Alcatel TEMPORIS 22 User manual

TEMPORIS 12 /TEMPORIS 22
Tempori_22_uk.qxd 29/05/01 17:05 Page 1

1. SETUP
lPlug one end of the spiral cord into the handset plug (A), and the other end into the
socket located on the left-hand side of the phone (B).
lPlug the telephone cord into the socket (C) situated on the back of the set and plug
the other end (D) into the telephone wall socket.
NOTE: The spare socket (E) enables a modem to be connected.
lStick the emergency number label in the appropriate place.
2. WALL MOUNTING
To mount your telephone set on the wall, remove the wall mounting peg and put it back
inreversepositionasdescribedbelow.Boretwo6mm-largeholes,spaced70 mmapart.
Put two plugs in place, then, place in two screws (3.5 mm Ø and 25 mm long) without
tightening them.
Place the cord in the slot situated underneath the set.
BA
D
E
C
Wall mounted position Horizontal position
Tempori_22_uk.qxd 29/05/01 17:05 Page 2

FUNCTION KEYS
Peg for wall mounting Stick the phone number
label there
Loudspeaker
10 memories
Message
waiting lamp
Loudspeaker
key *
Loudspeaker and ringer *
sound level adjustment
Additional
services
access key
Memories
and set
programming
key
Redial/Pause
Mute key
* on TEMPORIS 22 only
Tempori_22_uk.qxd 29/05/01 17:05 Page 3

3. GENERAL USE
3.1 LINE LAMP / MESSAGEWAITING LAMP
This light flashes in rhythm with the ringing when you receive a call.It lights up as
soon as you take the line.
If you are connected to a private ALCATEL telephone system equipped with mail,
the message waiting lamp informs you of a message in your “mail box”.
Dialling can be done in two different ways:
lBy lifting the handset then dialling.
lBy dialling in on hook mode.
3.2 DIALLING IN ON HOOK MODE*
Press the loudspeaker key then dial your correspondent’s number.Go off hook to
establish the conversation.
3.3 LOUDSPEAKER KEY*
During a call, press the Loudspeaker key so that the people around you can hear
the conversation.
lAdjust the sound level with the and keys.
lDeactivate the loudspeaker by pressing the Loudspeaker key again.
3.4 HANDSET SOUND VOLUME*
Whentheloudspeakerisdeactivated,youcanincreasethehandsetsoundvolume.
lPress the key.
lTo return to the initial volume, press the key.
3.5 MUTE
lPresstheMutekey. Yourcorrespondentcannolongerhearyouduringthiswaiting
time.
l1 beep is generated on the line every 10 seconds.
lTo resume the conversation, press the Mute key again.
3.6 LAST NUMBER REDIAL
lGo off hook.
lPress the Last Number Redial key.
To erase the last number redial
lGo off hook.
lPress the Programming key twice.
lPress the Last Number Redial key.
3.7 ADDITIONAL SERVICES KEYS
Function keys allowing access to additional services. (Ask at your local Telecom
company or your fitter for information).
* OnTEMPORIS 22 only
BEEP
Tempori_22_uk.qxd 29/05/01 17:05 Page 4

4. USINGTHE MEMORIES
NOTE: When programming your TEMPORIS communicates with you using .
1 Beep :Whilst programming, each key pressed is validated by 1 .
2 Beeps : Indicate that your programming is correct.
3 Beeps : Something is wrong in your programming;Restart from the beginning.
Your telephone set can store 10 numbers of up to 24 digits.
4.1 PROGRAMMINGTHE MEMORIES
Programming without calling
lGo off hook.
lPress the Programming key.
lEnter the number.
lPress one of the ten memory keys.
Programming whilst calling
lGo off hook.
lEnter the number.
lPress the Programming key whether you are in conversation or not.
lPress one of the ten memory keys.
4.2 DIALLING FROM A MEMORY
lGo off hook.
lPress one of the ten memories keys.The loaded number is dialled automatically.
4.3 ERASING A MEMORY
lGo off hook.
lPress the Programming key twice.
lPress the key corresponding to the memory to be erased.
5. CHOOSING AND ADJUSTINGTHE RINGER
Youcan choose and adjust one of the four melodies availablewhen your telephone
is ringing, or at any time after entering the programming mode.
5.1 WHENYOUR TELEPHONE IS RINGING
Modification of the ringer can be carried out during a ringing phase.
lPress one of the keys 1,2, 3or 4to change the melody.
lTo reduce or increase ringing volume, press or on TEMPORIS 22 or
press or on TEMPORIS 12.
Your modifications are memorized, you can answer the call.
5.2 WHEN IN PROGRAMMING MODE
To access the programming mode:
lPress and hold keys 1and 3simultaneously.
lPick up the handset.
lRelease the keys.
lAccess to programming mode is confirmed by 1 beep.
BEEP
BEEP
BEEP
Tempori_22_uk.qxd 29/05/01 17:05 Page 5

To adjust the ringing:
lPress the Programming key then key 1(current melody is heard).
lTo reduce or increase ringing volume, press or on TEMPORIS 22 or
press or on TEMPORIS 12.
lPressing a key between 1and 4changes the melody.
To put ringer ON/OFF:
lPress the Programming key then key 0.
lPress to put the ringer OFF.When ringer is OFF, 4 BEEP are heard when
picking up the handset.
lPress to put the ringer ON.
lPut the handset on hook.
6. LOCKINGTHETELEPHONE SET
Thanks to a 4-digit password, your can:
lForbid access to the ringing tone programming.
lForbid access to the configuration for professional use.
lLimit calls to phone numbers of up to 6 digits maximum.
The initial password is 0000.
6.1 ACCESSINGTHE PROGRAMMING MODE
Your are offered 3 operations. For each of them, access the programming mode
again.
lPress and hold keys 4and 6simultaneously.
lPick up the handset.
lRelease the keys.
6.2 LOCKING / UNLOCKING
lPress the Programming key followed by 1.
Locking
lPress the key.
lGo on hook.
Unlocking
lPress the #key.
lEnter the password.
lGo on hook.
6.3 MODIFYING THE PASSWORD
Access the programming mode again and then:
lPress the Programming key followed by 2.
lEnter the current password. 2 beeps are generated.
lEnter the new 4-digit password. 2 beeps are generated.
lEnter it a second time.2 beeps are generated.
lPut the handset on hook.
BEEP
BEEP
Tempori_22_uk.qxd 29/05/01 17:05 Page 6

6.4 IFYOU FORGOTTHE PASSWORD
Access the programming mode again and then:
lPress the Programming key followed by 0.
lPress the *key.
l2 beeps are generated.
lGo on hook.
7. CONFIGURATION FOR PROFESSIONAL USE
IfyourTEMPORIS is connected directly to the public network, do not payattention
to this chapter.
7.1 ACCESSINGTHE PROGRAMMING MODE
Your are offered 3 operations. For each of them, access the programming mode
again.
lPress keys 1and 3simultaneously.
lGo off hook.
lRelease the keys.
7.2 TYPE OF DIALLING
lPress the programming key followed by 2.
For pulse dialling
lPress the key (or key)
lGo on hook.
For tone dialling
lPress the key (or key).
lGo on hook.
7.3 FLASH DURATION (R)
Access the programming mode again and then:
lPress the Programming key followed by 3.
lPress : 1 for a 80 ms flash,
2 for a 100 ms flash,
3 for a 180 ms flash,
4 for a 250 ms flash,
5 for a 300 ms flash,
6 for a 600 ms flash.
lGo on hook.
FThis last operation erases the WHOLE programming including
memories.
The password is 0000 again.
BEEP
BEEP
Tempori_22_uk.qxd 29/05/01 17:05 Page 7

8. GUARANTEE
lThis product is guaranteed according to the clauses offered by your distributor.
lTo get this guarantee you must use your telephone according to the instructions of the
user guide and you have to keep the invoice or ticket mentioning purchasing date and
distributor name.
lThe guarantee doesn’t apply in case of:
- problem due to abnormal use,
- telephone damaged by shocks or fall,
- telephone damaged by overvoltage, lighting, fire or water,
- maintenance by unauthorized person.
9. CUSTOMERS SERVICE
Thestorefromwhichyoubought the set is in a position to give youinformationand/orprovide
after-sales service.
This product is designed to be connected to an analog telephone line classified TNV3.
DECLARATION OF CONFORMITY
According the disposition of the directive 1999/5/EC of the European parliament and of the
council of 9 March 1999 on radio equipment and Telecommunications terminal equipment and
the mutual recognition of their conformity.
The certificate of conformity is available from the following Internet site:“www.atlinks.com”.
Sales and Marketing Departments:
41 boulevard de la République - Bât. B6 - 78400 Chatou - France
Ref : 3BQ 13197 AAAE 05/01
Head office: 46, quai Alphonse Le Gallo
92100 Boulogne Billancourt - France
An ALCATEL/THOMSON multimedia
Joint Venture Company
Engineered by
The manufacturer reserves the right to modify the specifications of its products in order to make technical improvements or comply with new regulations. Nanterre companies registry number: 390 546 059.
