ALEXANDER ROSE 305 User manual

ALEXANDER ROSE ASSURANCE OF QUALITY
Home Address
For Information on all our products including treatments
Model Number
FOLD 2
available please visit our website: www.alexander-rose.co.uk
Seat Legs
Seats
Cross Rail Centre Plate
questionnaire, and for choosing Alexander Rose
West Sussex
Poor
Thankyou for taking the time to complete and return this
Signed
Hardware Bag
Trial Assembly Made
Other Comments
Contract Number
Quality Checked
TAPE THIS EDGE
Thank you for chosing to buy Alexander Rose Garden Furniture. We are confident that you will be pleased
BURGESS HILL
RH15 9LE
No
(Tick Boxes)
with the quality of the product. to ensure that the highest standards are maintained, please help us by
Upper Seat Legs
Assembly Instructions
completing this short questionnaire.
Good
Purchase Date:
Date
Ease of assembly
Condition of Product
Condition of Packaging
Average
Yes
Pressent in parcel
Inspector number
Stamp
Garden Centre Purchased From:
Top
Left Facing Cross Rails
Right Facing Cross Rails
Inner Seat Support Rails
Outer Seat Support Rails
Alexander Rose Ltd.
Alexander House
Victoria Road
Affix
Postage
FOLD 1
ref:ARL-305-6SeaterBelfryPicnicTable04-08-09
READ IN FULL BEFORE USING THIS PRODUCT
This product is very heavy. two people are required for assembly and moving
ref:ARL-305-6SeaterBelfryPicnicTable04-08-09
ALEXANDER ROSE
305 SIX SEATER BELFRY PICNIC TABLE
ASSEMBLY INSTRUCTIONS
Product Information
Your furniture is manufactured using FSC pine from Europe. This is treated with preservative to protect
against
decay, giving a lifespan in excess of ten years.
Under normal circumstances Pine cracks; this is due to its natural characteristics and will not
compromise the strength of your furniture, which is designed with this in mind.
Softwoods are prone to weather staining/blackening caused by moisture activating mould spores present
naturally in the wood.
Cleaner should remove this blackening.
We strongly recommend a twice yearly application of a water repellent preservative such as Cuprinol to
protect against fungal attack and blackening of the wood
Maintenance
Your furniture can be cleaned using soapy water and stiff brush. More severe stains such as spillages, bird
droppings. mildrew and blackening of the wood etc. can be removed using Alexander Rose Cleaner or
sanding using a medium grit sand paper.
Lifting grain or cracks can be glued using a waterproof adhesive suitable for timber. Clamping may be
necessary with excess glue being removed with a damp cloth. The area should be sanded once the glue is
dry.
Important Safety Notice
This Picnic Table is VERY HEAVY and requires at least TWO PEOPLE for assembly and THREE PEOPLE
when moving. Dragging yours table may cause damage to the legs. ALWAYS LIFT the table when moving
PLEASE RETAIN THESE ASSEMBLY INSTRUCTIONS FOR FUTURE REFERENCE.
A
L
E
X
A
N
D
E
R
A
L
E
X
A
N
D
E
R

H
J x 12
ref:ARL-305-6SeaterBelfryPicnicTable04-08-09
H
F
I
G
E
D
C
B
A
Before starting to assemble your furniture, identify and count all components of your chosen model,
Code Description Qty
H Seats 6
J Long M8 Allen Bolts 45
I Cross Rail centre plate 1
asshown in the table and drawings below. In the unlikely event that any components are missing or
K Short M8 Allen Bolts 3
L 5mm Allen Key 1
Dragging your table may cause damage to the legs. ALWAYS LIFT the table when
moving
Component Identification
PLEASE RETAIN THESE ASSEMBLY INSTRUCTIONS FOR FUTURE REFERENCE
damaged, please contact the retailer where you purchased this product.
G Upper Leg Rails 3
F Seat Legs 6
A Top 1
B Left Facing Cross Rails 3
C Right Facing Cross Rails 3
D Inner Seat support rails 3
(with pre fitted inserts)
E Outer Seat support rails 3
(without pre fitted inserts)
Important Safety Note
This picnic table is VERY HEAVY and requires at least TWO PEOPLE for
assembly and Moving
Always Lift The Table When Moving
Step 6 - Seat Bases
Attach Seat Bases using Long Allen Bolts
ref:ARL-305-6SeaterBelfryPicnicTable04-08-09

F
D
E
F
J x 4
Repeat this procedure with the other two sets of legs
A
K x 3
C
B
J x 12
I
(with pre-fitted thread inserts) using four long allen bolts, noting that the larger diameter holes in both
types of seat support rails face the outside as indicated. DO NOT TIGHTEN BOLTS FULLY YET
Step 2 - Attach Cross rails to Cross rail centre plate
Attach left and right hand cross rails to the cross rail centre plate, using the long allen bolts
Step 1 - Attach legs to seat support rails
Attach the seat support rail (without pre-fitted thread inserts) to two seat legs and a seat support rail
Step 5 - Attach Table Top to Upper Legs
Attach the Table Top to the Upper Legs using Short Allen Bolts
ref:ARL-305-6SeaterBelfryPicnicTable04-08-09
ref:ARL-305-6SeaterBelfryPicnicTable04-08-09

J x 6 J x 3
G
Step 4 - Attach Upper legs to Cross rails
Attach Upper Legs to cross rail assembly using long allen bolts
ref:ARL-305-6SeaterBelfryPicnicTable04-08-09
ref:ARL-305-6SeaterBelfryPicnicTable04-08-09
Step 3 - Attach legs to Cross rails
Attach Leg assemblies to cross rail assembly using long allen bolts
