finished, press the Center Soft Key to save.
4.2.4 Share a Contact
You can share a single contact with others by sending the contact's vCard to them via Email,
Messages, or Bluetooth.
On the contacts list screen, use the Navigation Key to select a Contact, then press the Right
Soft Key to access Options, and then select Share.
(1) Only for Phone memory contacts.
