Alcosec ACP10 User manual

ACP10
10 Zone Intruder Alarm System
Installation Manual

2 P0016-LI-00.00
Contents
1. System Overview ........................................... 4
System Configuration ............................................................. 4
Control Panel .......................................................................... 4
Remote Keypads .................................................................... 5
LED Remote Keypad.................................................................. 5
LCD Remote Keypad ................................................................. 5
USB-Link.................................................................................. 5
AlcoUDL Upload/Download Software .................................... 5
2. Installation..................................................... 6
Installation Sequence............................................................. 6
Control Panel .......................................................................... 6
Mounting .................................................................................... 6
Wiring the Control Panel ........................................................... 6
Control Panel Layout ................................................................. 7
PCB Layout ................................................................................. 8
Connecting Devices to the Network.......................................10
Remote Keypads ..................................................................11
PCB Layouts .............................................................................11
Wiring Detection Devices .....................................................11
Normally Closed.......................................................................11
Normally Open .........................................................................11
Single EOL - N/C ......................................................................12
Double EOL...............................................................................12
Triple EOL .................................................................................12
Loudspeaker Connections ...................................................12
External Sounder/Strobe Connections................................13
TR ..............................................................................................13
0V..............................................................................................13
+12 ...........................................................................................13
Bell (1) ......................................................................................13
Strobe (2) .................................................................................13
Panel Outputs 1 - 5...............................................................13
2-Wire Smoke Detectors ......................................................13
Telephone Line Connections................................................14
Commissioning .....................................................................14
Power-Up Options Menu..........................................................14
3. Programming the Control Panel ................ 15
Introduction...........................................................................15
Exiting Engineer’s Program Mode........................................15
Menu Navigation and Data Entry.........................................15
Selection List............................................................................15
Bit Toggle Selection .................................................................16
Number Entry ...........................................................................17
String Edit - Number Mode .....................................................17
String Edit - Text Mode ............................................................18
1. Zone Programming...........................................................18
Zone Type .................................................................................18
Zone Wiring ..............................................................................19
Zone Attributes ........................................................................19
Zone Bypass Options...............................................................20
Zone Chime ..............................................................................20
Zone Soak Test ........................................................................20
Zone Text..................................................................................20
Zone Link..................................................................................20
2. Arming Control..................................................................21
Arming Timers ..........................................................................21
Arming Modes ......................................................................... 21
Arm Options 1.......................................................................... 21
Arm Options 2.......................................................................... 22
Arm Keyswitch Control............................................................ 22
Auto Arm/Disarm .................................................................... 22
3. System Configuration....................................................... 23
System Timers......................................................................... 23
System Counters ..................................................................... 23
Hardware - Volume Levels...................................................... 23
Hardware - Output Monitoring ............................................... 24
Hardware - Monitoring ............................................................ 24
Configuration ........................................................................... 24
Control Timers ......................................................................... 24
Banner Text ............................................................................. 25
Voice Options........................................................................... 25
Activate by Link Control .......................................................... 25
Voice Message Options .......................................................... 25
System Links ........................................................................... 25
4. Keypad Configuration ...................................................... 26
Keypad Options 1.................................................................... 26
Keypad Options 2.................................................................... 26
Keypad Sounds ....................................................................... 26
5. Reserved........................................................................... 26
6. Panel Outputs and Devices ............................................. 27
Panel Output Type................................................................... 27
Panel Output Attributes .......................................................... 27
Output Types ........................................................................... 27
00: Global ................................................................................ 27
Group 02: Control Timer......................................................... 28
Group 03: PC Control.............................................................. 28
Group 04: Link Control ........................................................... 29
Group 20: Zone Mimic............................................................ 29
Group 30: Zone Alarm ............................................................ 29
Group 40: Zone Tamper ......................................................... 29
Group 50: Zone Masked......................................................... 30
Group 60: Zone Fault.............................................................. 30
Group 70: Zone Bypassed...................................................... 30
Group 80: User Access ........................................................... 30
Communication Ports ............................................................. 30
GSM Module............................................................................ 30
IP Module................................................................................. 30
7. Onboard Communicator .................................................. 31
ARC 1-4: Telephone Number.................................................. 31
ARC 1-4: Account Number...................................................... 31
ARC 1-4: Protocol .................................................................... 31
ARC 1-4: Protocol Options ...................................................... 31
ARC 1-4: Call Sequence/Attempts......................................... 31
ARC 1-4: Reported Event Groups........................................... 31
ARC 1-4: Cancel on Success .................................................. 32
ARC 1-4: PSTN Pre-Dial Number............................................ 32
ARC 1-4: IP Address ................................................................ 32
ARC 1-4: IP Port Number ........................................................ 32
Options: Auto Test Call Period................................................ 32
Options: Auto Test Call Time .................................................. 32
Fast Format: Reporting Channels.......................................... 32
Fast Format: Restore Channels ............................................. 33
Fast Format: Open/Close Channels ...................................... 33
Channel Type........................................................................... 33
Channel Attributes .................................................................. 33
Speech Dialler: Telephone Numbers 1 and 2 ...................... 34

P0016-LI-00.00 3
Speech Dialler: Dial Sequence ...............................................34
Speech Dialler: Trigger Type ...................................................34
UDL Options .............................................................................34
UDL Password ..........................................................................34
UDL Ring Count........................................................................34
Call-Back No.............................................................................34
UDL Dial Sequence..................................................................34
Remote IP Address ..................................................................35
Remote IP Port .........................................................................35
8. System Users....................................................................36
User Access Code ....................................................................36
User Type..................................................................................36
User Locked By ........................................................................36
User Name ...............................................................................36
User Link...................................................................................36
9. Utilities ..............................................................................37
Time and Date..........................................................................37
User Menus...........................................................................37
Away Arm A........................................................................37
Stay Arm 1 S......................................................................37
Stay Arm 2 2* ..................................................................37
Stay Arm 3 3* ..................................................................37
Walk Test 11* ................................................................37
Test Bell & Outputs 12* ................................................37
Do Test Call 13*.............................................................37
View Event Log 21* .......................................................37
Print Event Log 22* .......................................................37
Call UDL 23* ..................................................................37
Change Code 81* ..........................................................37
Program Mode 91* ....................................................... 37
Exit Menu 99* ............................................................... 37
Log Events ............................................................................ 38
LED Indications..................................................................... 40
Fault & Status Messages..................................................... 40
Resetting Faults & alarms...................................................... 40
4. Specifications.............................................. 41
Control Panel ........................................................................ 41
Electrical .................................................................................. 41
Environmental ......................................................................... 41
Physical .................................................................................... 41
LED Remote Keypad ............................................................ 41
Electrical .................................................................................. 41
Environmental ......................................................................... 41
Physical .................................................................................... 41
LCD Remote Keypad ............................................................ 41
Electrical .................................................................................. 41
Environmental ......................................................................... 41
Physical .................................................................................... 41
Standards ............................................................................. 41
Safety ....................................................................................... 41
EMC .......................................................................................... 41
Security .................................................................................... 41
Warranty ............................................................................... 41
Notes..................................................................................... 42
Notes..................................................................................... 43

4 P0016-LI-00.00
1. System Overview
System Configuration
Control Panel
The ACP10 control panel is an advanced intruder alarm system
with 10 on-board zones and on-board multi format communicator.
The system is ideally suited to domestic installations.
The ACP10 also supports a 4 channel speech dialler and voice
prompts which can be recorded via a touch tone telephone or by
using the AlcoUDL software.
Both systems support either LCD or LED remote keypads. Other
features include:
f10 programmable on-board zones
f5 programmable outputs (1Amp rated)
fOn-board communicator/modem
fLocal or remote upload/download
fAdvanced system diagnostics
f1.5 Amp switched mode power supply
fTwo communication ports for accessories etc
fLoudspeaker output
fSelectable battery charging rate
fReal time clock
fTwo-wire smoke detector support
fFlash upgradable

P0016-LI-00.00 5
Remote Keypads
The ACP10 will accept up to a maximum of 4 remote keypads. All
remote keypads require a 4-wire connection to the control panel
using standard alarm cable. The following remote keypad models
are available:
LED Remote Keypad
The LED keypad features a dual 7 segment display for displaying
zone status and system fault messages. A set of dedicated
system status LEDs for AC, Ready, Armed, Trouble, Bypass, Alert
and Alarm are also provided. Other features include:
f4-wire connection using standard alarm cable
fInternal sounder
fBacklit keyboard
LCD Remote Keypad
The LCD keypad features a 2 x 20 character blue display for
showing all zone status and system fault messages. A set of
dedicated system status LEDs for AC, Trouble and Alert are also
provided. Other features include:
f4-wire connection using standard alarm cable
fInternal sounder
fBacklit keyboard
USB-Link
The USB-Link provides USB connectivity between the ACP10 and
the host computer. It is required when a direct connection is
required between the AlcoUDL software package and the ACP10
control panel.
AlcoUDL Upload/Download Software
This Windows based software can be used to remotely or locally
program and diagnose the Alco range of security systems.
Features include:
fSimple intuitive user interface
fLocal or remote via modem
fAdvanced system diagnostics
fSystem audit trail
fRemote servicing

6 P0016-LI-00.00
2. Installation
Installation Sequence
Before attempting to install the alarm system, read this section.
Once you have an overall understanding of the installation
sequence, carefully work through each step.
1. Design the Layout
Make a rough sketch of the premises to get an idea of where all
alarm detection devices, keypads and other modules are to be
located.
2. Mounting the Control Panel
The control panel must be mounted within the protected area
close to an unswitched AC power source and the incoming
telephone line.
You must complete all wiring before connecting the battery, or
applying AC to the panel.
3. Install the Remote Keypads
Mount the remote keypads at locations that are easily accessible
during entry and exit from the protected area. Connect the remote
keypads to the control panel.
4. Zone Wiring
Install detection devices and connect to control panel or
expander.
5. Other Wiring
Complete all other wiring including external/internal sounders
and telephone line connections.
6. Apply Power to the Control Panel
Once steps 1 to 5 are completed, apply power to the control
panel. First, connect the red battery lead to the positive terminal
and the black lead to negative. Then, connect the AC.
7. Program the System
If available use the AlcoUDL software package to program the
system, if this is not available program this system in accordance
with the procedures in Section 3.
8. Testing the System
Test the system thoroughly to ensure that all features and
functions are operating as required.
Control Panel
Mounting
Mount the control panel on a flat, plumb wall using at least three
appropriate screws. The rear casing has been designed with a
central key-hole slot so that mounting is possible without
removing the Printed Circuit Board (PCB).
The angled slot in the lower corner has been provided to allow the
panel to be levelled easily. If the PCB has to be removed, carefully
pull back the two front PCB securing clips, lift the front of the PCB
and slide it downward. To replace the PCB simply reverse the
above procedure.
It is essential to ensure that none of the fixing slots or cable
entries are accessible after fixing.
Mains cabling must be secured (e.g. with a cable tie) to one of the
anchor points provided.
Wiring the Control Panel
WARNING: ELECTRICITY CAN KILL
BEFORE connecting the control panel ALWAYS
disconnect the supply at the consumer unit.
If in ANY doubt consult a qualified electrician.
ONLY connect the mains supply to the mains terminal
block, NEVER connect the mains supply directly to the
PCB.
The system installation MUST be carried out in
accordance with the national safety standards, for
example EN 60950: 1992.
ALWAYS refer to National Wiring Regulations when
conducting installation.
An appropriate and readily accessible disconnection
device (e.g. an unswitched fused spur) MUST be
provided as part of the installation.
The disconnection device must NOT be fitted in a
flexible cord.
Where identification of the neutral in the mains supply
is NOT possible, a two-pole disconnection device MUST
be used.
The building mains supply MUST incorporate
appropriate short-circuit backup protection (e.g. a fuse
or circuit breaker) of High Breaking Capacity (HBC, at
least 1500A).
Use mains cable of adequate carrying capacity for the
rated current (i.e. at least 0.75mm2).

P0016-LI-00.00 7
Control Panel Layout
1
3 4 5
2
1. Main Printed Circuit Board (PCB)
The main PCB that provides the terminals connection to remote
keypads and detection devices, see PCB Layout on next page for
full details.
2. Switched Mode Power Supply
The switch mode power supply module is housed under this
protected area and provides power to the main PCB via the three-
way harness.
3. Mains Connection
The AC Mains supply is connected to a 3 way Euro Type fused
terminal block, which is fitted with a 500mA fuse.
Fuse T500mA
L
E
N
To Power Supply
Module
4. Mains Supply Cable Entry
The mains supply cable must be routed into the control panel
housing via this cable entry.
5. Standby Battery
The system housing will accept a 12V 7Ah battery to provide
continued operation in the event of an AC mains failure. Connect
the red battery lead to the positive terminal of the battery and
then connect the black battery lead to the negative terminal.
The system will only become “live” when the AC supply is
connected or the “Battery On” pins are shorted.
ACP10
Control Panel
RD
Network
BAT
12V 7Ah
Sealed Lead Acid Battery

8 P0016-LI-00.00
PCB Layout
1
2
3
4 5 6 7 6 8 9 10 11
12
13
14
15
161616171618
1. PSU Connector
The harness from the switched mode power supply module plug
onto this connector and provides the power (13.7V) to power the
system.
2. Engineer’s Remote Keypad Connector
An engineer’s remote keypad maybe plugged onto to this
connector so that system programming and testing can be carried
out at the location of the control panel.
3. Lid Tamper Switch
This switch detects when the cover is in position and the screw is
fully secured. The tamper is designed to activate when the screw
is undone.
4. Battery Connections
A 12V rechargeable battery must be connected to these two
terminals in order to provide continuous system operation in the
event of mains failure. The battery output is protected by an auto
resetting fuse (PTC) rated at 1.6 Amp.
5. Network Connections
The network terminals provide connections to the remote keypads
and zone expanders. The + and – terminals provide power whilst
the R and R terminals are the data signals.
6. Zone Inputs 1 to 10
Detection devices such as movement sensors, vibration and door
contacts are connected to the zone input terminals. There are
several ways in which to wire a detection device (see page 11).
Each zone is fully programmable, see page 18 for information on
programming zones.
7. Auxiliary 12V
These terminals provide auxiliary power for detection devices that
require 12V power, e.g., moment sensors. The auxiliary output is
protected by an auto resetting fuse (PTC) rated at 1.1 Amp).
8. Speaker
These terminals are used for driving 16Ωextension loudspeakers
(see page 12).
9. Bell Tamper Return
This terminal is connected to the tamper return connection from
an external sounder unit. If it is not required link it to 0V.
10. External Sounder 12V
These terminals provide power for external sounder units. The
output is protected by an auto resetting fuse (PTC) rated at 1.1A.
11. Panel Outputs 1 to 5
These are fully programmable high current (1 Amp), switched
negative supervised outputs. Panel outputs 1 and 2 default to bell
and strobe operation, but can be programmed for other functions
if required, see page 27 for programming details. Each output can
also be programmed for supervision monitoring, see page 24.
12. Two-Wire Smoke Detector Enable
Set this link as shown when connecting 2-wire smoke detectors to
Panel Output 5.
2-wire Smoke Detectors Enabled: Panel Output 5
must be programmed as “2-wire Smoke” (0047)
and smoke detectors must be connected as shown
page 13.
2-wire Smoke Detectors Disabled: Panel Output 5
will function as a normal output.
13. Communication Ports 1 and 2
Two serial communication ports 1 and 2 are provided for local
downloading and for third party devices.
14. RJ11 Telephone Line Connector
An RJ11 connector is provided so that the panel can be
connected to the telephone line via a standard RJ11 patch lead.
15. Telephone Line Connections
Telephone line connections (see page 14).
16. Power/Status LED
On steady when either AC or standby battery is present. Flashes
when the on-board communicator is dialling or sending data.
17. Battery Charging Rate
The standby battery can be recharged at different rates:

P0016-LI-00.00 9
300mA: This is the recommended charge rate for a
7Ah standby battery. The system will fully recharge a
flat battery within 24hours.
750mA: This is the recommended charge rate for a
17Ah standby battery. The system will fully recharge
a flat battery within 24hours.
18. Battery On (Kick Start)
When powering the system from battery only, the “Battery On”
pins must be momentarily shorted together with a plain blade
screwdriver or similar to kick start the power supply into
operation.

10 P0016-LI-00.00
Connecting Devices to the Network
Before connecting devices to the control panel network, isolate
ALL power from the control panel (AC Mains & Battery). Do not
continue if there is still power present on the control panel.
Connecting devices with power still present on the
control panel may damage the device or control panel
and invalidate any warranty.
Remote keypads and zone expanders are all connected to the
same network terminals located at the bottom left hand corner of
the control panel and may be connected serially (daisy chain), in
parallel (star) or any combination of the two.
Network Connections
The network is made up of four terminals incorporating power and
data. To ensure correct operation, all four terminals on the device
must be connected to the corresponding terminals on the control
panel, or previous device. The table below shows each terminal
and its description:
+ +12V Supply
- 0V Supply
R Data Return
D Data I/O
ACP10
Control Panel
Network
500 metres
Remote Keypad
Address = 1
12V
RD
0V
Remote Keypad
Address = 2
Remote Keypad
Address = 3
Remote Keypad
Address = 4
RD
12V
RD
0V
12V
RD
0V
12V
RD
0V
Cable Type and Distances
For improved immunity to electrical noise, the use of screened 4
core cable is recommended. The screen should be twisted
together and wired into the (–) terminal at the control panel only.
The maximum recommended distance for devices when using
standard 7/0.2 alarm cable is:
f250m for each branch when using the star (parallel)
configuration
fWhen using a daisy chain (series) configuration the
maximum distance will depend on the number of devices
connected on the chain. The more devices that are
connected, the shorter the distance to the last device (this is
due to voltage drop in the cable)
Whichever method of wiring configuration is used, ensure that the
voltage between the ‘+’ and ‘–’ terminals at each device is no
lower than 10.0V when the system is running on the standby
battery.
Overcoming Voltage Drop
There are several ways to overcome voltage drop:
fUse thicker lower resistance cable. Standard 7/0.2 alarm
cable has a resistance of 8Ωper 100m
fDouble up on the power connections – this will require using
a 6 or 8-core cable rather than a 4-core cable
fInstall a power supply to power the device locally, remember
to common the two negative connections
Installing a Power Supply
When a power supply is installed, the 0V connections on the
power supply must be connected through to 0V on the control
panel and the +12V connection between the control panel and
the device must be disconnected (see figure below).
ACP10
Control Panel
Network
500 metres
Remote Keypad
Address = 1
12V
RD
0V
Remote Keypad
Address = 2
Remote Keypad
Address = 3
Remote Keypad
Address = 4
RD
12V
RD
0V
12V
RD
0V
12V
RD
0V
1km
Power Supply
12V
0V
Disconnect +12V
from control panel

P0016-LI-00.00 11
Remote Keypads
PCB Layouts
3
4
2 1
LED Remote Keypad
1
2
3
4
LCD Remote Keypad
1. Network Connections
The remote keypad is connected to the network terminals located
at the bottom left hand side of the PCB.
2. Address Selection
Each remote keypad must be assigned a different address using
the Address selector. Move the jumper to the required position 1,
2, 3 or 4.
3. Tamper Switch
The lid tamper for each remote keypad can be enabled or
disabled if required. Please refer to page 26 for further details.
4. Piezo Sounder
The piezo sounder generates low level alarm, key press, and
warning tones. Each type of tone can be enabled or disabled for
each remote keypad, please refer to page 26 for further details.
Wiring Detection Devices
The ACP10 provides 10 zones for connecting detection devices
such as movement sensors and magnetic door contacts. Each
zone is fully programmable to allow for maximum flexibility (see
page 18 for Zone Programming details). The program options for
a zone will also determine how the zone may be wired. The
following wiring options are available:
Normally Closed
This wiring configuration should be used when connecting
detection devices that only have a normally closed alarm output.
Connect the detector as shown below and ensure that the zone is
programmed for “Normally Closed” operation, see page 19.
Zy
Zx Com
Alarm
1 Detector
Alarm
Alarm
2 Detectors
Normally Open
This wiring configuration should be used when connecting
detection devices that only have a normally open alarm output.
Connect the detector as shown below and ensure that the zone is
programmed for “Normally Open” operation, see page 19.
Zy
Zx Com
Alarm
1 Detector
2 Detectors
Alarm
Alarm

12 P0016-LI-00.00
Single EOL - N/C
This wiring configuration should be used when connecting
detection devices that only have a normally closed alarm output.
Connect the detector as shown below and ensure that the zone is
programmed for “Single EOL – N/C” operation, see page 19.
Zy
Zx Com
3K3
3K3
1 Detector
2 Detectors
Alarm Alarm
Alarm
Double EOL
This wiring configuration should be used when connecting
detection devices that have a normally closed alarm and tamper
output. Connect the detector as shown below and ensure that the
zone is programmed for “Double EOL” operation, see page 19.
Zy
Zx Com
1 Detector
2 Detectors
Alarm
Tamper
E.O.L
Alarm
Tamper
Alarm
Tamper
E.O.L
4K7
2K2
4K7
4K7
2K2
Triple EOL
This wiring configuration should be used when connecting
detection devices that support triple EOL configuration, this will
allow the system to monitor alarm, tamper fault and mask.
Connect the detector as shown below and ensure that the zone is
programmed for “Triple EOL” operation, see page 19.
Zy
Zx Com
1 Detector
Fault
Alarm
E.O.L
2K2
2K2
4K7
Tamper
Loudspeaker Connections
The ACP10 has a loudspeaker output capable of driving one 16Ω
or two 8Ωwired in series as shown below:
16 LoudspeakerΩ
8 LoudspeakerΩ
8 LoudspeakerΩ
SPK
SPK
The volume level can be programmed, please refer to page 23 for
details. The loudspeaker can also be tested, please refer to page
23 for further details.

P0016-LI-00.00 13
External Sounder/Strobe Connections
The following connections are available for connection to an
external sounder/strobe unit:
TR
Tamper Return input. Connect to the tamper output on the
external sounder/strobe unit. If this input is not used it must be
linked to 0V.
0V
0V supply. Connect to the 0V (-) supply on the external
sounder/strobe unit.
+12
Positive 12V supply, which is protected by an auto resetting fuse
(PTC) rated at 1.1A. Connect to the +12V (+) supply on the
external sounder/strobe unit.
Bell (1)
Panel output 1 is pre-configured for Bell operation, i.e. it switches
to 0V when active. Connect this terminal to the bell trigger input
on the external sounder/strobe unit. The output can be inverted
for SCB operation, see page 27 for details.
Strobe (2)
Panel output 2 is pre-configured for Strobe operation, i.e., it
switches to 0V when active. Connect this terminal to the strobe
input on the external sounder/strobe unit.
ACP10
Control Panel
12V
TR 0V 12
External Sounder
Tamper
0V
+12V Suppy
Bell -ve
Strobe -ve
Panel Outputs 1 - 5
The control panel has five programmable outputs, which can be
used to drive auxiliary devices such as LEDs, sounders or relays
etc. (see page 27 for details on programming outputs). Each
panel output is rated at 1 Amp and switches to 0V when active.
The figure bellow shows some wiring examples:
ACP10
Control Panel
OP
12V
Relay Driver
+
-
12V Relay
ACP10
Control Panel
OP
12V
1K
cathode
anode
LED Indicator
LED
ACP10
Control Panel
OP
12V
Buzzer Driver
+
-
12V Buzzer
2-Wire Smoke Detectors
A maximum of 10, 12V 2-wire smoke detectors can be connected
to the control panel using panel output 5. The detectors must be
connected as shown below. The Enable 2-wire jumper link must
be set as shown and the output must be programmed for “2-wire
Smoke” (0047) operation, see page 27 for details.
A Maximum of 10 2-Wire Smoke Detectors
can be connected to panel output 5
ACP10
Control Panel
5
12V
VIn
0V
V Out
VIn
0V
V Out
E.O.L
1K

14 P0016-LI-00.00
Telephone Line Connections
The control panel has an advanced onboard communicator and
modem, which can be used for the following:
fSending digital alarm status information to an alarm
receiving centre using industry standard protocols
fSending voice messages to a mobile or landline telephone
fRemote uploading/downloading via AlcoUDL software
package
If any of these features are used, a permanent telephone
connection should be made to the control panel as shown:
In from telephone provider
Out to premises telephone
ACP10
Control Panel
R1
T
R
T1
Commissioning
Once ALL connections have been made to the control panel and
power is ready to be applied, you should read this section before
continuing.
The control panel leaves the factory programmed with default
settings and when the system is powered up for the first time the
default settings are in use. If the factory defaults need to be
reloaded in the future, please see “Power-up Options Menu”.
fConnect the black battery lead to the negative (–) terminal of
the standby battery and the red battery lead to the positive
(+) terminal of the standby battery. The green power LED on
the main PCB will light.
fIf the system enters into an alarm condition, enter the
default master user code 5678. The alarm tone will
then stop.
fTo access the Engineer Programming Menu, enter the
default engineer code 1234. The remote keypads will
show:
En
Engineers Menu
Location:----
LED LCD
fProgram the system as described in the next section
(Programming the Control Panel).
fCarry out a walk test as described on page 37. Remember
that some powered detectors (e.g. PIRs and combined
technology detectors) take several minutes to warm up
before they become operational.
fTest the internal sounder, external sounder and strobe as
described on page 37.
fReplace the lid and secure with the lid screw supplied - do
not over-tighten.
fEnter *99 to leave the programming menus.
fThe Service light will be flashing to indicate that action is
required. Switch on the mains supply to the control panel.
The Service light will stop flashing and stay on continuously.
Installation is now complete and the system is ready for use.
Please ensure the system users are provided with adequate
training on operating the alarm system.
Power-Up Options Menu
When power is applied to the system, the control panel enables
the “Power-Up Options Menu” for 10 seconds. During this period
the control panel status LED flashes between red and green and
the system will accept the following commands:
Command Description
*0#
Default Engineer Code
Entering this command will set engineer access code
back to 1234.
*3#
Save as Factory Defaults
Entering this command will save the current control
panel program configuration as the NEW factory
default profile.
*6#
Set UDL Password
Entering this command will set the UDL password to
123456.
*9#
Load Factory Defaults
Entering this command will set all control panel
program configuration options to the factory default
settings.

P0016-LI-00.00 15
3. Programming the Control Panel
Introduction
This section covers the system programming and it is important
that all engineers read this section carefully so as to familiarise
themselves with the many features and functions of the control
panel. To access the programming menu, enter the factory default
engineer code 1234. If a mistake is made whilst entering the
code, simply re-enter the code correctly.
When the system is in Engineers Mode, ALL zones and
tampers are disabled.
Each programming option is accessed by a four digit location
number followed by *. The location numbers have been grouped
together into logical sections. The programming sections are as
follows:
Section Page
1Zone Programming
1Zone Types
2Wiring
3Zone Attributes
4Reserved
5Bypass Options
6Chime Options
7Soak Test
8Zone Text
9Zone Links
18
2Arming Options
0Full Arm Options
1Stay Arm 1 Options
2Stay Arm 2 Options
3Stay Arm 3 Options
21
3 System Configuration
1System Timers
2 System Counters
3Hardware Options
4Configuration
5Control Timers
6Banner Text
7Voice Message Links
8Voice Message Options
9System Output Links
23
4 Keypad Options
1Keypad Options 1
1Keypad Options 2
1Keypad Sounds
26
5 Reserved
6 System Devices
1Panel Outputs
2Com Ports
3GSM Module
4TCP/IP Configuration
27
7 Onboard Communicator
0ARC 1 - 4 Configuration
1Options
2Fast Format
3Speech Dialler
4UDL Options
31
Section Page
8Users
1User Code
2User Type
3User Time Locks
4User Name
5User Link
36
9Utilities
0Set Time and Date
Exiting Engineer’s Program Mode
To exit the engineers programming menus and return to the
normal disarmed mode, ensure the display is prompting you to
enter a location number then enter 99*.
Menu Navigation and Data Entry
Each programming location is accessed by entering its four digit
location number followed by *. If you don’t know the exact
location you can enter less than four digits and the panel will take
you to the first location that starts with numbers you have
entered. For example if you enter 12 the panel will take you to
location 1201 – Zone 01 Wiring Type.
Selection List
This type of data entry is used when selecting an option from a
predefined list. Each item in the list has a number and associated
description. When using the LCD keypad for programming the
description is displayed. The LED keypad can only display the
number. The figures below show the programming procedure for
both LED and LCD remote keypads:
Selection List: LED Keypad
En
1 1 0 1
Enter Engineers code
????
Enter location No
e.g. 1101
????
Press to display
the current value
*
1 1 0 1 =1
Location number & current
value are displayed.
Enter item number, e.g., 04
1 1 0 1 =4
Press to accept
and return to step
*
Ì
Press to cancel
and return to step
R
Ê
Press to accept
and move to next location
#

16 P0016-LI-00.00
Selection List: LCD Keypad
Engineers Menu
Location:----
Engineers Menu
Location:1101
Zone 01 Type
Final Exit 1
Zone 01 Type
Intruder
Zone 01 Type
04
Enter Engineers code
????
Enter location No
e.g. 1101
????
Press to display
the current value
*
Press to scroll through
list options or enter item
number, e.g., 04
B
To display the item number
press and hold any
number key.
Press to accept
and return to step
*
Ì
Press to cancel
and return to step
R
Ê
Press to accept
and move to next location.
#
Bit Toggle Selection
This type of data entry is used for enabling and disabling up to 8
options. Each option is represented by a number 1 to 8 and has
an associated description. When using the LCD keypad for
programming the description can be displayed by holding down
the bit option number, the LED keypad can only display the
number. The figures below show the programming procedure for
both LED and LCD remote keypads:
Bit Toggle Selection: LED Keypad
En
1 3 0 1
Enter Engineers code
????
Enter location No
e.g. 1301
????
Press to display
the current value
*
Location number & current
options are displayed.
Options2&5areenabled.
1 3 0 1 =2 =5
Use keys to to toggle
options on or off, e.g, press
2 to turn option2 off.
18
1 3 0 1 =5
Press to accept
and return to step
*
Ì
Press to cancel
and return to step
R
Ê
Press to accept
and move to next location
#
Bit Toggle Selection: LCD Keypad
Engineers Menu
Location:----
Engineers Menu
Location:1301
Zone 01 ttributes 1
.2..5..
Enter Engineers code
????
Enter location No
e.g. 1301
????
Press to display
the current value
*
To display the option
description press and hold
the option number key.
Press to accept
and return to step
*
Ì
Press to cancel
and return to step
R
Ê
Press to accept
and move to next location.
#
Location number & current
options are displayed.
Options2&5areenabled.
Use keys to to toggle
options on or off, e.g, press
2 to turn option2 off.
18
Zone 01 ttributes 1
....5..
uto rearm
....5..

P0016-LI-00.00 17
Number Entry
This type of data entry is used for entering numeric values, such
as timers. The figures below show the programming procedure for
both LED and LCD remote keypads:
Number Entry: LED Keypad
En
3 1 0 1
Enter Engineers code
????
Enter location No
e.g. 3101
????
Press to display
the current value
*
Press to accept
and return to step
*
Ì
Press to cancel
and return to step
R
Ê
Press to accept
and move to next location
#
3 1 0 1 =0
Location number & current
value are displayed (0).
Enter required value, e.g, 35.
3 1 0 1 =3 5
Number Entry: LCD Keypad
Engineers Menu
Location:----
Engineers Menu
Location:3101
System Timers
C Fail:000
Enter Engineers code
????
Enter location No
e.g. 3101
????
Press to display
the current value
*
Press to accept
and return to step
*
Ì
Press to cancel
and return to step
R
Ê
Press to accept
and move to next location.
#
System Timers
C Fail:035
Location number & current
value are displayed (0).
Enter required value, e.g, 35.
String Edit - Number Mode
This type of data entry is used for entering a long string of
numbers, such as telephone and account numbers. The figures
below show the programming procedure for both LED and LCD
remote keypads:
String Edit - Number Mode: LED Keypad
En
7 0 1 1
Enter Engineers code
????
Enter location No
e.g. 7011
????
Press to display
the current value
*
Press to accept
and return to step
*
Ì
Press to cancel
and return to step
R
Ê
Press to accept
and move to next location
#
7 0 1 1 =
Enter required value,
e.g, 1234.
To clear value press &
*R
1 2 3 4
Location number & current
value are displayed (blank).
7 0 1 1 =
String Edit - Number Mode: LCD Keypad
Engineers Menu
Location:----
Engineers Menu
Location:7011
RC 1 ccount
ÿ
Enter Engineers code
????
Enter location No
e.g. 7011
????
Press to display
the current value
*
Press to accept
and return to step
*
Ì
Press to cancel
and return to step
R
Ê
Press to accept
and move to next location.
#
RC 1 ccount
1234ÿ
Enter required value,
e.g, 1234.
To clear value press &
*R
Location number & current
value are displayed (blank).

18 P0016-LI-00.00
String Edit - Text Mode
This type of data entry is used for entering text such as user
names and zone text. This mode is designed only for the LCD
keypad. The text is entered in the same way as entering text on a
mobile telephone. Each key is mapped to one or more letters.
Pressing a key will select the first letter, pressing it again will
select the next etc. The table below shows the keys to use and the
characters that are assigned to them:
Key Characters
1 1
2 A B C 2 a b c
3 D E F 3 d e F
4 G H I 4 g h i
5 J K L 5 j k l
6 M N O 6 m n o
7 P Q R S 7 p q r s
8 T U V 8 t u v
9 W X Y Z 9 w x y z
0 _ 0 . - ( ) #
B Clear all characters
The figures below show the programming procedure for LCD
remote keypads:
String Edit - Text Mode: LCD Keypad
Engineers Menu
Location:----
Engineers Menu
Location:1801
Zone 01 Text
ÿ
Enter Engineers code
????
Enter location No
e.g. 1801
????
Press to display
the current value
*
Press to accept
and return to step
*
Ì
Press to cancel
and return to step
R
Ê
Press to accept
and move to next location.
#
Zone 01 Text
H LLÿ
Use text editing keys
to enter text, e.g, HALL
Location number & current
value are displayed (blank).
1. Zone Programming
This section covers programming of the detection zones, each
zone must programmed a zone type, wiring type and attributes.
Zone Type
Each zone must be programmed to the correct type in order for
the correct response.
Locations: 1101 to 1110
Zone 01 to 10: Zone Type.
Entry Mode: Mode: Selection List (see page 15).
00 Not Used
Use this zone type for unused zones, as zone programmed as
“Not Used” are not be monitored by the system.
01 Final Exit 1
Use this zone type for the main entry/exit detector, normally a
magnetic contact on the front door. The zone can be activated
during the exit mode without causing a fault. If the system is
armed, activation of the zone will start the Entry 1 Delay timer for
the relevant arm mode.
02 Final Exit 2
Use this zone type for an alternative entry/exit detector. The zone
can be activated during the exit mode without causing a fault. If
the system is armed, activation of the zone will start the Entry 2
Delay timer for the relevant arm mode.
03 Walk Through
Use this zone type for detection devices along the entry/exit
route. This zone type will allow the user to walk past the detector
without causing a fault during the exit mode or an Intruder alarm
during the entry mode. However, if activated at any other time the
zone will cause an immediate intruder alarm. This zone type will
also start the entry mode when the system is stay armed.
04 Intruder
Use this zone type for detection devices such as PIR’s, vibration
detectors, magnetic door contacts etc. This zone type generates
an intruder alarm if activated when the system is armed.
05 Perimeter
Use this zone type for detection devices such as external PIR’s, IR
beams. This zone type generates an intruder alarm if activated
when the system is armed.
06 Fire
Use this zone type for smoke and heat detectors. This zone type
generates a distinctive fire alarm if activated at any time.
07 PA Silent
Use this zone type for panic buttons. This zone type generates a
silent panic alarm if it is activated at any time.
08 PA Audible
Use this zone type for panic buttons. This zone type generates an
audible panic alarm if it is activated at any time.
09 Medical
Use this zone type for medical alarms. This zone type generates a
medical alarm if it is activated at any time.
10 24 Hour
Use this zone type for detectors that require 24 hour monitoring.
This zone type generates an intruder alarm if it is activated when
the system is armed. If activated during the disarmed state an
internal alarm is generated.
11 Tamper
Use this zone type for tamper protection. This zone type generates
a tamper alarm if it is activated when the system is armed. If

P0016-LI-00.00 19
activated during the disarmed state an internal alarm is
generated.
12 Exit Terminator
Use this zone type for external push to set buttons. This zone type
terminates the exit delay when activated during exit mode. The
arming mode must be configured for “Exit Terminator” for this
zone type to function.
13 Away Arm Key
Use this zone type for a key switch or lock that has switch
contacts. This zone type will away arm the system when active
and disarm the system when healthy. If a “momentary” operation
is required then the “Momentary Keyswitch” attribute can be
assigned, see page 20.
14 Stay 1 Arm Key
Use this zone type for a key switch or door lock that has switch
contacts. This zone type will stay arm (1) the system when active
and disarm the system when healthy. If a “momentary” operation
is required then the “Momentary Keyswitch” attribute can be
assigned, see page 20.
15 Stay 2 Arm Key
Use this zone type for a key switch or door lock that has switch
contacts. This zone type will stay arm (2) the system when active
and disarm the system when healthy. If a “momentary” operation
is required then the “Momentary Keyswitch” attribute can be
assigned, see page 20.
16 Stay 3 Arm Key
Use this zone type for a key switch or door lock that has switch
contacts. This zone type will stay arm (3) the system when active
and disarm the system when healthy. If a “momentary” operation
is required then the “Momentary Keyswitch” attribute can be
assigned, see page 20.
17 Bypass Key
Use this zone type for a key switch or door lock that has switch
contacts. This zone type will bypass all zones with the bypass
attribute when active and reinstate them when healthy. If a
“momentary” operation is required then the “Momentary
Keyswitch” attribute can be assigned, see page 20.
18 Security Key
Use this zone type for a key switch. This zone type will disable all
remote keypads when active and reinstate them when healthy. If
a “momentary” operation is required then the “Momentary
Keyswitch” attribute can be assigned, see page 20.
19 Auxiliary
Use this zone type for auxiliary devices, which do not require an
audible alarm response. This zone type generates a silent alarm if
activated at any time.
20 Warning
Use this zone type for monitoring devices that require a warning
indication. This zone type generates a warning (low level beeps
from the keypad every 30 seconds and zone indication) if the
zone remains active for longer than the warning delay time, see
page 23 for details.
21 Log/Monitor
Use this zone type for monitoring devices that require an event log
entry. This zone type generates a log entry if activated at any time.
22 Trouble/Fault
Use this zone type for monitoring fault outputs on devices such as
remote power supplies. This zone type generates a fault condition
if it is activated at any time.
Zone Wiring
Each zone must be programmed to the correct wiring type in order
for the correct response.
Locations: 1201 to 1210
Zone 01 to 10: Zone Wiring.
Entry Mode: Mode: Selection List (see page 15).
0 Normally Closed
Use this wiring type for normally closed detection devices.
1 Normally Open
Use this wiring type for normally open detection devices.
2 Single EOL - N/C
Use this wiring type for normally closed detection devices.
3 Double EOL
Use this wiring type for detection devices that require both alarm
and tamper monitoring.
4 Triple EOL
Use this wiring type for detection devices that require alarm,
tamper, fault and anti-mask monitoring.
Zone Attributes
Each zone can have one or more optional attributes programmed
to further alter its functionality.
Locations: 1301 to 1310
Zone 01 to 10: Zone Attributes.
Entry Mode: Bit Toggle Selection (see page 16).
1 Double Knock
On: When a zone is enabled for Double Knock it will only cause
an alarm when:
(a) The zone remains active for the duration of the “Double
Knock Delay”.
(b) The zone is violated twice within the “Double Knock
Delay”.
(c) If any two zones with the “Double Knock” attribute are
activated during the “Double Knock Time Window”.
Off: The zone functions as normal.
2 Enable Comms
On: The on-board communicator will report the alarm status to
the monitoring station when the zone causes an alarm.
Off: The alarm status is not transmitted.
3 Reset
On: Zones with this attribute will not be monitored during the
detector reset period. The detector reset occurs when the
exit mode is started or when the user resets the system after
an alarm. Detection devices such as smoke detectors that
are powered from an output programmed as “Detector
Reset” should have this attribute switched on.
Off: The zone functions as normal.
4 Zone Response
On: Zones with this attribute respond at the response rate
determined by the “Zone Response Timer”.
Off: The zone functions as normal.
5 Auto Rearm
On: Zones with this attribute will only re-arm at the end of the
bell duration providing that the “Auto Re-Arm Counter” limit
has not been reached. Once this limit has been reached, the
zone will lock out and not cause any further Intruder alarms.
Off: The zone will always re-arm.

20 P0016-LI-00.00
6 Remote Detector Test
On: Zones with this attribute are monitored for specific activity
during the remote detector test. The detector must be
connected to the control panel using triple EOL wiring and
the detector remote test input must be connected to a panel
output programmed as “Remote Detector Test”.
Off: The zone functions as normal.
7 Momentary Keyswitch
On: If the zone type is a keyswitch type, the operation mode is
changed to momentary.
Off: If the zone type is a keyswitch type, the operation remains as
latching mode.
Zone Bypass Options
Each zone can have one or more optional bypass attributes
programmed to control when the zone is bypassed.
Locations: 1501 to 1510
Zone 01 to 10: Zone Bypass Options.
Entry Mode: Bit Toggle Selection (see page 16).
1 In Stay 1
On: The zone is bypassed when Stay 1 arming mode is selected.
Off: The zone is not bypassed when Stay 1 arming mode is
selected.
2 In Stay 2
On: The zone is bypassed when Stay 2 arming mode is selected.
Off: The zone is not bypassed when Stay 2 arming mode is
selected.
3 In Stay 3
On: The zone is bypassed when Stay 3 arming mode is selected.
Off: The zone is not bypassed when Stay 3 arming mode is
selected.
4 By User
On: The zone can be bypassed by the user when arming the
system.
Off: The zone cannot be bypassed by the user.
5 Auto Bypass
On: The zone is automatically bypassed at the end of exit mode if
the zone is still active.
Off: The zone is not bypassed at the end of exit mode, and the
system will fail to arm if the zone remains active.
6 Keyswitch Bypass
On: The zone is bypassed when a “Bypass Key” zone type is
active and reinstated when the “Bypass Key” is secure.
Off: The zone is not bypassed when a Bypass Key is operated.
7 Cleaner
On: The zone is bypassed when a cleaner code is entered.
Off: The zone is not bypassed when the cleaner code is entered.
Zone Chime
Each zone can have an optional chime mode programmed that
allows the panel and remote keypads to generate an audible tone
when the zone is activated in the disarmed mode.
Locations: 1601 to 1610
Zone 01 to 10: Zone Chime.
Entry Mode: Mode: Selection List (see page 15).
0 Off
The zone will not generate a chime tone.
1 Tone 1
The zone generates chime tone 1 when activated in the disarmed
mode.
2 Tone 2
The zone generates chime tone 2 when activated in the disarmed
mode.
3 Tone 3
The zone generates chime tone 3 when activated in the disarmed
mode.
Zone Soak Test
Each zone can be put on test for a programmed soak test period.
When a zone is on test it will not cause an alarm if activated, but
the system will record the failure in the event log and indicate the
fault to the user.
Locations: 1701 to 1710
Zone 01 to 10: Zone Soak Test.
Entry Mode: Mode: Selection List (see page 15).
0 No
The zone is not on soak test.
1 Yes
The zone is on soak test.
Zone Text
Each zone can be assigned a 20 character label that is displayed
on LCD remote keypads when viewing the zone status and event
log.
Locations: 1801 to 1810
Zone 01 to 10: Zone Text.
Entry Mode: String Edit - Text Mode (see page 18).
Zone Link
Each zone can be assigned a “Link” number, which in turn is used
to control “Link Control” output types, for details on link control,
see page 29.
Locations: 1901 to 1910
Zone 01 to 10: Zone Link.
Entry Mode: Number Entry (see page 17).
